Clarion PF-2945A-A, PF-2982B-A Service Manual

PF-2945A-A/PF-2982B-A

-1-

Service Manual

Model

SUBARU Automobile Genuine AM/
FM Radio CD/MP3/WMA Player

COMPONENT

PF-2945A-A / PF-2982B-A

1. Main unit

-----------

1

PF-2945A-A

(Genuine No. 86201FG600)
(ID No. CZ601U1)

SPECIFICATIONS

Tuner section

Tuning system: PLL Frequeency synthesizer system

Receive range: AM

530kHz to 1710kHz

(10kHz steps)

FM 87.75MHz to 107.9MHz

Intermediate frequency: AM 10.7 +0.03/-0.03MHz

FM 10.7 +0.03/-0.03MHz

Quieting sensitivity: AM Less than 39dBu

(at 20dB S/N)

FM Less than 15dBu

(at 30dB S/N)

Separation: FM More than 15dB

Auto stop sensitivity: AM 35 +6/-6dBu(DX)

55 +8/-8dBu(LO)

(PF-2945A-A)

41 +6/-6dBu(DX)

61 +8/-8dBu(LO)

(PF-2982B-A)

(600kHz, 1000kHz, 1400kHz)

FM 23 +6/-6dBu(DX)

(87.9MHz, 98.1MHz, 107.9MHz)

S/N ratio: AM More than 45dB

FM More than 50dB

CD section

Frequency Response: 17Hz to 20kHz

S/N ratio: More than 70dB (JIS-A)

Separation: More than 55dB (20kHz LPF)

MP3/WMA operations: MP3 Sampling rate 11.025kHz-48kHz,

Bit rate 8kbps-320kbps / VBR

WMA Bit rate 48kbps-192kbps

Logical format (File system);

ISO9660 level 1, 2 or JOLIET or Romeo

AUX section

Distortion: Less than 1.0% (20kHz LPF)

S/N ratio: More than 70dB (JIS-A)

Separation: More than 55dB (20kHz LPF)

General section

Load resistance: 4 ohm

Supply voltage: DC 13.2V

Negative ground

Max. power output: More than 16Wx4

Dimensions(mm): 205(W)x100(H)x157(D)

PF-2982B-A

(Genuine No. 86201SC600)
(ID No. CP603U1)

Weight: appro.1.75kg

Published by Service Dept.

Printed in P.R.C.

Clarion Co., Ltd.

7-2, Shintoshin, Chuo-Ku,Saitama-Shi, Saitama 330-0081, Japan

Service Dept.: 7-2, Shintoshin, Chuo-Ku,Saitama-Shi, Saitama 330-0081, Japan

Tel: [phone] FAX: [phone]

298-6487-00

Sep. 2007 X

CAUTION

Use of controls,adjustment,or performance of procedures
other than those specified herein,may result in hazardous
radiation exposure.
The compact disc player should not be adjusted or repaired
by anyone except properly qualified service personnel.

NOTE

*

We cannot supply PWB with component parts in principle. When
a circuit on PWB has failure, please repair it by component parts
base. Parts which are not mentioned in service manual are not
supplied.

*

Specifications and design are subject to change without notice for
further improvement.

*

Use only compact discs bearing the or mark.

*

Some CDs recorded in CD-R/CD-RW mode may not be usable.

* Windows Media , and the Windows logo are trademarks, or re-

gistered trademarks of Microsoft Corporation in the United States
and/or other countries.

* WMA is the abbreviation of Windows Media Audio, an audio file

format developed by Microsoft Corporation.

* This product includes technology owned by Microsoft Corporation

and cannot be used or distributed without a license from MSLGP.

* As for this model, the tuner of the DSP type is used.When

you exchange it due to the tuner pack(BL1:880-2091E) tro­uble, it is necessary to adjust for S-meter etc.Special JIG is
necessary for an accurate adjustment.The procedure docu­ment for the exclusive use jig is appended to it.

* This DSP IC SAF7730H(051-6706-50) of main PWB is exp-

osed die soldering pad type.The middle of this IC package
is soldered with the main PWB, and it cannot remove in an
ordinary soldering iron.Please use special removal JIG at
the time of IC exchange.

-2-

To engineers in charge of repair or inspe­ction of our products.

Before repair or inspection, make sure to follow the in­structions so that customers and Engineers in charge
of repair or inspection can avoid suffering any risk or
injury.

1. Use specified parts.
The system uses parts with special safety features against fire
and voltage. Use only parts with equivalent characteristics when
replacing them.
The use of unspecified parts shall be regarded as remodeling for
which we shall not be liable. The onus of product liability (PL) sh­all not be our responsibility in cases where an accident or failure
is as a result of unspecified parts being used.

2. Place the parts and wiring back in their original positions after re­placement or re-wiring.
For proper circuit construction, use of insulation tubes, bonding,
gaps to PWB, etc, is involved. The wiring connection and routing
to the PWB are specially planned using clamps to keep away
from heated and high voltage parts. Ensure that they are placed
back in their original positions after repair or inspection.
If extended damage is caused due to negligence during repair,
the legal responsibility shall be with the repairing company.

3. Check for safety after repair.
Check that the screws, parts and wires are put back securely in
their original position after repair. Ensure for safety reasons there
is no possibility of secondary ploblems around the repaired spots.
If extended damage is caused due to negligence of repair, the
legal responsibility shall be with the repairing company.

4. Caution in removal and making wiring connection to the parts for
the automobile.
Disconnect the battery terminal after turning the ignition key off.
If wrong wiring connections are made with the battery connected,
a short circuit and/or fire may occur.
If extensive damage is caused due to negligence of repair, the
legal responsibility shall be with the repairing company.

5. Cautions in soldering.
Please do not spread liquid flux in soldering.
Please do not wash the soldering point after soldering.

6. Cautions in soldering for chip capacitors
Please solder the chip capacitors after pre-heating for replacem­ent because they are very weak to heat.
Please do not heat the chip capacitors with a soldering iron dire­ctly.

7. Cautions in handling for chip parts.
Do not reuse removed chips even when no abnormality is obser­ved in their appearance. Always replace them with new ones.
(The chip parts include resistors, capacitors, diodes, transistors,
etc).

Please make an operation test after replacement.

8. Cautions in handling flexible PWB
Before working with a soldering iron, make sure that the iron tip
temperature is around 270 C. Take care not to apply the iron tip
repeatedly(more than three times) to the same patterns. Also ta­ke care not to apply the tip with force.

9. Turn the unit OFF during disassembly and parts replacement.
Recheck all work before you apply power to the unit.

10. Cautions in checking that the optical pickup lights up.

The laser is focused on the disc reflection surface through the
lens of the optical pickup. When checking that the laser optical
diode lights up, keep your eyes more than 30cms away from the
lens. Prolonged viewing of the laser within 30cms may damage
your eyesight.

11. Cautions in handling the optical pickup

The laser diode of the optical pickup can be damaged by elect­rostatic charge caused by your clothes and body. Make sure to
avoid electrostatic charges on your clothes or body, or discharge
static electricity before handling the optical pickup.

11-1. Laser diode

The laser diode terminals are shorted for transportation in order
to prevent electrostatic damage. After replacement, open the
shorted circuit.
When removing the pickup from the mechanism, short the ter­minals by soldering them to prevent this damage.

11-2. Actuator

The actuator has a powerful magnetic circuit. If a magnetic
material is put close to it. Its characteristics will change.
Ensure that not foreign substances enter through the ventila­tion slots in the cover.

11-3. Cleaning the lens

Dust on the optical lens affects performance.
To clean the lens, apply a small amount of isopropyl alcohol
to lens paper and wipe the lens gently.

Top view of Main unit

SERIAL NO.

PF-2945A-A/PF-2982B-A

ADJUSTMENT OF ZR1/PF3 DSP TUNER: 880-2091E

Setting

1 Open 2 switches of MICOM(EEP-ROM).

2 Open the Adjustment software:SUBARU_ZR1_ADJ_DSP_V307.exe

and turn on the unit.

3 Select “EUROPE” in the “AREA” box. Click the “Settings” items

in the following order:

Open Comm.PORT->Initialization of JIG->Incoming connection.

4 After 2 minutes, set the following items.

FM Adjustments

1 FM IF-Count

1-1 Set the reception frequency to 98.1MHz

1-2 Set the SG output to 60dBu.

1-3 Click “Adjustment”

2 FM S-Meter

2-1 Set the reception frequency to 98.1MHz
2-2 Set the MONO to 1kHz/22.5kHz variable.

2-3 Set the SG output to 20dBu.
2-4 Click “Adjustment”

AM Adjustments

1 MW/LW IF-Count

1-1 Use the AM ANT DUMMY.
1-2 Set the reception frequency to 1000kHz

1-3 Set the SG output to 60dBu.
1-4 Click “Adjustment”

2 MW/LW S-Meter

2-1 Use the AM ANT DUMMY.
2-2 Set the reception frequency to 1000kHz
2-3 Set the MONO to 400Hz/30% variable.

2-4 Set the SG output to 40dBu.
2-5 Click “Adjustment”

Writing data

1 Click “EEPROM Page Read”, and then “ROM DATA MAP” displays.
2 Input “00” into the right box of the “ROM DATA MAP”.

3 Select the “AUTO at EEPROM Write” of the “CheckSUM”. Then

click “ Calculate”.

4 Click “EEPROM Write in a checked line”, and then the data is

written in EEPROM-IC.

ADJUSTMENTS

052-3214-80 M30876FJAGP System Controller

Terminal Description

EXPLANATION OF IC

PF-2945A-A/PF-2982B-A

-3-

pin 1:ILL PULSE

:IN:

Illumination control signal input.

pin 2

:

TUN 5V ON

:O:

5V Power supply ON signal output. H = ON.

pin 3:Sie-BUS TX:O:Sie-BUS TX

pin 4

:

Sie-BUS RX:IN:Sie-BUS RX

pin 5:TUN 8V ON

:O:

8V Power supply ON signal output. H = ON.

pin 6

:

BYTE

:IN:

Data length selection(8bit/16bit).

pin 7:CN VSS

:IN:

L=Normal.

pin 8

:

TEST

:O:

For the test.

pin 9

:

M-AGC

:IN:

Strong electric field detection signal input.

pin 10:RESET

:IN:

Reset signal input.

pin 11

:

X out

:O:

Crystal connection.

pin 12

:

GND

:-:

Ground.

pin 13:Xin

:IN:

Crystal connection.

pin 14:VDD

:-:

Positive voltage supply.

pin 15

:

NMI

:IN:

Nonmaskable interrupt. Connect to VDD via

aresistor.

pin 16

:

ACC DET

:IN:

ACC detection signal input.

pin 17:BU DET

:IN:

Backup detection signal input.

pin 18

:

RDS/RBD SCK:IN:RDS/RBDserialclockinput.

pin 19

:

RDS/RBD SDI:IN:RDS/RBD serial data input.

pin 20:AMP MUTE

:O:

Muting signal output to the Audio power

amplifier.

pin 21

:

CAN-IN

:IN:

Serial data input from the CAN IC.

pin 22

:

CAN-OUT

:O:

Serial data output to the CAN IC.

pin 23:CAN ERR I

:IN:

Error signal input from the CAN IC.

pin 24

:

AMP ON

:O:

Audio power amplifier ON signal output.

pin 25

:

MP3/GIX REQ:IN:MP3/GIX request signal input.

pin 26:BEEP

:O:

Beep out.

pin 27

:

DSP/EEP SCK:O:DSP/EEP serial clock output.

pin 28:DSP/EEP SDO:O:DSP/EEP serial data output.

pin 29:FLASH TX

:O:

Flash memory Serial data output.

pin 30

:

FLASH RX

:IN:

Flash memory Serial data input.

pin 31:ANT ON

:O:

Antenna ON command output.

pin 32

:

FAN ON

:O:

The fan on signal output.

pin 33:MP3/GIX SDA:O:MP3/6CD-mechanism serial data output.

pin 34:MP3/GIX SCL:O:MP3/6CD-mechanism serial clock output.

pin 35

:

MP3/GIX RESET

:O:

MP3/6CD-mechanism reset pulse output.

pin 36

:

MP3stn/GIXsacc:O:MP3 standby/6CD-mechanism system ACC

control.

pin 37

:

MP3 RSTBY:O:MP3 S-RAM standby signal output.

pin 38:DSP PAUSE:IN:DSP automatic mute control. L = mute on.

pin 39:M-HLD-MUTE:O:Tuner mute signal output.

pin 40

:

M-HLD

:IN:

Tuner RDS hold.

pin 41

:

M-SMPL

:IN:

Tuner RDS sample.

pin 42:DSP INT

:IN:

Initial signal input from the DSP IC.

pin 43

:

DSP RESET:O:Reset signal output to the DSP IC.

pin 44:VFD ON

:O:

VFD ON signal output.

pin 45:ILL ON

:IN:

Illumination ON signal input.

pin 46:DAC RESET:O:Reset pulse output to the DAC. L = reset.

pin 47

:

CD 8V

:O:

8V Power supply ON signal output. H = ON.

pin 48

:

CD 3.3V

:O:

3.3V Power supply ON signal output. H = ON.

pin 49

:

CD +1.5V

:O:

1.5V Power supply ON signal output. H = ON.

pin 50:CD BUS0/EQDO

:

I/O

:

CD-BUS in/out. EQ data output.

pin 51:CD BUS1/EQCK

:

I/O

:

CD-BUS in/out. EQ clock output.

pin 52:CD BUS2/EQSA

:

I/O

:

CD-BUS in/out. Input the activating signal

to change the soft.

pin 53

:

CD BUS3

:

I/O

:

CD-BUS in/out.

pin 54:CD BU CK

:O:

CD IC clock pulse output.

pin 55:CD CCE

:O:

Chip enable signal output to the CD IC.

pin 56:CD RESET

:O:

Reset pulse output to the CD IC.

pin 57

:

CD SSTOP

:IN:

At loading, detects the chucking. And next,

detects the inside limit of the pick up position.

pin 58

:

CD CHUCK SW:IN:CD disk chucking signal input for the CD

mechanism.

pin 59

:

CD TR B

:IN:

Photo sensor signal input from the CD

mechanism.

pin 60

:

VDD

:-:

Positive voltage supply.

pin 61:CD TR A

:IN:

Photo sensor signal input from the CD
mechanism.

