This appendix includes information on CTM GateWay/CORBA’s notifications, fault management, and
probable cause mapping. This appendix includes the following sections:
• A.1 Overview of Notifications, page A-1
• A.2 Resolving the Notification Service, page A-2
• A.3 Tips to Improve Notification Throughput, page A-2
• A.4 Supported Events, page A-3
• A.5 Probable Cause Mapping, page A-12
A.1 Overview of Notifications
APPENDIX
A
The notification service forwards all fault notifications received from managed NEs to the network
management system (NMS). The notification service also forwards object creation, object deletion,
attribute change, protection switch, and threshold crossing alert (TCA) events. TMF 814 defines the
structure and format of attributes for all events and alarms.
The CTM server and the Operations Support System (OSS) host must have Domain Name System (DNS)
enabled in order to receive notifications. OSS clients running behind a firewall must configure an IIOP
listening port to enable the TCP connection with the notification server. CTM must configure the
notification service listening port number to allow OSS clients to communicate with the notification
service.
CTM creates the notification channel with the QoS parameters shown in the following table.
Ta b le A- 1 Q o S P a ra m et e r s f o r the Notification Channel
Parameter Value
ConnectionReliability BestEffort
StartTimeSupported false
OrderPolicy FifoOrder
DiscardPolicy FifoOrder
MaxEventsPerConsumer
1. The MaxEventsPerConsumer value is configurable. To modify this value, see B.8 Location of the Naming Service IOR File, page B-6. All other
parameter values are defined by the TMF and cannot be changed.
1
10000
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-1
Page 2
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Resolving the Notification Service
CTM sets the RejectNewEvents administration property of the channel to true, as defined by the TMF.
Every notification that CTM generates has the QoS parameters listed in the following table. These
parameter values are defined by the TMF and cannot be changed.
Table A-2 QoS Parameters for Notifications
Parameter Value
EventReliability BestEffort
Priority DefaultPriority
Timeout 30 minutes for alarms and TCAs; 24 hours for all other notifications
The NMS retrieves all active alarms on the Element Management System (EMS) and on managed
element objects. The NMS filters alarms based on probable cause and managed element name.
CTM GateWay/CORBA forwards CTM-specific alarms to the NMS.
For NE-related alarms, CTM inserts the original probable cause in the alarm’s nativeProbableCause
field. The TMF-mapped probable cause is available in the probableCause field.
A.2 Resolving the Notification Service
CTM GateWay/CORBA can integrate with external notification services. When CTM GateWay/CORBA
starts, a reference to EventNotifyChannelFactory is resolved. CTM GateWay/CORBA makes the
following attempts to resolve the object:
1. Resolve initial references with the default service name of NotificationService to resolve the object.
You can change the service name by setting the corbagw.notification.ServiceName property in the
corbagw.properties file.
2. Resolve the object through the naming service. The default naming service entry is
services.NotifyChannelFactory. You can change the naming service entry by setting the
corbagw.notification.NamingContext property in the corbagw.properties file.
3. Resolve the object directly through the Interoperable Object Reference (IOR). You can change the
URL of the IOR file by setting the corbagw.notification.FactoryIORFile property in the
corbagw.properties file. The default location for the IOR file is
file://localhost/CTM_baseDir/cfg/NotificationService.ior. You can specify a URL that points to a
remote web server.
A.3 Tips to Improve Notification Throughput
While CTM GateWay/CORBA and the bundled notification server are developed and tuned to provide
high throughput, you might want to take additional steps to improve throughput and avoid any loss of
notifications. You should implement the StructuredPushConsumer interface defined by the Object
Management Group (OMG) and implement the push_structured_event method. The notification server
invokes this method on the NMS.
A-2
Caution Because all CORBA calls are blocking, the notification server thread blocks until the
push_structured_event method completes. If you try to perform a time-consuming task before the
method completes, you will block the notification server.
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 3
Appendix A Notifications, Fault Management, and Probable Cause Mapping
To improve throughput, you should receive the event and forward it to another thread for processing.
For example:
void push_structured_event(StructuredEvent notification) {
try {
some_other_thread_queue.addNotification(notification);
} catch (Exception ex) {
// catch all exception and ignore
ex.printStackTrace();
}
}
Caution As shown in the example, you must catch all exceptions, or you will stop receiving notifications.
A.4 Supported Events
The following sections list the attributes of each event.
Supported Events
A.4.1 Object Creation
The following table lists the object creation types and attributes.
Table A-3 Object Creation
Attribute Name Type Supported by CTM?
notificatId string Yes. The uniqueness and sequence of the notification ID are not
guaranteed.
objectName globaldefs::NamingAttributes_T Yes.
objectType notifications::ObjectType_T Yes.
emsTime globaldefs::Time_T Yes.
neTime globaldefs::Time_T No.
edgePoint boolean No.
Object creation notifications are sent to the NMS for the objects in the following table.
Table A-4 Object Creation Notifications
Object Type Type Sent in remainder_of_body for Object Creation Event
OT_MANAGED_ELEMENT managedElement::ManagedElement_T
OT_MULTILAYER_SUBNETWORK multiLayerSubnetwork::MultiLayerSubnetwork_T
OT_TOPOLOGICAL_LINK topologicalLink::TopologicalLink_T
OT_SUBNETWORK_CONNECTION subnetworkConnection::SubnetworkConnection_T
OT_EQUIPMENT equipment::Equipment_T
OT_PROTECTION_GROUP protection::ProtectionGroup_T
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-3
Page 4
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Supported Events
Table A-4 Object Creation Notifications (continued)
Object Type Type Sent in remainder_of_body for Object Creation Event
OT_L2TOPOLOGY MultiLayerSubnetwork::L2Topology_T
OT_MLVLAN MultiLayerSubnetwork::MLVLAN_T
OT_ROLL MultiLayerSubnetwork::Roll_T
OT_VCAT SubnetworkConnection::VCAT_T
CTM does not generate object creation events for SubnetworkConnection for the ONS 15540.
CTM cannot give the object name for object creation events for ONS 15501, ONS 15530, and
ONS 15540 equipment.
For the MGX 8880/8850/8830, CTM generates object creation events for the object types
OT_MANAGED_ELEMENT and OT_EQUIPMENT.
Note The number of equipment holders for NEs supported by CTM is constant. To reduce traffic between
CTM and the NMS, CTM does not generate object creation events for equipment holders. The number
of PTPs on equipment is also constant. Therefore, CTM generates only object creation events for
equipment.
A.4.2 Object Deletion
The following table lists the object deletion types and attributes.
Table A-5 Object Deletion
Attribute Name Type Supported by CTM?
notificationId string Yes. The uniqueness and sequence of the notification ID are not
guaranteed.
objectName globaldefs::NamingAttributes_T Yes.
objectType notifications::ObjectType_T Yes.
emsTime globaldefs::Time_T Yes.
neTime globaldefs::Time_T No.
edgePoint boolean No.
Object deletion notifications are sent to the NMS for the objects in the following table.
Table A-6 Object Deletion Notifications
Object Type Type Sent in remainder_of_body for Object Deletion Event
OT_MANAGED_ELEMENT managedElement::ManagedElement_T
OT_MULTILAYER_SUBNETWORK multiLayerSubnetwork::MultiLayerSubnetwork_T
OT_TOPOLOGICAL_LINK topologicalLink::TopologicalLink_T
OT_SUBNETWORK_CONNECTION subnetworkConnection::SubnetworkConnection_T
A-4
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 5
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Table A-6 Object Deletion Notifications (continued)
Object Type Type Sent in remainder_of_body for Object Deletion Event
OT_EQUIPMENT equipment::Equipment_T
OT_PROTECTION_GROUP protection::ProtectionGroup_T
OT_L2TOPOLOGY MultiLayerSubnetwork::L2Topology_T
OT_MLVLAN MultiLayerSubnetwork::MLVLAN_T
OT_ROLL MultiLayerSubnetwork::Roll_T
OT_VCAT SubnetworkConnection::VCAT_T
CTM does not generate object deletion events for SubnetworkConnection for the ONS 15501,
ONS 15530, and ONS 15540.
For the MGX 8880/8850/8830, CTM generates object deletion events for the object types
OT_MANAGED_ELEMENT and OT_EQUIPMENT.
Note The number of equipment holders for all NEs supported by CTM is constant. To reduce traffic between
CTM and the NMS, CTM does not generate object deletion events for equipment holders. The number
of PTPs on equipment is also constant. Therefore, CTM generates only object deletion events for
equipment.
Supported Events
A.4.3 Attribute Value Change
The following table lists the attribute value change (AVC) types and attributes.
Table A-7 Attribute Value Change
Attribute Name Type Supported by CTM?
notificationId string Yes. The uniqueness and sequence of the notification ID are
not guaranteed.
objectName globaldefs::NamingAttributes_T Yes.
objectType notifications::ObjectType_T Yes.
emsTime globaldefs::Time_T Yes.
neTime globaldefs::Time_T No.
edgePoint boolean No.
attributeList notifications::NVList_T Yes.
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-5
Page 6
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Supported Events
Attribute value change notifications are sent to the NMS for the objects and attributes in the following
table.
Table A-8 Attribute Value Change Notifications
Object Type Attributes
OT_EMS nativeEMSName
OT_MANAGED_ELEMENT nativeEMSName—This field reflects the new managed element name if it is
changed.
location
version
productName
OT_MULTILAYER_SUBNETWORK NativeEMSName
OT_TOPOLOGICAL_LINK
OT_SUBNETWORK_CONNECTION
OT_L2TOPOLOGY NativeEMSName
OT_MLVLAN None
1
None
2
None
Note This event notifies the NMS that the VLAN was updated.
OT_ROLL None
Note This event notifies the NMS that the roll was updated.
OT_VCAT None
Note This event notifies the NMS that the VCAT changed.
1. The OT_TOPOLOGICAL_LINK event notifies the NMS that some attribute of the topological link changed.
2. The OT_SUBNETWORK_CONNECTION event is generated only when CTM fails to delete an SNC and it remains in the same state.
Note • CTM does not generate AVC events for SubnetworkConnection for the ONS 15501, ONS 15530,
and ONS 15540.
• For the MGX 8880/8850/8830, CTM generates AVC events for the object types
OT_MANAGED_ELEMENT and OT_EMS.
A.4.4 State Change Event
The following table lists the state change event types and attributes.
Table A-9 State Change Event
Attribute Name Type Supported by CTM?
notificationId string Yes. The uniqueness and sequence of the notification ID are not
guaranteed.
objectName globaldefs::NamingAttributes_T Yes.
objectType notifications::ObjectType_T Yes.
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-6
OL-14253-01
Page 7
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Table A-9 State Change Event (continued)
Attribute Name Type Supported by CTM?
emsTime globaldefs::Time_T Yes.
neTime globaldefs::Time_T No.
edgePoint boolean No.
attributeList notifications::NVList_T Yes.
State change event notifications are sent to the NMS for the objects and attributes in the following table.
Table A-10 State Change Event Notifications
Object Type Attributes
OT_MANAGED_ELEMENT communicationState—CTM supports the following values:
• CS_AVAILABLE
• C S _ U N AVA I L A B L E
emsInSyncState—CTM supports the following values:
• True
Supported Events
• False
OT_EQUIPMENT_HOLDER holderState—State change. CTM supports the following values:
• EMPTY
• INSTALLED_AND_EXPECTED
• EXPECTED_AND_NOT_INSTALLED
• MISMATCH_OF_INSTALLED_AND_EXPECTED
OT_SUBNETWORK_CONNECTION
1
sncState—CTM supports the following values:
• SNCS_DELETING
• SNCS_PARTIAL
• SNCS_ACTIVE
OT_L2TOPOLOGY L2TopoState—CTM supports the following values:
• L2TS_COMPLETE
• L2TS_INCOMPLETE
topoInSyncState—CTM supports the following values:
• true
• false
OT_MLVLAN vlanState—CTM supports the following values:
• VLS_COMPLETE
OL-14253-01
• VLS_INCOMPLETE
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-7
Page 8
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Supported Events
Table A-10 State Change Event Notifications (continued)
Object Type Attributes
OT_ROLL rollState—CTM supports the following values:
• ROLL_PENDING
• ROLL_COMPLETED
• ROLL_CANCELLED
• ROLL_INCOMPLETE
OT_VCAT vcatState—CTM supports the following values:
• VCATS_DELETING
• VCATS_PARTIAL
• VCAT_ACTIVE
1. The OT_SUBNETWORK_CONNECTION event is generated only when CTM changes the SNC. If CTC or any other tool is used to change the SNC,
CTM does not report this event.
CTM does not generate state change events for EquipmentHolder and SubnetworkConnection for the
ONS 15501, ONS 15530, and ONS 15540.
For the MGX 8880/8850/8830, CTM generates state change events for the object types
OT_MANAGED_ELEMENT and OT_EQUIPMENT_HOLDER.
A.4.5 Protection Switch
The following table lists the protection switch types and attributes. The protection switch event is not
supported for MGX 8880/8850/8830 NEs.
Table A-11 Protection Switch
Attribute Name Type Supported by CTM?
notificationId String Yes. The uniqueness and the sequence of the
notification ID are not guaranteed.
emsTime globaldefs::Time_T Yes.
neTime globaldefs::Time_T No.
ProtectionType protection::ProtectionType_T No.
switchReason protection::switchReason_T No.
layerRate transmissionParameters::LayerRate_T No.
groupName globaldefs::NamingAttributes_T No.
(Yes for ONS 15540 and ONS 15530.)
protectedTP globaldefs::NamingAttributes_T No.
(Yes for ONS 15540 and ONS 15530.)
switchAwayFromTP globaldefs::NamingAttributes_T Yes for ONS 15540 and ONS 15530.
switchToTP globaldefs::NamingAttributes_T No.
A-8
(Yes for ONS 15540 and ONS 15530.)
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 9
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Table A-11 Protection Switch (continued)
Attribute Name Type Supported by CTM?
affectedTP
globaldefs::NamingAttributes_T Yes.
Supported Events
Note This is not defined by the
(No for ONS 15540 and ONS 15530.)
TMF.
Description
Note This is not defined by the
TMF.
String Yes.
The value of this field is the native NE event
value.
A.4.6 Threshold Crossing Alert
The following table lists the TCA types and attributes. This event is not supported for ONS 15501,
ONS 15530, ONS 15540, and MGX 8880/8850/8830 NEs because TCAs are reported as alarms.
Table A-12 Threshold Crossing Alert
Attribute Name Type Supported by CTM?
notificationId string Yes. The uniqueness and the sequence of the
notification ID are not guaranteed.
objectName globaldefs::NamingAttributes_T Yes.
nativeEMSName string Yes.
objectType notifications::ObjectType_T Yes.
emsTime globaldefs::Time_T Yes.
neTime globaldefs::Time_T Yes.
isClearable boolean Yes.
Always set to false.
perceivedSeverity notifications::PerceivedSeverity_T Yes.
Always set to
PerceivedSeverity_T.PS_INDETERMINATE.
layerRate transmissionParameters::LayerRate_T Yes.
granularity Granularity_T Yes.
pmParameterName PMParameterName_T Yes.
Note If the NE does not report the location, this
pmLocation PMLocation_T Yes.
Note If the NE does not report the location, this
thresholdType PMThresholdType_T No.
value float Yes.
unit string No.
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
field is empty.
field is empty.
A-9
Page 10
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Supported Events
A.4.7 Alarm
The following table lists the most common alarm messages.
If there is an alarm on an STS/VC4 CTP utilizing all ports of a DS1/E1 card, the alarm is reported with
the containing PTP as port 127. If an STS/VC4 SNC exists with one of the drop CTPs of the SNC using
all ports on a DS1/E1 card, and if there is an alarm on the STS CTP, CTM reports the port number of the
containing PTP as 127.
Ta b l e A - 1 3 A l a r m
Attribute Name Type Supported by CTM?
notificationId string Yes. The uniqueness and sequence of the notification
ID are not guaranteed.
objectName globaldefs::NamingAttributes_T Yes.
nativeEMSName string Yes.
nativeProbableCause string Yes.
Note In case of external condition alarms, the string
value of the condition type is appended to this
field.
objectType notifications::ObjectType_T Yes.
emsTime globaldefs::Time_T Yes.
neTime globaldefs::Time_T Yes.
isClearable boolean Yes. The value is always set to True.
layerRate transmissionParameters::LayerRate_T Yes.
Note Not supported for ONS 15501, ONS 15530,
and ONS 15540 NEs.
probableCause string Yes.
probableCauseQualifier string Yes. CTM provides the same value as in the
nativeProbableCause field.
perceivedSeverity notifications::PerceivedSeverity_T Yes.
serviceAffecting notifications::ServiceAffecting_T Yes.
affectedTPList globaldefs::NamingAttributesList_T Yes.
additionalText string Yes.
additionalInfo globaldefs::NVSList_T Yes.
CTM provides subnetwork name when available.
If the alarmed object is OC-n PTP, CTM also includes
SDH_SONET_SS_BITS in this list.
CTM provides the IP address for ME-related alarms.
CTM provides the ME name when the object type is
OT_EMS and the alarm is ME-related.
CTM provides the affected object when the object
type is OT_EMS and the nativeProbableCause is
“Server Monitor Threshold Crossed.”
A-10
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 11
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Supported Events
Table A-13 Alarm (continued)
Attribute Name Type Supported by CTM?
isPropagated boolean Yes. For the MGX 8880/8850/8830, values are
assigned to this field. For all other NEs, this field is
always set to False.
aresFDN string Yes.
A.4.8 Heartbeat Event
CTM generates a periodic heartbeat event and pushes the event to the notification channel. By default,
this function is disabled. You can configure the interval value through the CTM Control Panel. If the
interval value is set to 0, the heartbeat event is disabled. By monitoring this event, the northbound
interface client knows whether the notification service is active. The type_name field contains the
NT_HEART_BEAT value under the fixed_header for this type of event. Filterable_data has only one
field, which is shown in the following table.
Table A-14 Heartbeat Event
Attribute Name Type Supported by CTM?
notificationId string Yes. The uniqueness and sequence of the notification ID are not guaranteed.
A.4.9 Backup Status Event
The backup status event contains details about changes to a managed element’s backup status.
Table A-15 Backup Status Event
Attribute Name Type Supported by CTM?
notificationId string Yes. The uniqueness and sequence of the notification ID are not
guaranteed.
emsTime globaldefs::Time_T Yes. The time when the EMS reported the event.
neTime globaldefs::Time_T Yes. The time provided by the NE. If the NE does not report time,
this field is optional or reports an empty string.
backupStatus softwareManager::BackupStatus_T Yes. The backup status of the managed element.
meName globaldefs::NamingAttributes_T Yes. The name of the managed element from which the backup
was taken.
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-11
Page 12
Probable Cause Mapping
A.5 Probable Cause Mapping
A.5.1 TMF-Defined Probable Cause
The following report lists the probable causes defined by the TMF:
"UNIDENTIFIED": for alarms that do not match any other string below. EMS shall in this
case fill out the additional text field as much as possible.
"AIS": alarm indication signal
"AMS": Alternate modulation signal
"AU-AIS": AU alarm indication signal
"BER_SD": signal degrade (includes receiver degrade)
"BER_SF": signal fail (includes receiver failure and excessive BER)
"DCC_FAILURE": Data Communication Channel Failure
"EMS": EMS system alarm
"EMS_ALM_LOSS": The 1st notification that the EMS may supply after 1 or more notifications
for protection switch, TCA, alarm, or file transfer status have been discarded by the EMS
while other events have not been discarded
"EMS_LIFECYCLE_LOSS": The 1st notification that an EMS may supply after 1 or more events
of type OC/OD/AVC/SC/RC have been discarded by the EMS
"EMS_ALM_AND_LIFECYCLE_LOSS": The 1st notification that an EMS may supply after 1 or more
notifications for protection switch, TCA, alarm, or file transfer status, and 1 or more
events of type OC/OD/AVC/SC/RC have been discarded by the EMS
"EQPT": equipment alarm
"ENV": Environmental/external cause
"FOP_APS": failure of APS protocol
"LCD": Loss of Cell Delineation (from TC Adaptor part of ATM NI)
"LOF": loss of frame (when distinguished from LOS)
"LOM": loss of multiframe (SDH only, since not an alarm in GR-253)
"LOP": loss of pointer
"LOS": loss of signal
"MS-AIS": MS alarm indication signal
"OSC-AIS": Optical Supervisory Channel alarm indication signal
"OSC_BER_SF": Optical Supervisory Channel signal fail/RX fail/excessive BER
"OSC_FERF": Optical Supervisory Channel Far End Receive Failure
"OSC_LOF": Optical Supervisory Channel Loss of Frame
"OSC_LOS": Optical Supervisory Channel Loss of Signal
"OSC_SD": Optical Supervisory Channel signal degrade
"PLM": payload label mismatch (when reported as an alarm)
"RAI": remote alarm indication (sometimes reported as RDI)
"SECURITY_VIOLATION": security violation
"SSF": server signal fail
"TCM-AIS": Tandem Connection Sink - Incoming Alarm Indication Signal
"TCM-LOS": Tandem Connection Sink - Loss of Tandem Connection Signal
"TCM-OAI": Tandem Connection Sink - Outgoing Defect Indication (same/similar to Alarm
Indication)
"TCM-RAI": Tandem Connection Sink - Remote Defect Indication (same/similar to Alarm
Indication)
"TCM-SD": Tandem Connection Sink - Signal Degrade
"TCM-SSF": Tandem Connection Sink - Server Signal Fail
"TCM-TIM": Connection Sink - Trace Identifier Mismatch
"TCM-UNEQ": Tandem Connection Sink - Unequipped
"TIM": trace identifier mismatch (when reported as an alarm)
"TU-AIS": TU alarm indication signal
"TX_DEGRADE": transmitter degrade, including laser degrade
"TX_FAIL": transmitter failure, including laser failure
"UAT": Unavailable Time
"UNEQ": payload unequipped
"VC-AIS": VCL/VCC TP Alarm Indication Signal
"VC-RDI": VCL/VCC TP Remote Defect Indication
"VP-AIS": VPL/VPC TP Alarm Indication Signal
Appendix A Notifications, Fault Management, and Probable Cause Mapping
A-12
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 13
Appendix A Notifications, Fault Management, and Probable Cause Mapping
"VP-RDI": VPL/VPC TP Remote Defect Indication
A.5.2 CTM GateWay/CORBA Mapping—EMS
The following table lists the CTM GateWay/CORBA mapping for the EMS.
Table A-16 CTM GateWay/CORBA Mapping for the EMS
CTM Internal Index (Not Reported in
TMF Mapping NE Native Probable Cause
EMS Loss of communication 5001
EMS Memory automatic or manual backup failure 5002
SECURITY_VIOLATION Maximum login attempts exceeded 5003
EMS Partition 0 free disk space low 5004
EMS Partition 1 free disk space low 5005
EMS Partition 2 free disk space low 5006
EMS Partition 3 free disk space low 5007
EMS Partition 4 free disk space low 5008
EMS Partition 5 free disk space low 5009
EMS Partition 6 free disk space low 5010
EMS Alarm resync unsuccessful 5011
EMS Server monitor threshold crossed 5012
the Notification)
Probable Cause Mapping
A.5.3 CTM GateWay/CORBA Mapping—MGX 8880/8850/8830
The following table lists the CTM GateWay/CORBA mapping for the MGX 8880/8850/8830.
Table A-17 CTM GateWay/CORBA Mapping for the MGX 8880/8850/8830
CTM Internal Index (Not
Reported in the
TMF Mapping NE Native Probable Cause
EMS Sync-up has not started yet 60009
EMS Currently in sync-up 60010
EMS Partial sync-up 60011
EMS Sync-up failed 60012
EMS Server in partial sync-up 60013
EMS Server sync-up failed 60014
Note The following EMS alarms must be cleared manually, so “isClearable” should be set to “False” in the corresponding
CTM GateWay/CORBA alarm event.
