Multiverse® SHoW Baby®
P/N 5900
User’s Manual
Rev 1.2
© 2019 City Theatrical, Inc.
Multiverse SHoW Baby Transceivers are covered by U.S. Patent # 7,432,803 and other patents pending.
Made in USA
Page 2 of 15
Table of Contents
Compliance .................................................................................................................................3
Safety Notices .............................................................................................................................4
Introduction ................................................................................................................................ .5
Multiverse SHoW Baby Settings ..............................................................................................5
Multiverse SHoW Baby Antennas ............................................................................................6
Setup and Operation ...................................................................................................................6
Transmitter Setup ....................................................................................................................6
Receiver Setup ........................................................................................................................7
RDM Operation ...........................................................................................................................7
Multiverse SHoW Baby Advanced Setup .................................................................................8
Installing the Mounting Bracket ................................................................................................9
Specifications ..........................................................................................................................9
What’s Included ................................................................ ..................................................... 11
List of Tables
Table 1: Setting SHoW ID by Color .............................................................................................5
Table 2: SHoW IDs and SHoW Keys ..........................................................................................8
Table 3: Physical Characteristics ................................................................................................9
Table 4: Multiverse SHoW IDs .................................................................................................. 12
Table 5: SHoW DMX Neo SHoW IDs ........................................................................................ 13
Table 6: Troubleshooting Guide ................................................................................................ 15
List of Figures
Figure 1: Multiverse SHoW Baby Front and Rear View Diagrams ...............................................6
Figure 2: Attaching the Mounting Bracket ....................................................................................8
Figure 3: What’s Included ......................................................................................................... 11
Page 3 of 15
Compliance
FCC Compliance Statement (United States)
This device complies with Part 15 of the Federal Communications Commission (FCC) Rules. Operation is
subject to the following two conditions:
1.
This device may not cause harmful interference.
2.
This device must accept any interference received, including interference that may
cause undesired operation.
CAUTION:
Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
IC Statement
This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the
following two conditions:
1.
This device may not cause interference; and
2.
This device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes:
1.
l’appareil ne doit pas produire de brouillage, et
2.
l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en compromettre le
fonctionnement.
CE Mark Conformity
City Theatrical Inc. declares that this product conforms to the specifications listed in this manual,
following the provisions of the European RED Directive 2014/53/EU, EMC Directive 2014/30/EU,
and Low Voltage Directive 2014/35/EU:
City Theatrical Inc. vakuuttaa täten että dieses produkt tyyppinen laite on direktiivin 2014/53/EU,
2014/30/EU, 2014/35/EU oleellisten vaatimusten ja sitä koskevien näiden direktiivien muiden
ehtojen mukainen.
City Theatrical Inc. déclare que le produit est conforme aux conditions essentielles et aux
dispositions relatives à la directive 2014/53/EU, 2014/30/EU, 2014/35/EU.
□
EN 301 489-1, 301 489-18 General EMC requirements for Radio equipment
□
EN 62832-1 Safety
□
EN 300 328 Technical requirements for Radio equipment
□
EN 55032, EN 55103-2
CAUTION— This equipment is intended to be used in all EU and EFTA countries. Outdoor use may
be restricted to certain frequencies and/or may require a license for operation. Contact local
Authority for procedure to follow.
Note: ESD precautions should be used when attaching or removing the antenna.
Note: Combinations of power levels and antennas resulting in a radiated power level of above 100 mW
equivalent isotropic radiated power (EIRP) are considered as not compliant with the above mentioned directive
and are not allowed for use within the European community and countries that have adopted the European
R&TTEdirective 2014/53/EU, 2014/30/EU, 2014/35/EU. For more details on legal combinations of power levels
and antennas, contact City Theatrical Inc.
Do not use this product near water, for example, in a wet basement or near a swimming pool.
Avoid using this product during an electrical storm. There may be a remote risk of electric shock from lightning.
Page 4 of 15
Regulatory Information
Radio Frequency Notifications
Belgique Dans le cas d'une utilisation privée, à l'extérieur d'un bâtiment, au-dessus d'un espace public, aucun
enregistrement n'est nécessaire pour une distance de moins de 300m. Pour une distance supérieure à 300m
un enregistrement auprès de l'IBPT est requise. Pour une utilisation publique à l'extérieur de bâtiments, une
licence de l'IBPT est requise. Pour les enregistrements et licences, veuillez contacter l'IBPT.
