PA-4T+ Synchronous Serial Port Adapter Installation and Configuration

CHAPTER

Overview

This chapterdescribes the PA-4T+ port adapterand describes its LEDs, cables,and receptacles. This chapter contains the following sections:

• Port Adapter Overview, page 1-1

• Synchronous Serial Overview, page 1-3

• Serial Interface Speciﬁcations, page 1-4

• Cables and Pinouts, page 1-5

• LEDs, page 1-15

Port Adapter Overview

The PA-4T+ provides the following electrical interfaces: EIA/TIA-232, EIA/TIA-449, EIA-530. X.21, and V.35.Each interface complies with itsspeciﬁcinterface speciﬁcations. The cable attached to each PA-4T+ port adapter’s interface ports determines its type (EIA/TIA-232, and so forth) and its mode (data communications equipment [DCE] or data terminal equipment [DTE]).

Note The PA-4T+ provides enhanced performance over the PA-4T. To determine if a PA-4T+ or

PA-4T is installed in your router, view the port adapters’ faceplate labels (refer to Figure 1-1 and Figure 1-2, respectively) or use the show diag command to view installed interface types.

Figure 1-1 PA-4T+ —Faceplate View

FAST SERIAL, ENHANCED

H9704

Overview 1-1

Port Adapter Overview

Figure 1-2 PA-4T Port Adapter—Faceplate View

FAST SERIAL

H4496

The following example of the show diag slot command shows a PA-4T+ in port adapter slot 0 (PA Bay 0) and a PA-4T in port adapter slot 1 (PA Bay 1) on a VIP2 that is in interface processor slot 3 in a Cisco 7500 series router.

Note In the following examples, the PA-4T+ is displayed as Mx serial.

Router# show diag 3 Slot 3: Physical slot 3, ~physical slot 0x6, logical slot 3, CBus 0 Microcode Status 0xC Master Enable, LED, WCS Loaded Board is analyzed Pending I/O Status: Console I/O EEPROM format version 1 VIP2 controller, HW rev 2.2, board revision UNKNOWN Serial number: 03517093 Part number: 73-1684-03 Test history: 0x00 RMA number: 00-00-00 Flags: cisco 7000 board; 7500 compatible

EEPROM contents (hex): 0x20: 01 15 02 03 00 35 AA A5 49 06 94 03 00 00 00 00 0x30: 50 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00

Slot database information: Flags: 0x4 Insertion time: 0x5314 (01:20:55 ago)

Controller Memory Size: 8 MBytes DRAM, 1024 KBytes SRAM

PA Bay 0 Information: Mx serial PA, 4 ports EEPROM format version 1 HW rev 1.0, Board revision 154 Serial number: 03699540 Part number: 73-1577-03

PA Bay 1 Information: Fast-Serial PA, 4 ports EEPROM format version 1 HW rev 1.0, Board revision 4 Serial number: 02827523 Part number: 73-3417-04

PA-4T+ Synchronous Serial Port Adapter Installation and Configuration1-2

Synchronous Serial Overview

The following example of the show diag slot command shows a PA-4T+ in port adapter slot 1 in a Cisco 7200 series or a cisco uBR7200 series router:

Router# show diag 1 Slot 1: Mx serial port adapter, 4 ports Port adapter is analyzed Port adapter insertion time 02:19:52 ago Hardware revision 1.0 Board revision UNKNOWN Serial number 3701161 Part number 73-1577-03 Test history 0x0 RMA number 00-00-00 EEPROM format version 1 EEPROM contents (hex): 0x20: 01 0C 01 00 00 38 79 A9 49 06 29 03 00 00 00 00 0x30: 05 00 00 00 FF FF FF 00 FF FF FF FF FF FF FF FF

The following example of the show diag slot command shows a PA-4T in port adapter slot 1 in a Cisco 7100 series router:

Router# show diag 1 Slot 3: Serial port adapter, 4 ports Port adapter is analyzed Port adapter insertion time 02:19:52 ago EEPROM contents at hardware discovery: Hardware revision 1.0 Board revision A0 Serial number 37296561 Part number 73-1556-04 Test history 0x0 RMA number 00-00-00 EEPROM format version 1 EEPROM contents (hex): 0x20: 01 11 01 00 00 A4 19 EC 49 06 98 04 00 00 00 00 0x30: 50 00 00 00 98 10 21 00 FF FF FF FF FF FF FF FF

Synchronous Serial Overview

The PA-4T+ provides four channel-independent, synchronous serial ports that support full-duplex operation at T1 (1.544-Mbps) and E1 (2.048-Mbps) speeds. Each port supports any of the available interface types: Electronics Industries Association/Telecommunications Industries Association (EIA/TIA)-232, EIA/TIA-449, V.35, X.21, and EIA-530.