EMS FTP transfer failure 62401
EMS FTP file size mismatch 62408
Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-13
Page 14
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-17 CTM GateWay/CORBA Mapping for the MGX 8880/8850/8830 (continued)
CTM Internal Index (Not
Reported in the
TMF Mapping NE Native Probable Cause
EMS FTP transfer failed 62409
EMS Upload file error 62410
EMS Minus 2 trap 62411
EMS Card lost trap 62412
EMS SNMP retry exceeded 62413
EMS FTP retry exceeded 62414
EMS Stats file error 62416
EMS Stats file transfer error 62417
EMS SNMP throttle error 62418
EMS Backoff failed 62419
EMS SNMP timeout 62420
EMS FTP session timeout 62421
EMS FTP transfer timeout 62422
EMS Unknown error 62448
EMS Initialization error 62449
EMS Communication error in ILOG 62452
EMS Communication error in shared memory 62453
EMS Communication error in CORBA 62454
EMS NTS registration failed 62456
EMS NTS trap loss 62457
EMS PM error 62459
EMS Process restarted 62502
Shelf-Level Peripheral Alarms
EQPT Above normal 60031
EQPT Below normal 60032
EQPT Down 60033
EQPT Power failure 60034
Card-Level Alarms for all Supported Cards on MGX8880/8850/8830
EQPT Front card not present 60101
EQPT Front card failed 60102
EQPT Front card in self test 60103
EQPT Front card held in reset 60104
EQPT Front card in boot 60105
EQPT Front card mismatch 60106
EQPT Front card unknown alarm 60107
Notification)
A-14
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 15
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Table A-17 CTM GateWay/CORBA Mapping for the MGX 8880/8850/8830 (continued)
CTM Internal Index (Not
Reported in the
TMF Mapping NE Native Probable Cause
EQPT Front card core card mismatch 60108
EQPT Front card failed, no backup 60109
EQPT Front card reserved 60110
EQPT Front card down 60111
EQPT Front card in update mode 60112
EQPT Front card unavailable 60113
EQPT Front card downloading 60114
EQPT Front card downloader 60115
EQPT Front card downloaded 60116
EQPT Front card locked 60117
EQPT Front card in program mode 60118
EQPT Front card upgrading 60119
EQPT Front card upgraded 60120
EQPT Front card frozen 60121
EQPT Front card in hold mode 60122
EQPT Front card not responding 60123
EQPT Front card in initialization 60124
EQPT Front card blocked 60125
EQPT Front card removed 60126
EQPT Primary back card not present 60201
EQPT Primary back card in mismatch 60202
EQPT Secondary back card not present 60301
EQPT Secondary back card in mismatch 60302
EQPT Primary card not present 60401
EQPT Primary card failed 60402
EQPT Primary card in self test 60403
EQPT Primary card held in reset 60404
EQPT Primary card in boot 60405
EQPT Primary card mismatch 60406
EQPT Primary card unknown alarm 60407
EQPT Primary card core card mismatch 60408
EQPT Primary card failed, no backup 60409
EQPT Primary card reserved 60410
EQPT Primary card down 60411
EQPT Primary card in update mode 60412
Notification)
Probable Cause Mapping
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-15
Page 16
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-17 CTM GateWay/CORBA Mapping for the MGX 8880/8850/8830 (continued)
CTM Internal Index (Not
Reported in the
TMF Mapping NE Native Probable Cause
EQPT Primary card unavailable 60413
EQPT Primary card downloading 60414
EQPT Primary card downloader 60415
EQPT Primary card downloaded 60416
EQPT Primary card locked 60417
EQPT Primary card in program mode 60418
EQPT Primary card upgrading 60419
EQPT Primary card upgraded 60420
EQPT Primary card frozen 60421
EQPT Primary card in hold mode 60422
EQPT Primary card not responding 60423
EQPT Primary card in initialization 60424
EQPT Primary card blocked 60425
EQPT Front card removed 60426
EQPT Secondary card not present 60501
EQPT Secondary card failed 60502
EQPT Secondary card in self test 60503
EQPT Secondary card held in reset 60504
EQPT Secondary card in boot 60505
EQPT Secondary card mismatch 60506
EQPT Secondary card unknown alarm 60507
EQPT Secondary card core card mismatch 60508
EQPT Secondary card failed, no backup 60509
EQPT Secondary card reserved 60510
EQPT Secondary card down 60511
EQPT Secondary card in update mode 60512
EQPT Secondary card unavailable 60513
EQPT Secondary card downloading 60514
EQPT Secondary card downloader 60515
EQPT Secondary card downloaded 60516
EQPT Secondary card locked 60517
EQPT Secondary card in program mode 60518
EQPT Secondary card upgrading 60519
EQPT Secondary card upgraded 60520
EQPT Secondary card frozen 60521
Notification)
A-16
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 17
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Table A-17 CTM GateWay/CORBA Mapping for the MGX 8880/8850/8830 (continued)
CTM Internal Index (Not
Reported in the
TMF Mapping NE Native Probable Cause
EQPT Secondary card in hold mode 60522
EQPT Secondary card not responding 60523
EQPT Secondary card in initialization 60524
EQPT Redundant blocked 60525
EQPT Secondary card removed 60526
EQPT Controller in standby mode 60601
EQPT License expired 60650
EQPT License missing 60651
EQPT Card sync-up failed 60660
EQPT Redundant card switch over 60661
Sensor Alarms: VXSM
EQPT Sensor less than threshold value 60670
EQPT Sensor greater than threshold value 60671
EQPT Sensor equal to threshold value 60672
EQPT Sensor less than threshold value 60673
EQPT Sensor greater than threshold value 60674
EQPT Sensor equal to threshold value 60675
EQPT Sensor less than threshold value 60676
EQPT Sensor greater than threshold value 60677
EQPT Sensor equal to threshold value 60678
Line-Level Alarms
DS1 Line: AXSM, MPSM, PXM1E, VXSM, VISM, SRME
RAI Receiving RAI 60701
RAI Transmitting RAI 60702
AIS Receiving AIS 60703
AIS Transmitting AIS 60704
OOF Receiving OOF 60705
LOS Receiving LOS 60706
UNIDENTIFIED Near-end local loop in effect 60707
UNIDENTIFIED Near-end remote loop in effect 60708
UNIDENTIFIED Near-end remote payload loop in effect 60709
OOF Receiving CRC MF OOF 60710
OOF Receiving signal MF OOF 60711
RAI Receiving MF RAI 60712
AIS Receiving MF AIS 60713
Notification)
Probable Cause Mapping
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-17
Page 18
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-17 CTM GateWay/CORBA Mapping for the MGX 8880/8850/8830 (continued)
CTM Internal Index (Not
Reported in the
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Far-end remote loopback 60714
UNIDENTIFIED Detected near-end remote loopback 60715
DS3 Line: AXSM, MPSM, PXM1E, VXSM, SRME
UNIDENTIFIED Receiving RAI 60801
RAI Transmitting RAI 60802
AIS Receiving AIS 60803
AIS Transmitting AIS 60804
OOF Receiving OOF 60805
LOS Receiving LOS 60806
UNIDENTIFIED Near-end local loop in effect 60807
UNIDENTIFIED Near-end remote loop in effect 60808
UNIDENTIFIED Receiving test pattern 60809
UNIDENTIFIED Receiving LOCD 60810
UNIDENTIFIED Receiving C-bit parity pattern 60811
SONET Line: AXSM, MPSM, PXM1E, VXSM, SRME
AIS Line receiving AIS 60901
UNIDENTIFIED Line receiving RDI 60902
AIS Line transmitting AIS 60903
UNIDENTIFIED Line transmitting RDI 60904
LOS Section LOS 60910
LOF Section LOF 60911
UNIDENTIFIED Section trace ID mismatch 60912
LOP Path receiving STS LOP 60920
AIS Path receiving STS AIS 60921
UNIDENTIFIED Path receiving STS RDI 60922
UNEQ Path unequipped 60923
UNIDENTIFIED Path signal label mismatch 60924
UNIDENTIFIED Path trace failure 60925
AIS Path transmitting AIS 60926
UNIDENTIFIED Path transmitting RDI 60927
UNIDENTIFIED Path signal receiving LOCD 60928
Line Stats Alarm
DS1/DS3: AXSM, MPSM, PXM1E, VXSM, VISM, SRME
UNIDENTIFIED Stats alarm, PES current 15-minute threshold exceeded 61101
UNIDENTIFIED Stats alarm, PES 24-hour threshold exceeded 61102
Notification)
A-18
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 19
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Table A-17 CTM GateWay/CORBA Mapping for the MGX 8880/8850/8830 (continued)
CTM Internal Index (Not
Reported in the
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Stats alarm, PSES current 15-minute threshold exceeded 61103
UNIDENTIFIED Stats alarm, PSES 24-hour threshold exceeded 61104
UNIDENTIFIED Stats alarm, SEFS current 15-minute threshold exceeded 61105
UNIDENTIFIED Stats alarm, SEFS 24-hour threshold exceeded 61106
UNIDENTIFIED Stats alarm, UAS current 15-minute threshold exceeded 61107
UNIDENTIFIED Stats alarm, UAS 24-hour threshold exceeded 61108
UNIDENTIFIED Stats alarm, LCV current 15-minute threshold exceeded 61109
UNIDENTIFIED Stats alarm, LCV 24-hour threshold exceeded 61110
UNIDENTIFIED Stats alarm, PCV current 15-minute threshold exceeded 61111
UNIDENTIFIED Stats alarm, PCV 24-hour threshold exceeded 61112
UNIDENTIFIED Stats alarm, LES current 15-minute threshold exceeded 61113
UNIDENTIFIED Stats alarm, LES 24-hour threshold exceeded 61114
UNIDENTIFIED Stats alarm, CCV current 15-minute threshold exceeded 61115
UNIDENTIFIED Stats alarm, CCV 24-hour threshold exceeded 61116
UNIDENTIFIED Stats alarm, CES current 15-minute threshold exceeded 61117
UNIDENTIFIED Stats alarm, CES 24-hour threshold exceeded 61118
UNIDENTIFIED Stats alarm, CSES current 15-minute threshold exceeded 61119
UNIDENTIFIED Stats alarm, CSES 24-hour threshold exceeded 61120
SONET: AXSM, MPSM, PXM1E, VXSM, SRME
UNIDENTIFIED Stats alarm, SONET line, total ESs 61201
UNIDENTIFIED Stats alarm, SONET line, total SESs 61202
UNIDENTIFIED Stats alarm, SONET line, total CVs 61203
UNIDENTIFIED Stats alarm, SONET line, total UAs 61204
UNIDENTIFIED Stats alarm, SONET line, current ESs 61205
UNIDENTIFIED Stats alarm, SONET line, current SESs 61206
UNIDENTIFIED Stats alarm, SONET line, current CVs 61207
UNIDENTIFIED Stats alarm, SONET line, current UAs 61208
UNIDENTIFIED Stats alarm, SONET line, far end, current ESs 61209
UNIDENTIFIED Stats alarm, SONET line, far end, total ESs 61210
UNIDENTIFIED Stats alarm, SONET line, far end, total SESs 61211
UNIDENTIFIED Stats alarm, SONET line, far end, total CVs 61212
UNIDENTIFIED Stats alarm, SONET line, far end, total UAs 61213
UNIDENTIFIED Stats alarm, SONET line, far end, current SESs 61214
UNIDENTIFIED Stats alarm, SONET line, far end, current CVs 61215
UNIDENTIFIED Stats alarm, SONET line, far end, current UASs 61216
Notification)
Probable Cause Mapping
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-19
Page 20
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-17 CTM GateWay/CORBA Mapping for the MGX 8880/8850/8830 (continued)
CTM Internal Index (Not
Reported in the
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Stats alarm, SONET section, total ESs 61301
UNIDENTIFIED Stats alarm, SONET section, total SESs 61302
UNIDENTIFIED Stats alarm, SONET section, total SEFSs 61303
UNIDENTIFIED Stats alarm, SONET section, total CVs 61304
UNIDENTIFIED Stats alarm, SONET section, current ESs 61305
UNIDENTIFIED Stats alarm, SONET section, current SESs 61306
UNIDENTIFIED Stats alarm, SONET section, current SEFSs 61307
UNIDENTIFIED Stats alarm, SONET section, current CVs 61308
UNIDENTIFIED Stats alarm, SONET path, total ESs 61401
UNIDENTIFIED Stats alarm, SONET path, total SESs 61402
UNIDENTIFIED Stats alarm, SONET path, total CVs 61403
UNIDENTIFIED Stats alarm, SONET path, total UAs 61404
UNIDENTIFIED Stats alarm, SONET path, current ESs 61405
UNIDENTIFIED Stats alarm, SONET path, current SESs 61406
UNIDENTIFIED Stats alarm, SONET path, current CVs 61407
UNIDENTIFIED Stats alarm, SONET path, current UAs 61408
UNIDENTIFIED Stats alarm, SONET path, far end, current ESs 61409
UNIDENTIFIED Stats alarm, SONET path, far end, total ESs 61410
UNIDENTIFIED Stats alarm, SONET path, far end, total SESs 61411
UNIDENTIFIED Stats alarm, SONET path, far end, total CVs 61412
UNIDENTIFIED Stats alarm, SONET path, far end, total UAs 61413
UNIDENTIFIED Stats alarm, SONET path, far end, current SESs 61414
UNIDENTIFIED Stats alarm, SONET path, far end, current CVs 61415
UNIDENTIFIED Stats alarm, SONET path, far end, current UASs 61416
Line APS Alarms: AXSM, MPSM, PXM1E, VXSM, SRME
FOP_APS APS alarm, channel mismatch 61501
FOP_APS APS alarm, protection byte fail 61502
FOP_APS APS alarms, FE protection failure 61503
FOP_APS APS alarms, mode mismatch 61504
FOP_APS APS alarms, signal degrade 61505
FOP_APS APS alarms, signal failure 61506
FOP_APS APS alarms, line alarm 61507
FOP_APS APS alarms, line loopback 61508
FOP_APS APS alarms, standby signal degrade 61509
FOP_APS APS alarms, standby signal failure 61510
Notification)
A-20
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 21
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Table A-17 CTM GateWay/CORBA Mapping for the MGX 8880/8850/8830 (continued)
CTM Internal Index (Not
Reported in the
TMF Mapping NE Native Probable Cause
FOP_APS APS alarms, standby line alarm 61511
FOP_APS APS alarms, standby line loopback 61512
FOP_APS APS alarms, direction mismatch 61513
FOP_APS APS alarms, wrong request 61514
EQPT APS alarms, protect BC missing 61515
EQPT APS alarms, protect DC missing 61516
EQPT APS alarms, working BC missing 61517
EQPT APS alarms, working DC missing 61518
EQPT APS alarms, working card mismatch 61519
EQPT APS alarms, protect card mismatch 61520
FOP_APS APS alarms, APS revertive switch fail 61521
FOP_APS APS alarms, APS manual switch fail 61522
FOP_APS APS alarms, APS SD low switch fail 61523
FOP_APS APS alarms, APS SD high switch fail 61524
FOP_APS APS alarms, APS SF low switch fail 61525
FOP_APS APS alarms, APS SF high switch fail 61526
FOP_APS APS alarms, APS force switch fail 61527
FOP_APS APS alarms, APS lockout switch fail 61528
FOP_APS APS alarms, APS line status OK 61529
Port Alarms: AXSM, MPSM, PXM1E
UNIDENTIFIED Port, not configured 61751
UNIDENTIFIED Port, down/failure 61752
UNIDENTIFIED Port, remote loopback 61753
UNIDENTIFIED Port, signaling failure 61754
UNIDENTIFIED Port, out of cell delineation 61755
UNIDENTIFIED Port, lower layer down 61756
RPM Port Alarms: RPM, RPM-XF
UNIDENTIFIED RPM port, down 62101
UNIDENTIFIED RPM port, testing 62102
UNIDENTIFIED RPM port, unknown 62103
UNIDENTIFIED RPM port, lower layer down 62104
SVC Port Alarms: AXSM, VXSM, RPM-XF, RPM
UNIDENTIFIED SVC port, failed 62201
UNIDENTIFIED SVC port, inactive 62202
UNIDENTIFIED SVC port, lower layer down 62203
Notification)
Probable Cause Mapping
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-21
Page 22
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-17 CTM GateWay/CORBA Mapping for the MGX 8880/8850/8830 (continued)
CTM Internal Index (Not
Reported in the
TMF Mapping NE Native Probable Cause
VISM Port Alarms: VISM
UNIDENTIFIED VISM port, failed 62221
UNIDENTIFIED VISM port, degraded 62222
UNIDENTIFIED VISM port, lower layer down 62223
Aggregate Port Alarms: AXSM, MPSM, PXM1E RPM, RPM-XF
UNIDENTIFIED Aggregate port alarm; one or more connections on this port are
in primary failure
UNIDENTIFIED Aggregate port alarm; one or more connections on this port are
in secondary failure
UNIDENTIFIED Aggregate port alarm; one or more connections on this port are
incomplete
Connection Alarm: AXSM, MPSM, PXM1E, VXSM, VISM, RPM, RPM-XF
UNIDENTIFIED Connection alarm, primary failure 62601
UNIDENTIFIED Connection alarm, secondary failure 62602
UNIDENTIFIED Incomplete connection 62603
Card-Level VXSM and VISM Alarms
UNIDENTIFIED CAC resources, above high threshold value 60681
UNIDENTIFIED CAC resources, above medium threshold value 60683
UNIDENTIFIED Media gateway link state, pending in service 60611
UNIDENTIFIED Media gateway link state, pending FOOS 60613
UNIDENTIFIED Media gateway link state, pending GOOS 60614
UNIDENTIFIED Media gateway link state, out of service 60612
UNIDENTIFIED Media gateway link state, MGC direct out of service 60615
UNIDENTIFIED RUDP session state, out of service 60631
UNIDENTIFIED RUDP session state, standby in service 60632
UNIDENTIFIED RUDP session state, full in service 60633
UNIDENTIFIED RUDP session state, unknown 60634
UNIDENTIFIED Session group state, out of service 60641
UNIDENTIFIED Session group state, unknown 60642
UNIDENTIFIED Session set state, out of service 60691
UNIDENTIFIED Session set state, standby in service 60692
UNIDENTIFIED Session set state, full in service 60693
UNIDENTIFIED Session set state, unknown 60694
UNIDENTIFIED MGC in redundancy group, inactive 60211
UNIDENTIFIED MGC communication state, inactive 60221
UNIDENTIFIED RTP connection state, failed 60231
Notification)
62301
62302
62303
A-22
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 23
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Table A-17 CTM GateWay/CORBA Mapping for the MGX 8880/8850/8830 (continued)
CTM Internal Index (Not
Reported in the
TMF Mapping NE Native Probable Cause
UNIDENTIFIED CID state, failed 60241
UNIDENTIFIED MTP link set active 66001
UNIDENTIFIED MTP link set inactive 66002
UNIDENTIFIED MTP link set inhibited 66003
UNIDENTIFIED MTP link set uninhibited 66004
UNIDENTIFIED MTP link set shut 66005
UNIDENTIFIED MTP link set no shut 66006
UNIDENTIFIED MTP link active 66007
UNIDENTIFIED MTP link inactive 66008
UNIDENTIFIED MTP link inhibited 66009
UNIDENTIFIED MTP link uninhibited 66010
UNIDENTIFIED MTP link shut 66011
UNIDENTIFIED MTP link no shut 66012
UNIDENTIFIED MTP signaling gateway route available 66013
UNIDENTIFIED MTP signaling gateway route unavailable 66014
UNIDENTIFIED MTP signaling gateway route restricted 66015
UNIDENTIFIED L3UA ASP active 66016
UNIDENTIFIED L3UA ASP inactive 66017
UNIDENTIFIED L3UA ASP down 66018
UNIDENTIFIED L3UA ASP undefined 66019
UNIDENTIFIED L3UA AS active 66020
UNIDENTIFIED L3UA AS inactive 66021
UNIDENTIFIED L3UA AS down 66022
UNIDENTIFIED L3UA AS pending 66023
UNIDENTIFIED L3UA AS undefined 66024
UNIDENTIFIED DPNSS DLC active 66025
UNIDENTIFIED DPNSS DLC inactive 66026
UNIDENTIFIED Gateway voice quality alert 66027
UNIDENTIFIED Gateway VBD call quality alert 66028
UNIDENTIFIED Gateway voice quality alert for IP-IP 66029
UNIDENTIFIED Gateway VQM trap queue full 66030
UNIDENTIFIED System resource utilization threshold exceeded 66031
UNIDENTIFIED System resource utilization normal 66032
UNIDENTIFIED System resource utilization medium level exceeded 66033
UNIDENTIFIED Zero percent call reduce rate reached 66034
Notification)
Probable Cause Mapping
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-23
Page 24
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-17 CTM GateWay/CORBA Mapping for the MGX 8880/8850/8830 (continued)
CTM Internal Index (Not
Reported in the
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Maximum call reduce rate reached 66035
UNIDENTIFIED Gateway drop call starts 66036
UNIDENTIFIED Gateway drop call alert cleared 66037
UNIDENTIFIED Gateway overload normal 66038
UNIDENTIFIED Gateway overload threshold exceeded 66039
Line-Level VISM and VXSM Alarms
UNIDENTIFIED Endpoint state, failed 60251
UNIDENTIFIED Endpoint state, degraded 60252
UNIDENTIFIED LAPD state, inactive 61591
UNIDENTIFIED LAPD trunk state, inactive 61531
UNIDENTIFIED LAPD trunk state, unknown 61532
Notification)
A.5.4 CTM GateWay/CORBA Mapping—ONS 15216
A.5.4.1 ONS 15216 OADM
The following table lists the alarms for the ONS 15216 OADM R2.2.
Table A-18 CTM GateWay/CORBA Alarms for the ONS 15216 OADM R2.2
CTM Internal Index
(Not Reported in the
TMF Mapping NE Native Probable Cause
LOS Add channel signal loss 8501
LOS Drop channel signal loss 8502
EQPT Add and drop channels are out of tolerance 8503
EQPT Add channel signal is too weak and VOA cannot adjust it to match the drop signal 8504
EQPT Power unit A failed 8505
EQPT Power unit B failed 8506
Notification)
A-24
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 25
Appendix A Notifications, Fault Management, and Probable Cause Mapping
A.5.4.2 ONS 15216 EDFA2
The following table lists the alarms for the ONS 15216 EDFA2 R2.3 and 2.4.
Table A-19 CTM GateWay/CORBA Alarms for the ONS 15216 EDFA2 R2.3 and R2.4
CTM Internal Index (Not Reported
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Unknown alarm 8601
EQPT Excessive pump 1 current 8602
EQPT Excessive pump 2 current 8603
EQPT Excessive pump 1 laser temperature 8604
EQPT Excessive pump 2 laser temperature 8605
EQPT Loss of output power 8606
EQPT Loss of input power 8607
EQPT Gain out of range 8608
EQPT Case temperature out of range 8609
EQPT Power unit A failed 8610
EQPT Power unit B failed 8611
EQPT Database backup 8612
EQPT Database restore 8613
EQPT Cutover reset 8614
EQPT Software load 8615
EQPT Software reset 8616
in the Notification)
Probable Cause Mapping
A.5.4.3 ONS 15216 EDFA3
The following table lists the alarms for the ONS 15216 EDFA3 R1.1.
Table A-20 CTM GateWay/CORBA Alarms for the ONS 15216 EDFA3 R1.1
CTM Internal Index (Not Reported in
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Unknown alarm 8701
EQPT Gain degrade high 8702
EQPT Gain degrade low 8703
EQPT Laser 1 bias degrade 8704
EQPT Laser 2 bias degrade 8705
EQPT Laser 1 bias fail 8706
EQPT Laser 2 bias fail 8707
EQPT Power degrade high LINE1TX port 8708
EQPT Power degrade low LINE1TX port 8709
EQPT Power fail low LINE1RX port 8710
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
the Notification)
A-25
Page 26
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-20 CTM GateWay/CORBA Alarms for the ONS 15216 EDFA3 R1.1 (continued)
CTM Internal Index (Not Reported in
TMF Mapping NE Native Probable Cause
EQPT Power fail low LINE1TX port 8711
EQPT Power fail low LINE2RX port 8712
EQPT VOA degrade high 8713
EQPT VOA degrade low 8714
EQPT VOA fail high 8715
EQPT Case temperature out of range 8716
EQPT Fiber temperature out of range 8717
EQPT Excessive pump 1 temperature 8718
EQPT Excessive pump 2 temperature 8719
EQPT Backup/restore in progress 8720
EQPT Data integrity fault 8721
EQPT Equipment failure 8722
EQPT Exceeding memory capacity 8723
EQPT Exceeding flash file system capacity 8724
EQPT Module communication failure 8725
EQPT Power bus A alarm 8726
EQPT Power bus B alarm 8727
the Notification)
A.5.5 CTM GateWay/CORBA Mapping—ONS 15302, ONS 15305, and ONS 15305
CTC
The following table lists the CTM GateWay/CORBA mapping for the ONS 15302, ONS 15305, and
ONS 15305 CTC.
