Preface

This preface describes the objectives and organization of this document and explains how to find additional information on related products and services. This preface contains the following sections:

• Objectives, page vii

• Changes to This Document, page vii

• Organization, page ix

• Related Documentation, page x

• Obtaining Documentation and Submitting a Service Request, page x

Objectives

This document describes the Cisco 7600 Ethernet Services Plus line cards that are supported on the Cisco 7600 series routers. This document also describes how to install the Cisco 7600 Series ES+ line cards and how to troubleshoot the installation.

Changes to This Document

Table 1 records technical changes to this document. The table shows the Cisco IOS software release

number and document revision number for the change, the date of the change, and a brief summary of the change.

Table 1 Document Revision History

Release No. Revision Date Change Summary

15.3(1)S OL-16146-10 November 2012 Added support for the 76-ES+XT-8TG

15.2(4)S OL-16146-09 July 2012 Added support for the 76-ES+T-8TG low

15.2(2)S OL-16146-08 March 2012 Added support for two new low queue

high queue card.

queue card.

line cards:

• 76-ES+T+XC-20G

• 76-ES+T+XC-40G

OL-16146-10

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

vii

Preface

Table 1 Document Revision History

15.1(2)S OL-16146-07 March 2011 Added support for low power XFPs, XFP-10GLR-OC192SR-L and XFP-10GLR-OC192IR-L, to these ES+ line cards:

• 7600 ES+ 2TG3C

• 7600 ES+ 2TG3CXL

• 7600 ES+ 4TG3C

• 7600 ES+ 4TG3CXL

• 76-ES+XT-2TG3C

• 76-ES+XT-2TG3CXL

• 76-ES+XT-4TG3C

• 76-ES+XT-4TG3CXL

• 76-ES+T-2TG

• 76-ES+T-4TG

• 76-ES+XC-20G3C

• 76-ES+XC-20G3CXL

• 76-ES+XC-40G3C

• 76-ES+XC-40G3CXL

12.2(33)SRD5 OL-16146-06 October 2010 Added troubleshooting information for line card power issues in

“Troubleshooting” chapter.

15.0(1)S OL-16146-05 July 2010 Updated Tab le 1-3 for Cisco 7600 ES+ Line Card and Cisco IOS Release and Hardware Version Compatibility information in“Cisco 7600 Ethernet

Services Plus Line Card Product Overview” chapter.

12.2(33)SRE OL-16146-04 February 2010 Updated table 1-2 in chapter 1.

viii

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

Preface

Table 1 Document Revision History

12.2(33)SRE OL-16146-04 December 2009 Added support for the following line cards:

• 7600-ES+20C3C

• 7600-ES+20C3CXL

• 7600-ES+40C3C

• 7600-ES+40C3CXL

• 76-ES+XT-2TG3C

• 76-ES+XT-4TG3C

Added support for additional DWDM SFPs (DWDM-SFP-3346, DWDM-SFP-3739, DWDM-SFP-4134, DWDM-SFP-4532, DWDM-SFP-4931, DWDM-SFP-5332, DWDM-SFP-5736, DWDM-SFP-6141)

12.2(33)SRD3 OL-16146-03 September 2009 Added support for the following line cards:

76-ES+T-20G

76-ES+T-2TG

12.2(33)SRD1 OL-16146-02 Added support for the following ES+

12.2(33)SRD OL-16146-01 February, 2007 Initial version.

Organization

This document contains the following chapters:

Section Title Description

Chapter 1 Cisco 7600 Ethernet Services Plus

Chapter 2 Overview: Cisco 7600 Series

Chapter 3 Preparing to Install a Cisco 7600

Line Card Product Overview

Ethernet Services Plus Line Cards

Series Ethernet Services Plus Line Card

76-ES+T-40G

76-ES+T-4TG

Extended Transport (ES+XT) line cards:

• 76-ES+XT-2TG3CXL

• 76-ES+XT-4TG3CXL

Provides an introduction to the Cisco 7600 Series Ethernet Services Plus line cards.

Provides a compatibility summary for the Cisco 7600 Series Ethernet Services Plus line cards. For each supported ES+ line card, provides a summary of characteristics and an overview.

Describes the required tools, equipment, and safety guidelines for installing Cisco 7600 Series Ethernet Services Plus line cards.

OL-16146-10

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

Section Title Description

Chapter 4 Installing and Removing a Cisco

7600 Series Ethernet Services Plus Line Card

Chapter 5 Installing and Removing SFP and

XFP Modules

Chapter 6 Troubleshooting Provides information for troubleshooting the

Obtaining Documentation and Submitting a Service Request

For information on obtaining documentation, submitting a service request, and gathering additional information, see the monthly What’s New in Cisco Product Documentation, which also lists all new and revised Cisco technical documentation, at:

http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

Preface

Subscribe to the What’s New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed and set content to be delivered directly to your desktop using a reader application. The RSS feeds are a free service and Cisco currently supports RSS Version 2.0.

OL-16146-10

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

Preface

xii

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

CHA P T E R

Cisco 7600 Ethernet Services Plus Line Card Product Overview

This chapter provides an introduction to the Cisco 7600 Series Ethernet Services Plus (ES+) line cards and ES+ combo low queue line cards. It includes the following sections:

• Introduction to the Cisco 7600 ES+ and ES+ Combo Low Queue Line Cards, page 1-1

• Cisco IOS Software Release and Hardware Revision Requirements, page 1-5

• Modular Optics Compatibility, page 1-6

• Power Management, page 1-8

Introduction to the Cisco 7600 ES+ and ES+ Combo Low Queue Line Cards

The Cisco 7600 Series ES+ line cards are a multiple-fabric, fixed-port Ethernet line card for the Cisco 7600 series routers that are capable of 40 gbps full-duplex traffic forwarding using a fixed port interface design. The Cisco 7600 Series ES+ line card versions are:

• 40-port version: 7600-ES+40G3C

• 40-port version: 7600-ES+40G3CXL

• 20-port version: 7600-ES+20G3C

• 20-port version: 7600-ES+20G3CXL

• 4-port version: 7600-ES+4TG3C

• 4-port version: 7600-ES+4TGCXL

• 2-port version: 7600-ES+2TG3C

• 2-port version: 7600-ES+2TGCXL

• 2-port version: 76-ES+XT-2TG3C

• 2-port version: 76-ES+XT-2TG3CXL

• 4-port version: 76-ES+XT-4TG3C

• 4-port version: 76-ES+XT-4TG3CXL

• 20-port version: 76-ES+T-20G

• 2-port version: 76-ES+T-2TG

OL-16146-10

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

1-1

Introduction to the Cisco 7600 ES+ and ES+ Combo Low Queue Line Cards

• 40-port version: 76-ES+T-40G

• 4-port version: 76-ES+T-4TG

• 11-port version: 76-ES+XC-20G3C

• 11-port version: 76-ES+XC-20G3CXL

• 22-port version: 76-ES+XC-40G3C

• 22-port version: 76-ES+XC-40G3CXL

• 11-port version: 76-ES+T+XC-20G

• 22-port version: 76-ES+T+XC-40G

• 8-port version: 76-ES+T-8TG

• 8-port version: 76-ES+XT-8TG

The difference between the versions are the link interface daughter cards that accept small form-factor pluggable (SFP, SFP+, or XFP

) optical transceivers. Additionally, each of the versions has a common baseboard card and a control processor daughter card, except for the 8 port version (76-ES+T-8TG) which has a different baseboard.

The SFP, SFP+, and XFP modules allow the line cards to be configured for different media types (copper or fiber) and different optical requirements (single mode fiber or multimode fiber) as available.

See Table 1-4 for information about which SFPs, SFP+, or XFPs are accepted on the different Cisco 7600 Series ES+ line cards.

Chapter 1 Cisco 7600 Ethernet Services Plus Line Card Product Overview

Product Overview

The Cisco 7600 Series ES+ line cards have the following features:

The system features listed here specify some of the key performance metrics and capabilities of the line cards. The information below applies to all four line cards unless stated otherwise.

• Line rate feature processing performance with 64 byte packets for four ports of 10 GE or forty ports

of GE (59.52Mpps). Note that the line card throughput is limited by the system switch fabric. The packet processor and internal sections of the line card are full line rate throughput capable for 40GbE.

• Large output buffers provide up to 200 mS of round-trip-time buffer (100 mS in each direction) per

10GE port or 10xGE ports to prevent transient output overloads from causing spurious packet loss.

• Up to 32K queues (per 10GE port or 10xGE ports) per direction for input or output queuing and

scheduling.

• Programmable ingress and egress feature processing capability through the Trident.

• 40+ Mpps Layer 3 or Layer 4 forwarding, 125Mpps Layer 2 forwarding.

• Dual fabric attachment providing an aggregate bandwidth of 40Gb/s, full duplex (each fabric

channel provides 20Gb/s, full duplex).

• 512-MB boot disk

1-2

1. SFP modules are optics modules with speeds lower than 10 Gbps; SFP+ and XFP modules are optics modules

with speeds equal to or greater than 10 Gbps.

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

Chapter 1 Cisco 7600 Ethernet Services Plus Line Card Product Overview

Introduction to the Cisco 7600 ES+ and ES+ Combo Low Queue Line Cards

Cisco 7600 Series Ethernet Services Plus Line Card Product Numbers

Table 1-1 lists the Cisco product numbers for the line cards.

