1
Overview
1
Your Security System
Your security system includes a number of detection devices, such
as magnetic contacts, glassbreak detectors, smoke detec-
tors, and motion sensors. These devices identify alarm condi-
tions and report them to the control panel. If programmed, the
control panel sounds an alarm. The control panel also communicates with you (through the keypad) and with a monitoring sta-
tion (through a telephone hook-up).
Each region monitored by a sensor (or group of sensors) is known
as a zone. Most zones will trigger an alarm only when the system is armed. Other sensors, such as smoke detectors, can trigger an alarm at any time. Your system's zones are identified on a
label placed inside the door of your keypad.
Monitoring station personnel respond to system messages, and
notify emergency personnel as needed. A monitoring service is
an optional part of a security system.
Smoke Detector
Motion Sensor
(Interior Protection)
ZONE
ZONE
ZONE
Magnetic Contact
Glassbreak Detector
(Perimeter Protection)
Keypad
CONTROL
PANEL
Siren (Alarm)
Monitoring Station
1
Overview
2
How Your Security System Works
When an intruder enters the building, a detection device is triggered. The device sends a message to the control panel. The
device may have LEDs (lights) that blink.
The control panel responds by sounding the alarm. (Alarm sounds
vary. If your system is programmed for silent alarms, no bells
sound.) A message is sent to the keypad and, if connected, to the
monitoring station.
The keypad displays a warning message. Personnel at the monitoring station confirm the alarm and respond accordingly.
Some alarms can be canceled before the siren sounds and the
monitoring station is notified. See Section 4 for more information.
Intruder
Sensor
Triggers Alarm
CONTROL
PANEL
Siren
Sounds Alarm
Keypad
Issues Warnings
Monitoring
Station Is Notified
1
Overview
3
Your System's Programming
Your Sierra security system has been customized to suit your
needs. Besides selecting the best equipment for your building,
your installer has programmed your system to operate in a way
that reflects your lifestyle. For example, your system may be programmed to recognize special user codes, to arm and disarm
automatically, or to report to a monitoring station.
Throughout this manual, you will find descriptions of features that
may have been programmed into your system. To see how your
system was programmed, refer to the checklist in Section 8.
Getting Used to Your System
Your security system can be programmed for a learning period
that can last from one to 31 days. With this option, you can practice using your system without causing any false alarms. Refer to
Section 8 to see if this learning period was programmed into your
system.
During the learning period, your system does two things differently. First, during an alarm, you do not hear any sirens or bells.
Second, if you have a monitoring station hook-up, your system
does not notify the station of an alarm.
After the learning period is over, your system automatically begins to function normally. If programmed, sirens and bells sound
during an alarm, and the monitoring station receives information
over the telephone hook-up.
IMPORTANT: Your building is not fully protected from actual
alarms during the learning period.
1
Overview
4
The Parts of Your Keypad
Arm LED
If on, the system is armed.
If off, the system is disarmed.
If blinking, the system is about to arm;
leave the building.
Power LED
If on, the system's power
supply is normal.
If off, the system is drawing
power from the battery.
If blinking slowly, the battery is
about to fail.
Numeric Keys
Used to enter
user codes and
perform other
functions.
Emergency Keys
To notify your monitoring station
of an emergency, press and
hold for two seconds until you
hear an alarm. (Keys must be
programmed to function.)
—for a medical emergency
—for a fire
—for a crime in progress
MED
FIRE
POLICE
Display
Describes the system's status,
such as:
—if the system is ready to arm
—if an alarm has occurred
—if a zone is faulted
—other special information
Secondary Function
Keys
Press and hold the key
for two seconds to
make changes to the
system.
1
Overview
5
Emergency Keys
Your keypad is equipped with
three emergency keys. The
keys do not function unless
your installer activated them. If
activated, these keys are a
one-button way to inform your
monitoring station of a medical
emergency, a fire, or a crime in
progress.
Depending upon how your system is programmed, an alarm
may sound when an emergency key is pressed. To can-
cel the alarm, press the
key and enter your
user code.
After you press an emergency
key, your keypad's display
shows that an emergency
alarm occurred. To clear the
display, press and hold the
key for two seconds.
To Use Emergency Keys:
1. To report a medical emergency, press and hold the
key for 2 seconds
until you see:
EMERGENCY ALARM
2. To report a fire, press and
hold the key for 2
seconds until you see:
FIRE ALARM
3. To report a crime in progress,
press and hold the
key for 2 seconds until you
see:
POLICE ALARM
1
Overview
6
System Status Messages
Your keypad's display gives you information about the status of
your system. If there is more than one condition to report, your
keypad displays each message in turn.
Below is a list of the types of messages you may see. On your
display, the # symbol is replaced with the number of the zone, or
zones, in question. For more information about many of these
messages, see Section 6.
ALARM (ZN#) A zone (ZN) is, or recently has been, in alarm.
ARMED-HOM The system is armed using home-arming.
ARMED-INS The system is armed using instant home-arming.
BYPASSED (ZN#) A zone has been bypassed, meaning the zone is no
longer protected.
FAULTED (ZN#) The sensor in the zone has detected a condition
which, if the system were armed, would cause an
alarm. (For example, a door may be ajar.)
READY The system is ready to be armed.
NOT READY The system is not ready to be armed because a zone
is faulted.
PRESS SERVICE Your system may need to be repaired.
TAMPER (ZN#) A sensor may have been vandalized.
TROUBLE (ZN#) A sensor may not be functioning properly.
No system status messages are displayed while you arm the system, or make other changes, like assign user codes.
2
User Codes
7
User Codes and User Numbers
A user code is a secret four-digit number, used to arm and dis-
arm the system, and possibly to make other changes. Every individual who has a user code is also assigned a two-digit user num-
ber. You cannot assign the same user code to more than one
user number.
You can assign a different user code and user number to each
person who operates the system. Your security system supports
up to 60 users (user numbers 1 through 60).
If you prefer, you can assign only one user code and user number
to a group of users. This is not recommended, since it will then
be impossible to determine which individual gave a specific command.
How to Enter a User Code
To enter a user code, simply press the four numbers in succession. Do not pause for more than five seconds between numbers.
For security reasons, the code you enter is not displayed.
2
User Codes
8
How to Assign or Change User Codes
To Assign or Change
a User Code:
1. Press and hold the
[user prg] key for 2 seconds
until you hear two beeps.
You see:
ENTER MASTER
USER CODE
2. Enter the master user code.
You see:
ENTER
USER NUMBER ##
If a user number is available,
the number is displayed.
3. Enter the two-digit user number . You see:
USER ## = ####
NEW CODE =
4. Enter the new four-digit user
code. You see:
ENGLISH?
Byp=NO Home=YES
(continued)
User codes can be created or
changed as often as you like.
Any code you select must be
four digits long.
You cannot use 0000, or assign
the same user code to more
than one user number. Avoid
codes that are easy to guess,
like 1234. The default master
user code (user number 1) is
5832. For security reasons, be
sure to change this code. Do
not assign the code 5832 to another user.
If you make a mistake while
assigning a user code, you may
correct it by repeating the procedure.
Be sure to record the user
codes, and to keep these
records in a safe place.
2
User Codes
9
Important Note. At installation, each user number is assigned rights and privileges.
For example, user number 18
may have the rights to arm, disarm, and bypass zones. This
is true even if, in this example,
there is no user 18 using the
system.
Thus, if you want to assign a
user code to a new user, be
sure that you select a user
number with the privileges you
want that user to have. Your
installer should have provided
you with specific information
about how your system was
configured. Refer to this information to select the proper user
number.