Table A-21 CTM GateWay/CORBA Mapping for the ONS 15302, ONS 15305, and ONS 15305 CTC
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED ONS 1530x condition unknown 19000
AIS Alarm indication signal 19001
AIS Alarm indication signal network side 19002
LOF Alarm indication signal customer side 19003
LOF Loss of frame alignment 19004
LOF Loss of frame alignment network side 19005
LOF Loss of frame alignment customer side 19006
LOP Loss of pointer 19007
LOS Loss of signal 19008
Reported in the Notification)
A-26
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 27
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-21 CTM GateWay/CORBA Mapping for the ONS 15302, ONS 15305, and ONS 15305 CTC (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
BER_SD Degraded signal defect 19009
LOM Loss of multiframe alignment 19010
RAI Remote defect indication 19011
TIM Trace identifier mismatch 19012
PLM Payload mismatch 19013
UNEQ Unequipped 19014
BER_SF Excessive error defect 19015
UNIDENTIFIED Communication subsystem failure 19016
SSF Server signal failure 19017
UNIDENTIFIED Alarm condition detected on an alarm input port 19018
EQPT Device main unit failure 19019
EQPT High temperature alarm 19020
EQPT Fan failure 19021
EQPT Power input failure 19022
EQPT Power output failure 19023
EQPT Module mismatch 19024
EQPT Module removed 19025
EQPT Module failure 19026
UNIDENTIFIED MSP signaling problem 19027
UNIDENTIFIED Power module failure 19028
UNIDENTIFIED LAN port is not working 19029
UNIDENTIFIED WAN port is not working 19030
UNIDENTIFIED Too large delay on WAN channel 19031
UNIDENTIFIED Sequence number fail on WAN channel 19032
UNIDENTIFIED No synchronization source available 19033
UNIDENTIFIED Defecting hardware impacting internal T0 clock 19034
UNIDENTIFIED No T4 synchronization source available with QL >= QL min 19035
UNIDENTIFIED Inventory failure 19036
UNIDENTIFIED Diagnostic failure 19037
UNIDENTIFIED DXC inlet failure 19038
UNIDENTIFIED DXC inlet bit error 19039
UNIDENTIFIED Card isolated 19040
UNIDENTIFIED Card anomaly 19041
UNIDENTIFIED Hot swap failure 19042
UNIDENTIFIED Power input failure 19043
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-27
Page 28
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-21 CTM GateWay/CORBA Mapping for the ONS 15302, ONS 15305, and ONS 15305 CTC (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Transmit degrade on laser 19044
UNIDENTIFIED Transmit fail on laser 19045
UNIDENTIFIED Port activated without mapping to an available VC-12 19046
UNIDENTIFIED Differential VC12 delay for the WAN port is greater than +/- 2 ms 19047
UNIDENTIFIED Rx buffer overflow in LAN or link interface 19048
UNIDENTIFIED Interport queue overflow in LAN or link interface 19049
UNIDENTIFIED Reset of the router/bridge required 19050
UNIDENTIFIED Device aborted FTP session 19051
UNIDENTIFIED Automatic switchover to backup link, main link fault 19052
UNIDENTIFIED Overflow layer 2 forward table 19053
UNIDENTIFIED Connection failed: frame relay switch and WAN gate 19054
UNIDENTIFIED Connection established: frame relay switch and WAN gate 19055
UNIDENTIFIED Error occurred during initialization 19056
UNIDENTIFIED Overflow in the client table 19057
UNIDENTIFIED Server not responding to dispatcher polling 19058
UNIDENTIFIED SNMP SET request was rejected 19059
UNIDENTIFIED Ping sequence completed 19060
UNIDENTIFIED Backup taken over for main server or server up after failure 19061
UNIDENTIFIED DHCP failed to allocate IP address to requesting host 19062
UNIDENTIFIED Overflow IGMP table 19063
UNIDENTIFIED Overflow PIM table 19064
UNIDENTIFIED Overflow condition in routing table 19065
UNIDENTIFIED Open gate IPX RIP table overflow 19066
UNIDENTIFIED Open gate IPX SAP table overflow 19067
UNIDENTIFIED FACS state NE with operation blockAndReport 19068
UNIDENTIFIED Zero hop routing connections table overflow 19069
UNIDENTIFIED No available IP virtual address 19070
UNIDENTIFIED Virtual IP address appeared as a source IP 19071
UNIDENTIFIED Source IP address sent an ARP specifying a virtual IP 19072
UNIDENTIFIED PPP link got an unrecognized secret 19073
UNIDENTIFIED FR DLCI status change 19074
UNIDENTIFIED CHAP failed communication 19075
UNIDENTIFIED IP SFFT overflow 19076
UNIDENTIFIED IP NFFT overflow 19077
UNIDENTIFIED IPX SFFT overflow 19078
Reported in the Notification)
A-28
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 29
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-21 CTM GateWay/CORBA Mapping for the ONS 15302, ONS 15305, and ONS 15305 CTC (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED IPX NFFT overflow 19079
UNIDENTIFIED IPM FFT overflow 19080
UNIDENTIFIED PAP failed communication 19081
UNIDENTIFIED Automatic switchover to backup link, main link fault 19082
UNIDENTIFIED Informational event 19083
UNIDENTIFIED T0 sync switch 19084
UNIDENTIFIED T0QI failed 19085
UNIDENTIFIED T0QIDnu 19086
UNIDENTIFIED Switch to protection 19087
UNIDENTIFIED Switch to working 19088
UNIDENTIFIED MSP command timeout 19089
UNIDENTIFIED MSP command overruled 19090
UNIDENTIFIED Loop closed 19091
UNIDENTIFIED Loop opened 19092
UNIDENTIFIED Link up 19093
UNIDENTIFIED Link down 19094
UNIDENTIFIED The communication link has come up 19095
UNIDENTIFIED Failure in communication link 19096
UNIDENTIFIED Addressee of a protocol message not properly authenticated 19097
UNIDENTIFIED Reinitializing; configuration or the protocol entity
implementation may be altered
UNIDENTIFIED Reinitializing; neither configuration nor protocol entity
implementation altered
UNIDENTIFIED RMON alarm has crossed the rising threshold 19100
UNIDENTIFIED RMON alarm has crossed the falling threshold 19101
UNIDENTIFIED Loss of an adjacency with a PIM neighbor 19102
UNIDENTIFIED Device finished TFTP transaction 19103
UNIDENTIFIED Device initiated TFTP transaction 19104
UNIDENTIFIED Auto configuration completed successfully 19105
UNIDENTIFIED VLAN port dynamically added 19106
UNIDENTIFIED VLAN port dynamically changed 19107
UNIDENTIFIED Physical description device changed 19108
UNIDENTIFIED Port transition from learning to forwarding 19109
UNIDENTIFIED Port transition from forwarding to learning 19110
UNIDENTIFIED Packet drop due to the QoS policy 19111
UNIDENTIFIED Packet forwarded based on the QoS policy 19112
Reported in the Notification)
19098
19099
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-29
Page 30
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-21 CTM GateWay/CORBA Mapping for the ONS 15302, ONS 15305, and ONS 15305 CTC (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
Reported in the Notification)
UNIDENTIFIED Protection link activated 19113
UNIDENTIFIED Working link activated 19114
UNIDENTIFIED MSP command timeout 19115
UNIDENTIFIED MSP command overruled 19116
UNIDENTIFIED Loss of external synchronization 19117
UNIDENTIFIED ONS 1530x condition unknown 19999
A.5.6 CTM GateWay/CORBA Mapping—ONS 15327 and ONS 15454 SONET R4.1
The following table lists the CTM GateWay/CORBA mapping for the ONS 15327 and ONS 15454
SONET R4.1.
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
Reported in the Notification)
UNIDENTIFIED Normal condition 25000
ENV Failure detected external to the NE 25001
ENV External error 25002
UNIDENTIFIED Excessive switching 25003
UNIDENTIFIED Incoming failure condition 25004
AIS Alarm indication signal 25005
AIS Alarm indication signal—line 25006
AIS Alarm indication signal—path 25007
FOP_APS APS channel failure 25008
FOP_APS Byte failure 25009
FOP_APS Protection switching channel match failure 25010
FOP_APS Automatic protection switch mode mismatch 25011
FOP_APS Far-end protection line failure 25012
UNIDENTIFIED Bipolar violation 25013
UNIDENTIFIED Carrier loss on the LAN 25014
UNIDENTIFIED STS concatenation error 25015
UNIDENTIFIED Excess collisions on the LAN 25016
UNIDENTIFIED Facility failure 25017
UNIDENTIFIED Far-end block error 25018
LOF Loss of frame 25019
LOP Loss of pointer 25020
A-30
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 31
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
LOP Loss of pointer—path 25021
LOS Loss of signal 25022
UNIDENTIFIED Out of frame 25023
UNIDENTIFIED Path selector failure 25024
RAI Remote alarm indication 25025
RAI Remote failure indication 25026
RAI Remote failure indication—line 25027
RAI Remote failure indication—path 25028
BER_SD Signal degrade 25029
UNIDENTIFIED Severely errored frame 25030
UNIDENTIFIED Invalid alarm 25031
BER_SF Signal failure 25032
UNIDENTIFIED Signal label mismatch failures 25033
UNIDENTIFIED Payload defect indication 25034
UNIDENTIFIED Payload defect indication—path 25035
PLM Payload label mismatch—path 25036
UNEQ Unequipped—path 25037
UNIDENTIFIED Loss of synchronization 25038
UNIDENTIFIED Out of synchronization 25039
UNIDENTIFIED Primary synchronization reference failure 25040
UNIDENTIFIED Secondary synchronization reference failure 25041
UNIDENTIFIED Third synchronization reference failure 25042
UNIDENTIFIED Fourth synchronization reference failure 25043
UNIDENTIFIED Fifth synchronization reference failure 25044
UNIDENTIFIED Sixth synchronization reference failure 25045
UNIDENTIFIED Outgoing failure condition 25046
RAI Remote defect indication—line 25047
RAI Remote defect indication—path 25048
UNIDENTIFIED Free running synchronization mode 25049
UNIDENTIFIED Holdover synchronization mode 25050
EQPT Internal fault 25051
UNIDENTIFIED Internal error 25052
UNIDENTIFIED Internal message error 25053
UNIDENTIFIED Mismatch of equipment and attributes 25054
UNIDENTIFIED Watchdog timer timeout 25055
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-31
Page 32
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
ENV Software fault or failure 25056
ENV Software fault—data integrity fault 25057
UNIDENTIFIED Program failure 25058
EQPT Control equipment failure 25059
EQPT Control processor failure 25060
EQPT Working memory failure 25061
EQPT Interconnection equipment failure 25062
EQPT Time slot interchange equipment failure 25063
EQPT Equipment failure 25064
EQPT High temperature 25065
EQPT Facility termination equipment failure 25066
EQPT Automatic laser shutdown 25067
UNIDENTIFIED Failure to release from protection 25068
EQPT Receiver failure 25069
EQPT Transmit failure 25070
UNIDENTIFIED Failure to switch to protection 25071
UNIDENTIFIED Equipment unit plug-in 25072
UNIDENTIFIED Internal power failure 25073
UNIDENTIFIED Fuse alarm 25074
UNIDENTIFIED Synchronization unit failure 25075
UNIDENTIFIED Synchronization switching equipment failure 25076
EQPT Equipment unit unplugged 25077
EQPT Manually caused abnormal condition 25078
UNIDENTIFIED Manual alarm cutoff 25079
UNIDENTIFIED Procedural error 25080
EQPT Improper removal 25081
UNIDENTIFIED Protection unit not available 25082
UNIDENTIFIED Protection switch 25083
UNIDENTIFIED Recovery or service protection action has been initiated 25084
UNIDENTIFIED Automatic system reset 25085
UNIDENTIFIED Cold restart 25086
UNIDENTIFIED Forced switch back to working 25087
UNIDENTIFIED Forced switch to protection 25088
UNIDENTIFIED Initialization initiated 25089
UNIDENTIFIED Lockout of protection 25090
Reported in the Notification)
A-32
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 33
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Lockout of working 25091
UNIDENTIFIED Manual system reset 25092
UNIDENTIFIED Manual switch to internal clock 25093
UNIDENTIFIED Manual switch to primary reference 25094
UNIDENTIFIED Manual switch to secondary reference 25095
UNIDENTIFIED Manual switch to third reference 25096
UNIDENTIFIED Manual switch to fourth reference 25097
UNIDENTIFIED Manual switch to fifth reference 25098
UNIDENTIFIED Manual switch to sixth reference 25099
UNIDENTIFIED Manual switch back to working 25100
UNIDENTIFIED Manual switch to protection 25101
UNIDENTIFIED Power fail restart 25102
UNIDENTIFIED Software download in progress 25103
UNIDENTIFIED Switch to internal clock 25104
UNIDENTIFIED Switch to primary reference 25105
UNIDENTIFIED Switch to secondary reference 25106
UNIDENTIFIED Switch to third reference 25107
UNIDENTIFIED Switch to fourth reference 25108
UNIDENTIFIED Switch to fifth reference 25109
UNIDENTIFIED Switch to sixth reference 25110
UNIDENTIFIED Switched back to working 25111
UNIDENTIFIED Switched to protection 25112
UNIDENTIFIED Warm restart 25113
UNIDENTIFIED Ring is in wait-to-restore state 25114
EQPT Primary nonvolatile backup memory failure 25115
EQPT Secondary nonvolatile backup memory failure 25116
EQPT Control bus failure 25117
EQPT Control communications equipment failure 25118
UNIDENTIFIED Loopback 25119
UNIDENTIFIED Loopback, network 25120
UNIDENTIFIED Loopback, terminal 25121
EQPT Fan failure 25122
DCC_FAILURE SDCC termination failure 25123
UNIDENTIFIED Loopback facility 25124
EQPT Payload bus failure to I/O slot 1 (XCON slot 8) 25125
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-33
Page 34
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
EQPT Payload bus failure to I/O slot 2 (XCON slot 8) 25126
EQPT Payload bus failure to I/O slot 3 (XCON slot 8) 25127
EQPT Payload bus failure to I/O slot 4 (XCON slot 8) 25128
EQPT Payload bus failure to I/O slot 5 (XCON slot 8) 25129
EQPT Payload bus failure to I/O slot 6 (XCON slot 8) 25130
EQPT Payload bus failure to I/O slot 12 (XCON slot 8) 25131
EQPT Payload bus failure to I/O slot 13 (XCON slot 8) 25132
EQPT Payload bus failure to I/O slot 14 (XCON slot 8) 25133
EQPT Payload bus failure to I/O slot 15 (XCON slot 8) 25134
EQPT Payload bus failure to I/O slot 16 (XCON slot 8) 25135
EQPT Payload bus failure to I/O slot 17 (XCON slot 8) 25136
EQPT Payload bus failure to I/O slot 1 (XCON slot 10) 25137
EQPT Payload bus failure to I/O slot 2 (XCON slot 10) 25138
EQPT Payload bus failure to I/O slot 3 (XCON slot 10) 25139
EQPT Payload bus failure to I/O slot 4 (XCON slot 10) 25140
EQPT Payload bus failure to I/O slot 5 (XCON slot 10) 25141
EQPT Payload bus failure to I/O slot 6 (XCON slot 10) 25142
EQPT Payload bus failure to I/O slot 12 (XCON slot 10) 25143
EQPT Payload bus failure to I/O slot 13 (XCON slot 10) 25144
EQPT Payload bus failure to I/O slot 14 (XCON slot 10) 25145
EQPT Payload bus failure to I/O slot 15 (XCON slot 10) 25146
EQPT Payload bus failure to I/O slot 16 (XCON slot 10) 25147
EQPT Payload bus failure to I/O slot 17 (XCON slot 10) 25148
EQPT Control bus 1 failure 25149
EQPT Control bus 2 failure 25150
EQPT Invalid MAC address 25151
EQPT Board failure 25152
EQPT Diagnostics failure 25153
EQPT Medium access control failure 25154
UNIDENTIFIED Duplicate node ID 25155
UNIDENTIFIED Failure to switch to protection—ring 25156
UNIDENTIFIED Failure to switch to protection—span 25157
UNIDENTIFIED Manual switch back to working—ring 25158
UNIDENTIFIED Manual switch back to working—span 25159
UNIDENTIFIED Manual switch to protection—ring 25160
Reported in the Notification)
A-34
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 35
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Manual switch to protection—span 25161
UNIDENTIFIED Forced switch back to working—ring 25162
UNIDENTIFIED Forced switch back to working—span 25163
UNIDENTIFIED Forced switch to protection—ring 25164
UNIDENTIFIED Forced switch to protection—span 25165
UNIDENTIFIED Lockout of protection—ring 25166
UNIDENTIFIED Lockout of protection—span 25167
UNIDENTIFIED Lockout of working—ring 25168
UNIDENTIFIED Lockout of working—span 25169
UNIDENTIFIED Ring is squelching traffic 25170
FOP_APS Inconsistent APS code 25171
FOP_APS Node ID mismatch 25172
FOP_APS Default K byte 25173
FOP_APS Connection loss 25174
EQPT TCC A to shelf slot 1 (DROP 1) communication failure 25175
EQPT TCC A to shelf slot 2 (DROP 2) communication failure 25176
EQPT TCC A to shelf slot 3 (DROP 3) communication failure 25177
EQPT TCC A to shelf slot 4 (DROP 4) communication failure 25178
EQPT TCC A to shelf slot 5 (TRUNK 1) communication failure 25179
EQPT TCC A to shelf slot 6 (TRUNK 2) communication failure 25180
EQPT TCC A to shelf slot 7 (TCC A) communication failure 25181
EQPT TCC A to shelf slot 8 (XCON A) communication failure 25182
EQPT TCC A to shelf slot 9 (AIC) communication failure 25183
EQPT TCC A to shelf slot 10 (XCON B) communication failure 25184
EQPT TCC A to shelf slot 11 (TCC B) communication failure 25185
EQPT TCC A to shelf slot 12 (TRUNK 3) communication failure 25186
EQPT TCC A to shelf slot 13 (TRUNK 4) communication failure 25187
EQPT TCC A to shelf slot 14 (DROP 5) communication failure 25188
EQPT TCC A to shelf slot 15 (DROP 6) communication failure 25189
EQPT TCC A to shelf slot 16 (DROP 7) communication failure 25190
EQPT TCC A to shelf slot 17 (DROP 8) communication failure 25191
EQPT TCC A to DCC A processor communication failure 25192
EQPT TCC B to shelf slot 1 (DROP 1) communication failure 25193
EQPT TCC B to shelf slot 2 (DROP 2) communication failure 25194
EQPT TCC B to shelf slot 3 (DROP 3) communication failure 25195
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-35
Page 36
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
EQPT TCC B to shelf slot 4 (DROP 4) communication failure 25196
EQPT TCC B to shelf slot 5 (TRUNK 1) communication failure 25197
EQPT TCC B to shelf slot 6 (TRUNK 2) communication failure 25198
EQPT TCC B to shelf slot 7 (TCC A) communication failure 25199
EQPT TCC B to shelf slot 8 (XCON A) communication failure 25200
EQPT TCC B to shelf slot 9 (AIC) communication failure 25201
EQPT TCC B to shelf slot 10 (XCON B) communication failure 25202
EQPT TCC B to shelf slot 11 (TCC B) communication failure 25203
EQPT TCC B to shelf slot 12 (TRUNK 3) communication failure 25204
EQPT TCC B to shelf slot 13 (TRUNK 4) communication failure 25205
EQPT TCC B to shelf slot 14 (DROP 5) communication failure 25206
EQPT TCC B to shelf slot 15 (DROP 6) communication failure 25207
EQPT TCC B to shelf slot 16 (DROP 7) communication failure 25208
EQPT TCC B to shelf slot 17 (DROP 8) communication failure 25209
EQPT TCC B to DCC B processor communication failure 25210
UNIDENTIFIED Fast start synchronization mode 25211
FOP_APS Improper APS code 25212
UNIDENTIFIED BLSR out of sync 25213
AIS Alarm indication signal—VT 25214
RAI Remote failure indication—VT 25215
PLM Signal label mismatch failure—payload label mismatch—VT 25216
UNEQ Signal label mismatch failure—unequipped—VT 25217
UNIDENTIFIED Peer state mismatch 25218
EQPT Facility termination equipment—receiver missing 25219
EQPT Facility termination equipment—transmitter missing 25220
LOP Loss of pointer—VT 25221
UNIDENTIFIED Embedded operations channel failure—link down 25222
UNIDENTIFIED Failed to receive synchronization status message 25223
UNIDENTIFIED Synchronization status messages are disabled on this interface 25224
UNIDENTIFIED Primary reference source—stratum 1 traceable 25225
UNIDENTIFIED Synchronized—traceability unknown 25226
UNIDENTIFIED Stratum 2 traceable 25227
UNIDENTIFIED Transit node clock traceable 25228
UNIDENTIFIED Stratum 3E traceable 25229
UNIDENTIFIED Stratum 3 traceable 25230
Reported in the Notification)
A-36
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 37
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED SONET minimum clock traceable 25231
UNIDENTIFIED Stratum 4 traceable 25232
UNIDENTIFIED Do not use for synchronization 25233
UNIDENTIFIED Reserved for network synchronization use 25234
UNIDENTIFIED Failure to switch to protection—path 25235
UNIDENTIFIED Manual switch of working facility—equipment to
protection—path
UNIDENTIFIED Working facility—equipment forced to switch to
protection—path
UNIDENTIFIED Lockout of protection—path 25238
UNIDENTIFIED Automatic path-protection switch caused by AIS 25239
UNIDENTIFIED Automatic path-protection switch caused by LOP 25240
UNIDENTIFIED Automatic path-protection switch caused by UNEQ 25241
UNIDENTIFIED Automatic path-protection switch caused by PDI 25242
UNIDENTIFIED Automatic path-protection switch caused by SFBER 25243
UNIDENTIFIED Automatic path-protection switch caused by SDBER 25244
UNIDENTIFIED DS3 idle condition 25245
UNIDENTIFIED DS1 loopback due to FEAC command 25246
UNIDENTIFIED DS1 loopback command sent to far end 25247
UNIDENTIFIED DS3 loopback due to FEAC command 25248
UNIDENTIFIED DS3 loopback command sent to far end 25249
UNIDENTIFIED DS2 loopback due to far-end command 25250
UNIDENTIFIED DS2 loopback command sent to far end 25251
ENV Far-end AIS 25252
UNIDENTIFIED Far-end multiple DS1 LOS detected on DS3 25253
ENV Far-end DS1 equipment failure—non-service affecting 25254
ENV Far-end DS1 equipment failure—service affecting 25255
ENV Far-end single DS1 LOS 25256
ENV Far-end DS3 equipment failure—non-service affecting 25257
ENV Far-end DS3 equipment failure—service affecting 25258
ENV Far-end common equipment failure—non-service affecting 25259
UNIDENTIFIED Far end idle 25260
ENV Far end LOS 25261
ENV Far end LOF 25262
UNIDENTIFIED Performance monitor threshold crossing alert 25263
UNIDENTIFIED Ethernet bridge is new root of spanning tree 25264
Reported in the Notification)
25236
25237
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-37
Page 38
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Ethernet bridge topology change 25265
UNIDENTIFIED BLSR tables resynchronized 25266
ENV System reboot 25267
UNIDENTIFIED Manual switch request on facility—equipment 25268
UNIDENTIFIED Forced switch request on facility or equipment 25269
UNIDENTIFIED Lockout switch request on facility—equipment 25270
UNIDENTIFIED RMON histories and alarms reset reboot 25271
UNIDENTIFIED RMON alarm 25272
LOS Video interface card loss of video IF signal 25273
LOS VIC loss of video baseband signal 25274
LOS VIC loss of audio FM signal 25275
LOS VIC loss of audio baseband channel 1 signal 25276
LOS VIC loss of audio baseband channel 2 signal 25277
LOS VIC loss of audio baseband channel 3 signal 25278
LOS VIC loss of audio baseband channel 4 signal 25279
TIM STS path trace identifier mismatch 25280
ENV NE power failure at connector A 25281
ENV NE power failure at connector B 25282
UNIDENTIFIED Free memory on card very low 25283
UNIDENTIFIED Free memory on card near zero 25284
UNIDENTIFIED Exercise request on ring 25285
UNIDENTIFIED Exercise request on span 25286
UNIDENTIFIED Squelching path 25287
UNIDENTIFIED Extra traffic preempted 25288
UNIDENTIFIED Far-end lockout of working—ring 25289
UNIDENTIFIED Far-end lockout of working—span 25290
UNIDENTIFIED Far-end lockout of protection—ring 25291
UNIDENTIFIED Far-end lockout of protection—all spans 25292
UNIDENTIFIED Far-end working facility forced to switch to protection—ring 25293
UNIDENTIFIED Far-end working facility forced to switch to protection—span 25294
UNIDENTIFIED Far-end manual switch of working facility to protection—ring 25295
UNIDENTIFIED Far-end manual switch of working facility to protection—span 25296
UNIDENTIFIED Far-end exercising ring 25297
UNIDENTIFIED Far-end exercising span 25298
ENV Far-end BER threshold passed for signal failure—ring 25299
Reported in the Notification)
A-38
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 39
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
ENV Far-end BER threshold passed for signal failure—span 25300
ENV Far-end BER threshold passed for signal degrade—ring 25301
ENV Far-end BER threshold passed for signal degrade—span 25302
ENV APS channel—far-end protection line signal degrade 25303
UNIDENTIFIED Ring switch is active on the east side 25304
UNIDENTIFIED Ring switch is active on the west side 25305
UNIDENTIFIED Span switch is active on the east side 25306
UNIDENTIFIED Span switch is active on the west side 25307
UNIDENTIFIED Unidirectional full pass-through is active 25308
UNIDENTIFIED Bidirectional full pass-through is active 25309
UNIDENTIFIED K bytes pass-through is active 25310
