Cisco UCS C220 M3
High-Density Rack Server
(Small Form Factor Disk
Drive Model)
CISCO SYSTEMS PUBLICATION HISTORY
170 W
EST TASMAN DR
S
AN JOSE, CA, 95134 REV A.16 OCTOBER 9, 2012
WWW.CISCO.COM
CONTENTS
OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
DETAILED VIEWS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chassis Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Chassis Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
BASE SERVER STANDARD CAPABILITIES and FEATURES . . . . . . . . . . . . . . . . . 6
CONFIGURING the SERVER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
STEP 1 VERIFY SERVER SKU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
STEP 2 SELECT CPU(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
STEP 3 SELECT MEMORY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
STEP 4 SELECT RAID CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
STEP 5 SELECT HARD DISK DRIVES (HDDs) or SOLID STATE DRIVES (SSDs) . . . . . . . . . . . . . 22
STEP 6 SELECT PCIe OPTION CARD(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
STEP 7 ORDER OPTIONAL NETWORK CARD ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . 26
STEP 8 ORDER POWER SUPPLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
STEP 9 SELECT AC POWER CORD(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
STEP 10 ORDER OPTIONAL REVERSIBLE CABLE MANAGEMENT ARM . . . . . . . . . . . . . . . . . 33
STEP 11 ORDER A TRUSTED PLATFORM MODULE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
STEP 12 ORDER CISCO FLEXIBLE FLASH SD CARD MODULE (OPTIONAL) . . . . . . . . . . . . . . . 35
STEP 13 ORDER OPTIONAL USB 2.0 DRIVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
STEP 14 SELECT OPERATING SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
STEP 15 SELECT OPERATING SYSTEM MEDIA KIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
STEP 16 SELECT OPTIONAL VALUE-ADDED SOFTWARE . . . . . . . . . . . . . . . . . . . . . . . . . 40
STEP 17 SELECT SERVICE and SUPPORT LEVEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
OPTIONAL STEP - ORDER RACK(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
OPTIONAL STEP - ORDER PDU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
SUPPLEMENTAL MATERIAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
CHASSIS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
CPUs and DIMMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Physical Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Memory Population Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Recommended Memory Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Supported DIMM Populations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Low-Voltage DIMM Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
RAID Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
RACKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
PDUs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
KVM CABLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Motherboard USB and SD Ports, and RAID Card Backup Location . . . . . . . . . . . . . . . . . . . .59
TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Power Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Compliance Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
2
OVERVIEW
Front View
Rear View
OVER VIEW
The Cisco® UCS C220 M3 rack server is designed for performance and density over a wide range of business
workloads from web serving to distributed database.
Building on the success of the Cisco UCS C200 M2 rack server, the enterprise-class UCS C220 M3 server
further extends the capabilities of Cisco’s Unified Computing System portfolio in a 1U form factor with the
addition of the Intel® E5-2600 series product family CPUs that deliver significant performance and
efficiency gains. In addition, the UCS C220 M3 server provides 16 DIMM slots, up to 8 drives and 2 x 1 GbE
LAN-on-motheroard (LOM) ports delivering outstanding levels of density and performance in a compact
package.
Figure 1 Cisco UCS C220 M3 High-Density SFF Rack Server
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
3
DETAILED VIEWS
HDD4 HDD5
HDD1
HDD6
HDD2
HDD7
HDD3
HDD8
8
9 10
1 3
4
5 7
6
2
331682
DETAILED VIEWS
Chassis Front View
Figure 2 shows the Cisco UCS C220 M3 High-Density SFF Rack Server.
Figure 2 Chassis Front View
1 Power button/power status LED 6 Power supply status LED
2 Identification button/LED 7 Network link activity LED
3 System status LED 8 Asset tag (serial number)
4 Fan status LED 9 KVM connector (used with KVM cable that
provides two USB, one VGA, and one serial
connector)
5 Temperature status LED 10 Drives (up to eight hot-swappable 2-5-inch
drives)
For more information about the KVM cable connection, see KVM CABLE, page 58.
4
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
DETAILED VIEWS
PSU1PSU1 PSU2PSU2PSU1 PSU2
PCIe2
PCIe1
4 5 6 98
2 31
7
331683
Chassis Rear View
Figure 3 shows the external features of the rear panel.
Figure 3 Chassis Rear View
1 Power supplies (up to two) 6 One 10/100/1000 Ethernet dedicated
management port
2 Slot 2: Low-profile PCIe slot on riser:
(half-height, half-length, x16 connector, x8
lane width)
3 Slot 1: Standard-profile PCIe slot on riser:
(full-height, half-length, x24 connector, x16
lane width)
4 VGA video connector 9 Rear Identification button/LED
5 Serial port (RJ-45 connector) - -
7 Dual 1-Gb Ethernet ports
(LAN1 and LAN2)
8 USB ports
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
5
BASE SERVER STANDARD CAPABILITIES and FEATURES
BASE SERVER STANDARD CAPABILITIES and FEATURES
Table 1 lists the capabilities and features of the base server. Details about how to configure the server for
a particular feature or capability (for example, number of processors, disk drives, or amount of memory)
are provided in
Table 1 Capabilities and Features
Capability/Feature Description
Chassis One rack unit (1RU) chassis
CPU One or two Intel® E5-2600 series processor family CPUs
Chipset Intel® C600 series chipset
Memory 16 slots for registered ECC DIMMs (RDIMMs) and load-reduced DIMMs
NIC Embedded dual-port Intel i350 PCIe-based Gigabit Ethernet controller,
CONFIGURING the SERVER, page 9.
(LRDIMMs)
supporting the following:
■ Pre-Execution Boot (PXE boot)
■ iSCSI boot
Expansion slots Two PCIe slots (on a riser card)
■ One full-height profile, half-length slot with x24 connector and x16 lane
■ One half-height profile, half-length slot with x16 connector and x8 lane
Internal storage devices Drives are installed into front-panel drive bays that provide hot-pluggable
access.
■ Small Form Factor (SFF) drives. Up to eight 2.5-inch SAS or SATA
hot-swappable hard disk drives (HDDs) or solid state drives (SSDs)
■ The server also contains one internal USB 2.0 port on the motherboard
that you can use with a USB thumb drive for additional storage
Cisco Flexible Flash
The server supports one internal Cisco Flexible Flash drive (SD card).
drives
■ The SD card is pre-loaded with four virtual drives. The four virtual drives
contain, respectively, the Cisco Server Configuration Utility, the Cisco
Host Upgrade Utility, the Cisco C-Series server drivers set, and a blank
virtual drive on which you can install an OS or a hypervisor
■ 4 GB is available for general use
Video The Emulex Pilot 3 Integrated Baseboard Management Controller provides
video:
■ Matrox G200e video controller
■ Integrated 2D graphics core with hardware acceleration
■ Supports all display resolutions up to 1920 x 1200 x 16 bpp resolution at
60 Hz
■ 24-bit color depth for all resolutions less than 1600x1200
■ Up to 256 MB video memory
6
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
Capability/Feature Description
Storage controller ■ Embedded RAID (3 Gbs)
• Embedded SATA-only RAID controller, supporting up to 4 SATA-only
drives (RAID 0, 1, 10)
• ROM5 embedded RAID upgrade, supporting up to 8 SAS/SATA drives
(RAID 0, 1, 10). SAS and SATA drives can be mixed.
• ROM55 embedded RAID upgrade, supporting up to 8 SAS/SATA drives
(RAID 0, 1, 10, 5). SAS and SATA drives can be mixed.
■ 2008M-8i Mezzanine Cards (6 Gbs) - two versions
• Cisco UCSC RAID SAS 2008M-8i Mezzanine Card, supporting up to 8
SAS/SATA drives supporting RAID 0, 1, 10, 5, and 50. SAS and SATA
drives can be mixed. This card has a product ID (PID) of
UCSC-RAID-11-C220.
• Cisco UCSC RAID SAS 2008M-8i Mezzanine Card, supporting up to
eight SAS/SATA drives supporting RAID 0, 1, and 10. SAS and SATA
drives can be mixed. This card has a product ID (PID) of
UCSC-RAID-MZ-220.
■ Plug-in PCIe Cards (6 Gbs)
• LSI MegaRAID SAS 9266-8i 8-port plug-in PCIe RAID RAID controller
card (occupies a half-height PCIe slot), supporting RAID levels 0, 1,
10, 5, 6, 50, 60 and up to 8 internal SAS or SATA drives. SAS and SATA
drives can be mixed.
• LSI MegaRAID SAS 9266CV-8i RAID 8-port PCIe plug-in RAID controller
card, supporting RAID 0, 1, 10, 5, 6, 50, and 60 and up to eight
internal SAS or SATA drives. SAS and SATA drives can be mixed.
BASE SERVER STANDARD CAPABILITIES and FEATURES
Interfaces ■ Rear panel
• One RJ45 serial port connector
• Two USB 2.0 port connectors
• One DB15 VGA connector
• Two RJ-45 10/100/1000 Ethernet port connectors
• One RJ-45 10/100/1000 Ethernet management port, using Cisco
Integrated Management Controller (CIMC) firmware
■ Various PCIe card ports (dependent on which cards are installed)
• Converged Network Adapter (CNA) ports
• Network Interface Card (NIC) ports
• Host Bus Adapter (HBA) ports
■ Front panel
• One KVM console connector (supplies two USB, one VGA, and one
serial connector)
Front Panel A front panel controller provides status indications and control buttons
Power subsystem Up to two 450 W 650 W power supplies. One is mandatory; one more can be
added for 1 + 1 redundancy.
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
7
BASE SERVER STANDARD CAPABILITIES and FEATURES
Capability/Feature Description
Fans Chassis:
■ Five hot-swappable fans for front-to-rear cooling
Power supply:
■ Each power supply is equipped with a fan.
Integrated management
processor
Cisco Integrated Management Controller (CIMC) firmware.
Depending on your CIMC settings, the CIMC can be accessed through the 1-Gb
Ethernet dedicated management port, the 1-Gb Ethernet LOM ports, or a
Cisco P81E or Cisco 1225 virtual interface card (VIC).