To Assign or Change
a User Code (continued):
5. If the user's language is English, press the
key.
6. If the user's language is not
English, press the
key until the appropriate language is displayed, then press
the
key.
You see:
USER ## COMPLETE
Home=NEXT USER
7. To change another user code,
press the key.
8. To exit, press and hold the
key for 2 seconds.
Assign User Codes (continued)
2
User Codes
10
You will know that you entered
an incorrect user code when
the system does not complete
your command. As a security
feature, your keypad does not
beep when you enter an incorrect user code.
If you make a mistake entering
the user code, simply re-enter
the code.
Correcting a User Code Entry
To Correct a User
Code Entry:
1. Re-enter your user code.
How to Delete a User Code
You may delete a user code by
changing that code to 0000.
Follow the procedure for assigning or changing a user
code, described on the previous page.
To Delete a User Code:
1. Change the user code to
0000, following the procedure for assigning or changing a user code.
Some security systems include wireless keyfobs and remotes, used to
arm and disarm the system. If a
keyfob or remote is lost, you can protect your building by deleting its user
code.
TIP
2
User Codes
11
Depending upon how your system was programmed, basic users
may have rights to arm, disarm, or bypass zones.
Basic User
Code
Standard Code _X_
Optional Code ___
Active Certain Days/Times ___
Types of User Codes
This section identifies the types of user codes your system may
recognize. At the top of each user code section, you will see a
checklist like this:
Items on this checklist followed by an "X" are features of the user
code.
The master user can arm and disarm the system, and can make
other changes, such as disabling your system's features, and
changing user codes.
Master User
Code
Standard Code _X_
Optional Code ___
Active Certain Days/Times ___
Standard Code _X_
Optional Code ___
Active Certain Days/Times ___
2
User Codes
12
Kidwatch
Code
Standard Code ___
Optional Code _X_
Active Certain Days/Times _X_
To Change Kidwatch Days:
1. Press and hold the
[kidwatch] key for 2 seconds
until you hear two beeps. You
see:
ENTER MASTER
USER CODE
2. Enter the master user code.
You see something like this:
SMTWTFS8 1234567
E SMTWTFS
3. The "" marks those days you
are notified about the use of
the Kidwatch Code.
4. Press the number above the
letter of the day(s) you wish
to switch on or off.
5. To exit, press the
key.
Designed for parents whose
children come home first, this
option allows you to be notified
if your child is not home by a
certain time. You can be notified by pager, by an automated
telephone call, or by your monitoring station. (Not all monitoring stations offer this service.)
The Kidwatch Code is a fourdigit code that you can change
or delete like any other user
code. The code is assigned to
user number 11. It allows your
children to disarm the system,
and can be programmed to allow them to arm or bypass
zones.
How it works. After arriving
home during a day when
Kidwatch is active, your children disarm the system by entering the Kidwatch code. If
they do not enter the code by a
given time, you are notified.
(continued)
2
User Codes
13
Changing Kidwatch Days.
You have the option of changing which days Kidwatch is in
effect. To do so, follow the procedure on the previous page.
Reviewing Kidwatch Use.
You can review the times that
Kidwatch Codes were used to
arm and disarm your system by
viewing Event Memory. See
Section 6 for more information.
Turning Kidwatch on and off.
Kidwatch can be turned on and
off. When Kidwatch is turned
off, you are no longer notified
of the use of the Kidwatch
Code. Otherwise, the code
works as before. If you turn the
Kidwatch Code on or off, it remains that way until you
change it back.
Kidwatch Setup. See Section
8 for the specifics of how the
Kidwatch Code was set up on
your system.
To Turn Kidwatch On/Off:
1. Press and hold the
[kidwatch] key for 2 seconds
until you hear two beeps. You
see:
ENTER MASTER
USER CODE
2. Enter the master user code.
You see something like this:
SMTWTFS8 1234567
E SMTWTFS
If there is an "E" under the
"8," the Kidwatch Code is enabled (on). If you see a "D,"
the Kidwatch Code is disabled (off).
3. To switch the Kidwatch Code
on or off, press the
key.
4. To exit, press the
key.
Kidwatch Code (continued)
2
User Codes
14
Maid
Code
Standard Code ___
Optional Code _X_
Active Certain Days/Times _X_
To Change Maid Days :
1. Press and hold the
[maid] key for 2 seconds until you hear two beeps. You
see:
ENTER MASTER
USER CODE
2. Enter the master user code. If
you see the following display,
press the
key:
START MAID TIMER
Byp=NO Home=YES
If you do not see this display,
continue to step 3.
3. You see something like this:
SMTWTFS8 1234567
E SMTWTFS
In this example, the "" below the "W" means the code
works only on Wednesdays.
(continued)
Unlike other user codes, which
work any day of the week, the
Maid Code works only on certain days of the week.
The Maid Code is a four-digit
user code that you can change
or delete like any other user
code. Your installer must have
programmed your system to
accept a Maid Code. For systems without multiple areas (as
described in Section 7), the
code is assigned to user number 13. It allows an individual
to arm and disarm the system
on specific days.
How it works. Arriving at the
building during a day when the
Maid Code is active, the maid
can disarm the system by entering the Maid Code. Upon
leaving the building, the maid
can arm the system by entering the same code.
Maid Days and Times. For the
(continued)
2
User Codes
15
specifics of how the Maid Code
was set up on your system, see
Section 8.
5. Press the number above the
letter of the day(s) you wish
to switch on or off.
6. To exit, press the
key.
To Change Maid Days
(continued):
To Start the Maid Code Timer:
1. Press and hold the
[maid] key for 2 seconds until you hear two beeps. You
see:
ENTER MASTER
USER CODE
2. Enter the master user code. If
you see the following display,
press the
key:
START MAID TIMER
Byp=NO Home=YES
As the preceding section
shows, the Maid Code can be
programmed to work on certain
days of the week only. If you
prefer, however, you can set
the Maid Code to work for the
next few hours, regardless of
the day of the week. The number of hours the Maid Code
works depends upon your
system's programming.
The Temporary Maid Code is
assigned to user number 13.
See Section 8 for the specifics
Temporary
Maid Code
Standard Code ___
Optional Code _X_
Active Certain Days/Times _X_
(continued)
(continued)
Maid Code (continued)
2
User Codes
16
of how your system was programmed.
If you turn on the Temporary
Maid Code, your maid can use
this code to disarm the system
for the next few hours. Once
that time has expired, the code
cannot be used to disarm the
system.
To Start the Maid Code Timer:
(continued)
If you do not see this display,
continue to step 3.
3. You see something like this:
SMTWTFS8 1234567
D SMTWTFS
4. Press the key until
you see an "E" under the 8.
5. Press the
key.
6. Press and hold the
[maid] key for 2 seconds until you hear two beeps. Enter
the master user code. You
see:
START MAID TIMER
Byp=NO Home=YES
7. Press the key. You
see something like this:
MAID CODE SET
FOR ## HOURS
Temporary Maid Code (continued)
2
User Codes
17
Relay
Code
Standard Code ___
Optional Code _X_
Active Certain Days/Times ___
If an intruder forces you to disarm your system, this optional
code sends a silent signal to
alert monitoring station personnel that you are in danger.
For systems without multiple
areas, the code is assigned to
user number 15. You can
change or delete this code like
any other user code.
Standard Code ___
Optional Code _X_
Active Certain Days/Times _X_
Duress
Code
A relay code acts like a switch. When you enter this code, a device
that is connected to the control panel is turned on or off. For example, your system can be programmed to switch the exterior lights
of your building on or off when you enter a relay code. Relay codes
must be programmed into your system by the installer.