051-3395-90 NJU7780U1-15-TE2 Voltage Regurator 1.5V

1
2
3

54Vin

2pin
Vout

Control (H= On)

Ground

No Connectin

051-3396-90 NJM2386ADL3-33-TE1 Voltage Regulator 3.3V

5

4

3

2

1

Ground

N.C.

Power Outut

Control in, H = ON.

VCC

3

Terminal Description

051-6706-50 SAF7730HV/N332 Dual IF Car Radio and Audio DSP

pin 62:GND

:-:

Ground.

pin 63

:

CD LD CONT:O:CD loading control signal output.

pin 64

:

CD LD MUTE:O:CD loading mute signal output.

pin 65

:

TEL MUTE

:IN:

Telephone mute command input.

pin 66

:

SIEMUTEin:IN:S IE-BUS mute request input.

pin 67

:

SIEMUTEout:O:S IE-BUS mute request output.

pin 68

:

S IE RESET:O:S IE-BUS Reset signal output.

pin 69

:

SIESYSON:O:S IE-BUS System On request output.

pin 70

:

SIESYSOFF:O:S IE-BUS System Off request output.

pin 71

:

SIEONREQ:IN:S IE-BUS System On request input.

pin 72

:

SIEOFFREQ:IN:S IE-BUS System Off request input.

pin 73

:

CD SBSY

:IN:

Sub Q data request command input from the
CD IC.

pin 74

:

DSP 3.3V

:O:

3.3V Power supply ON signal output.

pin 75

:NU:-:

Not in use.

pin 76

:

SYS ON

:O:

System ON signal output.

pin 77

:

VFD CS

:O:

Chip select signal output to VFD driver.

pin 78

:

VFD CP

:O:

Clock pulse output to VFD driver.

pin 79

:

VFD DA

:O:

Serial data output to the VFD driver.

pin 80

:

VFD/KEY RST:O:Reset signal output to the VFD IC and KEY

IC. L = Reset ON.

pin 81

:

KEY DI

:IN:

Serial data input from the Key scan IC.

pin 82

:

KEY CE

:O:

Chip enable output to Key-IC.

pin 83

:

KEY CK

:O:

Clock pulse output for the key scan IC.

pin 84

:

KEY DO

:O:

Serial data output to the Key scan IC.

pin 85

:

VOL1L

:IN:

Volume control pulse input from the rotary
encoder.

pin 86

:

VOL2L

:IN:

Volume control pulse input from the rotary
encoder.

pin 87

:

TONE SW

:IN:

Tone switch signal input.

pin 88

:

CD LOAD

:IN:

CD-loading detection signal input.

pin 89

:

CD EJECT

:IN:

CD eject switch signal input.

pin 90

:

POWER SW:IN:Power switch ON signal input.

pin 91

:

VOL1R

:IN:

Volume control pulse input from the rotary
encoder.

pin 92

:

VOL2R

:IN:

Volume control pulse input from the rotary
encoder.

pin 93

:

S METER

:IN:

The input terminal of the internal A/D
converter to monitor the radio field strength.

pin 94

:

AVSS

:-:

Analog ground.

pin 95

:

AUX ON

:IN:

AUX ON signal input.

pin 96

:

VREF-

:-:

Negative reference voltage.

pin 97

:

AVCC

:-:

Positive voltage supply for the internal analog
section.

pin 98

:

TSCK

:O:

BUS-TUNER serial clock output.

pin 99

:

TSDO

:O:

BUS-TUNER serial data output.

pin100

:

S REMOCON:IN:Steering wheel remote controller input.

pin 1:VDDA_1V8

:-:

1.8V supply for IFADC and Audio ADCs.

pin 2

:

AUX_R

:IN:

Right channel of auxiliary input.

pin 3

:

AUX_R_GND:IN:Right common mode reference auxiliary input.

pin 4

:

AUX_L_GND:IN:Left common mode reference auxiliary input.

pin 5

:

AUX_L

:IN:

Left channel of auxiliary input.

pin 6

:

TAPE_R

:IN:

Right channel of tape input.

pin 7

:

TAPE_L

:IN:

Left channel of tape input.

pin 8

:

VADCP

:-:

Positive reference voltage for Audio ADCs.

pin 9

:

VDD_ADC

:-:

3.3V supply for audio ADCs.

pin 10

:

VADCN

:-:

Ground reference for audio ADCs.

pin 11

:

VREFAD

:-:

Common mode reference voltage ADCs.

pin 12

:

CD_R

:IN:

Right channel of CD input.

pin 13

:

CD_R_GND:IN:Right common mode reference CD input.

pin 14

:

CD_L_GND:IN:Left common mode reference CD input.

pin 15:CD_L

:IN:

Right channel of CD input.

pin 16

:

PHONE_IN

:IN:

Audio phone input.

pin 17

:

PHONE_GND:IN:Common reference audio phone input.

pin 18

:

NAV

:IN:

Audio navigation input.

pin 19

:

NAV_GND

:IN:

Common reference audio navigation input.

pin 20

:

VDD D 1

:-:

1.8V positive supply.

pin 21

:

VSS S 1

:-:

Ground supply.

pin 22

:

TRSTN

:IN:

Test reset, active low.

pin 23

:

TCK

:IN:

Test clock.

pin 24

:

TDO

:O:

Test control data output.

pin 25

:

TDI

:IN:

Test control data input.

pin 26

:

TMS

:IN:

Test mode select.

pin 27

:A0:IN:

Slave sub-address I2C selection.

pin 28

:

SCL

:IN:

Serial clock input I2C bus.

pin 29

:

SDA

:IN:

Serial data input / output I2C bus.

pin 30

:

GAPREG

:-:

Decoupling for regultator bandgap voltage.

pin 31

:

CONREG

:O:

Control output for external PMOS transistor.

pin 32

:

FEBREG

:IN:

Feedback input monitoring the 1.8V.

pin 33

:

VDD_REG

:-:

3.3V supply for regulator.

pin 34

:

SPDIF_IN 1:IN:Spdif input 1.

pin 35

:

VSS_SPDIF

:-:

Ground supply for spdif input.

pin 36

:

SPDIF_IN 2:IN:Spdif input 2.

pin 37

:

VDD_SPDIF:-:3.3V supply for spdif input.

pin 38

:

DAC_RR

:O:

Audio output for Rear-right speaker.

pin 39

:

DAC_RL

:O:

Audio output for Rear_left speaker.

pin 40

:

VDACP

:-:

Positive reference voltage for audio DACs.

pin 41

:

VDACN

:-:

Ground reference voltage for audio DACs.

pin 42

:

VDD_DAC

:-:

3.3V supply for audio DACs.

pin 43

:

DAC_FR

:O:

Audio output for Front-right speaker.

pin 44

:

DAC_FL

:O:

Audio output for Front-left speaker.

pin 45

:

DAC_SUBW:O:Audio output for subwoofer.

pin 46

:

DAC_CENTER:O:Audio output for center speaker.

pin 47

:

VDD Q 1

:-:

Positive supply (peripheral cells only).

pin 48

:

FS_SYS

:O:

FS system clock in/output.

pin 49

:

RESETN

:IN:

General reset of chip (active low).

pin 50

:

TEST 1

:O:

Test pin1 reserved for digital testing.

pin 51

:

BCK_IN 1

:O:

IIS source 1 Bit Clock input.

pin 52

:

WS_IN 1

:O:

IIS source 1 Word Select input.

pin 53

:

SD_IN 1

:O:

IIS source 1 Data input.

pin 54

:

VDD D 2

:-:

1.8V positive supply.

pin 55

:

VSS S 2

:-:

Ground supply.

pin 56

:

RDS_CLK 1:O:Radio Data System bit clock output 1/ RDS.

external clock input 1, I2C bit controlled.

pin 57

:

RDS_DATA 1:O:Radio Data System data output 1.

pin 58

:

RDS_CLK 2:O:Radio Data System bit clock output 2/ RDS.

external clock input2, I2C bit controlled.

pin 59

:

RDS_DATA 2:O:Radio Data System data output 2.

pin 60

:

VDD_MEM 1:-:1.8V positive supply (for memories only).

pin 61

:

VSS S 5

:-:

Ground supply (for memories).

pin 62

:

BCK_IN 2

:O:

IIS source 2 Bit Clock input.

pin 63

:

WS_IN 2

:O:

IIS source 2 Word Select input.

pin 64

:

SD_IN 2

:O:

IIS source 2 Data input.

pin 65

:

BCK_IN 3

:O:

IIS source 3 Bit Clock input.

pin 66

:

WS_IN 3

:O:

IIS source 3 Word Select input.

pin 67

:

SD_IN 3

:O:

IIS source 3 Data input.

pin 68

:

VSS Q 1

:-:

Ground supply (peripheral cells only).

pin 69

:

VDD Q 2

:-:

Positive supply (peripheral cells only).

pin 70

:

ADSP_IOF 5:O:Audio DSP general purpose I/O flag.

pin 71

:

ADSP_IOF 6:O:Audio/SRC DSP general purpose I/O flag.

pin 72

:

BCK_IN 4

:O:

IIS source 4 Bit Clock input.

pin 73

:

WS_IN 4

:O:

IIS source 4 Word Select input.

pin 74

:

SD_IN 4

:O:

IIS source 4 Data input.

pin 75

:

SD_HOST_O 1:O:Host IIS 1 Data output.

pin 76

:

SD_HOST_O 2:O:Host IIS 2 Data output.

pin 77

:

SD_HOST_O 3:O:Host IIS 3 Data output.

pin 78

:

SD_HOST_O 4:O:Host IIS 4 Data output.

pin 79

:

WS_HOST

:O:

Host IIS Word Select output/input.

pin 80

:

BCK_HOST:O:Host IIS Bit Clock output/input.

pin 81

:

SD_HOST_IN 1:IN:Host IIS 1 Data input.

pin 82

:

SD_HOST_IN 2:IN:Host IIS 2 Data input.

pin 83

:

SD_HOST_IN 3:IN:Host IIS 3 Data input.

pin 84

:

SD_HOST_IN 4:IN:Host IIS 4 Data input.

pin 85

:

SD_HOST_IN 5:IN:Host IIS 5 Data input.

pin 86

:

VSS Q 2

:-:

Ground supply (peripheral cells only).

pin 87

:

VDD Q 3

:-:

Positive supply (peripheral cells only).

pin 88

:

ADSP_IOF 7:O:Audio/SRC DSP general purpose I/O flag.

pin 89

:

ADSP_IOF 8:O:Audio/SRC DSP general purpose I/O flag.

pin 90

:

ADSP_IOF 9:O:Audio/SRC DSP general purpose I/O flag.

pin 91

:

ADSP_IOF 10:O:Audio/SRC DSP general purpose I/O flag.

pin 92

:

ADSP_IOF 11:O:Audio/SRC DSP general purpose I/O flag.

pin 93

:

ADSP_IOF 12:O:Audio/SRC DSP general purpose I/O flag.

pin 94

:

VDD D 3

:-:

1.8V positive supply.