France 2.4 GHz Bande : les canaux 10, 11, 12, 13 (2457, 2462, 2467, et 2472 MHz respectivement) sont
complétement libres d'utilisation en France (en utilisation intérieur). Pour ce qui est des autres canaux, ils
peuvent être soumis à autorisation selon le départment.
L'utilisation en extérieur est soumis à autorisation préalable et trèsrestreint. Vous pouvez contacter l'Autorité de
Régulation des Télécommunications (http://www.art-telecom.fr) pour de plus amples renseignements
Safety Notices
Please read this entire manual before using your new equipment. Please keep the manual in a safe place so
you can refer to it in the future as required.
The Multiverse wireless DMX/RDM System is intended for use only by qualified professionals. Connection,
installation, and hanging of this equipment must be performed in accordance with all pertinent local, regional,
and national safety codes and regulations.
Multiverse wireless DMX/RDM equipment is intended for indoor use only unless specified for outdoor use. Keep
the equipment dry! Do not operate the equipment if it gets wet!
Do not operate in excessive heat/direct sunlight. Be sure installation provides adequate ventilation.
There are no user-serviceable parts inside! Refer to qualified service personnel!
RF Exposure: The antenna(s) used for this transmitter must be installed to provide a separation distance of at
least 20cm from all persons and must not be collocated or operating in conjunction with any other antenna or
transmitter.
Page 5 of 15
Introduction
City Theatrical’s Multiverse
®
SHoW Baby® is a wireless DMX transceiver that delivers
breakthrough plug and play wireless DMX and RDM transmission right out of the box. In its
default mode (SHoW ID 201), it is compatible with all SHoW Babys ever made, including SHoW
Baby, SHoW Baby 5, and SHoW Baby 6. By connecting an RDM controller, like DMXcat® Multi
Function Test Tool, all of the 147 revolutionary new 2.4GHz Multiverse SHoW IDs are accessible
as well as all 70 SHoW DMX Neo SHoW IDs. Users can add Multiverse SHoW Baby to their
existing SHoW Baby systems, build new single universe Multiverse systems, or use Multiverse
SHoW Baby as a receiver on multiple universe systems with a Multiverse Transmitter.
The Multiverse SHoW Baby features include:
• Full compatibility with all previous SHoW Babys right out of the box
• Instant plug-and-play configuration: For a Transmitter, connect DMX IN, for a Receiver,
don’t!
• Multiverse 2.4GHz Frequency Hopping Spread Spectrum (FHSS) Radio
• Wirelessly broadcast and receive a full Universe (512 slots) of DMX
• Robust wireless DMX512 and RDM data transmission
• Six user selectable SHoW IDs accessible on the “SET ID” button, plus 147 Multiverse and
70 SHoW DMX Neo SHoW IDs accessible via RDM.
• Extremely low 4mS latency
• RDM proxy and responder functions
• Mounting bracket for installation with C-Clamp or similar hanging hardware
• Included CL2 Power Supply
• Included 2dBi omni-directional antenna
• Neutrik® 5P XLR Connectors for DMX IN and DMX OUT
Every effort has been made to anticipate your questions in this manual, but if you have any
questions that are not answered here, or you want to discuss a special application, please feel
free to contact us directly at: support@citytheatrical.com
Multiverse SHoW Baby Settings
The Multiverse SHoW Baby uses the Multiverse Radio Module. It is configured with six SHoW
ID options for Spread Spectrum Frequency Hopping and Neo Low Latency broadcast mode. No
other settings are adjustable except by RDM. The SHoW ID can be changed by pressing the
small button on the back of the Multiverse SHoW Baby labeled “SET ID”.
Table 1: Setting SHoW ID by Color
Color
SHoW ID
Use
Green
201
Adaptive Hopping (default selection)
Cyan
102
Full bandwidth broadcast
Magenta
117
Broadcast limited to lower end of band
White
133
Broadcast limited to middle end of band
Red
149
Broadcast limited to upper end of band
Yellow
165
Broadcast limited to area of Wi-Fi channel 14
Any other SHoW ID set by RDM not included in this table will make the ID/Data LED turn blue.