The relay code is a four-digit code that you can change or delete like
any other user code. If you delete the relay code, you will no longer
be able to use this feature. For systems without multiple areas (as
described in Section 7), the code is assigned to user number 14.
To Use the Duress Code:
1. Enter the four-digit code.
You see:
READY
Your system appears to disarm normally. However, a
message is sent to your
monitoring station that you
are in danger.
3
Arm/ Bypass
18
How the Arming Modes Differ
Your security system can be armed in a number of ways, to suit
different situations. These modes are summarized below:
Full Arming. You cannot be inside the building when it is
armed with full-arming. If sensors detect movement within a
building, or at the building's perimeter, an alarm sounds.
Home Arming (optional): You can be inside the building
when it is armed with home-arming. If someone enters the
building through a protected door, you must enter a user code,
or an alarm sounds.
Instant Home-Arming (optional). You can be inside the
building when it is armed with instant home-arming. If someone enters the building through a protected door, an alarm
sounds instantly.
Automatic Arming (optional). Your system can be pre-programmed to arm and disarm at preset times and days. You
cannot be inside the building when it is automatically armed.
Quick Arming Modes
If your system is programmed for quick arming, you do not need
to enter your user code before arming begins. Refer to Section 8
to determine if your system was programmed for quick arming.
Quick arming does not affect how your system behaves once it is
armed. For example, there is no difference in the way a system
armed with home-arming or quick home-arming protects you.
3
Arm/ Bypass
19
Exit Delays
An exit delay is the amount of time you have to exit and secure
the building, once your security system begins to arm. These
delays last from 20 to 255 seconds, depending upon how your
system was programmed.
During the exit delay, the Arm LED blinks. The keypad may beep
during the delay; if so, it beeps
faster during the last ten seconds. As shown to the right, a
bar appears at the base of the
display. This bar represents the
amount of time you have to exit
and secure the building.
When half of the time has expired, the bar will be half its
original length.
EXIT NOW!
EXIT NOW!
Any arming command with an
exit delay may be canceled before the system is armed. To
cancel an arming sequence,
enter a user code during the exit
delay.
To Cancel an
Arming Sequence:
You see:
1. Enter your user code.
Canceling an Arming Sequence
EXIT NOW!
3
Arm/ Bypass
20
When your system is armed
with full arming, both the perimeter and interior zones are
armed. You are allowed a set
time to enter or exit the building before an alarm sounds.
See Section 8 for the entry and
exit delay settings programmed
into your system.
To Arm the System
with Full Arming:
Make sure the display reads:
READY TIME
1. Enter your user code. Exit
and secure the building.
To Arm the System with
Quick Full-Arming:
1. Press and hold the
key for 2 seconds until you
hear two beeps. Exit and secure the building.
Full
Arming
Interior armed _X_
Perimeter armed _X_
Exit allowed _X_
Requires user code _X_
Automatically arms ___
No entry allowed ___
Quick Full-Arming.
If your system is programmed for quick fullarming, you do not
need to enter a user
code.
If you are using a common-area keypad
or a common keypad to arm and disarm
your system, follow the arming instructions described in Section 7 of this
manual. (These keypads are used in
partitioned systems.)
!
NOTE
3
Arm/ Bypass
21
With home arming, you can remain inside a building while its
perimeter zones (such as doors
and windows) are armed. No
alarm sounds if a sensor detects movement within the
building.
Your system might be programmed for a home arming
exit delay option (see
Section 8.) This means that one
or more individuals can leave
the building during the exit delay.
At the end of the exit delay, only
the perimeter zones are armed.
Quick Home-Arming.
If your system is programmed for quick
home-arming, you do not
need to enter a user
code.
Home
Arming
Interior armed ___
Perimeter armed _X_
Exit allowed _X_
Requires user code _X_
Automatically arms ___
No entry allowed ___
To Arm the System
with Home Arming:
Make sure the display reads:
READY TIME
1. Press the key. You
see:
TO ARM
ENTER CODE NOW
2. Enter your user code. If your
system is programmed with
an exit delay, you can now
leave.
To Arm the System with
Quick Home-Arming:
1. Press the
key. If
your system is programmed
with an exit delay, you can
now leave.
3
Arm/ Bypass
22
Interior armed ___
Perimeter armed _X_
Exit allowed ___
Requires user code _X_
Automatically arms ___
No entry allowed _X_
Instant
Home-Arming
With instant home-arming, an
alarm sounds the instant a sensor on the building's perimeter
detects a problem. The interior
sensors are not armed.
Before anyone can open a protected door or window, the system must first be disarmed.
To prevent false alarms, use instant arming only when you are
sure no system user will open
a protected door or window.
Quick Instant HomeArming. If your system
is programmed for
quick instant arming,
you do not need to enter a user code.
To Arm the System
With Instant Home-Arming:
1. Make sure the display reads:
READY TIME
Press and hold the [instant] key for 2 seconds until
you hear two beeps. You see:
TO ARM
ENTER CODE NOW
2. Enter your user code. The Arm
LED blinks and the keypad
beeps twice. Your system is immediately instant-armed.
To Arm the System with
Quick Instant Home-Arming:
1. Press and hold the
[instant] key for 2 seconds until
you hear two beeps. Your system is immediately instantarmed.
3
Arm/ Bypass
23
Automatic (Timed)
Arming
Interior armed _X_
Perimeter armed _X_
Exit allowed _X_
Requires user code ___
Automatically arms _X_
No entry allowed ___
To Change Automatic-
Arming Days:
1. Press and hold the
[walk test] key for 2 seconds
until you hear two beeps.
Enter the master user code.
Then, press the
key
five times until you see:
AUTO-ARM DAYS?
Byp=N0 Home=YES
2. Press the key. You
see something like this:
SMTWTFS 1234567
SMTWTFS
3. In this example, the boxes
show that arming occurs on
weekdays. Press the number
above the letter of the day(s)
you wish to switch on or off.
4. To exit, press the
key.
Your system can automatically
arm itself at preset times of the
day.
At two minutes and again at one
minute before the Automatic
Arming sequence begins, the
siren sounds twice. Then, the
exit delay begins. You must
leave the building during the
exit delay, or an alarm sounds.
You can postpone the Automatic Arming sequence by one
hour. When the siren sounds
two minutes before arming occurs, press the
key,
then enter your user code.
You can change the days that
Automatic Arming occurs by
following the procedure to the
right. To change the times that
arming occurs, contact your installer.
3
Arm/ Bypass
24
Arming With Not-Ready Zones
The zones in your system are not always ready to arm. For example, a zone would not be ready to arm if one of its sensors has
been vandalized, needs service, or detects a potential alarm condition. Zones which are not ready to arm are referred to as not-ready
zones.
Your system has been programmed to automatically handle not-ready
zones in one of three ways described below. Refer to Section 8 to
see how your system was programmed.
Force Arming. With Force Arming, your system arms, even if
some not-ready zones exist. All not-ready zones are ignored
(bypassed), and therefore, not protected. Exception: Not-ready
Day Buzzer or Day Bell zones must be manually bypassed before arming can occur. These are zones that cause a buzzer or
bell to sound if they are faulted while the system is disarmed.
Chirp-Alert Arming. With Chirp Alert Arming, your system does
not arm if a not-ready zone exists. At the end of the exit delay,
your system's sounders chirp. You must re-enter the bulding
and enter a user code, or an alarm sounds. Then, you must
either correct or manually bypass these zones before the system can be armed.
