User Guide for Cisco LCD Professional Series Displays
© 2008 Cisco Systems, Inc. All rights reserved.
logo, LightStream, Linksys, MediaTone, MeetingPlace, MeetingPlace Chime Sound, MGX, Networkers, Networking Academy, Network Registrar,
logo are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.
IMPLIED, INCLUDING, WITHOUT
CONTENTS
CHAPTER
1 Important Safety and Compliance Information 1-1
About Electrical and Fire Dangers 1-1
About Choosing the Proper Installation Site 1-3
About Installing Your Display Safely 1-4
About Cleaning Your Display Safely 1-4
Cleaning the LCD Display Surface, Case, and Housing Safely 1-4
Cleaning the Power Plug and the Electrical Outlet Safely 1-5
About Batteries 1-5
Regulatory Compliance Notes and Notices 1-5
United States 1-6
FCC Class A Notice 1-6
FCC Class B Notice 1-6
User Information 1-7
Important Safety Instructions (UL Only) 1-7
EPA 1-8
Mercury Statement 1-8
Canada 1-8
ICES-003 Class A Notice (Avis NMB-003, Classe A) 1-8
ICES-003 Class B Notice (Avis NMB-003, Classe B) 1-8
Japan 1-8
VCCI Class A Notice 1-9
VCCI Class B Notice 1-9
Taiwan—BSMI Class A Notice 1-9
Republic of Korea 1-9
MIC Class A Notice 1-9
MIC Class B Notice 1-9
Europe and its Member Nations 1-9
European Notice 1-10
European Class A Warning 1-10
UK—Wiring the Mains: Power Supply Plug 1-10
Italy—Homologation Notice 1-11
Sweden—Swedish Confederation of Professional Employees (TCO) 1-11
Norway—Norges Elektriske Materiellkontroll (NEMKO) 1-11
Russia—GOST-R Quality Certificate (Знак Ростеста - PCT) 1-13
OL-17986-01
User Guide for Cisco LCD Professional Series Displays
iii
Contents
CHAPTER
CHAPTER
2 The Basics 2-1
Package Contents 2-1
Getting to Know Your Cisco LCD Professional Series Display 2-2
About Controls and Sensors on the Front of Your LCD Display 2-3
About Terminals on the Back of Your Display 2-4
Using the Kensington Slot 2-5
About the Remote Control 2-6
Locking Front Panel Controls and the Remote Control 2-7
Mechanical Layout — LCD Professional Series 100 (40" Display) 2-8
Mechanical Layout — LCD Professional Series 110 (52" Display) 2-10
Installing VESA Brackets 2-11
3 Connecting to Other Devices 3-1
Connecting to a Cisco Digital Media Player 3-1
Connecting to an Analog Audio Source 3-1
Connecting to an Audio Amplifier 3-2
Connecting to a Digital A/V Source (HDMI) 3-2
Connecting to a Digital A/V Source (DVI to HDMI) 3-3
CHAPTER
4 Adjusting Display Settings 4-1
Opening and Closing the Main Menu 4-1
Using the Input Menu 4-2
Choosing a Video Input Source from the Source List Menu 4-2
Working in the Edit Name Menu 4-3
Using the Picture Menu 4-3
Personalizing Picture Settings with the Custom Menu 4-4
Choosing a Color Tone Definition from the Color Tone Menu 4-4
Adjusting Picture Temperature Settings from the Color Temp Menu 4-5
Turning Automatic Contrast Optimation On or Off from the Dynamic Contrast Menu 4-6
Choosing a Picture Setting from the Mode Menu 4-6
Choosing an Aspect Ratio or a Zoom Level from the Size Menu 4-7
Turning Digital Noise Reduction On or Off from the Digital NR Menu 4-8
Turning Film Mode On or Off from the Film Mode Menu 4-8
Turning the Brightness Sensor On or Off from the Brightness Sensor Menu 4-9
Using the Sound Menu 4-9
Choosing an Optimized Audio Amplification Setting from the Mode Menu 4-9
Personalizing Audio Settings from the Custom Menu 4-10
Turning Equalization On or Off from the Auto Volume Menu 4-11
iv
User Guide for Cisco LCD Professional Series Displays
OL-17986-01
Turning Multichannel Audio On or Off from the SRS TS XT Menu 4-11
Using the Setup Menu 4-12
Choosing a Menu System Language from the Language Menu 4-12
Adjusting Clock-based Settings from the Time Menu 4-13
Adjusting Background Transparency Settings from the Menu Transparency Menu 4-14
Editing the 4-digit PIN from the Safety Lock PIN Menu 4-14
Adjusting Power Consumption Behaviors from the Energy Saving Menu 4-15
Compensating for Degraded Images from the HDMI Black Level Menu 4-15
Configuring Video Wall Options and Settings 4-16
Turning the Video Wall Feature On or Off from the Video Wall Menu 4-16
Choosing a Video Wall Aspect Ratio Preservation Setting from the Format Menu 4-17
Defining the Width (in Displays) of Your Video Wall from the Horizontal Menu 4-17
Defining the Height (in Displays) of Your Video Wall from the Vertical Menu 4-18