UNIDENTIFIED Ring is segmented 25311
UNIDENTIFIED Ring topology is under construction 25312
UNIDENTIFIED Lockout of protection—all spans 25313
UNIDENTIFIED Far-end of fiber is provisioned with different ring ID 25314
UNIDENTIFIED Both ends of fiber provisioned as east or both as west 25315
SECURITY_VIOLATION Security—invalid login—see audit trail 25316
UNIDENTIFIED Autonomous messages inhibited 25317
UNIDENTIFIED Traffic storm on LAN; LAN temporarily disabled 25318
UNIDENTIFIED REPT^DBCHG messages inhibited 25319
SECURITY_VIOLATION Security—user ID has expired 25320
EQPT Partial fan failure 25321
UNIDENTIFIED Force switch request on ring 25322
UNIDENTIFIED Force switch request on span 25323
UNIDENTIFIED Lockout switch request on ring 25324
UNIDENTIFIED Lockout switch request on span 25325
UNIDENTIFIED Manual switch request on ring 25326
UNIDENTIFIED Manual switch request on span 25327
EQPT Peer-to-peer slot communication failure 25328
EQPT Peer-to-peer slot communication failure 25329
EQPT TCC A to shelf slot communication failure 25330
EQPT TCC B to shelf slot communication failure 25331
EQPT Interconnection equipment failure—working XC payload bus 25332
EQPT Interconnection equipment failure—protect XC payload bus 25333
EQPT Inhibit switch to protect request on equipment 25334
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-39
Page 40
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
EQPT Inhibit switch to working request on equipment 25335
BER_SD BER threshold exceeded for signal degrade—line 25336
BER_SD BER threshold exceeded for signal degrade—path 25337
BER_SF BER threshold exceeded for signal failure—line 25338
BER_SF BER threshold exceeded for signal failure—path 25339
UNIDENTIFIED Exercising ring successfully 25340
UNIDENTIFIED Exercising span successfully 25341
UNIDENTIFIED Span is in wait-to-restore state 25342
EQPT Peer card not responding 25343
UNIDENTIFIED Exercise request on ring failed 25344
UNIDENTIFIED Exercise request on span failed 25345
UNIDENTIFIED Far-end lockout of protection—span 25346
EQPT Manufacturing data memory (EEPROM) failure 25347
EQPT Replaceable equipment/unit is missing 25348
ENV Software download failure 25349
TIM TIM section—trace identifier mismatch failure 25350
AIS AIS—multiplex section—alarm indication signal 25351
RAI RFI—multiplex section—remote failure/alarm indication 25352
TIM TIM—high order—trace identifier mismatch failure 25353
AU_AIS AIS—administration unit—alarm indication signal 25354
LOP LOP—administration unit—loss of pointer 25355
UNEQ SLMF—unequipped high order—path unequipped 25356
PLM SLMF—PLM high order—path label mismatch 25357
RAI RFI—high order—remote failure/alarm indication 25358
LOP LOP—tributary unit—loss of pointer 25359
TU-AIS AIS—tributary unit—alarm indication signal 25360
UNEQ SLMF—unequipped low order—path unequipped 25361
PLM SLMF—PLM low order—path label mismatch 25362
TIM TIM low order—trace identifier mismatch failure 25363
RAI RFI—low order—remote failure/alarm indication 25364
UNIDENTIFIED G811—primary reference clock traceable 25365
UNIDENTIFIED G812—transit node clock traceable 25366
UNIDENTIFIED G812—local node clock traceable 25367
UNIDENTIFIED G813—synchronous equipment timing source traceable 25368
UNIDENTIFIED E1 loopback due to FEAC command 25369
Reported in the Notification)
A-40
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 41
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED E1 loopback command sent to far end 25370
UNIDENTIFIED E3 loopback due to FEAC command 25371
ENV Far-end multiple E1 LOS detected on E3 25372
ENV Far-end E1 equipment failure non-service affecting 25373
ENV Far-end E1 equipment failure service affecting 25374
ENV Far-end single E1 LOS 25375
ENV Far-end E3 equipment failure service affecting 25376
UNIDENTIFIED E3 loopback command sent to far end 25377
ENV Far-end E3 equipment failure non-service affecting 25378
ENV Low voltage—battery A 25379
ENV High voltage—battery A 25380
ENV Low voltage—battery B 25381
ENV High voltage—battery B 25382
UNIDENTIFIED Procedural error—MS-SPRing out of sync 25383
UNIDENTIFIED MS-SPRing tables resynchronized 25384
UNIDENTIFIED Automatic SNCP switch caused by AIS 25385
UNIDENTIFIED Automatic SNCP switch caused by LOP 25386
UNIDENTIFIED Automatic SNCP switch caused by UNEQ 25387
UNIDENTIFIED Automatic SNCP switch caused by PDI 25388
UNIDENTIFIED Automatic SNCP switch caused by SFBER 25389
UNIDENTIFIED Automatic SNCP switch caused by SDBER 25390
UNIDENTIFIED STM concatenation error 25391
UNIDENTIFIED E3 idle condition 25392
UNIDENTIFIED IOS config copy failed 25393
UNIDENTIFIED IOS config copy in progress 25394
UNIDENTIFIED Alarms suppressed by user command 25399
UNIDENTIFIED Alarms suppressed for maintenance 25400
UNIDENTIFIED N/A 25401
UNIDENTIFIED Synchronization reference frequency out of bounds 25402
UNIDENTIFIED Ether Tx excess flow control 25403
UNIDENTIFIED Ether Tx oversubscribed 25404
UNIDENTIFIED Transport layer failure 25405
UNIDENTIFIED Ether Rx excess flow control 25406
UNIDENTIFIED Ether Rx oversubscribed 25407
UNIDENTIFIED Ether Tx underrun 25408
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-41
Page 42
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED SNTP host failure 25409
UNIDENTIFIED DS3 frame format mismatch 25410
UNIDENTIFIED Alarms/events suppressed for this object 25411
BER_SD BER threshold exceeded for signal degrade—high order 25412
BER_SF BER threshold exceeded for signal failure—high order 25413
BER_SD BER threshold exceeded for signal degrade—low order 25414
BER_SF BER threshold exceeded for signal failure—low order 25415
UNIDENTIFIED Failure to switch to protection—high order path 25416
UNIDENTIFIED Failure to switch to protection—low order path 25417
UNIDENTIFIED Wait to restore 25418
ENV Extreme high voltage—battery A 25419
ENV Extreme low voltage—battery A 25420
ENV Extreme high voltage—battery B 25421
ENV Extreme low voltage—battery B 25422
UNIDENTIFIED Switching matrix module failure 25423
UNIDENTIFIED Signaling unable to set up circuit 25424
UNIDENTIFIED RSVP hello FSM to neighbor down 25425
UNIDENTIFIED LMP hello FSM to control channel down 25426
UNIDENTIFIED LMP neighbor discovery has failed 25427
UNIDENTIFIED Unauthorized incoming signaling request 25428
UNIDENTIFIED Signaled circuit going down 25429
UNIDENTIFIED Autonomous PM report message inhibited 25430
EQPT I/O slot to XCON communication failure 25431
UNIDENTIFIED Forced switch to primary reference 25432
UNIDENTIFIED Forced switch to secondary reference 25433
UNIDENTIFIED Forced switch to third reference 25434
UNIDENTIFIED Forced switch to internal clock 25435
LOM LOF—administration unit—loss of multiframe 25436
UNIDENTIFIED Admin logout of user 25438
UNIDENTIFIED User locked out 25439
UNIDENTIFIED Admin lockout of user 25440
UNIDENTIFIED Admin lockout clear 25441
SECURITY_VIOLATION Security—invalid login—username—see audit log 25442
SECURITY_VIOLATION Security—invalid login—password—see audit log 25443
SECURITY_VIOLATION Security—invalid login—locked out—see audit log 25444
Reported in the Notification)
A-42
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 43
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
SECURITY_VIOLATION Security—invalid login—already logged on—see audit log 25445
UNIDENTIFIED Login of user 25446
UNIDENTIFIED Automatic logout of idle user 25447
UNIDENTIFIED Logout of user 25448
UNIDENTIFIED Cross-connect loopback 25451
UNIDENTIFIED Error in startup config 25454
UNIDENTIFIED No startup config 25455
EQPT Laser approaching end of life 25456
UNIDENTIFIED Database backup failed 25457
UNIDENTIFIED Database restore failed 25458
UNIDENTIFIED 8B10B out of sync 25459
AIS ODUk—alarm indication signal 25460
AIS OTUk—alarm indication signal 25461
UNIDENTIFIED OTUk—backward defect indicator 25462
UNIDENTIFIED ODUk—backward defect indicator 25463
UNIDENTIFIED FEC uncorrected word 25464
UNIDENTIFIED GCC embedded operation channel failure 25465
UNIDENTIFIED OTUk—incoming alignment error 25466
UNIDENTIFIED ODUk—locked defect—PM 25467
LOM Loss of multiframe 25468
UNIDENTIFIED ODUk—open connection indication 25469
PLM Payload type identifier mismatch 25470
TIM ODUk—trail trace identifier mismatch 25471
TIM OTUk—trail trace identifier mismatch 25472
EQPT Equipment high laser bias 25473
EQPT Equipment high laser temp 25474
EQPT Equipment high laser Peltier 25475
EQPT Equipment high Rx power 25476
EQPT Equipment high Tx power 25477
EQPT Equipment high Rx temperature 25478
EQPT Equipment low Tx temperature 25479
EQPT Equipment high transceiver voltage 25480
EQPT Equipment low laser bias 25481
EQPT Equipment low laser temp 25482
EQPT Equipment low laser Peltier 25483
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-43
Page 44
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
EQPT Equipment low Rx power 25484
EQPT Equipment low Tx power 25485
EQPT Equipment low transceiver voltage 25486
EQPT Equipment Rx locked 25487
EQPT Equipment squelched 25488
EQPT Equipment Tx locked 25489
BER_SF OTUk—signal failure 25490
BER_SF ODUk—signal failure 25491
BER_SD OTUk—signal degrade 25492
BER_SD ODUk—signal degrade 25493
UNIDENTIFIED Pluggable port missing 25494
UNIDENTIFIED Pluggable port rate mismatch 25495
SECURITY_VIOLATION Pluggable port security code mismatch 25496
UNIDENTIFIED TCI not selected 25497
UNIDENTIFIED TCI 1 clock failure 25498
UNIDENTIFIED ODUk—backward defect indicator 25499
UNIDENTIFIED ODUk—backward defect indicator 25500
UNIDENTIFIED ODUk—backward defect indicator 25501
UNIDENTIFIED ODUk—open connection indication 25504
UNIDENTIFIED ODUk—locked defect—TCM2 25505
AIS ODUk—alarm indication signal 25506
TIM ODUk—trail trace identifier mismatch 25507
BER_SD ODUk—signal degrade—TCM2 25508
BER_SF ODUk—signal failure—TCM2 25509
UNIDENTIFIED ODUk—open connection indication 25510
UNIDENTIFIED ODUk—locked defect—TCM1 25511
AIS ODUk—alarm indication signal 25512
TIM ODUk—trail trace identifier mismatch 25513
BER_SD ODUk—signal degrade—TCM1 25514
BER_SF ODUk—signal failure—TCM1 25515
LOF OTUk—loss of frame 25516
UNIDENTIFIED TCI 2 clock failure 25517
UNIDENTIFIED Audit log 80 percent full 25518
UNIDENTIFIED Module communication failure 25519
UNIDENTIFIED Need to save running config 25520
Reported in the Notification)
A-44
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 45
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-22 CTM GateWay/CORBA Mapping for the ONS 15327 and ONS 15454 SONET R4.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Audit log 100 percent full; oldest records will be lost 25521
UNIDENTIFIED Standby database out of sync 25522
EQPT Redundant power capability lost 25523
EQPT Equipment wavelength mismatch 25524
UNIDENTIFIED DSP communication failure 25525
UNIDENTIFIED DSP failure 25526
UNIDENTIFIED Loss of channel 25527
UNIDENTIFIED FEC mismatch 25528
UNIDENTIFIED LAN connection polarity reversed 25529
UNIDENTIFIED Enhanced remote failure indication—path—server 25530
UNIDENTIFIED Enhanced remote failure indication—path—connectivity 25531
UNIDENTIFIED Enhanced remote failure indication—path—payload 25532
SECURITY_VIOLATION Security violation detected 25533
UNIDENTIFIED Syslog messages 28000
UNIDENTIFIED Configuration events 28001
UNIDENTIFIED Link up/link down trap 28002
UNIDENTIFIED Cold/warm start trap 28003
SECURITY_VIOLATION Authentication failure notification 28004
Reported in the Notification)
A.5.7 CTM GateWay/CORBA Mapping—ONS 15310 CL, ONS 15327, ONS 15454
SONET, and ONS 15454 SDH R5.0
The following table lists the CTM GateWay/CORBA mapping for the ONS 15310 CL, ONS 15327,
ONS 15454 SONET, and ONS 15454 SDH R5.0.
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Normal condition 25000
ENV Failure detected external to the NE 25001
ENV External error 25002
UNIDENTIFIED Excessive switching 25003
UNIDENTIFIED Incoming failure condition 25004
AIS Alarm indication signal 25005
AIS Alarm indication signal—line 25006
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-45
Page 46
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
AIS Alarm indication signal—path 25007
FOP_APS APS channel failure 25008
FOP_APS Byte failure 25009
FOP_APS Protection switching channel match failure 25010
FOP_APS Automatic protection switch mode mismatch 25011
FOP_APS Far-end protection line failure 25012
UNIDENTIFIED Bipolar violation 25013
UNIDENTIFIED Carrier loss on the LAN 25014
UNIDENTIFIED STS concatenation error 25015
UNIDENTIFIED Excess collisions on the LAN 25016
UNIDENTIFIED Facility failure 25017
UNIDENTIFIED Far-end block error 25018
LOF Loss of frame 25019
LOP Loss of pointer 25020
LOP Loss of pointer—path 25021
LOS Loss of signal 25022
UNIDENTIFIED Out of frame 25023
UNIDENTIFIED Path selector failure 25024
RAI Remote alarm indication 25025
RAI Remote failure indication 25026
RAI Remote failure indication—line 25027
RAI Remote failure indication—path 25028
BER_SD Signal degrade 25029
UNIDENTIFIED Severely errored frame 25030
UNIDENTIFIED Invalid alarm 25031
BER_SF Signal failure 25032
UNIDENTIFIED Signal label mismatch failures 25033
UNIDENTIFIED Payload defect indication 25034
UNIDENTIFIED Payload defect indication—path 25035
PLM Payload label mismatch—path 25036
UNEQ Unequipped—path 25037
UNIDENTIFIED Loss of synchronization 25038
UNIDENTIFIED Out of synchronization 25039
UNIDENTIFIED Primary synchronization reference failure 25040
UNIDENTIFIED Secondary synchronization reference failure 25041
Reported in the Notification)
A-46
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 47
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Third synchronization reference failure 25042
UNIDENTIFIED Fourth synchronization reference failure 25043
UNIDENTIFIED Fifth synchronization reference failure 25044
UNIDENTIFIED Sixth synchronization reference failure 25045
UNIDENTIFIED Outgoing failure condition 25046
RAI Remote defect indication—line 25047
RAI Remote defect indication—path 25048
UNIDENTIFIED Free running synchronization mode 25049
UNIDENTIFIED Holdover synchronization mode 25050
EQPT Internal fault 25051
UNIDENTIFIED Internal error 25052
UNIDENTIFIED Internal message error 25053
UNIDENTIFIED Mismatch of equipment and attributes 25054
UNIDENTIFIED Watchdog timer timeout 25055
ENV Software fault or failure 25056
ENV Software fault—data integrity fault 25057
UNIDENTIFIED Program failure 25058
EQPT Control equipment failure 25059
EQPT Control processor failure 25060
EQPT Working memory failure 25061
EQPT Interconnection equipment failure 25062
EQPT Time slot interchange equipment failure 25063
EQPT Equipment failure 25064
EQPT High temperature 25065
EQPT Facility termination equipment failure 25066
EQPT Automatic laser shutdown 25067
UNIDENTIFIED Failure to release from protection 25068
EQPT Receiver failure 25069
EQPT Transmit failure 25070
UNIDENTIFIED Failure to switch to protection 25071
UNIDENTIFIED Equipment unit plug-in 25072
UNIDENTIFIED Internal power failure 25073
UNIDENTIFIED Fuse alarm 25074
UNIDENTIFIED Synchronization unit failure 25075
UNIDENTIFIED Synchronization switching equipment failure 25076
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-47
Page 48
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
EQPT Equipment unit unplugged 25077
EQPT Manually caused abnormal condition 25078
UNIDENTIFIED Manual alarm cutoff 25079
UNIDENTIFIED Procedural error 25080
EQPT Improper removal 25081
UNIDENTIFIED Protection unit not available 25082
UNIDENTIFIED Protection switch 25083
UNIDENTIFIED Recovery or service protection action has been initiated 25084
UNIDENTIFIED Automatic system reset 25085
UNIDENTIFIED Cold restart 25086
UNIDENTIFIED Forced switch back to working 25087
UNIDENTIFIED Forced switch to protection 25088
UNIDENTIFIED Initialization initiated 25089
UNIDENTIFIED Lockout of protection 25090
UNIDENTIFIED Lockout of working 25091
UNIDENTIFIED Manual system reset 25092
UNIDENTIFIED Manual switch to internal clock 25093
UNIDENTIFIED Manual switch to primary reference 25094
UNIDENTIFIED Manual switch to secondary reference 25095
UNIDENTIFIED Manual switch to third reference 25096
UNIDENTIFIED Manual switch to fourth reference 25097
UNIDENTIFIED Manual switch to fifth reference 25098
UNIDENTIFIED Manual switch to sixth reference 25099
UNIDENTIFIED Manual switch back to working 25100
UNIDENTIFIED Manual switch to protection 25101
UNIDENTIFIED Powerfail restart 25102
UNIDENTIFIED Software download in progress 25103
UNIDENTIFIED Switch to internal clock 25104
UNIDENTIFIED Switch to primary reference 25105
UNIDENTIFIED Switch to secondary reference 25106
UNIDENTIFIED Switch to third reference 25107
UNIDENTIFIED Switch to fourth reference 25108
UNIDENTIFIED Switch to fifth reference 25109
UNIDENTIFIED Switch to sixth reference 25110
UNIDENTIFIED Switched back to working 25111
Reported in the Notification)
A-48
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 49
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Switched to protection 25112
UNIDENTIFIED Warm restart 25113
UNIDENTIFIED Ring is in wait-to-restore state 25114
EQPT Primary nonvolatile backup memory failure 25115
EQPT Secondary nonvolatile backup memory failure 25116
EQPT Control bus failure 25117
EQPT Control communications equipment failure 25118
UNIDENTIFIED Loopback 25119
UNIDENTIFIED Loopback, network 25120
UNIDENTIFIED Loopback, terminal 25121
EQPT Fan failure 25122
DCC_FAILURE SDCC termination failure 25123
UNIDENTIFIED Loopback facility 25124
EQPT Payload bus failure to I/O slot 1 (XCON slot 8) 25125
EQPT Payload bus failure to I/O slot 2 (XCON slot 8) 25126
EQPT Payload bus failure to I/O slot 3 (XCON slot 8) 25127
EQPT Payload bus failure to I/O slot 4 (XCON slot 8) 25128
EQPT Payload bus failure to I/O slot 5 (XCON slot 8) 25129
EQPT Payload bus failure to I/O slot 6 (XCON slot 8) 25130
EQPT Payload bus failure to I/O slot 12 (XCON slot 8) 25131
EQPT Payload bus failure to I/O slot 13 (XCON slot 8) 25132
EQPT Payload bus failure to I/O slot 14 (XCON slot 8) 25133
EQPT Payload bus failure to I/O slot 15 (XCON slot 8) 25134
EQPT Payload bus failure to I/O slot 16 (XCON slot 8) 25135
EQPT Payload bus failure to I/O slot 17 (XCON slot 8) 25136
EQPT Payload bus failure to I/O slot 1 (XCON slot 10) 25137
EQPT Payload bus failure to I/O slot 2 (XCON slot 10) 25138
EQPT Payload bus failure to I/O slot 3 (XCON slot 10) 25139
EQPT Payload bus failure to I/O slot 4 (XCON slot 10) 25140
EQPT Payload bus failure to I/O slot 5 (XCON slot 10) 25141
EQPT Payload bus failure to I/O slot 6 (XCON slot 10) 25142
EQPT Payload bus failure to I/O slot 12 (XCON slot 10) 25143
EQPT Payload bus failure to I/O slot 13 (XCON slot 10) 25144
EQPT Payload bus failure to I/O slot 14 (XCON slot 10) 25145
EQPT Payload bus failure to I/O slot 15 (XCON slot 10) 25146
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-49
Page 50
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
EQPT Payload bus failure to I/O slot 16 (XCON slot 10) 25147
EQPT Payload bus failure to I/O slot 17 (XCON slot 10) 25148
EQPT Control bus 1 failure 25149
EQPT Control bus 2 failure 25150
EQPT Invalid MAC address 25151
EQPT Board failure 25152
EQPT Diagnostics failure 25153
EQPT Medium access control failure 25154
UNIDENTIFIED Duplicate node ID 25155
UNIDENTIFIED Failure to switch to protection—ring 25156
UNIDENTIFIED Failure to switch to protection—span 25157
UNIDENTIFIED Manual switch back to working—ring 25158
UNIDENTIFIED Manual switch back to working—span 25159
UNIDENTIFIED Manual switch to protection—ring 25160
UNIDENTIFIED Manual switch to protection—span 25161
UNIDENTIFIED Forced switch back to working—ring 25162
UNIDENTIFIED Forced switch back to working—span 25163
UNIDENTIFIED Forced switch to protection—ring 25164
UNIDENTIFIED Forced switch to protection—span 25165
UNIDENTIFIED Lockout of protection—ring 25166
UNIDENTIFIED Lockout of protection—span 25167
UNIDENTIFIED Lockout of working—ring 25168
UNIDENTIFIED Lockout of working—span 25169
UNIDENTIFIED Ring is squelching traffic 25170
FOP_APS Inconsistent APS code 25171
FOP_APS Node ID mismatch 25172
FOP_APS Default K byte 25173
FOP_APS Connection loss 25174
EQPT TCC A to shelf slot 1 (DROP 1) communication failure 25175
EQPT TCC A to shelf slot 2 (DROP 2) communication failure 25176
EQPT TCC A to shelf slot 3 (DROP 3) communication failure 25177
EQPT TCC A to shelf slot 4 (DROP 4) communication failure 25178
EQPT TCC A to shelf slot 5 (TRUNK 1) communication failure 25179
EQPT TCC A to shelf slot 6 (TRUNK 2) communication failure 25180
EQPT TCC A to shelf slot 7 (TCC A) communication failure 25181
Reported in the Notification)
A-50
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 51
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
EQPT TCC A to shelf slot 8 (XCON A) communication failure 25182
EQPT TCC A to shelf slot 9 (AIC) communication failure 25183
EQPT TCC A to shelf slot 10 (XCON B) communication failure 25184
EQPT TCC A to shelf slot 11 (TCC B) communication failure 25185
EQPT TCC A to shelf slot 12 (TRUNK 3) communication failure 25186
EQPT TCC A to shelf slot 13 (TRUNK 4) communication failure 25187
EQPT TCC A to shelf slot 14 (DROP 5) communication failure 25188
EQPT TCC A to shelf slot 15 (DROP 6) communication failure 25189
EQPT TCC A to shelf slot 16 (DROP 7) communication failure 25190
EQPT TCC A to shelf slot 17 (DROP 8) communication failure 25191
EQPT TCC A to DCC A processor communication failure 25192
EQPT TCC B to shelf slot 1 (DROP 1) communication failure 25193
EQPT TCC B to shelf slot 2 (DROP 2) communication failure 25194
EQPT TCC B to shelf slot 3 (DROP 3) communication failure 25195
EQPT TCC B to shelf slot 4 (DROP 4) communication failure 25196
EQPT TCC B to shelf slot 5 (TRUNK 1) communication failure 25197
EQPT TCC B to shelf slot 6 (TRUNK 2) communication failure 25198
EQPT TCC B to shelf slot 7 (TCC A) communication failure 25199
EQPT TCC B to shelf slot 8 (XCON A) communication failure 25200
EQPT TCC B to shelf slot 9 (AIC) communication failure 25201
EQPT TCC B to shelf slot 10 (XCON B) communication failure 25202
EQPT TCC B to shelf slot 11 (TCC B) communication failure 25203
EQPT TCC B to shelf slot 12 (TRUNK 3) communication failure 25204
EQPT TCC B to shelf slot 13 (TRUNK 4) communication failure 25205
EQPT TCC B to shelf slot 14 (DROP 5) communication failure 25206
EQPT TCC B to shelf slot 15 (DROP 6) communication failure 25207
EQPT TCC B to shelf slot 16 (DROP 7) communication failure 25208
EQPT TCC B to shelf slot 17 (DROP 8) communication failure 25209
EQPT TCC B to DCC B processor communication failure 25210
UNIDENTIFIED Fast start synchronization mode 25211
FOP_APS Improper APS code 25212
UNIDENTIFIED BLSR out of sync 25213
AIS Alarm indication signal—VT 25214
RAI Remote failure indication—VT 25215
PLM Signal label mismatch failure—payload label mismatch—VT 25216
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-51
Page 52
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNEQ Signal label mismatch failure—unequipped—VT 25217
UNIDENTIFIED Peer state mismatch 25218
EQPT Facility termination equipment—receiver missing 25219
EQPT Facility termination equipment—transmitter missing 25220
LOP Loss of pointer—VT 25221
UNIDENTIFIED Embedded operations channel failure—link down 25222
UNIDENTIFIED Failed to receive synchronization status message 25223
UNIDENTIFIED Synchronization status messages are disabled on this interface 25224
UNIDENTIFIED Primary reference source—stratum 1 traceable 25225
UNIDENTIFIED Synchronized—traceability unknown 25226
UNIDENTIFIED Stratum 2 traceable 25227
UNIDENTIFIED Transit node clock traceable 25228
UNIDENTIFIED Stratum 3E traceable 25229
UNIDENTIFIED Stratum 3 traceable 25230
UNIDENTIFIED SONET minimum clock traceable 25231
