Cisco XR 12410 User Manual

Cisco XR 12410 Router Installation Guide

Americas Headquarters

Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 USA http://www.cisco.com Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

Text Part Number: OL-13832-01

THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.

THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.

The following information is for FCC compliance of Class A devices: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio-frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case users will be required to correct the interference at their own expense.

The following information is for FCC compliance of Class B devices: The equipment described in this manual generates and may radiate radio-frequency energy. If it is not installed in accordance with Cisco’s installation instructions, it may cause interference with radio and television reception. This equipment has been tested and found to comply with the limits for a Class B digital device in accordance with the specifications in part 15 of the FCC rules. These specifications are designed to provide reasonable protection against such interference in a residential installation. However, there is no guarantee that interference will not occur in a particular installation.

Modifying the equipment without Cisco’s written authorization may result in the equipment no longer complying with FCC requirements for Class A or Class B digital devices. In that event, your right to use the equipment may be limited by FCC regulations, and you may be required to correct any interference to radio or television communications at your own expense.

You can determine whether your equipment is causing interference by turning it off. If the interference stops, it was probably caused by the Cisco equipment or one of its peripheral devices. If the equipment causes interference to radio or television reception, try to correct the interference by using one or more of the following measures:

• Turn the television or radio antenna until the interference stops.

• Move the equipment to one side or the other of the television or radio.

• Move the equipment farther away from the television or radio.

• Plug the equipment into an outlet that is on a different circuit from the television or radio. (That is, make certain the equipment and the television or radio are on circuits controlled by different circuit breakers or fuses.)

Modifications to this product not authorized by Cisco Systems, Inc. could void the FCC approval and negate your authority to operate the product.

The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public domain version of the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the University of California.

NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS” WITH ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR

IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND

NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE.

IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

CCVP, the Cisco logo, and Welcome to the Human Network are trademarks of Cisco Systems, Inc.; Changing the Way We Work, Live, Play, and Learn is a service mark of Cisco Systems, Inc.; and Access Registrar, Aironet, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity, Enterprise/Solver, EtherChannel, EtherFast, EtherSwitch, Fast Step, Follow Me Browsing, FormShare, GigaDrive, HomeLink, Internet Quotient, IOS, iPhone, IP/TV, iQ Expertise, the iQ logo, iQ Net Readiness Scorecard, iQuick Study, LightStream, Linksys, MeetingPlace, MGX, Networkers, Networking Academy, Network Registrar, PIX, ProConnect, ScriptShare, SMARTnet, StackWise, The Fastest Way to Increase Your Internet Quotient, and TransPath are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.

All other trademarks mentioned in this document or Website are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (0711R)

Any Internet Protocol (IP) addresses used in this document are not intended to be actual addresses. Any examples, command display output, and figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses in illustrative content is unintentional and coincidental.

Cisco XR12410 Router Installation Guide

About This Guide xi

Audience xi

Purpose xi

Document Organization xii

Document Conventions xii

Obtaining Documentation, Obtaining Support, and Security Guidelines xiv

CHAPTER

OL-13832-01

1 Cisco XR 12410 Router Overview 1-1

Physical and Functional Description of Router 1-1

AC and DC Power Subsystems 1-5

AC Power Entry Modules 1-5 DC Power Supplies 1-7

Switch Fabric and Alarm Card Overview 1-9

Switch Fabric Card Functionality 1-10

Clock Scheduler Card 1-10 Switch Fabric Card 1-11

Alarm Cards and Alarm Display 1-11

Line Card and Route Processor Overview 1-13

Line Cards 1-14 Route Processor 1-14 Performance Route Processor Overview 1-16

PRP PCMCIA Card Slots and Status LEDs 1-16 PRP Ethernet Ports and Status LEDs 1-17

Cisco XR 12410 Router Installation Guide

Contents

PRP Auxiliary and Console Ports 1-18 PRP Reset Switch 1-18 PRP Alphanumeric Message Displays 1-19

PRP Memory Components 1-20

PRP SDRAM 1-22 PRP SRAM 1-22 PRP NVRAM 1-23 PRP Flash Memory 1-23

Upper and Lower Cable Management Brackets 1-24

Upgrading a Cisco 12000 Series Router to a Cisco XR 12000 Series Router 1-24

Horizontal Cable Management Bracket 1-25

Blower Module 1-27

CHAPTER

2 Preparing for Installation 2-1

Safety Guidelines 2-2

General Safety Guidelines 2-2 Compliance and Safety Information 2-3 Laser Safety 2-3 Preventing Electrostatic Discharge Damage 2-3 Lifting Guidelines 2-5 Laser Safety 2-5

