TELEPRESENCE MOVI 4.1 - FOR WINDOWS
User Manual
20 pgs941.69 Kb0

Cisco TELEPRESENCE MOVI 4.1 - FOR WINDOWS, TelePresence Movi 4.1 User Manual

Download
Cisco TelePresence Movi
4.1
User Guide for Windows
D14409.06
January 2011
Table of contents
Microphone 5
Camera 5
Presence status 10
Status messages 10
Setting your status 10
Closing Movi 11
Closing and reopening the control window 11
Signing out 11
Exiting Movi 11
Cisco TelePresence Movi for Windows User Guide (4.1) Page 2 of 20
The pop-up toolbar 12
Selfview and camera control 12
Controlling your camera 12
Using the keypad (DTMF) 13
When to use the keypad 13
How to use the keypad 13
Using the keypad during conferences 13
Presentation sharing 13
How to share 13
What to share 14
The info bar 15
Far-end camera control (FECC) 15
How to control the far-end camera 15
Limitations 16
Joining calls to a conference 17
How to toggle between calls on hold 17
How to join participants to a conference 17
How to end calls on hold 17
Troubleshooting 18
Audio issues 18
Further troubleshooting 18
Conference information 18
Checking for updates and getting help 19
Cisco TelePresence Movi for Windows User Guide (4.1) Page 3 of 20
Getting started
Getting started
Prerequisites
The Movi software client is usually made available to you by your company’s IT administrator.
A web camera, a microphone, and loudspeakers or a headset must be connected to your computer for Movi to work correctly. (See Multimedia device requirements.)
Signing in
Your ITadministrator can automate your sign-in process, and you may not even notice the sign-in screen.
If enabled by your IT administrator, sign-in will be automatic and you may not even notice the sign-in screen. Otherwise, your IT administrator will supply you with a username and password.
Note: Automatic sign-in is not available to users of Mac OS X 10.5.
1. Start by entering your username and password in the sign-in form.
2. Movi will sign you in automatically from now on, unless you de-select Remember my Username, Remember my Password, and Sign in automatically.
3. Click Sign in or press Enter.
Show video window
After you have signed in, Movi displays its control window.
If you want to open your video window before a call to check your camera or your hair, click the Show
video button on the upper right corner of your Movi control window.
You can click the Show video button during a call to bring your video window to the top of your screens.
Making a call
1. In the search field, start typing the name of the person to call.
2. Click the name on the list or use your arrow keys to scroll down.
3. Double-click the name, click or press Enter. A video window will now appear on screen.
There are three more ways to initiate a new call:
1. Click My contacts and select a name from your list. (See Contacts.)
2. Click Recent calls and select a name from that list (See Recent calls)
3. Enter a video address (SIP URI) for a person or an endpoint directly.
Tip: To see your own video address, click the button with your name on it near the top of the Movi control window.
Receiving a call
When someone calls you on Movi, this dialog will appear:
Cisco TelePresence Movi for Windows User Guide (4.1) Page 4 of 20
Getting started
Answer or reject the call by clicking the buttons, or close the dialog using the X to ignore the call without this being visible to the caller.
PC requirements
Processor A processor supporting SSE3 (such as Pentium 4 Prescott) or better. For business-quality HD
video, Cisco recommends using the Cisco PrecisionHD™ USB camera and a 2 GHz Core 2 Duo processor or better.
Memory 512MB RAM or more.
Operating system
Connection IP network connection (broadband, LAN, wireless). At least 24 kbps is required for an audio
Graphics card
Sound card Any standard sound card (full-duplex, 16-bit or better) should work with Movi.
n Windows XP SP2 or later n Windows Vista SP1 or later n Windows 7
connection. For a video connection, the recommended minimum is 128 kbps.
OpenGL version 1.2 or higher. Hardware support for DirectX 8 or higher.
Multimedia device requirements
Microphone
All microphones work well with Movi. Note that some cameras have built-in microphones.
Camera
Movi works with most common web cameras. See the Cisco Knowledge Base for updated information
on Movi and cameras.
Cisco TelePresence Movi for Windows User Guide (4.1) Page 5 of 20
Settings
Settings
Movi comes with predefined settings that should work out of the box for most users.
The Settings button in the Movi control window brings up the Settings dialog.
Remember to store changes to settings by clicking OK when you are done.
Automatic startup
By default Movi starts up when you log on to Windows.
Select the Start Cisco TelePresence Movi at Windows logon check box to change this setting.
Video resolution
The video resolution will always be the highest resolution available to you with the resources available.