EIA/TIA-232, which is by far the most common interface standard in the U.S.,supportsunbalanced circuits at signal speeds up to 64 kbps. EIA/TIA-449, which supports balanced (EIA/TIA-422) and unbalanced (EIA/TIA-423) transmissions, is a faster (up to 2 Mbps) version of EIA/TIA-232 that provides more functions and supports transmissions over greater distances. The EIA/TIA-449 standard was intended to replace EIA/TIA-232, but it was not widely adopted.

Note The EIA/TIA standards were referred to as recommended standards called RS-232 and

RS-449 prior to their acceptance by the ANSI committee.

The resistance to convert to EIA/TIA-449 was due primarily to the large installed base of DB-25 hardware and to the larger size of the 37-pin EIA/TIA-449 connectors, which limited the number of connections possible (fewer than is possible with the smaller, 25-pin EIA/TIA-232 connector).

EIA-530, which supports balanced transmission, provides the increased functionality, speed, and distance of EIA/TIA-449 on the smaller, DB-25 connector used for EIA/TIA-232. The EIA-530 standard was created to support the more sophisticated circuitry of EIA/TIA-449 on the large number ofexisting EIA/TIA-232 (DB-25) hardwareinstead of the larger,37-pin connectors usedfor

Overview 1-3

Serial Interface Specifications

EIA/TIA-449. Like EIA/TIA-449, EIA-530 refers to the electrical speciﬁcations of EIA/TIA-422 and EIA/TIA-423. The speciﬁcation recommends a maximum speed of 2 Mbps. EIA-530 is used primarily in the United States.

The V.35 interface is most commonly used in the United States and throughout Europe, and is recommended for speeds up to 48 kbps. The X.21 interface uses a 15-pin connection for balanced circuits and is commonly used in the United Kingdom to connect public data networks. X.21 relocates some of the logic functions to the data terminal equipment (DTE) and data communications equipment (DCE) interfaces and, as a result, requires fewer circuits and a smaller connector than EIA/TIA-232.

All interface types except EIA-530 can be individuallyconﬁguredforoperation with either external (DTE mode) or internal (DCEmode)timingsignals;EIA-530 operates with external timing only.In addition, all VIP2 serial interface types support nonreturn to zero (NRZ) and nonreturn to zero inverted (NRZI) format, and both 16-bit and 32-bit cyclic redundancy checks (CRCs). The default conﬁguration is for NRZ format and 16-bit CRC. You can change the default settings with software commands. (For more information, see the Chapter 8, “Conﬁguring the PA-4T+ Interfaces.”)

There is no default mode or clock rate set on the VIP2 serial ports, although an internal clock signal is presentonall ports for DCE support. Theinternalclock also allows you toperformlocal loopback tests without having to terminate the port or connect a cable. (All interface types except X.21 DTE support loopback.)Touse the port asa DCE interface,youmust set theclockrate and connectaDCE adapter cable. Touse the port as a DTE interface, you need only connect a DTE adapter cable to the port. Because the serial adapter cables determine the mode and interface type, the PA-4T+interface becomes a DTE when a DTE cable is connected to it.

If a DTE cable is connected to a port with a clock rate set, the DTE ignores the clock rate and uses the external clock signal that is sent from the remote DCE. For a brief description of the clockrate command,seeChapter 8,“Conﬁguring the PA-4T+Interfaces.”For completecommanddescriptions and instructions, see the publications listed in the section “Related Documentation” section on page vi.

Serial Interface Speciﬁcations

The PA-4T+ provides up to four synchronous serial interfaces. Each interface allows a maximum bandwidth of 2.048 Mbps; the speed depends on the type of electrical interface used. Use EIA/TIA-232 for speeds of 64 kilobits per second (kbps) and below, and use X.21, EIA/TIA-449, V.35, or EIA-530 for higher speeds.