Multiverse SHoW Baby Antennas
The Multiverse SHoW Baby is shipped with a 2dBi omni directional antenna. Other approved
antennas include the P/N 5981 Panel Antenna and the P/N 5982 Yagi Antenna. If using a 5981
Panel Antenna, you must change the antenna type to “Panel” through the RDM Settings. If
using a 5982 Yagi Antenna, you must change the antenna type to “Yagi” through the RDM
Settings. The 5981 and 5982 antennas require the use of a P/N 5638 Antenna Adapter Cable.
Setup and Operation
Rear View Front View
Figure 1: Multiverse SHoW Baby Front and Rear View Diagrams
A Multiverse SHoW Baby system will normally consist of at least two Multiverse SHoW Baby units.
Transmitter Setup
Although a simple Multiverse SHoW Baby system will have one transmitter and one or more
receivers, you can use up to six Multiverse SHoW Baby units as transmitters set on different
SHoW IDs to create a multi universe system. The following instructions describe how to set up a
single universe system.
1. Install the Multiverse SHoW Baby you will use for a transmitter in a convenient
location where you can reach it with the DMX cable from your console or controller. For
best results, locate the unit as high in the air as possible to enable it to be clear of
obstructions. Consider where you will put your Multiverse SHoW Baby receivers and place
the Multiverse SHoW Baby transmitter where its antenna will be within line of sight with the
receivers, if possible.
2. Install the provided antenna and point it straight up in the air.
3. Connect the provided 12V DC Power Supply to the unit, and connect to mains power.
4. Select a SHoW ID for your transmitter by choosing an ID/Data LED color using the Set ID
button located on the rear next to the power jack.
5. Connect a DMX cable from the console/controller to the DMX IN. The Multiverse SHoW
Baby will automatically configure itself as a transmitter and the Tx LED will light. The DMX
IN will be automatically terminated, and the DMX OUT will be available as a DMX passthru. If you also connect a cable to the DMX OUT the termination is lifted.
6. As soon as you begin sending DMX from your console, the Multiverse SHoW Baby
will begin broadcasting and the Data LED will light solid.
Page 6 of 15
Page 7 of 15
Receiver Setup
You will need at least one Multiverse SHoW Baby to use as a receiver.
1. Install the Multiverse SHoW Baby you will use for a receiver in a convenient location
where you can reach it with a DMX cable to the device (or devices) it will be providing
DMX for. As with the Multiverse SHoW Baby transmitter, locate the unit higher in the air
for best results, and try to place your Multiverse SHoW Baby receiver where its antenna
will be within line of sight with the transmitter.
2. Install the provided antenna and point it straight up in the air.
3. Connect the provided 12V DC Power Supply to the unit, and connect to mains power.
The Multiverse SHoW Baby will be configured as a receiver and the Rx LED will light.
4. Select a SHoW ID by matching the ID/Data LED color to that of the transmitting
Multiverse SHoW Baby you wish to receive DMX data from by using the button located
on the rear of the unit next to the power jack. Transmitter and receiver SHoW ID colors
must match for them to communicate.
5. Connect a DMX cable from the Multiverse SHoW Baby DMX OUT to the first DMX device
you want to provide DMX to. You can then continue to add devices to up to a total of 32
DMX devices in the chain. Like any other DMX system, be sure the last connected
device in the chain is properly terminated.
6. As soon as you begin broadcasting from the Multiverse SHoW Baby set up as your
transmitter, the data will be received by the SHoW Baby(s) 6 set up as receiver(s) and the
transmitted DMX will be output from the receiver unit’s DMX OUT. The received signal
quality will be displayed on the four LO – RF Signal – HI LEDs. This four LED “meter” will
light to show you your signal quality; a high quality wireless signal is three or more LEDs,
and lower quality signal is two or less.
You can set up any number of additional Multiverse SHoW Baby units as receivers.
RDM Operation
Multiverse SHoW Baby is fully enabled as an RDM proxy system, so you can use RDM to
manage your Multiverse SHoW system and any connected RDM responders that are
downstream of the system.