Site Requirement Guidelines 2-6

Rack-Mounting Guidelines 2-6

Enclosed Rack 2-7 Open Rack 2-7 Telco Rack 2-8

Site Layout and Equipment Dimensions 2-10 Air Flow Guidelines 2-12 Temperature and Humidity Guidelines 2-13 Power Connection Guidelines 2-13

Cisco XR 12410 Router Installation Guide

OL-13832-01

AC-Powered Routers 2-14

DC-Powered Routers 2-15 NEBS Supplemental Unit Bonding and Grounding Guidelines 2-18 Site Wiring Guidelines 2-20

PRP Port Connection Guidelines 2-22

PRP Auxiliary and Console Port Connections 2-22

PRP Auxiliary Port Signals 2-24

PRP Console Port Signals 2-25 PRP Ethernet Connections 2-26

PRP RJ-45 Ethernet Connections 2-28

Alarm Display Connection Guidelines 2-31

Contents

CHAPTER

3 Installing the Cisco XR 12410 Router 3-1

Pre-Installation Considerations and Requirements 3-2

Installation Overview 3-3

Required Tools and Equipment 3-4 Unpacking and Positioning the Router 3-4

Removing Components Before Installing the Chassis 3-4

Removing Power Supplies 3-7

Removing AC PEMs 3-7

Removing DC PEMs 3-8 Removing the Blower Module 3-9

Removing Cards from the Chassis 3-11

Removing Cards from the Line Card and RP Card Cage 3-11 Removing Cards from the Switch Fabric and Alarm Card Cage 3-14

Rack-Mounting the Router Chassis 3-15

Verifying Rack Dimensions 3-17 Installing Rack-Mount Brackets—Optional 3-18 Installing Center-Mount Brackets—Optional 3-20

OL-13832-01

Cisco XR 12410 Router Installation Guide

vii

Contents

Installing the Chassis in the Rack 3-23

Supplemental Bonding and Grounding Connections 3-26

Reinstalling Components After Installing the Chassis 3-27

Reinstalling Power Supplies 3-27

Reinstalling AC PEMs 3-28

Reinstalling DC PEMs 3-29 Reinstalling the Blower Module 3-30

Reinstalling Cards in the Chassis 3-31

Reinstalling Cards in the Switch Fabric and Alarm Card Cage 3-31 Reinstalling Cards in the Line Card and RP Card Cage 3-33

Connecting Line Card Network Interface Cables 3-34

Connecting PRP Route Processor Cables 3-39

Connecting to the PRP Console Port 3-40 Connecting to the PRP Auxiliary Port 3-41 Connecting to the PRP Ethernet Ports 3-41

CHAPTER

viii

Connecting Alarm Display Card Cables 3-43

Connecting Power to the Router 3-44

Connecting Power to an AC-Powered Router 3-45 Connecting Power to a DC-Powered Router 3-46

4 Troubleshooting the Installation 4-1

Troubleshooting Overview 4-2

Troubleshooting Using a Subsystem Approach 4-2 Normal Router Startup Sequence 4-3 Identifying Startup Issues 4-4

Troubleshooting the Power Subsystem 4-5

Troubleshooting the AC-Input Power Subsystem 4-5 Troubleshooting the DC-Input Power Subsystem 4-8

Troubleshooting a DC PEM 4-10

Cisco XR 12410 Router Installation Guide

OL-13832-01

Additional Power Subsystem Troubleshooting Information 4-12 Troubleshooting the Power Distribution System 4-14

Troubleshooting the Processor Subsystem 4-15

Performance Route Processor Overview 4-16

PRP PCMCIA Card Slots and Status LEDs 4-16

PRP Ethernet Ports and Status LEDs 4-17

PRP Auxiliary and Console Ports 4-18

PRP Reset Switch 4-18

PRP Alphanumeric Message Displays 4-19 PRP Memory Components 4-20

PRP SDRAM 4-22

PRP SRAM 4-22

PRP NVRAM 4-23

PRP Flash Memory 4-23 Troubleshooting the Route Processor 4-24

Troubleshooting Using the RP Alphanumeric Display 4-25 Troubleshooting Line Cards 4-27

