Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

Cisco IOS® Software 12.3 BC, 12.2 BC, 12.2CX, 12.1 EC May 2009

Text Part Number: OL-2239-05

CCDE, CCSI, CCENT, Cisco Eos, Cisco HealthPresence, the Cisco logo, Cisco Lumin, Cisco Nexus, Cisco Nurse Connect, Cisco Stackpower, Cisco StadiumVision,

Cisco

TelePresence, Cisco WebEx, DCE, and Welcome to the Human Network are trademarks; Changing the Way We Work, Live, Play, and Learn and Cisco Store are service marks; and Access Registrar, Aironet, AsyncOS, Bringing the Meeting To You, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, CCVP, Cisco, the Cisco

Certified Internetwork Expert logo, Cisco IOS, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity, Collaboration Without Limitation, EtherFast, EtherSwitch, Event Center, Fast Step, Follow Me Browsing, FormShare, GigaDrive, HomeLink, Internet Quotient, IOS, iPhone, iQuick Study, IronPort, the IronPort

logo, LightStream, Linksys, MediaTone, MeetingPlace, MeetingPlace Chime Sound, MGX, Networkers, Networking Academy, Network Registrar, PCNow, PIX, PowerPanels, ProConnect, ScriptShare, SenderBase, SMARTnet, Spectrum Expert, StackWise, The Fastest Way to Increase Your Internet Quotient, TransPath, WebEx, and the WebEx

logo are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.

All other trademarks mentioned in this document or website are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (0903R)

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-04

CONTENTS

Preface 11

Document Revision History 1-11

Document Objectives 1-11

Audience 1-12

Document Organization 1-12

Conventions 1-13

Terms and Acronyms 1-14

Related Documentation 1-17

Cisco uBR7200 Series Documentation 1-17 Cisco Cable Modem Termination System Reference Documentation 1-18 Related Cisco IOS Release Documentation 1-18

CHAPTER

1 Overview of Cisco uBR7200 Series Software 1-1

Cisco IOS Releases and Images for the Cisco uBR7200 Series 1-2

Determining Your Cisco IOS Software Release 1-2 Upgrading to a New Software Release 1-2

12.3 BC Release Train Images and Requirements 1-3

12.2 BC Release Train Images and Requirements 1-4

12.2 CX Images and Requirements 1-5

12.1 EC Images and Requirements 1-7

Cisco uBR7200 Series Chassis Overview 1-8

Cisco uBR7200 Series Universal Broadband Routers 1-9 Supported Hardware on the Cisco uBR7200 Series 1-11 System Interoperability 1-14

Cisco uBR7200 Series Router Configuration Overview 1-15

Port Adapter and Line Card Slot and Logical Interface Numbering 1-15 MAC-Layer Addressing 1-17 Cable Interface Line Cards 1-17 Cable Interface Line Card Slots 1-19 Interfaces and Physical Ports 1-20 Port Adapter Slots 1-20

Supported Software Features for the Cisco uBR7200 Series 1-22

Cisco uBR7200 Series Router Features and Cisco IOS Releases 1-22 Cisco uBR7200 Series Router Configuration Tools 1-31

Contents

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-04

Bandwidth Management Features 1-33 Cisco IOS Command-Line Enhancements 1-33 Cisco Quality of Service Features 1-45 DHCP Servers and Feature Support 1-47 DOCSIS 1.0 Feature Support 1-49 DOCSIS 1.0+ Feature Support 1-56 DOCSIS 1.1 Feature Support 1-57 DOCSIS 2.0 Feature Support 1-67 High Availability Features 1-68 Intercept Features 1-72 IP Broadcast and Multicast Features 1-79 IP Routing Features 1-80 Management Features 1-86 Multicast Features 1-96 PacketCable and Voice Support Features 1-101 Security Features 1-102 SNMP Features and Enhancements 1-109 Spectrum Management and Advanced Spectrum Management Features 1-119 Testing, Troubleshooting and Diagnostic Features 1-123 Virtual Interfaces 1-125 VLAN Features 1-126 VPN and Layer 2 Tunneling Features 1-126 WAN Optimization and Services Features 1-131

DOCSIS and CMTS Interoperability 1-137

DOCSIS NTSC Cable Plants 1-137 EuroDOCSIS Cable Plants 1-138 DOCSIS-Compliant Downstream Signals 1-139 DOCSIS-Compliant Upstream Signals 1-140 Traffic Engineering 1-142

CHAPTER

2 Configuring the Cable Modem Termination System for the First Time 2-1

Configuration Fundamentals for the Cisco uBR7200 Series 2-2

Preconfiguring the Cisco uBR7200 Series 2-2 Booting and Logging onto the Cisco uBR7200 Series 2-5 Setting Password Protection on the Cisco uBR7200 Series 2-5 Recovering Passwords on the Cisco uBR7200 Series 2-6

Configuring the Cisco uBR7200 Series Using AutoInstall 2-10

Autoinstall Requirements 2-10 Understanding AutoInstall 2-11

Contents

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-04

Preparing for the AutoInstall Process 2-11 Performing the AutoInstall Procedure 2-12 Setting Up the TFTP Server for Autoinstall 2-15 Setting Up the BOOTP or RARP Server for Autoinstall 2-16 Connecting the New Router to the Network 2-16

Configuring the Cisco uBR7200 Series Using the Setup Facility 2-17

Introduction to the Setup Facility 2-17 Configuring Global Parameters with the Setup Facility 2-18 Configuring Upstream Frequencies with the Setup Facility 2-21 Configuring Interfaces with the Setup Facility 2-22

Configuring the Cable Interface with the Extended Setup Facility 2-25

Identifying the Cable Interface Line Card 2-25 Configuring Global Parameters in Extended Setup 2-26

Configuring the Cisco uBR7200 Series Manually Using Configuration Mode 2-27

Saving Your Configuration Settings 2-29

Reviewing Your Settings and Configurations 2-29

Viewing Sample Configuration Files 2-29

CHAPTER

3 Configuring Cable Modem Interface Features 3-1

Configuring the Downstream Cable Modem Interface 3-2

Activating Downstream Cable Address Resolution Protocol Requests 3-2 Activating Downstream Ports 3-3 Setting the Integrated Upconverter 3-4 Assigning the Downstream Channel ID 3-5 Configuring Downstream Rate Limiting and Traffic Shaping 3-6 Setting the Downstream Helper Address 3-7 Setting the Downstream Interleave Depth 3-8 Setting the Downstream Modulation 3-8 Setting the Downstream MPEG Framing Format 3-9 Setting Downstream Traffic Shaping 3-10

Configuring the Upstream Cable Modem Interface 3-11

Activating Upstream Admission Control 3-12 Activating Upstream Differential Encoding 3-13 Activating Upstream Forward Error Correction 3-14 Activating the Upstream Ports 3-15 Activating Upstream Frequency Adjustment 3-15 Activating Upstream Power Adjustment 3-16 Activating the Upstream Scrambler 3-17 Activating Upstream Timing Adjustment 3-17