8
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
CONFIGURING the SER VER
Follow these steps to configure the Cisco UCS C220 M3 High-Density SFF Rack Server:
■ STEP 1 VERIFY SERVER SKU, page 10
■ STEP 2 SELECT CPU(s), page 11
■ STEP 3 SELECT MEMORY, page 13
■ STEP 4 SELECT RAID CONFIGURATION, page 18
■ STEP 5 SELECT HARD DISK DRIVES (HDDs) or SOLID STATE DRIVES (SSDs), page 22
■ STEP 6 SELECT PCIe OPTION CARD(s), page 24
■ STEP 7 ORDER OPTIONAL NETWORK CARD ACCESSORIES, page 26
■ STEP 8 ORDER POWER SUPPLY, page 29
■ STEP 9 SELECT AC POWER CORD(s), page 30
■ STEP 10 ORDER OPTIONAL REVERSIBLE CABLE MANAGEMENT ARM, page 33
■ STEP 11 ORDER A TRUSTED PLATFORM MODULE, page 34
■ STEP 12 ORDER CISCO FLEXIBLE FLASH SD CARD MODULE (OPTIONAL), page 35
CONFIGURING the SERVER
■ STEP 13 ORDER OPTIONAL USB 2.0 DRIVE, page 36
■ STEP 14 SELECT OPERATING SYSTEM, page 37
■ STEP 15 SELECT OPERATING SYSTEM MEDIA KIT, page 39
■ STEP 16 SELECT OPTIONAL VALUE-ADDED SOFTWARE, page 40
■ STEP 17 SELECT SERVICE and SUPPORT LEVEL, page 41
■ OPTIONAL STEP - ORDER RACK(s), page 45
■ OPTIONAL STEP - ORDER PDU, page 46
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
9
CONFIGURING the SERVER
STEP 1 VERIFY SERVER SKU
Verify the product ID (PID) of the server as shown in Table 2.
Table 2 PID of the C220 M3 High-Density SFF Rack Base Server
Product ID (PID) Description
UCSC-C220-M3S UCS C220 M3 SFF, no CPU, memory, HDD, SDD, power supply, SD card, or PCIe
cards, with 1 rail kit
The Cisco C220 M3 server:
■ Includes one tool-less rail kit
■ Does not include power supply, CPU, memory, hard disk drives (HDDs), solid-state drives
(SSDs), SD card, or plug-in PCIe cards.
NOTE: Use the steps on the following pages to configure the server with
the components that you want to include.
10
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
STEP 2 SELECT CPU(s)
Notes . . .
The standard CPU features are:
■ Intel E5-2600 series processor family CPUs
■ Intel C600 series chipset
■ Cache size of 10, 15, or 20 MB
Select CPUs
The available CPUs are listed in Table 3.
Table 3 Available Intel CPUs: E5-2600 Series Processor Family CPUs
CONFIGURING the SERVER
Highest DDR3
DIMM Clock
Support (MHz)
Product ID (PID)
Intel
Number
Clock
Freq
(GHz)
Power
(W)
Cache
Size
(MB)
Cores QPI
UCS-CPU-E5-2690 E5-2690 2.90 135 20 8 8 GT/s 1600
UCS-CPU-E5-2680 E5-2680 2.70 130 20 8 8 GT/s 1600
UCS-CPU-E5-2667 E5-2667 2.90 130 15 6 8 GT/s 1600
UCS-CPU-E5-2665 E5-2665 2.40 115 20 8 8 GT/s 1600
UCS-CPU-E5-2660 E5-2660 2.20 95 20 8 8 GT/s 1600
UCS-CPU-E5-2650 E5-2650 2.00 95 20 8 8 GT/s 1600
UCS-CPU-E5-2650L E5-2650L 1.80 70 20 8 8 GT/s 1600
UCS-CPU-E5-2643 E5-2643 3.30 130 10 4 8 GT/s 1600
UCS-CPU-E5-2640 E5-2640 2.50 95 15 6 7.2 GT/s 1333
UCS-CPU-E5-2630 E5-2630 2.30 95 15 6 7.2 GT/s 1333
UCS-CPU-E5-2630L E5-2630L 2.00 60 15 6 7.2 GT/s 1333
UCS-CPU-E5-2620 E5-2620 2.00 95 15 6 7.2 GT/s 1333
UCS-CPU-E5-2609 E5-2609 2.40 80 10 4 6.4 GT/s 1066
1
1. If higher or lower speed DIMMs are selected than what is shown in the table for a given CPU, the DIMMs will be
clocked at the lowest common denominator of CPU clock and DIMM clock.
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
11
CONFIGURING the SERVER
Approved Configurations
(1) 1-CPU configurations:
■ Select any one CPU listed in Table 3.
(2) 2-CPU Configurations:
■ Select two identical CPUs from any one of the rows of Table 3 on page 11.
Caveats
■ You can select either one processor or two identical processors.
■ For optimal performance, select DIMMs with the highest clock speed for a given processor
(see
Table 3 on page 11). If you select DIMMs whose speeds are lower or higher than that
shown in the tables, suboptimal performance will result.
12
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
STEP 3 SELECT MEMORY
The standard memory features are:
■ DIMMs
— Clock speed: 1333 or 1600 MHz
— Ranks per DIMM: 1, 2, or 4
— Operational voltage: dual voltage capable (1.5 V or 1.35 V)
— Registered ECC DDR3 DIMMS (RDIMMS) or load-reduced DIMMS (LRDIMMs)
■ Memory is organized with four memory channels per CPU, with up to two DIMMs per channel,
as shown in
Figure 4 C220 M3 SFF Memory Organization
Figure 4.
CONFIGURING the SERVER
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
13
CONFIGURING the SERVER
Select DIMMs and Memory Mirroring
Select the memory configuration and whether or not you want the memory mirroring option.
The available memory DIMMs and mirroring option are listed in
NOTE: When memory mirroring is enabled, the memory subsystem simultaneously
writes identical data to two channels. If a memory read from one of the channels
returns incorrect data due to an uncorrectable memory error, the system
automatically retrieves the data from the other channel. A transient or soft error in
one channel does not affect the mirrored data, and operation continues unless there
is a simultaneous error in exactly the same location on a DIMM and its mirrored
DIMM. Memory mirroring reduces the amount of memory available to the operating
system by 50% because only one of the two populated channels provides data.
Table 4 Available DDR3 DIMMs
Table 4.
Product ID (PID) PID Description Voltage
DIMM Options
UCS-ML-1X324RY-A 32GB DDR3-1600-MHz LR DIMM/PC3-12800/quad rank/x4/1.35v 1.35 V 4
UCS-MR-1X162RY-A 16GB DDR3-1600-MHz RDIMM/PC3-12800/dual rank/x4/1.35v 1.35 V 2
UCS-MR-1X162RX-A 16GB DDR3-1333-MHz RDIMM/PC3-10600/dual rank/x4/1.35v 1.35 V 2
UCS-MR-1X082RY-A 8GB DDR3-1600-MHz RDIMM/PC3-12800/dual rank/x4/1.35v 1.35 V 2
UCS-MR-1X082RX-A 8GB DDR3-1333-MHz RDIMM/PC3-10600/dual rank/x4/1.35v 1.35 V 2
UCS-MR-1X041RY-A 4GB DDR3-1600-MHz RDIMM/PC3-12800/single rank/x4/1.35v 1.35 V 1
UCS-MR-1X041RX-A 4GB DDR3-1333-MHz RDIMM/PC3-10600/single rank/x4/1.35v 1.35 V 1
Memory Mirroring Option
N01-MMIRROR Memory mirroring option
Ranks/
DIMM
14
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
CONFIGURING the SERVER
Approved Configurations
(1) 1-CPU configuration without memory mirroring:
■ Select from 1 to 8 DIMMs. Refer to Memory Population Rules, page 50, for more detailed
information.
(2) 1-CPU configuration with memory mirroring:
■ Select 2, 4, 6, or 8 identical DIMMs. The DIMMs will be placed by the factory as shown in the
following table.
Total
Number
CPU 1 DIMM Placement in Channels
(for
identical DIMMs)
of
DIMMs
Blue Slots Black Slots
2 (A1, B1)
4 (A1,B1); (C1,D1)
6 (A1,B1); (C1,D1) (A2,B2)
8 (A1,B1); (C1,D1) (A2,B2); (C2,D2)
■ Select the memory mirroring option (N01-MMIRROR) as shown in Table 4 on page 14.
(3) 2-CPU configuration without memory mirroring:
■ Select from 1 to 8 DIMMs per CPU. Refer to Memory Population Rules, page 50, for more
detailed information.
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
15
CONFIGURING the SERVER
(4) 2-CPU configuration with memory mirroring:
■ Select 2, 4, 6, or 8 identical DIMMs per CPU. The DIMMs will be placed by the factory as
shown in the following table.
Number
of
CPU 1 DIMM Placement in Channels
(for
identical dual-rank DIMMs)
CPU 2 DIMM Placement in Channels
(for
identical dual-rank DIMMs)
DIMMs
per CPU
Blue Slots Black Slots Blue Slots Black Slots
2 (A1, B1) (E1, F1)
4 (A1,B1); (C1,D1) (E1,F1); (G1,H1)
6 (A1,B1); (C1,D1) (A2,B2) (E1,F1); (G1,H1) (E2,F2)
8 (A1,B1); (C1,D1) (A2,B2); (C2,D2) (E1,F1); (G1,H1) (E2,F2); (G2,H2)
■ Select the memory mirroring option (N01-MMIRROR) as shown in Table 4 on page 14.
NOTE: System performance is optimized when the DIMM type and quantity are equal
for both CPUs.
16
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
CONFIGURING the SERVER
Caveats
■ The server supports registered DIMMs (RDIMMs) or load-reduced DIMMS (LRDIMMs), however,
do not mix RDIMMs and LRDIMMs in a server.
■ When using mirroring, DIMMs must be installed in identical pairs across paired DDR3 buses.
That is, mirrored pairs in channels A and B must be identical and pairs in channels C and D
must be identical. However, the DIMMs used in channels A and B and in C and D can be
different.