Troubleshooting Using the Line Card Alphanumeric Display 4-28 Troubleshooting Using the Alarm Display 4-33

Monitoring Critical, Major, and Minor Alarm Status 4-34

Contents

CHAPTER

OL-13832-01

Troubleshooting the Cooling Subsystem 4-35

Blower Module Operation 4-36 Power Supply Operation 4-36 Overtemperature Conditions 4-37 Isolating Cooling Subsystem Problems 4-38

5 Maintaining the Router 5-1

Prerequisites and Preparation 5-2

Powering Off the Router 5-2

Removing and Replacing the Air Filter Door Front Cover 5-3

Cisco XR 12410 Router Installation Guide

Contents

Cleaning or Replacing the Chassis Air Filter 5-5

Cleaning or Replacing a Chassis Air Filter 5-6

Removing and Replacing the Blower Module 5-9

Troubleshooting the Blower Module Installation 5-11

Removing and Replacing AC and DC Power Subsystem Components 5-12

Installation Guidelines 5-12 Removing and Replacing an AC PEM 5-13 Troubleshooting the AC Power Supply Installation 5-16 Removing and Replacing an AC PDU 5-18 Removing and Replacing a DC PEM 5-22 Troubleshooting a 2800 W DC PEM Installation 5-25 Removing and Replacing a DC PDU 5-27

Removing and Replacing Cards from the Chassis 5-36

Removing and Replacing Cards from the Line Card and RP Card Cage 5-38 Removing and Replacing Cards from the Switch Fabric and Alarm Card

Cage 5-40

APPENDIX

NDEX

Removing and Installing a Chassis 5-41

Removing a Chassis from the Equipment Rack 5-42 Installing a Replacement Chassis in the Equipment Rack 5-44 Packing a Defective Chassis for Shipment 5-45

A Technical Specifications A-1

Router Specifications A-1

B Site Log B-1

Cisco XR 12410 Router Installation Guide

OL-13832-01

Audience

About This Guide

The Cisco XR 12410 Router Installation Guide is written for hardware installers and system administrators of Cisco routers.

This publication assumes that the user has a substantial background in installing and configuring router and switch-based hardware. The reader should also be familiar with electronic circuitry and wiring practices, and have experience as an electronic or electromechanical technician.

Purpose

OL-13832-01

This installation and configuration guide contains procedures for installing the router hardware, creating a basic startup configuration file, and powering on the router for the first time.

Cisco XR 12410 Router Installation Guide

Document Organization

This installation and configuration guide is organized into the following chapters and appendixes:

• Chapter 1, “Cisco XR 12410 Router Overview,” provides an introduction to

the major components of Cisco XR 12410 router.

• Chapter 2, “Preparing for Installation,” describes safety considerations,

required tools and equipment, an overview of the installation, and procedures to perform before the installation.

• Chapter 3, “Installing the Cisco XR 12410 Router,” provides instructions for

installing the hardware and connecting external network interface cables.

• Chapter 4, “Troubleshooting Overview,”provides guidelines for

troubleshooting the router hardware installation.

• Chapter 5, “Maintaining the Router,” provides removal and replacement

procedures for primary router components or field-replaceable units (FRUs).

• Appendix A, “Technical Specifications,” provides a summary of physical,

electrical, and environmental specifications for the router.

About This Guide

• Appendix B, “Site Log,”provides a sample site log that can be used to record

actions relevant to the operation and maintenance of the router.

• Index

Document Conventions

This publication uses the following conventions:

• Ctrl represents the key labeled Control. For example, the key combination

Ctrl-Z means hold down the Control key while you press the z

Command descriptions use these conventions:

• Examples that contain system prompts denote interactive sessions, indicating

the commands that you should enter at the prompt. The system prompt indicates the current level of the EXEC command interpreter.

For example:

–

The router> prompt indicates that you should be at the user level.

Cisco XR 12410 Router Installation Guide

xii

key.

OL-13832-01

About This Guide

Caution Means be careful. You are capable of doing something that might result in

Document Conventions

–

The router# prompt indicates that you should be at the privileged level.

Access to the privileged level usually requires a password. Refer to the related software configuration and reference documentation for additional information.

• Commands and keywords are in bold font.

• Arguments for which you supply values are in italic font.

• Elements in square brackets ([ ]) are optional.

• Alternative but required keywords are grouped in braces ({ }) and separated

by vertical bars (|).

equipment damage or loss of data.