Table 1-1 Cisco 7600 Ethernet Services Plus Line Card Product Numbers

Field-Replaceable Unit

Description Cisco Product Number

20xGE SFP with DFC 3C 7600-ES+20G3C 7600-ES+20G3C=

20xGE SFP with DFC 3CXL 7600-ES+20G3CXL 7600-ES+20G3CXL=

2x10GE XFP with DFC 3C 7600-ES+2TG3C 7600-ES+2TG3C=

2x10GE XFP with DFC 3CXL 7600-ES+2TG3CXL 7600-ES+2TG3CXL=

40xGE SFP with DFC 3C 7600-ES+40G3C 7600-ES+40G3C=

40xGE SFP with DFC 3CXL 7600-ES+40G3CXL 7600-ES+40G3CXL=

4x10GE XFP with DFC 3C 7600-ES+4TG3C 7600-ES+4TG3C=

4x10GE XFP with DFC 3CXL 7600-ES+4TG3CXL 7600-ES+4TG3CXL=

7600 ES+XT, LAN/WAN PHY, OTN/G.709,

76-ES+XT-2TG3C 76-ES+XT-2TG3C=

2x10GE, XFP, DFC3C

7600 ES+XT, LAN/WAN PHY, OTN/G.709,

76-ES+XT-2TG3CXL 76-ES+XT-2TG3CXL=

2x10GE, XFP, DFC3CXL

7600 ES+XT, LAN/WAN PHY, OTN/G.709,

76-ES+XT-4TG3C 76-ES+XT-4TG3C=

4x10GE, XFP, DFC3C

7600 ES+XT, LAN/WAN PHY, OTN/G.709,

76-ES+XT-4TG3CXL 76-ES+XT-4TG3CXL=

4x10GE, XFP, DFC3CXL

20xGE with DFC 3CXL 76-ES+T-20G 76-ES+T-20G=

2x10GE with DFC 3CXL 76-ES+T-2TG 76-ES+T-2TG=

40xGE with DFC 3CXL 76-ES+T-40G 76-ES+T-40G=

4x10GE with DFC 3CXL 76-ES+T-4TG 76-ES+T-4TG=

7600 ES+XC, LAN/WAN PHY, OTN/G.709,

76-ES+XC-20G3C 76-ES+XC-20G3C=

Combo 10x1GE/ 1x10GE, DFC3C

7600 ES+XC, LAN/WAN PHY, OTN/G.709,

76-ES+XC-20G3CXL 76-ES+XC-20G3CXL=

Combo 10x1GE/ 1x10GE, DFC3CXL

7600 ES+XC, LAN/WAN PHY, OTN/G.709,

76-ES+XC-40G3C 76-ES+XC-40G3C=

Combo 20x1GE/ 2x10GE, DFC3C

7600 ES+XC, LAN/WAN PHY, OTN/G.709,

76-ES+XC-40G3CXL 76-ES+XC-40G3CXL=

Combo 20x1GE/ 2x10GE, DFC3CXL

7600 ES+XC, LAN/WAN PHY, OTN/G.709,

76-ES+T+XC-20G 76-ES+T+XC-20G=

Combo 10x1GE/ 1x10GE, DFC3CXL

7600 ES+XC, LAN/WAN PHY, OTN/G.709,

76-ES+T+XC-40G 76-ES+T+XC-40G=

Combo 20x1GE/ 2x10GE, DFC3CXL

8x10GE with DFC 3CXL 76-ES+T-8TG 76-ES+T-8TG=

8x10GE with DFC 3CXL 76-ES+XT-8TG3CXL 76-ES+XT-8TG3CXL=

(FRU) Product ID

OL-16146-10

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

1-3

Introduction to the Cisco 7600 ES+ and ES+ Combo Low Queue Line Cards

Note The Distributed Forwarding Card (DFC) on a 7600 ES+ line card functions at the level of the lowest

common denominator DFC in the system. If the only DFC in a system is a DFC 3CXL, then the system would operate at the 3CXL level. If a DFC 3CXL is configured in a system with a DFC3BXL present, then the system will function at the DFC 3BXL level. Additionally, a DFC 3CXL provides for more TCAM entries than does a DFC 3C.

Supported Platforms

Table 1-2 lists the supported router platforms for Cisco 7600 ES+ line cards:

Table 1-2 Cisco 7600 ES+ Line Card Supported Router Platforms

Cisco 7600 ES+ Line Card Supported Platform

7600-ES+20G3C All Cisco 7600 series routers except for the Cisco 7603 router

7600-ES+20G3CXL All Cisco 7600 series routers except for the Cisco 7603 router

7600-ES+2TG3C All Cisco 7600 series routers except for the Cisco 7603 router

7600-ES+2TG3CXL All Cisco 7600 series routers except for the Cisco 7603 router

7600-ES+40G3C All Cisco 7600 series routers except for the Cisco 7603 router

7600-ES+40G3CXL Except for the Cisco 7603 router, all Cisco 7600 series routers including

7603-S.

7600-ES+4TG3C All Cisco 7600 series routers except for the Cisco 7603 router

7600-ES+4TG3CXL All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+XT-2TG3C All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+XT-2TG3CXL All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+XT-4TG3C All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+XT-4TG3CXL All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+T-20G All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+T-2TG All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+T-40G All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+T-4TG All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+XC-20G3C All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+XC-20G3CXL All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+XC-40G3C All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+XC-40G3CXL All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+T+XC-20G All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+T+XC-40G All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+T-8TG All Cisco 7600 series routers except for the Cisco 7603 router

76-ES+XT-8TG3CXL All Cisco 7600 series routers except for the Cisco 7603 router

Chapter 1 Cisco 7600 Ethernet Services Plus Line Card Product Overview

1-4

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

Chapter 1 Cisco 7600 Ethernet Services Plus Line Card Product Overview

Cisco IOS Software Release and Hardware Revision Requirements

The Cisco 7600 ES+ line cards have certain Cisco IOS software requirements. Also, to ensure compatibility with the software, your Cisco 7600 ES+ line card should have a specific hardware revision number. The number is printed on a label affixed to the component side of the card and is displayed by the show diag command.

Table 1-3 lists the hardware and software requirements for Cisco 7600 ES+ line cards.

Table 1-3 Cisco 7600 ES+ Line Card and Cisco IOS Release and Hardware Version

Compatibility

Cisco 7600 ES+ Line Card Cisco Product Number

7600 ES+ Line Card, 20xGE SFP with DFC 3C

7600 ES+ Line Card, 20xGE SFP with DFC 3CXL

7600 ES+ Line Card, 2x10GE XFP with DFC 3C

7600 ES+ Line Card, 2x10GE XFP with DFC 3CXL

7600 ES+ Line Card, 40xGE SFP with DFC 3C

7600 ES+ Line Card, 40xGE SFP with DFC 3CXL

7600 ES+ Line Card, 4x10GE XFP with DFC 3C

7600 ES+ Line Card, 4x10GE XFP with DFC 3CXL

7600 ES+XT, LAN/WAN PHY, OTN/G.709, 2x10GE, XFP, DFC3C

7600 ES+XT, LAN/WAN PHY, OTN/G.709, 2x10GE, XFP, DFC3CXL

7600 ES+XT, LAN/WAN PHY, OTN/G.709, 4x10GE, XFP, DFC3C

7600 ES+XT, LAN/WAN PHY, OTN/G.709, 4x10GE, XFP, DFC3CXL

7600 ES+T Line Card, 20xGE SFP with DFC 3CXL

7600 ES+XT, LAN/WAN PHY, OTN/G.709, Low Queue, 2x10GE, XFP, DFC3CXL

7600 ES+T Line Card, 40xGE SFP with DFC 3CXL

7600-ES+20G3C 68-2868-05 Cisco IOS Release

7600-ES+20G3CXL 68-3030-05 Cisco IOS Release

7600-ES+2TG3C 68-2867-04 Cisco IOS Release

7600-ES+2TG3CXL 68-3029-04 Cisco IOS Release

7600-ES+40G3C 68-2869-05 Cisco IOS Release

7600-ES+40G3CXL 68-3032-05 Cisco IOS Release

7600-ES+4TG3C 68-2866-06 Cisco IOS Release

7600-ES+4TG3CXL 68-3031-06 Cisco IOS Release

76-ES+XT-2TG3C 68-3558-01 Cisco IOS Release

76-ES+XT-2TG3CXL 68-3335-03 Cisco IOS Release

76-ES+XT-4TG3C 68-3557-01 Cisco IOS Release

76-ES+XT-4TG3CXL 68-3336-03 Cisco IOS Release

76-ES+T-20G 68-3030-06 Cisco IOS Release

76-ES+T-2TG 68-3029-05 Cisco IOS Release

76-ES+T-40G 68-3032-06 Cisco IOS Release

Required Hardware Version

Minimum Cisco IOS Software Release

12.2(33)SRD

12.2(33)SRD1

12.2(33)SRD4

OL-16146-10

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

1-5

Modular Optics Compatibility

Table 1-3 (continued)Cisco 7600 ES+ Line Card and Cisco IOS Release and Hardware Version

Chapter 1 Cisco 7600 Ethernet Services Plus Line Card Product Overview

Compatibility (continued)