Goof-Proof Arming. With Goof-Proof Arming, the system does
not arm if there are any not-ready exit zones (doors). Instead,
an alarm sounds at the end of the exit delay. You must re-enter
the building and correct the not-ready zones before arming can
occur.
3
Arm/ Bypass
25
When you manually bypass a
zone, your security system
functions as if that zone does
not exist. Bypassed zones
are not protected.
The master user can bypass
any zone. Other users may
have limited rights to bypass
zones, depending on your
system's programming.
If your system is programmed
for quick bypassing, you do not
need to enter a user code to bypass zones. Follow the instructions for quick bypassing on the
next page.
Restoring bypassed zones.
If you manually bypass a 24hour zone, such as a
glassbreak detector, that zone
remains bypassed until you restore it. However, if you manually bypass a zone that is not a
24-hour zone, it is restored
when you disarm the system.
Bypassing
To Bypass a Zone:
1. When a zone is faulted, the
display reads:
FAULTED ZN ##
ZONE LOCATION
2. To bypass the zone, press the
key. You see:
ZONE NUMBER?
ENTER 2 DIGITS
3. Enter the two-digit zone
number. (For zones 1-9, enter a "0" first.) You see:
TO BYPASS ZN ##
ENTER CODE NOW
4. Enter your user code.
To Restore a Bypassed Zone:
1. Repeat the procedure above.
The zone operates normally.
3
Arm/ Bypass
26
Quick
Bypassing
Quick bypassing allows you to
bypass zones without entering
a user code. This option must
be programmed into your system by the installer. With quick
bypassing, any user can bypass any bypassable zone.
IMPORTANT: If your system
is programmed for quick bypassing, anyone can bypass
your system's zones. Since
bypassed zones are not protected, this feature increases
the likelihood that your system
may be defeated.
To Bypass a Zone with Quick
Bypassing:
1. When a zone is faulted, the
display reads:
FAULTED ZN ##
ZONE LOCATION
2. To bypass the zone, press the
key. You see:
ZONE NUMBER?
ENTER 2 DIGITS
3. Enter the two-digit zone
number. (For zones 1-9, enter a "0" first.)
To Restore a Bypassed Zone
with Quick Bypassing:
Repeat the procedure above.
The zone operates normally.
3
Arm/ Bypass
27
Optional Arming Features
Your system offers the optional arming features described below.
Refer to Section 8 to see which are installed on your system.
Extended Exit Delay. This feature automatically resets the exit
delay if you re-enter the building while the system is being armed.
You may re-enter four times; each time, the exit delay is reset to
its full value.
Keypad Lockout. Designed to prevent an intruder from guessing a user code, this option causes the system to slow down if a
series of invalid user codes are entered. Before a new user code
can be entered, the user must wait through a delay. The delay
lengthens as more invalid codes are entered. Depending upon
your system's programming, the keypad lockout may not affect
arming.
Keyswitch Arming. This accessory (Sierra S5051 or equivalent) allows you to arm and/or disarm the system with a key. Follow the instructions provided with the switch.
Quick Exit. This option allows you to exit a home-armed building
without disarming and re-arming. To start the exit delay, press
and hold the
[quick exit] key for 2 seconds, enter your
user code, then exit. (Depending on your system's programming,
you may not need to enter your user code.)
Exit Termination. This option allows you to shorten the exit delay to the last five seconds by pressing a button connected to
your keypad.
3
Arm/ Bypass
28
Optional Arming Features (continued)
Automatic Home-Arming. Automatic Home-Arming allows you
to remain inside a building while its perimeter zones (such as
doors and windows) are armed. Arming begins by entering your
user code. If you exit the building during the exit delay, the system arms both the interior and perimeter zones (full arming). However, if you do not exit the building, the system automatically arms
the perimeter zones only (home-arming).
4
29
Disarm/Alarms
Entry Delays
Similar to an exit delay, an entry delay is the time you are allowed
to enter the building, walk to the keypad, and enter a user code
before an alarm sounds. This delay lasts from 10 to 255 seconds, depending on your system's programming. The length of
the delay may differ, depending on which door you use.
During the entry delay, the Arm LED blinks. The keypad may
beep during the delay. If so, it beeps faster during the last ten
seconds. As shown to the right, a bar appears at the base of the
display. This bar represents the
amount of time you have to enter
the building and disarm the system.
When half of the time has expired,
the bar is half its original length.
Disarming
To Disarm the System:
1. Enter through a door programmed with an entry delay.
2. Enter your user code.
Regardless of which method
was used to arm your system,
the disarming sequence is always the same.
Be sure that the door you use
to enter the building has been
programmed with an entry delay.
ENTER CODE NOW
ENTER CODE NOW
4
30
Disarm/Alarms
Automatic (Timed)
Disarming
To Change Automatic
Disarming Days:
1. Press and hold the
[walk test] key for 2 seconds
until you hear two beeps.
Enter the master user code.
Then, press the
key
seven times until you see:
AUTO-DISARM DAYS
Byp=N0 Home=YES
2. Press the key. You
see something like this:
SMTWTFS 1234567
SMTWTFS
3. In this example, the boxes
show disarming occurs on
weekdays. Press the number
above the letter of the day(s)
you wish to switch on or off.
4. To exit, press the
key.
Your system can automatically
disarm itself at preset times of
the day. This option must be
programmed into your system
by your installer.
You can change the days of the
week that Automatic Disarming
occurs by following the procedure to the right. To change the
time that disarming occurs, contact your installer.
4
31
Disarm/Alarms
Canceling an Alarm
To Cancel an Alarm:
1. You see:
ALARM ON ZONE ##
PUSH CANCEL KEY
Press the key. You
see:
ALARM ON ZONE ##
ENTER CODE NOW
2. Enter your user code. You
see:
ALARM ON ZONE ##
CANCELED
If programmed, your system
pauses briefly before sounding
an alarm. This gives you the
opportunity to cancel a false
alarm. You can cancel the
alarms of any sensor, including
a smoke detector.
The amount of time you have
to cancel the alarm depends
upon how your installer programmed the system. See the
"Cancel Alarm Time" listing in
Section 8.
Five seconds after an alarm is
canceled, your system reverts
to normal.
After an Alarm
You should reset your system
after an alarm. This action
clears your keypad's display
and resets your sensors.
To Reset After an Alarm:
1. Press and hold the
key for 2 seconds until you
hear two beeps.
4
32
Disarm/Alarms
How to Prevent False Alarms
False alarms are more than a nuisance—they reduce the reliability of your security system. Here are a few steps you can take to
prevent the annoyance and expense of false alarms.
1. Know your system. Make sure all system users under-
stand how to arm and disarm, and what special functions
they can and cannot do.
2. Remember your user code. Forgotten user codes are
the most common cause of false alarms.
3. If you have an optional keyswitch, be sure you know
where your keys are.
4. Shut doors and windows completely. Before arming
your system, be sure all protected windows and doors are
closed. As you leave the building, shut the exit door completely.
5. Regularly test and maintain your system. Routine
testing and maintenance will help you detect a service condition. See Section 6 for more information.
6. Be selective when arming the system for instant
alarms. This setting should not be used when a user might
open a door or window.
7. Make sure your system's clock and calendar are ac-
curate. Many system functions, such as Kidwatch and Automatic Arming, are time-related. Be sure to adjust your clock
to reflect seasonal time changes (such as Daylight Savings
4
33
Disarm/Alarms
Time). Also, check your clock after a power failure. See
Section 5.
8. Keep pets (and other animals) from motion detectors.
If you have obtained a pet since your system was installed,
your system may need to be modified. Contact your dealer
for more information.