Serial signals can travel a limited distance at any given bit rate; generally, the slower the baud rate, the greater the distance. All serial signals are subject to distance limits beyond which a signal degrades signiﬁcantly or is completely lost.

Table 1-1 lists the recommended (standard) maximum speeds and distances for each PA-4T+ serial interface type. The recommended maximum rate for V.35 is 2.048 Mbps.

PA-4T+ Synchronous Serial Port Adapter Installation and Configuration1-4

Table 1-1 Standards for Transmission Speed Versus Distance

Cables and Pinouts

Rate (bps) Feet Meters Feet Meters

2400 200 60 4,100 1,250 4800 100 30 2,050 625 9600 50 15 1,025 312 19200 25 7.6 513 156 38400 12 3.7 256 78 56000 8.6 2.6 102 31 1544000 (T1) – – 50 15

Balanced drivers allow EIA/TIA-449 signals to travel greater distances than EIA/TIA-232. The recommended distancelimitsfor EIA/TIA-449 showninTable 1-1 are alsovalid for V.35,X.21,and EIA-530. EIA/TIA-449 and EIA-530 support 2.048-Mbps rates, and V.35 supports 2.048-Mbps rates without any problems; we do not recommend exceeding published speciﬁcations for transmission speed versus distance. Do so at your own risk.

Cables and Pinouts

The following sections describe the serial receptacles on the PA-4T+, and the cables and pinouts for the various serial interface cables.

EIA/TIA-232 Distances

EIA/TIA-449, X.21, V.35, EIA-530 Distances

PA-4T+ Receptacles and Cables

The PA-4T+and adapter cables allow a high density of interface ports, regardless of the size of the connectorstypicallyused witheachelectrical interfacetype.All portsusean identical60-pinD-shell receptacle that supports all interface types: EIA/TIA-232, V.35, EIA/TIA-449, X.21, and EIA-530. Each port requires a serial adapter cable, which provides the interface between the high-density serial port and the standard connectors that are commonly used for each electrical interface type.

Note The adaptercable determines the electricalinterface type and modeof the port (DTEor DCE)

to which it is connected.

The network end of the cable is an industry-standard connector for the type of electrical interface that the cable supports. For most interface types, the adapter cable for DTE mode uses a plug at the network end, and the cable for DCE mode uses a receptacle at the network end. Exceptions are V.35 adapter cables, which are available with either a V.35 plug or a receptacle for either mode, and the EIA-530 adapter cable, which is availableonly in DTE mode with a DB-25 plug at the network end. The mode is labeled on the molded plastic connector shell at the ends of all cables except V.35 (which uses the standard Winchester block-type connector instead of a molded plastic D shell).

Following are the available interface cable options (and product numbers) for the mode and network-end connectors for each cable:

• EIA/TIA-232: DTE mode with a DB-25 plug (CAB-232MT=); DCE mode with a DB-25

receptacle (CAB-232FC=).

Overview 1-5

Cables and Pinouts

• EIA/TIA-449: DTE mode witha37-pinD-shell plug (CAB-449MT=); DCE mode with a 37-pin

D-shell receptacle (CAB-449C=).

• V.35: DTE mode or DCE mode with a 34-pin Winchester-type V.35 plug (CAB-V35MT= or

CAB-V35MC=); DTE mode or DCE mode with a 34-pin Winchester-type V.35 receptacle (CAB-V35FT=orCAB-V35FC=). Alsoavailable isa cable witha male DB-60plug on therouter end and a male DB-34 shielded plug on the network end (CAB-V35MTS=).

• X.21: DTE mode with a DB-15 plug (CAB-X21MT=); DCE mode with a DB-25 receptacle

(CAB-X21FC=).

• EIA-530: DTE mode with a DB-25 plug (CAB-530MT=).

Note For cable pinouts, see the “PA-4T+ Port Adapter Cable Pinouts” section on page 1-9.

Figure 1-3 showstheserial port adapter cablesfor connection from the PA-4T+ port adapters toyour network.

Figure 1-3 Serial Port Adapter Cables

(PA-4T+ port adapter)

Router connections

H10625

EIA/TIA-232 EIA-530

Metric (M3) thumbscrews are included with each portadaptercabletoallowconnections to devices that use metric hardware. Because the PA-4T+ uses a special, high-density port that requires special adapter cables for each electrical interface type, we recommend that you obtain serial interface cables from the factory.