Cisco 7600 ES+ Line Card Cisco Product Number

7600 ES+XT, LAN/WAN PHY, OTN/G.709, Low Queue, 4x10GE, XFP, DFC3CXL

7600 ES+XC Combo 10x1GE/ 1x10GE, DFC3C

7600 ES+XC Combo 10x1GE/ 1x10GE, DFC3CXL

7600 ES+XC Combo 20x1GE/ 2x10GE, DFC3C

7600 ES+XC Combo 20x1GE/ 2x10GE, DFC3CXL

7600 ES+XC Combo low queue 10x1GE/ 1x10GE, DFC3CXL

7600 ES+XC Combo low queue 20x1GE/ 2x10GE, DFC3CXL

7600 ES+T Low queue 8x 10GE, DFC3CXL

7600 ES+T High queue 8x 10GE, DFC3CXL

76-ES+T-4TG 68-3031-05 Cisco IOS Release

76-ES+XC-20G3C 68-3168-06 Cisco IOS Release

76-ES+XC-20G3CXL 68-3169-06 Cisco IOS Release

76-ES+XC-40G3C 68-3166-06 Cisco IOS Release

76-ES+XC-40G3CXL 68-3167-06 Cisco IOS Release

76-ES+T+XC-20G 68-4492-2 Cisco IOS 15.2(2)S

76-ES+T+XC-40G 68-4492-1 Cisco IOS 15.2(2)S

76-ES+T-8TG Cisco IOS 15.2(4)S

76-ES+XT-8TG3CXL 68-4765-01 Cisco IOS 15.3(1)S

Required Hardware Version

Minimum Cisco IOS Software Release

12.2(33)SRD4

12.2(33)SRE

The show diag slot_number, show version, and show hardware commands display the current hardware configuration of the router, including the system software version that is currently loaded and running, and the hardware revision number. For complete descriptions of show commands, refer to the

Cisco IOS Configuration Fundamentals Configuration Guide and the Cisco IOS Configuration Fundamentals Command Reference for the installed Cisco IOS release.

If the command displays indicate that the Cisco IOS software is a version earlier than you need, check the contents of flash memory to determine if the required images are available on your system. The dir devicename command displays a list of all files stored in flash memory. If you do not have the correct software version, contact Cisco customer service.

For software configuration information, refer to the Cisco IOS software configuration and command reference publications for the installed Cisco IOS release. Also refer to the Cisco IOS software release notes for additional information.

Modular Optics Compatibility

The Cisco 7600 Series ES+ line cards use small form-factor pluggable (SFP, SFP+, or XFP) optical transceivers to provide network connectivity. Table 1-4 provides links to tables showing the supported modules for the different Cisco 7600 Series ES+ line cards.

1-6

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

Chapter 1 Cisco 7600 Ethernet Services Plus Line Card Product Overview

Table 1-4 Supported Optical Transceiver Modules

Line Cards Supported Modules

7600-ES+20G3C Cisco 7600 ES+ 20G3C, -20G3CXL

7600-ES+20G3CXL

7600-ES+2TG3C Cisco 7600 ES+ 2TG3C, -3CXL Supported

7600-ES+2TG3CXL

7600-ES+40G3C Cisco 7600 ES+ 40G3C, -40G3CXL

7600-ES+40G3CXL

7600-ES+4TG3C Cisco 7600 ES+ 4TG3C, -4TG3CXL

7600-ES+4TG3CXL

76-ES+XT-2TG3C Cisco 76-ES+XT-2TG3C, -2TG3CXL

76-ES+XT-2TG3CXL

76-ES+XT-4TG3C Cisco 76-ES+XT-2TG3C, -2TG3CXL

76-ES+XT-4TG3CXL

76-ES+T-20G Supported SFP Modules; see Table 2-16 on

76-ES+T-2TG Supported XFP Modules; see Table 2-26 on

76-ES+T-40G Supported SFP Modules; see Table 2-21 on

76-ES+T-4TG Supported XFP Modules; see Table 2-31 on

76-ES+XC-20G3C Supported SFP Modules; see TBD; Supported

76-ES+XC-20G3CXL Supported SFP Modules; see TBD; Supported

76-ES+XC-40G3C Supported SFP Modules; see TBD; Supported

76-ES+XC-40G3CXL Supported SFP Modules; see TBD; Supported

76-ES+T-8TG Supported SFP+ Modules; see Table 2-78.

76-ES+XT-8TG Supported SFP+ Modules; see Table 2-83

Modular Optics Compatibility

Supported SFP Modules; see Table 2-16 on

page 2-16.

XFP Modules; see Table 2-5 on page 2-7.

Supported SFP Modules; see Table 2-21 on

page 2-21.

Supported XFP Modules; see Table 2-10 on

page 2-11.

Supported XFP Modules; see Table 2-26 on

page 2-26.

Supported XFP Modules; see Table 2-31 on

page 2-31.

page 2-16

page 2-26

page 2-21

page 2-31

XFP Modules; see TBD

OL-16146-10

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

1-7

Power Management

The Cisco ES+ line cards consume chassis power; you must make sure the chassis is within the power budget on Cisco 7600 series routers. See Tabl e 1-5 .

Table 1-5 Cisco 7600 ES+ Line Card Power Consumption

Cisco 7600 Series ES+ line cards Power Consumption (Maximum in Watts)

7600-ES+20G3C 277

7600-ES+20G3CXL 305

7600-ES+2TG3C 269

7600-ES+2TG3CXL 297

7600-ES+40G3C 391

7600-ES+40G3CXL 419

7600-ES+4TG3C 371

7600-ES+4TG3CXL 399

76-ES+XT-2TG3C 273

76-ES+XT-2TG3CXL 301

76-ES+XT-4TG3C 378

76-ES+XT-4TG3CXL 406

76-ES+T-20G 305

76-ES+T-2TG 301

76-ES+T-40G 419

76-ES+T-4TG 406

7600-ES+XC-20G3C 309

7600-ES+XC-20G3CXL 337

7600-ES+XC-40G3C 399

7600-ES+XC-40G3CXL 427

76-ES+T+XC-20G 337

76-ES+T+XC-40G 427

76-ES+T-8TG 433

76-ES+XT-8TG 433

Chapter 1 Cisco 7600 Ethernet Services Plus Line Card Product Overview

1-8

If the power limit is exceeded, the Cisco ES+ line card is not powered up and an error message is displayed.

Router#%C7KPWR-SP-4-POWERDENIED:insufficient power, module in slot 3 power denied.

On a Cisco 7600 series router, use the show power command on the Route Processor to determine how much power you have available in the chassis and how much is being used or reserved by line cards, supervisor engines, and fan trays.

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

Chapter 1 Cisco 7600 Ethernet Services Plus Line Card Product Overview

Note The show power command displays only the values programmed in the IDPROM and the IDPROM is

not dynamically updated for different power values.

This is sample output for the show power command on a Cisco 7600 series router:

Router# show power

system power redundancy mode = redundant system power redundancy operationally = non-redundant system power total = 3795.12 Watts (90.36 Amps @ 42V) system power used = 3320.94 Watts (79.07 Amps @ 42V) system power available = 474.18 Watts (11.29 Amps @ 42V) Power-Capacity PS-Fan Output Oper PS Type Watts A @42V Status Status State

---- ------------------ ------- ------ ------ ------ ----1 WS-CAC-4000W-INT 3795.12 90.36 OK OK on 2 none Pwr-Allocated Oper Fan Type Watts A @42V State

---- ------------------ ------- ------ ----1 WS-C6K-13SLT-FAN2 298.20 7.10 OK Pwr-Requested Pwr-Allocated Admin Oper Slot Card-Type Watts A @42V Watts A @42V State State

---- ------------------ ------- ------ ------- ------ ----- ----2 7600-SIP-200 240.24 5.72 240.24 5.72 on on 3 WS-X6724-SFP 125.16 2.98 125.16 2.98 on on 4 7600-SIP-400 265.02 6.31 265.02 6.31 on on 7 RSP720-3CXL-GE 354.06 8.43 354.06 8.43 on on 8 RSP720-3C-GE 354.06 8.43 354.06 8.43 on on 9 7600-ESM-BASE 304.92 7.26 304.92 7.26 on on 10 7600-ES+20G3CXL 297.36 7.08 297.36 7.08 on on 11 7600-SIP-600 341.88 8.14 341.88 8.14 on on 12 7600-SIP-600 341.88 8.14 341.88 8.14 on on 13 WS-X6704-10GE 398.16 9.48 398.16 9.48 on on Router#

Power Management

OL-16146-10

This is sample output for the show power command on a Cisco 7600 series router for a 76-ES+T+XC-40G low queue combo card:

A3-2#show power system power redundancy mode = redundant system power redundancy operationally = non-redundant system power total = 2671.20 Watts (63.60 Amps @ 42V) system power used = 1477.14 Watts (35.17 Amps @ 42V) system power available = 1194.06 Watts (28.43 Amps @ 42V) Power-Capacity PS-Fan Output Oper PS Type Watts A @42V Status Status State

---- ------------------ ------- ------ ------ ------ ----1 WS-CAC-6000W 2671.20 63.60 OK OK on 2 none Pwr-Requested Pwr-Allocated Admin Oper Slot Card-Type Watts A @42V Watts A @42V State State