9. Bypass trouble zones. If your system has one or more
trouble zones, bypass them before arming. Have the
sensor(s) inspected if the problem continues. Remember
that bypassed zones are not protected.
Optional Alarm Features
Your system offers the optional alarm features described below.
Refer to Section 8 to see if these options are installed on your
system.
Alarm Lockout. The system automatically ignores a sensor that
repeatedly sends alarm signals.
Silent alarm. With this option, no bells or sirens sound during an
alarm, but the monitoring station is notified. If the phone lines are
down, or the monitoring station cannot be reached for some other
reason, the on-site bells or sirens may be reactivated, depending
upon how your system is programmed.
How to Prevent False Alarms (continued)
5
Settings
34
To Set the Clock
and Calendar:
1. Press and hold the
[clock] key for 2 seconds until you hear two beeps. Enter
the master user code. You see
something like this:
07:32 am
Byp=OK Home=CHG
2. Press the key. You
see:
hr:min
00:00 am
3. Enter the correct time, using
four numbers. You see something like this:
hr:min 1=am 2=pm
12:21 am
4. Press for a.m. and
for p.m. You see:
##:## am
Byp=OK Home=CHG
5. If the time is correct, press
the
key. If the time
is not correct, press the
How to Set the Clock and Calendar
If your system's clock and calendar is incorrect, it could result in false alarms. Since many
system functions are time-dependent, it is very important
to regularly check your
system's clock and calendar.
Be sure to reset the clock after
seasonal time changes, such
as Daylight Savings Time. Also,
even if your system has a
backup battery, it is best to
check the clock and calendar
following a power failure.
35
5
Settings
Clock and Calendar (continued)
To Set the Clock
and Calendar (continued):
key and re-enter the
time.
6. You see something like this:
24 NOV 1998
Byp=OK Home=CHG
To change the date, press the
key. You see:
day:month:year
00:00:00
7. Enter the correct date using
two numbers (each) for the
day, month and year. You see
something like this:
10 JAN 1999
Byp=OK Home=CHG
8. Press the key if the
date is correct; if not, press
the key.
5
Settings
36
You hear a beeping sound
when the system is about to
arm, disarm, or sound an
alarm. The warning tone reminds you that time remains to
cancel the arming or disarming
sequence.
You can turn the tone on or off
by following the instructions to
the right. If the tone is on, the
action turns it off. If the tone is
off, the action turns it on.
To Turn Tone On/Off:
1. Press and hold the
[pre-warn] key for 2 seconds
until you hear two beeps.
When prompted, enter the
master user code.
If the tone is on, you see:
PREWARN ON
Byp=OK Home=CHG
2. To turn the leave the tone on,
press the
key. To
turn it off, press the
key.
If you made no changes, your
system returns to normal automatically. If you turned the
tone on or off, press the
key to exit.
How to Turn the Warning Tone On/Off
37
5
Settings
When your system is set to
chime, you hear three beeps
whenever you open a protected
door or window. You can turn
the chimes on or off by following the instructions to the right.
If the chimes are on, this action
turns them off.
How to Turn the Chimes On/Off
To Turn Chime On/Off:
1. Press and hold the
[chime] key for 2 seconds
until you hear two beeps.
When prompted, enter the
master user code.
If the chime is on, you see:
CHIME ON
Byp=OK Home=CHG
2. To turn leave the chime on,
press the
key. To
turn it off, press the
key.
If you made no changes, your
system returns to normal automatically. If you turned the
chime on or off, press the
key to exit.
5
Settings
38
To Turn Backlight On/Off:
1. Press and hold the
[walk test] key for 2 seconds
until you hear two beeps.
When prompted, enter the
master user code.
2. Press the
key five
times. If your backlighting
is off, you see:
BACKLIGHT OFF
Byp=OK Home=CHG
3. To set the backlight to shine
continuously, press the
key. To set the backlight shine only when the keypad is in use, press the
key.
4. To exit, press the
key.
Whenever you use your keypad, a light automatically illuminates the display and keys.
This backlight shuts off 60 seconds after you have finished using the keypad.
If you wish, you can set the
backlight to shine continuously.
This makes it easier for you to
notice system messages, especially if your keypad is located
in a dark area.
If you turn the backlight on, you
can turn it off again by repeating the procedure to the right.
How to Turn the Backlight On/Off
39
5
Settings
How to Change the Relay Days
Your system can be programmed with up to four relays
that work on the days of the
week you specify. The relays
are numbered 1, 2, 3, and 4.
The relays are programmed to
turn on or off one or more devices which are connected to
your system's control panel.
You can change the days that
the relay works by following the
procedure to the right.
For example, a business may
use a relay to turn on the floodlights near its loading docks. By
using the relay schedule menu,
the business owners could turn
the lights off during the business' upcoming holiday.
You can change the days that
the relay works by following the
procedure to the right. To
change the time of day that the
relay works, contact your installer.
To Change the Relay Days:
1. Press and hold the
[walk test] key for 2 seconds
until you hear two beeps.
When prompted, enter the
master user code. Then, press
the
key until you see:
RELAY SCHEDULE #
Byp=NO Home=Yes
2. On your display, the "#" symbol is replaced by a 1, 2, 3,
or 4. Press the key
until the relay number shown
is the one you wish to change.
Then, press the
key.
You see something like this:
SMTWTFS 1234567
SMTWTFS
3. In this example, the relay
works on Wednesdays. Press
the number above the letter
of the day(s) you wish to
switch on or off.
4. To exit, press the
key.
40
6
Maintenance
How to Walk-Test the System
A walk-test allows you to test
your system's functions without
causing an alarm. You can be
sure your security system is
functioning properly by conducting a walk-test once a
week.
The first step of a walk-test is
to place your system in walktest mode. Then, walk in front
of motion sensors, and open
protected doors and windows.
Each time a sensor detects
your presence, the keypad
beeps, and names the zone in
its display.
If your system fails to detect a
sensor, exit the walk-test mode
and make sure the sensor's
zone is not bypassed. If it is
bypassed, remove the bypass
and repeat the walk- test. If this
does not correct the problem,
contact your service representative.
Important: during a walk-test,
your building is not protected
against actual alarms.
To Conduct a Walk-Test:
1. Press and hold the
[walk test] key for 2 seconds
until you hear two beeps.
When prompted, enter the
master user code. You see:
WALK TEST?
Byp=NO Home=YES
2. Press the key. You
see:
AREA #
WALK TEST
Test your sensors by opening
protected doors and windows, and by walking in front
of motion sensors. You see
something like this:
FAULTED ZN 03
In this example, a fault was
noted on zone 3.
3. To exit, press the
key.
41
6
Maintenance
How to Use Event Memory
To Review Event Memory:
1. Press and hold the
[walk test] key for 2 seconds
until you hear two beeps.
When prompted, enter the
master user code. Press the
key. You see:
EVENT MEMORY
Byp=NO Home=YES
2. Press the key. To
view the oldest events first,
press
. To view the
latest events first, press
. You see something
like this:
9/9/98 17:14
ALARM ZONE 04
This example indicates there
was an alarm on zone 4 at
5:14 p.m. on 9/9/98.
3. Press
to view the
next event, or to
Your system records important
events in Event Memory. You
can review Event Memory to
monitor the status of your system.
Alarms, trouble indicators,
changed user codes, and battery failures are some of the
events recorded in Event
Memory. Your system can
store at least 60 events, but
may store as many as 500.
Times are recorded in a 24hour format. To convert from
24-hour time to 12-hour time,
simply subtract 12 hours from
all times greater than 12:00;
these are p.m. times. (In 24hour time, midnight is expressed as 00:00; noon is
12:00.)
