Cisco Systems MWR-1900-27 User Manual
Regulatory Compliance and Safety Information
for the Cisco MWR 1900 Mobile Wireless Edge
Router
Product Numbers: MWR-1900-27
This document provides international agenc y compliance, safety , and statutory information for the Cisco
MWR 1900 Mobile Wireless Edge Router.
Contents
This document contains the following sections:
• Regulatory Standards Compliance, page 2
• Operating Conditions for Canada, page 5
• Operating Conditions for the European Community, page 6
• Translated Safety Warnings, page 6
• Obtaining Documentation, page 25
• Obtaining Technical Assistance, page 26
Corporate Headquarters:
Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
Copyright © 2002. Cisco Systems, Inc. All rights reserved.
Regulatory Standards Compliance
Regulatory Standards Compliance
The Cisco MWR 1900 router is in compliance with the national and international standards described in
Table 1.
Table 1 Class A Regulatory Standards Compliance
Specification Standard
Regulatory Compliance Products bearing the CE mark indicate
compliance with the 1999/5/EEC directives,
which include the following safety and EMC
standards.
Safety UL/CUL 60950, Third Edition
EN 60950:1992 with amendments 1, 2, and 3
IEC 950:1991 with amendments 1, 2, and 3 with
all national deviations and group differences for
all countries participating in the CB scheme
EMI EN300386:2000
CISPR22 Class A
V-3 Class A (VCCI Japan)
47CFR15 Class A (FCC)
47CFR68 (FCC)
Immunity EN61000 4-2 Electrostatic Discharge
EN61000 4-3 Radiated Susceptibility
EN61000 4-4 Electrical
EN61000 4-5 Surges
EN61000 4-6 Injected RF Swept Immunity
Telecom (E1) TBR12, TBR13
Telecom (T1) TIA/EIA-IS-968
1
JATE
1. For specifics on the Cisco MWR 1900 router JATE approval, see the “JATE Certification” section on
page 5.
The Cisco MWR 1900 router complies with the following standards:
• FCC Class A Compliance, page 3
• FCC Part 68 Notice, page 3
• EMC Environmental Conditions, page 4
• FCC Class A Warning, page 4
• CISPR 22 Class A Warning, page 5
• JATE Certification, page 5
Regulatory Standards Compliance
2
78-13978-03
FCC Class A Compliance
This equipment has been tested and found to comply with the limits for a Class A di gital device, pursuant
to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio-frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in which case users will be
required to correct the interference at their own expense.
Yo u can de termine w hether yo ur equ ipment is causin g interference by turning it off. If the interference
stops, it was probably caused by the Cisco equipment or one of its peripheral devices. If the equipment
causes interference to radio or television reception, try to correct the interference by using one or more
of the following measures:
• Turn the television or radio antenna until the interference stops.
• Move the equipment to one side or the other of the television or radio.
• Move the equipment farther away from the television or radio.
• Plug the equipment into an outlet that is on a different circuit from the television or radio. (That is,
make certain the equipment and the television or radio are on circuits co ntroll ed b y different circuit
breakers or fuses.)
Regulatory Standards Compliance
FCC Part 68 Notice
This equipment complies with Part 68 of the FCC rules and the Technical Requirements for Connection
to the Telephone Network published by ACTA. On the bottom of the this equipment is a label that
contains, among other information, a product identif ier in the format US:5B1DDN AN0006. If requested,
this number must be provided to the telephone company.
If this equipment causes harm to the telephone network, the telephone company will notify you in
advance that temporary discontinuance of service may be required. If advance notice is not practical, the
telephone company will noti fy the custo mer as soon as possib le. A lso, you will b e ad vi sed of y our ri ght
to file a complaint with the FCC if you believe it is necessary.
The telephone company may make changes in its facilities, equipment, operation, or procedures that
could affect the operation of this equipment. If this happens, the telephone company will provide
advance notice in order for you to make the necessary modifications to maintain uninterrupted service.
If you have trouble with this equipment, please contact Cisco Systems for repair and warranty
information. If the trouble is causing harm to the telephone netw ork, the telephone compan y can request
that you remove the equipment from the network until the problem is resolved.
Normally, this equipment will be used in conjunction with FCC approved equipment that limits the
Encoded Analog Content that provides the required Billing Protection.