■ UDIMMs and non-ECC DIMMs are not supported.
■ Memory mirroring reduces the amount of available memory by 50% (quantity of DIMMs must
be even for mirroring).
■ When single- and dual-rank DIMMs are populated for 2DPC, always populate the dual rank
DIMM in the blue DIMM slot, and the single-rank DIMM in the black DIMM slot (only the 4GB
DIMMs are single-rank).
■ By default, all DIMMs run at 1.35 V, which yields 1333-MHz memory speeds. To run the
memory DIMMS at 1600 MHz, you need to go into the BIOS or set the policy with UCSM
(service profile) to run in Performance Mode. This forces the DIMMs to operate at 1.5 V and
yields 1600-MHz speeds, provided:
— The DIMMs are 1600-MHz devices
— The CPUs chosen support 1600-MHz operation.
For more information regarding memory, see CPUs and DIMMs, page 48.
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
17
CONFIGURING the SERVER
STEP 4 SELECT RAID CONFIGURATION
The RAID controller choices are:
■ Embedded RAID (on motherboard)
NOTE: If you do not select a mezzanine card, a plug-in PCIe RAID card, or one of the
embedded RAID upgrade options, you will have an embedded SATA-only RAID
controller that supports up to four SATA-only drives (RAID 0, 1, 10)
■ Mezzanine RAID controller cards
■ Plug-in PCIe RAID controller cards
Cisco can provide factory-configured RAID systems depending on the RAID controller chosen and
the number of drives ordered. Factory-configured RAID options are listed with each RAID card
description.
NOTE: The number of RAID groups (logical drives/ virtual drives) supported per
controller is as follows:
■ Embedded RAID = 8 drives
■ Cisco UCSC RAID SAS 2008M-8i Mezzanine Card = 16 drives
■ LSI MegaRAID SAS 9266-8i RAID controller card = 64 drives
Select RAID Options
Select as follows:
■ One embedded RAID upgrade option (see Table 5), or
■ One mezzanine RAID controller (see Table 6), or
■ One PCIe RAID controller card (see Table 7 on page 19)
Table 5 Available Embedded RAID Options
Product ID (PID) PID Description
RAID Controllers
UCSC-RAID-ROM5 Onboard RAID, supporting up to 8 SAS or SATA drives. SAS and SATA drives can
be mixed. This option supports RAID 0, 1, and 10, and operates at 3 Gb/s.
Operating systems supported are Windows and Linux only (no VMware
support).
UCSC-RAID-ROM55 Onboard RAID, supporting up to 8 SAS or SATA drives. SAS and SATA drives can
be mixed. This option supports RAID 0, 1, 10, and 5, and operates at 3 Gb/s.
Operating systems supported are Windows and Linux only (no VMware
support).
18
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
CONFIGURING the SERVER
Table 6 Available Mezzanine Card RAID Options
Product ID (PID) PID Description
RAID Controllers
UCSC-RAID-11-C220 Cisco UCSC RAID SAS 2008M-8i Mezzanine Card (RAID 0, 1, 10, 5, and 50
supported), operating at 6 Gbs.
■ Supports up to eight internal SAS or SATA drives. SAS and SATA drives can
be mixed.
■ Factory-configured RAID options available: RAID 0, 1, 10, and 5 (see the
RAID PIDs section in this table)
■ No data cache backup
UCSC-RAID-MZ-220 Cisco UCSC RAID SAS 2008M-8i Mezzanine Card (RAID 0, 1, 10 supported),
operating at 6 Gbs.
■ Supports up to eight internal SAS or SATA drives. SAS and SATA drives can
be mixed.
■ Factory-configured RAID options available: RAID 0, 1, and 10 (see the RAID
PIDs section in this table)
■ No data cache backup
Table 7 Available Plug-In PCIe Card RAID Options
Product ID (PID) PID Description
RAID Controllers
UCS-RAID-9266NB LSI MegaRAID SAS 9266-8i RAID controller card with no data cache backup
(RAID 0, 1, 10, 5, 6, 50, and 60 supported), operating at 6 Gbs.
■ Supports up to eight internal SAS and/or SATA drives. SAS and SATA drives
can be mixed.
■ Includes 1 GB of write cache
■ Factory-configured RAID options available: RAID 0, 1, 10 , 5, and 6 (see the
RAID PIDs section in this table)
UCS-RAID-9266CV LSI MegaRAID SAS 9266CV-8i RAID controller card with data cache backup (RAID
0, 1, 10, 5, 6, 50, 60), operating at 6 Gbs.
■ Supports up to eight internal SAS or SATA drives. SAS and SATA drives can
be mixed.
■ Includes a 1 GB Transportable Memory Module (TMM) and SuperCap power
module for data cache backup
■ Factory-configured RAID options available: RAID 0, 1, 10 , 5, and 6 (see the
RAID PIDs section in this table)
Super Capacitor Option
UCS-RAID-CV-SC= LSI CacheVault Power Module for SAS 9266CV
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
19
CONFIGURING the SERVER
Table 7 Available Plug-In PCIe Card RAID Options (continued)
Product ID (PID) PID Description
RAID Configuration Options
R2XX-RAID0 Factory preconfigured RAID striping option
Enable RAID 0 Setting. Requires a minimum of one hard drive.
R2XX-RAID1 Factory preconfigured RAID mirroring option
Enable RAID 1 Setting. Requires exactly two drives with the same size, speed,
capacity.
R2XX-RAID5 Factory preconfigured RAID option
Enable RAID 5 Setting. Requires a minimum of three drives of the same size,
speed, capacity.
R2XX-RAID6 Factory preconfigured RAID option
Enable RAID 6 Setting. Requires a minimum of four drives of the same size,
speed, capacity.
R2XX-RAID10 Factory preconfigured RAID option
Enable RAID 10 Setting. Requires a even number of drives (minimum of four
drives) of the same size, speed, capacity.
NOTE: Although RAID levels 50 and 60 are not orderable from the factory, they are
supported for selected controllers as shown in Table 5
NOTE: No RAID option can be chosen if you have no drives
20
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
CONFIGURING the SERVER
Approved Configurations
(1) 1-CPU Configurations
Mezzanine cards are not supported for 1-CPU configurations, Therefore, only the following RAID
controllers are supported for single-CPU configurations:
■ Embedded RAID
■ LSI MegaRAID SAS 9266-8i
■ LSI MegaRAID SAS 9266CV-8i
(2) 2-CPU Configurations
Select an embedded RAID option from Table 5, one mezzanine RAID controller from Table 6 on
page 19, or one PCIe RAID controller from Table 7 on page 19. You may also select an
appropriate optional RAID configuration listed in Table 7 on page 19.
Caveats
■ The mezzanine controller is not available for 1-CPU configurations.
■ If you choose a mezzanine card RAID controller or onboard RAID, both the half-height and
full-height PCIe card slots are still available for adding optional PCIe cards.
■ The optional PCIe RAID controllers are all half-height PCIe cards. If you choose one of these
cards, only the full-height PCIe card slot will be available for adding an optional PCIe card.
■ Note that only a single Cisco VIC card (either the full-height Cisco UCS P81E or the
half-height Cisco VIC 1225 PCIe card) is supported and it must be installed in the full-height
PCIe slot (slot 1) on riser 1. So take this into account when populating RAID controller cards.
■ You can choose only one RAID controller (embedded RAID, plug-in PCIe RAID controller, or
mezzanine card RAID controller).
■ You can choose an optional RAID configuration (RAID 0, 1, 5, 6, or 10), which is
preconfigured at the factory. The RAID level you choose must be an available RAID choice for
the controller selected. RAID levels 50 and 60 are supported, although they are not available
as configuration options.
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
21
CONFIGURING the SERVER
STEP 5 SELECT HARD DISK DRIVES (HDDs) or SOLID STATE DRIVES
(SSDs)
The standard disk drive features are:
■ 2.5-inch small form factor
■ Hot-pluggable
■ Sled-mounted
Select Drives
The available drives are listed in Table 8.
Table 8 Available Hot-Pluggable Sled-Mounted HDDs and SSDs
Product ID (PID) PID Description
HDDs
A03-D1TBSATA 1TB SATA 7.2K RPM SFF HDD SATA 1 TB
UCS-HDD900GI2F106 900 GB 6Gb SAS 10K RPM SFF HDD SAS 900 GB
A03-D600GA2 600 GB 6Gb SAS 10K RPM SFF HDD SAS 600 GB
A03-D500GC3 500 GB SATA 7.2K RPM SFF HDD SATA 500 GB
UCS-HDD300GI2F105 300 GB 6Gb SAS 15K RPM SFF HDD SAS 300 GB
A03-D300GA2 300 GB 6Gb SAS 10K RPM SFF HDD SAS 300 GB
SSDs
UCS-SD300G0KA2-E 300GB Std Height 15mm SATA SSD SATA 300 GB
UCS-SD200G0KA2-E 200GB Std Height 15mm SATA SSD SATA 200 GB
UCS-SD100G0KA2-E 100GB Std Height 15mm SATA SSD SATA 100 GB
NOTE: No RAID option can be chosen if you have no drives
Drive
Type
Capacity
22
NOTE: No virtual drive groupings are allowed if you mix HDDs and SSDs.
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
CONFIGURING the SERVER
Approved Configurations
(1) Onboard RAID, Mezzanine Cards, and all Plug-In RAID Controllers
■ If you have not selected an onboard RAID upgrade option (ROM5 or ROM55), a mezzanine
card, or a plug-in RAID controller, you may select up to 4 SATA-only drives.
■ Otherwise, select up to eight SAS/SATA drives listed in Table 8. You can mix SAS and SATA
drives.
Caveats
■ You can mix SATA and SAS drives.
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
23
CONFIGURING the SERVER
STEP 6 SELECT PCIe OPTION CARD(s)
The standard PCie card offerings are:
■ Converged Network Adapters (CNAs)
■ Network Interface Cards (NICs)
■ Host Bus Adapters (HBAs)
Select PCIe Option Cards
The available PCIe option cards are listed in Table 9.