Your service representative
can assist you in interpreting
the information stored in Event
Memory.
(continued)
42
6
Maintenance
How to Test the Bells and Sirens
To Test the Bells and Sirens:
1. Press and hold the
[walk test] key for 2 seconds.
When prompted, enter your
user code.
2. Press the
key twice.
You see:
AUDIBLE TEST
Byp=NO Home=YES
3. Press the key. Your
system's bells or sirens ring
for 4 seconds.
4. To exit, press the
key.
You can test your system's bells
and sirens by following the procedure to the right.
Event Memory (cont'd):
view the previous event.
4. To exit, press the
key.
Event Memory (continued)
43
6
Maintenance
To Start a Remote Programming Session
If you have a monitoring station
hookup, your installer may be
able to program your security
system through the telephone
line. It is not necessary for a
technician to come to your
home or business to make
changes to your system.
At your monitoring station's
prompting, you can initiate a remote programming session by
following the directions to the
right.
To Start A Remote
Programing Session:
1. Press and hold the
[walk test] key for 2 seconds
until you hear two beeps.
When prompted, enter your
user code.
2. Press the
key three
times. You see:
RPS CALLBACK?
Byp=NO Home=YES
3. Press the key. The
remote programming session
begins. Normally, a remote
programming session takes
just a few minutes.
44
6
Maintenance
How to Test the Battery
Your system may include a
backup battery. If it does, the
system will continue to function
during a power failure, because
it will draw power from the battery.
You can test the charge in your
system's battery by following
the procedure to the right.
If your backup battery's charge
is low, a service message appears in your display. To investigate the service message, follow the instructions in "Troubleshooting Service Conditions,"
later in this section.
To replace your system's battery, call your service representative.
To Test the Battery:
1. Press and hold the
[walk test] key for 2 seconds
until you hear two beeps.
When prompted, enter your
user code.
2. Press the
key four
times. You see:
BATTERY TEST?
Byp=NO Home=YES
3. Press the key. The
battery test begins. To clear
the display, press the
key. The test takes approxi-
mately 2 minutes, during
which time you see:
BATTERY TEST
IN PROGRESS
If the battery's charge is low,
you see the following once
the test has concluded:
PRESS SERVICE
45
6
Maintenance
How to Use Quick View
To Use Quick View:
1. Press and hold the
[quick view] key for 2 seconds until you hear two
beeps. You see something
like this:
F.......T.......
...............B
Each row of the display has
16 spaces, one for each of
the maximum 32 zones of
your system. The letters or
symbols on each line identify the zone's status (see the
list to the left).
In this example, zone 1 is
faulted, zone 9 is a trouble
zone, and zone 32 is bypassed. Periods mean no
problems exist with zones
2-8 and 10-31.
2. To exit, press the
key.
You can rapidly review the status of your system by using
Quick View. Quick View will
tell you, for example, if any
zones have been faulted or bypassed.
Quick View uses the following
abbreviations to summarize a
zone's status:
B = Bypass. The zone is
bypassed.
F = Faulted. The zone's
sensor is faulted.
T = Trouble. The zone's
sensor may be malfunctioning.
A = Alarm. An alarm event
occurred on this zone.
M = Tamper. The sensor
has been vandalized.
. = Normal. No problems
have been identified for this
zone.
46
6
Maintenance
Common System Messages
Below is an explanation of the common messages your keypad
might display. Beside each message is a discussion of what responses are appropriate. If you find the response is ineffective,
call your local C&K service representative.
In the table below, the ellipses (...) represent the specific information, such as zone numbers, that follows the system message.
If you notice That means What to do:
Power LED is off The system is not Verify that the rest of the
receiving AC (house building is receiving power;
current) power then call for service. That
Display reads: A zone is faulted; Correct the fault (by
"Faulted..." cannot fully arm closing doors/windows); or
bypass the zone.
Display reads: A sensor needs Bypass the sensor, or
"Trouble..." service arrange for repair.
Display reads: A sensor may have Call for service.
"Tamper..." been tampered with
Display repeatedly A sensor may need Call for service.
reads: "Trouble..." service
"Tamper..."
Display reads: Any one of your Depending upon your
Ready" sensors may be arming type, your system
faulted may be able to arm. If not,
correct any faulted zones,
then attempt to arm.
Display reads An alarm occurred Refer to "Resetting After an
"Alarm..." Alarm" in Section 4.
Display reads A zone has been Remember the zone is
"Bypass..." bypassed unprotected while bypassed.
You can remove the bypass
(see Section 3), or arm/
disarm with bypass in place.
47
6
Maintenance
Troubleshooting Service Conditions
Your system notifies you if a keypad, sensor, or other system component, needs service. When a service condition exists, the keypad beeps twice every 30 seconds for one minute. The display
shows the following message:
PRESS Service
To get more information about the service message, press and
hold the
[service] key for two seconds. You then see one
of the messages listed in the table below. If there is more than
one message, you can view the next one by pressing
again. Follow the recommended course of action listed in the
table.
To stop the service message warning tone, enter your user code
between the two beeps.
When done, press to exit.
What to do
Meaning
Message
AC POWER
LOSS
BROWN OUT
PANEL LOW
BATT
GROUND
FAULT
There is a power failure
in progress.
A power loss, short of
total failure, has
occurred.
The control panel's
battery is low.
Power from the system
has short-circuited to
the ground wire.
Look for signs of power failure in other
building equipment; if not found, call for
service. Reset the clock and calendar,
once power is restored.
When power returns to normal, your
system should revert to normal. If not,
call for service.
Allow the battery to recharge overnight.
If the problem remains, call for service.
Call for service.
48
6
Maintenance
What to doMeaningMessage
PHONE #1
NO RPT
PHONE #2
NO RPT
COMM
BUFFER
OVERFLOW
PHONE 1
CUT
PHONE 2
CUT
KEYPAD ##
TAMPER
KEYPAD ##
TRBL
SN KP #
TROUBLE
SN KP #
BATTERY
KEYFOB #
BATTERY
SELF DIAG
FAIL
BELL SUP
FAIL
If line is functioning, call monitoring
station. If not, call telephone company
for service.
If line is functioning, call monitoring
station. If not, call telephone company
for service.
If telephone line is functioning, call
monitoring station. If not, call telephone
company for service.
If line is functioning, call monitoring
station. If not, call telephone company
for service.
If line is functioning, call monitoring
station. If not, call telephone company
for service.
Call for service.
Call for service.
Call for service.
Call for service.
Call for service.
Call for service.
Call for service.
The monitoring station
(phone #1) does not
answer.
The monitoring station
(phone #2) does not
answer.
There are too many
messages to send to
the monitoring station.
Phone line #1 is not
working.
Phone line #2 is not
working.
Keypad number ##
has been vandalized.
Keypad number ##
needs service.
Wireless keypad
number # needs
service.
Wireless keypad
number # has a low
battery.
Wireless keyfob or
remote number # has
a low battery.
Self-diagnostic failure
of a sensor.
The external bell/siren
needs service.
49
Areas
7
What Areas Do
Your security system allows
you to divide (or "partition") a
building into as many as eight
areas, regions that can be
armed and disarmed individually. Designed primarily for
commercial settings, areas can
limit an individual's access to
portions of a building.
A building that is divided into
areas may include a common
area, an area most system users can arm and disarm. The
first diagram shows how a
building could be divided to include a common area.
Buildings may also be partitioned without a common area.
As the second diagram shows,
this setup works well for structures with tenant spaces, but no
lobby or shared hallway.