Contents

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-04

Configuring Upstream Rate Limiting and Traffic Shaping 3-18 Setting Upstream Backoff Values 3-19 Setting the Upstream Channel Width 3-21 Setting the Upstream Frequency 3-22 Setting the Upstream Input Power Level 3-24 Specifying Upstream Minislot Size 3-25 Setting Upstream Traffic Shaping 3-26

Configuring Optional Cable Modem Interface Features 3-28

Activating Host-to-Host Communication (Proxy ARP) 3-28 Activating Packet Intercept Capabilities 3-29

Configuring Cable Subinterfaces 3-29

Configuring and Monitoring Cable Interface Bundling 3-30

Configuring Payload Header Suppression and Restoration 3-33

Setting Optional IP Parameters (Broadcast and Multicast Echo) 3-33

Activating IP Multicast Echo 3-33 Activating IP Broadcast Echo 3-34

CHAPTER

4 Configuring DOCSIS Baseline Privacy Interface on the Cisco uBR7200 Series 4-1

Baseline Privacy Interface Overview 4-1

BPI Key Management 4-2 Differentiating Traffic Streams 4-3 CM Communication with BPI 4-3

Enabling DOCSIS BPI 4-3

DOCSIS 1.1 Baseline Privacy Interface Plus Overview 4-4

CHAPTER

5 Managing Cable Modems on the Hybrid Fiber-Coaxial Network 5-1

Activating Cable Modem Authentication 5-2

Activating Cable Modem Insertion Interval 5-3

Activating Cable Modem Upstream Address Verification 5-4

Clearing Cable Modem Counters 5-5

Clearing Cable Modem Reset 5-5

Configuring Cable Modem Registration Timeout 5-6

Configuring Dynamic Contention Algorithms (Cable Insertion Interval, Range, and Data Backoff) 5-6

cable insertion-interval Command Examples 5-6

Configuring the Dynamic Map Advance Algorithm 5-7

Configuring Maximum Hosts Attached to a Cable Modem 5-8

Configuring Per-Modem Filters 5-8

Contents

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-04

Configuring Sync Message Interval 5-9

CHAPTER

6 Configuring Basic Broadband Internet Access 6-1

Overview of Basic Broadband Internet Access 6-1

Recommended Basic Configuration for High-Speed Internet Access 6-2

Basic Internet Access Sample Configuration File 6-3

CHAPTER

7 Overview of the Cisco Network Registrar for the Cisco uBR7200 Series 7-1

Cisco Network Registrar Description 7-1

Cable Modem DHCP Response Fields 7-2 DOCSIS DHCP Fields 7-2 DHCP Relay Option (DOCSIS Option 82) 7-2

Overview of Scripts 7-3

Two-way Cable Modem Scripts 7-3 Telco Return Cable Modem Scripts 7-3

Placement of Scripts 7-3

Windows NT 7-3 Solaris 7-3

Activate Scripts in Cisco Network Registrar 7-4

Configuring the Cisco uBR7200 Series to Use Scripts 7-4

Configure the System Default Policy 7-5

Cable Modems 7-5 PCs 7-5

Create Selection Tag Scopes 7-5

General 7-5 Telco Return 7-6

Create Network Scopes 7-6

Create Policies for Class of Service or for Upgrading Cable Modem Cisco IOS Images 7-7

CNR Steps to Support Subinterfaces 7-7

CHAPTER

8 Troubleshooting the System 8-1

Understanding show Command Responses 8-2

Using a Headend Cable Modem to Verify Downstream Signals 8-6

Performing Amplitude Averaging 8-7

Enabling or Disabling Power Adjustment 8-7

Setting Downstream Test Signals 8-9

Configuring Unmodulated Test Signals 8-9

Contents

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-04

Configuring PRBS Test Signals 8-10 Verifying Test Signal Output 8-10

Pinging Unresponsive Cable Modems 8-10

Pinging a Cable Modem 8-10 Verifying the Ping 8-10

Using Cable Interface debug Commands 8-11

debug cable arp 8-11 debug cable error (for MAC Protocol Errors) 8-11 debug cable keyman (for Baseline Privacy Activity) 8-12 debug cable mac-messages 8-12 debug cable map 8-12 debug cable phy 8-12 debug cable privacy (for Baseline Privacy) 8-13 debug cable qos 8-13 debug cable range (for Ranging Messages) 8-13 debug cable receive (for Upstream Messages) 8-13 debug cable reg (for Modem Registration Requests) 8-14 debug cable reset (for Reset Messages) 8-14 debug cable specmgmt (for Spectrum Management) 8-14 debug cable startalloc (for Channel Allocations) 8-14 debug cable transmit (for CMTS Transmissions) 8-15 debug cable ucc (for Upstream Channel Change Messages) 8-15 debug cable ucd (for Upstream Channel Description Messages) 8-15

APPENDIX

A Installing or Upgrading Cisco IOS Software A-1

Introduction A-1

Before You Begin A-1

Installing or Upgrading Cisco IOS Software A-2

Sample Output—Cisco uBR7200 Series Router A-3 Related Information A-3

Copying a System Image from One Device to Another A-4

Copying from Device to Device Inside the Same Router A-4 Copying from One Router to Another A-4

APPENDIX

B Resolving Common Image Installation Problems B-1

Before You Begin B-1 Resolving Default Gateway Issues B-1 Troubleshooting Problems During Software Transfer B-3 Troubleshooting Problems by Verifying the Software Image B-5

Contents

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-04

APPENDIX

C Viewing Sample Configuration Files C-1

Basic Internet Access Examples C-1 Virtual Private Network (VPN) Example C-9 IP Telephony Example C-12 Telco Return Example C-14

APPENDIX

D Frequency Allocation for the Cisco uBR7200 Series Universal Broadband Routers D-1

APPENDIX

E Configuration Register Information for the Cisco uBR7200 Series Universal Broadband

Routers E-1

Configuration Bit Meanings E-1

Bits 0–3 E-2 Bit 6 E-3 Bit 7 E-3 Bit 8 E-3 Bit 10 and Bit 14 E-4 Bit 11 and Bit 12 E-4 Bit 13 E-5 Bit 15 E-5

Displaying the Configuration Register While Running Cisco IOS E-5

Displaying the Configuration Register While Running ROM Monitor E-6

Setting the Configuration Register While Running Cisco IOS E-6

Setting the Configuration Register While Running ROM Monitor E-7

NDEX

Contents

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-04

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-04

Preface

This preface describes the objectives, intended audience, organization and terminology of this Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide. The Cisco

uBR7200 series CMTS and this guide support the following Cisco IOS release trains:

• 12.3 BC

• 12.2 BC

• 12.1 EC

• 12.0 SC

For additional supported Cisco IOS release trains, refer to Cisco uBR7200 Series Software Release Notes on Cisco.com.

Document Revision History

The Document Revision History table below records technical changes to this document.

Ta b l e 1 Document Revision History

Document Objectives

This guide describes configuring, maintaining, and troubleshooting the Cisco uBR7200 series universal broadband routers: the Cisco uBR7223, Cisco uBR7246, and Cisco

uBR7246 VXR. Cisco’s Cable Modem Termination System (CMTS) solutions allow cable companies, Internet service providers (ISPs), and others to allocate channel capacity for Internet access, Virtual Private Network (VPN), and Voice over IP (VoIP) services using a broadband radio frequency (RF) cable plant.