Table 9 Available PCIe Option Cards
Product ID (PID) PID Description
Card
Height
Converged Network Adapters (CNAs)
N2XX-ACPCI01 Cisco UCS P81E Virtual Interface Card (VIC)/ 2-port 10Gbps Full
UCSC-PCIE-BSFP Broadcom 57712 Dual Port 10Gb SFP+ w/TOE iSCSI Half
UCSC-PCIE-CSC-02 Cisco VIC 1225 Dual Port 10Gb SFP+ CNA Half
Network Interface Cards (NICs)
N2XX-ABPCI01-M3 Broadcom 5709 Dual Port 1Gb w/TOE iSCSI for M3 Servers Half
N2XX-ABPCI03-M3 Broadcom 5709 Quad Port 1Gb w/TOE iSCSI for M3 Servers Half
N2XX-AIPCI01 Intel X520 Dual Port 10Gb SFP+ Adapter Half
UCSC-PCIE-IRJ45 Intel i350 Quad Port 1Gb Adapter Half
UCSC-PCIE-BTG Broadcom 57712 Dual Port 10GBASE-T w/TOE iSCSI Half
Host Bus Adapters (HBAs)
N2XX-AEPCI03 Emulex LPe 11002 Dual Port 4Gb Fibre Channel HBA Half
N2XX-AEPCI05 Emulex LPe 12002 Dual Port 8Gb Fibre Channel HBA Half
N2XX-AQPCI03 Qlogic QLE2462 Dual Port 4Gb Fibre Channel HBA Half
N2XX-AQPCI05 Qlogic QLE2562 Dual Port 8Gb Fibre Channel HBA Half
24
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
CONFIGURING the SERVER
Approved Configurations
(1) No RAID controller plug-in card
■ If you did not choose a plug-in RAID controller (for example, you are using embedded RAID
or a mezzanine RAID controller), you can select up to two PCie option cards listed in
Table 9.
(2) One RAID controller plug-in card
■ If you selected a plug-in PCIe RAID controller, you can select only one of the optional PCIe
cards listed in
Table 9.
NOTE: If a plug-in RAID controller card is installed, any optional PCIe card yo u select
will be installed in the full-height slot. RAID controllers are always installed in the
half-height slot.
Caveats
■ For 1-CPU systems:
— Only the full-height PCIe slot (slot 1) is supported
— Neither PCIe slot 2 nor the mezzanine card slot are supported
— Only a single VIC card (either the full-height Cisco UCS P81E or the Cisco VIC 1225
PCIe card) is supported and it must be installed in slot 1 (the full-height slot).
■ For 2-CPU systems:
— Both PCIe slots and the mezzanine card slot are supported
— Only a single VIC card (either the full-height Cisco UCS P81E or the half-height Cisco
VIC 1225 PCIe card) is supported and it must be installed in slot 1 (the full height
slot).
■ All PCIe cards will fit in either slot, except the Cisco UCS P81E Virtual Interface Card (VIC),
which must be installed in the full-height slot (slot 1).
■ Other considerations for the Cisco VIC 1225:
— Supports 10G SFP+ optical and copper twinax connections
— R equires that the server has CIMC firmwar e version 1.4(6) or later installed. There is
a heartbeat LED on the top of the card that indicates when firmware is active.
— To use this card for UCS integration (Cisco UCS Manager mode) with Cisco UCS
Manager 2.1(0) or later, the minimum card-firmware and uboot image level is
2.1(0.306).
■ To help ensure that your operating system is compatible with the card you have selected,
check the Hardware Compatibility List at this URL:
http://www.cisco.com/en/US/products/ps10477/prod_technical_reference_list.html
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
25
CONFIGURING the SERVER
STEP 7 ORDER OPTIONAL NETWORK CARD ACCESSORIES
Copper twinax cables and SFP optical modules may be ordered to support the two-port network cards that
are available with the server.
Choose Optional Twinax Cables
Table 10 lists the copper twinax cables available for the PCIe cards. You can choose cable
lengths of 1, 3, 5, 7, or 10 meters. The two longer cables (7 and 10 meters) are active, which
means that they contain active components within the SFP+ housing to improve signal quality.
Table 10 Available Twinax Cables
Product ID (PID) PID Description
SFP-H10GB-CU1M 10GBASE-CU SFP+ Cable (1 M)
SFP-H10GB-CU3M 10GBASE-CU SFP+ Cable (3 M)
SFP-H10GB-CU5M 10GBASE-CU SFP+ Cable (5 M)
SFP-H10GB-ACU7M 10GBASE-CU SFP+ Cable (7 M)
SFP-H10GB-ACU10M 10GBASE-CU SFP+ Cable (10 M)
Approved Configurations
(1) Choose Up to Two Twinax Cables for Each Network Card Ordered
■ You may choose one or two twinax cables for each network card ordered. The cables can be
different lengths; however, you would normally order two cables of equal lengths to connect
to the primary and redundant network switching equipment.
Caveats
The twinax cables listed in Table 10 can be ordered only for the following PCIe cards:
— N2XX-ACPCI01 (Cisco UCS P81E Virtual Interface Card/ 2-port 10Gbps)
— UCS-PCIE-BSFP (Broadcom 57712)
— N2XX-AEPCI01 (Emulex OCe10102-F)
— N2XX-AIPCI01 (Intel Dual Port Ethernet X520)
26
— UCSC-PCIE-CSC-02 (Cisco VIC 1225 Dual Port 10Gb SFP+ CNA)
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
Choose Optional SFP Modules
Optical Cisco SFP+ modules are listed in Table 11.
Table 11 Available SFP Modules
Product ID (PID) PID Description
SFP-10G-SR 10GBASE-SR SFP+ Module
850 nm, multimode, SR, 3.3V, LC connector, with Digital Optical Monitoring
DS-SFP-FC8G-SW 8 Gbit SFP+ Module
850 nm, multimode, SR, 3.3V, LC connector, with Digital Optical Monitoring
Approved Configurations
(1) Choose Up to Two SFP+ Modules for Each Network Card Ordered
■ You may choose one or two SFP+ optical modules cables for each network card ordered. You
would normally order two modules for connecting to the primary and redundant network
switching equipment. With the SFP+ optical modules, you can use common fiber optic
cables, widely available.
CONFIGURING the SERVER
See Figure 5 on page 28 for typical SFP+ and twinax connections to the network cards.
Caveats
The SFP-10G-SR optical module listed in Table 11 should be ordered only for the following PCIe
cards, as they do not come by default with any optical modules:
— N2XX-ACPCI01 (Cisco UCS P81E Virtual Interface Card/ 2-port 10Gbps)
— UCSC-PCIE-BSFP (Broadcom 57712)
— N2XX-ABPCI02 (Broadcom 57711)
— N2XX-AEPCI01 (Emulex OCe10102-F)
— UCSC-PCIE-CSC-02 (Cisco VIC 1225 Dual Port 10Gb SFP+ CNA)
The DS-SFP-FC8G-SW optical module listed in Table 11 should be ordered only for the following
PCIe cards, as they do not come by default with any optical modules:
— N2XX-AEPCI05 (Emulex LPe 12002, 8Gb dual-port Fibre Channel HBA)
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
27
CONFIGURING the SERVER
Figure 5 Network Card Connections
28
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
STEP 8 ORDER POWER SUPPLY
The C220 M3 SFF server accommodates two power supplies. A lightly loaded server can operate
from one 650 W power supply . A fully loaded server might need to be powered with two 450 W or
two 650 W power supplies (see
determine the needed power based on the options chosen (CPUs, drives, memory, and so on):
https://express.salire.com/Go/Cisco/Cisco-UCS-Power-Calculator.aspx
Table 12 Power Supply PIDs
Product ID (PID) PID Description
UCSC-PSU-450W 450 W power supply
UCSC-PSU-650W 650 W power supply
NOTE: In a two power supply server, both power supplies must be identical.
Table 12). Use the power calculator at the following link to
CONFIGURING the SERVER
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
29
CONFIGURING the SERVER
1
Cordset rating 13A, 250V
(6.6 feet) (79±2m)
Plug:
EL312MoldedTwistlock
(NEMA L6-20)
186568
Connector:
EL 701
(IEC60320/C13)
STEP 9 SELECT AC POWER CORD(s)
Using Table 13, select the appropriate AC power cords. You can select a minimum of no power
cords and a maximum of two. If you select the option R2XX-DMYMPWRCORD, no power cord is
shipped with the server.