Note Means take note. Notes contain helpful suggestions or references to materials not

contained in this manual.

Timesaver Means the described action saves time. You can save time by performing the

OL-13832-01

Warning

action described in the paragraph.

This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents. To see translations of the warnings that appear in this publication, refer to the Regulatory Compliance and Safety Information document that accompanied this device.

Cisco XR 12410 Router Installation Guide

xiii

About This Guide

Obtaining Documentation, Obtaining Support, and Security Guidelines

For information on obtaining documentation, obtaining support, providing documentation feedback, security guidelines, and recommended aliases and general Cisco Documentation, which also lists all new and revised Cisco documentation, at:

http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html

documents, see the monthly What’s New in Cisco Product

technical

xiv

Cisco XR 12410 Router Installation Guide

OL-13832-01

CHA P TER

Cisco XR 12410 Router Overview

This chapter provides an overview of the Cisco XR 12410 router. It contains physical descriptions of the router hardware and major components, and functional descriptions of the hardware-related features.

Physical and Functional Description of Router

The router chassis is a sheet-metal enclosure that houses router components.

All router models contain the following major components (Figure 1-1):

• Blower module—Supplies cooling air to the router so it does not overheat.

See the

• Alarm display—Monitors various router functions such as power and CSC

and SFC status. See the

page 1-11 for additional information.

• Horizontal cable management bracket—Used to neatly route line card cables.

See the additional information.

• Line card and Route Processor card cage—Has 10 user-configurable slots that

support a combination of line cards and either one or two route processors (RPs).

“Blower Module” section on page 1-27 for additional information.

“Alarm Cards and Alarm Display” section on

“Horizontal Cable Management Bracket” section on page 1-25 for

OL-13832-01

Cisco XR 12410 Router Installation Guide

1-1

Physical and Functional Description of Router

• Switch fabric and alarm card cage—Located behind the air filter door, this

card cage contains 7 slots for the switch fabric card set, and two slots for alarm cards. The switch fabric card set is made up of five switch fabric cards (SFCs) and two clock scheduler cards (CSCs). See the

Alarm Card Overview” section on page 1-9 for additional information.

• Power Entry Modules—Either two AC power entry modules (PEMs) or two

DC PEMs provide power to the router. See the

Subsystems” section on page 1-5 for additional information.

• Chassis backplane (not shown)—Distributes power to the chassis

components.

Chapter 1 Cisco XR 12410 Router Overview

“Switch Fabric and

“AC a n d DC Power

1-2

Cisco XR 12410 Router Installation Guide

OL-13832-01

Chapter 1 Cisco XR 12410 Router Overview

Physical and Functional Description of Router

Figure 1-1 Cisco XR 12410 Router Components—Front View

Blower module

Alarm display

Horizontal cable

management bracket

Line card and RP card cage

A C

IV C A

R R X

A C

IV C A

R R X

A C

IV C A

R R X

A C

IV C A

R R X

Q OC-3/STM-POS

ALA

A C

T IV

K T

A C

T IV

K T

A C

T IV

K T

A C

T IV

K T

Q OC-3/STM-POS

ARM

DOWN

LOOP RA LA

DOWN

LOOP RA LA

CDHNT CD

12DS3–SMB P

6DS3–SMB P

R O

NABLE

A C I

E J

ACTIVE

CARRIER

RX PKT

OC-48/STM-16-SCPOS

A C

T IV

R R

R E L L

OC-12/STM-4 ATM

FAST ETERNET

-0

R E

NSO

L IN

I I

ROUTE PROCESSOR

E C

-1

O L

-4 5

Air filter door

(switch fabric

and alarm

card cage

behind filter)

Power supplies

OL-13832-01

52636

A and B

Figure 1-2 shows the slot numbering layout of the router with the location of the

major components. Power is distributed to these components over the chassis backplane (not shown).

Cisco XR 12410 Router Installation Guide

1-3

Physical and Functional Description of Router

Figure 1-2 Router Components and Slot-Numbering

Chapter 1 Cisco XR 12410 Router Overview

I N E

1-4

Blower module

Alarm display

I N E

Cisco XR 12410 Router Installation Guide

OL-13832-01

Chapter 1 Cisco XR 12410 Router Overview

AC and DC Power Subsystems

A router ships as either an AC or DC powered system. Source power connects to power distribution units (PDUs) on the back of the chassis which route power to the power supplies, also referred to as power entry modules (PEMs).