The Cisco uBR7200 series universal broadband routers sustain downstream and upstream traffic to and from two-way Data Over Cable Service Interface Specification (DOCSIS)-based cable modems (CMs) that support 6 MHz National Television Systems Committee (NTSC) operations. For NTSC cable plants not upgraded for full two-way operations, the routers also support DOCSIS-compliant telco-return CMs. For international cable companies using 8 MHz channel widths, the Cisco

uBR7200 series equipment supports Phase Alternating Line (PAL) and Systeme Electronique Couleur Avec Memoire (SECAM) channel plans to operate with EuroDOCSIS-based CMs and set

top box (STB) units with integrated

EuroDOCSIS modems.

Document Revision

Date Change Summary

OL-2239-04 September 30, 2005 Incorporated new features and enhancements introduced in

Cisco IOS Release 12.3(13a)BC. Added Document Revision History table.

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-04

Preface

Audience

This guide is intended for system administrators and support engineers who configure and maintain the Cisco

uBR7200 series. Many different delivery models exist for Cisco uBR7200 series equipment:

• In smaller networks, a single service provider manages all equipment and infrastructure.

• In larger networks, multiple service operators (MSOs) and ISPs share responsibility for provisioning

and managing the cable plant and IP network.

The MSO and ISP divide responsibilities according to the service model. In some cases, the MSO maintains and operates the cable plant and attached CMs and STBs, whereas the ISP owns, operates, and maintains the regional network and IP infrastructure beyond the cable distribution hub. In other cases, the CMTS and RF customer premises equipment (CPE) are viewed as part of the networking infrastructure, and the ISP maintains control for provisioning and managing DOCSIS functionality.

Note This guide considers the MSO and ISP as a single service principle with responsibility to provision and

manage DOCSIS-based cable modems and set-top boxes (STBs). This guide assumes that administrators are familiar with Cisco

uBR7200 series hardware, DOCSIS or EuroDOCSIS requirements, and

networking.

Document Organization

This guide focuses on configuration of Cisco IOS software for the Cisco uBR7200 series. Tab l e 2 summarizes the chapters and procedures in this guide.

Ta b l e 2 Guide Contents and Organization

Title Description

Chapter 1, “Overview of Cisco uBR7200 Series Software”

Acquaints you with the supported Cisco IOS features and configuration.

Chapter 2, “Configuring the Cable Modem Termination System for the First Time”

Provides instructions to make basic configurations to the Cisco uBR7200 series cable modem termination system (CMTS) using AutoInstall, the Setup facility, Extended Setup, or manual configuration mode. Includes sample Cisco

uBR7200 series software configurations.

Note Complete the configurations in this chapter prior to attempting additional

configurations later in this guide or elsewhere.

Chapter 3, “Configuring Cable Modem Interface Features”

Provides instructions for required cable modem interface configurations for upstream and downstream interfaces.

Chapter 4, “Configuring DOCSIS Baseline Privacy Interface on the Cisco uBR7200 Series”

Provides an overview of DOCSIS 1.0 Baseline Privacy Interface (BPI), instructions for enabling BPI, and an introduction to DOCSIS 1.1 BPI+ features.

Chapter 5, “Managing Cable Modems on the Hybrid Fiber-Coaxial Network”

After completing upstream and downstream cable modem interface configurations, this chapter provides a number of procedures that you can implement in order to manage operations of your cable modems in the hybrid fiber-coaxial network.

Chapter 6, “Configuring Basic Broadband Internet Access”

Provides a recommended basic configuration for high-speed Internet access and a basic Internet access sample configuration file.

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-04

Preface

Conventions

This guide uses the following conventions for command syntax descriptions and textual emphasis:

Chapter 7, “Overview of the Cisco Network Registrar for the Cisco uBR7200 Series”

Supplements the Cisco Network Registrar (CNR) documentation by providing additional cable-specific instructions that are pertinent to the Cisco

uBR7200 series and CMTS management.

Chapter 8, “Troubleshooting the System” Provides troubleshooting instructions for the configuration of the

Cisco

uBR7200 series CMTS.

Appendix A, “Installing or Upgrading Cisco IOS Software”

Explains how to install Cisco IOS software onto "Run from RAM" Cisco routers using a TFTP server or remote copy protocol (rcp) server application.

Appendix B, “Resolving Common Image Installation Problems”

Explains the resolution to common installation problems when installing images using TFTP or an rcp server.

Appendix C, “Viewing Sample Configuration Files”

Provides examples of Cisco uBR7200 series universal broadband router configuration files.

Appendix D, “Frequency Allocation for the Cisco uBR7200 Series Universal Broadband Routers”

Provides information on NTSC 6-MHz, Phase Alternating Line (PAL) and Systeme Electronique Couleur Avec Memoire (SECAM) 8-MHz channel bands.

Appendix E, “Configuration Register Information for the Cisco uBR7200 Series Universal Broadband Routers”

Provides information about the functions and configuration of bits in the Cisco IOS Software Configuration Register.

Index Index for the entire manual.

Table 2 Guide Contents and Organization (continued)

Title Description

Ta b l e 3 Command Syntax and Emphasis Conventions

Convention Description

boldface font Commands and keywords are in boldface.

italic font Arguments for which you supply values are in italics.

[ ] Elements in square brackets are optional.

{x | y | z} Alternative, mutually exclusive, keywords are grouped in braces and

separated by vertical bars.

[x | y | z] Optional alternative keywords are grouped in brackets and separated by

vertical bars.

string A nonquoted set of characters. Do not use quotation marks around the string

or the string will include the quotation marks.

screen font Terminal sessions and information the system displays are in screen font.

boldface screen font Information you must enter is in boldface screen font.

italic screen font Arguments for which you supply values are in italic screen font.

^ The symbol ^ represents the key labeled Control—for example, the key

combination ^D in a screen display means hold down the Control key while you press the D key.

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-04

Preface

Terms and Acronyms

Note This symbol means reader take note. Notes contain helpful suggestions or references to material not

covered in the publication.

Tip This symbol means the following are useful tips.

Timesaver This symbol means the described action saves time. You can save time by performing the action

described in the paragraph.

Caution This symbol means reader be careful. In this situation, you might do something that could result in

equipment damage or loss of data.

Terms and Acronyms

A complete list of terms and acronyms is available in the Internetworking Terms and Acronyms guide, available on the Documentation CD-ROM.

To fully understand the content of this guide, you should be familiar with the following terms and acronyms.

• A/D—analog to digital (conversion)

• ABR—available bit rate

• AAL5—ATM adaptation layer 5

• AGC—automatic gain control

• AM-VSB—Amplitude Modulation - Vestigial Side Band (Modulation scheme)

• ASIC—Application Specific Integrated Circuit

• AWG—American wire gauge

• BGP—Border Gateway Protocol

• BPI—Baseline Privacy Interface

• CATV—cable television

• CM—cable modem

• CMTS—cable modem termination system (headend)

• CoS—class of service

< > Nonprinting characters, such as passwords, are in angle brackets in contexts

where italics are not available.

