Cisco Systems DS71-MD4, BayTech DS User Manual

DS Series Manual

DATA SWITCH

DS71-MD4 Host-Modem Module

BayTech Manual Publication

Revision May 2008

Copyright 2007 by Bay Technical Associates, Inc.

BayTech, is a registered trademarks of Bay Technical Associates, Inc.

Windows 2000®, Windows XP® are products and registered trademark of Microsoft Corporation.

Tera Term is a product and registered trademark of Vector, Inc.

DS71-MD4 Serial host and 56k Modem

ABOUT THIS OWNER’S MANUAL..........................................................................................................4

Connection Description.........................................................................................................................4

EIA-232 SERIAL CONNECTION.......................................................................................................5

Internal MODEM CONNECTION.......................................................................................................5

External Modem Connection.............................................................................................................5

Installation.................................................................................................................................................5

Power....................................................................................................................................................6

QUICK START: DS71-MD4 Module.........................................................................................................6

Serial Setup...........................................................................................................................................6

Main Menu ............................................................................................................................................7

Login Setup .......................................................................................................................................8

Local Modem Option .......................................................................................................................10

Cabling ...................................................................................................................................................10

RJ-45 Cables and Adapters................................................................................................................10

Adapters..............................................................................................................................................11

Detailed Operation and Configuration ....................................................................................................13

DS71-MD4 Main Menu........................................................................................................................13

Configuration Menu .............................................................................................................................13

Host Module Configuration..............................................................................................................13

Configuration Status ....................................................................................................................14

Serial Port Configuration ..............................................................................................................16

Port Device Name........................................................................................................................18

Port Select Code ..........................................................................................................................18

Attention Character......................................................................................................................18

Disconnect Timeguard.................................................................................................................19

Connect port ID Echo...................................................................................................................19

Login Setup..................................................................................................................................19

Header......................................................................................................................................20

Access Control.........................................................................................................................20

Menu ........................................................................................................................................20

Manage Users..........................................................................................................................20

Auto Connect............................................................................................................................22

Dial-Back Number....................................................................................................................22

Assign User Ports.....................................................................................................................23

Local Modem Option....................................................................................................................24

Ring to Answer.........................................................................................................................24

Connectivity Timeout................................................................................................................24

Inactivity Timeout .....................................................................................................................24

Unit ID..........................................................................................................................................25

I/O modules Reset ..............................................................................................................................25

Unit Reset ...........................................................................................................................................25

Troubleshooting:.....................................................................................................................................25

Functional Solutions:...........................................................................................................................25

DS71-MD4 Reset Procedure ..............................................................................................................27

BayTech Product Warranty.....................................................................................................................27

Technical Support...............................................................................................................................28

Return Authorization Process: ............................................................................................................29

3

DS71-MD4 Serial host and 56k Modem

ABOUT THIS OWNER’S MANUAL

This document provides information required for installing and operating your Bay Tech equipment. It
should allow the user to connect to, power up, and access an applications menu where peripheral
equipment can be controlled. We recommend reading this manual carefully, while placing special
emphasis on correct cabling and configuration. If you have any problems with your installation, please
contact BayTech’s Technical Support at 228-563-7334, call toll free from anywhere in the United States
using 1-800-523-2702 or contact us at our Web Site, www.baytech.net.

BayTech manufactures many remote site management products, data switches, data collection
multiplexers, and remote power controllers. If you would like information on any of these products,
please contact BayTech Customer Service at the above numbers or visit our web site.

Conventions used in this manual include:

• CAUTION: This term is used to denote any condition that could possibly result in physical

harm to personnel or damage to equipment.

• IMPORTANT: This term is used to denote conditions that could result in the loss of

communications or to highlight the proper functioning of equipment.

• NOTE: This term is used to denote items of interest to the user.

• <cr>: Carriage Return or ENTER

The information in this document is subject to change without notice. The statements, configurations,
technical data, and recommendations in this document are believed to be accurate and reliable, but are
presented without express or implied warranty. Users must take full responsibility for their applications
of any products specified in this document. The information in this document is proprietary to Bay
Technical Associates, Inc.

In the interest of improving internal design, operational function, and/or reliability, Bay Technical
Associates, Inc reserves the right to make changes to the products described in this document without
notice.

Bay Technical Associates, Inc does not assume any liability that may occur due to the use or application
of the product(s) or circuit layout(s) described herein.

BayTech units are in accordance with the general requirements of Standard for Information Technology
Equipment (ETL listed, conforms to ANSI/UL STD 60950-1-2003 CERTIFIED CAN/CSA C22.2 NO.
60950-1-03, UL STD 231 8TH EDITION, UL STD 1950 3RD EDITION CERTIFIED CAN/CSA 22.2
NO. 950-95, CE conforms to IEC 60950-1).

We welcome any comments you may have about our products, and we hope that you will continue to
look to BayTech for your data communication needs.

Connection Description

BayTech's DS71-MD4 host communication modem module provides an interface that controls user
access to the DS Series data switch and other DS Series connected modules. The DS71-MD4 is a system
data controller that directs operations between the base unit, system modules and externally connected
devices.