---- ------------------ ------- ------ ------- ------ ----- ----1 7600-SIP-600 341.88 8.14 341.88 8.14 on on 4 7600-ES20-GE3C 340.20 8.10 - - off off (admin request) 5 (Redundant Sup) - - 354.06 8.43 - 6 RSP720-3CXL-GE 354.06 8.43 354.06 8.43 on on 7 7600-ES+20G3C 276.36 6.58 - - off off (admin request) 8 7600-ES20-GE3C 340.20 8.10 - - off off (admin request) 9 '76-ES+T+XC-40G' 427.14 10.17 427.14 10.17 on on

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

1-9

Power Management

Chapter 1 Cisco 7600 Ethernet Services Plus Line Card Product Overview

This is sample output for the show power command on a Cisco 7600 series router for a 76-ES+T+XC-20G low queue combo card:

A1-2#show power system power redundancy mode = redundant system power redundancy operationally = non-redundant system power total = 2669.10 Watts (63.55 Amps @ 42V) system power used = 2181.90 Watts (51.95 Amps @ 42V) system power available = 487.20 Watts (11.60 Amps @ 42V) Power-Capacity PS-Fan Output Oper PS Type Watts A @42V Status Status State

---- ------------------ ------- ------ ------ ------ ----1 PWR-2700-AC 2669.10 63.55 OK OK on 2 none Pwr-Allocated Oper Fan Type Watts A @42V State

---- ------------------ ------- ------ ----1 FAN-MOD-6HS 180.18 4.29 OK Pwr-Requested Pwr-Allocated Admin Oper Slot Card-Type Watts A @42V Watts A @42V State State

---- ------------------ ------- ------ ------- ------ ----- ----1 76-ES+T+XC-20G 337.26 8.03 337.26 8.03 on on 2 WS-X6748-GE-TX 325.50 7.75 325.50 7.75 on on 3 7600-ES20-10G3CXL 340.20 8.10 340.20 8.10 on on 4 7600-SIP-600 341.88 8.14 341.88 8.14 on on 5 (Redundant Sup) - - 328.44 7.82 - 6 WS-SUP720-3BXL 328.44 7.82 328.44 7.82 on on

This is sample output for the show power command on a Cisco 7600 series router for a 76-ES+T-8TG low queue card:

Router#show power system power redundancy mode = redundant system power redundancy operationally = non-redundant system power total = 2671.20 Watts (63.60 Amps @ 42V) system power used = 1536.36 Watts (36.58 Amps @ 42V) system power available = 1134.84 Watts (27.02 Amps @ 42V) Power-Capacity PS-Fan Output Oper PS Type Watts A @42V Status Status State

---- ------------------ ------- ------ ------ ------ ----1 WS-CAC-6000W 2671.20 63.60 OK OK on 2 none Pwr-Allocated Oper Fan Type Watts A @42V State

---- ------------------ ------- ------ ----1 FAN-MOD-9SHS 241.50 5.75 OK 2 FAN-MOD-9SHS 241.50 5.75 OK Pwr-Requested Pwr-Allocated Admin Oper Slot Card-Type Watts A @42V Watts A @42V State State

---- ------------------ ------- ------ ------- ------ ----- -----

2 76-ES+T-8TG 432.60 10.30 432.60 10.30 on on

5 (Redundant Sup) - - 310.38 7.39 - 6 RSP720-3C-GE 310.38 7.39 310.38 7.39 on on

1-10

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

CHA P T E R

Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

This chapter describes the Cisco 7600 Series Ethernet Services + line cards that are supported on the Cisco 7600 series routers and contains the following sections:

• Cisco 7600 Series Ethernet Services Plus Line Card Summary, page 2-2

• Identifying Slots and Subslots for the Cisco 7600 Cisco 7600 Series ES+ Line Cards, page 2-3

• Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Line Card Overview, page 2-5

• Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Line Card Overview, page 2-9

• Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card Overview, page 2-14

• Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Line Card Overview, page 2-19

• Cisco 76-ES+XT-2TG3C, 76-ES+XT-2TG3CXL Line Card Overview, page 2-24

• Cisco 76-ES+XT-4TG3C, 76-ES+XT-4TG3CXL Line Card Overview, page 2-28

• Cisco 76-ES+T-20G Line Card Overview, page 2-33

• Cisco 76-ES+T-40G Line Card Overview, page 2-38

OL-16146-10

• Cisco 76-ES+T-2TG Line Card Overview, page 2-42

• Cisco 76-ES+T-4TG Line Card Overview, page 2-47

• Cisco 76-ES+XC-20G3C, 76-ES+XC-20G3CXL Line Card Overview, page 2-52

• Cisco 76-ES+XC-40G3C, 76-ES+XC-40G3CXL Line Card Overview, page 2-59

• Cisco 76-ES+T+XC-20G Line Card Overview, page 2-66

• Cisco 76-ES+T+XC-40G Line Card Overview, page 2-70

• Cisco 76-ES+T-8TG Line Card Overview, page 2-75

• Cisco 76-ES+XT-8TG Line Card Overview, page 2-77

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

2-1

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

Cisco 7600 Series Ethernet Services Plus Line Card Summary

Summary descriptions of the Cisco 7600 Cisco 7600 Series ES+ line cards that are supported on the Cisco 7600 series routers are shown in Tabl e 2-1 .

Table 2-1 Cisco 7600 ES+ Line Card Summary

Product Numbers Description

7600-ES+20G3C,

7600-ES+20G3CXL

7600-ES+2TG3C,

7600-ES+2TG3CXL

7600-ES+40G3C,

7600-ES+40G3CXL

7600-ES+4TG3C,

7600-ES+4TG3CXL

76-ES+XT-2TG3C,

76-ES+XT-2TG3CXL

76-ES+XT-4TG3C,

76-ES+XT-4TG3CXL

76-ES+T-20G 7600 ES+T Line Card, 20xGE

76-ES+T-40G 7600 ES+T Line Card, 40xGE

76-ES+T-2TG 7600 ES+XT, LAN/WAN

7600 ES+ Line Card, 20xGE SFP with DFC 3C

7600 ES+ Line Card, 20xGE

SFP with DFC 3CXL

7600 ES+ Line Card, 2x10GE XFP with DFC 3C

7600 ES+ Line Card, 2x10GE XFP with DFC 3CXL

7600 ES+ Line Card, 40xGE SFP with DFC 3C

7600 ES+ Line Card, 40xGE SFP with DFC 3CXL

7600 ES+ Line Card, 4x10GE XFP with DFC 3C

7600 ES+ Line Card, 4x10GE XFP with DFC 3CXL

7600 ES+XT, LAN/WAN PHY, OTN/G.709, 2x10GE, XFP, DFC3C

7600 ES+XT, LAN/WAN PHY, OTN/G.709, 2x10GE, XFP, DFC3CXL

7600 ES+XT, LAN/WAN PHY, OTN/G.709, 4x10GE, XFP, DFC3C

7600 ES+XT, LAN/WAN PHY, OTN/G.709, 4x10GE, XFP, DFC3CXL

SFP with DFC 3CXL

SFP with DFC 3CX

PHY, OTN/G.709,Low queue, 2x10GE, XFP, DFC3CXL

Maximum Number of SFPs or XFPs

20 SFPs Cisco IOS

2 XFPs Cisco IOS

40 SFPs Cisco IOS

4 XFPs Cisco IOS

2 XFPs Cisco IOS

4 XFPs Cisco IOS

20 SFPs Cisco IOS

40 SFPs Cisco IOS

2 XFPs Cisco IOS

Minimum Cisco IOS Release

Release

12.2(33)SRD

Release

12.2(33)SRD

Release

12.2(33)SRD

Release

12.2(33)SRD

Release

12.2(33)SRD1

Release

12.2(33)SRD1

Release

12.2(33)SRD3

Release

12.2(33)SRD3

Release

12.2(33)SRD3

2-2

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

Identifying Slots and Subslots for the Cisco 7600 Cisco 7600 Series ES+ Line Cards

Table 2-1 Cisco 7600 ES+ Line Card Summary (continued)

Maximum Number

Product Numbers Description

76-ES+T-4TG3XCL 7600 ES+XT, LAN/WAN

PHY, OTN/G.709,Low queue, 4x10GE, XFP, DFC3CXL

76-ES+XC-20G3C

76-ES+XC-20G3CXL

76-ES+XC-40G3C

76-ES+XC-40G3CXL

7600 ES+XC Combo 10x1GE/ 1x10GE, DFC3C

7600 ES+XC Combo 10x1GE/ 1x10GE, DFC3CXL

7600 ES+XC Combo 20x1GE/ 2x10GE, DFC3C

7600 ES+XC Combo 20x1GE/ 2x10GE, DFC3CXL

of SFPs or XFPs

4 XFPs Cisco IOS

10 SFPs, 1 XFP Cisco IOS

20 SFPs, 2 XFPs Cisco IOS

Checking Hardware and Software Compatibility

To check the minimum software requirements of Cisco IOS software with the hardware installed on your router, Cisco maintains the Software Advisor tool on Cisco.com. This tool does not verify whether the Cisco 7600 Series ES+ line cards within a system are compatible, but it does provide the minimum Cisco IOS requirements for individual hardware modules or components.

Minimum Cisco IOS Release

Release

12.2(33)SRD3

Release

12.2(33)SRE

Release

12.2(33)SRE

Note Access to this tool is limited to users with Cisco.com login accounts.