[ ] Default responses to system prompts are in square brackets.

!, # An exclamation point ( ! ) or a pound sign ( # ) at the beginning of a line of

code indicates a comment line.

Table 3 Command Syntax and Emphasis Conventions (continued)

Convention Description

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-04

Preface

Terms and Acronyms

• CPE—customer premises equipment

• CPR—Centralized Priority Reservation

• CRC—cyclic redundancy check

• CSU—channel service unit

• CTS—Clear To Send

• D/A—digital to analog (conversion)

• DAVIC —Digital Audio-Visual Council

• DCD—Data Carrier Detect

• DCE—data communications equipment

• DDS—Direct Digital Synthesis

• DES—Data Encryption Standard

• DHCP—Dynamic Host Configuration Protocol

• DOCSIS—Data-over-Cable Service Interface Specification

• DVB—Digital Video Broadcasting

• DIMM—dual in-line memory module

• DSR—data set ready

• DSU—data service unit

• DTE—data terminal equipment

• DTR—data terminal ready

• ESP—Electronic Systems Products

• EMC—electromagnetic compliance

• EMI—electromagnetic interference

• ESD—electrostatic discharge

• EuroDOCSIS—European DOCSIS (Data-over-Cable Service Interface Specification)

• FCS—Frame Check Sequence; First Customer Shipment

• FDR—Final Design Review

• FEC—Forward Error Correction

• FRU—field-replaceable unit (router components that do not require replacement by a service

provider certified by Cisco)

• FTP—foil twisted-pair

• HCCP—Hot Standby CMTS-to-CMTS Protocol

• HDLC—High-Level Data Link Control

• HEAD—Head-end Modulator and Demodulator

• HEM—Head End Modem

• HFC—Hybrid Fiber Coax

• HOME—Subscriber Unit

• HS—Head-end Shelf

• HSRP—Hot-Standby Router Protocol

• IP—Internet Protocol

• IPSec—IP Security Protocol

• ISL—Inter-Switch Link protocol

• ISS—Instruction Set Simulator

• Kbps—kilo-bits per second

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-04

Preface

Terms and Acronyms

• LAN—local area network

• LCN—logical channel number

• LED—light emitting diode

• LLC—logical link control

• MAC—Media Access Control

• MB—megabyte

• Mbps—mega-bits per second

• MM—multimode

• MODEM—modulator/demodulator

• MPEG-2—Moving Picture Experts Group (Specification 2)

• MPEG-2-TS—MPEG-2 Transport Stream

• MSN—manufacturer serial number

• MSO—multiple systems operator

• NIU/STB—network interface unit/set-top box

• nrt-VBR—non-real-time variable bit rate

• NTSC—National Television Standards Committee

• NVRAM—nonvolatile random-access memory

• OAM AIS—Operation, Administration, and Maintenance alarm indication signal

• OAM&P—Operations, Administration, Maintenance and Provisioning

• OC3—Optical Carrier Level 3

• OIR—online insertion and removal

• PCI—Peripheral Component Interconnect

• PCMCIA—Personal Computer Memory Card International Association

• PDD—Project Design Document

• PHY—Physical Layer Interface

• PID—Packet Identifier

• PLL—Phase Locked Loop

• PPP—Point-to-Point Protocol

• QAM—Quadrature Amplitude Modulation

• QoS—quality of service

• QPSK—Quadrature Phase Shift Keying

• rcp—remote copy protocol

• RFI—radio frequency interference

• RIP—Routing Information Protocol

• RISC—Reduced Instruction Set Computer

• RTP—Real-Time Transport Protocol

• RTS—Request To Send

• SDRAM—synchronous dynamic random-access memory

• SIMM—single in-line memory module

• SM—Subscriber Modem or Spectrum Manager

• SMI—single-mode intermediate reach

• SNMP—Simple Network Management Protocol

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-04

Preface

Related Cisco IOS Release Documentation

For detailed Cisco IOS software configuration information and support, refer to the configuration and command reference publications on these web pages:

• Cisco IOS Release 12.1 Documentation

• Cisco IOS Release 12.2 Documentation

• To query Cisco IOS releases according to feature or release number, refer to the Cisco IOS Feature

Navigator (Cisco.com login ID and password required). Obtaining Documentation and Submitting

a Service Request

For information on obtaining documentation, submitting a service request, and gathering additional information, see the monthly What’s

New in Cisco Product Documentation, which also lists all new and

revised Cisco

technical documentation, at:

http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html

Subscribe to the What’s New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed and set content to be delivered directly to your desktop using a reader application. The RSS feeds are a free service and Cisco currently supports RSS

Ve r si o n 2.0.

Document Title Online Location

Cable DOCSIS 1.1 FAQs http://www.cisco.com/en/US/tech/tk86/tk168/te

chnologies_q_and_a_item09186a0080174789.s html

Cisco Cable Modem Termination System Feature Guide

http://www.cisco.com/en/US/docs/cable/cmts/f eature/guide/cmtsfg.html

Cisco IOS CMTS Cable Command Reference Guide http://www.cisco.com/en/US/docs/ios/cable/co

mmand/reference/cbl_book.html

Cisco IOS Multiservice Applications Configuration Guide:

• Configuring Headend Broadband Access Router

Features

• Configuring Subscriber-End Broadband

Access Router Features

http://www.cisco.com/en/US/docs/ios/12_1/mu ltiserv/configuration/guide/multi_c.html

DOCSIS 1.1 for the Cisco uBR7200 Series Universal Broadband Routers

http://www.cisco.com/en/US/docs/cable/cmts/f eature/DOCSIS11.html

CHAP T E R

1-1

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-05

Overview of Cisco uBR7200 Series Software

The Cisco uBR7200 series uses Cisco IOS® software to offer enhanced stability, features, performance and investment protection. This chapter summarizes system and software features of the Cisco uBR7200 series Cable Modem Termination System (CMTS). This chapter contains the following sections:

Section Purpose

“Cisco IOS Releases and Images for the Cisco uBR7200 Series,” page 2

Describes the supported Cisco IOS release trains, associated features, and latest Cisco IOS images for each recently supported train.

One early step in CMTS feature configuration is to verify your Cisco IOS release train, the associated image and feature set. This section guides you in determining such information.

“Cisco uBR7200 Series Chassis Overview,” page 8

Describes the Cisco uBR7200 series routers, and their supported hardware features and interoperability.

“Cisco uBR7200 Series Router Configuration Overview,” page 15

Provides an overview of the hardware and interfaces that typically require configuration through Cisco IOS software.

“Supported Software Features for the Cisco uBR7200 Series,” page 22

Describes the features and configuration utilities that are available on the Cisco

uBR7200 series.

“DOCSIS and CMTS Interoperability,”

page 137

Provides an overview of DOCSIS NTSC and EuroDOCSIS cable plants, DOCSIS-compliant signals, and traffic engineering.