PA-4T+ Synchronous Serial Port Adapter Installation and Configuration1-6

EIA/TIA-449 V.35 X.21

Network connections at the modem or CSU/DSU

EIA/TIA-232 Connections

The router end of all EIA/TIA-232 adapter cables is a high-density 60-pin plug. The network end of the adapter cable is a standard 25-pin D-shell connector (known as a DB-25) that is commonly used for EIA/TIA-232 connections. Figure 1-4 shows the connectors at the network end of the adapter cable.

Note The system console and auxiliary ports on the Route Switch Processor (RSP) in the

Cisco 7500 series also use EIA/TIA-232 connections; however, the PA-4T+ interfaces support synchronous serial connections, and the console and auxiliary ports only support asynchronous connections. Use caution when connecting EIA/TIA-232 cables to the PA-4T+ receptacles.

Note Do not use the Cisco Systems-provided EIA/TIA-232 adapter cable CAB-232MT= to

connect a PA-4T+ interface that is conﬁgured for DTE mode directly to an NEC - NEXTSTAR 1E model C4969 MD/SACunitinterfacethat is conﬁgured for DCE mode. Doing so will keep transmit and receive data signals from being properly exchanged between the two interfaces.

Instead, you must connect an additional, intermediate adapter cable—with standard EIA/TIA-232 DB-25 connectors at both ends—from the network end of CAB-232MT= to the standard EIA/TIA-232 DB-25 connector (the DCE interface) on the NEC - NEXTSTAR 1E model C4969 MD/SAC unit. Cisco Systems does not provide this additional cable; however, its signals and pin assignments are listed in Table 1-3.

PA-4T+ Receptacles and Cables

Note You can use the Cisco Systems-provided EIA/TIA-232 adapter cable CAB-232FC= to

connect a PA-4T+ interface that is conﬁgured for DCE mode directly to an NEC - NEXTSTAR 1E model C4969 MD/SAC unit interface that is conﬁgured for DTE mode.

Figure 1-4 EIA/TIA-232 Adapter Cable Connectors

DTE

DCE

H1343a

Overview 1-7

Cables and Pinouts

EIA/TIA-449 Connections

The router end of all EIA/TIA-449 adapter cables is a high-density 60-pin plug. The network end of the adapter cable provides a standard 37-pin D-shell connector, which is commonly used for EIA/TIA-449 connections. Figure 1-5 shows the connectors atthenetworkend of the adapter cable. EIA/TIA-449 cables are available as either DTE (DB-37 plug) or DCE (DB-37 receptacle).

Figure 1-5 EIA/TIA-449 Adapter Cable Connectors

DTE

V.35 Connections

DCE

H1344a

The router end of all V.35 adapter cables is a high-density 60-pin plug. The network end of the adapter cable provides a standard 34-pin Winchester-type connector commonly used for V.35 connections. Figure 1-6 shows the connectors at the network end of the V.35 adapter cable. V.35 cables are available with a standard V.35 plug for DTE mode (CAB-V35MT=) or a V.35receptacle for DCE mode (CAB-V35FC=).

Figure 1-6 V.35 Adapter Cable Connectors

DTE

DCE

H1616a

Note Also available, but not shown in Figure 1-6, are CAB-V35MC=, a V.35 cable with a plug on

the network end for DCE mode, and CAB-V35FT=, a V.35 cable with a receptacle on the network end for DTE mode. These cables are used for connecting V.35-equipped systems back to back.

PA-4T+ Synchronous Serial Port Adapter Installation and Configuration1-8

X.21 Connections

PA-4T+ Port Adapter Cable Pinouts

The router end of all X.21 adapter cables is a high-density 60-pin plug. The network end of the adapter cable is a standard DB-15 connector. Figure 1-7 shows the connectors at the network end of the X.21 adapter cable. X.21 cables are available as either DTE (DB-15 plug) or DCE (DB-15 receptacle).

Figure 1-7 X.21 Adapter Cable Connectors

DTE

EIA-530 Connections

The EIA-530 adapter cable is available in DTE mode only. The router end of the EIA-530 adapter cable is a high-density 60-pin plug. The network end of the adapter cable is a standard DB-25 plug commonly used for EIA/TIA-232 connections. Figure 1-8 shows the DB-25 connector at the network end of the adapter cable.

