HURRICANE II FAN
TM
Operating Instructions
P/N 100160 (110V)
P/N 100165 (230V
)
Page 2
1
Thank you for purchasing this Hurricane II FanTM.
o As you will notice from the table of contents, the manual for your new
fan is quite extensive.
o To guarantee perfect and successful work with this machine, please
take some time to read the manual carefully.
o And finally, we believe you will enjoy many years of dependable,
trouble-free service if you properly install and maintain this powerful
piece of machinery called the Hurricane II Fan
TM
.
CITC
2100 196
th
St. S.W., Ste. 138
Lynnwood, WA 98036
(888) 786-CITC
www.citcfx.com
Page 3
2
Contents
1. Set of Equipment Supplied 3
2. Accessories and Parts 3
3. Description 3
4. Safety Instructions 4
5. Operating the Hurricane II Fan
TM
4
5.1 Unpacking the Hurricane II FanTM
5.2 Electrical Power Requirements
5.3 Running the Hurricane II Fan
TM
5.4 Transporting the Hurricane II FanTM
5.5 Hanging the Hurricane II FanTM
5.6 Optional Universal DMX Control
5.7 Troubleshooting
5.8 Notes on optional Universal DMX operation
6. Service and Maintenance 7
7. Technical Data 7
8. Warranty Conditions 8
Page 4
3
1. Set of Equipment Supplied
1 Hurricane II FanTM
1 Bracket with hardware (P/N 600440)
Operating Instructions Booklet
2. Accessories and Parts
C-Clamp w/Baby Spud and Safety Cable (P/N 250140)
Universal DMX for on/off control only (P/N 250041)
DMX Turret (P/N 250350)
Floor plate with baby spud (P/N 250130)
Road Case (P/N 250150)
The following miscellaneous parts are available for the Hurricane II Fan
TM
600424 Metal Tubular Bracket/Stand - OS
600416 Motor - 120vac, 1hp - OS
600417 Blower Wheel - OS
600418 Motor Mount Bracket - OS
600419 Spider - OS
600420 Switch - OS
600421 Grill Guard - OS
600422 Motor 1/2 hp 120vac - OS
600423 Capacitor for Hurricane - OS
Please check whether all the products you ordered are supplied.
3. Description of the Hurricane II Fan
TM
o Blow fog, haze, snow, wind to 150’ (45.7m). Tilt 300 degrees, swivel 360 degrees.
Three speeds: three seconds to top speed. Blow massive volumes of air without
motor hum. Continuous output without overheating. Lightweight, portable and
economical. The Hurricane II Fan
TM
is a full hp and can blow to 150’ (45.7m).
o The Hurricane II Fan
TM
can be on/off controlled with optional Universal DMX control.
o Portable and compact, capable of much more than fans four times its size, the
Hurricane II Fan
TM
weighs just 49 lbs (23kg).
Page 5
4
4. Safety Instructions
WARNING: Read and understand all labels and operating instructions
before attempting installation.
o RISK OF ELECTRICAL SHOCK- This fan is supplied with a grounding conductor.
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. To reduce risk of electrical shock, connect only to a properly grounded,
grounding type receptacle.
o In the event of a malfunction or breakdown, grounding will reduce the risk of electric
shock by providing a path of least resistance for the electric current. Install electrical
hookup in accordance with all local codes and ordinances. Warning: Check with a
qualified electrician if you are in doubt whether the fan is properly grounded.
o To reduce risk of electric shock, disconnect power before servicing this fan.
o SAFETY CABLE- When suspending the fan using the C-Clamps, be sure to attach
the safety cable around the pipe grid and go through the handle of the Hurricane and
attach the cable to itself. It is mandatory to use a safety cable when suspending this
unit!
o C-Clamp- Be sure the Baby Spud has a solid unscrewable connection to the Spud.
When tightening the baby spud in place, always use the washer and cotter key.
Tighten the side lock bolt on the knurled area of the baby spud. Never loosen this lock
bolt to swivel the fan. Always swivel with the loosening of the swivel bolt on the side of
the C-Clamp and spin the entire spud/baby spud together. Tighten the swivel bolt
when in place.