UNIDENTIFIED Stratum 4 traceable 25232
UNIDENTIFIED Do not use for synchronization 25233
UNIDENTIFIED Reserved for network synchronization use 25234
UNIDENTIFIED Failure to switch to protection—path 25235
UNIDENTIFIED Manual switch of working facility—equipment to
protection—path
UNIDENTIFIED Working facility—equipment forced to switch to protection—path 25237
UNIDENTIFIED Lockout of protection—path 25238
UNIDENTIFIED Automatic path-protection switch caused by AIS 25239
UNIDENTIFIED Automatic path-protection switch caused by LOP 25240
UNIDENTIFIED Automatic path-protection switch caused by UNEQ 25241
UNIDENTIFIED Automatic path-protection switch caused by PDI 25242
UNIDENTIFIED Automatic path-protection switch caused by SFBER 25243
UNIDENTIFIED Automatic path-protection switch caused by SDBER 25244
UNIDENTIFIED DS3 idle condition 25245
UNIDENTIFIED DS1 loopback due to FEAC command 25246
UNIDENTIFIED DS1 loopback command sent to far end 25247
UNIDENTIFIED DS3 loopback due to FEAC command 25248
UNIDENTIFIED DS3 loopback command sent to far end 25249
UNIDENTIFIED DS2 loopback due to far-end command 25250
Reported in the Notification)
25236
A-52
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 53
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED DS2 loopback command sent to far end 25251
ENV Far-end AIS 25252
UNIDENTIFIED Far-end multiple DS1 LOS detected on DS3 25253
ENV Far-end DS1 equipment failure—non-service affecting 25254
ENV Far-end DS1 equipment failure—service affecting 25255
ENV Far-end single DS1 LOS 25256
ENV Far-end DS3 equipment failure—non-service affecting 25257
ENV Far-end DS3 equipment failure—service affecting 25258
ENV Far-end common equipment failure—non-service affecting 25259
UNIDENTIFIED Far-end IDLE 25260
ENV Far-end LOS 25261
ENV Far-end LOF 25262
UNIDENTIFIED Performance monitor threshold crossing alert 25263
UNIDENTIFIED Ethernet bridge is new root of spanning tree 25264
UNIDENTIFIED Ethernet bridge topology change 25265
UNIDENTIFIED BLSR tables resynchronized 25266
ENV System reboot 25267
UNIDENTIFIED Manual switch request on facility—equipment 25268
UNIDENTIFIED Forced switch request on facility or equipment 25269
UNIDENTIFIED Lockout switch request on facility—equipment 25270
UNIDENTIFIED RMON histories and alarms reset reboot 25271
UNIDENTIFIED RMON alarm 25272
LOS Video interface card loss of video IF signal 25273
LOS VIC loss of video baseband signal 25274
LOS VIC loss of audio FM signal 25275
LOS VIC loss of audio baseband channel 1 signal 25276
LOS VIC loss of audio baseband channel 2 signal 25277
LOS VIC loss of audio baseband channel 3 signal 25278
LOS VIC loss of audio baseband channel 4 signal 25279
TIM STS path trace identifier mismatch 25280
ENV NE power failure at connector A 25281
ENV NE power failure at connector B 25282
UNIDENTIFIED Free memory on card very low 25283
UNIDENTIFIED Free memory on card near zero 25284
UNIDENTIFIED Exercise request on ring 25285
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-53
Page 54
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Exercise request on span 25286
UNIDENTIFIED Squelching path 25287
UNIDENTIFIED Extra traffic preempted 25288
UNIDENTIFIED Far-end lockout of working—ring 25289
UNIDENTIFIED Far-end lockout of working—span 25290
UNIDENTIFIED Far-end lockout of protection—ring 25291
UNIDENTIFIED Far-end lockout of protection—all spans 25292
UNIDENTIFIED Far-end working facility forced to switch to protection—ring 25293
UNIDENTIFIED Far-end working facility forced to switch to protection—span 25294
UNIDENTIFIED Far-end manual switch of working facility to protection—ring 25295
UNIDENTIFIED Far-end manual switch of working facility to protection—span 25296
UNIDENTIFIED Far-end exercising ring 25297
UNIDENTIFIED Far-end exercising span 25298
ENV Far-end BER threshold passed for signal failure—ring 25299
ENV Far-end BER threshold passed for signal failure—span 25300
ENV Far-end BER threshold passed for signal degrade—ring 25301
ENV Far-end BER threshold passed for signal degrade—span 25302
ENV APS channel—far-end protection line signal degrade 25303
UNIDENTIFIED Ring switch is active on the east side 25304
UNIDENTIFIED Ring switch is active on the west side 25305
UNIDENTIFIED Span switch is active on the east side 25306
UNIDENTIFIED Span switch is active on the west side 25307
UNIDENTIFIED Unidirectional full pass-through is active 25308
UNIDENTIFIED Bidirectional full pass-through is active 25309
UNIDENTIFIED K bytes pass-through is active 25310
UNIDENTIFIED Ring is segmented 25311
UNIDENTIFIED Ring topology is under construction 25312
UNIDENTIFIED Lockout of protection—all spans 25313
UNIDENTIFIED Far end of fiber is provisioned with different ring ID 25314
UNIDENTIFIED Both ends of fiber provisioned as east or both as west 25315
SECURITY_VIOLATION Security—invalid login—see audit trail 25316
UNIDENTIFIED Autonomous messages inhibited 25317
UNIDENTIFIED Traffic storm on LAN; LAN temporarily disabled 25318
UNIDENTIFIED REPT^DBCHG messages inhibited 25319
SECURITY_VIOLATION Security—user ID has expired 25320
Reported in the Notification)
A-54
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 55
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
EQPT Partial fan failure 25321
UNIDENTIFIED Force switch request on ring 25322
UNIDENTIFIED Force switch request on span 25323
UNIDENTIFIED Lockout switch request on ring 25324
UNIDENTIFIED Lockout switch request on span 25325
UNIDENTIFIED Manual switch request on ring 25326
UNIDENTIFIED Manual switch request on span 25327
EQPT Peer-to-peer slot communication failure 25328
EQPT Peer-to-peer slot communication failure 25329
EQPT TCC A to shelf slot communication failure 25330
EQPT TCC B to shelf slot communication failure 25331
EQPT Interconnection equipment failure—working XC payload bus 25332
EQPT Interconnection equipment failure—protect XC payload bus 25333
EQPT Inhibit switch to protect request on equipment 25334
EQPT Inhibit switch to working request on equipment 25335
BER_SD BER threshold exceeded for signal degrade—line 25336
BER_SD BER threshold exceeded for signal degrade—path 25337
BER_SF BER threshold exceeded for signal failure—line 25338
BER_SF BER threshold exceeded for signal failure—path 25339
UNIDENTIFIED Exercising ring successfully 25340
UNIDENTIFIED Exercising span successfully 25341
UNIDENTIFIED Span is in wait-to-restore state 25342
EQPT Peer card not responding 25343
UNIDENTIFIED Exercise request on ring failed 25344
UNIDENTIFIED Exercise request on span failed 25345
UNIDENTIFIED Far-end lockout of protection—span 25346
EQPT Manufacturing data memory (EEPROM) failure 25347
EQPT Replaceable equipment/unit is missing 25348
ENV Software download failure 25349
TIM TIM section—trace identifier mismatch failure 25350
AIS AIS—multiplex section—alarm indication signal 25351
RAI RFI—multiplex section—remote failure/alarm indication 25352
TIM TIM high order—trace identifier mismatch failure 25353
AU_AIS AIS—administration unit—alarm indication signal 25354
LOP LOP—administration unit—loss of pointer 25355
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-55
Page 56
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNEQ SLMF—unequipped high order—path unequipped 25356
PLM SLMF—PLM high order—path label mismatch 25357
RAI RFI—high order—remote failure/alarm indication 25358
LOP LOP—tributary unit—loss of pointer 25359
TU-AIS AIS—tributary unit—alarm indication signal 25360
UNEQ SLMF—unequipped low order—path unequipped 25361
PLM SLMF—PLM low order—path label mismatch 25362
TIM TIM low order—trace identifier mismatch failure 25363
RAI RFI—low order—remote failure/alarm indication 25364
UNIDENTIFIED G811—primary reference clock traceable 25365
UNIDENTIFIED G812—transit node clock traceable 25366
UNIDENTIFIED G812—local node clock traceable 25367
UNIDENTIFIED G813—synchronous equipment timing source traceable 25368
UNIDENTIFIED E1 loopback due to FEAC command 25369
UNIDENTIFIED E1 loopback command sent to far end 25370
UNIDENTIFIED E3 loopback due to FEAC command 25371
ENV Far-end multiple E1 LOS detected on E3 25372
ENV Far-end E1 equipment failure non-service affecting 25373
ENV Far-end E1 equipment failure service affecting 25374
ENV Far-end single E1 LOS 25375
ENV Far-end E3 equipment failure service affecting 25376
UNIDENTIFIED E3 loopback command sent to far end 25377
ENV Far-end E3 equipment failure non-service affecting 25378
ENV Low voltage—battery A 25379
ENV High voltage—battery A 25380
ENV Low voltage—battery B 25381
ENV High voltage—battery B 25382
UNIDENTIFIED Procedural error—MS-SPRing out of sync 25383
UNIDENTIFIED MS-SPRing tables resynchronized 25384
UNIDENTIFIED Automatic SNCP switch caused by AIS 25385
UNIDENTIFIED Automatic SNCP switch caused by LOP 25386
UNIDENTIFIED Automatic SNCP switch caused by UNEQ 25387
UNIDENTIFIED Automatic SNCP switch caused by PDI 25388
UNIDENTIFIED Automatic SNCP switch caused by SFBER 25389
UNIDENTIFIED Automatic SNCP switch caused by SDBER 25390
Reported in the Notification)
A-56
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 57
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED STM concatenation error 25391
UNIDENTIFIED E3 idle condition 25392
UNIDENTIFIED IOS config copy failed 25393
UNIDENTIFIED IOS config copy in progress 25394
UNIDENTIFIED Alarms suppressed by user command 25399
UNIDENTIFIED Alarms suppressed for maintenance 25400
UNIDENTIFIED N/A 25401
UNIDENTIFIED Synchronization reference frequency out of bounds 25402
UNIDENTIFIED Ether Tx excess flow control 25403
UNIDENTIFIED Ether Tx oversubscribed 25404
UNIDENTIFIED Transport layer failure 25405
UNIDENTIFIED Ether Rx excess flow control 25406
UNIDENTIFIED Ether Rx oversubscribed 25407
UNIDENTIFIED Ether Tx underrun 25408
UNIDENTIFIED SNTP host failure 25409
UNIDENTIFIED DS3 frame format mismatch 25410
UNIDENTIFIED Alarms/events suppressed for this object 25411
BER_SD BER threshold exceeded for signal degrade—high order 25412
BER_SF BER threshold exceeded for signal failure—high order 25413
BER_SD BER threshold exceeded for signal degrade—low order 25414
BER_SF BER threshold exceeded for signal failure—low order 25415
UNIDENTIFIED Failure to switch to protection—high order path 25416
UNIDENTIFIED Failure to switch to protection—low order path 25417
UNIDENTIFIED Wait to restore 25418
ENV Extreme high voltage—battery A 25419
ENV Extreme low voltage—battery A 25420
ENV Extreme high voltage—battery B 25421
ENV Extreme low voltage—battery B 25422
UNIDENTIFIED Switching matrix module failure 25423
UNIDENTIFIED Signaling unable to set up circuit 25424
UNIDENTIFIED RSVP hello FSM to neighbor down 25425
UNIDENTIFIED LMP hello FSM to control channel down 25426
UNIDENTIFIED LMP neighbor discovery failed 25427
UNIDENTIFIED Unauthorized incoming signaling request 25428
UNIDENTIFIED Signaled circuit going down 25429
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-57
Page 58
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Autonomous PM report message inhibited 25430
EQPT I/O slot to XCON communication failure 25431
UNIDENTIFIED Forced switch to primary reference 25432
UNIDENTIFIED Forced switch to secondary reference 25433
UNIDENTIFIED Forced switch to third reference 25434
UNIDENTIFIED Forced switch to internal clock 25435
LOM LOF—administration unit—loss of multiframe 25436
UNIDENTIFIED Admin logout of user 25438
UNIDENTIFIED User locked out 25439
UNIDENTIFIED Admin lockout of user 25440
UNIDENTIFIED Admin lockout clear 25441
SECURITY_VIOLATION Security—invalid login—username—see audit log 25442
SECURITY_VIOLATION Security—invalid login—password—see audit log 25443
SECURITY_VIOLATION Security—invalid login—locked out—see audit log 25444
SECURITY_VIOLATION Security—invalid login—already logged on—see audit log 25445
UNIDENTIFIED Login of user 25446
UNIDENTIFIED Automatic logout of idle user 25447
UNIDENTIFIED Logout of user 25448
UNIDENTIFIED Cross-connect loopback 25451
UNIDENTIFIED Error in startup config 25454
UNIDENTIFIED No startup config 25455
EQPT Laser approaching end of life 25456
UNIDENTIFIED Database backup failed 25457
UNIDENTIFIED Database restore failed 25458
UNIDENTIFIED 8B10B out of sync 25459
AIS ODUk—alarm indication signal 25460
AIS OTUk—alarm indication signal 25461
UNIDENTIFIED OTUk—backward defect indicator 25462
UNIDENTIFIED ODUk—backward defect indicator 25463
UNIDENTIFIED FEC uncorrected word 25464
UNIDENTIFIED GCC embedded operation channel failure 25465
UNIDENTIFIED OTUk—incoming alignment error 25466
UNIDENTIFIED ODUk—locked defect—PM 25467
LOM Loss of multiframe 25468
UNIDENTIFIED ODUk—open connection indication 25469
Reported in the Notification)
A-58
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 59
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
PLM Payload type identifier mismatch 25470
TIM ODUk—trail trace identifier mismatch 25471
TIM OTUk—trail trace identifier mismatch 25472
EQPT Equipment high laser bias 25473
EQPT Equipment high laser temp 25474
EQPT Equipment high laser Peltier 25475
EQPT Equipment high Rx power 25476
EQPT Equipment high Tx power 25477
EQPT Equipment high Rx temperature 25478
EQPT Equipment low Rx temperature 25479
EQPT Equipment high transceiver voltage 25480
EQPT Equipment low laser bias 25481
EQPT Equipment low laser temp 25482
EQPT Equipment low laser Peltier 25483
EQPT Equipment low Rx power 25484
EQPT Equipment low Tx power 25485
EQPT Equipment low transceiver voltage 25486
EQPT Equipment Rx locked 25487
EQPT Equipment squelched 25488
EQPT Equipment Tx locked 25489
BER_SF OTUk—signal failure 25490
BER_SF ODUk—signal failure 25491
BER_SD OTUk—signal degrade 25492
BER_SD ODUk—signal degrade 25493
UNIDENTIFIED Pluggable port missing 25494
UNIDENTIFIED Pluggable port rate mismatch 25495
SECURITY_VIOLATION Pluggable port security code mismatch 25496
UNIDENTIFIED TCI not selected 25497
UNIDENTIFIED TCI 1 clock failure 25498
UNIDENTIFIED ODUk—backward defect indicator 25499
UNIDENTIFIED ODUk—backward defect indicator 25500
UNIDENTIFIED ODUk—backward defect indicator 25501
UNIDENTIFIED ODUk—open connection indication 25504
UNIDENTIFIED ODUk—locked defect—TCM2 25505
AIS ODUk—alarm indication signal 25506
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-59
Page 60
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
TIM ODUk—trail trace identifier mismatch 25507
BER_SD ODUk—signal degrade—TCM2 25508
BER_SF ODUk—signal failure—TCM2 25509
UNIDENTIFIED ODUk—open connection indication 25510
UNIDENTIFIED ODUk—locked defect—TCM1 25511
AIS ODUk—alarm indication signal 25512
TIM ODUk—trail trace identifier mismatch 25513
BER_SD ODUk—signal degrade—TCM1 25514
BER_SF ODUk—signal failure—TCM1 25515
LOF OTUk—loss of frame 25516
UNIDENTIFIED TCI 2 clock failure 25517
UNIDENTIFIED Audit log 80 percent full 25518
UNIDENTIFIED Module communication failure 25519
UNIDENTIFIED Need to save running config 25520
UNIDENTIFIED Audit log 100 percent full—oldest records will be lost 25521
UNIDENTIFIED Standby database out of sync 25522
EQPT Redundant power capability lost 25523
EQPT Equipment wavelength mismatch 25524
UNIDENTIFIED DSP communication failure 25525
UNIDENTIFIED DSP failure 25526
UNIDENTIFIED LAN connection polarity reversed 25527
UNIDENTIFIED Loss of channel 25528
UNIDENTIFIED FEC mismatch 25529
UNIDENTIFIED Optical power degrade low 25531
UNIDENTIFIED Optical power degrade high 25532
SECURITY_VIOLATION Security intrusion attempt detected—see audit log 25533
SECURITY_VIOLATION Security intrusion attempt detected—see audit log 25534
UNIDENTIFIED Variable optical attenuator degrade low 25536
UNIDENTIFIED Variable optical attenuator degrade high 25537
UNIDENTIFIED Variable optical attenuator failure low 25538
UNIDENTIFIED Variable optical attenuator failure high 25539
UNIDENTIFIED Laser bias degrade 25540
UNIDENTIFIED Laser bias failure 25541
UNIDENTIFIED Laser temperature degrade 25542
UNIDENTIFIED Optical amplifier gain degrade low 25543
Reported in the Notification)
A-60
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 61
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Optical amplifier gain degrade high 25544
UNIDENTIFIED Optical amplifier gain failure low 25545
UNIDENTIFIED Optical amplifier gain failure high 25546
UNIDENTIFIED Laser auto power reduction 25547
UNIDENTIFIED Case temperature degrade 25548
UNIDENTIFIED Fiber temperature degrade 25549
UNIDENTIFIED Shutter open 25550
UNIDENTIFIED AWG temperature degrade 25551
UNIDENTIFIED AWG temperature failure 25552
UNIDENTIFIED AWG over temperature 25553
UNIDENTIFIED Shutter insertion loss variation degrade low 25554
UNIDENTIFIED Shutter insertion loss variation degrade high 25555
UNIDENTIFIED AWG warm up 25556
UNIDENTIFIED Plug-in module communication failure 25557
UNIDENTIFIED Optical amplifier initialization 25558
UNIDENTIFIED Optical channel connection failure 25559
UNIDENTIFIED Optical channel activation failure 25560
UNIDENTIFIED Optical channel deactivation failure 25561
UNIDENTIFIED Network topology incomplete 25562
UNIDENTIFIED Optical network type mismatch 25563
UNIDENTIFIED Automatic power control failure 25564
UNIDENTIFIED Automatic power control disabled 25565
UNIDENTIFIED Ring ID mismatch 25566
UNIDENTIFIED TIM section monitor—trace identifier mismatch failure 25569
UNIDENTIFIED Optical channel incomplete 25570
UNIDENTIFIED Enhanced remote failure indication—path—server 25571
UNIDENTIFIED Enhanced remote failure indication—path—connectivity 25572
UNIDENTIFIED Enhanced remote failure indication—path—payload 25573
UNIDENTIFIED Automatic laser shutdown 25574
UNIDENTIFIED Firewall has been disabled 25575
UNIDENTIFIED Optical power failure low 25576
UNIDENTIFIED Optical power failure high 25577
UNIDENTIFIED Battery failure 25578
UNIDENTIFIED Extreme high voltage 25579
UNIDENTIFIED Extreme low voltage 25580
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-61
Page 62
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED High voltage 25581
UNIDENTIFIED Low voltage 25582
UNIDENTIFIED Connection equipment mismatch 25583
UNIDENTIFIED Disable inactive user 25584
UNIDENTIFIED Disable inactive user 25585
UNIDENTIFIED Suspend user 25586
UNIDENTIFIED Suspend user clear 25587
UNIDENTIFIED Line DCC termination failure 25588
UNIDENTIFIED Multiplex section DCC termination failure 25589
UNIDENTIFIED Gigabit Ethernet out of sync 25590
AIS Alarm indication signal in Tx 25591
AIS Remote alarm indication in Tx 25592
UNIDENTIFIED Incoming signal loss on fibre channel interface 25594
UNIDENTIFIED Incoming synchronization loss on fibre channel interface 25595
UNIDENTIFIED Out of frame detected by GFP receiver 25596
UNIDENTIFIED Client signal loss frames detected by GFP receiver 25597
UNIDENTIFIED Client synchronization loss frames detected by GFP receiver 25598
UNIDENTIFIED Sequence mismatch 25599
UNIDENTIFIED Loss of alignment 25600
UNIDENTIFIED Out of use—administrative command 25601
UNIDENTIFIED Out of use—transport failure 25602
UNIDENTIFIED VCAT group down 25603
UNIDENTIFIED VCAT group degraded 25604
UNIDENTIFIED VCAT group incomplete 25605
UNIDENTIFIED K byte channel failure 25606
UNIDENTIFIED Industrial high temperature 25607
UNIDENTIFIED APS invalid mode 25608
UNIDENTIFIED IP address already in use within the same DCC area 25609
UNIDENTIFIED Node name already in use within the same DCC area 25610
UNIDENTIFIED Rear panel Ethernet link removed 25611
UNIDENTIFIED Manual switch to protect resulted in no traffic switch 25612
UNIDENTIFIED Manual switch back to working resulted in no traffic switch 25613
UNIDENTIFIED Forced switch to protection resulted in no traffic switch 25614
UNIDENTIFIED Forced switch back to working resulted in no traffic switch 25615
UNIDENTIFIED Loss of signal for optical channel 25616
Reported in the Notification)
A-62
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 63
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Incoming overhead signal absent 25617
UNIDENTIFIED Optical safety remote interlock on 25618
UNIDENTIFIED OSPF hello fail 25619
UNIDENTIFIED Automatic power control correction skipped 25620
UNIDENTIFIED Plug-in module range settings mismatch 25621
UNIDENTIFIED APC cannot set value due to range limits 25622
UNIDENTIFIED Automatic WDM ANS finished 25623
UNIDENTIFIED Port failure 25624
UNIDENTIFIED Unreachable port target power 25625
UNIDENTIFIED Port add power degrade low 25626
UNIDENTIFIED Port add power degrade high 25627
UNIDENTIFIED Port add power fail low 25628
UNIDENTIFIED Port add power fail high 25629
UNIDENTIFIED Equipment power failure at connector A 25630
UNIDENTIFIED Equipment power failure at connector B 25631
UNIDENTIFIED Equipment power failure at return connector A 25632
UNIDENTIFIED Equipment power failure at return connector B 25633
UNIDENTIFIED Far-end manual switch back to working—span 25634
UNIDENTIFIED Far-end forced switch back to working—span 25635
UNIDENTIFIED Universal transponder module hardware failure 25636
UNIDENTIFIED Universal transponder module communication failure 25637
UNIDENTIFIED Automatic power control terminated on manual request 25638
UNIDENTIFIED Fibre channel distance extension credit starvation 25639
PLM GFP user payload mismatch 25640
UNIDENTIFIED GFP fibre channel distance extension mismatch 25641
UNIDENTIFIED GFP fibre channel distance extension buffer starvation 25642
BER_SF GFP client signal fail detected 25643
LOF GFP loss of frame delineation 25644
UNIDENTIFIED GFP extension header mismatch 25645
UNIDENTIFIED Signal loss on data interface 25646
UNIDENTIFIED Encapsulation mismatch—path 25647
UNIDENTIFIED Encapsulation mismatch—VT 25648
UNIDENTIFIED Encapsulation mismatch high order—path 25649
UNIDENTIFIED Encapsulation mismatch low order—path 25650
UNIDENTIFIED Synchronization loss on data interface 25651
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-63
Page 64
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-23 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15327, ONS 15454 SONET, and ONS 15454
SDH R5.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
AIS ODUk-1—alarm indication signal 25652
AIS ODUk-2—alarm indication signal 25653
AIS ODUk-3—alarm indication signal 25654
AIS ODUk-4—alarm indication signal 25655
UNIDENTIFIED LCAS control word CRC check failure 25656
UNIDENTIFIED Duplicate serial number detected on a pluggable entity 25657
UNIDENTIFIED LCAS VCG member Tx side in DNU state 25658
UNIDENTIFIED LCAS VCG member Tx side in ADD state 25659
UNIDENTIFIED LCAS VCG member Rx side in FAIL state 25660
UNIDENTIFIED Optimized 1+1 APS primary facility 25661
UNIDENTIFIED Optimized 1+1 APS primary section mismatch 25662
UNIDENTIFIED Optimized 1+1 APS invalid primary section 25663
UNIDENTIFIED Composite clock high line voltage 25664
BER_SD BER threshold exceeded for signal degrade—VT 25665
BER_SF BER threshold exceeded for signal failure—VT 25666
UNIDENTIFIED Alarms suppressed on out-of-group VCAT member 25667
UNIDENTIFIED Span length out of range 25668
UNIDENTIFIED Temperature reading mismatch between SC cards 25669
UNIDENTIFIED Voltage reading mismatch between SC cards 25670
UNIDENTIFIED Syslog messages 28000
UNIDENTIFIED Configuration events 28001
UNIDENTIFIED Link up/link down trap 28002
UNIDENTIFIED Cold/warm start trap 28003
SECURITY_VIOLATION Authentication failure notification 28004
Reported in the Notification)
A-64
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 65
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
A.5.8 CTM GateWay/CORBA Mapping—ONS 15310 CL, ONS 15454 SONET, and
ONS 15454 SDH R6.0 and R8.0; ONS 15327 R6.0
The following table lists the CTM GateWay/CORBA mapping for the ONS 15310 CL, ONS 15454
SONET, and ONS 15454 SDH R6.0 and R8.0, and for the ONS 15327 R6.0.