Figure 1-8 EIA-530 Adapter Cable Connector

PA-4T+ Port Adapter Cable Pinouts

The PA-4T+ supports EIA/TIA-232, EIA/TIA-449, X.21, V.35, and EIA-530 serial interfaces. All PA-4T+ ports use a a 60-pin receptacle that supports all available interface types. A special serial adapter cable determinestheelectrical interface type and mode oftheinterface. The router end of all of theadapter cables hasa60-pin plug; theconnectors at the networkend are thestandard connectors used for the respective interfaces. All interface types except EIA-530 are available in DTE or DCE format: DTE with a plug at the network end and DCE with a receptacle at the network end. V.35 is available in either mode with either gender at the network end. EIA-530 is available in DTE only. The tables that follow list the signal pinouts for both the DTE and DCE mode serial port adapter cables, for each of the following PA-4T+ interface types:

DCE

H1346a

DTE

H1615a

• EIA/TIA-232 pinouts, Table 1-2

• EIA/TIA-449 pinouts, Table 1-4

• EIA-530 pinouts, Table 1-5

• V.35 pinouts, Table 1-6

• X.21 pinouts, Table 1-7

Overview 1-9

Cables and Pinouts

Table 1-2 EIA/TIA-232 Adapter Cable Signals DTE Cable (CAB-232MT=) DCE Cable (CAB-232FC=)

Router End, HD 60-Position Plug

Network End, DB-25 Plug

Router End, HD 60-Position Plug

Network End, DB-25 Receptacle

Signal Pin Pin Signal Signal Pin Pin Signal

Shield ground 46 1 Shield ground Shield ground 46 1 Shield ground TxD/RxD 41 —> 2 TxD RxD/TxD 36 <— 2 TxD RxD/TxD 36 <— 3 RxD TxD/RxD 41 —> 3 RxD RTS/CTS 42 —> 4 RTS CTS/RTS 35 <— 4 RTS CTS/RTS 35 <— 5 CTS RTS/CTS 42 —> 5 CTS DSR/DTR 34 <— 6 DSR DTR/DSR 43 —> 6 DSR Circuit ground 45 7 Circuit ground Circuit ground 45 7 Circuit ground DCD/LL 33 <— 8 DCD LL/DCD 44 —> 8 DCD TxC/NIL 37 <— 15 TxC TxCE/TxC 39 —> 15 TxC RxC/TxCE 38 <— 17 RxC NIL/RxC 40 —> 17 RxC LL/DCD 44 —> 18 LTST DCD/LL 33 <— 18 LTST DTR/DSR 43 —> 20 DTR DSR/DTR 34 <— 20 DTR TxCE/TxC 39 —> 24 TxCE RxC/TxCE 38 <— 24 TxCE Mode 0

Ground Mode_DCE

1 HD = high density.

50 51 52

Shorting group

Mode 0 Ground

50 51 Shorting group

PA-4T+ Synchronous Serial Port Adapter Installation and Configuration1-10

PA-4T+ Port Adapter Cable Pinouts

Table 1-3 Intermediate Adapter Cable Signals (for Connecting a PA-4T+ to a

NEC - NEXTSTAR 1E Model C4969 MD/SAC Unit)

Router (DTE) End, DB-25 Receptacle

Signal Pin Pin Signal

Shield ground 1 1 Shield ground TxD 2 —> 2 TxD RxD 3 <— 3 RxD RTS 4 —> 4 RTS CTS 5 <— 5 CTS DSR 6 <— 6 DSR Circuit ground 7 7 Circuit ground DCD 8 <— 8 DCD TxC, RxC 15, 17 <— 15 TxC – – <— 17 RxC LTST 18 —> 18 LTST DTR 20 —> 20 DTR TxCE 24 —> 24 TxCE Shorting group Shorting group

Network (DCE) End, DB-25 Plug

Overview 1-11

Cables and Pinouts

Table 1-4 EIA/TIA-449 Adapter Cable Signals DTE Cable (CAB-449MT=) DCE Cable (CAB-449C=)