-4-

PF-2945A-A/PF-2982B-A

pin 96:TDSP_IOF 1:O:Tuner DSP general purpose I/O flag 1.
pin 97

:

TDSP_IOF 2:O:Tuner DSP general purpose I/O flag 2.

pin 98

:

TDSP_IOF 3:O:Tuner DSP general purpose I/O flag 3.

pin 99

:

TDSP_IOF 4:O:Tuner DSP general purpose I/O flag 4

pin100

:

TDSP_IOF 5:O:Tuner DSP general purpose I/O flag 5.

pin101

:

TDSP_IOF 6:O:Tuner DSP general purpose I/O flag 6.

pin102

:

TDSP_IOF 7:O:Tuner DSP general purpose I/O flag 7.

pin103

:

TDSP_IOF 8:O:Tuner DSP general purpose I/O flag 8.

pin104

:

VSS Q 3

:-:

Ground supply (peripheral cells only).

pin105

:

VDD Q 4

:-:

Positive supply (peripheral cells only).

pin106

:

TDSP_IOF 9:O:Tuner DSP general purpose I/O flag 9.

pin107

:

TDSP_IOF 10:O:Tuner DSP general purpose I/O flag 10.

pin108

:

AGC1_1

:O:

LSB Gain control output 1 to DICE 1.

pin109

:

AGC1_2

:O:

MSB Gain control output 2 to DICE 1.

pin110

:

AGC2_1

:O:

LSB Gain control output 1 to DICE 2.

pin111

:

AGC2_2

:O:

MSB Gain control output 2 to DICE 2.

pin112

:

TDSP_IOF 11:O:Tuner DSP general purpose I/O flag 11.

pin113

:

TDSP_IOF 12:O:Tuner DSP general purpose I/O flag 12.

pin114

:

ADSP_IOF 4:O:Audio DSP general purpose I/O flag

(e.g. IBOC_BLEND).

pin115

:

SD_IBOC_O _I:O:Serial data output IBOC I-signal.

pin116

:

SD_IBOC_O _Q:O:Serial data output IBOC Q-signal.

pin117

:

WS_IBOC_OUT:O:IBOC Word Select output.

pin118:BCK_IBOC_OUT

:O:

IBOC Bit Clock output.

pin119

:

RESERVED_2:-:Reserved.

pin120

:

RESERVED_3:-:Reserved.

pin121

:

VSSS6

:-:

Ground supply (for memories).

pin122

:

VDD_MEM 2:-:1.8V positive supply (for memories only).

pin123

:

SCL_DICE

:O:

Serial clock output I2C bus to the I2C clock
inputoftheDICE.

pin124

:

SDA_DICE

:IN:

Serial data input/output I2C bus to the data
inputoftheDICE.

pin125

:

VDD D 4

:-:

1.8V positive supply.

pin126

:

VSSS4

:-:

Ground supply.

pin127

:

DICE 2_CLK:O:100 kHz clock current output reference to DICE2.

pin128

:

DICE 2_CLKN:O:100 kHz clock not current output reference

to DICE2.

pin129

:

VSS Q 4

:-:

Ground supply (peripheral cells only).

pin130

:

VSS_OSC

:-:

Ground supply for oscillator and PLLs.

pin131

:

OSC_IN

:IN:

Crystal oscillator input.

pin132

:

OSC_OUT

:O:

Crystal oscillator output.

pin133

:

VDD_OSC

:-:

1.8V supply for oscillator and PLLs.

pin134

:

KAGC 1

:O:

Keyed AGC DAC output 1.

pin135

:

KAGC 2

:O:

Keyed AGC DAC output 2.

pin136

:

IFAD_N 1

:IN:

Negative phase of the first differential IF input.

pin137

:

IFAD_P 1

:IN:

Positive phase of the first differential IF input.

pin138

:

VSS_IFAD

:-:

Ground supply for IF ADCs.

pin139

:

VDD_IFAD

:-:

3.3V supply for IF ADCs.

pin140

:

VIFADP

:-:

Decoupling for IF ADCs positive reference voltage.

pin141

:

VIFADN

:-:

Ground reference voltage for IF ADCs.

pin142

:

VIFADBG

:-:

Decoupling for IF ADCs bandgap voltage.

pin143

:

IFAD_P 2

:IN:

Positive phase of the second differential IF input.

pin144

:

IFAD_N 2

:IN:

Negative phase of the second differential IF input.

ADSP:Audio DSP.
AFC

:

Automatic Frequency Control.

AGC

:

Automatic Gain Control.

AM

:

Amplitude Modulation.

BIOSROM:Basic IO System Read Only Memory.
CD

:

Compact Disc.

CMRR

:

Common Mode Rejection Ratio.

CRD

:

Cordic Rotate and Derotate.

DAC

:

DigitaltoAnalogConverter.

DARC

:

DAta Radio Channel.

DICE

:

Digital In Car Entertainment.

DSP

:

Digital Signal Processor.

EPICS

:

Economic Parameterised Integrated CoreS.

FIR

:

Finite Impulse Response.

FM

:

Frequency Modulation.

FSM

:

Finite State Machine.

HW

:

HardWare.

I2C

:

Inter IC Communication.

I2S

:

Inter IC Sound (Philips standard).

IAC

:

Interference Absorption Circuit.

IBOC

:

In Band On Channel.

IF

:

Intermediate Frequency.

IFAD

:

Intermediate Frequency Analog to Digital Converter.

IIS

:

Inter IC Sound (any data format).

IP

:

Intellectual Property.

KAGC

:

Keyed AGC.

MPX

:

frequency MultiPleXed signal (audio/data).

MSS

:

Music Search System.

NZIF

:

Near Zero IF.

PACS

:

Precision Adjacent Channel Suppression.

PDC

:

Primary Decimation Chain.

PRAM

:

Program Random Access Memory.

PROM

:

Program Read Only Memory.

RDS

:

Radio Data System.

SDSP

:

Samplerate converter DSP.

SPDIF

:

Sony/Philips Digital Interface Format.

SRC

:

SampleRate Converter.

SW

:

SoftWare.

TDSP

:

Tuner DSP.

WB

:

Weather Band.

XRAM

:

X (typically for DSP data) Random Access Memory.

YRAM

:

Y (typically for DSP coefficients) Random Access Memory.

YROM

:

Y (typically for DSP coefficients) Read Only Memory.

ZIF

:

Zero IF.

Terminal Description

051-9426-90 S-24CS16A01-T8T1G EEP ROM

pin 1:NU

:-:

Not in use.

pin 2:NU

:-:

Not in use.

pin 3:A2

:-:

For the Test.

pin 4:GND

:-:

Ground.

pin 5:SDATA

:

I/O

:

Serial data input/output.

pin 6:SCK

:IN:

Sift clock input.

pin 7:Write Protect

:IN:

Write protect signal input.

pin 8:VDD

:-:

Positive voltage supply.

Abbreviations Table

AD

:

Analog to Digital converter.

ADC

:

Analog to Digital converter.

CD mechanism section:929-5000-80

BLOCK DIAGRAM

J101

SLED / LOADING
MOTOR

SPINDLE MOTOR

RF-AMP

SERVO PROCESSOR

IC2

TC94A15F

MOTOR DRIVER

IC1

BA5830FP-E2

IF-VDD

8.0V

AOUT
SFSY
SBSY

/RST
BUS0
BUS1
BUS2
BUS3
BUCK

/CCE
DATA

LDMUT
LDCONT
SW /

DET

3.3V

PICK UP UNIT

LASER
DETECTOR

A,B,C,E,F

FOCUS
TRACKING COIL

S2

LIMIT
SWITCH

CHUCKING
SWITCH

Q1,2

TR A,B

D1,2

LED A,B

S1

CLCK
BCK

LRCK
MBOV
IPF

8V

CD-VDD

3.3V

5.0V

PF-2945A-A/PF-2982B-A

-5-

BL101

TA8276H

BUS

ACC

NJM2103M

B/U

GND

BEEP

SYSTEM CONTROL MICOM

ILLUMI

BUS DRIVER

POWER SUPPLY

MUTE,ST-BY

FL(+)

FL(-)

RL(+)

RL(-)

RR(+)

RR(-)

FR(+)

FR(-)

S-GND

KEY-SWITCH

IC301

CONNECTOR

J801(20PIN)

EEP-ROM

AUX

AUX-ON

AUX-L/R

L-OUT(+)(-)

R-OUT(+)(-)

BUS(+)(-)

MAIN-POWER-IC

ANT-ON

J802(8PIN)

CAN+

CAN-

S.R(-)

ILL(-)

ILL(+)

S.R(+)

CAN-DRIVER

IC801

TJA1054AT-N1

. VDD+5V Q603

. ANT+B : Q807

DSP

B/U-DET/RESET

IC604

IC601

M30876FJAGP

. ILL(+) : Q812

. ILL-CONT : Q811

. ILL-PULSE : Q809

. VFD+B : Q822

. F+6.0V : Q821

. D+5V : IC401

. AUDIO+9V : IC508

. CD+8V : IC207

NJM2386ADL3-09-TE1

880-2091E

RADIO-BUS-TUNER

IF-OUT1

IF-OUT2

IF-AD

SAF7730HV/N332

NJM2396F05

TUNER+5V

IC102

NJM2886DL3-05-TE1

TUNER+9V

Q102

AUDIO-1/2VCC

IC507

NJM4558V

DSP+3.3V

IC302

NJM2386ADL3-33-TE1

1.8V-REG

Q301

PHK04P02T

SIE-BUS

J903(20PIN)

IC603

HA12187FP

NJM2396F08

VFD-DRIVER

IC2

ML9203-06GA

FL1

VFD

IC602

S-24CS16A01-T8T1G

KEY-SCAN-IC

IC1

LC75700T

CD+3.3V

IC205

NJM2386ADL3-33-TE1

CD+1.5V

IC203

NJU7780U1-15-TE2

SYS+3.3V

Q209

VDD+1.5V

IC201

NJU7780U1-15-TE2

IC204

TC94A34FG-004

IC202

MSM51V17400D-60TS-K

IC208

HD74LV541A

VFD+32V

Q814

20K-LPF

IC501

NJM2060V

FLFRRL

RR

PRE-AMP

IC502

NJM2060V

D5~D39

GS1-N3-MECH

IC503

J201(29PIN)

IIC

IIC

CD+8V

CD-VDD

AUX/(SUB-W)

Main section

LEVEL SHIFT-IC

MP3DECODER

SHOCK PROOF MEMORY

-6-

PF-2945A-A/PF-2982B-A

PF-2945A-A/PF-2982B-A

-7-

1

15

9

7

x23

9

10

8

x4

8x4

11

12

16

14

17

3

2

13

13

4

5

EXPLODED VIEW / PARTS LIST

Escutcheon section

NO. PART NO. DESCRIPTION Q'TY NO. PART NO. DESCRIPTION Q'TY

1 940-8185-10 ES-ASSY 1 10 074-3014-78 OUTLET SOCKET(28P) 1
2 345-6070-00 RUBBER SWITCH A 1 11 345-5995-20 SPACER 2
3 345-6071-00 RUBBER SWITCH B 1 12 379-4062-24 INDICATOR(VFD) 1
4 345-6072-00 RUBBER SWITCH C 2 13 716-0778-52 SCREW(M2x8) 14
5 345-6073-00 RUBBER SWITCH D 1 14 335-8079-00 COLOR-FILTER 1
6 ------------- Switch PWB 1 15 373-1146-10 DIAL-CVR(PF-2945A-A) 1
7 001-7094-91 DIODE 23 373-1146-15 DIAL-CVR(PF-2982B-A) 1
8 001-7094-92 DIODE 8 16 380-5700-10 KNOB 2
9 016-0018-21 VR W/SHAFT 2 17 335-8078-00 ILLUMI RING 2

6

Note) Some parts depend on
each model. The model name
is specified in the description.

37

21

34

21

31

36

32

21

21

13

35

22

9

2

4

1

3

10

13

21

21

21

21

33

21

21

27

24

28

25

26

27

30

21

29

27

12

14

15

8

5

6

7

2

19

18

17

16

23

23

21

20

2

2

Main section

M

5

X

8

m

m

M

A

X

M

5

X

8

m

m

M

A

X

-

11

NO. PART NO. DESCRIPTION Q'TY NO. PART NO. DESCRIPTION Q'TY

1 ------------- Main PWB 1 22 311-1944-00 LOWER CASE 1
2 073-0762-90 TERMINAL 6 23 716-0878-50 SCREW(M2.6x5) 6
3 074-1237-79 OUTLET SOCKET(29P) 1 24 309-0845-01 ES PLATE(1CD) 1
4 076-3011-78 PLUG(8P) 1 25 929-5000-80 DIGITAL-MECH 1
5 074-4009-20 OUTLET SOCKET(20P) 1 26 331-4123-00 CD BRKT 1
6 074-1302-08 OUTLET SOCKET(8P) 1 27 714-2603-89 MACHINE SCREW(M2.6x3) 4
7 092-0702-00 ANT-RECEPT 1 28 345-5895-00 CUSHION RUBBER 1
8 051-2040-00 IC(TA8276H) 1 29 816-4025-50 FLAT WIRE 1

9 880-2091E TUNER 1 30 310-1826-50 UPPER CASE 1
10 331-4414-00 TR HOLDER 1 31 313-2018-00 HEAT SINK 1
11 313-2019-00 SUB HEAT SINK 1 32 331-3579-00 EARTH PLATE 1
12

307-0727-00 REAR PLATE 1

33 347-8295-01 PROTECTOR 1
13 778-3006-00 TAP-SCREW(M3x6) 4 34 714-2610-89 MACHINE SCREW(M2.6x10) 3
14 076-0368-10 PLUG(10P) 1 35 093-2137-01 ANT-JUMPER 1
15 076-0368-06 PLUG(6P) 1 36 290-8338-11 LABEL(PF-2945A-A) 1
16 ------------- Sub PWB 1 290-8338-21 LABEL(PF-2982B-A) 1
17 074-0898-06 OUTLET SOCKET(6P) 1 37 276-0217-01 SETPLATE(PF-2945A-A) 1
18 074-0898-10 OUTLET SOCKET(10P) 1 276-0217-11 SETPLATE(PF-2982B-A) 1
19 074-4027-20 OUTLET SOCKET(20P) 1 38 345-5805-24 GASKET 3
20 331-4413-00 PWB HOLDER 1 345-5805-04 GASKET 3
21 714-2606-8B MACHINE SCREW(M2.6x6) 20

Note)Several different parts of the same reference number are alternative parts.

One of those parts is used in the set.
Some parts depend on each model. The model name is specified in the description.