Designating the Position of One LCD Display in a Video Wall from the Screen Divider
Menu
Preventing Video Wall Afterimage Burn-in from the Safety Screen Menu 4-19
Setting the Delay Interval from the Power On Adjustment Menu 4-21
Adjusting Brightness Intensity for Gray Backgrounds from the Side Gray Menu 4-21
Restore Factory Default Color Settings from the Reset Menu 4-21
Adjusting Inverter Lamp Power Consumption Settings from the Lamp Control Menu 4-22
Working in the S/N Menu 4-22
4-19
Contents
OL-17986-01
User Guide for Cisco LCD Professional Series Displays
v
Contents
vi
User Guide for Cisco LCD Professional Series Displays
OL-17986-01
Warning
CHAP T ER
1
Important Safety and Compliance Information
Revised April 2, 2009
• About Electrical and Fire Dangers, page 1-1
• About Choosing the Proper Installation Site, page 1-3
• About Installing Your Display Safely, page 1-4
• About Cleaning Your Display Safely, page 1-4
• About Batteries, page 1-5
• Regulatory Compliance Notes and Notices, page 1-5
Cisco sold this LCD Professional Series display to you with the expectation that you will attach it to
a Cisco Digital Media Player (DMP) for use in your digital signage network or enterprise TV network.
In this way, your LCD display is an accessory for the DMP to which it is attached. The regulatory
compliance information for that DMP extends to all its accessories, including this LCD display. See
the printed regulatory compliance document that you received with your DMP. Alternatively, see the
most recent revision of that document on Cisco.com, at http://www.cisco.com/en/US/products/
ps7220/prod_installation_guides_list.html.
This chapter contains warnings, cautionary messages, and statements of compliance with
international regulations that supplement the compliance statements for your DMP. Read this chapter
carefully in combination with the Regulatory Compliance and Safety Information document on
Cisco.com that pertains to your DMP, and always use this product correctly.
Failure to heed all recommendations can lead to bodily harm, equipment failure, property damage,
signal interference, and other consequences.
About Electrical and Fire Dangers
Read all of the Cisco user documentation and product literature concerning proper operation and
maintenance of your LCD display.
OL-17986-01
User Guide for Cisco LCD Professional Series Displays
1-1
About Electrical and Fire Dangers
Mishandling this product and its accessories might cause fire, personal injury, electric shocks, or product
damage that is preventable otherwise. Be sure to follow these guidelines:
Always... Never...
• Always keep candles and other open flames away from
your LCD display.
• Always use only the provided power cord and connect its
polarized plug to a properly grounded power outlet.
• Always ensure that the power cord is plugged into the
power outlet firmly and correctly.
• To disconnect your LCD display from the mains, the
polarized plug must be pulled out from the mains socket,
therefore the mains plug shall be readily operable.
• Always grip the polarized plug tightly when you unplug
it from a outlet.
• Always unplug the power cord from its outlet before
cleaning.
• Always unplug your LCD display from the power outlet
and disconnect the antenna or cable system during
electrical storms and whenever your display is left
unattended or unused for long periods of time (especially
when children, older adults, people with severely
impaired judgment, or people with severely impaired
physical coordination will be left alone with it).
• Always lay power cords where they are not likely to be
walked on or pinched by items placed upon or against
them, and pay particular attention to plugs, adaptors, and
the point where the power cord attaches to your LCD
display.
• Always ensure before connecting the AC power cord to
the DC adaptor outlet that the voltage designation of the
DC adaptor corresponds to the local electrical supply.
• Always disconnect your LCD display immediately if it
emits any unusual sounds or odors or otherwise does not
operate normally, and then contact a qualified and
licensed technician immediately.
• Never use the power cord from any other product.
• Never touch the power plug with wet hands when
removing or plugging the plug into the outlet.
• Never expose your LCD display to dripping or splashing.