If Movi detects that it is using too high a share of your system resources, the resolution will be lowered automatically.
Note: Your IT administrator may limit the video resolution options available to you.
Network
If you experience low video quality, for example jitter, lowering the bandwidth can be helpful.
If you know that more bandwidth than the default setting is available, you may increase the bandwidth setting for better video quality.
Note: Your IT administrator may limit the bandwidth options available to you.
Notifications and ring tone
You can decide when and how Movi shall notify you when calls come through.
To change the ringtone, follow these steps:
1. Use the drop-down menu and select one of the alternatives.
2. Listen to the tone by clicking the Play button. Note that you must stop one ring tone before you can try another.
3. Click OK when you are happy with your selection.
You may also want to tweak the following settings:
Do not play notification when I am busy
You will see the pop up dialog when you have set your status to Busy, but no ring tone will be played. This setting is enabled by default.
Do not play notification when I am in a call
Enable tray icon notifications
Cisco TelePresence Movi for Windows User Guide (4.1) Page 6 of 20
You will see the pop up dialog when you are already in a call, but no ring tone will be played. This setting is disabled by default.
Movi provides "balloon"-style notifications from the systray, for example if you have missed calls. This setting is enabled by default.
Device selection
You may want to use different audio and video devices than those Movi has picked by default. For example, your camera and your PC may both have built-in microphones.
The drop-down lists let you choose from all devices detected on your system:
n Microphones (audio input) n Loudspeakers and/or headphones (audio output) n Cameras (video input)
Settings
Cisco TelePresence Movi for Windows User Guide (4.1) Page 7 of 20
Contacts
Contacts
The My contacts list contains endpoints and Movi users whose video addresses you have stored for quick retrieval and reuse.
Note: The My contacts list, the Recent calls list and your password are stored per Windows user and per Movi account. If there are other user accounts on your computer, they will not have access to your list.
Adding a contact
There are several ways of adding a new contact to the My contacts list. To get started:
1. Use the search field or the Recent calls list to locate a person or endpoint.
2. Select the list entry you want using the mouse or arrow keys. This will make the link Add to my contacts appear.
3. Click Add to my contacts.
4. Enter the name you want for your contact.
5. Click Save or press Enter.
You can also add a video address as a contact directly:
1. Click My contacts.
2. Click Add new contact.
3. Enter the name you want for your contact.
4. Enter the video address (SIP URI).
5. Click Save or press Enter.
Deleting a contact
1. Click My contacts
2. Select the contact you want to delete using the mouse or arrow keys to make the link Edit contact appear.
3. Click Edit contact.
4. Click Delete contact.
Cisco TelePresence Movi for Windows User Guide (4.1) Page 8 of 20
Recent calls
Recent calls
Call information
Recent calls is an overview of your latest outgoing, incoming, and missed calls. You can use the list to redial and to add callers and recipients from the list as contacts.
Note: The list of recent calls is stored per user. If there are other user accounts on your computer, they will not have access to your list.
Each entry in the recent calls list has an icon indicating status:
You made an outgoing call.
You answered an incoming call.
You missed an incoming call.
If you have answered a call from a different Movi installation or endpoint, this will be noted in the list as "Answered elsewhere".
Each list entry also contains information on:
n Date and time of call n Call duration (click on each entry to display) n Video address of the caller (incoming) or the recipient (outgoing)
Deleting call information
To clear the Recent calls list:
1. Click Recent calls.
2. Click the link Clear history in the lower right corner.
Cisco TelePresence Movi for Windows User Guide (4.1) Page 9 of 20
Presence status
Status messages
Your Movi presence status is reflected in search results and contact lists.
Online This is an online Movi user.
Registered This is a connected endpoint.
Away The user has set this status.
Presence status
Busy in call
Busy The user has set this status.
Offline This status is set by Movi or the endpoint when the user signs out or exits, but it may also
No status No status information is available for this user, who may be online or offline.
This status is set by Movi or the endpoint when the user is in a call.
have been set by the user.
Setting your status
You can manually change your status by clicking on the Status button next to your name in the Movi control window. The alternatives are:
Online
Away
Busy This status may also turn off the ring tone, depending on your settings. (See Settings.)
Appear offline You will remain logged in while appearing offline to others.
Note: Your status will change automatically from Online to Busy in call.
Cisco TelePresence Movi for Windows User Guide (4.1) Page 10 of 20
Closing Movi
Closing Movi
Closing and reopening the control window
1. Click on the X in the upper right corner to close the Movi window while remaining available to receive calls.
2. Movi is now placed in your computer's systray in the lower right corner of your screen. Your current status will be displayed on top of the Movi icon.