In order to use RDM, you will also need an RDM controller such as the DMXcat Multi Function
Test Tool or a lighting control console with a built-in RDM controller.
Multiverse SHoW Baby Advanced Setup
Besides the six SHoW IDs settable via the “Set ID” button on the back of the SHoW Baby, all SHoW
DMX Neo SHoW IDs (70) and all Multiverse 2.4GHz SHoW IDs (147) are accessible with any RDM
controller, such as DMXcat®. When set to a SHoW ID not listed in Table 1, the ID/Data LED will
become blue.
Using Multiverse SHoW IDs enables the use of additional Multiverse features such as Forward Error
Correction, mDMX (lower radio energy), and improved RDM performance, as well as allowing the
Multiverse SHoW Baby to serve as a receiver on a system with a Multiverse Transmitter or Multiverse
Node. See Table 4: Multiverse SHoW IDs on page 12 for more information about the additional
SHoW DMX Neo or Multiverse SHoW IDs.
Page 8 of 15
Using an RDM controller like a DMXcat allows access to several other Multiverse SHoW Baby
features:
• SHoW ID
All available Multiverse or SHoW DMX Neo SHoW IDs can be entered here.
• Output Power
Output power may be user selected as Low, Med, Hi, or Maximum. It is a best practice to use
the least amount of output power to achieve a successful show. This helps to reduce
reflections which can reduce signal fidelity and to reduce any potential negative effect on
other radio users in the area. You can monitor signal strength via RDM. Default is Maximum.
• RDM Traffic
The RDM Traffic setting determines whether RDM data is passed downstream of the
Multiverse SHoW Baby. It does not affect whether the Multiverse SHoW Baby is detectable
by devices upstream. It is recommended that RDM be turned off before production situations
as many DMX devices do not correctly handle RDM data and may exhibit flickering or other
undesired behavior. Default is Off.
• Antenna Selection
If a panel (P/N 5981) or Yagi (P/N 5982) antenna is used instead of the default omni antenna,
choose it on this menu for optimum performance and to remain in compliance with FCC and
other radio compliance regulations. An (P/N 5638) adapter cable is required to use a panel or
Yagi antenna.
• SHoW Key Security (Multiverse SHoW IDs only)
The SHoW Key setting allows a user to enter a key to privatize their SHoW ID from another
system on the same SHoW ID. SHoW IDs and SHoW Keys need to match in order for
receivers and transmitters to talk to each other. Keeping your SHoW Key private will provide a
level of security to your Multiverse system from unauthorized use. It is not recommended to
use different SHoW Keys in a system that uses multiple Multiverse SHoW Babys as
Transmitters on the same SHoW ID. The range is 0 (Default) to 500.
Table 2: SHoW IDs and SHoW Keys
• Forward Error Correction (Multiverse SHoW IDs only)
High noise environments can affect wireless DMX performance. Enabling Error Correction
adds additional information to the data packets to correct errors in slot data that would have
otherwise been lost, restoring DMX delivery back to near perfect levels. The extra data
reduces the number of slots that can be transported, Max reduces slots by 50%, Med by 33%,
Min by 25%. Only needs to be set at the Transmitter. Default is Off.
• mDMX (Multiverse SHoW IDs only)
Improves fidelity while dramatically reducing radio energy broadcast into the spectrum. Only
needs to be set at the Transmitter. Default is on.