• Never expose your LCD display to rain or place it near
water (near a bathtub, washbowl, kitchen sink, or laundry
tub, in a wet basement, near a swimming pool, or in any
similar setting). If your LCD display is wet, unplug it and
contact a licensed technician immediately.
• Never use a damaged power cord or plug.
• Never use a damaged or loose power outlet.
• Never forcefully bend or pull the power plug.
• Never place any heavy objects on the power plug.
• Never connect multiple appliances to the same power
outlet, and never overload power outlets, extension cords
or adaptors beyond their capacity.
• Never disconnect the power cord while using your LCD
display.
• Never insert anything metallic into the open parts of your
LCD display.
• Never open your LCD display and never remove its cover
or its back. High voltage is present inside. It is dangerous
to make any kind of contact with anything inside this
product. There are no user-serviceable parts inside. Refer
all servicing to qualified personnel.
• Never touch the inside of your LCD display. Only
qualified personnel should open it.
• Never allow dust to accumulate on your LCD display or
its power cord.
• Never drop your LCD display or impart any shock to it.
If it is damaged, disconnect the power cord and contact a
qualified and licensed technician.
• Never place your LCD display near or over a radiator or
heat resistor, or where it is exposed to direct sunlight.
Chapter 1 Important Safety and Compliance Information
1-2
• Never place any vessel that holds water (such as a vase)
on your LCD display.
User Guide for Cisco LCD Professional Series Displays
OL-17986-01
Chapter 1 Important Safety and Compliance Information
About Choosing the Proper Installation Site
The ideal installation site for your LCD display is a high-visibility location with physical stability that:
• Allows for adequate ventilation and clearance.
• Is protected from heat sources.
• Is not readily accessible to children or others who might lack the personal judgment or physical
coordination to recognize, avoid, and prevent danger to themselves and others.
To learn more about choosing the proper site for installations and about our recommended best practices
that promote your safety and success, see
Ta b l e 1-1 Attributes of a Proper Installation Site
Consideration Details
Environmental
factors
If the installation site for your display is one where it will operate 24 hours a day, such as an airport or
train station, or where its will be exposed to:
• Heavy dust
• High or low temperatures
• High humidity
Table 1-1.
About Choosing the Proper Installation Site
• Chemical substances
Be sure that only a qualified technician performs the installation. Personnel who are not qualified might
not understand how to prevent serious damage to your LCD display that can occur in such settings.
Ventilation and
clearance
To ensure reliable operation of your display and to protect it from overheating, which might result
in
fire:
• Install your display in a well ventilated location with more than 10 cm clearance from the wall.
• Never block or cover the slots and openings in the display cabinet, including those on the back and
bottom. They provide necessary ventilation.
• Never cover the slots and openings with a cloth or other materials.
• Never block the slots and openings by placing your display on a bed, sofa, rug or other similar
surface.
• Never place your display in a confined space, such as a rack, bookcase, closet, or built-in cabinet,
unless it provides sufficient ventilation.
Heat sources Protect your display from combustible materials and from sources of additional heat.
• Never operate this product near lit candles, mosquito repellent, cigarettes, or any heating
appliances.
• Keep heating appliances as far away from the power cord and the display as possible.
Physical stability Do not install your LCD display in an unstable location such as a poorly anchored shelf, a slanted floor,
or a location exposed to vibration.
Child safety
OL-17986-01
Warning
Keep all accessories and product package materials out of reach of young children.
Do not allow children to dangle or hang from the display at any time.
User Guide for Cisco LCD Professional Series Displays
1-3
About Installing Your Display Safely
About Installing Your Display Safely
Cisco LCD Professional Series displays are not designed to stand freely on the floor. They must be
installed correctly in an appropriate mount, bracket, stand, rack, or cabinet.
Chapter 1 Important Safety and Compliance Information
Warning
Dropping this equipment, handling it roughly, or allowing it to fall might damage it or cause
personal injury.
• Ensure that at least two persons lift and move the display.
• When putting the display down, be sure to put it down softly.
• Never place the display face-down on the floor.
• When installing the display in a cabinet or rack, make sure that the front end of the bottom of the
product does not project out. Use a cabinet or rack of a size appropriate to the product.
• If the display will be mounted to a wall, ensure that a qualified contractor installs the wall mount,
and make sure that the wall mount is designed specifically for a display like yours.