78-13978-03
FCC Class A Compliance
3
Regulatory Standards Compliance
The facility interface and service order codes are shown in Table 2.
Cisco MWR-1900-27 routers (bearing labeling identification number US:5B1DDNAN0006) comply
with the following requirements:
• FCC Rules and Regulations 47 CFR Part 68
• TIA/EIA/IS-968, Technical Criteria for Terminal Equipment to Prevent Harms to the Telephone
Network, July 2001, as adopted by the Administrative Council on Terminal Attachments (ACTA).
Table 2 Cisco MWR-1900-27 Router Facility Interface and Service Order Codes
Model Name Facility Interface Code Service Order Code Jack Type
VWIC-2MFT-T1-DIR 04DU9-BN/DN/1SN/1KN 6.0Y RJ48C
EMC Environmental Conditions
This equipment is intended to operate under the following environmental conditions with respect to
EMC:
1. In a separate defined location under the user’s control.
2. Earthing and bonding shall meet the requirements of ETS 300 253 or CCITT K27.
Acceptable environmental parameters are listed in Table 3.
Table 3 Environmental Operating P arameters
Parameter Range
Operating Temperature 14 to 131°F (-10 to + 55°C)
Operating Humidity 5 to 90% RH (non-condensing)
Operating Altitude 3000m @ 104°F (40°C)
Operating Vibration 0.41 Grms, 3 to 500 Hz/2 hours per axis
Non-Operational Vibration 1.12 Grms, 3 to 500 Hz/30 minutes per axis
Operating Acoustics < 60 dBa
In addition, if equipment is operated in a domestic environment, interference may occur.
FCC Class A Warning
“Modifying the equipment without Cisco's authorization may result in the equipment no longer
complying with FCC requirements for Class A or Class B d igital de vices. In that e v ent, you r right to use
the equipment may be limited by FCC regulations, and you may be required to correct any interference
to radio or television communications at your own expense.”
[cfr reference 15.21]
For Class A equipment:
“NOTE: This equipment has been tested and found to comply with the limits for a Class A digital de vice,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable pro tection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
EMC Environmental Conditions
4
78-13978-03
the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.”
[cfr reference 15.105]
CISPR 22 Class A Warning
For CISPR22 Class A, the following warning is provided:
Operating Conditions for Canada
Warning
This is a class A product. In a domestic environment, this product may cause radio interference,
in which case the user may be required to take adequate remedial measures.
JATE Certification
The Cisco MWR 1900 router VWIC-2MFT-T1-DIR Voice/WAN interface card meets the Japanese
Approvals Institute for Telecommunication Equipment (JATE) approval:
Table 4 JATE Approval for Cisco MWR 1900 VWIC-2MFT-T1-DIR WAN Interface Card
Model Number Approval Number
VWIC-2MFT-T1-DIR D02-0552JP
Operating Conditions for Canada
78-13978-03
In addition to the warnings and safety guidelines listed in the section “Translated Safety Warnings,” the
following warnings apply to models used in Canada:
• The Canadian Department of Communications label identifies certified equipment. This
certification means that the equipment meets certain telecommunications network protective
operational and safety requirements. The Department does not guarant ee the equipment will operate
to the user’s satisfaction.
• Before installing the equipment, users should ensure that it is permissible to be connected to the
facilities of the local telecommunications company. The equipment must also be installed using an
acceptable method of connection. In some cases, the company’s inside wiring associated with a
single line individual service may be extended by means of a certified connector assembly
(telephone extension cord). The customer should be aware that compliance with the preceding
conditions may not prevent degradation of service in some situations.
CISPR 22 Class A Warning
5
Operating Conditions for the European Community
• Repairs to certified equipment should be made by an authorized Canadian maintenance facility
designated by the supplier. Any repairs or alterations made by the user to this equipment, or
equipment malfunctions, may give the telecommunications company cause to request the user to
disconnect the equipment.
• Users should ensure for their own protection that the electrical ground connections of the power
utility, telephone lines, and internal metallic water pipe system, if present, are connected together.
This precaution may be particularly important in rural areas.
Caution Users should not attempt to make such connections themselves, but should contact the appropriate
electric inspection authority, or electrician, as appropriate.
Operating Conditions for the European Community
The following operating conditions are required within the European Community.
• The ports marked “Ethernet,” “Console,” and “AUX” are SELV circuits.
• SELV circuits should only be connected to other SELV circuits.