4

DS71-MD4 Serial host and 56k Modem

EIA-232 SERIAL CONNECTION

The DS-Series host communications modules have an RJ-45 port which uses an 8-pin crossed modular
cable to connect to a local EIA-232 device such as a computer terminal or external modem. Most serial
computers do not have RJ-45 connections; therefore an adapter is provided with this unit to convert from
a DE-9 connector to an RJ-45 connector (Bay Tech Part No. 9FRJ45PC-4). An adapter to convert from a
DB-25 connector to an RJ-45 connector is also available from Bay Tech, upon request (Bay Tech Part
No. 25FRJ45PC-4). The 8-pin crossed modular cable is configured to operate with these adapters.
Configure serial communications parameters for the host terminal to match the DS71-MD4 module. The
modules have factory serial communications parameters of 9600 bps, 8 data bits, 1 stop bit, no parity,
XON/XOFF disabled.

Internal MODEM CONNECTION

The DS71-MD4 Host Communications Module has a Flash upgradeable 56 Kbps (V.90bis) modem
which allows two RJ-11 ports connected to standard dial-up telephone lines to be used between the Data
Switch unit and the user's Telco wall jack using a standard RJ-11 straight through cable. These ports are
in parallel and the second port is available for another Telco device using communications software, dial
the modem using the ATDT command.

IMPORTANT: The DS71-MD4 modem option has priority over the EIA-232 serial port. If a serial port
user is in configuration mode or connected to a DS74 I/O port when a modem connection is established,
the serial port user will be “booted” off, allowing the remote user to communicate with the DS unit.

External Modem Connection

Using the 25MRJ45MD-6 adapter (or other applicable adapter) and the RJ08X007 crossed cable,
connect the COM (or serial) port of the modem to the RJ-45 port labeled EIA-232 on the DS71-MD4
module. Using an RJ04X007 (RJ-11) modular cable, connect the port labeled “LINE” on the modem to
the Telco wall jack. The 25MRJ45MD-6 is not shipped with unit but is available upon request at time of
purchase.

Installation

UNPACKING

Compare the unit and serial number of the equipment you received to the packing slip located on the
outside of the box. Inspect equipment carefully for damage that may have occurred in shipment. If there
is damage to the equipment or if materials are missing, contact BayTech technical support at 228-563-
7334 or call toll free inside the United States at 800-523-2702. At a minimum, you should receive the
following:

1. The DS71-MD4 Module.

2. Manual insert describing the location of the User’s Guide on BayTech’s website at

www.baytech.net

3. Power Cords that may be attached to the unit (if order requested detachable cords).

4. 1 ea. DE-9 (9 pin) PC com port adapter -- 9FRJ45PC (with Cisco Interface) or 9FRJ45PC-1.

5. 1 ea. RJ-45 Roll over cable -- RJ08X007.

NOTE: Keep the shipping container and packing material in the event future shipment is
required.

.

5

DS71-MD4 Serial host and 56k Modem

Power

CAUTION: This unit is intended for indoor use only. Do not install near water or expose this unit to
moisture. To prevent heat buildup, do not coil the power cord when in use. Do not use extension cords.
Do not attempt to make any internal changes to the power source. Do not attempt to modify any portion
or component of a DS-Series Data Switch unless specifically directed to; as in Appendix E of this
manual. BayTech must perform any internal changes.

CAUTION: High-voltage surges and spikes can damage this equipment. To protect from such power
surges and spikes, this unit must have a good earth ground. A grounding screw connection is located
near the power switch on the back of the unit.

CAUTION: Before removing or replacing any modules, turn off main power switch located on the DS­Series Base Unit. Communication to the DS-Series Data Switch will be disrupted while power is off.

QUICK START: DS71-MD4 Module

by Bay Technical Associates

For those Administrators who have requested the bare minimum for this type of equipment, follow these
steps exactly. If this is a new unit shipped directly from Baytech, follow the steps. If this is a previously
own unit, perform a factory reset to clear out any users and passwords still in the unit.

Serial/Modem Configuration:

1. Connect the 9FRJ45PC-4 or 9FRJ45PC-1 adapter to your PC.

2. Connect the supplied rollover flat cable RJ08X007 to the adapter and to the EIA232 serial port
on the Baytech DS71-MD4 Module.

3. Use terminal emulation software to access the unit, (i.e. Microsoft Hyper-terminal). Set the PC
serial port configuration to the following: 9600 bps, 8 data bits, 1stop bit and no parity.

4. If you get only a blinking cursor Press ‘Enter’. If still only a blinking cursor, Type 5 semi-colons
(;),The Attention Character will not echo on the screen. There is a one second delay before the
menu is displayed. You should see a menu similar to (Figure 1).