Each system user is assigned
rights to one or more areas.
Users can arm and disarm only
those areas to which they have
rights.
When a building is divided into
Figure 1
Partitioned building
with a common area
Areas
7
50
Figure 2
Partitioned building
with no common area
areas, portions of the building
can be independently armed
and disarmed. In the case of
the first building illustrated, an
employee can work in the repair shop while the showroom,
offices, and warehouse are
armed. Similarly, in the case
of the second illustration, the
restaurant can remain open after the other shops are closed
and armed.
Dividing a building into areas
changes the following system
functions:
1. Users have restricted access to system functions. A
user with access to only one
area cannot issue commands
affecting other areas, or obtain
information about the other areas.
2. Keypads may respond differently, depending upon
where they are located and
how they are programmed. A
keypad assigned to one area
is limited to handling information about that area only.
51
Areas
7
How Areas Affect User Codes
As described below, some of the user code types function differently
in a partitioned system.
Area
Grand Master User Code. The grand master user
can assign and change user codes, and may be able
to arm and disarm the entire system. Only the grand
master user and your installer can view and change
the grand master user code.
Area Master User Code. Each area has its own
master user. The area master user can make any
user-controlled changes within a given area.
Area Basic User Code. Area basic users can disarm and may be able to arm, bypass, or make other
changes within an area. Users can have rights to
more than one area.
Area Maid Code. Maid Days are assigned to each
area, so if you need to change the Maid Days, you
must make the changes for each area individually.
Kidwatch Code. Your system recognizes only one
Kidwatch Code, regardless of how many areas are
present. The Kidwatch Code is assigned to area 1.
Area Duress Code. One duress code can be assigned to each area.
Area Relay Code. One relay code can be assigned
to each area.
Area
If your building is divided into areas, your system may also recognize
one or more of these optional user code types:
Area
Area
Area
Areas
7
52
Pre-Assigned Area User Numbers
As the table below shows, some user numbers are reserved for
specific user types. For example, User 11 is the preassigned
Kidwatch user number. If programmed, your system automatically restricts User 11 to the limited Kidwatch privileges.
When your system does not recognize a given user type, the user
number functions like other non-reserved user numbers. If your
building is not divided into areas, user codes reserved for areas
do not apply. Also, if your building is divided into only two or three
areas, codes reserved for the remaining areas do not apply.
No. Reserved User
01 Grand Master User
11 Kidwatch
12 Area 1 Master
13 Area 1 Maid
15 Area 1 Duress
16 Area 2 Master
17 Area 2 Maid
19 Area 2 Duress
20 Area 3 Master
21 Area 3 Maid
23 Area 3 Duress
24 Area 4 Master
25 Area 4 Maid
No. Reserved User
27 Area 4 Duress
28 Area 5 Master
29 Area 5 Maid
31 Area 5 Duress
32 Area 6 Master
33 Area 6 Maid
35 Area 6 Duress
36 Area 7 Master
37 Area 7 Maid
39 Area 7 Duress
40 Area 8 Master
41 Area 8 Maid
43 Area 8 Duress
Changing Area User Codes
In a system with multiple areas, an Area Master User can
only change the codes of the users assigned to that area. If
you attempt to change the code of a user when you do not
have the right to do so, you see:
USER NUMBER
NOT ASSIGNED
53
Areas
7
Understanding the Area Status Menu
The Area Status Menu summarizes the conditions of your system's
areas. The menu only appears on keypads assigned to the common area of a partitioned system. To display the menu, enter
your user code. You see something like this:
AREA 12345678
STATUS RNAHIRAH
The numbers on the right-hand side of the display represent the
areas of your system. The letter under the number indicates the
status of the area. If you do not have rights to all of the areas in
your system, your keypad may be programmed to blacken a portion of the menu's display (see below).
The table on the following page explains the abbreviations used
in the Area Status menu. Thus, in the example above, area 1 is
ready to be armed, while area 3 is armed.
To get more information about any given area, press and hold the
[quick view] key for two seconds until you hear two beeps.
Then, press the area number. This takes you to the Quick View
display, described later in this section. To exit this menu, press
the
key. If you do not press any keys, the keypad auto-
matically exits the Area Status Menu.
AREA 12345678
STATUS RNAHIRAH
AREA 12345678
STATUS RNAH■■■
If you do not have rights to all
of the areas of your system,
your keypad may be programmed to blacken out portions of the Area Status Menu,
as the lower example shows.
Areas
7
54
If You See... That Means...
A (steadily lit) The area is armed with full-arming.
A (blinking) The area is being armed with full arming. (An exit
delay is in progress.)
H (steadily lit) The area is armed with home arming.
H (blinking) The area is being armed with home arming. (An exit
delay is in progress.)
I (steadily lit) The area is armed with instant arming.
N (steadily lit) The area is not ready to be armed.
R (steadily lit) The area is ready to be armed.
R (blinking) The area is being disarmed. (An entry delay is
in progress.)
Area No. The area is (or was) in alarm.
(blinking)
Word "Area" Enter the area number to be armed, disarmed, etc.
is blinking
The Area Status Menu (continued)
55
Areas
7
From the Area Status Menu,
you can arm individual areas of
your system. Each partition can
be armed with full arming, home
arming or instant home-arming.
If an area is not ready to be
armed, your command to arm
this area causes one of two
things to happen. If your system is programmed for Force
Arming (see Section 8), the
area is armed, but any trouble/
faulted zones are automatically
bypassed. If your system is not
programmed for Force Arming,
the Zone Status Menu appears.
In that case, you must correct
or bypass any trouble or faulted
zones before arming can take
place.
To Arm One Area:
1. Enter your user code. You see
something like this:
AREA 12345678
STATUS RNAHIRAH
2. To arm an area using full arming, press that area number.
3. To arm an area using home
arming, press the
key
followed by the area number.
4. To arm an area using instant
home-arming, press and hold
the
[instant] key for
2 seconds until you hear two
beeps. Then, enter the area
number.
Arming Individual Areas
Using Multiple Keypads in an Area
In any area, only one keypad can be used at a time. If you try to
use another keypad while one is in use, you see the following:
ANOTHER KEYPAD
IS IN USE
Areas
7
56
From the Area Status Menu,
you can enter one command
which instructs your system to
arm all of the areas to which you
have rights.
NOTE: If any of the areas are
not ready to be armed, none of
your assigned areas will be
armed when you enter this
command. Instead, your keypad displays the Zone Status
Menu of the first area which is
not ready to be armed. You
must correct or bypass any
trouble or faulted zones before
arming can take place.
NOTE: If an area is already
armed, it will not be affected by
a command to arm all areas.
Thus, for example, if Area 4 is
armed with home-arming, and
a command is issued to arm all
areas with full arming, Area 4
will remain armed with homearming.
Arming Multiple Areas
To Arm All Areas:
1. Enter your user code. You see
something like this:
AREA 12345678
STATUS RNAHIRAH
2. To arm all of your assigned
areas using full arming, press
.
3. To arm all of your assigned
areas using home arming,
press the
key fol-
lowed by the key.
4. To arm all of your assigned
areas using instant home-arming, press and hold the
[instant] key for 2
seconds until you hear two
beeps. Then, press the
key.
57
Areas
7
From the Area Status Menu,
you can disarm the individual
areas of your system.
You can only disarm an area
that is armed. In the Area Status Menu, an "A," "H," or "I" is
shown under the number of an
armed area.
To Disarm One Area:
1. Enter your user code. You see
something like this:
AREA 12345678
STATUS RNAHIRAH
2. To disarm an armed area,
press that area number.