Table 13 Available Power Cords
Product ID (PID) PID Description Images
R2XX-DMYMPWRCORD No power cord (dummy PID to
allow for a no power cord option)
CAB-N5K6A-NA Power Cord, 200/240V 6A, North
America
CAB-AC-250V/13A Power Cord, NEMA L6-20 250V/20A
plug-IEC320/C13 receptacle, North
America,
CAB-C13-CBN CABASY,WIRE,JUMPER CORD, 27" L,
C13/C14, 10A/250V
CAB-C13-C14-2M CABASY,WIRE,JUMPER CORD, PWR,
2 Meter, C13/C14,10A/250V
Not applicable
Plug: NEMA 6-15P
Cordset rating: 10 A, 250 V
Length: 8.2 ft
Connector:
IEC60320/C13
86570
CAB-C13-C14-AC CORD,PWR,JMP,IEC60320/C14,IEC6
0320/C13, 3.0M
30
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
Table 13 Available Power Cords
2500 mm
Cordset rating: 10 A, 250/500 V MAX
Length: 8.2 ft
Plug:
EL 219
(IRAM 2073)
Connector:
EL 701
(IEC60320/C13)
Plug:
Cordset rating: 10 A, 250 V/500 V MAX
Length: 2500mm
Connector:
EL 701C
(EN 60320/C15)
EL 210
(BS 1363A) 13 AMP fuse
Cordset rating 10A, 250V
(2500 mm)
Plug:
EL 218
(CCEE GB2009)
186573
Connector:
EL 701
(IEC60320/C13)
Connector:
VSCC15
Cordset rating: 10A/16 A, 250 V
Length: 8 ft 2 in. (2.5 m)
Plug:
M2511
186576
1
Cordset rating 10A, 250V/500V MAX
(2500 mm)
Plug:
EL 212
(SI-32)
186574
Connector:
EL 701B
(IEC60320/C13)
EL
-212
16A
250V
Product ID (PID) PID Description Images
SFS-250V-10A-AR Power Cord, SFS, 250V, 10A,
Argentina
CAB-9K10A-AU Power Cord, 250V AC 10A 3112 Plug,
Australia
SFS-250V-10A-CN Power Cord, SFS, 250V, 10A, China
CONFIGURING the SERVER
CAB-250V-10A-CN AC Power Cord - 250V, 10A - PRC
CAB-9K10A-EU Power Cord, 250VAC 10A CEE 7/7
Plug, EU
SFS-250V-10A-ID Power Cord, SFS, 250V, 10A, India
SFS-250V-10A-IS Power Cord, SFS, 250V, 10A, Israel
Plug:
EL 208
Cordset rating 16A, 250V
(2500mm)
OVE
Connector:
EL 701
87490
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
31
CONFIGURING the SERVER
Plug:
I/3G
(CEI 23-16)
Connector
C15M
(EN60320/C15 )
Cordset rating: 10 A, 250 V
Length: 8 ft 2 in. (2.5 m)
186575
Plug:
MP232-R
Cordset rating: 10 A, 250 V
Length: 8 ft. 2 in (2.5 m)
Connector:
IEC 60320 C15
Plug:
Cordset rating: 10 A, 250 V/500 V MAX
Length: 2500mm
186580
Connector:
EL 701C
(EN 60320/C15)
EL 210
(BS 1363A) 13 AMP fuse
Table 13 Available Power Cords
Product ID (PID) PID Description Images
CAB-9K10A-IT Power Cord, 250VAC 10A CEI
23-16/VII Plug, Italy
CAB-9K10A-SW Power Cord, 250VAC 10A MP232
Plug, Switzerland
CAB-9K10A-UK Power Cord, 250VAC 10A BS1363
Plug (13 A fuse), UK
CAB-9K12A-NA Power Cord, 125VAC 13A NEMA
5-15 Plug, North America
CAB-JPN-3PIN Power Cord 3PIN, Japan Image not available
32
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
CONFIGURING the SERVER
STEP 10 ORDER OPTIONAL REVERSIBLE CABLE MANAGEMENT ARM
The reversible cable management arm mounts on either the right or left slide rails at the rear of
the server and is used for cable management. Use
Table 14 Cable Management Arm
Product ID (PID) PID Description
UCSC-CMA1 Cable Management Arm for C220 rack servers
For more information about the cable management arm, see the Cisco UCS C220 M3 Installation
and Service Guide at this URL:
http://www.cisco.com/en/US/docs/unified_computing/ucs/c/hw/C220/install/C220.pdf
Table 14 to order a cable management arm.
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
33
CONFIGURING the SERVER
STEP 11 ORDER A TRUSTED PLATFORM MODULE
Trusted Platform Module (TPM) is a computer chip (microcontroller) that can securely store
artifacts used to authenticate the platform (server). These artifacts can include passwords,
certificates, or encryption keys. A TPM can also be used to store platform measurements that
help ensure that the platform remains trustworthy. Authentication (ensuring that the platform
can prove that it is what it claims to be) and attestation (a process helping to prove that a
platform is trustworthy and has not been breached) are necessary steps to ensure safer
computing in all environments.
The TPM ordering information is listed in Table 15.
Table 15 Trusted Platform Module
Product ID (PID) PID Description
UCSX-TPM1-001 Trusted Platform Module
34
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
CONFIGURING the SERVER
STEP 12 ORDER CISCO FLEXIBLE FLASH SD CARD MODULE (OPTIONAL)
You can order one optional 16 GB Cisco Flexible Flash secure digital (SD) card. This SD card
contains preloaded software for simplified server operation. The ordering information is listed
in
Table 16.
Table 16 Secure Digital (SD) Card
Product ID (PID) PID Description
UCSC-SD-16G-C220 16GB SD Card for C220 servers
See Figure 6 on page 47 for the location of the SD cards. There are two locations, SD1 and SD2;
however, at present only SD1 is supported.
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
35
CONFIGURING the SERVER
STEP 13 ORDER OPTIONAL USB 2.0 DRIVE
You may order one optional USB 2.0 drive. The USB drive ordering information is listed in
Table 17.
Table 17 USB 2.0 Drive
Product ID (PID) PID Description
UCS-USBFLSH-S-4GB 4GB Flash USB Drive (shorter length) for all servers except C260
See Figure 6 on page 47 for the location of the USB connector.
36
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
STEP 14 SELECT OPERATING SYSTEM
Several operating systems are available from which to choose. Select one of the operating
systems shown in
Table 18 Operating Systems
PID Description Product ID (PID)
SUSE Linux Enterprise Server
SLES-1A SLES/1yr subscription/svcs required/0 media
SLES-3A SLES/3yr subscription/svcs required/0 media
Red Hat Enterprise Linux
RHEL-2S-1G-1A RHEL/2 Socket/1 Guest/1Yr Svcs Required
RHEL-2S-1G-3A RHEL/2 Socket/1 Guest/3Yr Svcs Required
RHEL-2S-4G-1A RHEL/2 Socket/4 Guest/1Yr Svcs Required
Table 18.
CONFIGURING the SERVER
RHEL-2S-4G-3A RHEL/2 Socket/4 Guest/3Yr Svcs Required
RHEL-2S-UG-1A RHEL/2 Socket/U Guest/1Yr Svcs Required
RHEL-2S-UG-3A RHEL/2 Socket/U Guest/3Yr Svcs Required
RHEL Add-Ons
RHEL-HA-2S-1A RHEL Option/High-Availability/2 Socket/1Yr Svcs Required
RHEL-RS-2S-1A RHEL Option/Resilient w/Ha /2 Socket/1 Yr Svcs Required
RHEL-SFS-2S-1A RHEL Option/Scalable File System/2 Socket/1 Yr Svcs Required
RHEL-HA-2S-3A RHEL Option/High-Availability/2 Socket/3Yr Svcs Required
RHEL-RS-2S-3A RHEL Option/Resilient Storage w/ HA /2 Socket/3 Yr Svcs Reqd
RHEL-SFS-2S-3A RHEL Option/Scalable File System/2 Socket/3 Yr Svcs Required
Windows Server
MSWS-08R2-STHV Windows Svr 2008 ST media R2 ST (1-4CPU, 5CAL)
MSWS-08R2-ENHV Windows Svr 2008 EN media R2 EN (1-8CPU, 25CAL)
MSWS-08R2-DCHV2S Windows Svr 2008 R2-2 CPU-Data Center
MSWS-08R2-DCHV4S Windows Svr 2008 R2-4 CPU-Data Center
VMWare Server
VMW-VS5-STD-1A VMware vSphere 5 Standard for 1 Processor, 1 Year, Support Required
VMW-VS5-STD-2A VMware vSphere 5 Standard for 1 Processor, 2 Year, Support Required
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
37
CONFIGURING the SERVER
Table 18 Operating Systems (continued)
PID Description Product ID (PID)
VMW-VS5-STD-3A VMware vSphere 5 Standard for 1 Processor, 3 Year, Support Required
VMW-VS5-STD-4A VMware vSphere 5 Standard for 1 Processor, 4 Year, Support Required
VMW-VS5-STD-5A VMware vSphere 5 Standard for 1 Processor, 5 Year, Support Required
VMW-VS5-ENT-1A VMware vSphere 5 Enterprise for 1 Processor, 1 Year Support Required
VMW-VS5-ENT-2A VMware vSphere 5 Enterprise for 1 CPU, 2 Yr Support Required
VMW-VS5-ENT-3A VMware vSphere 5 Enterprise for 1 CPU, 3 Yr Support Required
VMW-VS5-ENT-4A VMware vSphere 5 Enterprise for 1 Processor, 4 Year Support Required
VMW-VS5-ENT-5A VMware vSphere 5 Enterprise for 1 CPU, 5 Yr Support Required
VMW-VS5-ENTP-1A VMware vSphere 5 Enterprise Plus for 1 Processor, 1 Year Support Required
VMW-VS5-ENTP-2A VMware vSphere 5 Enterprise Plus for 1 CPU, 2 Yr Support Required
VMW-VS5-ENTP-3A VMware vSphere 5 Enterprise Plus for 1 Processor, 3 Year Support Required
VMW-VS5-ENTP-4A VMware vSphere 5 Enterprise Plus for 1 Processor, 4 Year Support Required
VMW-VS5-ENTP-5A VMware vSphere 5 Enterprise Plus for 1 Processor, 5 Year Support Required
38
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
STEP 15 SELECT OPERATING SYSTEM MEDIA KIT
Select the optional operating system media listed in Table 19.
Table 19 OS Media
Product ID (PID) PID Description
RHEL-6 RHEL 6 Recovery Media Only (Multilingual)
SLES-11 SLES 11 media only (multilingual)
MSWS-08R2-STHV-RM Windows Svr 2008 R2 ST (1-4CPU, 5CAL), Media
MSWS-08R2-ENHV-RM Windows Svr 2008 R2 EN (1-8CPU, 25CAL), Media
MSWS-08R2-DCHV-RM Windows Svr 2008 R2 DC (1-8CPU, 25CAL), Media
CONFIGURING the SERVER
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
39
CONFIGURING the SERVER
STEP 16 SELECT OPTIONAL VALUE-ADDED SOFTWARE
You can select from a variety of value-added software listed in Table 20.