Situation
Condition
Outcome
Same SHoW Key
with
Different SHoW IDs
OK
Different SHoW Keys
with
Same SHoW IDs
Not OK
Different SHoW Keys
with
Different SHoW IDs
OK
Specifications
Product Information
Product Name
Multiverse SHoW Baby
Part Number
5900
Maximum Concurrent Universes
1
Frequency Range:
2400 – 2480 MHz
Physical Specifications
Length
92mm (3.625 in)
Width
76mm (3.00 in)
Height
46mm (1.80in)
Weight
0.16 Kg (0.35 lb)
Construction
Steel, ABS plastic, Black
Connection Specifications
*
DC Jack, 5.5mm x 2.1mm barrel, center positive, 9mm mating depth
Neutrik® 5-Pin XLR connectors for DMX512 IN and OUT/thru ports
RP-SMA female antenna connector
USB Type-A port, internal (requires removing cover and circuit board)
Functionality
User Interface
1 Button/LEDs
RDM Features
RDM Proxy, RDM Responder
Power
Input Power
5-30VDC, 0.8W
Max Draw
66mA max draw at 12V
AC Adapter Voltage
100VAC to 240VAC 50/60Hz
Radio Technology
Latency
4 ms average
RF Sensitivity
-95dBm
Loss of Data Behavior
Output stops
Broadcast Power
2.5mW, 8mW, 25mW, 80mW EIRP
Broadcast Modes
Adaptive, Full, Low, Mid, High, Max
DMX Burst Modes
Auto Dynamic
Show IDs
217 (Americas and Worldwide)
Product Information
Use Environment
Indoor
Operating Temperature
0° C to 40° C
Storage Temperature
-40° C to 85° C
IP Rating
IP50
Compliance
FCC, IC, CE
Warranty
One year
*Note: This power supply connector is not compatible with Multiverse Node.
Table 3: Physical Characteristics
Page 9 of 15
Page 10 of 15
Installing the Mounting Bracket
The Multiverse SHoW Baby is provided with a Mounting Bracket for use with ½” theatrical
mounting hardware like a C-Clamp.
Mount the Bracket on the Multiverse SHoW Baby using the three provided 8-32 x ½" pan
head Philips screws.
Figure 2: Attaching the Mounting Bracket
Page 11 of 15
What’s Included
Figure 3: What's Included
Table 3: Included Item Descriptions and Part Numbers
Label in
Figure 3
Item Description
Part
Number
1
Multiverse SHoW Baby Transceiver
5900
2
Mounting Plate with hardware
5602
3
12VDC Power Supply with plug kit
5627
4
2dBi Omni, 2.3” Multiverse Antenna
5729
1.
4.
3.
2.
Page 12 of 15
Table 4: Multiverse SHoW IDs
Multiverse SHoW ID Example: 24
3 0
2
Prefix
Data Rate
Band
Hop Pattern
24 2.4GHz
Faster data rates provide more
DMX universes. Slower data
rates travel longer distances and
provide more immunity to
interference.
2.4GHz:
Universes
Range
1
1
1500’ Outdoor
300’ Indoor
2
2
1500’ Outdoor
300’ Indoor
3
5
1000’ Outdoor
100’ Indoor
Specifies which sections
of the wireless band the
frequency hopping
utilizes.
0
Use full range of
900MHz or 2.4GHz
band.
1
Use only low band
channels.
2
Use only mid band
channels (available for
Data Rate 1 only).
3
Use only high band
channels.
4
Use only extreme high
band to avoid WiFi
(2.4GHz only.
5
Adaptive hopping.
Avoids busy channels
by analyzing
spectrum.
If multiple wireless
systems need to operate
with the same data rate
and band this value will
change the hopping
pattern to minimize
overlapping between the
two systems. Can be any
number from 0 – 9 (not all
bands have all Hop
Patterns).
Note: Not all combinations of digits are possible and unused numbers are reserved for future use.