3. To reopen the Movi window, double-click the systray icon, or right-click it and select Open.
Signing out
To sign out from Movi, for example to allow another user to log in:
1. Click the status button in the Movi control window.
2. Select Sign out.
3. If your username and password are already filled in, click the Clear sign-in link to empty the fields for the next user.
Exiting Movi
To exit the Movi application completely:
1. Right-click on the Movi icon in the systray.
2. Select Exit.
When you exit Movi, you will also be signed out.
Cisco TelePresence Movi for Windows User Guide (4.1) Page 11 of 20
The pop-up toolbar
The pop-up toolbar
A toolbar with these buttons will appear when you move the mouse pointer over the video window:
Icon Controls Description Toggled
Selfview See yourself on camera. (See Selfview and camera control.)
Camera Turn your camera off/on. (See Selfview and camera control.)
Microphone Turn your microphone off/on.
Speaker volume Click to mute, or drag slider to adjust.
Fullscreen Use entire screen for video.
Presentation sharing Share an application window. (See Presentation sharing.)
End call Hang up.
Move the mouse pointer away from the toolbar to make it disappear.
Selfview and camera control
Selfview is the functionality that lets you see your own camera image.
Click on the Selfview button during a call. Selfview will appear to you as a picture-in-picture (PiP) inside the video window. You can:
n Double-click a PiP to focus and enlarge it. n Click and drag to move a PiP around inside the window.
Controlling your camera
on the video pop-up toolbar toggles your camera on and off.
Should you switch off the camera during a call, Movi will continue to show the last video frame as a still image to other call participants.
If you switch the camera off before the recipient answers your call, there will be no image of you available. You may still turn the camera on during the call.
Note: This setting does not affect the cameras of other participants.
Cisco TelePresence Movi for Windows User Guide (4.1) Page 12 of 20
The pop-up toolbar
Using the keypad (DTMF)
When to use the keypad
Dual-tone multi-frequency (DTMF) signaling is used for telephone calls in the voice-frequency band. A tone is sent representing each number pressed on the keypad.
The tone-based keypad in Movi has several uses, notably:
n The keypad can be used to create and/or enter passwords for multi-part conferences. n Setting up a new conference may in other ways involve equipment that requires DTMF. n Voice systems frequently have tone-based menu navigation (such as, "To speak to an operator, please
press 1").
How to use the keypad
The Keypad button on the video info bar brings up the keypad. You can then enter a number using the mouse.
Note: Sending DTMF may fail if the microphone is muted.
Using the keypad during conferences
The keypad may also be used for changing the layout of your video window and far-end camera control during conferences.
Note: This feature relies on the Cisco MCU, which may or may not be part of your Cisco setup. If in doubt, talk to your IT administrator.
When the keypad is active during multi-part conferences, you may:
n Press 2 or 8 to change the layout. n Press 4 or 6 to change which participant appears in the largest pane. n Press 1 or 7 to enable far end camera control.
1 and 7 will then zoom in and out if supported
2, 4, 6, and 8 will work as arrows to move the camera of the participant in the largest pane.
Presentation sharing
How to share
During a call, you can share one of your application windows, such as a PowerPoint presentation.
You can share an application window by:
1. The Presentation button on the video window pop-up toolbar brings up a list of your open
application windows. Select any of them to start sharing. To stop, click the same button again, then click Stop sharing presentation.
2. Turn on fullscreen or slideshow view in an application during a call, and Movi will ask you whether you want to share that window. When you exit fullscreen view, Movi will stop sharing.
Cisco TelePresence Movi for Windows User Guide (4.1) Page 13 of 20
The pop-up toolbar
Your shared window will appear to you as a picture-in-picture (PiP) inside the video window. Double-click a PiP to focus it.
Tip: If bandwidth or system resources are limited, turning off your camera during a presentation will improve presentation quality.
What to share
Participants will see everything that happens in the shared window as it occurs. This feature has many potential uses. Here are a few examples:
n Share your word processor and let call participants see your meeting notes as you type. n Share pictures from your computer as a slideshow. n Draw as you go, share an image editor or other visualization tool. n Share your web browser, email inbox, calendar ...
You cannot share the Movi windows themselves or your desktop.
Note: Conference participants will not see your mouse cursor in the shared window.
Cisco TelePresence Movi for Windows User Guide (4.1) Page 14 of 20
The info bar
The info bar
An info bar with information and buttons will appear when you are in a call. The information is:
n The duration of the conference. n The address of the recipient of the call; either one person or the device hosting the conference.
n
An icon / indicating if the conference is encrypted or not.