1-2

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-05

Chapter 1 Overview of Cisco uBR7200 Series Software

Cisco IOS Releases and Images for the Cisco uBR7200 Series

This section describes the supported releases, latest images, memory requirements, and major software features for the following Cisco IOS software:

• Determining Your Cisco IOS Software Release

• Upgrading to a New Software Release

• 12.3 BC Release Train Images and Requirements

• 12.2 BC Release Train Images and Requirements

• 12.2 CX Images and Requirements

• 12.1 EC Images and Requirements

To configure the CMTS for the first time, refer to Chapter 2, “Configuring the Cable Modem

Termination System for the First Time.”

For additional release information, refer to the Cisco uBR7200 Series Software Release Notes on Cisco.com:

http://www.cisco.com/en/US/docs/cable/cmts/ubr7200/release/notes/12_3bc/123BCu72.html

Determining Your Cisco IOS Software Release

To determine the version of Cisco IOS software running on the Cisco uBR7200 series universal broadband router, log in to the router and enter the show version command in User or privileged EXEC mode.

Router> show version

Cisco Internetwork Operating System Software IOS (tm) Cisco IOS 12.2 BC Software (ubr7200-is-mz), Version Cisco IOS Release 12.2(4)BC1, RELEASE SOFTWARE

Note Your display may vary according to your release and image.

Upgrading to a New Software Release

An upgrade is an order placed for a Cisco IOS feature set that contains more functionality than the feature set that you are replacing. An upgrade is not an “update.” An update consists of installing a more recent version of the same feature set.

• Exception—If a feature set has been made obsolete, the next closest feature set on a more recent

release is considered an update.

For general information about upgrading to a new software release, refer to the Cisco IOS Upgrade

Ordering Instructions on Cisco.com. Also refer to Appendix A, “Installing or Upgrading Cisco IOS

Software.”

1-3

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-05

Chapter 1 Overview of Cisco uBR7200 Series Software

Cisco IOS Releases and Images for the Cisco uBR7200 Series

12.3 BC Release Train Images and Requirements

The Cisco 12.3 BC release train is the latest Cisco IOS release train to support the Cisco uBR7200 Series, and emphasizes additional features and performance specifically for the Cisco uBR7246VXR universal broadband router.

Table 1-2 displays the memory recommendations of the Cisco IOS feature sets for the

Cisco uBR7200 series universal broadband routers for Cisco IOS Release 12.3(9a)BC. Cisco

uBR7200 series routers are only available with a 48 MB or 128 MB of Flash disk memory on the

I/O Controller cards. The UBR7200-NPE-G1 uses compact Flash disk only.

Note Flash disks, an alternative to linear Flash memory, are Flash memory-based devices that can be used as

file storage media in the PCMCIA card slots of the I/O Controllers. Each I/O Controller has two PCMCIA slots and can be configured with up to 256 MB of Flash disk memory.

The image subset legend for Tab l e 1-2 is as follows:

• i = IP routing, MPLS-VPN support, and non-cable interface bridging, including Network Address

Translation (NAT)

• k8 = DOCSIS Baseline Privacy

• p = IP routing with Intermediate System-to-Intermediate System (IS-IS) and Border Gateway

Protocol (BGP); MPLS-VPN support; no bridging and no NAT

• s = “Plus” features: NAT and Inter-Switch Link (ISL)

• k9 = 3DES level of encryption

Note All images support all of the hardware listed in the “Supported Hardware on the Cisco uBR7200 Series”

section on page 1-11, unless otherwise indicated.

Note A Cisco uBR7200 series router requires 256 MB of DRAM memory on the NPE processor card when

HCCP redundancy is configured and the router is supporting more than 3,000 cable modems. Using less memory in these conditions results in temporary out-of-memory situations and incomplete synchronization between the Working and Protect interfaces.

Ta b l e 1 Memory Recommendations for the Cisco uBR7200 Series Routers,

Cisco IOS Release 12.3(9a)BC Feature Sets

Feature Set Software Image

Recommended Flash Memory

Recommended DRAM Memory

Runs From

Two-Way Data/VoIP Images

DOCSIS Two-Way ubr7200-p-mz 32 MB Flash 256 MB DRAM RAM

DOCSIS Two-Way IP Plus ubr7200-is-mz 32 MB Flash 256 MB DRAM RAM

DOCSIS Two-Way with BPI ubr7200-k8p-mz 32 MB Flash 256 MB DRAM RAM

DOCSIS Two-Way IP Plus with BPI ubr7200-ik8s-mz 32 MB Flash 256 MB DRAM RAM

DOCSIS Two-Way 3DES ubr7200-k9p-mz 32 MB Flash 256 MB DRAM RAM

DOCSIS Two-Way 3DES IP Plus ubr7200-ik9s-mz 32 MB Flash 256 MB DRAM RAM

Boot Image

UBR7200 Boot Image ubr7200-kboot-mz None None —

UBR7200 Boot Image ubr7200-boot-mz None None —

1-4

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-05

Chapter 1 Overview of Cisco uBR7200 Series Software

Cisco IOS Releases and Images for the Cisco uBR7200 Series

12.2 BC Release Train Images and Requirements

Note Cisco IOS release 12.2(4)BC1 offers certified DOCSIS 1.1 support on the Cisco uBR7246 VXR router.

The 12.2 BC train is an interim release train that provides certified DOCSIS 1.1 two-way support on the Cisco uBR7246 VXR universal broadband router, along with support for selected new features. The latest release in this train, Cisco IOS Release 12.2(4)BC1, provides a migration path from the earlier Cisco IOS 12.2 XF releases, which included a subset of the features supported in these Cisco IOS release trains:

• Cisco IOS Release 12.0 SC

• Cisco IOS Release 12.1 EC

• Cisco IOS Release 12.1 CX1

Table 1-2 displays the memory recommendations of the Cisco IOS feature sets for the

Cisco uBR7200 series universal broadband routers for Cisco IOS Release 12.2(15)BC1 and

12.2(15)BC2a. Cisco

uBR7200 series routers are available with 48 MB or 128 MB of Flash disk memory

on the I/O Controller cards. The UBR7200-NPE-G1 uses compact Flash disk only.

Note Flash disks, an alternative to linear Flash memory, are Flash memory-based devices that can be used

as file storage media in the PCMCIA card slots of the I/O Controllers. Each I/O Controller has two PCMCIA slots and can be configured with up to 256 MB of Flash disk memory.

Note Cisco IOS release 12.2(4)BC1and later BC releases offer certified DOCSIS 1.1 support on the Cisco

uBR7246 VXR router.

Ta b l e 1-2 Memory Recommendations for the Cisco uBR7200 Series Routers,

Cisco

IOS Release 12.2(15)BC1 and 12.2(15)BC2a Feature Sets

Feature Set Software Image

Recommended Flash Memory

Recommended DRAM Memory

Runs From

Two-Way Data/VoIP Images

DOCSIS Two-Way ubr7200-p-mz 16 MB Flash

32 MB Flash

1. 32 MB of Flash is required for Cisco IOS Release 12.2(15)BC2a and later releases in the Cisco IOS BC train.