38

38

38

-8-

PF-2945A-A/PF-2982B-A

H4

H5

G6

H6

H7

A5

A1

A2

A3

A4

G2

G3

B2

A8

A8

I1

M1

K3

K4

C1

A2

A3

G9

G8

G11

G5

G14

G6

3

4

75

74

76

5

11

7

9

12

31

32

33

34

35

36

13

14

15

16

17

37

38

39

40

18

19

29

20

21

22

30

23

24

25

26

28

43

44

45

46

47

65

48

48

50

53

51

67

63

64

54

55

56

57

59

60

61

62

70

68

71

72

73

69

1

2

59

46

I1

I2

D2

D1

H6

H7

K1

K2

C3

H5

H4

22

29

H6

B1

H1

H2

H3

G13

D1

52

D2

G12

H2

H1

H3

65

A4

A5

E2

G2

G14

G5

G1

G3

E1

G4

M1

G9

G8

G11

C5

C2

G1

I2

C1

66

66

49

49

H6

C5

C2

C3

K1

K2

K3
K4

G12

G4

A1

G13

B1

B2

69

E1

E2

41

6

8

10

42

27

58

1

CD mechanism section: 929-5000-80

PF-2945A-A/PF-2982B-A

-9-

-10-

PF-2945A-A/PF-2982B-A

NO. PART NO. DESCRIPTION Q'TY NO. PART NO. DESCRIPTION Q'TY

1 --------------- SENSOR PWBPWB 1

39 621-1750-20 POWER GEAR C

1

2 --------------- CD PWB 1

40 621-1751-20 POWER GEAR D

1

3

SMA-182-100

SPINDLE MOTOR-ASSY 1

41 621-1752-20 DISC STOPPER

1

4

SMA-183-100

SLED MOTOR-ASSY 1

42 621-1753-20 CLAMPER RING

1

5 345-5476-20 CUSHION RUBBER 1

43 621-1754-20 GEAR BASE

1

6 620-1023-23 CLAMPER PLATE 1

44 622-1571-21 ROLLER SHAFT

1

7 620-1026-21 SPRING PLATE

1

45 624-0020-00 LEAD SCREW

1

8 620-1596-23 CLAMPER LINK

1

46 629-0086-20 DAMPER F

2

9 620-1598-22 UPPER CHASSIS

1

47 629-0087-20 DAMPER R

1

10 620-1752-20 SENSOR ARM

1

48 716-1507-01 SCREW(M2x3)

3

11 620-1753-20 ID-LOCK PLATE

1

49 716-1670-01 SCREW(M2x4)

4

12 620-1754-20 LOWER CHASSIS

1

50 716-1733-01 SCREW(M1.7x2.3)

2

13 621-0608-21 SECOND GEAR

1

51 716-3469-01 SCREW(1.7x4)

2

14 621-0609-20 BASE GEAR

1

52 716-3473-01 SCREW(M2x3)

1

15 621-0610-20 IDLE GEAR A

1

53 716-3551-00 SCREW(M1.4x2.5)

2

16 621-0611-20 IDLE GEAR B

1

54 750-7865-20 SHIFT SPRING

1

17 621-0612-21 ROLLER GEAR A

1

55 750-7866-20 RACK SPRING

1

18 621-0620-20 THREAD GEAR A

1

56 750-7867-20 CLAMPER SPRING

1

19 621-0621-20 THREAD GEAR B

1

57 750-7868-20 ID-LOCK SPRING

1

20 621-0623-23 LS-HOLDER

1

58 750-7869-20 SENSOR SPRING

1

21 621-0624-22 GUIDE RAIL

1

59 750-7870-20 DR-SPRING F

2

22 621-0711-21 LOADING ROLLER

2

60 750-7871-20 DR-SPRING RA

1

23 621-0718-21 ROLLER GUIDE

1

61 750-7872-20 DR-SPRING RB

1

24 621-0719-20 ROLLER GEAR B

1

62 750-7873-20 DR-SPRING C

1

25 621-0720-20 ROLLER GEAR C

1

63 750-6797-20 ROLLER SPRING L

1

26 621-0721-20 ROLLER GEAR D

1

64 750-6798-20 ROLLER SPRING R

1

27 621-0728-20 STOPPER LINK

1

65 714-2003-8B SCREW(M2x3)

2

28 621-1719-20 IDLE CASE

1

66 780-2025-00 SCREW(M2x2.5)

3

29 621-1726-20 ROLLER SLEEVE

2

67 781-1730-00 SCREW(M1.7x3)

1

30 621-1729-20 SH-BASE

1

68 803-4906-60 VINYL-COAT-WIRE(ORG)

1

31 621-1742-20 UPPER GUIDE

1

69 816-2542-01 FLAT WIRE

1

32 621-1743-20 SHIFT LEVER

1

70 816-2590-00 VINYL-COAT-WIRE(GRN)

1

33 621-1744-20 RACK

1

71 816-2591-00 VINYL-COAT-WIRE(YEL)

1

34 621-1745-20 LOCK ARM L

1

72 816-2592-00 VINYL-COAT-WIRE(BLUE)

1

35 621-1746-20 LOCK ARM R

1

73 816-2593-00 VINYL-COAT-WIRE(PUR)

1

36 621-1747-20 GEAR COVER

1

74 966-1722-20 SH-RACK-ASSY

1

37 621-1748-20 POWER GEAR A

1

75 966-1743-21 DRIVE-PLT-ASSY

1

38 621-1749-20 POWER GEAR B

1

76 969-0071-30 PICKUP-ASSY

1

ELECTRICAL PARTS LIST

Main PWB(B1) section

Note)Several different parts of the same reference number are alternative parts.

One of those parts is used in the set.

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

ANT101 092-0702-00 ANT-RECEPT C207 166-1007-50 10pF CH C231 168-1042-78 16V 0.1uF

BL101 880-2091E

TUNER

C208 166-1007-50 10pF CH C233 168-1042-38 50V 0.1uF

C101 166-8201-50 82pF CH C209 168-1042-78 16V 0.1uF C234 168-1042-78 16V 0.1uF

C102 166-2201-50 22pF CH C210 168-1042-78 16V 0.1uF C238 189-4763-48 25V47pF

C104 168-1042-78 16V 0.1uF C211 166-1007-50 10pF CH C301 178-2255-79 2.2uF

C105 163-1073-35 16V 100uF C212 166-1007-50 10pF CH C302 166-2201-50 22pF CH

C106 168-1022-55 1000pF K C213 166-1007-50 10pF CH C303 166-2201-50 22pF CH

C108 168-1022-55 1000pF K C214 166-1007-50 10pF CH C304 178-2255-79 2.2uF

C109 168-1022-55 1000pF K C215 166-1007-50 10pF CH C305 178-2255-79 2.2uF

C110 168-1042-78 16V 0.1uF C216 163-4763-15 6.3V 47uF C306 166-2201-50 22pF CH

C111 163-1073-35 16V 100uF C217 168-1042-78 16V 0.1uF C307 166-2201-50 22pF CH

C117 168-1042-78 16V 0.1uF C218 168-1042-78 16V 0.1uF C308 178-2255-79 2.2uF

C118 178-3342-78 0.33uF C219 163-4763-15 6.3V 47uF C309 178-2255-79 2.2uF

C201 163-4763-15 6.3V 47uF C220 168-1042-78 16V 0.1uF C310 166-2201-50 22pF CH

C202 168-1032-55 0.01uF K C221 168-1042-78 16V 0.1uF C311 166-2201-50 22pF CH

C203 168-1042-78 16V 0.1uF C222 168-1042-78 16V 0.1uF C312 178-2255-79 2.2uF

C204 168-1042-78 16V 0.1uF C223 189-1073-29 1 0V 100uF C313 178-2255-79 2.2uF

C205 166-1007-50 10pF CH C225 178-3342-78 0.33uF C314 166-2201-50 22pF CH

C206 166-1007-50 10pF CH C230 189-2273-29 10V 220uF C315 166-2201-50 22pF CH

PF-2945A-A/PF-2982B-A

-11-

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

C316 178-2255-79 2.2uF C509 166-2711-50 270pF C823 188-1063-38 16V 10uF

C317 178-1052-78 1uF C510 166-2711-50 270pF C824 168-1042-38 50V 0.1uF

C318 166-2201-50 22pF CH C511 166-2201-50 22pF CH C825 189-1073-59 35V 100uF

C319 166-2201-50 22pF CH C512 166-2201-50 22pF CH C826 188-1063-68 50V 10uF

C320 178-1052-78 1uF C513 166-2201-50 22pF CH C827 189-4773-62 50V 470uF

C321 119-0000-05 1/10W 0 ohm JW C514 166-2201-50 22pF CH C828 189-4773-39 16V 470uF

C322 168-1042-78 16V 0.1uF C515 166-5611-50 560pF CH C829 168-1042-38 50V 0.1uF

C323 168-1042-78 16V 0.1uF C516 166-5611-50 560pF CH C830 189-4773-39 16V 470uF

C324 166-1007-50 10pF CH C517 166-2711-50 270pF C831 168-1042-38 50V 0.1uF

C325 166-1007-50 10pF CH C518 166-2711-50 270pF C832 168-1042-38 50V 0.1uF

C327 168-5622-55 5600pF K C519 166-1011-50 100pF CH C833 168-1042-38 50V 0.1uF

C328 168-5622-55 5600pF K C520 166-1011-50 100pF CH C834 168-1042-38 50V 0.1uF

C329 168-1042-78 16V 0.1uF C521 166-2201-50 22pF CH C835 168-1042-38 50V 0.1uF

C330 168-1042-78 16V 0.1uF C522 166-2201-50 22pF CH C836 168-2232-55 0.022uF K

C331 188-4753-68 50V 4.7uF C523 166-2201-50 22pF CH C837 168-2232-55 0.022uF K

C334 168-1022-55 1000pF K C524 166-2201-50 22pF CH C838 189-2273-39 16V 220uF

C335 168-1022-55 1000pF K C525 166-1011-50 100pF CH C839 168-1042-78 16V 0.1uF

C336 168-1042-78 16V 0.1uF C526 166-1011-50 100pF CH C840 042-1334-75 16V 47uF

C337 188-4753-68 50V 4.7uF C527 043-0311-92 10V 0.22uF B C841 188-1063-38 16V 10uF

C338 168-1042-78 16V 0.1uF C528 043-0311-92 10V 0.22uF B C842 189-2273-39 16V 220uF

C339 188-4753-68 50V 4.7uF C529 043-0311-92 10V 0.22uF B C843 189-4763-48 25V 47uF

C340 168-1042-78 16V 0.1uF C530 043-0311-92 10V 0.22uF B C845 168-1042-78 16V 0.1uF