Table 20 Value Added Software
Product ID (PID) PID Description
BMC-SE-4C BMC BladeLogic Standard Edition, 4 Cores, Support Required
BMC-SE-6C BMC BladeLogic Standard Edition, 6 Cores, Support Required
BMC-SE-8C BMC BladeLogic Standard Edition, 8 Cores, Support Required
BMC-SE-10C BMC BladeLogic Standard Edition, 10 Cores, Support Required
BMC-AE-4C BladeLogic Advanced Edition, 4 Cores, Support Required
BMC-AE-6C BMC BladeLogic Advanced Edition, 6 Cores, Support Required
BMC-AE-8C BMC BladeLogic Advanced Edition, 8 Cores, Support Required
BMC-AE-10C BMC BladeLogic Advanced Edition, 10 Cores, Support Required
BMC-002 BMC BladeLogic CM for Physical Cisco Servers
BMC-012 BMC BPPM Per Server
VMW- VC5-STD-1A VMware vCenter 5 Standard for 1 Processor, 1 Year, Support Required
VMW- VC5-STD-2A VMware vCenter 5 Standard for 1 Processor, 2 Year, Support Required
VMW- VC5-STD-3A VMware vCenter 5 Standard for 1 Processor, 3 Year, Support Required
VMW- VC5-STD-4A VMware vCenter 5 Standard for 1 Processor, 4 Year, Support Required
VMW- VC5-STD-5A VMware vCenter 5 Standard for 1 Processor, 5 Year, Support Required
N1K-VLEM-UCS-1 Nexus 1000V License PAK for 1 Virtual Ethernet module
N1K-CSK9-UCS-404 Nexus 1000V VSM Virtual Appliance Software
40
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
STEP 17 SELECT SERVICE and SUPPORT LEVEL
A variety of service options are available, as described in this section.
Unified Computing Warranty, No Contract
If you have noncritical implementations and choose no service contract, the following coverage
is supplied:
■ Three-year parts coverage.
■ Next business day (NBD) parts replacement eight hours a day, five days a week.
■ 90-day software warranty on media.
■ Downloads of BIOS, drivers, and firmware updates.
■ UCSM updates for systems with Unified Computing System Manager. These updates include
minor enhancements and bug fixes that are designed to maintain the compliance of UCSM
with published specifications, release notes, and industry standards.
Unified Computing Support Service
For support of the entire Cisco Unified Computing System, Cisco offers the Cisco Unified
Computing Support Service. This service provides expert software and hardware support to help
sustain performance and high availability of the unified computing environment. Access to the
Cisco Technical Assistance Center (TAC) is provided around the clock, from anywhere in the
world.
CONFIGURING the SERVER
For UCS blade servers, there is Smart Call Home, which provides proactive, embedded
diagnostics and real-time alerts. For systems that include Unified Computing System Manager,
the support service includes downloads of UCSM upgrades. The Unified Computing Support
Service includes flexible hardware replacement options, including replacement in as little as
two hours. There is also access to Cisco's extensive online technical resources to help maintain
optimal efficiency and uptime of the unified computing environment. You can choose a desired
service listed in
Table 21.
Table 21 UCS Computing Support Service
Product ID (PID) On Site? Description
CON-UCS1-C220-M3-W No UC Support 8X5XNBD
CON-UCS2-C220-M3-W No UC Support 8X5X4
CON-UCS3-C220-M3-W No UC Support 24x7x4
CON-UCS4-C220-M3-W No UC Support 24x7x2
CON-UCS5-C220-M3-W Yes UC Support 8X5XNBD
CON-UCS6-C220-M3-W Yes UC Support 8X5X4
CON-UCS7-C220-M3-W Yes UC Support 24x7x4
CON-UCS8-C220-M3-W Yes UC Support 24x7x2
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
41
CONFIGURING the SERVER
Unified Computing Warranty Plus Service
For faster parts replacement than is provided with the standard Cisco Unified Computing System
warranty, Cisco offers the Cisco Unified Computing Warranty Plus Service. You can choose from
several levels of advanced parts replacement coverage, including onsite parts replacement in as
little as two hours. Warranty Plus provides remote access any time to Cisco support professionals
who can determine if a return materials authorization (RMA) is required. See
Table 22 UCS Computing Warranty Plus Service
Product ID (PID) On Site? Description
CON-UCW2-C220-M3-W No UC Warranty Plus 8x5x4
CON-UCW3-C220-M3-W No UC Warranty Plus 24x7x4
CON-UCW4-C220-M3-W No UC Warranty Plus 24x7x2
CON-UCW5-C220-M3-W Yes UC Warranty Plus 8X5XNBD
CON-UCW6-C220-M3-W Yes UC Warranty Plus 8X5X4
CON-UCW7-C220-M3-W Yes UC Warranty Plus 24x7x4
Table 22.
CON-UCW8-C220-M3-W Yes UC Warranty Plus 24x7x2
Unified Computing Drive Retention Service
With the Cisco Unified Computing Drive Retention (UCDR) Service, you can obtain a new disk
drive in exchange for a faulty drive without returning the faulty drive. In exchange for a Cisco
replacement drive, you provide a signed Certificate of Destruction (CoD) confirming that the
drive has been removed from the system listed, is no longer in service, and has been destroyed.
Sophisticated data recovery techniques have made classified, proprietary, and confidential
information vulnerable, even on malfunctioning disk drives. The UCDR service enables you to
retain your drives and ensures that the sensitive data on those drives is not compromised, which
reduces the risk of any potential liabilities. This service also enables you to comply with
regulatory, local, and federal requirements.
If your company has a need to control confidential, classified, sensitive, or proprietary data, you
might want to consider one of the Drive Retention Services listed in
Table 23.
NOTE: Cisco does not offer a certified drive destruction service as part of this
service.
42
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
Table 23 Drive Retention Service Options
CONFIGURING the SERVER
Service Description
UCS Mission Critical
Support Service
With Drive
Retention
UCS Support
Service With Drive
Retention
Service
Program Name
Service
Level GSP
Service Level Product ID (PID)
UC CRIT DR UCMD7 24x7x4 Onsite CON-UCMD7-C220-M3-WSFF
UCMD8 24x7x2 Onsite CON-UCMD8-C220-M3-WSFF
UC SUPP DR UCSD1 8x5xNBD CON-UCSD1-C220-M3-WSFF
UCSD2 8x5x4 CON-UCSD2-C220-M3-WSFF
UCSD3 24x7x4 CON-UCSD3-C220-M3-WSFF
UCSD4 24x7x2 CON-UCSD4-C220-M3-WSFF
UCSD5 8x5xNBD
CON-UCSD5-C220-M3-WSFF
Onsite
UCSD6 8x5x4 Onsite CON-UCSD6-C220-M3-WSFF
UCSD7 24x7x4 Onsite CON-UCSD7-C220-M3-WSFF
UCSD8 24x7x2 Onsite CON-UCSD8-C220-M3-WSFF
UCS Warranty Plus
With Drive
Retention
Mission Critical Support Service
This service delivers personalized technical account management, expedited technical support,
and expert field support engineering for the Cisco Unified Computing System (UCS).
The Mission Critical Support Service provides a designated technical account manager (TAM) who
acts as a strategic resource to help ensure that the unified computing environment runs at peak
efficiency. If a problem arises that threatens business continuity, the TAM provides crisis
management leadership, and your IT staff receives expedited access to Cisco's Technical
Assistance Center (TAC).
UC PLUS DR UCWD2 8x5x4 CON-UCWD2-C220-M3-WSFF
UCWD3 24x7x4 CON-UCWD3-C220-M3-WSFF
UCWD4 24x7x2 CON-UCWD4-C220-M3-WSFF
UCWD5 8x5xNBD
CON-UCWD5-C220-M3-WSFF
Onsite
UCWD6 8x5x4 Onsite CON-UCWD6-C220-M3-WSFF
UCWD7 24x7x4 Onsite CON-UCWD7-C220-M3-WSFF
UCWD8 24x7x2 Onsite CON-UCWD8-C220-M3-WSFF
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
43
CONFIGURING the SERVER
Mission Critical Support Service is a layered service available for all Cisco data center products
already support by a UCS Support Service or SMARTnet service contract. For further information
about Cisco Mission Critical Support Service, please consult the Service Description that can be
found at the following link:
http://www.cisco.com/web/about/doing_business/legal/service_descriptions/index.html
or contact your Cisco account Manager.
For more service and support information, see this URL:
http://www.cisco.com/en/US/services/ps2961/ps10312/ps10321/Cisco_UC_Warranty_Support_DS.pdf
For a complete listing of available services for Cisco Unified Computing System, see this URL:
http://www.cisco.com/en/US/products/ps10312/serv_group_home.html
44
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
OPTIONAL STEP - ORDER RACK(s)
Notes . . .
The optional R42610 rack is available from Cisco for the C-Series servers, including the C220 M3
SFF server. This rack is a standard 19-inch rack and can be ordered with a variety of options, as
listed in
Table 24 Racks and Rack Options
Product ID (PID) PID Description
Table 24. Racks are shipped separately from the C220 M3 SFF server.
OPTIONAL STEP - ORDER RACK(s)
RACK-UCS
RACK-UCS2
1
1
Cisco R42610 expansion rack, no side panels
Cisco R42610 standard rack, w/side panels
RACK-BLANK-001 Filler panels (qty 12), 1U, plastic, toolless
RACK-CBLMGT-001 Cable mgt D rings (qty 10), metal
RACK-CBLMGT-011 Cable mgt straps (qty 10), Velcro
RACK-FASTEN-001 Mounting screws (qty 100), M6
RACK-FASTEN-002 Cage nuts (qty 50), M6
RACK-JOIN-001 Rack joining kit
1. Use these same base PIDs to order spare racks (available only as next-day replacements).
For more information about the R42610 rack, see RACKS, page 55.
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
45
OPTIONAL STEP - ORDER PDU
OPTIONAL STEP - ORDER PDU
An optional power distribution unit (PDU) is available from Cisco for the C-Series rack servers,
including theC220 M3 server. This PDU is available in a zero rack unit (RU) style (see
Table 25 PDU Options
Product ID (PID) PID Description
RP208-30-2P-U-2 Zero RU PDU
For more information about the PDU, see PDUs, page 57.
Table 24).
46
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
SUPPLEMENTAL MATERIAL
FAN1FAN1FAN1
FAN2
FAN2FAN2
FAN3
FAN3FAN3
FAN4FAN4
FAN4FAN4
FAN5
FAN5FAN5
PSU2
PCIe1
PCIe2
PSU1
CPU1
CPU2
SAS1
SAS2
SAS1
SAS2
1718
15
11
10
8
96
7
52 3
4
1
12
13
16
14
CHASSIS
An internal view of the C220 M3 chassis with the top cover removed is shown in Figure 6.