5. Operating the Hurricane II Fan
TM
5.1 Unpacking the Hurricane II FanTM
Before removing from the box, note the position of the packing material and how the unit
is setting with the sprocket side down for future transport or boxing.
Pull the fan sprocket cover (foam block) and remove the clamping ring with an Allen
wrench. Slide collar over spindle toward fan until seated against the shoulder.
Once the bracket is completely slipped on, reapply the clamping ring until the shaft is
flush to the outside. Tighten securely with an Allen wrench.
5.2 Electrical Power Requirements
Check to see that the power switch on the handle is in the off position. Plug in the cord to
a grounded outlet with sufficient amperage. You may double check the voltage marking,
inside the mouth of the air output. The voltage requirement for this fan is acceptable to
almost all types of single-phase electrical supply. Current consumption is 10 amps at
110vac and 5 amps for the 230 VAC model. Make sure you are using an adequate
extension cord. These fans need at least 12-gauge extension cord for sufficient
amperage supply. Because initial current surge is higher, the fan should have a
Page 6
5
dedicated circuit with extra capacity (20 amp circuit at 110 VAC. 10 amp circuit at 230
VAC).
5.3 Running the Hurricane II FanTM
1. Quickly turn on then off the power and check to see if the fan is moving easily without
rubbing the edge. Sometimes in shipping the fan may be damaged due to mishandling or
jarring of the unit. Contact your shipper and CITC if damage has occurred in transport.
2. Spin the entire fan to the position you want the air to flow, tightening the lock- down nut
on the spindle to stop it from moving. Use a wrench.
3. Turn on the fan to speed desired, aiming the airflow the direction you want, allowing 2530' (7.6-9.1m) of open air space for air movement in front of the fan Your fan is designed
to be left on continuously for 2 years without overheating or failure.
5.4 Transporting the Hurricane II FanTM
When shipping or transporting to another location (not boxed), be sure to set the fan on
the floor, not hanging from the bracket. Damage may occur or you may misalign the fan
unit. Always have the fan lying down on the floor with the bracket up or legs off the floor.
5.5 Hanging the Hurricane II FanTM
1. For hanging, use baby-spud C-Clamp with a washer, cotter key and safety cable.
Place the C-Clamp baby spud onto the attachment on the edge of either of the legs,
placing the cotter key through the pin and tightening the lock screw with a wrench. Adjust
the position by loosening the upper nut and spinning the entire shaft inside the C-Clamp.
Never loosen the tightening screw on the Hurricane IITM bracket while hanging.
2. Attach the safety cable around the pipe grid and through the handle of the Hurricane
and attach the cable to itself. You may now adjust the position of the Hurricane IITM with
the wrench, spinning or tilting as desired. Do not loosen any of the anchor bolts for
movement without the safety cable attached first.
5.6 Optional Universal DMX Control
With DMX control, you will be able to turn the fan on when the slider control reaches
approximately 50%. (See section 5.8).
Swivel Lock
Washer
Cotter Key
Page 7
6
5.7 Troubleshooting
DMX doesn’t work: turn on control knob on fan to desired speed setting.
Fan rubs when turning: call CITC for instructions. Do not remove cover.
Motor jumps or is unsteady: check extension cord for low gauge. Turn off any other
loads sharing the same circuit or test in dedicated outlet.
Fan starts slowly: Check extension cord for low gauge. Turn off any other loads sharing
the same circuit or test in dedicated outlet.
5.8 Notes on optional Universal DMX operation
Each DMX’d unit will occupy a unique DMX address on the DMX chain. By adjusting the
dip switches on the side of the machine near the DMX cable plug-ins, the user may
assign one address to the machine, giving you on/off and volume control with one DMX
channel (there is no timer on this DMX).
Step 1). Attach the DMX cable to the upper “in” female connector located on the end of
the fan.
Step 2). The DMX address is configured by adding the dip switch numbers together to
total the number required. For example, DipSwitch 1 + 6 = 33. Your DMX channel would
be 33.
Dip Switch 1 2 3 4 5 6 7 8 9
Channel # 1 2 4 8 16 32 64 128 256
When you move the slide control or digital control to approximately the 50%
position the fan will turn on.