Caution To ensure that the chassis configuration complies with the required power

budgets, use the on-line power calculator. Failure to properly verify the configuration may result in an unpredictable state if one of the power units fails. Contact your local sales representative for assistance.

AC Power Entry Modules

An AC powered router consists of two AC PDUs and AC PEMs. AC power to the router is provided through power cords connected from AC power outlets to the PDUs on the chassis rear panel as shown in

Figure 1-3 AC PDU Connection

Physical and Functional Description of Router

Figure 1-3.

OL-13832-01

52645

Cisco XR 12410 Router Installation Guide

1-5

Physical and Functional Description of Router

Each AC PEM converts 200 to 240 VAC into -48 VDC, which is distributed through the chassis backplane to all cards, RPs, and the blower module.

Figure 1-4 identifies the components of an AC PEM.

Figure 1-4 AC PEM Components

PWR OK

FAULT

TEMP

Chapter 1 Cisco XR 12410 Router Overview

ILIM

93040

1 Status indicators 3 Ejector lever

2 Handle 4 Power On/Off switch (shown in the ON/1 position)

1-6

Cisco XR 12410 Router Installation Guide

OL-13832-01

Chapter 1 Cisco XR 12410 Router Overview

129277

DC Power Supplies

A DC powered router consists of two DC PDUs and DC PEMs. DC power to the router is provided from cables from a DC power source that are connected to threaded DC-input terminal studs on the chassis rear panel as shown in

Figure 1-5 DC Power Cables—2800 W DC PDU

Physical and Functional Description of Router

Figure 1-5.

– 48/60V RTN

(+)

– 48/60V (–)

Feed A2

OL-13832-01

– 48/60V (–)

-48/-60V

-40A MAX (2x)

–

-48/-60V

-40A MAX (2x)

–

– 48/60V RTN

(+)

Feed A1

Each DC PEM operates from a nominal source DC voltage of –48 to –60 VDC and requires a dedicated 60-amp service.

Cisco XR 12410 Router Installation Guide

Ground

1-7

Physical and Functional Description of Router

Figure 1-6 identifies the components of a DC power supply.

Figure 1-6 2800 Watt DC PEM Components

F1LO

F2LO

RPF1

RPF2

FAIL

INOK

DCOK

Chapter 1 Cisco XR 12410 Router Overview

F1LO

F2LO

RPF1

RPF2

FAIL

INOK

DCOK

1 Power on/off switch 3 Handle

2 Status indicators 4 Ejector lever

129275

1-8

Cisco XR 12410 Router Installation Guide

OL-13832-01

Chapter 1 Cisco XR 12410 Router Overview

Switch Fabric and Alarm Card Overview

The switch fabric provides synchronized gigabit-speed connections between line cards and the route processor. The 9-slot switch fabric and alarm card cage contain:

• 2 clock scheduler cards (CSCs)

• 5 switch fabric cards (SFCs)

• 2 alarm cards

Note The two alarm cards that are located in the switch fabric and alarm card

cage are not part of the switch fabric.

One CSC and four SFCs are required for an active switch fabric; the second CSC and the fifth SFC provide redundancy. The combination of CSCs and SFCs make up the 10-Gbps per-slot switch fabric.

Each SFC or CSC provides a 10-Gbps full-duplex connection to each line card in the system. For example, in a Cisco XR 12410 router with 8 line cards, each with 2 x 10

Gbps capacity (full duplex), the system switching bandwidth is 8 x 20 Gbps

= 160 Gbps.

OL-13832-01

Figure 1-2 shows the slot configuration in the switch fabric and alarm card cage.

The labeling identifies the type of card for each slot and can only be seen when the air filter door is opened.

Note Cisco XR 12410 router support online insertion and removal (OIR), which allows

you to remove and replace a card while the router remains powered on.

Cisco XR 12410 Router Installation Guide

1-9

Switch Fabric and Alarm Card Overview

Switch Fabric Card Functionality

Routers ship from the factory with 2 CSCs and 5 SFCs installed in the 7 slots in the switch fabric and alarm card cage (see

• CSCs are installed in slot 0 (CSC0) or slot 1 (CSC1).

• SFCs are installed in slot 2 (SFC0), slot 3 (SFC1), slot 4 (SFC2),

slot

5 (SFC3), and slot 6 (SFC4).