C341 168-1042-78 16V 0.1uF C531 168-1032-55 0.01uF K C846 168-1042-78 16V 0.1uF

C342 168-1042-78 16V 0.1uF C532 188-1053-68 50V 1uF C847 166-1007-50 10pF CH

C344 168-1042-78 16V 0.1uF C533 163-1063-35 16V 10uF C848 166-1007-50 10pF CH

C345 178-1052-78 1uF C534 188-1053-68 50V 1uF C849 168-1022-55 1000pF K

C346 168-1042-78 16V 0.1uF C543 166-2201-50 22pF CH C850 168-1022-55 1000pF K

C347 168-1042-78 16V 0.1uF C558 168-1042-78 16V 0.1uF CCT201 050-0140-54

1/32W 1k ohm x4J

C348 189-2273-19 6.3V 220uF C559 189-1073-39 16V 100uF CCT301 050-0140-53

1/32W 0 ohm x4J

C350 188-2263-38 16V 22uF C560 189-1073-29 10V 100uF CCT302 050-0140-53

1/32W 0 ohm x4J

C353 168-1042-78 16V 0.1uF C561 163-1073-35 16V 100uF CCT601 050-0140-54

1/32W 1k ohm x4J

C354 042-0423-94 10V 4.7uF C562 168-1042-78 16V 0.1uF CCT602 050-0140-54

1/32W 1k ohm x4J

C355 168-1042-78 16V 0.1uF C564 188-1053-68 50V 1uF CCT603 050-0140-54

1/32W 1k ohm x4J

C356 163-4763-15 6.3V 47uF C601 168-1032-55 0.01uF K CCT604 050-0140-54

1/32W 1k ohm x4J

C357 168-1042-78 16V 0.1uF C602 168-1042-78 16V 0.1uF D106 001-0516-90 MA111

C358 168-1042-78 16V 0.1uF C603 189-1073-39 16V 100uF D106 001-0580-90 1 SS352

C359 168-1042-78 16V 0.1uF C604 168-1032-55 0.01uF K D501 001-0516-90 MA111

C360 168-1042-78 16V 0.1uF C605 168-1032-55 0.01uF K D501 001-0580-90 1SS352

C363 168-1022-55 1000pF K C606 166-8097-50 8pF C CH D601 001-0516-90 MA111

C364 168-1022-55 1000pF K C607 166-8097-50 8pF C CH D601 001-0580-90 1SS352

C366 168-1022-55 1000pF K C608 042-0559-00 5.5V0.1F D602 001-0466-90 S5688B

C367 168-1042-78 16V 0.1uF C609 189-1073-39 16V 100uF D603 001-0504-36 HZS7A1L

C368 168-1022-55 1000pF K C610 168-1042-78 16V 0.1uF D604 001-4301-25 HZU4.7B1

C369 168-1022-55 1000pF K C611 188-1063-38 16V 10uF D701 001-4301-32 HZU 5.6B2

C370 168-1022-55 1000pF K C612 168-1042-78 16V 0.1uF D702 001-4301-32 HZU 5.6B2

C373 166-6811-50 680pF C613 168-1032-55 0.01uF K D703 001-0347-69 MA4180M

C374 166-6811-50 680pF C614 168-1042-78 16V 0.1uF D704 001-0347-69 MA4180M

C375 166-6811-50 680pF C615 163-1053-65 50V 1uF D801 001-4902-92 HZM27FA-TL

C376 166-6811-50 680pF C616 168-1022-55 1000pF K D802 001-0466-90 S5688B

C378 042-0643-58 6.3V 330uF C617 168-1022-55 1000pF K D803 001-0592-00 RM4Z

C379 168-1042-78 16V 0.1uF C701 166-1007-50 10pF CH D804 001-4301-68 HZU18B1

C380 163-2263-35 16V 22uF C702 166-1007-50 10pF CH D808 001-4301-68 HZU18B1

C381 189-1073-29 10V 100uF C703 166-1007-50 10pF CH D809 001-0466-90 S5688B

C382 168-1042-78 16V 0.1uF C704 166-1007-50 10pF CH D810 001-0466-90 S5688B

C383 168-1022-55 1000pF K C705 166-1007-50 10pF CH D811 001-0466-90 S5688B

C384 178-3342-78 0.33uF C706 166-1007-50 10pF CH D812 001-0504-87 HZS333L

C401 188-4763-18 6.3V 47uF C800 168-2212-55 220pF K D813 001-0466-90 S5688B

C402 168-1042-78 16V 0.1uF C801 168-2212-55 220pF K D814 001-0466-90 S5688B

C403 168-1022-55 1000pF K C802 168-1032-55 0.01uF K D815 001-0466-90 S5688B

C404 168-1042-38 50V 0.1uF C803 168-2212-55 220pF K D816 001-4301-37 HZU6.8B1

C501 189-1073-39 16V 100uF C804 168-2212-55 220pF K D817 001-0347-69 MA4180M

C502 168-1042-78 16V 0.1uF C805 172-1041-15 0.1uF D818 001-0516-90 MA111

C503 178-2732-78 0.027uF C806 188-1053-68 50V 1uF D818 001-0580-90 1SS352

C504 178-2732-78 0.027uF C807 172-1041-15 0.1uF IC102 051-3368-90

NJM2886DL3-05-TE1

C505 178-2732-78 0.027uF C808 042-1624-00 16V 4700uF IC201 051-3395-90

NJU7780U1-15-TE2

C506 178-2732-78 0.027uF C820 168-1042-78 16V 0.1uF IC202 051-9318-00

MSM51V17400D-60TS-K

C507 166-5611-50 560pF CH C821 166-1011-50 100pF CH IC202 051-9318-10

GLT4160L04P-60TC

C508 166-5611-50 560pF CH C822 168-1032-55 0.01uF K IC203 051-3395-90

NJU7780U1-15-TE2

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

IC204 051-6711-20

TC94A34FG-004

Q209 125-0021-91 DTA114EUA Q822 103-1684-00 2SD1684

IC205 051-3396-90

NJM2386ADL3-33-TE1

Q209 125-0034-92

RT1P141M-T111-1

Q823 190-1162-00 2SA1162

IC207

051-3366-00

NJM2396F08 Q210 125-2027-91 DTC114EUA Q824 125-2027-91 DTC114EUA

IC208 051-7513-08 HD74LV541A Q210 125-2041-92

RT1N141M-T111-1

Q824 125-2041-92

RT1N141M-T111-1

IC301

SAF7730HV/N332

Q301 125-7005-90 PHK04P02T R101 119-0000-05 1/10W 0 ohm JW

IC302 051-3396-90

NJM2386ADL3-33-TE1

Q302 125-2027-91 DTC114EUA R104 119-0000-05 1/10W 0 ohm JW

IC401

051-3333-00

NJM2396F05 Q302 125-2041-92

RT1N141M-T111-1

R107 119-0000-05 1/10W 0 ohm JW

IC501 051-3019-90 NJM2060V Q303 125-2027-91 DTC114EUA R108 119-2741-15 1/10W 270k ohm

IC502 051-3019-90 NJM2060V Q303 125-2041-92

RT1N141M-T111-1

R109 119-1031-15 1/10W 10k ohm

IC503

051-2040-00

TA8276H Q304 125-2027-91 DTC114EUA R110 119-1031-15 1/10W 10k ohm

IC507 051-3034-90 NJM4558V Q304 125-2041-92

RT1N141M-T111-1

R111 119-1011-15 1/10W 100 ohm

IC508 051-3397-90

NJM2386ADL3-09-TE1

Q305 125-2027-91 DTC114EUA R112 119-1011-15 1/10W 100 ohm

IC601 052-3214-80 M30876FJAGP Q305 125-2041-92

RT1N141M-T111-1

R113 119-1011-15 1/10W 100 ohm

IC602 051-9426-90

S-24CS16A01-T8T1G

Q306 125-2027-91 DTC114EUA R119 119-4731-15 1/10W 47k ohm

IC603 051-6600-58 HA12187FP Q306 125-2041-92

RT1N141M-T111-1

R120 116-1021-15 1/4W 1k ohm

IC604 051-0869-58 NJM2103M Q307 125-2027-91 DTC114EUA R121 119-1031-15 1/10W 10k ohm

IC801 051-6623-18 TJA1054AT-N1 Q307 125-2041-92

RT1N141M-T111-1

R201 119-1521-15 1/10W 1.5k ohm

IC802 051-0172-08 TC4011BF Q308 125-2027-91 DTC114EUA R202 119-2251-15 1/10W 2.2M ohm

J201 074-1237-79 29P Q308 125-2041-92

RT1N141M-T111-1

R203 119-2211-15 1/10W 220 ohm

J801

074-4009-20

20P Q309 125-2027-91 DTC114EUA R204 119-1031-15 1/10W 10k ohm

J802

074-1302-08

8P Q309 125-2041-92

RT1N141M-T111-1

R205 119-1031-15 1/10W 10k ohm

L101 010-2003-04 30uH(Variable) Q501 125-2027-91 DTC114EUA R206 119-5121-15 1/10W 5.1k ohm

L114 010-6009-76 22uH J Q501 125-2041-92

RT1N141M-T111-1

R207 119-5121-15 1/10W 5.1k ohm

L201 010-3407-66 22uH J Q502 192-4116-00 2SC4116 R210 119-1031-15 1/10W 10k ohm

L202 010-3104-50 30 ohm/100MHz Q502 192-4155-51 2SC4155A S,T R211 119-5121-15 1/10W 5.1k ohm

L301 010-3104-54

600 ohm/100MHz

Q601 190-2071-00 2SA2071 T100 R219 119-1031-15 1/10W 10k ohm

L302 010-3104-54

600 ohm/100MHz

Q602 125-2027-91 DTC114EUA R220 119-3321-15 1/10W 3.3k ohm

L303 010-3104-54

600 ohm/100MHz

Q602 125-2041-92

RT1N141M-T111-1

R221 119-3331-15 1/10W 33k ohm

L304 010-3104-54

600 ohm/100MHz

Q603 193-2118-50 2SD2118F5 R,S R222 119-4731-15 1/10W 47k ohm

L305 010-3104-54

600 ohm/100MHz

Q604 192-4116-00 2SC4116 R227 119-1021-15 1/10W 1k ohm

L306 010-3104-54

600 ohm/100MHz

Q604 192-4155-51 2SC4155A S,T R228 119-3331-15 1/10W 33k ohm

L307 010-3104-54

600 ohm/100MHz

Q605 192-4116-00 2SC4116 R229 119-4731-15 1/10W 47k ohm

L308 010-3104-54

600 ohm/100MHz

Q605 192-4155-51 2SC4155A S,T R230 119-3331-15 1/10W 33k ohm

L309 010-3104-54

600 ohm/100MHz

Q701 190-1162-00 2SA1162 R231 119-0000-05 1/10W 0 ohm JW

L310 010-3104-54

600 ohm/100MHz

Q702 125-2027-91 DTC114EUA R232 119-4721-15 1/10W 4.7k ohm

L311 010-3104-54

600 ohm/100MHz

Q702 125-2041-92

RT1N141M-T111-1

R233 119-3331-15 1/10W 33k ohm

L312 010-3104-54

600 ohm/100MHz

Q703 192-4116-00 2SC4116 R234 119-4721-15 1/10W 4.7k ohm

L313 010-3104-54

600 ohm/100MHz

Q703 192-4155-51 2SC4155A S,T R235 119-4731-15 1/10W 47k ohm

L314 010-3104-54

600 ohm/100MHz

Q704 190-1162-00 2SA1162 R301 032-0140-51 1/10W 15k ohm F

L318 010-3104-54

600 ohm/100MHz

Q705 125-2027-91 DTC114EUA R302 032-0140-51 1/10W 15k ohm F

L328 010-3104-54

600 ohm/100MHz

Q705 125-2041-92

RT1N141M-T111-1

R303 032-0140-51 1/10W 15k ohm F

L329 010-3104-54

600 ohm/100MHz

Q706 192-4116-00 2SC4116 R304 032-0140-51 1/10W 15k ohm F

L337 010-3104-54

600 ohm/100MHz

Q706 192-4155-51 2SC4155A S,T R305 032-0140-51 1/10W 15k ohm F

L338 010-3104-54

600 ohm/100MHz

Q709 192-4116-00 2SC4116 R306 032-0140-51 1/10W 15k ohm F

L347 010-3104-54

600 ohm/100MHz

Q709 192-4155-51 2SC4155A S,T R307 032-0140-51 1/10W 15k ohm F

L350 010-3104-54

600 ohm/100MHz

Q710 190-1162-00 2SA1162 R308 032-0140-51 1/10W 15k ohm F

L501 010-6009-76 22uH J Q711 125-2027-91 DTC114EUA R309 119-1531-15 1/10W 15k ohm

L503 010-3407-66 22uH J Q711 125-2041-92

RT1N141M-T111-1

R310 119-1531-15 1/10W 15k ohm

L504 010-3104-54

600 ohm/100MHz

Q807 190-2071-00 2SA2071 T100 R311 168-1042-78 16V 0.1uF

L505 010-3104-54

600 ohm/100MHz

Q808 192-4116-00 2SC4116 R312 119-1031-15 1/10W 10k ohm

L801 010-3407-66 22uH J Q808 192-4155-51 2SC4155A S,T R313 119-1011-15 1/10W 100 ohm

L803 010-3601-50

600 ohm/100MHz

Q809 192-4116-00 2SC4116 R314 119-1021-15 1/10W 1k ohm

L806

010-8026-00

COIL Q809 192-4155-51 2SC4155A S,T R315 119-2201-15 1/10W 22 ohm

P601 076-0478-59 PLUG (9P) Q810 190-1048-00 2SA1048 R316 119-3921-15 1/10W 3.9k ohm

P602 076-3011-78 28P Q811 192-2873-00 2SC2873 R317 119-3921-15 1/10W 3.9k ohm

P701

076-0368-06

6P Q811 192-4357-00 2SC4357 R319 119-3921-15 1/10W 3.9k ohm

P702

076-0368-10

10P Q812 190-2071-00 2SA2071 T100 R320 119-3921-15 1/10W 3.9k ohm

Q101 192-4116-00 2SC4116 Q813 192-4116-00 2SC4116 R321 119-1031-15 1/10W 10k ohm

Q101 192-4155-51 2SC4155A S,T Q813 192-4155-51 2SC4155A S,T R322 119-1031-15 1/10W 10k ohm

Q102 191-1197-50 2SB1197K Q,R Q814 192-5886-00 2SC5886 R325 119-1021-15 1/10W 1k ohm

Q102 190-1365-50 2SA1365 F,G Q815 190-1428-00 2SA1428 R326 119-1011-15 1/10W 100 ohm

Q103 125-2027-91 DTC114EUA Q816 192-3668-00 2SC3668 R327 119-1011-15 1/10W 100 ohm

Q103 125-2041-92

RT1N141M-T111-1

Q817 190-1428-00 2SA1428 R330 119-0000-05 1/10W 0 ohm JW

Q201 125-2027-91 DTC114EUA Q818 192-3668-00 2SC3668 R331 032-0140-89 1/10W 47k ohm F

Q201 125-2041-92

RT1N141M-T111-1

Q819 190-1428-00 2SA1428 R332 032-0140-89 1/10W 47k ohm F

Q206 193-0601-00 2SD601A Q820 192-3668-00 2SC3668 R333 032-0140-89 1/10W 47k ohm F

Q207 198-3018-00 2SK3018 Q821 103-2012-00 2SD2012 R334 032-0140-89 1/10W 47k ohm F

Q208 198-3018-00 2SK3018 Q821 103-2394-00 2SD2394 R335 119-0000-05 1/10W 0 ohm JW

-12-

PF-2945A-A/PF-2982B-A

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

R336 119-0000-05 1/10W 0 ohm JW R573 119-1021-15 1/10W 1k ohm R715 119-4731-15 1/10W 47k ohm

R339 032-0140-50 1/10W 10k ohm F R574 119-4731-15 1/10W 47k ohm R716 119-1021-15 1/10W 1k ohm

R340 032-0140-50 1/10W 10k ohm F R601 119-4721-15 1/10W 4.7k ohm R719 119-1021-15 1/10W 1k ohm