To access Software Advisor, click Login at Cisco.com, type “Software Advisor” in the SEARCH box, and click GO. Click the link for the Software Advisor tool.

Choose a product family or enter a specific product number to search for the minimum supported software release needed for your hardware.

Identifying Slots and Subslots for the Cisco 7600 Cisco 7600 Series ES+ Line Cards

This section describes how to specify the physical location of a Cisco 7600 Cisco 7600 Series ES+ line cards on the Cisco 7600 series routers within the command-line interface (CLI) to configure or monitor those devices.

Specifying the Slot Location for a Cisco 7600 Cisco 7600 Series ES+ Line Cards

The Cisco 7600 series routers support different chassis models, each of which supports a certain number of chassis slots.

OL-16146-10

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

2-3

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

Identifying Slots and Subslots for the Cisco 7600 Cisco 7600 Series ES+ Line Cards

Note The Cisco 7600 Series ES+ line cards are not supported with a Supervisor Engine 1, Supervisor

Engine 1A, Supervisor Engine 2, Supervisor Engine 720-3A, or Supervisor Engine 32.

For information about the chassis slots available in different Cisco 7600 series router models, see

http://www.cisco.com/univercd/cc/td/doc/product/core/cis7600/hardware/cis_76xx/osr_over.htm.

Some commands allow you to display information about the Cisco 7600 Series ES+ line card itself, such as show module, show idprom module, show hw-module slot, and show diagbus. These commands require you to specify the chassis slot location where the Cisco 7600 Series ES+ line card that you want information about is installed.

For example, to display status and information about the Cisco 7600 Series ES+ line card installed in slot 10 of a Cisco 7609 router, enter the following command:

Router# show module 10

Mod Ports Card Type Model Serial No.

--- ----- -------------------------------------- ------------------ ---------- 10 20 7600 ES+ 7600-ES+20G3CXL JAE1151865I

Mod MAC addresses Hw Fw Sw Status

--- ---------------------------------- ------ ------------ ------------ ------ 10 001d.e5e8.2a00 to 001d.e5e8.2a3f 0.301 12.2(33r)SRD 12.2(nightly Ok

Mod Sub-Module Model Serial Hw Status

---- --------------------------- ------------------ ----------- ------- ------ 10 7600 ES+ DFC XL 7600-ES+3CXL JAE115188YM 0.200 Ok 10 7600 ES+ 20xGE SFP 7600-ES+20G JAE1151860R 0.301 Ok

Mod Online Diag Status

---- ------------------ 10 Pass Router#

For more information about Cisco 7600 Series ES+ line card commands, see the Cisco IOS Software

Releases 12.2 SR Command References.

Note The Cisco 7600 Series ES+ line card must be in a slot that provides two primary serial channels. Dual

serial channels are not available in all slots of a 13-slot chassis. Dual fabric connectivity is supported in slots 9 to 13.

Cisco 7600 ES+ Line Card Slot, Bay, and Port Locations

The Cisco 7600 Series ES+ line card uses a <slot, port> numbering scheme. The slot refers to whichever slot the line card occupies in the router. The port numbering begins at 1 on all versions of the Cisco 7600 Series ES+ line card. The upper limit depends on the card type. This physical port numbering is reflected in CLI messages and all references to port numbers that are visible to the user.

Executing the show interface command for a Cisco 7600 Series ES+ line card located in slot 10 of a Cisco 7600 series router chassis produces the following (only first six interfaces are shown):

Router# show interfaces gigabitEthernet 10/2

2-4

GigabitEthernet10/2 is up, line protocol is up (connected) Hardware is X40G 1Gb 802.3, address is 000f.35c2.ec00 (bia 000f.35c2.ec00) Description: connect to test 7/2 MTU 1500 bytes, BW 1000000 Kbit, DLY 10 usec,

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

reliability 255/255, txload 196/255, rxload 196/255 Encapsulation ARPA, loopback not set Keepalive set (10 sec) Full-duplex, 1000Mb/s input flow-control is off, output flow-control is off Clock mode is auto ARP type: ARPA, ARP Timeout 04:00:00 Last input never, output 00:00:24, output hang never Last clearing of "show interface" counters 00:00:12 Input queue: 0/75/0/0 (size/max/drops/flushes); Total output drops: 0 Queueing strategy: fifo Output queue: 0/40 (size/max) 5 minute input rate 772455000 bits/sec, 1419960 packets/sec 5 minute output rate 772455000 bits/sec, 1419960 packets/sec L2 Switched: ucast: 0 pkt, 0 bytes - mcast: 0 pkt, 0 bytes L3 in Switched: ucast: 0 pkt, 0 bytes - mcast: 0 pkt, 0 bytes mcast L3 out Switched: ucast: 0 pkt, 0 bytes mcast: 0 pkt, 0 bytes 11363519 packets input, 772719292 bytes, 0 no buffer Received 0 broadcasts (0 IP multicasts) 0 runts, 0 giants, 0 throttles 0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored 0 watchdog, 0 multicast, 0 pause input 0 input packets with dribble condition detected 11363519 packets output, 772719292 bytes, 0 underruns 0 output errors, 0 collisions, 0 interface resets 0 babbles, 0 late collision, 0 deferred 0 lost carrier, 0 no carrier, 0 pause output 0 output buffer failures, 0 output buffers swapped out

Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Line Card Overview

For more information about Cisco 7600 Series ES+ line card commands, see the Cisco IOS Software

Releases 12.2 SR Command References.

Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Line Card Overview

The following sections describe the Cisco 7600 Series ES+ line card:

• Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Line Card Processors, page 2-5

• Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Line Card LEDs, page 2-6

• Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Physical Specifications, page 2-6

• Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Line Card Memory Options, page 2-7

• Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Supported XFP Modules, page 2-7

Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Line Card Processors

The processors on the Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL line cards are listed in Table 2-2 .

Table 2-2 Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Line Card Processors

Type Speed Description

Processor 300 megahertz (MHz) internal operating

frequency

Local control

1333 MHz (1.3GHz) MPC8548

processor

Trident

OL-16146-10

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

2-5

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Line Card Overview

Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Line Card LEDs

The Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL line cards have Status and A/L (Active Loopback) LEDs, as shown in Figure 2-1 and Figure 2-2. Tabl e 2-3 provides LED descriptions.

Figure 2-1 Cisco 7600 ES+ 2TG3C

7600-ES+ 2TG3C

EXT CLK

STATUS

ETHERNET SERVICES MODULE

A/L

CLASS 1 LASER

A/L

Figure 2-2 Cisco 7600 ES+ 2TG3CXL Faceplate

7600-ES+ 2TG3CXL

EXT CLK

STATUS

ETHERNET SERVICES MODULE

A/L

CLASS 1 LASER

A/L

There is one line card Status LED and two port Status LEDs. Tab l e 2- 3 provides LED descriptions.

Table 2-3 Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL LEDs

LED Label Color State Meaning

STATUS Red On The line card has encountered an error.

Green On The line card is online.

Yellow On The line card is loading.

Off Off The line card is powered off.

A/L Amber On The port is enabled but there is not a valid Ethernet

link.

Green On The port is enabled and a valid Ethernet link has been

established.

Off Off The port is not enabled by software.

270819

270820

Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Physical Specifications

The Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL physical specifications are shown in Tabl e 2-4 .

Table 2-4 7600-ES+ 2TG3C,7600-ES+ 2TG33CXL Physical Specifications

Description Specifications

Physical dimensions The Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL line cards occupy

one module slot and can be operated in all Cisco 7600 series routers except the Cisco 7603 router.

Shipping weight 8 lb (3.64 kg)

Operating temperature 32 to 104°F (0 to 40°C)

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

2-6

OL-16146-10

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Line Card Overview

Table 2-4 7600-ES+ 2TG3C,7600-ES+ 2TG33CXL Physical Specifications (continued)

Description Specifications

Relative humidity 10 to 90 percent, noncondensing

Storage temperature –4 to 149°F (–20 to 65°C)

Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Line Card Memory Options

Table 2-5 lists the memory options available for the 7600-ES+ 2TG3C, -3CXL line cards:

Table 2-5 Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Line Card Memory Options

Line Card Memory Options

Cisco 7600 ES+ 2TG3C 1 GB

Cisco 7600 ES+ 2T3CXL 2 GB

Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Supported XFP Modules

The Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL line cards support the XFP modules listed in

Table 2-6.

Table 2-6 Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Supported XFP Modules

XFP Description

XFP-10GLR-OC192SR Cisco Multirate 10.GBASE-LR and OC-192/STM-64 SR-1 XFP

Module for SMF

XFP-10GZR-OC192LR Cisco Multirate 10GBASE-ZR and OC-192/STM-64 lR-2 XFP

Module for SMF.

XFP-10GER-192IR+ Cisco Multirate 10GBASE-ER and OC-192/STM-64 IR-2 XFP

Module for SMF.

XFP-10GLR-OC192SR-L Cisco Multirate 10GBASE-LR Ethernet and OC-192/STM-64 low

power XFP Module for SMF.

XFP-10GLR-OC192IR-L Cisco Multirate 10GBASE-LR Ethernet and OC-192/STM-64 low

power XFP Module for SMF.

XFP-10G-MM-SR Cisco multirate XFP transceiver module for 10GBASE-SR Ethernet

and OC-192/STM-64 short-reach (SR-1) Packet-over-SONET/SDH (POS) applications, SMF, dual LC connector, and Multimode fiber.