Translated Safety Warnings
This section repeats in multiple languages the basic warnings appropriate for the Cisco MWR 1900
router. These warnings can be used with other documents related t o this publ ication. Translations of the
following warnings are included in this section:
• Installation Warning, page 8
• Installation Warning—Qualified Personnel, page 9
• DC Power Connection Warning—Circuit Breaker, page 22
• Jewelry Removal Warning, page 11
• Power Supply Disconnection Warning, page 12
• Power Supply Warning, page 13
• Grounded Equipment Warning, page 14
• Ground Connection Warning, page 15
• Circuit Breaker (15A) Warning, page 16
• Power Cabling Warning, page 17
• Main Disconnecting Device, page 17
• Exposed DC Power Wire Warning, page 18
• Lightning Activity Warning, page 19
• SELV Circuit Warning, page 20
• DC Power Disconnection Warning—Transverter, page 21
• DC Power Connection Warning—Circuit Breaker, page 22
• Chassis Warning—Rack-Mounting and Servicing, page 23
Operating Conditions for the European Community
6
78-13978-03
Translated Safety Warnings
Warning
Waarschuwing
Varoitus
Attention
This warning symbol means danger. You are in a situation that could cause bodily injury. Before
you work on any equipment, be aware of the hazards involved with electrical circuitry and be
familiar with standard practices for preventing accidents. To see translations of the warnings
that appear in this publication, refer to the Regulatory Compliance and Safety Information
document that accompanied this device.
Dit waarschuwingssymbool betekent gevaar. U verkeert in een situatie die lichamelijk letsel
kan veroorzaken. Voordat u aan enige apparatuur gaat werken, dient u zich bewust te zijn van
de bij elektrische schakelingen betrokken risico's en dient u op de hoogte te zijn va n standaard
maatregelen om ongelukken te voorkomen. Voor vertalingen van de waarschuwingen die in
deze publicatie verschijnen, kunt u het document Regulatory Compliance and Safety Information
(Informatie over naleving van veiligheids- en andere voorschriften) raadplegen dat bij dit
toestel is ingesloten.
Tämä varoitusmerkki merkitsee vaaraa. Olet tilanteessa, joka voi johtaa ruumiinvammaan.
Ennen kuin työskentelet minkään laitteiston parissa, ota selvää sähkökytkentöihin liittyvistä
vaaroista ja tavanomaisista onnettomuuksien ehkäisykeinoista. Tässä julkaisussa esiintyvien
varoitusten käännökset löydät laitteen mukana olevasta Regulatory Compliance and Safety
Information -kirjasesta (määräysten noudattaminen ja tietoa turvallisuudesta).
Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation pouvant
causer des blessures ou des dommages corporels. Avan t de trava iller sur u n éq uipem ent, so yez
conscient des dangers posés par les circuits électriques et familiarisez-vous avec les
procédures couramment utilisées pour éviter les accidents. Pour prendre connaissance des
traductions d’avertissements figurant dans cette publication, consultez le document Regulatory
Compliance and Safety Information (Conformité aux règlements et consignes de sécurité) qui
accompagne cet appareil.
Warnung
Avvertenza
Advarsel
Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu einer
Körperverletzung führen könnte. Bevor Sie mit der Arbeit an irgendeinem Gerät beginnen, seien
Sie sich der mit elektrischen Stromkreisen verbundenen Gefahren und der Standardpraktiken
zur Vermeidung von Unfällen bewußt. Übersetzungen der in dieser V eröffentlichung enthaltene n
Warnhinweise finden Sie im Dokument Regulatory Compliance and Safety Information
(Informationen zu behördlichen Vorschriften und Sicherheit), das zusammen mit diesem Gerät
geliefert wurde.
Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe causare infortuni alle
persone. Prima di lavorare su qualsiasi apparecchiatura, occorre conoscere i pericoli relativi
ai circuiti elettrici ed essere al corrente delle pratiche standard per la prevenzione di incidenti.
La traduzione delle avvertenze riportate in questa pubblicazione si trova nel documento
Regulatory Compliance and Safety Information (Conformità alle norme e informazioni sulla
sicurezza) che accompagna questo dispositivo.