Page 13 of 15
Table 5: SHoW DMX Neo SHoW IDs for Use with Multiverse SHoW Baby
SHoW ID
Mode
Hopping
Pattern
Bandwidth
101
Neo 1 Full
102
Neo 2 Full
103
Neo 3 Full
104
Neo 4 Full
105
Neo 5 Full
106
Neo 6 Full
107
Neo 7 Full
108
Neo 8 Full
109
Neo 9 Full
110
Neo
10
Full
111
Neo
11
Full
112
Neo
12
Full
113
Neo
13
Full
114
Neo
14
Full
115
Neo
15
Full
116
Neo
16
Full
SHoW ID
Mode
Hopping Pattern
Bandwidth
117
Neo
1
Limited Low, Wi-Fi 1-6
118
Neo
2
Limited Low, Wi-Fi 1-6
119
Neo
3
Limited Low, Wi-Fi 1-6
120
Neo
4
Limited Low, Wi-Fi 1-6
121
Neo
5
Limited Low, Wi-Fi 1-6
122
Neo
6
Limited Low, Wi-Fi 1-6
123
Neo
7
Limited Low, Wi-Fi 1-6
124
Neo
8
Limited Low, Wi-Fi 1-6
125
Neo
9
Limited Low, Wi-Fi 1-6
126
Neo
10
Limited Low, Wi-Fi 1-6
127
Neo
11
Limited Low, Wi-Fi 1-6
128
Neo
12
Limited Low, Wi-Fi 1-6
129
Neo
13
Limited Low, Wi-Fi 1-6
130
Neo
14
Limited Low, Wi-Fi 1-6
131
Neo
15
Limited Low, Wi-Fi 1-6
132
Neo
16
Limited Low, Wi-Fi 1-6
Page 14 of 15
SHoW ID
Mode
Hopping Pattern
Bandwidth
133
Neo
1
Limited Mid, Wi-Fi 5-9
134
Neo
2
Limited Mid, Wi-Fi 5-9
135
Neo
3
Limited Mid, Wi-Fi 5-9
136
Neo
4
Limited Mid, Wi-Fi 5-9
137
Neo
5
Limited Mid, Wi-Fi 5-9
138
Neo
6
Limited Mid, Wi-Fi 5-9
139
Neo
7
Limited Mid, Wi-Fi 5-9
140
Neo
8
Limited Mid, Wi-Fi 5-9
141
Neo
9
Limited Mid, Wi-Fi 5-9
142
Neo
10
Limited Mid, Wi-Fi 5-9
143
Neo
11
Limited Mid, Wi-Fi 5-9
144
Neo
12
Limited Mid, Wi-Fi 5-9
145
Neo
13
Limited Mid, Wi-Fi 5-9
146
Neo
14
Limited Mid, Wi-Fi 5-9
147
Neo
15
Limited Mid, Wi-Fi 5-9
148
Neo
16
Limited Mid, Wi-Fi 5-9
SHoW ID
Mode
Hopping Pattern
Bandwidth
149
Neo
1
Limited High, Wi-Fi 7-11
150
Neo
2
Limited High, Wi-Fi 7-11
151
Neo
3
Limited High, Wi-Fi 7-11
152
Neo
4
Limited High, Wi-Fi 7-11
153
Neo
5
Limited High, Wi-Fi 7-11
154
Neo
6
Limited High, Wi-Fi 7-11
155
Neo
7
Limited High, Wi-Fi 7-11
156
Neo
8
Limited High, Wi-Fi 7-11
157
Neo
9
Limited High, Wi-Fi 7-11
158
Neo
10
Limited High, Wi-Fi 7-11
159
Neo
11
Limited High, Wi-Fi 7-11
160
Neo
12
Limited High, Wi-Fi 7-11
161
Neo
13
Limited High, Wi-Fi 7-11
162
Neo
14
Limited High, Wi-Fi 7-11
163
Neo
15
Limited High, Wi-Fi 7-11
164
Neo
16
Limited High, Wi-Fi 7-11
165
Neo 1 Max, Wi-Fi 13-14
166
Neo 2 Max, Wi-Fi 13-14
SHoW ID
Mode
Universe
Bandwidth
201
Neo Adaptive
A
Full
202
Neo Adaptive
B
Full
203
Neo Adaptive
C
Full
204
Neo Adaptive
D
Full
Page 15 of 15
Table 6: Troubleshooting Guide
SHoW DMX Neo SHoW IDs
Multiverse SHoW IDs
Symptom
Solution(s)
Unit does not power up.
Check that power cable is properly installed.
Test power outlet with another device.
Fixtures connected to the
receiver are not responding.
Check that the Tx and Rx symbols on transmitters and receivers are solid.
Check that SHoW ID matches on transmitters and receivers.
Symptom
Solution(s)
Unit does not power up.
Check that power cable is properly installed.
Test power outlet with another device.
Fixtures connected to the
receiver are not responding.
Check that the Tx and Rx symbols on transmitters and receivers are solid.
Check that SHoW ID and SHoW Key match on transmitters and receivers.
Check that Universe setting matches on Tx and Rx.
Loading...