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Normal condition 25000
ENV Failure detected external to the NE 25001
ENV External error 25002
UNIDENTIFIED Excessive switching 25003
UNIDENTIFIED Incoming failure condition 25004
AIS Alarm indication signal 25005
AIS Alarm indication signal—line 25006
AIS Alarm indication signal—path 25007
FOP_APS APS channel failure 25008
FOP_APS Byte failure 25009
FOP_APS Protection switching channel match failure 25010
FOP_APS Automatic protection switch mode mismatch 25011
FOP_APS Far-end protection line failure 25012
UNIDENTIFIED Bipolar violation 25013
UNIDENTIFIED Carrier loss on the LAN 25014
UNIDENTIFIED STS concatenation error 25015
UNIDENTIFIED Excess collisions on the LAN 25016
UNIDENTIFIED Facility failure 25017
UNIDENTIFIED Far-end block error 25018
LOF Loss of frame 25019
LOP Loss of pointer 25020
LOP Loss of pointer—path 25021
LOS Loss of signal 25022
UNIDENTIFIED Out of frame 25023
UNIDENTIFIED Path selector failure 25024
RAI Remote alarm indication 25025
RAI Remote failure indication 25026
RAI Remote failure indication—line 25027
RAI Remote failure indication—path 25028
BER_SD Signal degrade 25029
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-65
Page 66
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Severely errored frame 25030
UNIDENTIFIED Invalid alarm 25031
BER_SF Signal failure 25032
UNIDENTIFIED Signal label mismatch failures 25033
UNIDENTIFIED Payload defect indication 25034
UNIDENTIFIED Payload defect indication—path 25035
PLM Payload label mismatch—path 25036
UNEQ Unequipped—path 25037
UNIDENTIFIED Loss of synchronization 25038
UNIDENTIFIED Out of synchronization 25039
UNIDENTIFIED Primary synchronization reference failure 25040
UNIDENTIFIED Secondary synchronization reference failure 25041
UNIDENTIFIED Third synchronization reference failure 25042
UNIDENTIFIED Fourth synchronization reference failure 25043
UNIDENTIFIED Fifth synchronization reference failure 25044
UNIDENTIFIED Sixth synchronization reference failure 25045
UNIDENTIFIED Outgoing failure condition 25046
RAI Remote defect indication—line 25047
RAI Remote defect indication—path 25048
UNIDENTIFIED Free running synchronization mode 25049
UNIDENTIFIED Holdover synchronization mode 25050
EQPT Internal fault 25051
UNIDENTIFIED Internal error 25052
UNIDENTIFIED Internal message error 25053
UNIDENTIFIED Mismatch of equipment and attributes 25054
UNIDENTIFIED Watchdog timer timeout 25055
ENV Software fault or failure 25056
ENV Software fault—data integrity fault 25057
UNIDENTIFIED Program failure 25058
EQPT Control equipment failure 25059
EQPT Control processor failure 25060
EQPT Working memory failure 25061
EQPT Interconnection equipment failure 25062
EQPT Time slot interchange equipment failure 25063
EQPT Equipment failure 25064
Reported in the Notification)
A-66
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 67
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
EQPT High temperature 25065
EQPT Facility termination equipment failure 25066
EQPT Automatic laser shutdown 25067
UNIDENTIFIED Failure to release from protection 25068
EQPT Receiver failure 25069
EQPT Transmit failure 25070
UNIDENTIFIED Failure to switch to protection 25071
UNIDENTIFIED Equipment unit plug-in 25072
UNIDENTIFIED Internal power failure 25073
UNIDENTIFIED Fuse alarm 25074
UNIDENTIFIED Synchronization unit failure 25075
UNIDENTIFIED Synchronization switching equipment failure 25076
EQPT Equipment unit unplugged 25077
EQPT Manually caused abnormal condition 25078
UNIDENTIFIED Manual alarm cutoff 25079
UNIDENTIFIED Procedural error 25080
EQPT Improper removal 25081
UNIDENTIFIED Protection unit not available 25082
UNIDENTIFIED Protection switch 25083
UNIDENTIFIED Recovery or service protection action has been initiated 25084
UNIDENTIFIED Automatic system reset 25085
UNIDENTIFIED Cold restart 25086
UNIDENTIFIED Forced switch back to working 25087
UNIDENTIFIED Forced switch to protection 25088
UNIDENTIFIED Initialization initiated 25089
UNIDENTIFIED Lockout of protection 25090
UNIDENTIFIED Lockout of working 25091
UNIDENTIFIED Manual system reset 25092
UNIDENTIFIED Manual switch to internal clock 25093
UNIDENTIFIED Manual switch to primary reference 25094
UNIDENTIFIED Manual switch to secondary reference 25095
UNIDENTIFIED Manual switch to third reference 25096
UNIDENTIFIED Manual switch to fourth reference 25097
UNIDENTIFIED Manual switch to fifth reference 25098
UNIDENTIFIED Manual switch to sixth reference 25099
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-67
Page 68
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Manual switch back to working 25100
UNIDENTIFIED Manual switch to protection 25101
UNIDENTIFIED Powerfail restart 25102
UNIDENTIFIED Software download in progress 25103
UNIDENTIFIED Switch to internal clock 25104
UNIDENTIFIED Switch to primary reference 25105
UNIDENTIFIED Switch to secondary reference 25106
UNIDENTIFIED Switch to third reference 25107
UNIDENTIFIED Switch to fourth reference 25108
UNIDENTIFIED Switch to fifth reference 25109
UNIDENTIFIED Switch to sixth reference 25110
UNIDENTIFIED Switched back to working 25111
UNIDENTIFIED Switched to protection 25112
UNIDENTIFIED Warm restart 25113
UNIDENTIFIED Ring is in wait-to-restore state 25114
EQPT Primary nonvolatile backup memory failure 25115
EQPT Secondary nonvolatile backup memory failure 25116
EQPT Control bus failure 25117
EQPT Control communications equipment failure 25118
UNIDENTIFIED Loopback 25119
UNIDENTIFIED Loopback, network 25120
UNIDENTIFIED Loopback, terminal 25121
EQPT Fan failure 25122
DCC_FAILURE SDCC termination failure 25123
UNIDENTIFIED Loopback facility 25124
EQPT Payload bus failure to I/O slot 1 (XCON slot 8) 25125
EQPT Payload bus failure to I/O slot 2 (XCON slot 8) 25126
EQPT Payload bus failure to I/O slot 3 (XCON slot 8) 25127
EQPT Payload bus failure to I/O slot 4 (XCON slot 8) 25128
EQPT Payload bus failure to I/O slot 5 (XCON slot 8) 25129
EQPT Payload bus failure to I/O slot 6 (XCON slot 8) 25130
EQPT Payload bus failure to I/O slot 12 (XCON slot 8) 25131
EQPT Payload bus failure to I/O slot 13 (XCON slot 8) 25132
EQPT Payload bus failure to I/O slot 14 (XCON slot 8) 25133
EQPT Payload bus failure to I/O slot 15 (XCON slot 8) 25134
Reported in the Notification)
A-68
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 69
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
EQPT Payload bus failure to I/O slot 16 (XCON slot 8) 25135
EQPT Payload bus failure to I/O slot 17 (XCON slot 8) 25136
EQPT Payload bus failure to I/O slot 1 (XCON slot 10) 25137
EQPT Payload bus failure to I/O slot 2 (XCON slot 10) 25138
EQPT Payload bus failure to I/O slot 3 (XCON slot 10) 25139
EQPT Payload bus failure to I/O slot 4 (XCON slot 10) 25140
EQPT Payload bus failure to I/O slot 5 (XCON slot 10) 25141
EQPT Payload bus failure to I/O slot 6 (XCON slot 10) 25142
EQPT Payload bus failure to I/O slot 12 (XCON slot 10) 25143
EQPT Payload bus failure to I/O slot 13 (XCON slot 10) 25144
EQPT Payload bus failure to I/O slot 14 (XCON slot 10) 25145
EQPT Payload bus failure to I/O slot 15 (XCON slot 10) 25146
EQPT Payload bus failure to I/O slot 16 (XCON slot 10) 25147
EQPT Payload bus failure to I/O slot 17 (XCON slot 10) 25148
EQPT Control bus 1 failure 25149
EQPT Control bus 2 failure 25150
EQPT Invalid MAC address 25151
EQPT Board failure 25152
EQPT Diagnostics failure 25153
EQPT Medium access control failure 25154
UNIDENTIFIED Duplicate node ID 25155
UNIDENTIFIED Failure to switch to protection—ring 25156
UNIDENTIFIED Failure to switch to protection—span 25157
UNIDENTIFIED Manual switch back to working—ring 25158
UNIDENTIFIED Manual switch back to working—span 25159
UNIDENTIFIED Manual switch to protection—ring 25160
UNIDENTIFIED Manual switch to protection—span 25161
UNIDENTIFIED Forced switch back to working—ring 25162
UNIDENTIFIED Forced switch back to working—span 25163
UNIDENTIFIED Forced switch to protection—ring 25164
UNIDENTIFIED Forced switch to protection—span 25165
UNIDENTIFIED Lockout of protection—ring 25166
UNIDENTIFIED Lockout of protection—span 25167
UNIDENTIFIED Lockout of working—ring 25168
UNIDENTIFIED Lockout of working—span 25169
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-69
Page 70
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Ring is squelching traffic 25170
FOP_APS Inconsistent APS code 25171
FOP_APS Node ID mismatch 25172
FOP_APS Default K byte 25173
FOP_APS Connection loss 25174
EQPT TCC A to shelf slot 1 (DROP 1) communication failure 25175
EQPT TCC A to shelf slot 2 (DROP 2) communication failure 25176
EQPT TCC A to shelf slot 3 (DROP 3) communication failure 25177
EQPT TCC A to shelf slot 4 (DROP 4) communication failure 25178
EQPT TCC A to shelf slot 5 (TRUNK 1) communication failure 25179
EQPT TCC A to shelf slot 6 (TRUNK 2) communication failure 25180
EQPT TCC A to shelf slot 7 (TCC A) communication failure 25181
EQPT TCC A to shelf slot 8 (XCON A) communication failure 25182
EQPT TCC A to shelf slot 9 (AIC) communication failure 25183
EQPT TCC A to shelf slot 10 (XCON B) communication failure 25184
EQPT TCC A to shelf slot 11 (TCC B) communication failure 25185
EQPT TCC A to shelf slot 12 (TRUNK 3) communication failure 25186
EQPT TCC A to shelf slot 13 (TRUNK 4) communication failure 25187
EQPT TCC A to shelf slot 14 (DROP 5) communication failure 25188
EQPT TCC A to shelf slot 15 (DROP 6) communication failure 25189
EQPT TCC A to shelf slot 16 (DROP 7) communication failure 25190
EQPT TCC A to shelf slot 17 (DROP 8) communication failure 25191
EQPT TCC A to DCC A processor communication failure 25192
EQPT TCC B to shelf slot 1 (DROP 1) communication failure 25193
EQPT TCC B to shelf slot 2 (DROP 2) communication failure 25194
EQPT TCC B to shelf slot 3 (DROP 3) communication failure 25195
EQPT TCC B to shelf slot 4 (DROP 4) communication failure 25196
EQPT TCC B to shelf slot 5 (TRUNK 1) communication failure 25197
EQPT TCC B to shelf slot 6 (TRUNK 2) communication failure 25198
EQPT TCC B to shelf slot 7 (TCC A) communication failure 25199
EQPT TCC B to shelf slot 8 (XCON A) communication failure 25200
EQPT TCC B to shelf slot 9 (AIC) communication failure 25201
EQPT TCC B to shelf slot 10 (XCON B) communication failure 25202
EQPT TCC B to shelf slot 11 (TCC B) communication failure 25203
EQPT TCC B to shelf slot 12 (TRUNK 3) communication failure 25204
Reported in the Notification)
A-70
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 71
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
EQPT TCC B to shelf slot 13 (TRUNK 4) communication failure 25205
EQPT TCC B to shelf slot 14 (DROP 5) communication failure 25206
EQPT TCC B to shelf slot 15 (DROP 6) communication failure 25207
EQPT TCC B to shelf slot 16 (DROP 7) communication failure 25208
EQPT TCC B to shelf slot 17 (DROP 8) communication failure 25209
EQPT TCC B to DCC B processor communication failure 25210
UNIDENTIFIED Fast start synchronization mode 25211
FOP_APS Improper APS code 25212
UNIDENTIFIED BLSR out of sync 25213
AIS Alarm indication signal—VT 25214
RAI Remote failure indication—VT 25215
PLM Signal label mismatch failure—payload label mismatch—VT 25216
UNEQ Signal label mismatch failure—unequipped—VT 25217
UNIDENTIFIED Peer state mismatch 25218
EQPT Facility termination equipment—receiver missing 25219
EQPT Facility termination equipment—transmitter missing 25220
LOP Loss of pointer—VT 25221
UNIDENTIFIED Embedded operations channel failure—link down 25222
UNIDENTIFIED Failed to receive synchronization status message 25223
UNIDENTIFIED Synchronization status messages are disabled on this interface 25224
UNIDENTIFIED Primary reference source—stratum 1 traceable 25225
UNIDENTIFIED Synchronized—traceability unknown 25226
UNIDENTIFIED Stratum 2 traceable 25227
UNIDENTIFIED Transit node clock traceable 25228
UNIDENTIFIED Stratum 3E traceable 25229
UNIDENTIFIED Stratum 3 traceable 25230
UNIDENTIFIED SONET minimum clock traceable 25231
UNIDENTIFIED Stratum 4 traceable 25232
UNIDENTIFIED Do not use for synchronization 25233
UNIDENTIFIED Reserved for network synchronization use 25234
UNIDENTIFIED Failure to switch to protection—path 25235
UNIDENTIFIED Manual switch of working facility—equipment to
protection—path
UNIDENTIFIED Working facility—equipment forced to switch to
protection—path
Reported in the Notification)
25236
25237
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-71
Page 72
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Lockout of protection—path 25238
UNIDENTIFIED Automatic path-protection switch caused by AIS 25239
UNIDENTIFIED Automatic path-protection switch caused by LOP 25240
UNIDENTIFIED Automatic path-protection switch caused by UNEQ 25241
UNIDENTIFIED Automatic path-protection switch caused by PDI 25242
UNIDENTIFIED Automatic path-protection switch caused by SFBER 25243
UNIDENTIFIED Automatic path-protection switch caused by SDBER 25244
UNIDENTIFIED DS3 idle condition 25245
UNIDENTIFIED DS1 loopback due to FEAC command 25246
UNIDENTIFIED DS1 loopback command sent to far end 25247
UNIDENTIFIED DS3 loopback due to FEAC command 25248
UNIDENTIFIED DS3 loopback command sent to far end 25249
UNIDENTIFIED DS2 loopback due to far-end command 25250
UNIDENTIFIED DS2 loopback command sent to far end 25251
ENV Far-end AIS 25252
UNIDENTIFIED Far-end multiple DS1 LOS detected on DS3 25253
ENV Far-end DS1 equipment failure—non-service affecting 25254
ENV Far-end DS1 equipment failure—service affecting 25255
ENV Far-end single DS1 LOS 25256
ENV Far-end DS3 equipment failure—non-service affecting 25257
ENV Far-end DS3 equipment failure—service affecting 25258
ENV Far-end common equipment failure—non-service affecting 25259
UNIDENTIFIED Far-end idle 25260
ENV Far-end LOS 25261
ENV Far-end LOF 25262
UNIDENTIFIED Performance monitor threshold crossing alert 25263
UNIDENTIFIED Ethernet bridge is new root of spanning tree 25264
UNIDENTIFIED Ethernet bridge topology change 25265
UNIDENTIFIED BLSR tables resynchronized 25266
ENV System reboot 25267
UNIDENTIFIED Manual switch request on facility—equipment 25268
UNIDENTIFIED Forced switch request on facility or equipment 25269
UNIDENTIFIED Lockout switch request on facility—equipment 25270
UNIDENTIFIED RMON histories and alarms reset reboot 25271
UNIDENTIFIED RMON alarm 25272
Reported in the Notification)
A-72
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 73
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
LOS Video interface card loss of video IF signal 25273
LOS VIC loss of video baseband signal 25274
LOS VIC loss of audio FM signal 25275
LOS VIC loss of audio baseband channel 1 signal 25276
LOS VIC loss of audio baseband channel 2 signal 25277
LOS VIC loss of audio baseband channel 3 signal 25278
LOS VIC loss of audio baseband channel 4 signal 25279
TIM STS path trace identifier mismatch 25280
ENV NE power failure at connector A 25281
ENV NE power failure at connector B 25282
UNIDENTIFIED Free memory on card very low 25283
UNIDENTIFIED Free memory on card near zero 25284
UNIDENTIFIED Exercise request on ring 25285
UNIDENTIFIED Exercise request on span 25286
UNIDENTIFIED Squelching path 25287
UNIDENTIFIED Extra traffic preempted 25288
UNIDENTIFIED Far-end lockout of working—ring 25289
UNIDENTIFIED Far-end lockout of working—span 25290
UNIDENTIFIED Far-end lockout of protection—ring 25291
UNIDENTIFIED Far-end lockout of protection—all spans 25292
UNIDENTIFIED Far-end working facility forced to switch to protection—ring 25293
UNIDENTIFIED Far-end working facility forced to switch to protection—span 25294
UNIDENTIFIED Far-end manual switch of working facility to protection—ring 25295
UNIDENTIFIED Far-end manual switch of working facility to protection—span 25296
UNIDENTIFIED Far-end exercising ring 25297
UNIDENTIFIED Far-end exercising span 25298
ENV Far-end BER threshold passed for signal failure—ring 25299
ENV Far-end BER threshold passed for signal failure—span 25300
ENV Far-end BER threshold passed for signal degrade—ring 25301
ENV Far-end BER threshold passed for signal degrade—span 25302
ENV APS channel—far-end protection line signal degrade 25303
UNIDENTIFIED Ring switch is active on the east side 25304
UNIDENTIFIED Ring switch is active on the west side 25305
UNIDENTIFIED Span switch is active on the east side 25306
UNIDENTIFIED Span switch is active on the west side 25307
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-73
Page 74
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Unidirectional full pass-through is active 25308
UNIDENTIFIED Bidirectional full pass-through is active 25309
UNIDENTIFIED K bytes pass-through is active 25310
UNIDENTIFIED Ring is segmented 25311
UNIDENTIFIED Ring topology is under construction 25312
UNIDENTIFIED Lockout of protection—all spans 25313
UNIDENTIFIED Far end of fiber is provisioned with different ring ID 25314
UNIDENTIFIED Both ends of fiber provisioned as east or both as west 25315
SECURITY_VIOLATION Security—invalid login—see audit trail 25316
UNIDENTIFIED Autonomous messages inhibited 25317
UNIDENTIFIED Traffic storm on LAN; LAN temporarily disabled 25318
SECURITY_VIOLATION REPT^DBCHG messages inhibited 25319
SECURITY_VIOLATION Security—user ID has expired 25320
EQPT Partial fan failure 25321
UNIDENTIFIED Force switch request on ring 25322
UNIDENTIFIED Force switch request on span 25323
UNIDENTIFIED Lockout switch request on ring 25324
UNIDENTIFIED Lockout switch request on span 25325
UNIDENTIFIED Manual switch request on ring 25326
UNIDENTIFIED Manual switch request on span 25327
EQPT Peer-to-peer slot communication failure 25328
EQPT Peer-to-peer slot communication failure 25329
EQPT TCC A to shelf slot communication failure 25330
EQPT TCC B to shelf slot communication failure 25331
EQPT Interconnection equipment failure—working XC payload bus 25332
EQPT Interconnection equipment failure—protect XC payload bus 25333
EQPT Inhibit switch to protect request on equipment 25334
EQPT Inhibit switch to working request on equipment 25335
BER_SD BER threshold exceeded for signal degrade—line 25336
BER_SD BER threshold exceeded for signal degrade—path 25337
BER_SF BER threshold exceeded for signal failure—line 25338
BER_SF BER threshold exceeded for signal failure—path 25339
UNIDENTIFIED Exercising ring successfully 25340
UNIDENTIFIED Exercising span successfully 25341
UNIDENTIFIED Span is in wait-to-restore state 25342
Reported in the Notification)
A-74
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 75
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
EQPT Peer card not responding 25343
UNIDENTIFIED Exercise request on ring failed 25344
UNIDENTIFIED Exercise request on span failed 25345
UNIDENTIFIED Far-end lockout of protection—span 25346
EQPT Manufacturing data memory (EEPROM) failure 25347
EQPT Replaceable equipment/unit is missing 25348
ENV Software download failure 25349
TIM TIM section—trace identifier mismatch failure 25350
AIS AIS—multiplex section—alarm indication signal 25351
RAI RFI—multiplex section—remote failure/alarm indication 25352
TIM TIM high order—trace identifier mismatch failure 25353
AU_AIS AIS—administration unit—alarm indication signal 25354
LOP LOP—administration unit—loss of pointer 25355
UNEQ SLMF—unequipped high order—path unequipped 25356
PLM SLMF—PLM high order—path label mismatch 25357
RAI RFI—high order—remote failure/alarm indication 25358
LOP LOP—tributary unit—loss of pointer 25359
TU-AIS AIS—tributary unit—alarm indication signal 25360
UNEQ SLMF—unequipped low order—path unequipped 25361
PLM SLMF—PLM low order—path label mismatch 25362
TIM TIM low order—trace identifier mismatch failure 25363
RAI RFI—low order—remote failure/alarm indication 25364
UNIDENTIFIED G811—primary reference clock traceable 25365
UNIDENTIFIED G812—transit node clock traceable 25366
UNIDENTIFIED G812—local node clock traceable 25367
UNIDENTIFIED G813—synchronous equipment timing source traceable 25368
UNIDENTIFIED E1 loopback due to FEAC command 25369
UNIDENTIFIED E1 loopback command sent to far end 25370
UNIDENTIFIED E3 loopback due to FEAC command 25371
ENV Far-end multiple E1 LOS detected on E3 25372
ENV Far-end E1 equipment failure non-service affecting 25373
ENV Far-end E1 equipment failure service affecting 25374
ENV Far-end single E1 LOS 25375
ENV Far-end E3 equipment failure service affecting 25376
UNIDENTIFIED E3 loopback command sent to far end 25377
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-75
Page 76
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
ENV Far-end E3 equipment failure non-service affecting 25378
ENV Low voltage—battery A 25379
ENV High voltage—battery A 25380
ENV Low voltage—battery B 25381
ENV High voltage—battery B 25382
UNIDENTIFIED Procedural error—MS-SPRing out of sync 25383
UNIDENTIFIED MS-SPRing tables resynchronized 25384
UNIDENTIFIED Automatic SNCP switch caused by AIS 25385