Dette varselsymbolet betyr fare. Du befinner deg i en situasjon som kan fø re til personskade. Før
du utfører arbeid på utstyr , må du vare oppmerksom på de faremomentene som elektriske kretser
innebærer, samt gjøre deg kjent med vanlig praksis når det gjelder å unngå ulykker. Hvis du vil
se oversettelser av de advarslene som finnes i denne publikasjonen, kan du se i dokumentet
Regulatory Compliance and Safety Information (Overholdelse av forskrifter og
sikkerhetsinformasjon) som ble levert med denne enheten.
78-13978-03
Translated Safety Warnings
7
Translated Safety Warnings
Aviso
Este símbolo de aviso indica perigo. Encontra-se numa situação que lhe poderá causar danos
físicos. Antes de começar a trabalhar com qualquer equipamento, familiarize-se com os perigos
relacionados com circuitos eléctricos, e com quaisquer práticas comuns que possam prevenir
possíveis acidentes. Para ver as traduções dos avisos que constam desta publicação, consulte
o documento Regulatory Compliance and Safety Information (Informação de Segurança e
Disposições Reguladoras) que acompanha este dispositivo.
¡Advertencia!
Este símbolo de aviso significa peligro. Existe riesgo para su integridad física. Antes de
manipular cualquier equipo, considerar los riesgos que entraña la corriente eléctrica y
familiarizarse con los procedimientos estándar de prevención de accidentes. Para ver una
traducción de las advertencias que aparecen en esta publicación, consultar el documento
titulado Regulatory Compliance and Safety Information (Información sobre seguridad y
conformidad con las disposiciones reglamentarias) que se acompaña con este dispositivo.
Varning!
Denna varningssymbol signalerar fara. Du befinner dig i en situation som kan leda till
personskada. Innan du utför arbete på någon utrustning måste du vara medveten om farorna med
elkretsar och känna till vanligt förfarande för att förebygga skador. Se förklaringar av de
varningar som förkommer i denna publikation i dokumentet Regulatory Compliance and Safety
Information (Efterrättelse av föreskrifter och säkerhetsinformation), vilket medföljer denna
anordning.
Installation Warning
Warning
Waarschuwing
Varoitus
Attention
Warnung
Avvertenza
Advarsel
Aviso
¡Advertencia!
Varning!
Read the installation instructions before you connect the system to its power source.
Raadpleeg de installatie-aanwijzingen voordat u het systeem met de voeding verbindt.
Lue asennusohjeet ennen järjestelmän yhdistämistä virtalähteeseen.
Avant de brancher le système sur la source d'alimentation, consulter les directives
d'installation.
Lesen Sie die Installationsanweisungen, bevor Sie das System an die Stromquelle anschließen.
Consultare le istruzioni di installazione prima di collegare il sistema all’alimentatore.
Les installasjonsinstruksjonene før systemet kobles til strømkilden.
Leia as instruções de instalação antes de ligar o sistema à sua fonte de energia.
Ver las instrucciones de instalación antes de conectar el sistema a la red de alimentación.
Läs installationsanvisningarna innan du kopplar systemet till dess strömförsörjningsenhet.
Installation Warning
8
78-13978-03
Installation Warning—Qualified Personnel
Translated Safety Warnings
Warning
Waarschuwing
Varoitus
Attention
Warnung
Avvertenza
Advarsel
Aviso
Only trained and qualified personnel should be allowed to install, replace, or service this
equipment.
Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door bevoegd
geschoold personeel.
Tämän laitteen saa asentaa, vaihtaa tai huoltaa ainoastaan koulutettu ja laitteen tunteva
henkilökunta.
Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de c es
équipements à des personnels qualifiés et expérimentés.
Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem,
qualifiziertem Personal gestattet werden.
Questo apparato può essere installato, sostituito o mantenuto unicamente da un personale
competente.
Bare opplært og kvalifisert personell skal foreta installasjoner, utskiftninger eller service på
dette utstyret.
Apenas pessoal treinado e qualificado deve ser autorizado a instalar, substituir ou fazer a
revisão deste equipamento.
¡Advertencia!
Varning!
Solamente el personal calificado debe instalar, reemplazar o utilizar este equipo.
Endast utbildad och kvalificerad personal bör få tillåtelse att installera, byta ut eller reparera
denna utrustning.
Restricted Area Warning
Invisible laser radiation when this component is opened and the preregulation is disabled. Do not look into
the laser beam.
78-13978-03
Installation Warning—Qualified Personnel
9
Loading...