Figure 6 C220 M3 SFF With Top Cover Off
SUPPLEMENTAL MATERIAL
1 Drives
(hot-swappable, accessed through front panel)
2 Drive backplane 11 Standard-profile PCIe riser (PCIe slot 1)
3 SuperCap backup unit mounting location 12 Low-profile PCIe riser (PCIe slot 2)
4 Cooling fans (five) 13 Cisco Flexible Flash SD socket SD2 on PCIe
5 SCU upgrade ROM header (RAID key). 14 Cisco Flexible Flash SD socket SD1 on PCIe
10 Trusted platform module socket on
motherboard
riser 2
riser 2
6 DIMM slots on motherboard (16) 15 Internal USB port
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
47
SUPPLEMENTAL MATERIAL
7 CPUs and heatsinks (two) 16 Power supplies (two, hot-swappable
access through rear panel)
8 Integrated RAID on motherboard, and mini-SAS
connectors
9 Mezzanine RAID card, mini-SAS connectors
SAS1 and SAS2
17 RTC battery on motherboard
18 Software RAID 5 header (RAID key).
CPUs and DIMMs
Physical Layout
Each CPU has four DIMM channels:
■ CPU1 has channels A, B, C, and D
■ CPU2 has channels E, F, G, and H
Each DIMM channel has two banks: bank 1 and bank 2. The blue-colored DIMM banks are for bank 1 and the
black-colored are for bank 2.
As an example, DIMM slots A1, B1, C1, and D1 belong to bank 1, while A2, B2, C2, and D2 belong to bank 2.
Figure 7 shows how banks and channels are physically laid out on the motherboard. The DIMM slots on the
right (channels A, B, C, and D) are associated with CPU1, while the DIMM slots on the left (channels E, F, G,
and H) are associated with CPU2. The bank 1 (blue) DIMM slots are always located farther away from a CPU
than the corresponding bank 2 (black) slots. Bank 1 slots (blue) are populated before bank 2 slots (black).
48
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
Figure 7 Physical Layout of CPU DIMM Channels and Banks
C1
C2
D1
D2
CPU1
Front of Server
B2
B1
A2
A1
G1
G2
H1
H2
SUPPLEMENTAL MATERIAL
F2
F1
E2
E1
CPU2
331707
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
49
SUPPLEMENTAL MATERIAL
Notes . . .
Memory Population Rules
When considering the memory configuration of your server, you should consider the following items:
■ For optimum performance, populate at least one DIMM per memory channel per CPU. If
using 4 GB DIMMs, you must populate 2 DIMMs per CPU memory channel.
■ The server supports registered DIMMs (RDIMMs) or load-reduced DIMMS (LRDIMMs), however,
do not mix RDIMMs and LRDIMMs in a server.
■ Each channel has two DIMM slots (for example, channel A = slots A1 and A2).
— A channel can operate with one or two DIMMs installed.
— If a channel has only one DIMM, populate slot 1 first (the blue slot).
■ When both CPUs are installed, populate the DIMM slots of each CPU identically.
— Fill blue slots in the channels first: A1, E1, B1, F1, C1, G1, D1, H1
— Fill black slots in the channels second: A2, E2, B2, F2, C2, G2, D2, H2
■ Any DIMM installed in a DIMM socket for which the CPU is absent is not recognized.
■ Observe the DIMM mixing rules shown in Table 26
Table 26 DIMM Mixing Rules for C220 M3 Server
DIMM Parameter Mixed Mix Across a Single Bank? Mix Across Multiple Banks?
DIMM Size (4, 8, 16 GB) No—Must be same size in the
same bank
Yes—Different banks can use
different DIMM sizes (as long
as all DIMMs in a single bank
use the same DIMM size).
DIMM Speed
(1066, 1333, or 1600 MHz)
DIMM Type (R-DIMM) No—All DIMMs in a bank must
1. Only 1333 and 1600 MHz DIMMs are currently available for the C220 M3 server.
No—Must be same speed in
1
the same bank.
be same type.
No—All DIMMs in the server
must be same speed.
No—All DIMMs in the server
must be same type.
50
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
SUPPLEMENTAL MATERIAL
Recommended Memory Configuration
This section explains the recommended DIMM population order rules for the C220 M3 server.
■ All DIMMs must be DDR3 DIMMs.
■ Do not mix:
— DIMMs with different sizes or clock rates in a bank
— RDIMMs and LRDIMMs
— ECC and non-ECC DIMMs
■ There are blue and black DIMM slots. Populate blue slots first.
■ When single- and dual-rank DIMMs are populated for 2DPC, always populate the dual-rank
DIMM in the blue DIMM slot and the single-rank DIMM in the black DIMM slot.
Many memory configurations are possible. For best results, follow Table 27 when populating DIMMs.
Table 27 Recommended Memory Configurations
Total
System
Memory
Size
32 GB
64 GB
96 GB
128 GB
CPU 1 DIMMs CPU 2 DIMMs
DIMM Max
Blue Slots
Bank 1
(A1, B1,
C1, D1)
Black Slots
Bank 2
(A2, B2,
C2, D2)
Blue Slots
Bank 1
(E1, F1,
G1, H1)
Black Slots
Bank 2
(E2, F2,
G2, H2)
Operating
Speed
(MHz)
DIMMs in
System
4x4 GB — 4x4 GB — 1600 8
2x8 GB — 2x8 GB — 1600 4
4x4 GB 4x4 GB 4x4 GB 4x4 GB 1600 16
4x8 GB — 4x8 GB — 1600 8
1x32 GB — 1x32GB — 1600 2
4x8 GB 2x8 GB 4x8 GB 2x8 GB 1600 12
3x16 GB — 3x16 GB — 1600 6
4x8 GB 4x4 GB 4x8 GB 4x4 GB 1600 16
1x32 GB 1x16 GB 1x32 GB 1x16 GB 1600 4
4x8 GB 4x8 GB 4x8 GB 4x8 GB 1600 16
Total
the
1
4x16 GB — 4x16 GB — 1600 8
1x32 GB 1x32GB 1x32 GB 1x32GB 1600 8
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
51
SUPPLEMENTAL MATERIAL
Notes . . .
Table 27 Recommended Memory Configurations (continued)
Total
CPU 1 DIMMs CPU 2 DIMMs
System
Memory
Size
192 GB
Blue Slots
Bank 1
(A1, B1,
C1, D1)
4x16 GB 2x16 GB 4x16 GB 2x16 GB 1600 12
Black Slots
Bank 2
(A2, B2,
C2, D2)
4x16 GB 4x8 GB 4x16 GB 4x8 GB 1600 16
2x32 GB 1x32 GB 2x32 GB 1x32 GB 1600 6
256 GB
4x16 GB 4x16 GB 4x16 GB 4x16 GB 1600 16
2x32 GB 2x32 GB 2x32 GB 2x32 GB 1600 8
512 GB
1. Rows marked in yellow indicate best performance
4x32 GB 4x32 GB 4x32 GB 4x32 GB 1600 16
Blue Slots
Bank 1
(E1, F1,
G1, H1)
Black Slots
Bank 2
(E2, F2,
G2, H2)
DIMM Max
Operating
Speed
(MHz)
Total
DIMMs in
the
System
1
52
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
Supported DIMM Populations
The supported DIMM populations are listed in Table 28.
Table 28 Supported DIMM Configurations
SUPPLEMENTAL MATERIAL
Total
Capacity for
2 CPUs
CPU 1 DIMMs
T otal DIMMs
for CPU 1
CPU 1
Capacity
CPU 2 DIMMs
Total DIMMs
for CPU 2
CPU 2
Capacity
1 x 8 GB 1 8 GB 1 x 8 GB 1 8 GB 16 GB
1 x 16 GB 1 16 GB 1 x 16 GB 1 16 GB 32 GB
2 x 4 GB 2 8 GB 2 x 4 GB 2 8 GB 16 GB
4 x 4 GB 4 16 GB 4 x 4 GB 4 16 GB 32 GB
2 x 8 GB 2 16 GB 2 x 8 GB 2 16 GB 32 GB
6 x 4 GB 6 24 GB 6 x 4 GB 6 24 GB 48 GB
8 x 4 GB 8 32 GB 8 x 4 GB 8 32 GB 64 GB
4 x 8 GB 4 32 GB 4 x 8 GB 4 32 GB 64 GB
8 x 4 GB 8 32 GB 8 x 4 GB 8 32 GB 64 GB
1 x 32 GB 1 32 GB 1 x 32 GB 1 32 GB 64 GB
5 x 8 GB 5 40 GB 5 x 8 GB 5 40 GB 80 GB
3 x 16 GB 3 48 GB 3 x 16 GB 3 48 GB 96 GB
6 x 8 GB 6 48 GB 6 x 8 GB 6 48 GB 96 GB
4x8 GB + 4x4 GB 8 48 GB 4x8 GB + 4x4 GB 8 48 GB 96 GB
7 x 8 GB 7 56 GB 7 x 8 GB 7 56 GB 112 GB
4 x 16 GB 4 64 GB 4 x 16 GB 4 64 GB 128 GB
8 x 8 GB 8 64 GB 8 x 8 GB 8 64 GB 128 GB
2 x 32 GB 2 64 GB 2 x 32 GB 2 64 GB 128 GB
5 x 16 5 80 GB 5 x 16 5 80 GB 160 GB
4x16 GB + 4x4 GB 8 80 GB 4x16 GB + 4x4 GB 8 80 GB 160 GB
6 x 16 GB 6 96 GB 6 x 16 GB 6 96 GB 192 GB
4x8 GB + 4x16 GB 8 96 GB 4x8 GB + 4x16 GB 8 96 GB 192 GB
7 x 16 GB 7 112 GB 7 x 16 GB 7 112 GB 224 GB
8 x 16 GB 8 128 GB 8 x 16 GB 8 128 GB 256 GB
4 x 32 GB 4 128 GB 4 x 32 GB 4 128 GB 256 GB
8 x 32 GB 8 256 GB 8 x 32 GB 8 256 GB 512 GB
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
53
SUPPLEMENTAL MATERIAL
Low-Voltage DIMM Considerations
The C220 M3 server can be ordered with dual-voltage (1.5/1.35 V) DIMMs only. Note the following
considerations:
■ Low-voltage DIMMs within the server must have the identical manufacturer, type, speed,
and size.