DWDM-XFP-60.61 DWDM XFP 1560.61 nm XFP (100 GHz ITU grid).

DWDM-XFP-59.79 DWDM XFP 1559.79 nm XFP (100 GHz ITU grid).

DWDM-XFP-58.98 DWDM XFP 1558.98 nm XFP (100 GHz ITU grid).

DWDM-XFP-58.17 DWDM XFP 1558.17 nm XFP (100 GHz ITU grid).

DWDM-XFP-56.55 DWDM XFP 1556.55 nm XFP (100 GHz ITU grid).

DWDM-XFP-55.75 DWDM XFP 1555.75 nm XFP (100 GHz ITU grid).

DWDM-XFP-54.94 DWDM XFP 1554.94 nm XFP (100 GHz ITU grid).

OL-16146-10

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

2-7

Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Line Card Overview

Table 2-6 Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL Supported XFP Modules (continued)

XFP Description

DWDM-XFP-54.13 DWDM XFP 1554.13 nm XFP (100 GHz ITU grid).

DWDM-XFP-52.52 DWDM XFP 1552.52 nm XFP (100 GHz ITU grid).

DWDM-XFP-51.72 DWDM XFP 1551.72 nm XFP (100 GHz ITU grid)

DWDM-XFP-50.92 DWDM XFP 1550.92 nm XFP (100 GHz ITU grid).

DWDM-XFP-50.12 DWDM XFP 1550.12 nm XFP (100 GHz ITU grid).

DWDM-XFP-48.51 DWDM XFP 1548.51 nm XFP (100 GHz ITU grid).

DWDM-XFP-47.72 DWDM XFP 1547.72 nm XFP (100 GHz ITU grid).

DWDM-XFP-46.92 DWDM XFP 1546.92 nm XFP (100 GHz ITU grid).

DWDM-XFP-46.12 DWDM XFP 1546.12 nm XFP (100 GHz ITU grid).

DWDM-XFP-44.53 DWDM XFP 1544.53 nm XFP (100 GHz ITU grid).

DWDM-XFP-43.73 DWDM XFP 1543.73 nm XFP (100 GHz ITU grid).

DWDM-XFP-42.94 DWDM XFP 1542.94 nm XFP (100 GHz ITU grid).

DWDM-XFP-42.14 DWDM XFP 1542.14 nm XFP (100 GHz ITU grid).

DWDM-XFP-40.56 DWDM XFP 1540.56 nm XFP (100 GHz ITU grid).

DWDM-XFP-39.77 DWDM XFP 1539.77 nm XFP (100 GHz ITU grid).

DWDM-XFP-38.98 DWDM XFP 1538.98 nm XFP (100 GHz ITU grid).

DWDM-XFP-38.19 DWDM XFP 1538.19 nm XFP (100 GHz ITU grid).

DWDM-XFP-36.61 DWDM XFP 1536.61 nm XFP (100 GHz ITU grid).

DWDM-XFP-35.82 DWDM XFP 1535.82 nm XFP (100 GHz ITU grid).

DWDM-XFP-35.04 DWDM XFP 1535.04 nm XFP (100 GHz ITU grid).

DWDM-XFP-34.25 DWDM XFP 1534.25 nm XFP (100 GHz ITU grid).

DWDM-XFP-32.68 DWDM XFP 1532.68 nm XFP (100 GHz ITU grid).

DWDM-XFP-31.90 DWDM XFP 1531.90 nm XFP (100 GHz ITU grid).

DWDM-XFP-31.12 DWDM XFP 1531.12 nm XFP (100 GHz ITU grid).

DWDM-XFP-30.33 DWDM XFP 1530.33 nm XFP (100 GHz ITU grid).

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

2-8

The XFP modules provide high-speed serial links at the following rates: 9.95 Gbps (OC-192) and

10.3125 Gbps (10 Gigabit Ethernet) on single-mode fiber (SMF). The transmit side recovers and retimes the 10-Gbps serial data and passes it to a laser driver. The laser driver biases and modulates a 1310-nm or 1550-nm laser, enabling data transmission over SMF through an LC connector. The receive side recovers and retimes the 10-Gbps optical data stream from a photo-detector transimpedance amplifier and passes it to an output driver.

See the label on the XFP module for technology type and model.

XFP module dimensions are:

• Height: 12.5 mm

• Width: 18.35 mm

• Length: 71.1mm

The XFP module temperature range is 0°C to 70°C. Figure 2-3 shows a typical XFP module.

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

129499

57653

Figure 2-3 XFP Module

Connectors and Cabling

The XFP optical transceiver module on the Cisco 7600 ES+ 2TG3C, 7600 ES+ 2TG3CXL line card require dual LC/PC connectors. Only connections with patch cords with PC or UPC connectors are supported. Patch cords with APC connectors are not supported. All cables and cable assemblies used must be compliant with the standards specified below:

• GR-20-CORE: Generic Requirements for Optical Fiber and Optical Fiber Cable

• GR-326-CORE: Generic Requirements for Singlemode Optical Connectors and Jumper Assemblies

Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Line Card Overview

• GR-1435-CORE: Generic Requirements for Multi-Fiber Optical Connectors

Figure 2-4 shows the cable type for use with the XFP optical transceiver module on the Cisco 7600 ES+

2TG3C, 7600 ES+ 2TG3CXL line card.

Figure 2-4 Duplex LC-Type Cable and Connector

For additional information on Cisco Transceiver Modules, see

http://www.cisco.com/en/US/products/hw/modules/ps5455/products_data_sheets_list.html.

Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Line Card Overview

The following sections describe the Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL line cards:

• Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Line Card Processors, page 2-10

OL-16146-10

• Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Line Card LEDs, page 2-10

• Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Physical Specifications, page 2-11

• Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Line Card Memory Options, page 2-11

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

2-9

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Line Card Overview

• Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Supported XFP Modules, page 2-11

Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Line Card Processors

The processors on the Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL line cards are listed in Tab l e 2- 7 .

Table 2-7 Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Line Card Processor

Type Speed Description

CPU 300 megahertz (MHz) internal operating

Trident

frequency

Local control

1333 MHz (1.3GHz) MPC8548

processor

Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Line Card LEDs

The Cisco 7600 ES+ 4TG3C, 7600 ES+4TG3CXL line cards have Status and A/L (Active Loopback) LEDs, as shown in Figure 2-5 and Figure 2-6. Tabl e 2-8 provides LED descriptions.

Figure 2-5 Cisco 7600 ES+ 4TG3C Faceplate

7600-ES+ 4TG3C

EXT CLK

STATUS

ETHERNET SERVICES MODULE

A/L

CLASS 1 LASER

A/L

Figure 2-6 Cisco 7600 ES+ 4TG3CXL Faceplate

76-ES+XT-4TG3CXL

EXT CLK

STATUS

ETHERNET SERVICES MODULE

A/L

CLASS 1 LASER

A/L

There is one line card Status LED and two port Status LEDs. Tab l e 2- 3 provides LED descriptions.

Table 2-8 Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL LEDs

LED Label Color State Meaning

STATUS Red On The line card has encountered an error.

Green On The line card is online.

Yellow On The line card is loading.

Off Off The line card is powered off.

A/L Amber On The port is enabled but there is not a valid Ethernet

link.

270823

251133

2-10

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Line Card Overview

Table 2-8 Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL LEDs (continued)

LED Label Color State Meaning

Green On The port is enabled and a valid Ethernet link has been

established.

Off Off The port is not enabled by software.

Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Physical Specifications

The Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL physical specifications are shown in Tabl e 2-9 .

Table 2-9 7600-ES+ 4TG3C, 7600-ES+ 4TG3CXL Physical Specifications

Description Specifications

Physical dimensions The Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL line cards occupy

one module slot and can be operated in all Cisco 7600 series routers except the Cisco 7603 router.

Shipping weight 8 lb (3.64 kg)

Operating temperature 32 to 104°F (0 to 40°C)

Relative humidity 10 to 90 percent, noncondensing

Storage temperature –4 to 149°F (–20 to 65°C)

Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Line Card Memory Options

Table 2-10 lists the memory options available for the Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL line

cards:

Table 2-10 Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Line Card Memory Options

Line Card Memory Options

Cisco 7600 ES+ 4TG3C 1 GB

Cisco 7600 ES+ 4TG3CXL 2 GB

Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Supported XFP Modules

The Cisco 7600 ES+ 4TG3C, -3CXL line cards support the XFP modules listed in Table 2-11

Table 2-11 Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Supported XFP Modules

XFP Description

XFP-10GLR-OC192SR Cisco Multirate 10GBASE-LR and OC-192/STM-64 SR-1 XFP

Module for SMF

XFP-10GZR-OC192LR Cisco Multirate 10GBASE-ZR and OC-192/STM-64 lR-2 XFP

Module for SMF

OL-16146-10

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

2-11

Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Line Card Overview

Table 2-11 Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Supported XFP Modules (continued)

XFP Description

XFP-10GER-192IR+ Cisco Multirate 10GBASE-ER and OC-192/STM-64 IR-2 XFP

XFP-10GLR-OC192SR-L Cisco Multirate 10GBASE-LR Ethernet and OC-192/STM-64 low

XFP-10GLR-OC192IR-L Cisco Multirate 10GBASE-LR Ethernet and OC-192/STM-64 low

DWDM-XFP-60.61 DWDM XFP 1560.61 nm XFP (100 GHz ITU grid)