128 MB DRAM RAM

DOCSIS Two-Way IP Plus ubr7200-is-mz 16 MB Flash

32 MB Flash

128 MB DRAM RAM

DOCSIS Two-Way with BPI ubr7200-k8p-mz 16 MB Flash

32 MB Flash

128 MB DRAM RAM

DOCSIS Two-Way IP Plus with BPI

ubr7200-ik8s-mz 16 MB Flash

32 MB Flash

128 MB DRAM RAM

DOCSIS Two-Way 3DES ubr7200-k9p-mz 16 MB Flash

32 MB Flash

128 MB DRAM RAM

DOCSIS Two-Way 3DES IP Plus

ubr7200-ik9s-mz 16 MB Flash

32 MB Flash

128 MB DRAM RAM

Boot Image

UBR7200 Boot Image ubr7200-kboot-mz None None —

UBR7200 Boot Image ubr7200-boot-mz None None —

1-5

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-05

Chapter 1 Overview of Cisco uBR7200 Series Software

Cisco IOS Releases and Images for the Cisco uBR7200 Series

The image subset legend for Tab l e 1-2 is as follows:

• i = IP routing, MPLS-VPN support, and non-cable interface bridging, including Network Address

Translation (NAT)

• k8 = DOCSIS Baseline Privacy

• p = IP routing with Intermediate System-to-Intermediate System (IS-IS) and Border Gateway

Protocol (BGP); MPLS-VPN support; no bridging and no NAT

• s = “Plus” features: NAT and Inter-Switch Link (ISL)

• k9 = 3DES level of encryption

Note All images support all of the hardware listed in the “Supported Hardware on the Cisco uBR7200

Series” section on page 1-11, unless otherwise indicated.

Note A Cisco uBR7200 series router requires 256 MB of DRAM memory on the NPE processor card when

12.2 CX Images and Requirements

The 12.2 CX releases are based on Cisco IOS Release 12.2(15)BC1, which is a child of Cisco IOS Release

12.2(15)T. The 12.2 BC train is an interim release train that provides DOCSIS 1.1 two-way

support, along with fixes for software caveats and support for selected new features.

The latest image in the 12.2 CX release train, Cisco IOS Release 12.2(15)CX1, provides two different boot images for the Cisco uBR7200 series routers:

• ubr7200-kboot-mz.122-15.CX.bin

The "kboot" version of the boot image is a new version of the boot image software that can run only on the Cisco uBR7200-NPE-G1 processor and the UBR7200-I/O-2FE/E I/O controller, because it is too large to load on the other I/O controllers. This image contains support for almost all supported port adapters, allowing the Cisco uBR7246VXR router to boot over almost any type of WAN interface.

• ubr7200-boot-mz.122-15.CX.bin

The "boot" version of the boot image is small enough to be loaded on I/O controllers with 4MB of Flash memory, but it supports only Ethernet, FastEthernet, Gigabit Ethernet, OC POS, and a limited number of ATM port adapters. If you are using a serial port adapter or most ATM port adapters, you will not be able to boot over the WAN interface.

This difference in boot images affects only the ability of the Cisco uBR7246VXR router to boot over the WAN interface. When the router has successfully loaded the Cisco IOS software, it has connectivity over all of the port adapters that this particular version of Cisco IOS software supports.

Table 1-3 displays the memory recommendations of the Cisco IOS feature sets for the Cisco uBR7200

series universal broadband routers for Cisco IOS Release 12.2(15)CX1. Cisco uBR7200 series routers are only available with a 48 MB or 128 MB of Flash disk memory on the I/O Controller cards. The UBR7200-NPE-G1 uses only compact Flash disk.

1-6

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-05

Chapter 1 Overview of Cisco uBR7200 Series Software

Cisco IOS Releases and Images for the Cisco uBR7200 Series

Flash disks, an alternative to linear Flash memory, are Flash memory-based devices that can be used as file storage media in the PCMCIA card slots of the I/O Controllers. Each I/O Controller has two PCMCIA slots and can be configured with up to 256 MB of Flash disk memory.

The image subset legend for Tab l e 1-3 is as follows:

• i = IP routing, MPLS-VPN support, and non-cable interface bridging, including Network Address

Translation (NAT)

• k8 = DOCSIS Baseline Privacy

• p = IP routing with Intermediate System-to-Intermediate System (IS-IS) and Border Gateway

Protocol (BGP); MPLS-VPN support; no bridging and no NAT

• s = "Plus" features: NAT and Inter-Switch Link (ISL)

• k9 = 3DES level of encryption

Ta b l e 1-3 Memory Recommendations for the Cisco uBR7200 Series Routers,

Cisco

Release 12.2(15)CX1 Feature Sets

Feature Set Software Image

Recommended Flash Disk Memory

Recommended DRAM Memory

Runs From

Two-Way Data/VoIP Images

DOCSIS Two-Way ubr7200-p-mz 48 MB Flash 128 MB DRAM RAM

DOCSIS Two-Way IP Plus ubr7200-is-mz 48 MB Flash 128 MB DRAM RAM

DOCSIS Two-Way with BPI ubr7200-k8p-mz 48 MB Flash 128 MB DRAM RAM

DOCSIS Two-Way IP Plus with BPI ubr7200-ik8s-mz 48 MB Flash 128 MB DRAM RAM

DOCSIS Two-Way 3DES ubr7200-k9p-mz 48 MB Flash 128 MB DRAM

DOCSIS Two-Way 3DES IP Plus ubr7200-ik9s-mz 48 MB Flash 128 MB DRAM

1-7

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-05

Chapter 1 Overview of Cisco uBR7200 Series Software

Cisco IOS Releases and Images for the Cisco uBR7200 Series

12.1 EC Images and Requirements

The 12.1 EC train is the Cisco cable-specific early deployment release train that introduces several new feature sets, support for the Cisco uBR-MC28C cable interface line card, and several new software features.

Table 4 displays the memory recommendations of the Cisco IOS feature sets for the

Cisco uBR7200 series universal broadband routers for the latest Cisco IOS Release 12.1(20)EC1. Cisco

uBR7200 series routers support a 16-MB or 20-MB Type II PCMCIA Flash memory card.

The image subset legend for Tab l e 4 is as follows:

• i = IP routing, MPLS-VPN support, and non-cable interface bridging, including Network Address

Translation (NAT)

• k1 = DOCSIS Baseline Privacy and MPLS-VPN support

• p = IP routing with Intermediate System-to-Intermediate System (IS-IS) and Border Gateway

Protocol (BGP); MPLS-VPN support; no bridging and no NAT

• s = “Plus” features: NAT and Inter-Switch Link (ISL)

• t = DOCSIS telco return

Note All images support all of the hardware listed in the section “Supported Hardware on the

Cisco uBR7200 Series” section on page 1-11, unless otherwise indicated.