■ Low-voltage DIMMs and standard-voltage DIMMs can be mixed in the same server. Note that
this causes the system BIOS to default to standard-voltage operation (Performance Mode).
That is, the server cannot operate in Power Saving Mode unless all DIMMs are low-voltage
DIMMs.
■ CPUs that have a maximum memory frequency less than 1333 MHz support low-voltage
DIMMs operating in Power Saving Mode only, and do not support Performance Mode.
RAID Summary
The C220 M3 SFF server has an 8-drive backplane.
■ ROM5 and ROM55 embedded RAID upgrade options support up to 8 drives
■ Mezzanine card (UCSC-RAID-11-C220) supports up to 8 drives
■ Mezzanine card (UCSC-RAID-MZ-220) supports up to 8 drives
■ SAS 9266-8i and SAS 9266CV-8i PCIe cards support up to 8 drives
NOTE: If you do not select a mezzanine card, a plug-in PCIe RAID card, or one of the
embedded RAID upgrade options, you will have an embedded SATA-only RAID
controller that supports up to four SATA-only drives (RAID 0, 1, 10)
54
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
SUPPLEMENTAL MATERIAL
RACKS
The Cisco R42610 rack (see Figure 8) is certified for Cisco UCS installation at customer sites and is suitable
for the following equipment:
■ Cisco UCS B-Series servers and fabric interconnects
■ Cisco UCS C-Series and select Nexus switches
The rack is compatible with hardware designed for EIA-standard 19-inch racks. Rack specifications are
listed in
Table 29 Cisco R42610 Rack Specifications
Parameter Standard Rack Expansion Rack
Table 29.
Dimensions (H x W x D) 78.74 x 24 x 43.38 in.
(2000 x 610 x 1102 mm)
Dimensions (H x W x D)
with packaging
Distance from front
89 x 33 x 47 in.
(2261 x 838 x 1194 mm)
29.2 in (741 mm) 29.2 in (741 mm)
78.74 x 23.58 x 43.38 in.
(2000 x 599 x 1102 mm)
89 x 33 x 47 in.
(2261 x 838 x 1194 mm)
mounting rail to rear
mounting rail
Weight 299.83 lb (136 kg) 231. 49 lb (105 kg)
Weight with packaging 354 lb
(161 kg)
284 lb
(129 kg)
Side panels included Yes No
Equipment mounting
42RU 42RU
capacity
Static load capacity 2100 lb
(954 kg)
2100 lb
(954 kg)
Dynamic load capacity Not applicable Not applicable
NOTE: The AC input connector is an IEC 320 C-14 15 A/250 VAC power inlet.
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
55
SUPPLEMENTAL MATERIAL
Front view - door closed Front view - door open Front view - door removed
Figure 8 Cisco R42610 Rack
56
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
SUPPLEMENTAL MATERIAL
PDUs
Cisco RP Series Power Distribution Units (PDUs) offer power distribution with branch circuit protection.
Cisco RP Series PDU models distribute power to up to 24 outlets. The architecture organizes power
distribution, simplifies cable management, and enables you to move, add, and change rack equipment
without an electrician.
With a Cisco RP Series PDU in the rack, you can replace up to two dozen input power cords with just one.
The fixed input cord connects to the power source from overhead or under-floor distribution. Your IT
equipment is then powered by PDU outlets in the rack using short, easy-to-manage power cords.
The C-series severs accept the zero-rack-unit (0RU) PDU. See Figure 9).
Figure 9 Zero Rack Unit PDU (PID = RP208-30-2P-U-2)
1 Breakers 3 C19 plugs
2 Ground connection 4 C13 plugs
Cisco RP Series PDU models provide two 20-ampere (A) circuit breakers for groups of receptacles. The
effects of a tripped circuit are limited to a receptacle group. Simply press a button to reset that circuit.
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
57
SUPPLEMENTAL MATERIAL
KVM CABLE
The KVM cable provides a connection into the server, providing a DB9 serial connector, a VGA connector for
a monitor, and dual USB ports for a keyboard and mouse. With this cable, you can create a direct
connection to the operating system and the BIOS running on the server.
The KVM cable ordering information is listed in Table 30.
Table 30 KVM Cable
Product ID (PID) PID Description
N20-BKVM KVM cable for B-Series Blade Server console port
Figure 10 KVM Cable
1 Connector (to server front panel) 3 VGA connector (for a monitor)
2 DB-9 serial connector 4 Two-port USB connector (for a mouse and
keyboard)
58
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
SUPPLEMENTAL MATERIAL
FAN1FAN1FAN1
FAN2
FAN2FAN2
FAN3
FAN3FAN3
FAN4FAN4
FAN4FAN4
FAN5
FAN5FAN5
PSU2
PCIe1
PCIe2
PSU1
CPU1
CPU2
SAS1
SAS2
SAS1
SAS2
331714
2
1
3
4
Motherboard USB and SD Ports, and RAID Card Backup Location
The C220 M3 SFF motherboard has a general-purpose USB socket, and two SD sockets as shown in Figure 11.
The mounting location for the RAID SuperCap data cache power backup module is also shown.
Figure 11 Motherboard USB and SD Ports and RAID Card Super Capacitor Location
1 SD1 socket 3 USB connector
2 SD2 socket 4 SuperCap module mounting location
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
59
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
Dimensions and Weight
Table 31 UCS C220 M3 Dimensions and Weight
Parameter Value
Height 1.7 in. (4.32 cm)
Width 16.92 in.(43.0 cm)
Depth 28.5 in. (72.4cm)
Front Clearance 3 in. (76 mm)
Side Clearance 1 in. (25 mm)
Rear Clearance 6 in. (152 mm)
Weight
Maximum (8 HDDs, 2 CPUs, 16 DIMMs, 2 power supplies) 35.6 lbs (16.2 kg)
Minimum (1 HDD, 1 CPU, 1 DIMM, 1 power supply) 26.8 lbs (12.1 kg)
Bare (0 HDD, 0 CPU, 0 DIMM, 1 power supply) 22 lbs (10 kg)
Power Specifications
The general power specifications for the C220 M3 SFF server 450 W power supply are listed in Table 32.
Table 32 UCS C220 M3 SFF 450 W Power Supply Specifications
Description Specification
AC input voltage 90 to 264 VAC self-ranging,
100 to 120 VAC nominal
200 to 240 VAC nominal
AC input frequency Range: 47 to 63 Hz (single phase, 50 to 60 Hz nominal)
Maximum AC input current 7.6 A peak at 100 VAC
3.65 A peak at 208 VAC
Maximum AC inrush current 11 A
Maximum output power for each
power supply
Power supply output voltage Main power: 12 VDC
60
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
450 W
Standby power: 12 VDC
TECHNICAL SPECIFICATIONS
Table 32 UCS C220 M3 SFF 450 W Power Supply Specifications
Description Specification
Power supply efficiency CSCI Platinum
NOTE: AC input connector is an IEC 320 C-14 15A/250VAC power inlet.
The general power specifications for the C220 M3 SFF server 650 W power supply are listed in Table 32.
Table 33 UCS C220 M3 LFF 650 W Power Supply Specifications
Description Specification
AC input voltage 90 to 264 VAC self-ranging,
100 to 120 VAC nominal
200 to 240 VAC nominal
AC input frequency Range: 47 to 63 Hz (single phase, 50 to 60 Hz nominal)
Maximum AC input current 7.6 A peak at 100 VAC
3.65 A peak at 208 VAC
Maximum AC inrush current 11 A
Maximum output power for the
650 W
power supply
Power supply output voltage Main power: 12 VDC
Standby power: 12 VDC
Power supply efficiency CSCI Platinum
NOTE: AC input connector is an IEC 320 C-14 15A/250VAC power inlet.
For configuration-specific power specifications, use the Cisco UCS Power Calculator at this URL:
https://express.salire.com/Go/Cisco/Cisco-UCS-Power-Calculator.aspx
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
61
TECHNICAL SPECIFICATIONS
Environmental Specifications
The power specifications for the C220 M3 server are listed in Table 34.
Table 34 UCS C220 M3 Environmental Specifications
Parameter Minimum
Temperature operating 41 to 104° F (5 to 40° C)
derate the maximum temperature by 1°C per every 305m of
altitude above sea level
Temperature nonoperating –40 to 149°F (–40 to 65°C)
Humidity (RH) nonoperating,
non-condensing
Altitude operating 0 to 3,000 m (0 to 10,000 ft.)
Altitude nonoperating 0 to 12,192 m (0 to 40,000 ft.)
Sound Power level, Measure
A-weighted per ISO7779 LWAd
(Bels)Operation at 73°F (23°C)
Sound Pressure level, Measure
A-weighted per ISO7779 LpAm
(dBA)Operation at 73°F (23°C)
10 to 90%
5.4
37
62
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
TECHNICAL SPECIFICATIONS
Compliance Requirements
The regulatory compliance requirements for C-Series servers are listed in Table 35.
Table 35 UCS C-Series Regulatory Compliance Requirements
Parameter Description
Regulatory Compliance Products should comply with CE Markings per directives
2004/108/EC and 2006/95/EC
Safety UL 60950-1 Second Edition
CAN/CSA-C22.2 No. 60950-1 Second Edition
EN 60950-1 Second Edition
IEC 60950-1 Second Edition
AS/NZS 60950-1
GB4943 2001
EMC - Emissions 47CFR Part 15 (CFR 47) Class A
AS/NZS CISPR22 Class A
CISPR22 Class A
EN55022 Class A
ICES003 Class A
VCCI Class A
EN61000-3-2
EN61000-3-3
KN22 Class A
CNS13438 Class A
EMC - Immunity EN55024
CISPR24
EN300386
KN24
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
63
TECHNICAL SPECIFICATIONS
64
Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
Loading...