Router End, HD 60-Position Plug

Network End, DB-37 Plug

Router End, HD 60-Position Plug

Network End, DB-37 Receptacle

Signal Pin Pin Signal Signal Pin Pin Signal

Shield ground 46 1 Shield ground Shield ground 46 1 Shield ground TxD/RxD+ 11 —> 4 SD+ RxD/TxD+ 28 <— 4 SD+ TxD/RxD– 12 —> 22 SD– RxD/TxD– 27 <— 22 SD– TxC/RxC+ 24 <— 5 ST+ TxCE/TxC+ 13 —> 5 ST+ TxC/RxC– 23 <— 23 ST– TxCE/TxC– 14 —> 23 ST– RxD/TxD+ 28 <— 6 RD+ TxD/RxD+ 11 —> 6 RD+ RxD/TxD– 27 <— 24 RD– TxD/RxD– 12 —> 24 RD– RTS/CTS+ 9 —> 7 RS+ CTS/RTS+ 1 <— 7 RS+ RTS/CTS– 10 —> 25 RS– CTS/RTS– 2 <— 25 RS– RxC/TxCE+ 26 <— 8 RT+ TxC/RxC+ 24 —> 8 RT+ RxC/TxCE– 25 <— 26 RT– TxC/RxC– 23 —> 26 RT– CTS/RTS+ 1 <— 9 CS+ RTS/CTS+ 9 —> 9 CS+ CTS/RTS– 2 <— 27 CS– RTS/CTS– 10 —> 27 CS– LL/DCD 44 —> 10 LL NIL/LL 29 —> 10 LL Circuit ground 45 37 SC Circuit ground 30 37 SC DSR/DTR+ 3 <— 11 ON+ DTR/DSR+ 7 —> 11 ON+ DSR/DTR– 4 <— 29 ON– DTR/DSR– 8 —> 29 ON– DTR/DSR+ 7 —> 12 TR+ DSR/DTR+ 3 <— 12 TR+ DTR/DSR– 8 —> 30 TR– DSR/DTR– 4 <— 30 TR– DCD/DCD+ 5 <— 13 RR+ DCD/DCD+ 5 —> 13 RR+ DCD/DCD– 6 <— 31 RR– DCD/DCD– 6 —> 31 RR– TxCE/TxC+ 13 —> 17 TT+ RxC/TxCE+ 26 <— 17 TT+ TxCE/TxC– 14 —> 35 TT– RxC/TxCE– 25 <— 35 TT– Circuit ground 15 19 SG Circuit ground 15 19 SG Circuit ground 16 20 RC Circuit ground 16 20 RC Mode 1

Ground Ground

Mode_DCE

1 HD = high density.

49 48

51 52

Shorting group Mode 1

Ground

Shorting group

49 48

Shorting group

PA-4T+ Synchronous Serial Port Adapter Installation and Configuration1-12

Table 1-5 EIA-530 DTE Adapter Cable Signals (CAB-530MT=) Router End, HD

60-Position Plug

Network End, DB-25 Plug

Signal Pin Pin Signal

Shield ground 46 1 Shield ground TxD/RxD+ 11 —> 2 TxD+ TxD/RxD– 12 —> 14 TxD– RxD/TxD+ 28 <— 3 RxD+ RxD/TxD– 27 <— 16 RxC– RTS/CTS+ 9 —> 4 RTS+ RTS/CTS– 10 —> 19 RTS– CTS/RTS+ 1 <— 5 CTS+ CTS/RTS– 2 <— 13 CTS– DSR/DTR+ 3 <— 6 DSR+ DSR/DTR– 4 <— 22 DSR– DCD/DCD+ 5 <— 8 DCD+ DCD/DCD– 6 <— 10 DCD– TxC/RxC+ 24 <— 15 TxC+ TxC/RxC– 23 <— 12 TxC– RxC/TxCE+ 26 <— 17 RxC+ RxC/TxCE– 25 <— 9 RxC– LL/DCD 44 —> 18 LL Circuit ground 45 7 Circuit ground DTR/DSR+ 7 —> 20 DTR+ DTR/DSR– 8 —> 23 DTR– TxCE/TxC+ 13 —> 24 TxCE+ TxCE/TxC– 14 —> 11 TxCE– Mode_1