R341 032-0140-50 1/10W 10k ohm F R602 119-4721-15 1/10W 4.7k ohm R720 119-4731-15 1/10W 47k ohm

R342 032-0140-50 1/10W 10k ohm F R603 119-1011-15 1/10W 100 ohm R721 119-4731-15 1/10W 47k ohm

R343 119-0000-05 1/10W 0 ohm JW R604 119-1011-15 1/10W 100 ohm R722 119-4731-15 1/10W 47k ohm

R344 119-0000-05 1/10W 0 ohm JW R605 119-4731-15 1/10W 47k ohm R723 119-1021-15 1/10W 1k ohm

R345 032-0140-50 1/10W 10k ohm F R606 119-4731-15 1/10W 47k ohm R724 119-2231-15 1/10W 22k ohm

R346 032-0140-50 1/10W 10k ohm F R607 119-1041-15 1/10W 100k ohm R725 119-2231-15 1/10W 22k ohm

R348 119-4731-15 1/10W 47k ohm R608 119-1041-15 1/10W 100k ohm R726 116-1211-15 1/4W 120 ohm

R349 119-1031-15 1/10W 10k ohm R609 119-4721-15 1/10W 4.7k ohm R727 116-1211-15 1/4W 120 ohm

R352 119-1021-15 1/10W 1k ohm R610 119-4721-15 1/10W 4.7k ohm R803 119-1041-15 1/10W 100k ohm

R353 119-1021-15 1/10W 1k ohm R611 119-4721-15 1/10W 4.7k ohm R807 119-1041-15 1/10W 100k ohm

R354 119-1021-15 1/10W 1k ohm R612 119-4721-15 1/10W 4.7k ohm R808 119-1041-15 1/10W 100k ohm

R355 119-1021-15 1/10W 1k ohm R614 119-4721-15 1/10W 4.7k ohm R809 116-1521-15 1/4W 1.5k ohm

R358 119-4731-15 1/10W 47k ohm R615 119-4721-15 1/10W 4.7k ohm R810 116-1521-15 1/4W 1.5k ohm

R359 119-4731-15 1/10W 47k ohm R616 119-4731-15 1/10W 47k ohm R813 119-0000-05 1/10W 0 ohm JW

R360 119-4731-15 1/10W 47k ohm R617 119-4731-15 1/10W 47k ohm R814 111-5621-94 1/4W 5.6k ohm

R361 119-4731-15 1/10W 47k ohm R618 119-4731-15 1/10W 47k ohm R815 116-4721-15 1/4W 4.7k ohm

R362 119-4731-15 1/10W 47k ohm R619 119-4731-15 1/10W 47k ohm R829 119-1021-15 1/10W 1k ohm

R363 119-4731-15 1/10W 47k ohm R620 119-4721-15 1/10W 4.7k ohm R830 117-1031-15 1/8W 10k ohm

R364 119-1001-15 1/10W 10 ohm R621 119-4721-15 1/10W 4.7k ohm R831 116-2221-15 1/4W 2.2k ohm

R365 119-4731-15 1/10W 47k ohm R622 119-1031-15 1/10W 10k ohm R832 119-3321-15 1/10W 3.3k ohm

R367 119-0000-05 1/10W 0 ohm JW R623 119-1021-15 1/10W 1k ohm R833 119-1031-15 1/10W 10k ohm

R401 119-4731-15 1/10W 47k ohm R624 119-1011-15 1/10W 100 ohm R834 116-2221-15 1/4W 2.2k ohm

R501 119-1031-15 1/10W 10k ohm R625 119-4721-15 1/10W 4.7k ohm R835 119-4731-15 1/10W 47k ohm

R502 119-1031-15 1/10W 10k ohm R626 119-1011-15 1/10W 100 ohm R836 119-2231-15 1/10W 22k ohm

R503 119-1031-15 1/10W 10k ohm R627 119-4721-15 1/10W 4.7k ohm R837 119-3331-15 1/10W 33k ohm

R504 119-1031-15 1/10W 10k ohm R628 119-4721-15 1/10W 4.7k ohm R838 119-3321-15 1/10W 3.3k ohm

R505 119-1031-15 1/10W 10k ohm R629 032-0140-24 1/10W 82 ohm F R839 119-1031-15 1/10W 10k ohm

R506 119-1031-15 1/10W 10k ohm R630 032-0140-11 1/10W 300 ohm F R840 119-2221-15 1/10W 2.2k ohm

R507 119-0000-05 1/10W 0 ohm JW R631 119-1031-15 1/10W 10k ohm R841 116-4721-15 1/4W 4.7k ohm

R508 119-0000-05 1/10W 0 ohm JW R632 119-1031-15 1/10W 10k ohm R843 111-1831-94 1/4W 18k ohm

R511 119-4741-15 1/10W 470k ohm R633 119-1031-15 1/10W 10k ohm R844 119-1031-15 1/10W 10k ohm

R512 119-4741-15 1/10W 470k ohm R634 119-1021-15 1/10W 1k ohm R845 116-2221-15 1/4W 2.2k ohm

R513 119-4741-15 1/10W 470k ohm R635 119-1031-15 1/10W 10k ohm R846 119-3321-15 1/10W 3.3k ohm

R514 119-4741-15 1/10W 470k ohm R636 116-1001-15 1/4W 10 ohm R847 116-2221-15 1/4W 2.2k ohm

R517 119-0000-05 1/10W 0 ohm JW R638 119-6821-15 1/10W 6.8k ohm R848 111-2221-94 1/4W 2.2k ohm

R518 119-0000-05 1/10W 0 ohm JW R639 119-1011-15 1/10W 100 ohm R849 119-5631-15 1/10W 56k ohm

R519 119-1031-15 1/10W 10k ohm R640 119-1011-15 1/10W 100 ohm R850

111-2721-88

1/2W 2.7k ohm

R520 119-1031-15 1/10W 10k ohm R641 119-4721-15 1/10W 4.7k ohm R851 111-1521-94 1/4W 1.5k ohm

R521 119-1531-15 1/10W 15k ohm R642 119-4721-15 1/10W 4.7k ohm R852 111-1521-94 1/4W 1.5k ohm

R522 119-1531-15 1/10W 15k ohm R643 119-4731-15 1/10W 47k ohm R853 111-1521-94 1/4W 1.5k ohm

R523 119-0000-05 1/10W 0 ohm JW R644 119-4731-15 1/10W 47k ohm R854 119-1231-15 1/10W 12k ohm

R524 119-0000-05 1/10W 0 ohm JW R645 119-6831-15 1/10W 68k ohm R855 119-1231-15 1/10W 12k ohm

R525 119-0000-05 1/10W 0 ohm JW R646 119-3341-15 1/10W 330k ohm R856 119-4731-15 1/10W 47k ohm

R526 119-0000-05 1/10W 0 ohm JW R647 032-0140-22 1/10W 68k ohm F R857 119-4731-15 1/10W 47k ohm

R527 119-1031-15 1/10W 10k ohm R648 032-0140-00 1/10W 56k ohm F R858 116-1021-15 1/4W 1k ohm

R528 119-1031-15 1/10W 10k ohm R649 119-4731-15 1/10W 47k ohm R859 119-4711-15 1/10W 470 ohm

R529 119-1031-15 1/10W 10k ohm R650 119-5621-15 1/10W 5.6k ohm R860 116-5621-15 1/4W 5.6k ohm

R530 119-1031-15 1/10W 10k ohm R651 119-1021-15 1/10W 1k ohm R861 119-1031-15 1/10W 10k ohm

R531 119-1531-15 1/10W 15k ohm R652 119-4731-15 1/10W 47k ohm SUP102

060-0122-91

DSP-141N-S00B

R532 119-1531-15 1/10W 15k ohm R653 119-3321-15 1/10W 3.3k ohm TH801 002-0318-21 THERMISTOR

R533 119-1031-15 1/10W 10k ohm R654 119-1831-15 1/10W 18k ohm TM101 073-0762-90 TERMINAL

R534 119-1031-15 1/10W 10k ohm R701 119-2231-15 1/10W 22k ohm TM201 073-0762-90 TERMINAL

R535 119-1031-15 1/10W 10k ohm R702 119-2231-15 1/10W 22k ohm TM401 073-0762-90 TERMINAL

R536 119-1031-15 1/10W 10k ohm R703 119-1041-15 1/10W 100k ohm TM601 073-0762-90 TERMINAL

R537 119-5631-15 1/10W 56k ohm R704 119-1021-15 1/10W 1k ohm TM801 073-0762-90 TERMINAL

R538 119-1521-15 1/10W 1.5k ohm R705 119-1021-15 1/10W 1k ohm TM802 073-0762-90 TERMINAL

R539 119-1031-15 1/10W 10k ohm R706 119-4731-15 1/10W 47k ohm Z101 073-0778-90 TERMINAL

R540 119-2221-15 1/10W 2.2k ohm R707 119-4731-15 1/10W 47k ohm Z201 073-0778-90 TERMINAL

R541 119-2221-15 1/10W 2.2k ohm R708 119-4731-15 1/10W 47k ohm Z301 073-0778-90 TERMINAL

R542 119-2221-15 1/10W 2.2k ohm R709 119-1021-15 1/10W 1k ohm X201 061-3534-90 16.92MHz

R543 119-2221-15 1/10W 2.2k ohm R710 119-2231-15 1/10W 22k ohm X301 061-3537-90 41.6MHz

R544 119-4731-15 1/10W 47k ohm R711 119-2231-15 1/10W 22k ohm X601 061-3541-90

CRYSTAL 10MHz

R545 119-4731-15 1/10W 47k ohm R712 119-1021-15 1/10W 1k ohm PWB

039-3180-00

PWB(WITHOUT

R546 119-1031-15 1/10W 10k ohm R713 119-1041-15 1/10W 100k ohm COMPONENT)

R572 119-8211-15 1/10W 820 ohm R714 119-4731-15 1/10W 47k ohm

PF-2945A-A/PF-2982B-A

-13-

Switch PWB(B2) section

Sub PWB(B3) section

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

C901 166-1007-50 50V 10pF C905 166-1007-50 50V 10pF PWB 039-3062-00 PWB(WITHOUT

C902 166-1007-50 50V 10pF J901 074-0898-06 6P COMPONENT)

C903 172-1041-11 50V 0.1uF J902 074-0898-10 10P

C904 166-1007-50 50V 10pF J903 074-4027-20 20P

CD mechanism section: 929-5000-80
SENSOR PWB(B4) section

CD PWB(B5) section

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

C1 168-1042-78 16V 0.1uF C27 046-3332-78 0.033uF R2 117-1001-15 1/8W 10 ohm

C2 163-1073-35 16V 100uF C29 046-6822-58 6800pF R3 033-2211-15 1/10W 220 ohm

C4 178-1052-78 1uF C30 168-1042-78 16V 0.1uF R5 033-0000-05 1/10W 0 ohm

C5 042-0560-85 6.3V 100uF C31 046-4712-58 470pF R6 033-5621-15 1/10W 5 .6k ohm

C6 178-1052-78 1uF C32 046-4712-58 470pF R7 033-4731-15 1/10W 47k ohm

C8 178-1052-78 1uF C33 168-1042-78 16V 0.1uF R8 033-3341-15 1/10W 330k ohm

C10 168-1042-78 16V 0.1uF C34 168-4732-78 16V 0.047uF R9 033-2231-15 1/10W 22k ohm

C11 168-1042-78 16V 0.1uF C35 168-4732-78 16V 0.047uF R10 033-2231-15 1/10W 22k ohm

C12 045-4701-50 47pF C36 045-1007-50 10pF R11 033-2731-15 1/10W 27k ohm

C13 046-1532-78 0.015uF C37 045-1007-50 10pF R12 033-4731-15 1/10W 47k ohm

C14 168-1042-78 16V 0.1uF C38 168-1042-78 16V 0.1uF R13 033-2731-15 1/10W 27k ohm

C15 046-1032-78 0.015uF C39 046-5622-58 5600pF R14 033-1531-15 1/10W 15k ohm

C17 046-4722-58 4700pF C40 168-1042-78 16V 0.1uF R15 033-2731-15 1/10W 27k ohm

C18 046-1522-58 1500pF CCT1 050-0140-63

1/32W 47k ohm x4J

R16 033-8231-15 1/10W 82k ohm

C19 168-1042-78 16V 0.1uF D3 001-0367-91 1SS226 R17 033-2731-15 1/10W 27k ohm

C20 168-1042-78 16V 0.1uF IC1 051-6079-90 BA5830FP-E2 R18 033-8231-15 1/10W 82k ohm

C21 046-6812-58 680pF IC2 051-6399-00 TC94A15F R19 0 33-1051-15 1/10W 1M ohm

C22 168-1042-78 16V 0.1uF J101 074-1228-79 29P R20 119-2221-15 1/10W 2.2k ohm

C23 046-1532-78 0.015uF J201 074-1138-65 15P X2 061-3534-90 16.92MHz

C24 168-1042-78 16V 0.1uF J301 074-1138-60 10P PWB 039-2741-20 PWB(WITHOUT

C25 045-6801-50 68pF Q3 131-1188-50 2SB1188PQR COMPONENT)

C26 168-1042-78 16V 0.1uF R1 117-6811-15 1/8W 680 ohm

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

C1 168-1022-55 1000pF K D29 001-7094-91 VFR1112H-TR R15 119-1231-15 1/10W 12k ohm