DWDM-XFP-59.79 DWDM XFP 1559.79 nm XFP (100 GHz ITU grid)

DWDM-XFP-58.98 DWDM XFP 1558.98 nm XFP (100 GHz ITU grid)

DWDM-XFP-58.17 DWDM XFP 1558.17 nm XFP (100 GHz ITU grid)

DWDM-XFP-56.55 DWDM XFP 1556.55 nm XFP (100 GHz ITU grid)

DWDM-XFP-55.75 DWDM XFP 1555.75 nm XFP (100 GHz ITU grid)

DWDM-XFP-54.94 DWDM XFP 1554.94 nm XFP (100 GHz ITU grid)

DWDM-XFP-54.13 DWDM XFP 1554.13 nm XFP (100 GHz ITU grid)

DWDM-XFP-52.52 DWDM XFP 1552.52 nm XFP (100 GHz ITU grid)

DWDM-XFP-51.72 DWDM XFP 1551.72 nm XFP (100 GHz ITU grid)

DWDM-XFP-50.92 DWDM XFP 1550.92 nm XFP (100 GHz ITU grid)

DWDM-XFP-50.12 DWDM XFP 1550.12 nm XFP (100 GHz ITU grid)

DWDM-XFP-48.51 DWDM XFP 1548.51 nm XFP (100 GHz ITU grid)

DWDM-XFP-47.72 DWDM XFP 1547.72 nm XFP (100 GHz ITU grid)

DWDM-XFP-46.92 DWDM XFP 1546.92 nm XFP (100 GHz ITU grid)

DWDM-XFP-46.12 DWDM XFP 1546.12 nm XFP (100 GHz ITU grid)

DWDM-XFP-44.53 DWDM XFP 1544.53 nm XFP (100 GHz ITU grid)

DWDM-XFP-43.73 DWDM XFP 1543.73 nm XFP (100 GHz ITU grid)

DWDM-XFP-42.94 DWDM XFP 1542.94 nm XFP (100 GHz ITU grid)

DWDM-XFP-42.14 DWDM XFP 1542.14 nm XFP (100 GHz ITU grid)

DWDM-XFP-40.56 DWDM XFP 1540.56 nm XFP (100 GHz ITU grid)

DWDM-XFP-39.77 DWDM XFP 1539.77 nm XFP (100 GHz ITU grid)

DWDM-XFP-38.98 DWDM XFP 1538.98 nm XFP (100 GHz ITU grid)

DWDM-XFP-38.19 DWDM XFP 1538.19 nm XFP (100 GHz ITU grid)

DWDM-XFP-36.61 DWDM XFP 1536.61 nm XFP (100 GHz ITU grid)

DWDM-XFP-35.82 DWDM XFP 1535.82 nm XFP (100 GHz ITU grid)

DWDM-XFP-35.04 DWDM XFP 1535.04 nm XFP (100 GHz ITU grid)

DWDM-XFP-34.25 DWDM XFP 1534.25 nm XFP (100 GHz ITU grid)

DWDM-XFP-32.68 DWDM XFP 1532.68 nm XFP (100 GHz ITU grid)

DWDM-XFP-31.90 DWDM XFP 1531.90 nm XFP (100 GHz ITU grid)

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

Module for SMF

power XFP Module for SMF

2-12

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

129499

Table 2-11 Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Supported XFP Modules (continued)

XFP Description

DWDM-XFP-31.12 DWDM XFP 1531.12 nm XFP (100 GHz ITU grid)

DWDM-XFP-30.33 DWDM XFP 1530.33 nm XFP (100 GHz ITU grid)

The XFP modules provide high-speed serial links at the following rates: 9.95 Gbps (OC-192) and

See the label on the XFP module for technology type and model.

XFP module dimensions are:

• Height: 12.5 mm

• Width: 18.35 mm

• Length: 71.1mm

Cisco 7600 ES+ 4TG3C, 7600 ES+ 4TG3CXL Line Card Overview

The XFP module temperature range is 0°C to 70°C. Figure 2-7 shows a typical XFP module.

Figure 2-7 XFP Module

Connectors and Cabling

The XFP optical transceiver module on the Cisco 7600 ES+ 4TG3C, -3CXL line cards require dual LC/PC connectors. Only connections with patch cords with PC or UPC connectors are supported. Patch cords with APC connectors are not supported. All cables and cable assemblies used must be compliant with the standards specified below:

• GR-20-CORE: Generic Requirements for Optical Fiber and Optical Fiber Cable

• GR-326-CORE: Generic Requirements for Singlemode Optical Connectors and Jumper Assemblies

• GR-1435-CORE: Generic Requirements for Multi-Fiber Optical Connectors

OL-16146-10

Figure 2-8 shows the cable type for use with the XFP optical transceiver module on the Cisco 7600 ES+

4TG3C, -3CXL line card.

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

2-13

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

57653

Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card Overview

Figure 2-8 Duplex LC-Type Cable and Connector

For additional information on Cisco Transceiver Modules, see

http://www.cisco.com/en/US/products/hw/modules/ps5455/products_data_sheets_list.html.

Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card Overview

The following sections describe the Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL line cards:

• Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card Processors, page 2-14

• Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card LEDs, page 2-14

• Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Physical Specifications, page 2-15

• Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card Memory Options, page 2-16

• Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Supported SFP Modules, page 2-16

Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card Processors

The processors on the Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL line cards are listed in Tab l e 2-1 2.

Table 2-12 Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card Processor

Type Speed Description

CPU 300 megahertz (MHz) internal operating

frequency

Local control processor

1333 MHz (1.3GHz) MPC8548

Trident Processor

Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card LEDs

The Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL line cards have Status and A/L (Active Loopback) LEDs, as shown in Figure 2-9 and Figure 2-10.

2-14

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

Figure 2-9 Cisco 7600 ES+ 20G3C Line Card Faceplate

Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card Overview

7600-ES+ 20G3C

EXT CLK

STATUS

ETHERNET SERVICES MODULE

A/L

CLASS 1 LASER

Figure 2-10 Cisco 7600 ES+ 20G3CXL Line Card Faceplate

7600-ES+ 20G3CXL

EXT CLK

STATUS

ETHERNET SERVICES MODULE

A/L

CLASS 1 LASER

Table 2-13 provides LED descriptions.

Table 2-13 Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card LEDs

LED Label Color State Meaning

STATUS Red On The line card has encountered an error.

Green On The line card is online.

Yellow On The line card is loading.

Off Off The line card is powered off.

A/L Amber On The port is enabled but there is not a valid Ethernet

link.

Green On The port is enabled and a valid Ethernet link has been

established.

Off Off The port is not enabled by software.

270817

270818

Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Physical Specifications

The Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL line card physical specifications are shown in

Table 2-14 .

Table 2-14 Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card Physical Specifications

Description Specifications

Physical dimensions The Cisco 7600 ES+ 20G3C, -20G3CX line card occupies one module

slot and can be operated in all Cisco 7600 series routers except the Cisco 7603 router.

Shipping weight 8 lb (3.64 kg)

Operating temperature 32 to 104°F (0 to 40°C)

Relative humidity 10 to 90 percent, noncondensing

Storage temperature –4 to 149°F (–20 to 65°C)

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

2-15

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card Overview

Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card Memory Options

Table 2-15 lists the memory options available for the Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL line

cards:

Table 2-15 Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card Memory Options

Line Card Memory Options

Cisco 7600 ES+ 20G3C 1 GB

Cisco 7600 ES+ 20G3XL 2 GB

Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Supported SFP Modules

The Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL line cards support the small form-factor pluggable (SFP) optical transceiver modules listed in Table 2-16

Table 2-16 Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Supported SFP Modules

SFP Modules Description

SFP-GE-S 1000BASE-SX short wavelength; with DOM

SFP-GE-L 1000BASE-LX/LH short wavelength; with DOM

SFP-GE-Z 1000BASE-ZX; with DOM

SFP-GE-T 1000BASE-T SFP

GLC-BX-D 1000BASE-BX10-D downstream bidirectional single fiber; with DOM

GLC-BX-U 1000BASE-BX10-U upstream bidirectional single fiber; with DOM

CWDM-SFP-1470 Cisco CWDM SFP 1470 nm; Gigabit Ethernet and 1G/2G FC

CWDM-SFP-1490 Cisco CWDM SFP 1490 nm; Gigabit Ethernet and 1G/2G FC

CWDM-SFP-1510 Cisco CWDM SFP 1510 nm; Gigabit Ethernet and 1G/2G FC

CWDM-SFP-1530 Cisco CWDM SFP 1530 nm; Gigabit Ethernet and 1G/2G FC

CWDM-SFP-1550 Cisco CWDM SFP 1550 nm; Gigabit Ethernet and 1G/2G FC

CWDM-SFP-1570 Cisco CWDM SFP 1570 nm; Gigabit Ethernet and 1G/2G FC

CWDM-SFP-1590 Cisco CWDM SFP 1590 nm; Gigabit Ethernet and 1G/2G FC

CWDM-SFP-1610 Cisco CWDM SFP 1610 nm; Gigabit Ethernet and 1G/2G FC

DWDM-SFP-3033 1000BASE-DWDM 1530.33 nm SFP (100-GHz ITU grid)

DWDM-SFP-3112 1000BASE-DWDM 1531.12 nm SFP (100-GHz ITU grid)