The buttons are:
Icon Controls Description
Far-end camera control Turn your far-end camera control off/on.
Numeric keypad Use for tone-based input. (See Using the keypad (DTMF).)
Conference info Opens your conference information box.
Far-end camera control (FECC)
How to control the far-end camera
In calls that support far-end camera control, you can adjust the far-end camera to give you a better view of the person(s) you are talking with.
To activate the far end camera control, click the FECC button on the info bar in the upper corner of the video window. A control will appear above the toolbar on mouse movement.
You can also use arrow keys on your keyboard to pan and tilt the far-end camera. To zoom in and out use the + and - keys.
Cisco TelePresence Movi for Windows User Guide (4.1) Page 15 of 20
The info bar
Limitations
If any of the equipment in the video conference does not support the far-end camera control ability, the button will be disabled (gray).
If the functionality is not available at all, the button will not be displayed.
Cisco TelePresence Movi for Windows User Guide (4.1) Page 16 of 20
Joining calls to a conference
Joining calls to a conference
During a call you can have up to four calls on hold, switch between them or join them in a conference.
If you make a new call while talking, the current call will be put on hold. A panel to the right shows the calls on hold. The same happens if you accept an incoming call while you are already talking to someone.
How to toggle between calls on hold
To switch between open calls on hold, mouse over the calls-on-hold indicator on the left hand side of the video. The calls on hold panel opens. Click on the participant.
How to join participants to a conference
To join calls to a conference, mouse over the indicator. The calls on hold panel opens. Click Join all.
How to end calls on hold
To end a call:
1. Make the call active by clicking on it.
2. Click the End conference button .
Cisco TelePresence Movi for Windows User Guide (4.1) Page 17 of 20
Troubleshooting
Troubleshooting
Audio issues
You cannot hear others
If you cannot hear the other participant(s), make sure your loudspeakers or headphones are connected. Then check all volume controls:
n Your headphones or loudspeakers may have their own volume buttons or switches. n The Windows volume settings will override all other volume controls. Look for the loudspeaker icon in
your systray to open and/or unmute.
n Movi has its own volume settings, see page Speaker volume.
If this does not solve the problem, it may be that audio is not being sent from the other end. Ask the other participant(s) to perform the microphone check described below.
Others cannot hear you
If the other call participant(s) cannot hear you, make sure your microphone is properly connected and not muted.
Low or distorted sound
If call participants are experiencing distorted sound, very low sound, or echos:
1. Check whether any of you have enabled microphone boost, echo cancellation, gain control, noise reduction, digital effects or similar features for your audio devices.
2. Turn all such audio device features off for Movi to work optimally.
Further troubleshooting
If all local devices are turned on and working and audio and/or video issues remain, the problem could be with the videoconferencing infrastructure setup. Contact your ITadministrator for support and further troubleshooting.
Conference information
Move the cursor over the video window to display the information bar at the top of the window.
The Call status info button in the top right corner opens Conference information. Your IT administrator may request such information from you for troubleshooting purposes.
Cisco TelePresence Movi for Windows User Guide (4.1) Page 18 of 20
Checking for updates and getting help
Checking for updates and getting help
We recommend registering your product at http://www.tandberg.com/services/video-conferencing-
product-registration.jsp in order to receive notifications about the latest software and security updates.
New feature and maintenance releases are published regularly, and we recommend that your software is always kept up to date.
If you experience any problems when configuring or using the product, consult the documentation at
http://www.tandberg.com/support/video-conferencing-documentation.jsp for an explanation of how its
individual features and settings work. You can also check the support site at
http://www.tandberg.com/support/ to make sure you are running the latest software version.
You or your reseller can also get help from our support team by raising a case at
http://www.tandberg.com/support/. Make sure you have the following information ready:
n The software build number which can be found in the product user interface (if applicable). n Your contact email address or telephone number. n The serial number of the hardware unit (if applicable).
Cisco TelePresence Movi for Windows User Guide (4.1) Page 19 of 20
Checking for updates and getting help
THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.
THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.
The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public domain version of the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the University of California.
NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS” WITH ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE.
IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other countries. A listing of Cisco's trademarks can be found at www.cisco.com/go/trademarks. Third party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (1005R)
Any Internet Protocol (IP) addresses and phone numbers used in this document are not intended to be actual addresses and phone numbers. Any examples, command display output, network topology diagrams, and other figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses or phone numbers in illustrative content is unintentional and coincidental.
Cisco TelePresence Movi for Windows User Guide (4.1) Page 20 of 20
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