C2 168-1042-78 16V 0.1uF D30 001-7094-91 VFR1112H-TR R16 119-1031-15 1/10W 10k ohm

C3 043-0328-90 0.1uF D31 001-7094-91 VFR1112H-TR R17 119-1231-15 1/10W 12k ohm

C4 043-0328-90 0.1uF D32 001-7094-91 VFR1112H-TR R18 119-1031-15 1/10W 10k ohm

C5 178-1052-78 1uF D33 001-7094-91 VFR1112H-TR R19 119-1231-15 1/10W 12k ohm

D5 001-7094-91 VFR1112H-TR D34 001-7094-91 VFR1112H-TR R20 119-4721-15 1/10W 4.7k ohm

D7 001-7094-91 VFR1112H-TR D35 001-2403-90 M1F60 R21 119-4721-15 1/10W 4.7k ohm

D8 001-7094-91 VFR1112H-TR D36 001-2403-90 M1F60 R22 119-3921-15 1/10W 3.9k ohm

D9 001-7094-92

VFR1112H-6A83A2

D37 001-2403-90 M1F60 R23 119-3921-15 1/10W 3.9k ohm

D10 001-7094-92

VFR1112H-6A83A2

D38 001-7094-91 VFR1112H-TR R24 119-3921-15 1/10W 3.9k ohm

D11 001-7094-92

VFR1112H-6A83A2

D39 001-7094-91 VFR1112H-TR R25 119-3921-15 1/10W 3.9k ohm

D12 001-7094-92

VFR1112H-6A83A2

FL1 379-4062-24

VFD(INDICATOR)

R26 119-3921-15 1/10W 3.9k ohm

D13 001-7094-92

VFR1112H-6A83A2

IC1 051-6642-08 LC75700T R27 119-4721-15 1/10W 4.7k ohm

D14 001-7094-92

VFR1112H-6A83A2

IC2 051-6059-10 ML9203-06GA R28 119-3921-15 1/10W 3.9k ohm

D15 001-7094-92

VFR1112H-6A83A2

J1 074-3014-78 28P R29 119-4721-15 1/10W 4.7k ohm

D16 001-7094-92

VFR1112H-6A83A2

L1 010-3407-66 22uH J R30 119-2721-15 1/10W 2.7k ohm

D17 001-7094-91 VFR1112H-TR L2 010-3407-66 22uH J R31 119-3321-15 1/10W 3.3k ohm

D18 001-7094-91 VFR1112H-TR R1 119-1031-15 1/10W 10k ohm R32 119-2721-15 1/10W 2.7k ohm

D19 001-7094-91 VFR1112H-TR R2 119-1021-15 1/10W 1k ohm R33 119-3321-15 1/10W 3.3k ohm

D20 001-7094-91 VFR1112H-TR R3 119-3931-15 1/10W 39k ohm R35 119-3921-15 1/10W 3.9k ohm

D21 001-7094-91 VFR1112H-TR R4 119-0000-05 1/10W 0 ohm JW R36 119-4721-15 1/10W 4.7k ohm

D22 001-7094-91 VFR1112H-TR R6 119-6821-15 1/10W 6.8k ohm R37 119-1021-15 1/10W 1k ohm

D23 001-7094-91 VFR1112H-TR R7 119-8221-15 1/10W 8.2k ohm TM1 073-0778-90 TERMINAL

D24 001-7094-91 VFR1112H-TR R10 119-6821-15 1/10W 6.8k ohm VR1 016-0018-21 EC11E15644

D25 001-7094-91 VFR1112H-TR R11 119-6821-15 1/10W 6.8k ohm VR2 016-0018-21 EC11E15644

D26 001-7094-91 VFR1112H-TR R12 119-1031-15 1/10W 10k ohm X1 060-1550-90 4.023MHz

D27 001-7094-91 VFR1112H-TR R13 119-1231-15 1/10W 12k ohm PWB 039-3063-00 PWB(WITHOUT

D28 001-7094-91 VFR1112H-TR R14 119-1031-15 1/10W 10k ohm COMPONENT)

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

REF No.

PART No. DESCRIPTION

D1 001-7058-90 AN1105W-RR Q1 060-4015-91 PS1192HB S2 013-7413-50 LIMIT

D2 001-7058-90 AN1105W-RR Q2 060-4015-91 PS1192HB PWB 039-2675-20 PWB(WITHOUT

J1 074-1138-60 10P S1 013-7414-50 CHUCKING COMPONENT)

-14-

PF-2945A-A/PF-2982B-A

CONNECTIONS

1
2
3
4

5
6

7
8

N.C

N.C

No.

Description

N.C
N.C

AUX O N+
AUX R +
AUX LR­AUX L +

1

3

5

7

2

4

6

8

1

325

4

7

6

9

8

111013

12

15

14

17

16

19

18

20

1
2
3
4
5
6
7

11
12

13
14

15
16

B/U

FR+

No.

Description

No.

Description

FL+

CAN+

N.C
ANT ON

FR­FL-

RL­S.R­S.R+
N.C
ACC

8
9

10

RR+

RL+
RR-

17
18

19
20

GND

ILL­CAN­ILL+

SIE-BUS cable

AUX kit

Steering wheel
Remote control

ECU unit

Main Connector

CAR STEREO

Main unit

SIRIUS-TUNER-BB
(EF-1327A-A)

SIE- BUS

XM-TUNER-BB
(EF-1247S-B)

SIE- BUS

CD-A/C

or

or

SIE- BUS

AUX

Rear view

SIE-BUS

AUX

Main Connector

Main Connector

1
2
3
4
5
6
7

11
12

13
14

15
16

B/U

GND

No.

Description

No.

Description

BUS-

N.C

BUS OFF
BUS+

BUS GND
MUTE

N.C
N.C
N.C
N.C
R-CH

8
9

10

RESET

BUS ON
N.C

17
18

19
20

NAVI GND

L-CH
AUDIO GND
NAVI SIG

1

2

3

4

5

6

7

8

9

10

111213

14

15

16

17

18

19

20

SIE-BUS

-15-

PF-2945A-A/PF-2982B-A

AB

A: Main
B: N.C

ANTENA

ANT JUMPER

PRINTED WIRING BOARD 1/6

Sub PWB(B3) section

SOLDER SIDE

Caution:
COMPONENT SIDE: Parts on the component
side seen from the component side are indicated.
SOLDER SIDE: Parts on the solder side seen
from the solder side are indicated.

COMPONENT SIDE

1

1

2

9

10

1

2

5

6

2

1
2
3
4
5
6
7

11
12

13
14

15
16

B/U

GND

No.

Description

No.

Description

BUS-

N.C

BUS OFF
BUS+

BUS GND
MUTE

N.C
N.C
N.C
N.C
R-CH

8
9

10

RESET

BUS ON
N.C

17
18

19
20

NAVI GND

L-CH
AUDIO GND
NAVI SIG

3

4

5

6

7

8

9

10

111213

14

15

16

17

18

19

20

J903

1

2

9

10

1

2

5

6

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

The parts of a dotted line express the parts on a

component side.

To P701 of Main

PWB(B1) (page 17)

To P702 of Main

PWB(B1) (page 17)

-16-

PF-2945A-A/PF-2982B-A

COMPONENT SIDE

PRINTED WIRING BOARD 2/6

Main PWB(B1) section 1/2

Caution:

COMPONENT SIDE: Parts on the component side seen

from the component side are indicated.

IC Q

PF-2945A-A/PF-2982B-A

-17-

J801

J802

1
2
3
4

5
6
7
8

N.C

N.C

No.

Description

No.

Description

N.C
N.C

AUX ON+
AUX ON+
AUX LR­AUX L +

800-0205-00

VINYL-COAT-WIRE

ANT JUMPER

093-2137-01

To J1 of CD PWB(B5) (page 28)

To J901 of Switch PWB(B2) (page 20)

FLAT WIRE 816-4025-50

To J901 of Sub

PWB(B3) (page 16)

To J902 of Sub

PWB(B3) (page 16)

13254

7

6

9

8

111013

12

15

14

17

16

19

18

20

1

325

4

7

6

9

8

111013

12

15

14

17

16

19

18

20

1
2
3
4
5
6
7

11
12
13
14
15
16

B/U

FR+

No.

Description

No.

Description

FL+

CAN+

N.C
ANT ON

FR­FL-

RL­S.R­S.R+
N.C
ACC

8
9

10

RR+

RL+
RR-

17
18
19
20

GND

ILL­CAN­ILL+

2

1

4

3

6

5

8

7

135

7

2

4

6

8

AB

A: Main
B: N.C

ANTENA

PRINTED WIRING BOARD 3/6

Main PWB(B1) section 2/2

SOLDER SIDE

Caution:

SOLDER SIDE: Parts on the solder side seen

from the solder side are indicated.

The parts of a dotted line express the parts on a component side.

PF-2945A-A/PF-2982B-A

-18-

A

B

CD

E

F

G

H

B

A

C

DE

L

M

N

O

FGHIJK

P

QR

S

T

1

31

51

81

TUNE/TRACK/CH

POWER/VOLUME

CD/AUX

FM/AM

SAT

TEXT

RPT/RDM

SCAN

RUBBER SWITCH C

(345-6072-00)

MENU

1

2

3

4

5 6

COMPONENT SIDE

Caution:
COMPONENT SIDE: Parts on the component side seen

from the component side are indicated.

PRINTED WIRING BOARD 4/6

Switch PWB(B2) section 1/2

-19-

PF-2945A-A/PF-2982B-A

RUBBER SWITCH A
(345-6070-00)

PTY/CAT

RUBBER SWITCH C

(345-6072-00)

RUBBER SWITCH D
(345-6073-00)

RUBBER SWITCH B
(345-6071-00)

1

11

1

2

27

28

To P602 of Main PWB(B1) (page 17)

SOLDER SIDE

-20-

PRINTED WIRING BOARD 5/6

Switch PWB(B2) section 2/2

The parts of a dotted line expressthe parts on acomponent side.

PF-2945A-A/PF-2982B-A

Caution:
SOLDER SIDE: Parts on the solder side seen

from the solder side are indicated.

1
2
3
4
5
6
7

11
12
13
14
15
16

B/U

GND

No.

Description

No.

Description

BUS-

N.C

BUS OFF
BUS+

BUS GND
MUTE

N.C
N.C
N.C
N.C
R-CH

8
9

10

RESET

BUS ON
N.C

17
18
19
20

NAVI GND

L-CH
AUDIO GND
NAVI SIG

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

To P701 of Main

PWB(B1) (page 24)

To P702 of Main

PWB(B1) (page 24)

-21-

PF-2945A-A/PF-2982B-A

CIRCUIT DIAGRAM 1/10

Sub PWB(B3) section

To3/7 (page23)

To6/7 (page25)

To4/7 (page24)

To7/7 (page26)

CIRCUIT DIAGRAM 2/10

Main PWB(B1) section 1/7

NJM2886DL3-05-TE1

800-0205-00

VINYL-COAT-WIRE

30uH

A03

BL101---7Pin

D03

D01

BL101---9Pin

BL101---11,12Pin

Wavefor m

Waveform point

J902---5,6Pin

J903---3,5Pin

Wavefor m

Waveform point

F02

CIRCUIT DIAGRAM 3/10

Main PWB(B1) section 2/7

-22-

PF-2945A-A/PF-2982B-A

To6/7 (page25)

To6/7 (page25)

To3/7 (page23)

To7/7 (page26)

To7/7 (page26)

x4

To J101 of CD PWB(B5) (page 28)

connect with 816-4025-50 FLAT WIRE

MSM51V17400D-60TS-K

TC94A34FG-004

NJU7780U1-15-TE2

NJU7780U1-15-TE2

NJM2386ADL3-33-TE1

30uH

D03

IC204---58,59Pin

J201---12,13,14,15,16,17Pin

IC202--2,3,22,23Pin

IC202--4,5,20,21Pin

IC204--14,15,16,17,19,

22,24,25,26,27Pin

IC204--6,7Pin

R230,R233,
Q207,Q208

IC202---7,8,9,10,11,14,15,16,

17,18,19Pin

IC204---43,44,45,46,47,48,49,50,

51,52,53Pin

IC204--32,33,34,35Pin

IC208--2,3,4,5,7,8,12,

13,15,16,17,18Pin

J201---1,2,3,4,5,6Pin

J201---19Pin

IC208---6,14Pin
Q206

R227,R228

IC204---11,12,13Pin

IC204---18Pin

Wavefor m

Wavefor m

point

Wavefor m

Wavefor m

point

C02

C02

D01

D02

A01

C01

C01

C03

Wavefor m

Wavefor m

point

CIRCUIT DIAGRAM 4/10

Main PWB(B1) section 3/7

-23-

PF-2945A-A/PF-2982B-A

To1/7 (page21)

To7/7 (page26)

To5/7 (page24)

To2/7 (page22)

To6/7 (page25)

To4/7 (page24)

To7/7 (page26)

x4

x4

NJM2386ADL3-33-TE1

0 ohm(JW)

IC301---51,52,53,

56,57Pin

IC301---131,132Pin

Q302,Q303

IC301---28,29Pin

Wavefor m

Wavefor m

point

Wavefor m

Wavefor m

point

D01

A01

C02

CIRCUIT DIAGRAM 5/10

Main PWB(B1) section 4/7

-24-

PF-2945A-A/PF-2982B-A

CIRCUIT DIAGRAM 6/10

Main PWB(B1) section 5/7

To3/7 (page23)