DWDM-SFP-3190 1000BASE-DWDM 1531.90 nm SFP (100-GHz ITU grid)

DWDM-SFP-3268 1000BASE-DWDM 1532.68 nm SFP (100-GHz ITU grid)

DWDM-SFP-3425 1000BASE-DWDM 1534.25 nm SFP (100-GHz ITU grid)

DWDM-SFP-3504 1000BASE-DWDM 1535.04 nm SFP (100-GHz ITU grid)

DWDM-SFP-3582 1000BASE-DWDM 1535.82 nm SFP (100-GHz ITU grid)

DWDM-SFP-3661 1000BASE-DWDM 1536.61 nm SFP (100-GHz ITU grid)

DWDM-SFP-3819 1000BASE-DWDM 1538.19 nm SFP (100-GHz ITU grid)

2-16

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

Table 2-16 Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Supported SFP Modules (continued)

SFP Modules Description

DWDM-SFP-3898 1000BASE-DWDM 1538.98 nm SFP (100-GHz ITU grid)

DWDM-SFP-3977 1000BASE-DWDM 1539.77 nm SFP (100-GHz ITU grid)

DWDM-SFP-4056 1000BASE-DWDM 1540.56 nm SFP (100-GHz ITU grid)

DWDM-SFP-4214 1000BASE-DWDM 1542.14 nm SFP (100-GHz ITU grid)

DWDM-SFP-4294 1000BASE-DWDM 1542.94 nm SFP (100-GHz ITU grid)

DWDM-SFP-4373 1000BASE-DWDM 1543.73 nm SFP (100-GHz ITU grid)

DWDM-SFP-4453 1000BASE-DWDM 1544.53 nm SFP (100-GHz ITU grid)

DWDM-SFP-4612 1000BASE-DWDM 1546.12 nm SFP (100-GHz ITU grid)

DWDM-SFP-4692 1000BASE-DWDM 1546.92 nm SFP (100-GHz ITU grid)

DWDM-SFP-4772 1000BASE-DWDM 1547.72 nm SFP (100-GHz ITU grid)

DWDM-SFP-4851 1000BASE-DWDM 1548.51 nm SFP (100-GHz ITU grid)

DWDM-SFP-5012 1000BASE-DWDM 1550.12 nm SFP (100-GHz ITU grid)

DWDM-SFP-5092 1000BASE-DWDM 1550.92 nm SFP (100-GHz ITU grid)

DWDM-SFP-5172 1000BASE-DWDM 1551.72 nm SFP (100-GHz ITU grid)

DWDM-SFP-5252 1000BASE-DWDM 1552.52 nm SFP (100-GHz ITU grid)

DWDM-SFP-5413 1000BASE-DWDM 1554.13 nm SFP (100-GHz ITU grid)

DWDM-SFP-5494 1000BASE-DWDM 1554.94 nm SFP (100-GHz ITU grid)

DWDM-SFP-5575 1000BASE-DWDM 1555.75 nm SFP (100-GHz ITU grid)

DWDM-SFP-5655 1000BASE-DWDM 1556.55 nm SFP (100-GHz ITU grid)

DWDM-SFP-5817 1000BASE-DWDM 1558.17 nm SFP (100-GHz ITU grid)

DWDM-SFP-5898 1000BASE-DWDM 1558.98 nm SFP (100-GHz ITU grid)

DWDM-SFP-5979 1000BASE-DWDM 1559.79 nm SFP (100-GHz ITU grid)

DWDM-SFP-6061 1000BASE-DWDM 1560.61 nm SFP (100-GHz ITU grid)

DWDM-SFP-3346 DWDM SFP 1533.47 nm SFP (100 GHz ITU grid)

DWDM-SFP-3739 DWDM SFP 1537.40 nm SFP (100 GHz ITU grid)

DWDM-SFP-4134 DWDM SFP 1541.35 nm SFP (100 GHz ITU grid)

DWDM-SFP-4532 DWDM SFP 1545.32 nm SFP (100 GHz ITU grid)

DWDM-SFP-4931 DWDM SFP 1549.32 nm SFP (100 GHz ITU grid)

DWDM-SFP-5332 DWDM SFP 1553.33 nm SFP (100 GHz ITU grid)

DWDM-SFP-5736 DWDM SFP 1557.36 nm SFP (100 GHz ITU grid)

DWDM-SFP-6141 DWDM SFP 1561.42 nm SFP (100 GHz ITU grid)

Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card Overview

OL-16146-10

SFPs are integrated fiber-optic transceivers that provide high-speed serial links from a port or slot to the network. Various latching mechanisms can be used on the SFPs. There is no correlation between the type of latch to the model type (such as SX or LX/LH) or technology type (such as Gigabit Ethernet). See the label on the SFP for the technology type and model.

SFP dimensions are:

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

2-17

Cisco 7600 ES+ 20G3C, 7600 ES+ 20G3CXL Line Card Overview

127158

• Height 0.03 in. (8.5 mm)

• Width 0.53 in. (13.4 mm)

• Depth 2.22 in. (56.5 mm)

SFP temperature ranges are:

• COM—Commercial operating temperature range -5 to 70 degrees C (23 to 158 degrees F)

• EXT—Extended operating temperature range -5 to 85 degrees C (23 to 185 degrees F)

• IND—Industrial operating temperature range -40 to 85 degrees C (-40 to 85 degrees F)

Figure 2-11 shows a typical SFP module.

Figure 2-11 SFP Optics Module

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

Connectors and Cabling

The SFP optical transceiver module on the Cisco 7600 ES+ 20G3C, -3CXL line card require dual or single LC/PC connectors. Only connections with patch cords with PC or UPC connectors are supported. Patch cords with APC connectors are not supported. All cables and cable assemblies used must be compliant with the standards specified below:

• GR-20-CORE: Generic Requirements for Optical Fiber and Optical Fiber Cable

• GR-326-CORE: Generic Requirements for Singlemode Optical Connectors and Jumper Assemblies

• GR-1435-CORE: Generic Requirements for Multi-Fiber Optical Connectors

For single-mode and multimode optical fiber connections, you can use either a duplex LC-type cable or two simplex LC-type cables, one for transmit (TX) and one for receive (RX). See Figure 2-12.

2-18

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

57653

Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Line Card Overview

Figure 2-12 Duplex LC-Type Cable and Connector

For additional information on Cisco Transceiver Modules, see

http://www.cisco.com/en/US/products/hw/modules/ps5455/products_data_sheets_list.html.

Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Line Card Overview

The following sections describe the Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL line cards:

• Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Line Card Processors, page 2-19

• Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Line Card LEDs, page 2-19

• Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Physical Specifications, page 2-20

• Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Line Card Memory Options, page 2-21

• Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Supported SFP Modules, page 2-21

Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Line Card Processors

The processors on the Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL line card are listed in Table 2-17.

Table 2-17 Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Line Card Processor

Type Speed Description

CPU 300 megahertz (MHz) internal operating

frequency

Local control processor

1333 MHz (1.3GHz) MPC8548

Trident Processor

Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Line Card LEDs

OL-16146-10

The Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL line cards have Status and A/L (Active Loopback) LEDs, as shown in Figure 2-13 and Figure 2-14.

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

2-19

Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Line Card Overview

270821

CLASS 1

LASER

7600-ES+ 40G3C

ETHERNET SERVICES MODULE

STATUS

EXT CLK

A/L

270822

CLASS 1

LASER

7600-ES+ 40G3CXL

ETHERNET SERVICES MODULE

STATUS

EXT CLK

A/L

Figure 2-13 Cisco 7600 ES+ 40G3C Line Card Faceplate

Figure 2-14 Cisco 7600 ES+ 40G3CXL Line Card Faceplate

Table 2-18 provides LED descriptions.

Table 2-18 Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Line Card LEDs

LED Label Color State Meaning

STATUS Red On The line card has encountered an error.

Green On The line card is online.

Yellow On The line card is loading.

Off Off The line card is powered off.

A/L Amber On The port is enabled but there is not a valid Ethernet

Green On The port is enabled and a valid Ethernet link has been

Off Off The port is not enabled by software.

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

link.

established.

Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Physical Specifications

The Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL line card physical specifications are shown in

Table 2-19 .

Table 2-19 Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Line Card Physical Specifications

Description Specifications

Physical dimensions The Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL line cards occupy

one module slot and can be operated in all Cisco 7600 series routers except the Cisco 7603 router.

Shipping weight 8 lb (3.64 kg)

Operating temperature 32 to 104°F (0 to 40°C)

Relative humidity 10 to 90 percent, noncondensing

Storage temperature –4 to 149°F (–20 to 65°C)

2-20

Cisco 7600 Series Ethernet Services Plus Line Card Hardware Installation Guide

OL-16146-10

Chapter 2 Overview: Cisco 7600 Series Ethernet Services Plus Line Cards

Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Line Card Overview

Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Line Card Memory Options

Table 2-20 lists the memory options available for the Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL line

cards:

Table 2-20 Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Line Card Memory Options

Line Card Memory Options

Cisco 7600 ES+ 40G3C 1 GB

Cisco 7600 ES+ 40G3CXL 2 GB

Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Supported SFP Modules

The Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL line cards support the small form-factor pluggable (SFP) optical transceiver modules listed in Table 2-21 .

Table 2-21 Cisco 7600 ES+ 40G3C, 7600 ES+ 40G3CXL Supported SFP Modules