Ta b l e 4 Memory Recommendations for the Cisco uBR7200 Series Routers,

Cisco Release 12.1(20)EC1 Feature Sets

Feature Set Software Image

Recommended Flash Memory

Recommended DRAM Memory

Runs From

Two-Way Data/VoIP Images

DOCSIS Two-Way ubr7200-p-mz 16 MB Flash 128 MB DRAM RAM

DOCSIS Two-Way IP Plus ubr7200-is-mz 16 MB Flash 128 MB DRAM RAM

DOCSIS Two-Way with BPI ubr7200-k1p-mz 16 MB Flash 128 MB DRAM RAM

DOCSIS Two-Way IP Plus with BPI

ubr7200-ik1s-mz 16 MB Flash 128 MB DRAM RAM

Telco-Return Images

DOCSIS IP Plus Telco Return ubr7200-ist-mz 16 MB Flash 128 MB DRAM RAM

DOCSIS IP Plus Telco Return with BPI

ubr7200-ik1st-mz 16 MB Flash 128 MB DRAM RAM

Boot Image

UBR7200 Boot Image

1. The 12.1 EC UBR7200 boot image is provided for the IUBR7200-I/O-2FE/E input/output controller, which must use the Cisco

IOS 12.1(10)EC1 or later 12.1 EC release boot image. This image cannot be used on any other I/O controllers.

ubr7200-boot-mz None None —

1-8

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-05

Chapter 1 Overview of Cisco uBR7200 Series Software

Cisco uBR7200 Series Chassis Overview

The Cisco uBR7200 series universal broadband routers allow high-speed data services to be packaged similar to cable TV service or video fare. Cisco uBR7200 Series equipment supports data and digitized voice connectivity between Internet Protocol (IP) hosts and connected subscribers using a bidirectional cable TV and IP backbone.

Note For 6 MHz National Television Systems Committee (NTSC) cable plants not fully upgraded to two-way

transmission, the equipment works with dial-up access products to support upstream traffic from Data-over-Cable Service Interface Specification (DOCSIS)-based telco-return cable

interfaces.

For international cable plants that use 8-MHz Phase Alternating Line (PAL) or Systeme Electronique Couleur Avec Memoire (SECAM) channel plans, Cisco uBR7200 Series equipment supports bidirectional transfer of traffic between the Cable

Modem Termination System (CMTS) and

EuroDOCSIS-based CMs or set top box (STB) units with integrated EuroDOCSIS modems.

Cable companies and Internet service providers (ISPs) can allocate radio frequency (RF) channel capacity for Internet access, Virtual Private Network (VPN), or Voice over IP (VoIP) services using a hybrid fiber/coax (HFC) or all-coax cable

plant. Cisco currently provides three router-based DOCSIS

CMTS solutions that offer a wider feature set and better manageability than bridge-based systems.

• Cisco uBR7246 VXR Universal Broadband Router—Supports higher density and broad media

configurations; the chassis contains up to two single-width IP backbone interfaces, up to four cable TV RF interfaces, up to two power supplies, an optional clock interface that enables the router to synchronize to an external timing reference, a faster processor, and higher bus bandwidth.

• Cisco uBR7246 Universal Broadband Router—Supports large cable installations; the chassis

contains up to two single-width IP backbone interfaces, up to four cable TV RF interfaces, and up to two power supplies.

• Cisco uBR7223 Universal Broadband Router—Supports small-to-medium cable installations; the

chassis contains one single-width IP backbone interface and up to two cable TV RF interfaces.

Note This guide focuses on Cisco uBR7200 Series software. For detailed descriptions of Cisco uBR7200

Series chassis and components, refer to the

Cisco uBR7200 Series Hardware Installation Guide and

appropriate field replaceable unit (FRU) documents on Cisco.com.

Cisco cable interface line cards serve as the RF cable TV interfaces, supporting downstream and upstream signal combining and splitting arrangements. The cards currently require external upconverters to connect to the cable system. Cisco port adapters connect to the IP backbone and external networks. Your cable plant, combined with your planned and installed subscriber base, service offering, and external network connections, determine the Cisco uBR7200 Series chassis, cable interface line cards, port adapters, and other components you use.

Data is modulated or demodulated using either of the following two methods:

• Downstream 6 MHz channels in the 54-to-860 MHz range with upstream ranges of 5 to 42 MHz.

Cisco MC11 FPGA, MC11C, MC12C, MC14C, MC16B, MC16C, and MC16S cable interface line cards support NTSC channel operation, using standard (STD), Harmonic Related Carrier (HRC), or Incremental Related Carrier (IRC) frequency plans conforming to EIA-S542.

NTSC uses a 6 MHz-wide modulated signal with an interlaced format of 25 frames per second and 525 lines per frame. NTSC is compatible with CCIR Standard M.

PAL, used in West Germany,

England, Holland, Australia, and several other countries.

1-9

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-05

Chapter 1 Overview of Cisco uBR7200 Series Software

Cisco uBR7200 Series Chassis Overview

Note Cisco 6 MHz products can be used in 8 MHz cable plants. The products, however, operate at a

maximum downstream bandwidth of 27 Mbps, ignoring 2 MHz of available channel width, and limiting upstream channel choices to the range below 42 MHz.

• Downstream 8 MHz channels in the 85-to-860 MHz range with an upstream range of 5 to 65 MHz.

The Cisco MC16E cable interface line card supports PAL and SECAM channel plans using an 8

MHz modulated signal.

PAL uses a 625-line scan picture delivered at 25 frames per second where the color carrier phase definition changes in alternate scan lines. SECAM uses an 819 line scan picture that provides better resolution than PAL's 625-line and NTSC's 525-line.

The MC16E uses the EuroDOCSIS J.112 (Annex A) standard, CableLabs ECR RFI-R-98036, which is similar to the Digital Audio Video Council/Digital Video Broadcast (DAVIC/DVB) ITU

J.83

Annex

A physical layer. Cable companies can support data, voice, and video services with

DOCSIS-based CMs or set top boxes (STBs) that contain integrated EuroDOCSIS modems.

Caution The MC16E supports only Annex A operation and should not be used in production cable plants that

support a 6 MHz channel plan.

Note The difference between DOCSIS and EuroDOCSIS is at the physical layer. EuroDOCSIS support

requires the Cisco MC16E cable interface line card, appropriate upconverters that support an 8

MHz

PAL or SECAM channel plan, appropriate diplex filters, and EuroDOCSIS-based CMs or STBs.

The DOCSIS Radio Frequency (RF) specification defines the RF communication paths between the CMTS and CMs (or CMs in STBs). The DOCSIS RF specification defines the physical, link, and network layer aspects of the communication interfaces. It includes specifications for power level, frequency, modulation, coding, multiplexing, and contention control. Cisco offers products that support all DOCSIS error correction encoding and modulation types and formats, and that support DOCSIS Annex B or EuroDOCSIS Annex A operations.

Cisco uBR7200 Series Universal Broadband Routers

The Cisco uBR7200 series universal broadband routers are based on the Data-over-Cable Service Interface Specification (DOCSIS) standards. Each is designed to be installed at a cable operator's headend facility or distribution hub and to function as the cable modem termination system (CMTS) for subscriber-end devices such as the Cisco uBR905 and Cisco uBR925 cable access routers, and other DOCSIS-compliant CMs and set-top boxes (STBs).