UNIDENTIFIED Automatic SNCP switch caused by LOP 25386
UNIDENTIFIED Automatic SNCP switch caused by UNEQ 25387
UNIDENTIFIED Automatic SNCP switch caused by PDI 25388
UNIDENTIFIED Automatic SNCP switch caused by SFBER 25389
UNIDENTIFIED Automatic SNCP switch caused by SDBER 25390
UNIDENTIFIED STM concatenation error 25391
UNIDENTIFIED E3 idle condition 25392
UNIDENTIFIED IOS config copy failed 25393
UNIDENTIFIED IOS config copy in progress 25394
UNIDENTIFIED Alarms suppressed by user command 25399
UNIDENTIFIED Alarms suppressed for maintenance 25400
UNIDENTIFIED N/A 25401
UNIDENTIFIED Synchronization reference frequency out of bounds 25402
UNIDENTIFIED Ether Tx excess flow control 25403
UNIDENTIFIED Ether Tx oversubscribed 25404
UNIDENTIFIED Transport layer failure 25405
UNIDENTIFIED Ether Rx excess flow control 25406
UNIDENTIFIED Ether Rx oversubscribed 25407
UNIDENTIFIED Ether Tx underrun 25408
UNIDENTIFIED SNTP host failure 25409
UNIDENTIFIED DS3 frame format mismatch 25410
UNIDENTIFIED Alarms/events suppressed for this object 25411
BER_SD BER threshold exceeded for signal degrade—high order 25412
BER_SF BER threshold exceeded for signal failure—high order 25413
BER_SD BER threshold exceeded for signal degrade—low order 25414
BER_SF BER threshold exceeded for signal failure—low order 25415
UNIDENTIFIED Failure to switch to protection—high order path 25416
Reported in the Notification)
A-76
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 77
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Failure to switch to protection—low order path 25417
UNIDENTIFIED Wait to restore 25418
ENV Extreme high voltage—battery A 25419
ENV Extreme low voltage—battery A 25420
ENV Extreme high voltage—battery B 25421
ENV Extreme low voltage—battery B 25422
UNIDENTIFIED Switching matrix module failure 25423
UNIDENTIFIED Signaling unable to set up circuit 25424
UNIDENTIFIED RSVP hello FSM to neighbor down 25425
UNIDENTIFIED LMP hello FSM to control channel down 25426
UNIDENTIFIED LMP neighbor discovery has failed 25427
UNIDENTIFIED Unauthorized incoming signaling request 25428
UNIDENTIFIED Signaled circuit going down 25429
UNIDENTIFIED Autonomous PM report message inhibited 25430
EQPT I/O slot to XCON communication failure 25431
UNIDENTIFIED Forced switch to primary reference 25432
UNIDENTIFIED Forced switch to secondary reference 25433
UNIDENTIFIED Forced switch to third reference 25434
UNIDENTIFIED Forced switch to internal clock 25435
LOM LOF—administration unit—loss of multiframe 25436
UNIDENTIFIED Admin logout of user 25438
UNIDENTIFIED User locked out 25439
UNIDENTIFIED Admin lockout of user 25440
UNIDENTIFIED Admin lockout clear 25441
SECURITY_VIOLATION Security—invalid login—username—see audit log 25442
SECURITY_VIOLATION Security—invalid login—password—see audit log 25443
SECURITY_VIOLATION Security—invalid login—locked out—see audit log 25444
SECURITY_VIOLATION Security—invalid login—already logged on—see audit log 25445
UNIDENTIFIED Login of user 25446
UNIDENTIFIED Automatic logout of idle user 25447
UNIDENTIFIED Logout of user 25448
UNIDENTIFIED Cross-connect loopback 25451
UNIDENTIFIED Error in startup config 25454
UNIDENTIFIED No startup config 25455
EQPT Laser approaching end of life 25456
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-77
Page 78
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Database backup failed 25457
UNIDENTIFIED Database restore failed 25458
UNIDENTIFIED 8B10B out of sync 25459
AIS ODUk—alarm indication signal 25460
AIS OTUk—alarm indication signal 25461
UNIDENTIFIED OTUk—backward defect indicator 25462
UNIDENTIFIED ODUk—backward defect indicator 25463
UNIDENTIFIED FEC uncorrected word 25464
UNIDENTIFIED GCC embedded operation channel failure 25465
UNIDENTIFIED OTUk—incoming alignment error 25466
UNIDENTIFIED ODUk—locked defect—PM 25467
LOM Loss of multiframe 25468
UNIDENTIFIED ODUk—open connection indication 25469
PLM Payload type identifier mismatch 25470
TIM ODUk—trail trace identifier mismatch 25471
TIM OTUk—trail trace identifier mismatch 25472
EQPT Equipment high laser bias 25473
EQPT Equipment high laser temp 25474
EQPT Equipment high laser Peltier 25475
EQPT Equipment high Rx power 25476
EQPT Equipment high Tx power 25477
EQPT Equipment high Rx temperature 25478
EQPT Equipment low Rx temperature 25479
EQPT Equipment high transceiver voltage 25480
EQPT Equipment low laser bias 25481
EQPT Equipment low laser temp 25482
EQPT Equipment low laser Peltier 25483
EQPT Equipment low Rx power 25484
EQPT Equipment low Tx power 25485
EQPT Equipment low transceiver voltage 25486
EQPT Equipment Rx locked 25487
EQPT Equipment squelched 25488
EQPT Equipment Tx locked 25489
BER_SF OTUk—signal failure 25490
BER_SF ODUk—signal failure 25491
Reported in the Notification)
A-78
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 79
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
BER_SD OTUk—signal degrade 25492
BER_SD ODUk—signal degrade 25493
UNIDENTIFIED Pluggable port missing 25494
UNIDENTIFIED Pluggable port rate mismatch 25495
SECURITY_VIOLATION Pluggable port security code mismatch 25496
UNIDENTIFIED TCI not selected 25497
UNIDENTIFIED TCI 1 clock failure 25498
UNIDENTIFIED ODUk—backward defect indicator 25499
UNIDENTIFIED ODUk—backward defect indicator 25500
UNIDENTIFIED ODUk—backward defect indicator 25501
UNIDENTIFIED ODUk—open connection indication 25504
UNIDENTIFIED ODUk—locked defect—TCM2 25505
AIS ODUk—alarm indication signal 25506
TIM ODUk—trail trace identifier mismatch 25507
BER_SD ODUk—signal degrade—TCM2 25508
BER_SF ODUk—signal failure—TCM2 25509
UNIDENTIFIED ODUk—open connection indication 25510
UNIDENTIFIED ODUk—locked defect—TCM1 25511
AIS ODUk—alarm indication signal 25512
TIM ODUk—trail trace identifier mismatch 25513
BER_SD ODUk—signal degrade—TCM1 25514
BER_SF ODUk—signal failure—TCM1 25515
LOF OTUk—loss of frame 25516
UNIDENTIFIED TCI 2 clock failure 25517
UNIDENTIFIED Audit log 80 percent full 25518
UNIDENTIFIED Module communication failure 25519
UNIDENTIFIED Need to save running config 25520
UNIDENTIFIED Audit log 100 percent full—oldest records will be lost 25521
UNIDENTIFIED Standby database out of sync 25522
EQPT Redundant power capability lost 25523
EQPT Equipment wavelength mismatch 25524
UNIDENTIFIED DSP communication failure 25525
UNIDENTIFIED DSP failure 25526
UNIDENTIFIED LAN connection polarity reversed 25527
UNIDENTIFIED Loss of channel 25528
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-79
Page 80
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED FEC mismatch 25529
UNIDENTIFIED Optical power degrade low 25531
UNIDENTIFIED Optical power degrade high 25532
SECURITY_VIOLATION Security intrusion attempt detected—see audit log 25533
SECURITY_VIOLATION Security intrusion attempt detected—see audit log 25534
UNIDENTIFIED Variable optical attenuator degrade low 25536
UNIDENTIFIED Variable optical attenuator degrade high 25537
UNIDENTIFIED Variable optical attenuator failure low 25538
UNIDENTIFIED Variable optical attenuator failure high 25539
UNIDENTIFIED Laser bias degrade 25540
UNIDENTIFIED Laser bias failure 25541
UNIDENTIFIED Laser temperature degrade 25542
UNIDENTIFIED Optical amplifier gain degrade low 25543
UNIDENTIFIED Optical amplifier gain degrade high 25544
UNIDENTIFIED Optical amplifier gain failure low 25545
UNIDENTIFIED Optical amplifier gain failure high 25546
UNIDENTIFIED Laser auto power reduction 25547
UNIDENTIFIED Case temperature degrade 25548
UNIDENTIFIED Fiber temperature degrade 25549
UNIDENTIFIED Shutter open 25550
UNIDENTIFIED AWG temperature degrade 25551
UNIDENTIFIED AWG temperature failure 25552
UNIDENTIFIED AWG over temperature 25553
UNIDENTIFIED Shutter insertion loss variation degrade low 25554
UNIDENTIFIED Shutter insertion loss variation degrade high 25555
UNIDENTIFIED AWG warm up 25556
UNIDENTIFIED Plug-in module communication failure 25557
UNIDENTIFIED Optical amplifier initialization 25558
UNIDENTIFIED Optical channel connection failure 25559
UNIDENTIFIED Optical channel activation failure 25560
UNIDENTIFIED Optical channel deactivation failure 25561
UNIDENTIFIED Network topology incomplete 25562
UNIDENTIFIED Optical network type mismatch 25563
UNIDENTIFIED Automatic power control failure 25564
UNIDENTIFIED Automatic power control disabled 25565
Reported in the Notification)
A-80
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 81
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Ring ID mismatch 25566
TIM TIM section monitor—trace identifier mismatch failure 25569
UNIDENTIFIED Optical channel incomplete 25570
UNIDENTIFIED Enhanced remote failure indication—path—server 25571
UNIDENTIFIED Enhanced remote failure indication—path—connectivity 25572
UNIDENTIFIED Enhanced remote failure indication—path—payload 25573
UNIDENTIFIED Automatic laser shutdown 25574
UNIDENTIFIED Firewall has been disabled 25575
UNIDENTIFIED Optical power failure low 25576
UNIDENTIFIED Optical power failure high 25577
EQPT Battery failure 25578
EQPT Extreme high voltage 25579
EQPT Extreme low voltage 25580
UNIDENTIFIED High voltage 25581
UNIDENTIFIED Low voltage 25582
UNIDENTIFIED Connection equipment mismatch 25583
UNIDENTIFIED Disable inactive user 25584
UNIDENTIFIED Disable inactive user 25585
UNIDENTIFIED Suspend user 25586
UNIDENTIFIED Suspend user clear 25587
UNIDENTIFIED Line DCC termination failure 25588
UNIDENTIFIED Multiplex section DCC termination failure 25589
UNIDENTIFIED Gigabit Ethernet out of sync 25590
AIS Alarm indication signal in Tx 25591
AIS Remote alarm indication in Tx 25592
LOF Loss of frame in Tx 25593
LOS Incoming signal loss on fibre channel interface 25594
UNIDENTIFIED Incoming synchronization loss on fibre channel interface 25595
UNIDENTIFIED Out of frame detected by GFP receiver 25596
UNIDENTIFIED Client signal loss frames detected by GFP receiver 25597
UNIDENTIFIED Client synchronization loss frames detected by GFP receiver 25598
UNIDENTIFIED Sequence mismatch 25599
UNIDENTIFIED Loss of alignment 25600
UNIDENTIFIED Out of use—administrative command 25601
UNIDENTIFIED Out of use—transport failure 25602
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-81
Page 82
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED VCAT group down 25603
UNIDENTIFIED VCAT group degraded 25604
UNIDENTIFIED VCAT group incomplete 25605
UNIDENTIFIED K byte channel failure 25606
UNIDENTIFIED Industrial high temperature 25607
FOP_APS APS invalid mode 25608
UNIDENTIFIED IP address already in use within the same DCC area 25609
UNIDENTIFIED Node name already in use within the same DCC area 25610
UNIDENTIFIED Rear panel Ethernet link removed 25611
UNIDENTIFIED Manual switch to protect resulted in no traffic switch 25612
UNIDENTIFIED Manual switch back to working resulted in no traffic switch 25613
UNIDENTIFIED Forced switch to protection resulted in no traffic switch 25614
UNIDENTIFIED Forced switch back to working resulted in no traffic switch 25615
LOS Incoming payload signal absent 25616
UNIDENTIFIED Incoming overhead signal absent 25617
UNIDENTIFIED Optical safety remote interlock on 25618
UNIDENTIFIED OSPF hello fail 25619
UNIDENTIFIED Automatic power control correction skipped 25620
UNIDENTIFIED Plug-in module range settings mismatch 25621
UNIDENTIFIED APC cannot set value due to range limits 25622
UNIDENTIFIED Automatic WDM ANS finished 25623
UNIDENTIFIED Port failure 25624
UNIDENTIFIED Unreachable port target power 25625
UNIDENTIFIED Port add power degrade low 25626
UNIDENTIFIED Port add power degrade high 25627
UNIDENTIFIED Port add power fail low 25628
UNIDENTIFIED Port add power fail high 25629
UNIDENTIFIED Equipment power failure at connector A 25630
UNIDENTIFIED Equipment power failure at connector B 25631
UNIDENTIFIED Equipment power failure at return connector A 25632
UNIDENTIFIED Equipment power failure at return connector B 25633
UNIDENTIFIED Far-end manual switch back to working—span 25634
UNIDENTIFIED Far-end forced switch back to working—span 25635
UNIDENTIFIED Universal transponder module hardware failure 25636
UNIDENTIFIED Universal transponder module communication failure 25637
Reported in the Notification)
A-82
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 83
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Automatic power control terminated on manual request 25638
UNIDENTIFIED Fibre channel distance extension credit starvation 25639
PLM GFP user payload mismatch 25640
UNIDENTIFIED GFP fibre channel distance extension mismatch 25641
UNIDENTIFIED GFP fibre channel distance extension buffer starvation 25642
BER_SF GFP client signal fail detected 25643
LOF GFP loss of frame delineation 25644
UNIDENTIFIED GFP extension header mismatch 25645
UNIDENTIFIED Signal loss on data interface 25646
UNIDENTIFIED Encapsulation mismatch—path 25647
UNIDENTIFIED Encapsulation mismatch—VT 25648
UNIDENTIFIED Encapsulation mismatch high order—path 25649
UNIDENTIFIED Encapsulation mismatch low order—path 25650
UNIDENTIFIED Synchronization loss on data interface 25651
AIS ODUk-1—alarm indication signal 25652
AIS ODUk-2—alarm indication signal 25653
AIS ODUk-3—alarm indication signal 25654
AIS ODUk-4—alarm indication signal 25655
UNIDENTIFIED LCAS control word CRC check failure 25656
UNIDENTIFIED Duplicate serial number detected on a pluggable entity 25657
UNIDENTIFIED LCAS VCG member Tx side in DNU state 25658
UNIDENTIFIED LCAS VCG member Tx side in ADD state 25659
UNIDENTIFIED LCAS VCG member Rx side in FAIL state 25660
UNIDENTIFIED Optimized 1+1 APS primary facility 25661
UNIDENTIFIED Optimized 1+1 APS primary section mismatch 25662
UNIDENTIFIED Optimized 1+1 APS invalid primary section 25663
UNIDENTIFIED Composite clock high line voltage 25664
BER_SD BER threshold exceeded for signal degrade—VT 25665
BER_SF BER threshold exceeded for signal failure—VT 25666
UNIDENTIFIED Alarms suppressed on out-of-group VCAT member 25667
UNIDENTIFIED Span length out of range 25668
UNIDENTIFIED Temperature reading mismatch between SC cards 25669
UNIDENTIFIED Voltage reading mismatch between SC cards 25670
TIM VT path trace identifier mismatch 25671
UNIDENTIFIED BLSR software version mismatch 25672
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-83
Page 84
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Bridge and roll occurred 25673
UNIDENTIFIED Bridge and roll is pending a valid signal 25674
TIM Open I/O slot(s) 25675
UNIDENTIFIED ISIS adjacency failure 25676
SECURITY_VIOLATION Session time limit expired 25677
SECURITY_VIOLATION User password change required 25678
SECURITY_VIOLATION Remote authentication fail 25679
TIM Section trace identifier mismatch 25680
TIM Regenerator section trace identifier mismatch 25681
UNIDENTIFIED Switching matrix module failure—working 25682
UNIDENTIFIED Switching matrix module failure—protect 25683
UNIDENTIFIED Provisioning mismatch 25684
UNIDENTIFIED Slot communication disabled 25685
UNIDENTIFIED MSSP software version mismatch 25686
UNIDENTIFIED Archival of audit log failed 25687
UNIDENTIFIED RPR wrapped 25688
UNIDENTIFIED Software mismatch 25689
UNIDENTIFIED Link layer keepalive failure 25690
UNIDENTIFIED Bad packet count exceeds threshold 25691
UNIDENTIFIED Autonegotiation remote failure indication 25692
UNIDENTIFIED Shelf communication failure 25693
UNIDENTIFIED Duplicated shelf identifier 25694
UNIDENTIFIED Ring is squelching STS traffic 25695
UNIDENTIFIED Ring is squelching VT traffic 25696
UNIDENTIFIED Clock bus failure—shelf controller A 25697
UNIDENTIFIED Clock bus failure—shelf controller B 25698
UNIDENTIFIED Loss of clock from mate shelf controller 25699
UNIDENTIFIED Payload missing indication 25700
UNIDENTIFIED Forward defect indication 25701
UNIDENTIFIED Optical termination incomplete 25702
UNIDENTIFIED Span loss not checked 25703
UNIDENTIFIED Ring is squelching higher order traffic 25704
UNIDENTIFIED Ring is squelching lower order traffic 25705
UNIDENTIFIED Trail signal fail 25706
UNIDENTIFIED DS1 loopback command sent to far end 25707
Reported in the Notification)
A-84
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 85
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Multiplex section—signal degraded 25708
UNIDENTIFIED Multiplex section—excessive errors 25709
UNIDENTIFIED High order path—signal degraded 25710
UNIDENTIFIED High order path—excessive errors 25711
UNIDENTIFIED Low order path—signal degraded 25712
UNIDENTIFIED Low order path—excessive errors 25713
UNIDENTIFIED Regenerator section—DCC termination failure 25714
UNIDENTIFIED Network memory pool low 25715
UNIDENTIFIED OSPF routing table overflow 25716
UNIDENTIFIED Auto laser shutdown disabled 25717
UNIDENTIFIED RPR protection is active 25718
UNIDENTIFIED Max RPR station number exceeded 25719
UNIDENTIFIED RPR protection configuration mismatched 25720
UNIDENTIFIED Reserved bandwidth link rate exceeded on ringlet 0 25721
UNIDENTIFIED Reserved bandwidth link rate exceeded on ringlet 1 25722
UNIDENTIFIED RPR interface in pass-through mode 25723
UNIDENTIFIED RPR peer node is missing 25724
UNIDENTIFIED RPR RI failure 25725
UNIDENTIFIED RPR signal failure 25726
UNIDENTIFIED RPR signal degrade 25727
UNIDENTIFIED RPR span mismatch 25728
UNIDENTIFIED LMP failure 25729
UNIDENTIFIED LMP signal degrade 25730
UNIDENTIFIED LMP signal failure 25731
UNIDENTIFIED LMP unallocated data link 25732
UNIDENTIFIED APC wrong gain setpoint 25733
EQPT Non-Cisco PPM inserted 25734
EQPT Unqualified PPM inserted 25735
UNIDENTIFIED Fast automatic protection switching 25736
UNIDENTIFIED Fast automatic protection switching config mismatch 25737
UNIDENTIFIED ADM peer cards interlink failure 25738
EQPT Fan tray mismatch 25739
UNIDENTIFIED Fibre channel distance extension function not established 25740
UNIDENTIFIED LCAS sink group error 25741
UNIDENTIFIED LCAS VCG member Rx side in DNU state 25742
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-85
Page 86
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-24 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.0 and
R8.0; ONS 15327 R6.0 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Card/ports unable to provide protection 25743
UNIDENTIFIED TCC front port link loss 25744
UNIDENTIFIED Shutter insertion loss variation degrade low 25745
UNIDENTIFIED Shutter insertion loss variation degrade high 25746
UNIDENTIFIED Idle signal condition 25747
UNIDENTIFIED Idle signal condition in TX 25748
UNIDENTIFIED Automatic power control correction skipped 25749
UNIDENTIFIED Port add power fail low 25750
UNIDENTIFIED Port add power fail high 25751
UNIDENTIFIED Span length out of range 25752
UNIDENTIFIED Port add power degrade low 25753
UNIDENTIFIED Port add power degrade high 25754
UNIDENTIFIED DCU loss failure 25755
UNIDENTIFIED Syslog messages 28000
UNIDENTIFIED Configuration events 28001
UNIDENTIFIED Link up/link down trap 28002
UNIDENTIFIED Cold/warm start trap 28003
UNIDENTIFIED Authentication failure notification 28004
Reported in the Notification)
A.5.9 CTM GateWay/CORBA Mapping—ONS 15310 CL, ONS 15454 SONET, and
ONS 15454 SDH R6.2
The following table lists the CTM GateWay/CORBA mapping for the ONS 15310 CL, ONS 15454
SONET, and ONS 15454 SDH R6.2.
Table A-25 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R6.2
TMF Mapping NE Native Probable Cause NE Native Alarm Description CTM Internal Index
UNIDENTIFIED Bad packet count exceeds threshold DATA_CRC 25691
UNIDENTIFIED Autonegotiation remote failure indication AUTONEG_RFI 25692
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-86
OL-14253-01
Page 87
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
A.5.10 CTM GateWay/CORBA Mapping—ONS 15310 CL, ONS 15454 SONET, and
ONS 15454 SDH R8.5
The following table lists the CTM GateWay/CORBA mapping for the ONS 15310 CL, ONS 15454
SONET, and ONS 15454 SDH R8.5.
Table A-26 CTM GateWay/CORBA Mapping for the ONS 15310 CL, ONS 15454 SONET, and ONS 15454 SDH R8.5
TMF Mapping NE Native Probable Cause CTM Internal Index (Not Reported in the Notification)
UNIDENTIFIED BERT enabled 25763
UNIDENTIFIED BERT synchronization status failed 25764
UNIDENTIFIED Work queue full 25765
A.5.11 CTM GateWay/CORBA Mapping—ONS 15501
The following table lists the CTM GateWay/CORBA mapping for the ONS 15501.
Table A-27 CTM GateWay/CORBA Mapping for the ONS 15501
CTM Internal Index (Not Reported
TMF Mapping NE Native Probable Cause
ENV Temperature out of range 14703
ENV Electrical power level is unacceptable 14704
UNIDENTIFIED Input signal level out of range 14705
UNIDENTIFIED Output optical/signal level out of range 14706
UNIDENTIFIED Communication with embedded controller failed 14707
UNIDENTIFIED Measure signal gain is out of acceptable range 14714
UNIDENTIFIED One or more of the laser pump(s) bad 14715
in the Notification)
A.5.12 CTM GateWay/CORBA Mapping—ONS 15530
The following table lists the CTM GateWay/CORBA mapping for the ONS 15530.