• Some installation sites have attributes that can cause serious damage to your display. Contact Cisco
or a Cisco-authorized Digital Media Systems partner before installing your display in any physical
location where it will be exposed to heavy dust, high or low temperatures, high humidity, or
chemical substances, or anywhere that it will operate continuously for more than 20 hours at a time,
such as an airport, a train station, or a similar setting.
About Cleaning Your Display Safely
• Cleaning the LCD Display Surface, Case, and Housing Safely, page 1-4
• Cleaning the Power Plug and the Electrical Outlet Safely, page 1-5
Cleaning the LCD Display Surface, Case, and Housing Safely
Disconnect the power cord and use the soft cotton flannel cleaning cloth that shipped with your LCD
display. Moisten the cloth slightly with LCD panel cleanser or use water. If you must use a cleanser that
is not formulated specifically for use with LCD display panels, dilute it with water at a ratio of 1:10.
• Wipe the display case.
• Wipe the surface of the TFT-LCD screen.
• To prevent product discoloration, structural distortion, erasure of printing, and peeling of the screen
surface, never spray any cleanser directly onto any surface of your display. In particular, avoid using
any cleanser formulation that contains wax, acetone, benzene, alcohol, paint thinner, or any other
flammable or corrosive substance.
• Because the display housing is easily scratched, use the specified cloth only. As your LCD display
may be scratched if there is any foreign material on the cloth, shake the cloth thoroughly before
using it.
User Guide for Cisco LCD Professional Series Displays
1-4
OL-17986-01
Chapter 1 Important Safety and Compliance Information
Cleaning the Power Plug and the Electrical Outlet Safely
Disconnect the power cord and use the soft fabric cleaning cloth that shipped with your LCD display.
• To prevent electric shock, fire, and malfunctions that might occur as a result of improper cleaning:
–
Never moisten the cloth when you clean the power plug pins or dust the power outlet. Always
use the cloth dry.
–
Never spray water directly onto the main body of your LCD display. Ensure that water does not
enter your LCD display and that it is not wet.
• To prevent changes in the appearance of the product surface and peeling of stickers from its surface
from cleaning, never not any formulation that contains wax, acetone, benzene, alcohol, paint thinner,
or any other flammable or corrosive substance.
About Batteries
Note Product kits that shipped before April 2, 2009 include AAA batteries for your remote control. After this
date, the product kit no longer includes these batteries, which are sold separately.
About Batteries
The remote control for your LCD display uses batteries. In your community there might be
environmental and safety regulations that require you to dispose of these batteries properly. To learn how
these requirements affect you, contact your local authorities.
Store batteries and all other accessories in a location where they are safely out of the reach of children.
Do not dispose of batteries in a fire.
Do not short circuit, disassemble or overheat batteries.
There is a danger of explosion if you use the wrong type of batteries. Replace batteries only with the
same type (or its equivalent) that you received from Cisco.
Regulatory Compliance Notes and Notices
Your LCD display is marked to indicate its compliance with standards set forth by the prevailing
regulatory agencies in multiple regions, including but not limited to these:
• USA—Federal Communications Commission (FCC) and other agencies
• Canada—Industry Canada Equipment Standard for Digital Equipment (ICES-003)
• Japan—Voluntary Control Council for Interference (VCCI)
• Tai w an —Bureau of Standards Metrology and Inspection (BSMI)
• Europe—Conformité Européenne (CE)
• Republic of Korea—Ministry of Information and Communication (MIC)
OL-17986-01
• Italy—Italian Post Ministry (Homologation)
• Sweden—Swedish Board for Technical Accreditation (SWEDAC)
• Norway—Norges Elektriske Materiellkontroll (NEMKO)
• Russia—Gosstandart; Gosudarstvennyy Standart (GOST)
User Guide for Cisco LCD Professional Series Displays
1-5
Regulatory Compliance Notes and Notices
United States
• FCC Class A Notice, page 1-6
• FCC Class B Notice, page 1-6
• User Information, page 1-7
• Important Safety Instructions (UL Only), page 1-7
• EPA, page 1-8
• Mercury Statement, page 1-8
FCC Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Chapter 1 Important Safety and Compliance Information
Operation is subject to the following two conditions:
Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
FCC Class B Notice
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation.
Operation is subject to the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that may cause undesired
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired
operation.
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
operation.
1-6
User Guide for Cisco LCD Professional Series Displays
OL-17986-01
Chapter 1 Important Safety and Compliance Information
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
User Information
This LCD display shows television closed captioning in accordance with Section 15.119 of FCC rules.
To maintain FCC compliance for your LCD display, you must use shielded signal cables.