Note The enhanced version of the CSC and SFC cards is required for support of BITS,

Single Router APS and Dual Priority features. The enhanced version of the cards cannot be mixed with the original version fabric cards.

Clock Scheduler Card

Clock scheduler cards provide the following functionality:

• Scheduler—Handles all scheduling requests from the line cards for access to

the switch fabric.

Chapter 1 Cisco XR 12410 Router Overview

Figure 1-2).

1-10

• System clock—Supplies the synchronizing signal to all SFCs, line cards, and

the RP. The system clock synchronizes data transfers between line cards or between line cards and the RP through the switch fabric.

• Switch fabric—Carries user traffic between line cards or between the RP and

a line card. The switch fabric on the CSC is identical to the switch fabric on the SFC.

The second CSC provides redundancy for the data path, scheduler, and reference clock. Traffic between the line cards and the switch fabric is monitored constantly. If the system detects a loss of synchronization (LOS), it automatically activates the data paths on the redundant CSC so data flows across the redundant paths. The switch to the redundant CSC occurs within sub-seconds (the actual switch time depends on your configuration and its scale).

Cisco XR 12410 Router Installation Guide

OL-13832-01

Chapter 1 Cisco XR 12410 Router Overview

Switch Fabric Card

The switch fabric cards augment the traffic capacity of the router. SFCs contain switch fabric circuitry that can only carry user traffic between line cards or between the RP and the line cards. SFCs receive all scheduling information and the system clock signal from the CSCs.

Alarm Cards and Alarm Display

The two alarm cards (in the switch fabric and alarm card cage) provide several functions:

• Supply +5 VDC to the MBus modules on router components (see AC and DC

Power Subsystems, page 1-5).

• Work in conjunction with the alarm display to monitor the system. The alarm

display (sometimes referred to as the alarm display card) is above the horizontal cable management bracket (

Switch Fabric and Alarm Card Overview

Figure 1-7).

OL-13832-01

Cisco XR 12410 Router Installation Guide

1-11

Switch Fabric and Alarm Card Overview

Figure 1-7 Alarm Display Location

A C

X P

A C

X P

A C

X P

A C

X P

Q OC-3/STM-POS

Alarm display

R T

M B

DOWN

LOOP RA LA

DOWN

LOOP RA LA

CDHNT CD

12DS3–SMB P

6DS3–SMB P

Chapter 1 Cisco XR 12410 Router Overview

BUS

FAIL

ENABL

ACT

CARR

IER R X PK

OC-48/STM-16-SCPOS

1 0

E J

-0

A C

T IV

R R

R E L

OC-12/STM-4 ATM

FAST ETERNET

-1

R E

E T

NSO

NSOLE

L IN

R X

-4 J

4 5

ROUTE PROCESSOR

A C

I T I R

1-12

53369

Cisco XR 12410 Router Installation Guide

OL-13832-01

Chapter 1 Cisco XR 12410 Router Overview

The following connectors and LEDs are on the front panel of the alarm display (

Figure 1-8):

Figure 1-8 Alarm Display

ALARM A

ALARM B

• Cable connections for the two alarm cards (labeled Alarm A and Alarm B)

• Critical, Major, and Minor LEDs that identify system level alarm conditions

• A pair of status LEDs that correspond to each of the 9 card slots in the switch

fabric and alarm card cage (seven fabric cards and two alarm cards):

–

ENABLED (green) On—The card installed in that slot is operational and functioning properly. Off—Either the slot is empty or the card installed in that slot is faulty.

–

FAIL (yellow)—The card in that slot is faulty.

Line Card and Route Processor Overview

MBUS

CSC

SFC

FAIL

ENABLE

53368

Line Card and Route Processor Overview

The line card and route processor (RP) card cage has 10 user-configurable slots that support a combination of line cards and either one or two RPs (see

Figure 1-2). Router configurations can consist of either nine line cards and one

RP, or eight line cards and two RPs (one primary and one redundant) using the following slot configurations:

• Slots 0 to 7 accommodate the newer (wider) line card designs. These wider

line card slots can also accept narrower legacy line cards.

• Slots 8 and 9 only accept RPs or a narrower legacy line card.

Note If a system uses only one RP install it in slot 9. You can use slot 8 for a

legacy line card.

Cisco XR 12410 Router Installation Guide

OL-13832-01

1-13

Line Card and Route Processor Overview

Line Cards

Ports and connectors on the line card front panels provide interfaces for external connections. Line cards communicate with the RP and exchange packet data with each other through the switch fabric cards.