Table A-28 CTM GateWay/CORBA Mapping for the ONS 15530
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
FAN Alarms
EQPT Two or more fans failed 9021
EQPT One fan failed 9022
CPU Alarms
UNIDENTIFIED Unknown alarm detected 9051
EQPT SRC diag failure 9052
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-87
Page 88
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-28 CTM GateWay/CORBA Mapping for the ONS 15530 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
EQPT PCI diag failure 9053
EQPT PCMCIA diag failure 9054
EQPT Cannot access multiple line card 9055
EQPT IDPROM/backplane slot mismatch 9056
EQPT Cannot access backplane IDPROM 9057
EQPT Inconsistent redun states 9058
EQPT Read invalid SRC 9059
EQPT Unprotected; peer missing 9060
EQPT Unprotected; peer not responding 9061
EQPT Standby with lower capabilities 9062
TSP Alarms
EQPT Access to TSP card failed 9501
EQPT Access to IDPROM failed 9502
TX_FAIL Line laser failure detected 9503
TX_DEGRADE Trunk laser degrade detected 9504
UNIDENTIFIED Trunk laser lambda deviation 9505
UNIDENTIFIED Wavelength mismatch error 9506
MDSUBCARD Alarms
EQPT Access to IDPROM failed 9601
Client Port Alarms
UNIDENTIFIED Loss of lock event 9701
LOS Loss of signal event 9702
UNIDENTIFIED Loss of sync event 9703
LOF SONET loss of frame event 9704
UNIDENTIFIED SONET severely errored frame 9705
UNIDENTIFIED Laser shut down by forward laser control 9706
UNIDENTIFIED Laser shut down by open fibre control 9707
Wave Port Alarms
UNIDENTIFIED Loss of lock event 9801
LOS Loss of signal event 9802
UNIDENTIFIED Loss of sync event 9803
LOF SONET loss of frame event 9804
UNIDENTIFIED SONET severely errored frame 9805
UNIDENTIFIED Laser shut down by forward laser control 9806
UNIDENTIFIED Laser shut down by laser safety control 9807
UNIDENTIFIED Link down 9903
Reported in the Notification)
A-88
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 89
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Table A-28 CTM GateWay/CORBA Mapping for the ONS 15530 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
Chassis Alarm
EQPT Chassis fan tray missing 12601
ENV Chassis temp > critical limit 12602
ENV Chassis temp > major limit 12603
ENV Chassis temp > minor limit 12604
ENV Chassis temp less than –5 C 12605
ENV Chassis power supply 0 missing 12606
ENV Chassis power supply 1 missing 12607
Power Supply Alarms
EQPT Power supply unit failed 12701
Wave OSC Alarms
UNIDENTIFIED Loss of lock event 10101
OSC_LOS Loss of signal event 10102
Wave Ethernet Phy Alarms
UNIDENTIFIED Loss of lock event 10201
LOS Loss of signal event 10202
UNIDENTIFIED Loss of sync event 10203
UNIDENTIFIED Laser shut down by forward laser control 10206
UNIDENTIFIED Laser shut down by laser safety control 10207
Ten Gig Ethernet Phy Alarms
UNIDENTIFIED Loss of lock event 10301
LOS Loss of signal event 10302
UNIDENTIFIED Loss of sync event 10303
UNIDENTIFIED Laser shut down by forward laser control 10306
UNIDENTIFIED Laser shut down by laser safety control 10307
ESCON Port Alarms
UNIDENTIFIED Loss of lock event 10401
LOS Loss of signal event 10402
UNIDENTIFIED Loss of sync event 10403
UNIDENTIFIED Laser disabled event 10411
UNIDENTIFIED Local failure, laser disabled 10412
ESCON SFP Alarms
TX_FAIL Transmit laser failed 10501
10G Card Alarms
EQPT Access to 10G card failed 10601
EQPT Access to IDPROM failed 10602
Reported in the Notification)
Probable Cause Mapping
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-89
Page 90
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-28 CTM GateWay/CORBA Mapping for the ONS 15530 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Ethernet DCC loopback from PSC failed 10603
EQPT 10G internal loopback failed 10604
EQPT 10G internal loopback through PSC failed 10605
TX_FAIL Laser failure detected 10606
UNIDENTIFIED Laser wavelength deviation 10607
ESCON Card Alarms
EQPT Access to ESCON card failed 10701
EQPT Access to IDPROM failed 10702
EQPT ESCON card internal loopback failed 10703
EQPT ESCON card internal loopback through PSC failed 10704
OSC MB Alarms
EQPT Access to card failed 10801
EQPT Access to IDPROM failed 10802
UNIDENTIFIED Ethernet DCC loopback from PSC failed 10803
OSC Subcard Alarms
EQPT Access to card failed 10901
EQPT Access to IDPROM failed 10902
UNIDENTIFIED Ethernet DCC loopback from OSCMB failed 10903
TX_FAIL Laser failure detected 10904
UNIDENTIFIED Laser wavelength deviation 10905
VOA and PEQ SubCard Alarms
EQPT Access to card failed 11001
EQPT Access to IDPROM failed 11002
IF-THRESHOLD Alarms
UNIDENTIFIED CVRD failure threshold exceeded 9976
UNIDENTIFIED CVRD degrade threshold exceeded 9977
UNIDENTIFIED CDL HEC failure threshold exceeded 9978
UNIDENTIFIED CDL HEC degrade threshold exceeded 9979
UNIDENTIFIED SONET/SDH CV-S failure threshold exceeded 9980
UNIDENTIFIED SONET/SDH CV-S degrade threshold exceeded 9981
UNIDENTIFIED CDL header CRC failure threshold exceeded 9982
UNIDENTIFIED CDL header CRC degrade threshold exceeded 9983
UNIDENTIFIED ESCON encapsulation packet errors failure threshold exceeded 9984
UNIDENTIFIED ESCON encapsulation packet errors degrade threshold exceeded 9985
CDL Alarms
UNIDENTIFIED CDL hop-by-hop backward defect indication 10001
Reported in the Notification)
A-90
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 91
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Table A-28 CTM GateWay/CORBA Mapping for the ONS 15530 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED CDL hop-by-hop forward defect indication 10002
UNIDENTIFIED CDL end-by-end forward defect indication 10003
UNIDENTIFIED CDL end-by-end backward defect indication 10004
Transceiver Alarms
TX_FAIL Laser failure 11501
2.5G Card Alarms
EQPT Access to 2.5G card failed 11601
EQPT Access to IDPROM failed 11602
UNIDENTIFIED Ethernet DCC loopback from PSC failed 11603
EQPT 2.5G internal loopback failed 11604
EQPT 2.5G internal loopback through PSC failed 11605
TX_FAIL Laser failure detected 11606
UNIDENTIFIED Laser wavelength deviation 11607
FCGE Card Alarms
EQPT Access to card failed 11701
EQPT Access to IDPROM failed 11702
EQPT Card internal loopback failed 11704
EQPT Card internal loopback through PSC failed 11705
Reported in the Notification)
Probable Cause Mapping
A.5.13 CTM GateWay/CORBA Mapping—ONS 15540
The following table lists the CTM GateWay/CORBA mapping for the ONS 15540.
Table A-29 CTM GateWay/CORBA Mapping for the ONS 15540
CTM Internal Index
(Not Reported in the
TMF Mapping NE Native Probable Cause
Chassis Alarms
EQPT Chassis fan tray missing 9001
ENV Chassis temp > critical limit 9002
ENV Chassis temp > major limit 9003
ENV Chassis temp > minor limit 9004
ENV Chassis temp less than –15 C 9005
ENV Chassis power supply A failed 9006
ENV Chassis power supply B failed 9007
FAN Alarms
EQPT Two or more fans failed 9021
Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-91
Page 92
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-29 CTM GateWay/CORBA Mapping for the ONS 15540 (continued)
CTM Internal Index
(Not Reported in the
TMF Mapping NE Native Probable Cause
EQPT One fan failed 9022
CPU Alarms
UNIDENTIFIED Unknown alarm detected 9051
EQPT SRC diag failure 9052
EQPT PCI diag failure 9053
EQPT PCMCIA diag failure 9054
EQPT Cannot access multiple line card 9055
EQPT IDPROM/backplane slot mismatch 9056
EQPT Cannot access backplane IDPROM 9057
EQPT Inconsistent redun states 9058
EQPT Read invalid SRC 9059
EQPT Unprotected; peer missing 9060
EQPT Unprotected; peer not responding 9061
EQPT Standby with lower capabilities 9062
LCMB Alarms
EQPT Access to LRC failed 9201
EQPT Access to IDPROM failed 9202
UNIDENTIFIED Waveport 0 opt switch failed 9203
UNIDENTIFIED Waveport 1 opt switch failed 9204
UNIDENTIFIED Waveport 2 opt switch failed 9205
UNIDENTIFIED Waveport 3 opt switch failed 9206
UNIDENTIFIED Ethernet DCC loopback from PSC failed 9207
MDMBOSC Alarms
EQPT Access to LRC failed 9301
EQPT Access to IDPROM failed 9302
EQPT OSC hardware failure detected 9303
TX_FAIL Trunk laser failure detected 9304
UNIDENTIFIED Trunk laser lambda deviation 9305
UNIDENTIFIED Ethernet DCC loopback from PSC failed 9306
MDMB Alarms
EQPT Access to LRC failed 9401
EQPT Access to IDPROM failed 9402
UNIDENTIFIED Ethernet DCC loopback from PSC failed 9406
TSP1 Alarms
EQPT Access to TSP card failed 9501
Notification)
A-92
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 93
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-29 CTM GateWay/CORBA Mapping for the ONS 15540 (continued)
CTM Internal Index
(Not Reported in the
TMF Mapping NE Native Probable Cause
EQPT Access to IDPROM failed 9502
TX_FAIL Line laser failure detected 9503
TX_FAIL Trunk laser failure detected 9504
UNIDENTIFIED Trunk laser lambda deviation 9505
UNIDENTIFIED Wavelength mismatch error 9506
MD Subcard Alarms
EQPT Access to IDPROM failed 9601
Client Port Alarms
UNIDENTIFIED Loss of lock event 9701
LOS Loss of signal event 9702
UNIDENTIFIED Loss of sync event 9703
LOF SONET loss of frame event 9704
UNIDENTIFIED SONET severely errored frame 9705
UNIDENTIFIED Laser shut down by forward laser control 9706
UNIDENTIFIED Laser shut down by open fibre control 9707
Wave Port Alarms
UNIDENTIFIED Loss of lock event 9801
LOS Loss of signal event 9802
UNIDENTIFIED Loss of sync event 9803
LOF SONET loss of frame event 9804
UNIDENTIFIED SONET severely errored frame 9805
UNIDENTIFIED Laser shut down by forward laser control 9806
UNIDENTIFIED Laser shut down by laser safety control 9807
UNIDENTIFIED Link down 9903
IF-THRESHOLD Alarms
UNIDENTIFIED CVRD failure threshold exceeded 9976
UNIDENTIFIED CVRD degrade threshold exceeded 9977
UNIDENTIFIED HEC failure threshold exceeded 9978
UNIDENTIFIED HEC degrade threshold exceeded 9979
UNIDENTIFIED SONET/SDH CV-S failure threshold exceeded 9980
UNIDENTIFIED SONET/SDH CV-S degrade threshold exceeded 9981
CDL Alarms
UNIDENTIFIED CDL hop-by-hop backward defect indication 10001
UNIDENTIFIED CDL hop-by-hop forward defect indication 10002
UNIDENTIFIED CDL end-by-end forward defect indication 10003
Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-93
Page 94
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-29 CTM GateWay/CORBA Mapping for the ONS 15540 (continued)
CTM Internal Index
(Not Reported in the
TMF Mapping NE Native Probable Cause
UNIDENTIFIED CDL end-by-end backward defect indication 10004
Wave Ethernet Phy Alarms
UNIDENTIFIED Loss of lock event 10201
LOS Loss of signal event 10202
UNIDENTIFIED Loss of sync event 10203
UNIDENTIFIED Laser shut down by forward laser control 10206
UNIDENTIFIED Laser shut down by laser safety control 10207
Ten Gig Ethernet Phy Alarms
UNIDENTIFIED Loss of lock event 10301
LOS Loss of signal event in Cisco OPT-MON-MIB 10302
UNIDENTIFIED Loss of sync event 10303
UNIDENTIFIED Laser shut down by forward laser control 10306
UNIDENTIFIED Trunk laser shut down by laser safety control 10307
10G Card Alarms
EQPT Access to card failed 11101
EQPT Access to IDPROM failed 11102
EQPT 10G internal loopback failed 11103
TX_FAIL Line laser failed 11104
TX_FAIL Trunk laser failure 11105
UNIDENTIFIED Trunk laser wavelength deviation 11106
10G MB Alarms
EQPT Access to LRC failed 11201
EQPT Access to IDPROM failed 11202
UNIDENTIFIED Waveport 0 opt switch failed 11203
UNIDENTIFIED Waveport 1 opt switch failed 11204
UNIDENTIFIED Waveport 2 opt switch failed 11205
UNIDENTIFIED Waveport 3 opt switch failed 11206
UNIDENTIFIED Ethernet DCC loopback from PSC failed 11207
Dummy TSP for 10GE Alarms
EQPT Access to subcard failed 11301
EQPT Access to IDPROM failed 11302
TSP2 Alarms
EQPT Access to TSP2 card failed 11401
EQPT Access to IDPROM failed 11402
TX_FAIL Line laser failure 11403
Notification)
A-94
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 95
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-29 CTM GateWay/CORBA Mapping for the ONS 15540 (continued)
CTM Internal Index
(Not Reported in the
TMF Mapping NE Native Probable Cause
Notification)
TX_FAIL Trunk laser failure detected 11404
UNIDENTIFIED Trunk laser lambda deviation 11405
Transceiver Alarms
TX_FAIL Laser failure 11501
A.5.14 Optical Monitoring Alarms—ONS 15530 and ONS 15540
The following table lists the optical monitoring alarms applicable to both the ONS 15530 and
ONS 15540.
Table A-30 Optical Monitoring Alarms for the ONS 15530 and ONS 15540
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
Power Optical Monitor Alarms
Reported in the Notification)
UNIDENTIFIED Rx optical power exceeds high alarm threshold 14501
UNIDENTIFIED Tx optical power exceeds high alarm threshold 14502
UNIDENTIFIED Rx optical power exceeds high warning threshold 14503
UNIDENTIFIED Tx optical power exceeds high warning threshold 14504
UNIDENTIFIED Rx optical power below low alarm threshold 14505
UNIDENTIFIED Tx optical power exceeds high alarm threshold 14506
UNIDENTIFIED Rx optical power below low warning threshold 14507
UNIDENTIFIED Tx optical power below low warning threshold 14508
AC Power Optical Monitor Alarms
UNIDENTIFIED Rx optical AC power exceeds high alarm threshold 14516
UNIDENTIFIED Tx optical AC power exceeds high alarm threshold 14517
UNIDENTIFIED Rx optical AC power exceeds high warning threshold 14518
UNIDENTIFIED Tx optical AC power exceeds high warning threshold 14519
UNIDENTIFIED Rx optical AC power below low alarm threshold 14520
UNIDENTIFIED Tx optical AC power below low alarm threshold 14521
UNIDENTIFIED Rx optical AC power below low warning threshold 14522
UNIDENTIFIED Tx optical AC power below low warning threshold 14523
Ambient Temp Power Optical Monitor Alarms
UNIDENTIFIED Rx ambient temp exceeds high alarm threshold 14531
UNIDENTIFIED Tx ambient temp exceeds high alarm threshold 14532
UNIDENTIFIED Rx ambient temp exceeds high warning threshold 14533
UNIDENTIFIED Tx ambient temp exceeds high warning threshold 14534
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-95
Page 96
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-30 Optical Monitoring Alarms for the ONS 15530 and ONS 15540 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Rx ambient temp below low alarm threshold 14535
UNIDENTIFIED Tx ambient temp below low alarm threshold 14536
UNIDENTIFIED Rx ambient temp below low warning threshold 14537
UNIDENTIFIED Tx ambient temp below low warning threshold 14538
Laser Temp Power Optical Monitor Alarms
UNIDENTIFIED Rx laser temp exceeds high alarm threshold 14546
UNIDENTIFIED Tx laser temp exceeds high alarm threshold 14547
UNIDENTIFIED Rx laser temp exceeds high warning threshold 14548
UNIDENTIFIED Tx laser temp exceeds high warning threshold 14549
UNIDENTIFIED Rx laser temp below low alarm threshold 14550
UNIDENTIFIED Tx laser temp below low alarm threshold 14551
UNIDENTIFIED Rx laser temp below low warning threshold 14552
UNIDENTIFIED Tx laser temp below low warning threshold 14553
Bias Temp Monitor Alarms
UNIDENTIFIED Rx bias current exceeds high alarm threshold 14561
UNIDENTIFIED Tx bias current exceeds high alarm threshold 14562
UNIDENTIFIED Rx bias current exceeds high warning threshold 14563
UNIDENTIFIED Tx bias current exceeds high warning threshold 14564
UNIDENTIFIED Rx bias current below low alarm threshold 14565
UNIDENTIFIED Tx bias current below low alarm threshold 14566
UNIDENTIFIED Rx bias current below low warning threshold 14567
UNIDENTIFIED Tx bias current below low warning threshold 14568
Laser Peltier Current Monitor Alarms
UNIDENTIFIED Rx laser Peltier current exceeds high alarm threshold 14576
UNIDENTIFIED Tx laser Peltier current exceeds high alarm threshold 14577
UNIDENTIFIED Rx laser Peltier current exceeds high warning threshold 14578
UNIDENTIFIED Tx laser Peltier current exceeds high warning threshold 14579
UNIDENTIFIED Rx laser Peltier current below low alarm threshold 14580
UNIDENTIFIED Tx laser Peltier current below low alarm threshold 14581
UNIDENTIFIED Rx laser Peltier current below low warning threshold 14582
UNIDENTIFIED Tx laser Peltier current below low warning threshold 14583
Transceiver Voltage Monitor Alarms
UNIDENTIFIED Rx transceiver voltage exceeds high alarm threshold 14591
UNIDENTIFIED Tx transceiver voltage exceeds high alarm threshold 14592
UNIDENTIFIED Rx transceiver voltage exceeds high warning threshold 14593
UNIDENTIFIED Tx transceiver voltage exceeds high warning threshold 14594
Reported in the Notification)
A-96
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 97
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Table A-30 Optical Monitoring Alarms for the ONS 15530 and ONS 15540 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Rx transceiver voltage below low alarm threshold 14595
UNIDENTIFIED Tx transceiver voltage below low alarm threshold 14596
UNIDENTIFIED Rx transceiver voltage below low warning threshold 14597
UNIDENTIFIED Tx transceiver voltage below low warning threshold 14598
Reported in the Notification)
A.5.15 CTM GateWay/CORBA Mapping—ONS 15600 SONET
A.5.15.1 ONS 15600 SONET R1.3.1
The following table lists the CTM GateWay/CORBA mapping for the ONS 15600 SONET R1.3.1.
Table A-31 CTM GateWay/CORBA Mapping for the ONS 15600 SONET R1.3.1
Probable Cause Mapping
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Normal condition 17000
EQPT Alarms/events suppressed for this object 17001
DCC_FAILURE DCC channel loss 17002
DCC_FAILURE SDCC termination failure 17003
AIS Alarm indication signal 17004
AIS Alarm indication signal—line 17005
AIS Alarm indication signal—path 17006
FOP_APS Byte failure 17007
FOP_APS Protection switching channel match failure 17008
FOP_APS Automatic protection switch mode mismatch 17009
FOP_APS Connection loss 17010
FOP_APS Default K byte 17011
FOP_APS Far-end protection line failure 17012
ENV APS channel—far-end protection line signal degrade 17013
FOP_APS Improper APS code 17014
FOP_APS Inconsistent APS code 17015
FOP_APS Node ID mismatch 17016
UNIDENTIFIED STS concatenation error 17017
LOF Loss of frame 17018
LOP Loss of pointer—path 17019
LOS Loss of signal 17020
RAI Remote failure indication—line 17021
Reported in the Notification)
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-97
Page 98
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-31 CTM GateWay/CORBA Mapping for the ONS 15600 SONET R1.3.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
RAI Remote failure indication—path 17022
BER_SD BER threshold exceeded for signal degrade—line 17023
BER_SD BER threshold exceeded for signal degrade—path 17024
ENV Far-end BER threshold passed for signal degrade—ring 17025
ENV Far-end BER threshold passed for signal degrade—span 17026
BER_SF BER threshold exceeded for signal failure—line 17027
BER_SF BER threshold exceeded for signal failure—path 17028
ENV Far-end BER threshold passed for signal failure—ring 17029
ENV Far-end BER threshold passed for signal failure—span 17030
UNIDENTIFIED Payload defect indication—path 17031
UNEQ Unequipped—path 17032
UNIDENTIFIED Don’t use for synchronization 17033
UNIDENTIFIED Failed to receive synchronization status message 17034
UNIDENTIFIED Synchronization status messages are disabled on this interface 17035
UNIDENTIFIED Primary reference source—stratum 1 traceable 17036
UNIDENTIFIED Reserved for network synchronization use 17037
UNIDENTIFIED SONET minimum clock traceable 17038
UNIDENTIFIED Stratum 2 traceable 17039
UNIDENTIFIED Stratum 3 traceable 17040
UNIDENTIFIED Stratum 3E traceable 17041
UNIDENTIFIED Stratum 4 traceable 17042
UNIDENTIFIED Synchronized—traceability unknown 17043
UNIDENTIFIED Transit node clock traceable 17044
UNIDENTIFIED Fifth synchronization reference failure 17045
UNIDENTIFIED Fourth synchronization reference failure 17046
UNIDENTIFIED Synchronization reference frequency out of bounds 17047
UNIDENTIFIED Primary synchronization reference failure 17048
UNIDENTIFIED Secondary synchronization reference failure 17049
UNIDENTIFIED Sixth synchronization reference failure 17050
UNIDENTIFIED Third synchronization reference failure 17051
TIM STS path trace identifier mismatch 17052
ENV NE power failure at connector A 17053
ENV NE power failure at connector B 17054
EQPT Power fuse failure 17055
ENV Failure detected external to the NE 17056
Reported in the Notification)
A-98
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Page 99
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Table A-31 CTM GateWay/CORBA Mapping for the ONS 15600 SONET R1.3.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
UNIDENTIFIED Extra traffic preempted 17057
UNIDENTIFIED Free running synchronization mode 17058
UNIDENTIFIED Stratum 3E fast start synchronization mode 17059
UNIDENTIFIED Holdover synchronization mode 17060
UNIDENTIFIED Autonomous messages inhibited 17061
UNIDENTIFIED Autonomous PM report message inhibited 17062
ENV Airflow failure 17063
EQPT Equipment fails to boot 17064
UNIDENTIFIED Connection ID mismatch on CXC 0 17065
UNIDENTIFIED Connection ID mismatch on CXC 1 17066
EQPT Clock module failure 17067
EQPT Control bus failure—TSC 0 17068
EQPT Control bus failure—TSC 1 17069
EQPT Clock bus failure—TSC 0 17070
EQPT Clock bus failure—TSC 1 17071
EQPT Control communication equipment failure 17072
EQPT Primary nonvolatile backup memory failure 17073
EQPT Manufacturing data memory (EEPROM) failure 17074
EQPT Payload bus failure—CXC 0 17075
EQPT Payload bus failure—CXC 1 17076
UNIDENTIFIED CXC operations suspended 17077
EQPT Equipment failure 17078
EQPT Equipment failure—high temperature 17080
EQPT Invalid MAC address 17081
UNIDENTIFIED Failure to switch to protection—path 17083
UNIDENTIFIED Failure to switch to protection—ring 17084
UNIDENTIFIED Failure to switch to protection—span 17085
EQPT Fan failure 17086
EQPT Partial fan failure—speed degradation 17087
EQPT Partial fan failure—parts failure 17088
EQPT Clock module frequency mismatch 17089
UNIDENTIFIED OSPF hello fail 17090
EQPT Laser bias current high 17091
EQPT High laser temperature 17092
UNIDENTIFIED Different software version 17093
Reported in the Notification)
Probable Cause Mapping
OL-14253-01
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
A-99
Page 100
Appendix A Notifications, Fault Management, and Probable Cause Mapping
Probable Cause Mapping
Table A-31 CTM GateWay/CORBA Mapping for the ONS 15600 SONET R1.3.1 (continued)
CTM Internal Index (Not
TMF Mapping NE Native Probable Cause
EQPT Synchronization equipment unavailable 17094
EQPT Unprotected synchronization equipment 17095
EQPT Unprotected matrix equipment 17096
UNIDENTIFIED System upgrade in progress 17097
EQPT Matrix equipment unavailable 17098
UNIDENTIFIED Mismatch of equipment and attributes 17099
ENV Software fault—data integrity fault 17100
UNIDENTIFIED Loopback—cross connect 17101
UNIDENTIFIED Loopback facility 17102
UNIDENTIFIED Loopback payload 17103
UNIDENTIFIED Loopback, terminal 17104
SECURITY_VIOLATION Security—invalid login (see audit trail) 17105
SECURITY_VIOLATION Invalid login attempt threshold exceeded 17106
UNIDENTIFIED Performance monitor threshold crossing alert 17107
EQPT Improper removal 17108
UNIDENTIFIED Both ends of fiber provisioned as east, or both as west 17109
EQPT Equipment power failure 17110
EQPT Equipment power failure at connector A 17111
EQPT Equipment power failure at connector B 17112
EQPT Equipment power failure at return connector A 17113
EQPT Equipment power failure at return connector B 17114
UNIDENTIFIED Automatic system reset 17115
UNIDENTIFIED Automatic path-protection switch caused by AIS 17116
UNIDENTIFIED Automatic path-protection switch caused by LOP 17117
UNIDENTIFIED Automatic path-protection switch caused by PDI 17118
UNIDENTIFIED Automatic path-protection switch caused by SDBER 17119
UNIDENTIFIED Automatic path-protection switch caused by SFBER 17120
UNIDENTIFIED Automatic path-protection switch caused by UNEQ 17121
UNIDENTIFIED Exercise request on ring 17123
UNIDENTIFIED Far-end exercise ring 17124
UNIDENTIFIED Exercise span 17125
UNIDENTIFIED Far-end exercise span 17126
UNIDENTIFIED Force switch request on facility/equipment 17127
UNIDENTIFIED Force switch request on ring 17128
UNIDENTIFIED Force switch request on span 17129
Reported in the Notification)
A-100
Cisco Transport Manager Release 8.5 GateWay/CORBA User Guide and Programmer Manual
OL-14253-01
Loading...