A detachable power supply cord with IEC320-style terminations is provided with your LCD display.
• For 120 Volt applications, use only UL Listed detachable power cord with NEMA configuration
5-15P type (parallel blades) plug cap.
• For 240 Volt applications use only UL Listed detachable power supply cord with NEMA
configuration 6-15P type (tandem blades) plug cap.
Changes or modifications not expressly approved by the original equipment manufacturer can void your
authority to operate this LCD display. If necessary, consult with your dealer or an experienced
radio/television technician for additional suggestions. You may find the booklet called How to Identify
and Resolve Radio/TV Interference Problems helpful. This booklet was prepared by the Federal
Communications Commission. It is available from the U.S. Government Printing Office.Washington,
DC 20402, Stock Number 004-000-00345-4.
Regulatory Compliance Notes and Notices
Important Safety Instructions (UL Only)
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with manufacturer instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
OL-17986-01
User Guide for Cisco LCD Professional Series Displays
1-7
Regulatory Compliance Notes and Notices
12. Use only with cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
Chapter 1 Important Safety and Compliance Information
Warning
To prevent damage which may result in fire or electric shock hazard, do not expose this appliance to
rain or moisture.
EPA
This product meets the ENERGY STAR guidelines for energy efficiency.
Mercury Statement
Contains mercury. Dispose according to local, state or federal laws.
Canada
• ICES-003 Class A Notice (Avis NMB-003, Classe A), page 1-8
• ICES-003 Class B Notice (Avis NMB-003, Classe B), page 1-8
ICES-003 Class A Notice (Avis NMB-003, Classe A)
This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe
A est conforme à la norme NMB-003 du Canada.
ICES-003 Class B Notice (Avis NMB-003, Classe B)
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe
B est conforme à la norme NMB-003 du Canada.
Japan
• VCCI Class A Notice, page 1-9
• VCCI Class B Notice, page 1-9
User Guide for Cisco LCD Professional Series Displays
1-8
OL-17986-01
Chapter 1 Important Safety and Compliance Information
VCCI Class A Notice
VCCI Class B Notice
Taiwan—BSMI Class A Notice
The following statement is applicable to products shipped to Taiwan and marked as Class A on the
product compliance label.
Regulatory Compliance Notes and Notices
Republic of Korea
MIC Class A Notice
MIC Class B Notice
Europe and its Member Nations
• European Notice, page 1-10
• European Class A Warning, page 1-10
• UK—Wiring the Mains: Power Supply Plug, page 1-10
• Italy—Homologation Notice, page 1-11
• Sweden—Swedish Confederation of Professional Employees (TCO), page 1-11
OL-17986-01
• Norway—Norges Elektriske Materiellkontroll (NEMKO), page 1-11
User Guide for Cisco LCD Professional Series Displays
1-9
Regulatory Compliance Notes and Notices
European Notice
Products with the CE marking comply with the EMC Directive (89/336/EEC), (92/31/EEC),
(93/68/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European
Community. Compliance with these directives implies conformity to the following European norms:
• EN55022: Radio Frequency Interference
• EN55024: Electromagnetic Immunity of Information Technology Equipment
• EN61000-3-2: Power Line Harmonics
• EN61000-3-3: Voltage Fluctuations
• EN55013: Radio disturbance characteristics of broadcast receivers and associated equipment
• EN55020: Electromagnetic immunity of broadcast receivers and associated equipment
European Class A Warning
This is a Class A product. In a domestic environment this product may cause radio interference in which
case you may be required to take adequate measures.
Chapter 1 Important Safety and Compliance Information
UK—Wiring the Mains: Power Supply Plug
Before disconnecting the power supply plug from the mains, contact Cisco or a Cisco-authorized Digital
Media Systems partner.
The mains lead on this equipment is supplied with a moulded plug incorporating a fuse. The value of the
fuse is indicated on the pin face of the plug and, if it requires replacing, a fuse approved to BSI1362 of
the same rating must be used. Never use the plug with the fuse cover omitted if the cover is detachable.
If a replacement fuse cover is required, it must be of the same colour as the pin face of the plug.
Replacement covers are available from your dealer. If the fitted plug is not suitable for the power points
in your house or the cable is not long enough to reach a power point, you should obtain a suitable safety
approved extension lead or consult your dealer for assistance. However, if there is no alternative but to
cut off the plug, remove the fuse and then safely dispose of the plug. Do not connect the plug to a mains
socket as there is a risk of shock hazard from the bared flexible cord.