Cisco uBR7200 series universal broadband routers allow two-way transmission of digital data and Voice over IP (VoIP) traffic over a hybrid fiber-coaxial (HFC) network. For cable plants not fully upgraded to support two-way cable transmission, the routers support DOCSIS-compliant telco return, where the cable modem's return path to the CMTS uses a dial-up telephone line connection instead of an upstream channel over the coaxial cable. The telco-return delivery mechanism enables cable operators to accelerate deployment of high-speed data services before the cable systems are upgraded to two-way plants.

The Cisco uBR7200 series routers support IP routing with a wide variety of protocols and combinations of Ethernet, Fast Ethernet, Gigabit Ethernet, serial, High-Speed Serial Interface (HSSI), Packet over SONET (POS) OC-3 and OC-12c, and Asynchronous Transfer Mode (ATM) media.

1-10

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-05

Chapter 1 Overview of Cisco uBR7200 Series Software

Cisco uBR7200 Series Chassis Overview

Cisco uBR7246 VXR Universal Broadband Router

The Cisco uBR7246VXR offers an industry-proven CMTS and carrier-class router in a scalable platform with a high-performance network processing engine to support data, voice, and video services for medium to large network installations.

The Cisco uBR7246 VXR provides the following major hardware features:

• High-performance network processing engine or network services engine

• I/O controller

• Up to two network interface port adapters

• Up to four cable interface line cards

• Up to two removable power supplies providing load-sharing and redundancy capabilities

• Two Personal Computer Memory Card International Association (PCMCIA) slots that allow for

software upgrades through the use of Flash memory cards

Note The Cisco uBR7246 VXR chassis does not support the MC11-FPGA cable interface line card.

Cisco uBR7246 Universal Broadband Router

The Cisco uBR7246 offers an industry-proven CMTS and carrier-class router in a scalable platform to support data, voice, and video services for medium to large network installations. The Cisco uBR7246 provides the following major hardware features:

• Network processing engine

• I/O controller

• Up to two network interface port adapters

• Up to four cable interface line cards

• Up to two removable power supplies providing load-sharing and redundancy capabilities

• Two PCMCIA slots that allow for software upgrades through the use of Flash memory cards

Cisco uBR7223 Universal Broadband Router

The Cisco uBR7223 is a cost-effective, scalable interface between subscriber CMs and the backbone data network, and is designed specifically for small to medium network installations.

The Cisco uBR7223 provides the following major hardware features:

• Network processing engine

• I/O controller

• One network interface port adapter

• Up to two cable interface line cards

• One removable power supply (The Cisco uBR7223 does not feature load-sharing and redundant

power supply capability like the Cisco uBR7246 VXR and Cisco uBR7246.)

• Two PCMCIA slots that allow for software upgrades through the use of Flash memory cards

1-11

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-05

Chapter 1 Overview of Cisco uBR7200 Series Software

Cisco uBR7200 Series Chassis Overview

Supported Hardware on the Cisco uBR7200 Series

Tabl e 1-5 provides a quick overview of the major hardware features of the Cisco uBR7200 series routers.

Note Earlier release notes stated that the NPE-175 was also supported on the Cisco uBR7200 series routers.

Because the NPE-175 has reached its end of life and was never made available for order on the Cisco uBR7200 series routers, it has been removed from the table.

The UBR7200-NPE-G1 does not require that an I/O controller be installed. Refer to the Cisco uBR7200 Series Software Release Notes on Cisco.com:

http://www.cisco.com/en/US/docs/cable/cmts/ubr7200/release/notes/12_3bc/123BCu72.html

Network Processing Engines

The Cisco uBR7246 VXR supports the following Network Processing Engines (NPEs):

• UBR7200-NPE-G1

• NPE-225

• NPE-300

• NPE-400

The Cisco uBR7223 and the Cisco uBR7246 support the following Network Processing Engines (NPE) :

• NPE-150

• NPE-200

• NPE-225

Note The NPE-300 and NPE-400 are not supported on the Cisco uBR7223 and the Cisco uBR7246. The

NPE-150 and NPE-200 are not supported on the Cisco uBR7246 VXR.

Ta b l e 1-5 Cisco uBR7200 Series Hardware Overview

Supported Hardware Cisco uBR7246 VXR Cisco uBR7246 Cisco uBR7223

Network Processing Engines One of the following:

• UBR7200-NPE-G1

• NPE-225

• NPE-300

• NPE-400

One of the following:

• NPE-150

• NPE-200

• NPE-225

One of the following:

• NPE-150

• NPE-200

• NPE-225

I/O Controllers One of the following:

• UBR7200-I/O

• UBR7200-I/O-FE

• UBR7200-I/O-2FE/E

One of the following:

• UBR7200-I/O

• UBR7200-I/O-FE

One of the following:

• UBR7200-I/O

• UBR7200-I/O-FE

Network Interface Port Adapters Up to two Up to two One

Cable Interface Line Cards Up to four Up to four Up to four

Removable Power Supplies Up to two Up to two One

PCMCIA Slots Two Two Two

1-12

Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

OL-2239-05

Chapter 1 Overview of Cisco uBR7200 Series Software

Cisco uBR7200 Series Chassis Overview

For more information, refer to the following resources on Cisco.com:

• Network Processing Engine and Network Services Engine Installation and Configuration Guide

• Memory Replacement Instructions for the Network Processing Engine or Network Services Engine and

Input/Output Controller

I/O Controllers

The Cisco uBR7200 series universal broadband routers support the following input/output (I/O) controllers:

• UBR7200-I/O-2FE/E input/output controller

–

Features two Fast Ethernet ports and one Ethernet port.

–

Equipped with 2 RJ-45 receptacles for 10/100 Mbps operation.

–

Supported for the Cisco uBR7246VXR router.

–

The Cisco IOS Release 12.1(10)EC boot helper image [ubr7200-boot-mz.12.1-10.EC] must be used on this controlle.r

• UBR7200-I/O-FE

–

Features one Fast Ethernet port.

–

Equipped with an MII receptacle and an RJ-45 receptacle for use at 100 Mbps full-duplex or half-duplex operation.

–

Only one receptacle can be configured for use at a time.

–

Supported for Cisco uBR7223, Cisco uBR7246, and Cisco uBR7246 VXR routers.

–

The 12.0(15)SC [ubr7200-boot-mz.12.0-15.SC] boot helper image is recommended for this controller.

• UBR7200-I/O

–

Has no Fast Ethernet port.

–

Supported for Cisco uBR7223, Cisco uBR7246, and Cisco uBR7246 VXR routers.

–

The 12.0(15)SC [ubr7200-boot-mz.12.0-15.SC] boot helper image is recommended for this controller.

Note The Single-Port Fast Ethernet I/O Controller (UBR7200-I/O-FE) reached its End of Sale (EOS) point

on June 30, 2003. For details, see the Addendum to Product Bulletin, No. 1725, available at the following location on Cisco.com:

http://www.cisco.com/en/US/products/hw/cable/ps2217/prod_eol_notice09186a00800a470d.html

Note Do not use the 12.1(10)EC boot helper image with the UBR7200-I/O-FE and UBR7200-I/O

controllers.

+ 294 hidden pages

Cisco 7246VXR - uBR Router, UBR7223 - uBR 7223 Modular Expansion Base, uBR7200 Series Software Configuration Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