Caution Any unoccupied card slot in the line card and RP card cage must have a blank

filler panel installed to meet electromagnetic compatibility (EMC) requirements and to ensure proper air flow through the chassis. Also, if the front panel of a line card does not completely fill the card slot opening, a narrow card filler panel must be installed to meet the EMC requirements.

A cable management bracket on the front panel of each line card helps to organize the interface cables connected to that line card.

The following line cards, SIPs, and SPAs are supported on the Cisco XR 12410 router:

Chapter 1 Cisco XR 12410 Router Overview

–

The Cisco XR 12410 router supports online insertion and removal (OIR), allowing you to remove and replace a card while the router remains powered on.

Note Refer to the current s software release notes for the most up-to-date list of

supported line cards (see

Security Guidelines” section on page -xiv).

Route Processor

The route processor for the Cisco XR 12410 router is the Performance Route Processor (PRP-2). For detailed information about the Performance Route Processor, refer to the Cisco document, Performance Route Processor Installation and Configuration Guide.

Cisco XR 12410 Router Installation Guide

1-14

“Obtaining Documentation, Obtaining Support, and

OL-13832-01

Chapter 1 Cisco XR 12410 Router Overview

The PRP-2 performs the following primary functions:

• Executes routing protocol stacks

• Performs all protocol communications with other routers

• Builds and distributes forwarding information to all line cards

• Uploads the operating system software images to all installed line cards

during power-up

• Provides out-of-band system console and auxiliary ports and an Ethernet port

for router configuration and maintenance

• Monitors and manages the power and temperature of system components

such as line cards, power supplies, and fans

The Cisco PRP-2 delivers all these functions with enhanced performance and capabilities. It also delivers the following feature enhancements (depending on the software version running):

• Gigabit Ethernet management port

• Hard-drive support (optional part)

• BITS input ports

• 1 GB compact image Flash memory support (optional part)

Line Card and Route Processor Overview

OL-13832-01

• Memory scalability up to 4 GB

The PRP-2 communicates with the line cards either through the switch fabric or through the MBus. The switch fabric connection is the main data path for routing table distribution as well as for packets that are sent between the line cards and the PRP-2. The MBus connection allows the PRP-2 to download a system bootstrap image, collect or load diagnostic information, and perform general, internal system maintenance operations.

The PRP-2 can be designated as either the Designated System Controller (DSC) or the Secure Domain router (SDR).

The Designated System Controller (DSC) performs the following functions:

• Implements control plane operations for the chassis

• Monitors temperature and voltage

• Monitors line cards

• On boot up, the first card to become active is designated as the DSC.

Cisco XR 12410 Router Installation Guide

1-15

Line Card and Route Processor Overview

The Secure Domain Router (SDR) controls domain security features independent of any other SDRs on the network.

Performance Route Processor Overview

The performance route processor (PRP) uses a Motorola PowerPC 7450 CPU that runs at an external bus clock speed of 133 MHz and has an internal clock speed of 667 MHz.

Figure 1-9 identifies the slots, ports, and LEDs on the PRP front panel.

Figure 1-9 Performance Route Processor Front Panel

Chapter 1 Cisco XR 12410 Router Overview

EJECT

ETH 1ETH 0 AUX

SLOT-1

SLOT-0

PRIMARY

LINK

CONSOLE

RESET

PERFORMANCE ROUTE PROCESSOR 1 (PRP-1)

1 3 4 52 6

1 PCMCIA flash disk slots (shown with cover in

4 Console serial port

place) and slot LEDs

2 RJ-45 Ethernet ports and data status LEDs 5 Reset button

3 Auxiliary serial port 6 Alphanumeric message displays

PRP PCMCIA Card Slots and Status LEDs

Two PCMCIA card slots (slot 0 and slot 1) provide the PRP with additional flash memory capacity. All combinations of different flash devices are supported by the PRP. You can use ATA flash disks, Type 1 or Type 2 linear flash memory cards, or a combination of the two.

Note The PRP only supports +5.2 VDC flash memory devices. It does not support

+3.3 VDC PCMCIA devices.

Status LEDs (Slot-0 / Slot-1) indicate when the flash memory card in that slot is accessed (see to remove a flash card from the slot.

Figure 1-9). Each slot has an eject button (located behind the cover)

129307

1-16

Cisco XR 12410 Router Installation Guide

OL-13832-01