To1/7 (page21)

To7/7 (page26)

To6/7 (page25)

To3/7 (page23)

To7/7 (page26)

To6/7 (page25)

To J901 of Sub

PWB(B3) (page 21)

To J902 of Sub

PWB(B3) (page 21)

NJM2386ADL3-09-TE1

Wavefor m

Waveform point

F02

P702---5,6Pin

Wavefor m

Wavefor m point

D01

IC503---16Pin
C531
BEEP

CIRCUIT DIAGRAM 7/10

Main PWB(B1) section 6/7

-25-

PF-2945A-A/PF-2982B-A

To J1 of Switch PWB(B2) (page 27)

To3/7 (page23)

To1/7 (page21)

To2/7 (page22)

To7/7 (page26)

To7/7 (page26)

To4/7 (page24)

To5/7 (page24)

x4

x4

x4

x4

( FIASH-WRITE)

M30876FJAGP

S-24CS16A01

-T8T1G

IC601---18,19,26Pin

IC601---25,73Pin

IC601---81,98,99Pin

IC601---3,4,79,82,83,Pin

IC601---33,34,77,78,84Pin

P602---11,12,18Pin

P602---13,16,17Pin

IC601---11,13Pin

IC602---5,6Pin

IC601---27,28,50,51,52,

53,54,55Pin

Wavefor m

Wavefor m

point

C03

C04

C02

D01

D02

D03

A01

P602---15Pin

F02

IC603---5,6Pin

Wavefor m

Waveform point

CIRCUIT DIAGRAM 8/10

Main PWB(B1) section 7/7

-26-

PF-2945A-A/PF-2982B-A

To6/7 (page25)

To3/7 (page23)

To5/7 (page25)

To2/7 (page22)

To4/7 (page24)

To5/7 (page24)

To4/7 (page24)

To3/7 (page23)

To1/7 (page21)

1

2

7

8

3

4

5

6

1
2
3
4

5
6
7
8

N.C

N.C

No.

Description

N.C
N.C

AUX ON+
AUX R +
AUX LR­AUX L +

2

3

18

20

1
2
3
4
5
6
7

11
12
13
14
15
16

B/U

FR+

No.

Description

No.

Description

FL+

CAN+

N.C
ANT ON

FR­FL-

RL­S.R­S.R+
N.C
ACC

8
9

10

RR+
RL+
RR-

17
18
19
20

GND

ILL­CAN­ILL+

4

5

1

6

7

8

9

10

11

12

13

14

15

16

17

19

IC802---3,4,9,11,12Pin
Q815 Q820
D815
C828

IC802---1,2,6,7Pin
Q816 Q818 Q820

Q817 Q819

Wavefor m

Wavefor m

point

Wavefor m

Wavefor m

point

D01

E05

E04

To P602 of Main PWB(B1) (page 25)

CIRCUIT DIAGRAM 9/10

Switch PWB(B2) section

-27-

PF-2945A-A/PF-2982B-A

J1---11,12, 18Pin
IC1---20Pin
IC2---66,67Pin

IC2---68Pin

IC2---63,64Pin

IC1---18,19Pin

J1---13,16,17Pin

J1---15Pin

IC1---1,2,3,4,5,6,

7,8,9,10,Pin

Wavefor m

Wavefor m

point

C03

C04

D03

Wavefor m Wave form

Wavefor m

point

Wavefor m point

C05

IC1---17Pin

VOLUME

POWER

TUNE

EJECT

TONE

IC2---1~52Pin

IC2---53~60Pin

IC2---71~78Pin

IC2---79~100Pin

B04

D02

A01

P

Q

T

S

S

L

M

N

U

F

E

D

C

B

A

I

K J

G

A

B

C D

E

F

J

I

K

O

P

Q

H

L

M

N

R

S

T

U

V

KEY NAME

A
B
C
D
E
F
G
H

I
J
K

L
M
N
O
P
Q
R
S

T

V

U

1
2
3
4
5
6

EJECT

--------

CD/AUX

FM/AM

SAT

TEXT

RPT/RDM

SCAN

POWER/VOLUME

PTY/CAT

SEEK DOWN

SEEK UP

FOLDER UP

FOLDER DOWN

MENU

TB/TUNE

MARK

CD INSERTL

CD INSERTL

-28-

PF-2945A-A/PF-2982B-A

PRINTED WIRING BOARD 6/6

SENSOR PWB(B4)/CD PWB(B5) section

CD PWB(B5)

CD PWB(B5)

SENSOR PWB(B4)

SENSOR PWB(B4)-B

GR

N

(-

)

FLATWIRE

816-2542-01

PICK UP-ASSY

(969-0071-30)

SPINDLE MOTOR-ASSY

With LEAD

(SMA-182-100)

S

L

ED MOTOR-ASSY

(

SMA-183-10

0

)

O

RG(

+

)

R

E

D

(+)

B

L

K(

-)

ToJ201 of Main PWB(B1)(page17)

GR

N

O

R

G

B

L

K

RE

D

BLU

PU

R

YE

L

P

UR

YE

L

B

L

U

SENSOR PWB(B4)-A

IC Q

MARKING

+

+

COMPONENT SIDE

SOLDER SIDE

Caution:
COMPONENT SIDE: Parts on the component side seen

from the component side are indicated.

SOLDER SIDE: Parts on the solder side seen

from the solder side are indicated.

29

FLATWIRE

816-4025-50

CIRCUIT DIAGRAM 10/10

SENSOR PWB(B4)/CD PWB(B5) section

SENSOR-A

SENSOR-

B

TO PICK UP-ASSY

ToJ201 ofMain PWB(B1)

connect with 816-4025-50 FLAT WIRE

CD PWB(B5)

SENSOR

PWB(B4)

(page 22)

RF-AMP AND

DIGITAL SERVO PROCESSOR

D

R

I

VER WI

TH

R

EG.

CONTROL

LER

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨٨

٨

٨

٨

٨

٨٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

٨

CCT1

47KX4

1

2

3

4

5

6

7

8

9

10

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

1

7

1

8

19

20

21

22

23

24

25

26

2

7

28

29

SBOK

IPF

CLC

K

VD
D3

V
S
S3

DATA

S
FS

Y

SBSY

AR
S

EL

A
W
RC

PVD

D3

PD
O

T
M
AXS

L
PFN

L
PFO

PV
R

E
F

VCO

F

VC
O

R
E
F

DTCN

DTCP

PV
SS3

T
MAX

SLCO

RFRPI

RFI

RFEQO

AVDD3

RESIN

VRO

VMDIR

TESTR

AGCI

RFDCI

RFO

PNSEL

EQSET

RVDD3

MDI

FNI2

FNI1

FPI1

TNI

RFZI

AV
SS3

RFRP

RFDC

FEI

SBAD

TEI

TEZI

AVDD3

F
OO

T
RO

V
RE

F

F
M
O

D
M
O

M
ONIT

FGI

N

V
S
S3

TES

IN

XV
S

S
3

XI

XO

DVSS3

RO

DVDD3

DVR

LO

DVSS3

ZDET

VSS5

BUS0

BUS1

BUS2

BUS3

BUCK

VDD5

IO0B

IO1B

IO2B

IO3B

EMPH

BCK

AOUT

LRCK

DOUT

X
V
DD3

VDD3

RVSS3

S

L-

SL

+

S

P-

SP

+

SS

TOP

CHU

TR-BTR-A

G

ND

F

C

S

(

+

)

1

2

3

4

5

6

7

8

9

1

0

1

1

1

2

1

3

1

5

1

4

F

C

S

(

-

)

TRK(

-)

T

R

K

(

+

)

F

V

C

V

C

C

L

D

G

N

D

V

R

P

D

B

A

E

C

8V

8

V

T

R

-B

TR-A

C

H

U

-SW

SB

SY

BUCK

BUS3

BUS

2

BUS1

GN

D

BUS

0

/CCE

/

RESE

T

P-GND

P-G

N

D

SS

T

OP

INVSEL

LDO

FPI2

TPI

/CCE

/RST

CLV

:L

L

ED+

LCONT

LDMUT

fc=13.5KHz

IO0

A

IO
1A

IO2

A

IO
3A

AOUT

LRC

K

BC

K

SFSY

MBO

V

IPF

C

D-VDD

IF-VDD

DAT

A

CLC

K

VO2+

VO2-

VO1+

PwVCC

PwGND

MUTE

PrGND

REG

OPIN2

OPOUT2

OPIN1

OPOUT1

REG-B

VO-

VO3+

VO3-

VO4+

PwVCC2

PwGND

VO4-

CNT

LDIN

OPOUTSL

OPINSL-

OPOUT3

OPIN3

BIAS

PrVCC

S

L-

SL+

SP-

SP+

PHOT

O-B

PHOT

O

-A

GND

LED

+

1

2

3

4

5

6

7

8

9

10

C

HUCK-SW

LIMI

T-SW

J

201

R

2

C11

C

13

C

1

5

R

3

C17

C18

C19 C20

C21

C22

C25

C26

C

2

7

C29

C31

C33

C38

C39

R

6

R

7

R

8

R

9

R10

R13

R

15

TP18

TP19

R

5

C

6

R12

X2

C

10

C14

R16

R18

R17

R19

R

20

D

3

Q3

C4

C5

C

30

R11

C35

IC1

C34

C32

C

1

C

2

R1

D2

D

1

S1

S2

Q2

Q1

J

1

J

301

J

101

C36

C37

C12

C40

R14

IC2

C8

C23

C24

1

0

0

.

1

0.

015

0.01

2

2

0

4700p

1500p

0.1 0.1

680p

0.1

68p

0.1

0

.

0

3

3

6800p

470p

0.1

0.1

5600p

5.

6

K

47K

33

0K

22K

22K

27K

27K

LD-

LD+

FTE

0

1

47K

16.

92M

0

.

1

0.1

82K

82K

2

7K

1M

2.

2

K

1

S

S

2

2

6

T

E

8

5

L

2SB1188

1

100

6.3V

0.

1

27K

0.047

BA5830FP

0.047

470p

0.

1

100

16V

680

AN1105W-RR

AN

1105W-

R

R

SPVG22

SP

VG12

PS1192HB

PS1192HB

SP+

SP-

SL+

SL-

GND

10p

10p

47p

0.1

15K

TC94A15FG

1

0.015

0.1

A-3.3V

8V

D-3.3V

IF-VDD

T

R-A

C

HU

SST

OP

T

R-A

C

HU

SST

O

P

BUS0

BUS1

BUS2

BUS3

/CCE

BUCK

SP+

S

P-

SL+

S

L-

F

-

T

+

F

+

T

-

T

R-B

T

R-B

/RST

LRCK

BCK

AOUT

F-

F+

T-

T+

SBSY

/RST

/

C

C

E

B

U

CK

B

U

S3

B

U

S2

B

U

S1

B

U

S0

I

P

F

M

BOV

CLCK

D

AT

A

S

F

SY

BCK

LR

C

K

AO

U

T

SL-

SL+

SP+

SP-

I

PF

M

BOV

C

LCK

D

ATA

SFSYSBSY

C

C

C

C

C

C

C

C

C

C

CCC

C

C

C

C

C

C

C

1 2 3 4 5 6 7 8 9101112131415161718192021222324

31

32

33

34

35

36

37

38

39

40

565758596061626364

25

41

42

43

44

45

46

47

48

49

50

6566676869707172737475

81

82

83

84

85

86

87

88

89

90

91

92

93

94

95

96

97

98

99

100 26

27

28

29

30

80

79

78

77

76

5152535455

C

C

C

C

C

C

C

C

C

C

C

C

C

1

2

3

4

5

6

7

8

9

10

11

12

13

14

21

27

28

22

23

24

25

26

15

16

17

18

19

20

0V

0V

8V

1.

7V

0.

8V

1

.

7V

1.4V

1

.

7V

1.

7V

1.

7V

3.

3V

0V

3.

3V

0V

0V

1.7V

0V

3.3V

0V

0V

3.

3V

0V

1.

8V

1.

7V

1

.

7V

1.

7V

1.7V

3.

3V

1

.

7V

1.7V

1.

7V

2

.0 ~ 2.8V

0V

1.7 ~ 2.0V

0V

0.2V

2.4V

3.3V

0.6 ~ 1.8V

1.1 ~ 2.4V

1.6V

1.5V

1.7V

1.5V

3.3V

~2.3V

1.7V

0V

0V

3.3V

1

.

8

~

2

.

2

V

3.3V

3

.

3

V

1

.

7

V

0

V

0

.

1

9

V

0

.

1

5

V

1.7V

1.8V1.7V

0V

0V

8V

3.8V

3.8V

3.8V

4.0V

3.6V

4.0V

3.6V

4.0V

8V

0V

1.8V

1.7V

1.6V

1.7V

1.7V

7.9V

3.

3V

3.3V or 5V

0/IF-VDD

0/IF-VDD 3.3V

3.3V

0/IF-VDD

0/IF-VDD

0/IF-VDD

0/

IF-

VDD

3.3V or 5V

1.8V

0.6 ~ 1.8V

1

.

3

~

2

.

2

V

0.6 ~ 1.8V

1.0 ~ 2.3V

1.0

1

.

8

~

2

.

2

V