Disarming Individual Areas
Disarming Multiple Areas
From the Area Status Menu,
you can enter one command
which instructs your system to
disarm all of the areas to which
you have rights.
To Disarm All Areas:
1. Enter your user code. You see
something like this:
AREA 12345678
STATUS RNAHIRAH
2. To disarm all of the areas to
which you have rights, press
the
key.
Areas
7
58
Using the Zone Status Menu
How To Use the
Zone Status Menu:
1. From the Area Status Menu,
press and hold the
[quick view] key for 2 seconds
until you hear two beeps.
Then, press the area number.
You see something like this:
.F.F.B■■■■■■■■■■
■■■■■■■■■■■■■■
The display identifies each
zone's status, using the abbreviations to the left. Zones outside of the area are blacked out.
2. To bypass a faulted zone,
press the
key followed by the two-digit zone
number.
3. To remove the bypass on a
zone, press the
key
followed by the zone number.
4. To exit, press the
key twice.
The Zone Status Menu tells you
if the zones of an areas are normal, faulted or bypassed. Depending on your system's programming, you may only be
able to view the Zone Status
Menu for those areas to which
you have rights.
The Zone Status Menu uses the
following abbreviations to summarize a zone's status:
. = Normal. The zone is
ready to be armed.
B = Bypassed. The zone
was bypassed.
F = Faulted. The zone's sensor is faulted.
59
Areas
7
Resetting After an Alarm:
1. Enter your user code. You see
something like this:
AREA 123456678
STATUS RNAHIRAH
In this example, the "6" is
blinking.
2. To clear the system's alarm
memory, press and hold the
[clear mem] key for
2 seconds until you hear two
beeps. Then, press the area
number (or
, to clear
all areas).
Resetting After an Alarm
When an alarm has occurred in
a given area, that area number
in the Area Status Menu blinks.
You can reset the display by
following the instructions to the
right.
Canceling Alarms
In a partitioned system, you can have simultaneous alarms in
several areas. For example, at the same time, alarms may occur
in areas 2, 3, and 5.
To cancel an alarm in an area, press the
key and enter
your user code. You must have rights to an area to cancel an
alarm in that area. If more than one area is in alarm, the keypad
prompts you to repeat the cancellation command for each of the
areas in alarm.
60
8
Notes
Monitoring Station: ______Yes ______No
Maximum Number of Users: ______
Partitioned: ______Yes ______No
Keypad assigned to area #:_________________________
Alternate Language: ______________________________
Learning Period (days): ______________ Begins: ________
System Configuration
Your installer will fill out these pages, to indicate how your system
has been configured.
Setup
Options
Check if installed:
_____Maid Code
_____Kidwatch Code
_____Duress Code
_____Automatic (Timed) Arming
_____Automatic Disarming
_____Home Arming
_____Quick Home-Arming
_____Quick Full-Arming
_____Automatic Home-Arming
_____Instant Home-Arming
_____Quick Instant Home-Arming
_____Force Arming
_____Goof-Proof Arming
_____Chirp-Alert Arming
_____Quick Bypassing
_____Quick Exit
_____Exit Termination
_____Extended Exit Delay
_____Keypad Lockout
_____Alarm Lockout
_____Silent Alarm
Emergency Keys:
_____Medical
_____Fire
_____Police
_____ Keyfob Arming
_____ Keyswitch Arming
61
8
Notes
Temporary Maid Code Hours: _________________________
Kidwatch Times: ___________________________________
Entry Delay #1 __________enter through:_______________
Entry Delay #2: __________enter through:_______________
Exit Delay: ________________________________________
Cancel Alarm Time: _________________________________
Automatic Arming Time: _____________________________
Automatic Disarming Time: ___________________________
Device Connected to Relay 1: _________________________
Relay 1 Start Time: _________________________________
Device Connected to Relay 2: _________________________
Relay 2 Start Time: _________________________________
Device Connected to Relay 3: _________________________
Relay 3 Start Time: _________________________________
Device Connected to Relay 4: _________________________
Relay 4 Start Time: _________________________________
Customization
62
8
Notes
Below is a space to sketch how the building is zoned and/
or divided into areas. Be sure to note how the zones and/
or areas are numbered and labeled.
Sketch
63
8
Notes
Glossary of Terms
Area: a region of a building that can
be armed and disarmed independently
of the remainder of the building.
Bypassing (or shunting): the act of
instructing your security system to ignore a zone. A bypassed zone is not
protected.
Entry Delay: The amount of time you
have to enter your armed building, walk
to the keypad, and enter your user code
before an alarm sounds.
Exit Delay: The amount of time you
have to exit and secure your building
before an alarm sounds.
Faulted: describes a condition which,
if the system were armed, would cause
an alarm, such as an opened door or
window. Faulted zones must be corrected or bypassed before arming.
Full Arming: a method of arming that
arms all of your system's sensors, both
along the building's perimeter, and inside the building.
Home Arming: a method of arming that
arms only those sensors along the perimeter of your building.
Instant Arming: a method of arming
that triggers an alarm the instant a sensor detects an alarm condition.
Monitoring Station: a service that
monitors the status of your security system through a telephone hook-up.
Tamper: describes a sensor, or other
system equipment, that has been deliberately damaged.
Trouble: describes a sensor, or other
system equipment, that may be in need
of service.
User Code: a secret four-digit number
used to arm and disarm the system, and
make other changes.
User Number: a two-digit number assigned to each user.
Zone: a sensor or a group of sensors
protecting a region of your building.
24-Hour Zone: a zone, such as a
smoke detector, which is programmed
to detect alarm conditions whether your
system is armed or disarmed.
64
8
Notes
Notes
65
8
Notes
Notes
66
8
Notes
Notes
67
8
Notes
Index
Alarm
canceling 31, 59
lockout 33
after 31, 59
silent 33
Area, defined 49
Area Status Menu 53
Area user codes
assigned 52
changing 52
types 51
Arming
areas, 55, 56
automatic 18, 23
automatic home- 28
canceling 19
Chirp-Alert 24
full 18, 20
Force 24
Goof-Proof 24
home 18, 21
instant home- 18, 22
quick 18
quick full- 20
quick home- 21
quick instant
home- 22
Backlight, turning on/off 38
Battery test 44
Bell test 42
Bypassing 25
Bypassing, quick 26
Calendar, setting 34
Chimes, turning on/off 37
Clock, setting 34
Date, setting 34
Disarming 29, 57
Disarming, automatic 30
Emergency keys 4, 5
Entry delay 29
Event Memory 41
Exit delay 19
Exit termination 27
Extended exit delay 27
False alarms,
preventing 32
Glossary 63
Keyfob, deleting lost 10
Keypad lockout 27
Keyswitch arming 27
Kidwatch Days 12
Learning period 3
Maid Days 14
RPS session 43
Relay days, changing 39
Remote, deleting lost 10
Remote Programming
Session 43
Secondary Function
Keys 4
Service conditions 47
Siren test 42
System messages 6, 46
Quick exit 27
Quick View 45
Time, setting 34
Troubleshooting guide 47
User codes, types
basic 11
duress 17
Kidwatch 12
Maid 14
master 11
relay 17
temporary maid 15
with areas 51
User codes, using
assigning 8
changing 8, 52
deleting 10
entering 7
User numbers, areas 52
Walk-test 40
Warning tone, turning
on/off 36
Zone Status Menu 58
68
8
Notes
Sierra is a registered trademark
of C&K Systems
C&K is a registered trademark of
C&K Components
http:// www.cksys.com
Copyright 1998, C&K Systems, Inc.
5-051-530-01 Rev A
Loading...
