Page 1
7-PIECE STRAIGHT & RIGHT ANGLE
DRILL SET
Model CHT622
Part No 1801622
USER INSTRUCTIONS
GC0709
Page 2
INTRODUCTION
Thank you for purchasing this CLARKE Straight & Right Angle Drill Set.
Before attempting to use this product, it is essential that you read this manual
thoroughly and carefully follow all instructions given. In doing so you will
ensure the safety of yourself and that of others around you, and you can also
look forward to the product giving you long and satisfactory service.
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of
12 months from the date of purchase. Please keep your receipt as proof of
purchase. This guarantee is invalid if the product is found to have been
abused or tampered with in any way, or not used for its intended purpose.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission. This guarantee does not effect
your statutory rights.
ENVIRONMENTAL PROTECTION
Do not dispose of this product with general household waste. All tools,
accessories and packaging should be sorted, taken to a recycling
centre and disposed of appropriately.
TECHNICAL SPECIFICATIONS
1. Right angle drive adaptor Chuck capacity 10 mm,
Hexagonal drive 8 mm.
2. Heavy Duty flexible drive shaft Chuck capacity 10 mm
Drive type (round) 8 mm.
3. 3/8” Chuck Key
4. Magnetic bit holder Hexagonal 6.35 mm drive, bit size
6.35 mm.
5. Flexible bit holder Hexagonal 6.35 mm drive, bit size
6.35 mm (max angle of bend
approx 28º).
6. Quick release bit adaptor Hexagonal 8 mm drive, bit size
6.35 mm
7. Countersink bit Hexagonal 6.35 mm drive,
max countersink dia 12.4 mm.
2
Page 3
USER INSTRUCTIONS
1. Insert and secure the chosen attachment into the chuck of your power
drill. Install a drill bit into the chuck of the right angle adaptor using the
chuck key provided or the long flexible adaptor and tighten securely.
• Never use with a drill in ‘hammer’ mode.
2. Set the drill to a reasonably slow speed, plug in and switch on.
3. When drilling, use a steady pressure, push the drill into the surface, do not
force the drill, allow the drill bit to do the work. It may be necessary to
adjust the speed to suit the size of drill bit and the material.
• As a general guide, the larger the hole, the slower the speed required,
also the harder the material being cut, the slower the speed.
4. Always store the attachments in the carry case after use.
SAFETY PRECAUTIONS
ALWAYS take care that your hands or clothing do not come into contact with
the chuck of the drill which drives these attachments. Beware of wearing
loose clothing & ensure cuffs are secured.
ALWAYS learn the applications, limitations and potential hazards relating to
the tool you are using. Read and become familiar with all operating
instructions.
ALWAYS wear safety goggles manufactured to the latest European Safety
Standards when drilling. Everyday eyeglasses do not have impact resistant
lenses and are not safety glasses.
ALWAYS check for damage before use and that the tool will operate
properly. If in doubt, do not use. Consult your local dealer. Any damage
should be properly repaired or the part replaced.
ALWAYS check for alignment of moving parts and any condition that may
affect operation.
ALWAYS keep work area clean. Cluttered areas invite accidents.
ALWAYS ensure that adequate lighting is available and that you will not be
working in your own shadow.
ALWAYS concentrate on the job in hand, no matter how trivial it may seem. Be
aware that accidents are caused by carelessness.
3