The wires in the mains lead are coloured in accordance with the following code:
• Blue is neutral.
• Brown is live.
As these colours may not correspond to the coloured markings identifying the terminals in your plug,
proceed as follows:
• The wire coloured blue must be connected to the terminal marked with the letter N or coloured blue
or black.
• The wire coloured brown must be connected to the terminal marked with the letter L or coloured
brown or red.
1-10
Warning
User Guide for Cisco LCD Professional Series Displays
Do not connect either wire to the earth terminal, which is marked with the letter E, or by the Earth
symbol, or is coloured green, or is coloured green and yellow.
OL-17986-01
Chapter 1 Important Safety and Compliance Information
Italy—Homologation Notice
Questo apparecchio e fabbricato in conformita al D.M.28.08.95 n.548 ed in particolare a quanto
specificato nell Art.2, comma 1. Questo apparecchio e fabbricato nella U.E. in conformita al
D.M.28.08.95 n.548 Art.2, comma 1 ed al D.M.26.03.92 Art.1.
• For products produced in countries except European Community — Questo apparecchio e
fabbricato in conformita al D.M.28.08.95 n.548 ed in particolare a quanto specificato nell Art.2,
comma 1.
• For products produced in European Community — Questo apparecchio e fabbricato nella U.E.
in conformita al D.M.28.08.95 n.548 Art.2, comma 1 ed al D.M.26.03.92 Art.1.
Sweden—Swedish Confederation of Professional Employees (TCO)
• MPR II Compliance Notice, page 1-11
• TCO 95 and TCO 99 Certificates, page 1-11
MPR II Compliance Notice
Regulatory Compliance Notes and Notices
This LCD display complies with SWEDAC (MPR II) recommendations for reduced electric and
magnetic fields.
TCO 95 and TCO 99 Certificates
For information about recycling TCO-certified Cisco LCD displays, contact Cisco or a Cisco-authorized
Digital Media Systems partner.
Norway—Norges Elektriske Materiellkontroll (NEMKO)
• Risk of Hazard Connecting Class l Equipment to Cable Distribution Networks, page 1-11
• N-mark for Medical Electrical Equipment, page 1-12
Risk of Hazard Connecting Class l Equipment to Cable Distribution Networks
For Class l equipment in Norway, intended to be connected to cable distribution systems, the screen of
a coaxial cable is required to be galvanic isolated from the protective earth.
• Connection to a Cable Distribution System is to be provided through a galvanic isolator.
• Må kun tilkoples kabel-TV nett via galvanisk isolator.
OL-17986-01
User Guide for Cisco LCD Professional Series Displays
1-11
Regulatory Compliance Notes and Notices
N-mark for Medical Electrical Equipment
Classifications
In accordance with UL 2601-1/IEC 60601-1, the product is classified as continuous duty Class I
equipment, which is not protected against ingress of liquids. The product is not suitable for use in the
presence of a flammable anaesthetic mixture with air or with oxygen or nitrous oxide.
• Type of protection against electrical shock: Class l.
• Degree of protection against electrical shock (Patient connection): Not applicable.
• Degree of protection against harmful ingress of water: Ordinary equipment.
• Methods of sterilization or disinfection: Not applicable.
• Degree of safety of application in the presence of a flammable anesthetic material with air or with
oxygen or nitrous oxide: Equipment not suitable for use in the presence of a flammable anesthetic
mixture with air or with oxygen or nitrous oxide.
Chapter 1 Important Safety and Compliance Information
• Mode of operation: Continuous.
EMC
This equipment has been tested and found to comply with the limits for medical devices to the IEC
60601-1-2:2001. These limits are designed to provide reasonable protection against harmful interference
in a typical medical installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to other
devices in the vicinity. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to other devices, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving device.
• Increase the separation between the equipment.
• Connect the equipment into an outlet on a circuit different from that to which the other device (s)
are connected.
• Consult the manufacturer or field service technician for help.
Video In / RS 232 / Video Out
Accessories equipment connected to the analog and digital interfaces must be certified to the respective
IEC standards (i.e. IEC 60950-1 for data processing equipment and IEC 60601-1 for medical
equipment.) Furthermore all configurations shall comply with the system standard IEC 60601-1-1.
Anyone who connects additional equipment to the signal input part or signal output part configures a
medical system, and is therefore, responsible that the system complies with the requirements of the
system standard IEC 60601-1-1. If in doubt, consult the technical services department or your local
representative.
1-12
User Guide for Cisco LCD Professional Series Displays
OL-17986-01
Loading...