Ground Mode_2

Ground Mode_DCE

1 HD = high density.

49 48 47

51 52

Shorting group

PA-4T+ Port Adapter Cable Pinouts

Overview 1-13

Cables and Pinouts

Table 1-6 V.35 Adapter Cable Signals DTE Cable (CAB-V35FT= or CAB-V35MT=) DCE Cable (CAB-V35FC= or CAB-V35MC=)

Network End, 34-Position Receptacle

Router End, HD 60-Position Plug

Network End, 34-Position Plug

Router End, HD 60-Position Plug

Signal Pin Pin Signal Signal Pin Pin Signal

Shield ground 46 A Frame ground Shield ground 46 A Frame ground Circuit ground 45 B Circuit ground Circuit ground 45 B Circuit ground RTS/CTS 42 —> C RTS CTS/RTS 35 <— C RTS CTS/RTS 35 <— D CTS RTS/CTS 42 —> D CTS DSR/DTR 34 <— E DSR DTR/DSR 43 —> E DSR DCD/LL 33 <— F RLSD LL/DCD 44 —> F RLSD DTR/DSR 43 —> H DTR DSR/DTR 34 <— H DTR LL/DCD 44 —> K LT DCD/LL 33 <— K LT TxD/RxD+ 18 —> P SD+ RxD/TxD+ 28 <— P SD+ TxD/RxD– 17 —> S SD– RxD/TxD– 27 <— S SD– RxD/TxD+ 28 <— R RD+ TxD/RxD+ 18 —> R RD+ RxD/TxD– 27 <— T RD– TxD/RxD– 17 —> T RD– TxCE/TxC+ 20 —> U SCTE+ RxC/TxCE+ 26 <— U SCTE+ TxCE/TxC– 19 —> W SCTE– RxC/TxCE– 25 <— W SCTE– RxC/TxCE+ 26 <— V SCR+ NIL/RxC+ 22 —> V SCR+ RxC/TxCE– 25 <— X SCR– NIL/RxC– 21 —> x SCR– TxC/RxC+ 24 <— Y SCT+ TxCE/TxC+ 20 —> Y SCT+ TxC/RxC– 23 <— AA SCT– TxCE/TxC– 19 —> AA SCT– Mode 1

Ground Mode 0

Ground Mode_DCE

TxC/NIL RxC/TxCE RxC/TxD Ground

1 HD = high density.

49 48

50 51 52

53 54 55 56

Shorting group Mode 1

Ground

Shorting group Mode 0

Ground

Shorting group TxC/NIL

RxC/TxCE RxC/TxD Ground

49 48

50 51

53 54 55 56

Shorting group

PA-4T+ Synchronous Serial Port Adapter Installation and Configuration1-14

Table 1-7 X.21 Adapter Cable Signals DTE Cable (CAB-X21MT=) DCE Cable (CAB-X21FC=)

Router End, HD 60-Position Plug

Signal Pin Pin Signal Signal Pin Pin Signal

Shield ground 46 1 Shield ground Shield ground 46 1 Shield ground TxD/RxD+ 11 —> 2 Transmit+ RxD/TxD+ 11 —> 2 Transmit+ TxD/RxD– 12 —> 9 Transmit– RxD/TxD– 12 —> 9 Transmit– RTS/CTS+ 9 —> 3 Control+ CTS/RTS+ 9 —> 3 Control+ RTS/CTS – 10 —> 10 Control– CTS/RTS – 10 —> 10 Control– RxD/TxD+ 28 <— 4 Receive+ TxD/RxD+ 28 <— 4 Receive+ RxD/TxD– 27 <— 11 Receive– TxD/RxD– 27 <— 11 Receive– CTS/RTS+ 1 <— 5 Indication+ RTS/CTS+ 1 <— 5 Indication+ CTS/RTS – 2 <— 12 Indication– RTS/CTS– 2 <— 12 Indication– RxC/TxCE+ 26 <— 6 Timing+ TxC/RxC+ 26 <— 6 Timing+ RxC/TxCE– 25 <— 13 Timing– TxC/RxC – 25 <— 13 Timing– Circuit ground 15 8 Circuit ground Circuit ground 15 8 Circuit ground Ground

Mode_2 Ground

Mode_DCE

1 HD = high density.

48 47

51 52

Network End, DB-15 Plug

Shorting group Ground

Router End, HD 60-Position Plug

Mode_2

Mode_DCE

48 47

51 52

Network End, DB-15 Receptacle

Shorting group

LEDs

The PA-4T+ contains the enabled LED, standard on all port adapters, and one status LED for each port. After system initialization, the enabled LED goes on to indicate that the PA-4T+ has been enabled for operation. (The LEDs are shown in Figure 1-9.)