0 – 50% = Off
51– 100% = On
“Input” and “Output” designations on the DMX plugs are arbitrary (i.e., you can use the
input plug for output and visa-versa). It is not necessary to attempt converting your DMX
line’s connector to female/male to match the appropriate socket on the plug. As long as it
is looped in/out, it will work.
Page 8
7
6. Service and Maintenance
Care of your Hurricane II FanTM will give you years of service. Note:
cleaning your unit is going to pay off in constant good performance.
1. Because air passes through the wiring and blades, it is important not to feed fog or wet
fluids through this unit. It will damage the circuitry.
2. Keeping your unit clean is essential. Use of Filter Foam would be advised if the air is full
of lint or dirt.
3. Wipe down all vent inlets with a clean dry cloth.
4. Never use water around the electrical connections
5. Inspect the cord for damage before each use.
6. Never operate with extension cords that are under 12 awg.
7. Technical Data
Hurricane II FanTM P/N 100160 (230V P/N 100165)
Weight 49lbs (19.3 kg)
Size (with bracket) 17 3/4” x 19 1/2” x 19 1/2”
(45 cm x 49.5 cm x 49.5 cm)
Shipping Weight 55 lbs. (25 kg) without clamp
60 lbs (27.3 kg) with clamp
Shipping Box Size 23” x 23” x 23”
(58.4 cm x 58.4 cm x 58.4 cm)
DMX Optional Universal DMX on/off
control
CFM’s
3000/4000/5000
Wind Speed
3 speeds to 58 mph (93 km/hr)
Wind Range
3 speeds to 150’ (45.7m)
Fan Outlet Opening 5” x 19” (12.7 cm x 48 cm)
Motor 1 hp
Color Black
Positioning 360 degrees
Electrical Supply 110VAC, 10 A, 60 Hz
230 VAC, 5 A, 50 Hz
Limited Warranty One (1) year
Rev. 8/1/03
Page 9
8
8. Limited Warranty Conditions
for the Hurricane II Fan
TM
1. Subject to the following conditions we will repair any defect or fault in the unit
if it is caused by a proven factory fault and has been advised immediately
after appearance and within 30 days of delivery to the end user. Insignificant
deviations of the regular product quality does not guarantee replacement
rights, nor do faults or defects caused by water, by generally abnormal
environment conditions or Force Majeure.
2. Limited Warranty Service will be done in the following way: Faulty parts will be
repaired or replaced (our choice) with correct parts. Faulty units have to be
shipped to us or sent to us at customer’s expense. The RMA# has to come
with the faulty unit.
3. The customer loses all rights for limited warranty services, if any repairs or
adjustments are done to the units by unauthorized persons and/or if spare
parts are used, which are not approved by us. Also non-compliance with the
instructions in this manual or mistakes by incorrect handling/treating of the
machine, any faults and damages caused by undue force will lead to a loss of
limited warranty.
4. Freight costs to CITC when under the limited warranty services are the
responsibility of the customer. CITC will pay freight upon return.
5. Limited warranty services do not cause an extension of the limited warranty
time or the start of a new limited warranty time. The warranty of replaced
parts ends with the limited warranty time of the whole unit.
6. If a defect/fault can not be repaired by us in a satisfactory time, we will, within
30 days after sale of the unit, our choice either:
Replace the whole unit for free or
Refund the lesser value or
Take back the whole unit and refund the purchase price, but not more that
the usual market price at the time of refund.
7. Further claims, especially for damages, losses etc. outside the unit are
excluded.
Page 10
9
If you should send the unit for service, obtain your RMA#
first by calling CITC. Obtain your RMA # by calling CITC.
Payment arrangements for repair must be made before
receiving RMA # in case unit is not covered under Limited
Warranty.
Send unit to:
CITC
RMA # XXXXXXX
2100 196
th
Street SW Suite #138
Lynnwood, WA 98036
Tel: (888) 786-CITC or (425) 776-4950
Fax: (425) 776-5129
Website: www.citcfx.com
E-mail: [email protected]
2100 196th St. SW, #138, Lynnwood, WA 98036-7083
425-776-4950 FAX: 425-776-5129
www.citcfx.com [email protected]
August 1, 2003
Loading...