5. Select ‘C’ for the configuration menu.

6. Select the DS71-MD4 module. You should see a menu similar to (Figure 2).

7. Select the number for ‘Login Setup’ option. You should see a menu similar to (Figure 3).

8. Select the number for ‘Manage Users’ option. You should see a menu similar to (Figure 4).

9. NOTE: The ‘admin’ user can not be deleted.

10. Select ‘A’ to add user. Type the name and password at the prompts.

11. Press ‘Enter’ until get to the ‘Login Setup Menu’ (Figure 3).

12. Select option ‘Access Control’ to enable or disable the Modem and Serial Login Prompts.

13. Press ‘Enter’ until get to the ‘Login Setup Menu’ (Figure 3).

14. Select option ‘Assign User Ports’ (Figure 5).

15. Select the user and add the ports.

16. Press ‘Enter’ until you get the Configuration menu (Figure 2).

17. Select ‘Serial Port Configuration’ and set up the modem configuration.

At this point you have setup enough basic configurations to operate this Baytech unit.

Serial Setup

• Connect the 9FRJ45PC-4 adapter to the user’s computer

6

DS71-MD4 Serial host and 56k Modem

• Connect the Host Module’s EIA-232 port to the adapter via the RJ08X007 rolled flat ribbon
cable.

• Default configuration is 9600 bps, 8 data bits, 1 stop bit and no parity.

NOTE: At any time during the session you need to go to another menu, use the Attention
Character = semi-colon (;). Press the attention character key 5 consecutive times to get back to the

main status menu.
NOTE: Depending on the DS-Series model, the menus will vary according to the number of DS74

modules installed in the unit. If this is not an initial set-up and Password has already been enabled,
you are prompted to login. After logging in successfully, invoke the main menu by sending the
attention character five times (;;;;;).

NOTE: Password feature is case sensitive. (Default is user/password is root/baytech)

Main Menu

The following Header and Menu appears or similar:

Figure 1

Data Switch Series - F.1.04.00
Bay Technical Associates
Unit ID: DS71-MD4
Attention Character: ;
Module 1: admin on Host EIA-232

Device A (3,1).................1

Device B (3,2).................2

Device C (3,3).................3

Device D (3,4).................4

DS-RPC (5,1).................5

Configuration .........................C

I/O Modules Reset .....................RM

Unit Reset ............................RU

Exit ..................................X

Logout ................................T

Enter Request :

Select option ‘C’ for the configuration menu. Select the DS71-MD4 module option and the following
menu is displayed:

7

DS71-MD4 Serial host and 56k Modem

Figure 2

Copyright(C) Bay Technical Associates 2006
DS71-MD4 Data Switch Series - V90 Modem Host Module
Revision F.1.01.01
Module 2

Status .........................1

Serial Port Configuration.......2

Port Device Name................3

Port Select Code................4

Attention Character.............5

Disconnect Timeguard............6

Connect port ID Echo ...........7

Login Setup ....................8

Local Modem Option .............9

Unit ID ........................U

Exit ........................X, CR

Enter Request :

Login Setup

This menu allows the user to enable or disable the Header, Access Control, Menu, Manage Users, Auto
Connect, Dial Back Number, and Assign User Ports.

Figure 3

Login Setup:

Header .......................1 Enable/Disable header for each menu

Access Control ...............2 Enable/Disable Network/Serial port user name

and password.

Menu .........................3 Enable menu on startup or 5 attention Char.

Manage Users .................4 Add/Delete users and change passwords.

Auto Connect .................5 Auto connect to module and port on power-up,

Has priority over setup menu, Disables the

menu selection screen on initial login.

Dial Back Number .............6 Have the modem to dial back the user

Assign User Ports ............7 Assign users to specific ports

Exit ......................X,CR Returns to previous menu

Enter Request :

Header

This allows the admin to have enable or disable Header upon connection to the host module.

Access Control

This security feature allows the admin to enable or disable usernames and passwords for both serial and
modem port access.

Menu

This allows the admin to enable or disable the Menu on start up. The default user and password is
“admin/baytech”, all lower case.

8

DS71-MD4 Serial host and 56k Modem

Manage Users

This option allows the administrator to change user passwords or add/delete new users. Up to 19 users
plus an administrator allowed. Usernames are case sensitive and alphanumeric.

Figure 4

User Management Menu:

”admin” .............................. 1

Add New User ..........................A

Delete User ...........................D

Change User ...........................C

To change user password, enter number of user
Enter Request :1

Auto Connect

This feature allows the admin to select the module and port that the user will be automatically connected
on dial-in.

Dial-Back Number

This allows user to dial in, hang up and the unit dials the assigned number back when using a secure
phone line.

Assign User Ports

This option allows the administrator to limit users’ port access.

Figure 5

Assigned User Ports:
+----+----------* +-M3-+-M4-+-M5-+
|User| Name \|1234|1234|1234|
+----+------------*----+----+----+
| 2 | johnt |x234|123x|1xx4|
+----+------------*----+----+----+

Add Port(s)............................1 Adds individual ports

Remove Ports(s)........................2 Removes individual ports

Add All Ports..........................3 Add All

Remove All Ports.......................4 Remove All

Exit ..................................X,CR

Enter Request :1

9