Figure 1-9 LEDs on the PA-4T+—Horizontal Orientation

H4491

The following conditions must be met before the PA-4T+ is enabled:

• The port adapter is correctly connected to the backplane midplane and receiving power.

• A valid system software image for the port adapter has been downloaded successfully.

• The system software recognizes the port adapter or VIP2 with an installed PA-4T+.

Overview 1-15

LEDs

If any of the above conditions are not met, or if the initialization fails for other reasons, the enabled LED will not go on. Table 1-8 lists port LED status indications.

Table 1-8 PA-4T+ Port LEDs LED Label Color State Function

EN Green On Indicates ports are ready. TD Green On DTE—Transmit data out.

DCE—Transmit data in.

TC Green On DTE—Transmit clock in.

DCE—Transmit clock in (TXCE).

RD Green On DTE—Receive data in.

DCE—Receive data out.

RC Green On DTE—Receive clock in.

DCE—Receive clock out.

LB/CD Green On Indicates DTR, DSR, RTS, CTS, or DCD is active.

Green Flashing Indicates RTS, CTS, or DCD is sending and receiving

data in half-duplex mode.

Yellow On Indicates local loop or internal loop active.

PA-4T+ Synchronous Serial Port Adapter Installation and Configuration1-16

Objectives

Preface

This preface describes the objectives and organization of this document and explains how to ﬁnd additional information on the PA-4T+ port adapter and other Cisco products and services. This preface contains the following sections:

• Objectives, page v

• Document Organization, page vi

• Related Documentation, page vi

• Cisco Connection Online, page vii

• Documentation CD-ROM, page viii

This document describes how to install and conﬁgure the PA-4T+ synchronous serial port adapter (PA-4T+[=]), which is used in the following platforms:

• Second-generation Versatile Interface Processor (VIP2) in Cisco 7500 series routers and

Cisco 7000 series routers with the Cisco 7000 Series Route Switch Processor (RSP7000) and Cisco 7000 Series Chassis Interface (RSP7000CI)

• Cisco 7200 series routers—which consist of the two-slot Cisco 7202, the four-slot Cisco 7204

and Cisco 7204VXR, and the six-slot Cisco 7206 and Cisco 7206VXR

• Cisco uBR7200 series universal broadband routers—which consist of the six-slot Cisco

uBR7246 and the three-slot Cisco uBR7223

• Cisco 7100 series routers—which consist of the Cisco 7120 series and Cisco 7140 series

Preface v

Document Organization

This document is organized into the following chapters:

Section Title Description

Chapter 1 Overview Describes the PA-4T+ port adapter, illustrates their

Chapter 2 Preparing for Installation Describes safety considerations, tools required, and

Chapter 3 VIP2 and the

PA-4T+ Port Adapter

Chapter 4 Cisco 7200 Series and the

PA-4T+ Port Adapter

Chapter 5 Cisco uBR7200 Series and the

PA-4T+ Port Adapter

Chapter 6 Cisco 7100 Series and the

PA-4T+ Port Adapter

Chapter 7 Installing the PA-4T+ Interface

Cables

Chapter 8 Conﬁguring the PA-4T+

Interfaces

location in the supported hardware platforms, and describes its LED displays, cables, and receptacles.

procedures you should perform before the actual installation.

Provides instructions for installing the PA-4T+ port adapter on a VIP2 interface processor installed in a Cisco 7500 or Cisco 7000 series router.

Provides instructions for installing the PA-4T+ port adapter in a Cisco 7200 series router.

Provides instructions for installing the PA-4T+ port adapter in a Cisco uBR7200 series universal broadband router.

Provides instructions for installing the PA-4T+ port adapter in Cisco 7100 series routers.

Provides instructions for installing port adapter cables on the supported platforms.

Provides instructions for conﬁguring your port adapter on the supported platforms. The instructions givenin this chapter applyto all supported platforms described in this document.
