Cisco Model DPC3941B DOCSIS 3.0 24x4
Wireless Business Gateway
If you’re looking for a cost-effective, high performance networking gateway for a small
office, you’ve just found it. The Cisco
Business Gateway is multiple solutions in one product. It combines a cable modem, a
router, and 802.11ac wireless access points in a single device. The gateway delivers
a faster connection to the Internet by incorporating 24 bonded downstream channels
along with four bonded upstream channels. The bonded channels can deliver
downstream data rates that exceed 900 Mbps and upstream data rates that exceed
120 Mbps. Downstream rates are up to 24 times faster than conventional
single-channel DOCSIS® 2.0 cable modem rates.
®
Model DPC3941B DOCSIS 3.0 24x4 Wireless
The Cisco Model DPC3941B Business Gateway (Figure 1) is designed to meet DOCSIS 3.0 specifications and
backward compatibility for operation in DOCSIS 2.0, 1.1, and 1.0 networks.
Figure 1. Cisco Model DPC3941B DOCSIS 3.0 24x4 Wireless Business Gateway
(Image Below May Vary from Actual Product)

© 2015 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 2 of 7
Power, DS/US, Online, WiFi1, WiFi2, Tel1, Tel2, and Battery
Black, black lens, and silver text
Xfinity and Comcast model name
The integrated router features a Dynamic Host Configuration Protocol (DHCP) server, Network Address
Translation (NAT), Network Address Port Translation (NAPT), and a stateful packet inspection (SPI) firewall. These
features allow the user to share a single high-speed public Internet connection and to share files and folders
between devices in the home network by attaching multiple wired and wireless devices in the active home or office
to the wireless Business gateway.
Consumer-friendly features like Wireless Protected Setup (WPS) and user-configured parental controls can protect
the home network from unwelcome intruders and protect family members from access to undesirable websites.
Features
DOCSIS
●
Compliant with DOCSIS 3.0, 2.0, 1.1, and 1.0 standards to deliver high-end performance and reliability
Connections
●
Four 10/100/1000BASE-T Ethernet ports to provide wired connectivity
●
High-performance broadband Internet connectivity
●
Optional: Two USB 2.0 Type 2 connections
●
Dual-band concurrent 802.11ac Wireless Access Point (WAP) with eight Service Set Identifiers (SSIDs)
compatible with 802.11b/g/n
●
WPS, including a push-button switch to activate WPS for simplified and highly secure wireless setup
Design and Function
●
Attractive, compact design and versatile orientation to stand vertically
●
LED status indicators on the front panel, providing an informative and easy-to-understand display that
indicates the operational status
●
TR-068-compliant, color-coded interface ports and corresponding cables that simplify installation and setup
Management
●
User-configurable parental controls that block access to undesirable Internet sites
●
Advanced firewall technology that deters hackers and protects the home network from unauthorized access
●
Automatic software upgrades by your service provider allowed
Software and Documentation
●
User guide and optional USB driver installation software that can be downloaded from Cisco.com
Table 1. Front-Panel Features

© 2015 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 3 of 7
Black, black lens, and silver text
Figure 2. Cisco Model DPC3941B Business Gateway Top Panel
(Image Below May Vary from Actual Product)
Table 2. Top-Panel Features
Figure 3. Cisco Model DPC3941B Business Gateway Back Panel
(Image Below May Vary from Actual Product)

© 2015 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 4 of 7
Performs a soft configuration reset of the Cisco Model DPC3941B.
USB Connector color: blue
Optional (2): Each Type 2 USB 2.0 port connects to a USB port on a printer or another USB device.
ETHERNET (1- 4) Connector
color: yellow
Four RJ-45 Ethernet ports connect to the Ethernet port on your PC or your home network.
POWER Connector color:
black
Connection for AC power input 120 VAC.
6 internal Antenna's. 3 for 2.4 and 3 for 5 GHz. and 802.11ac.
Manufacturer label
Color: white with black text
Label with key manufacturing information, such as the part number, serial number, CM MAC address, MTA
MAC address, and WAN MAC address
Battery compartment for a 10.8V lithium-ion, 2600 mAh rechargeable battery
Note: 3000mAh battery available as well.
Battery does not ship with gateway but can be ordered separately)
Gateway configuration
management
● TR-069 and subset of TR-098 data model (optional)
● Extensive custom SNMP MIB for the gateway
● Provisioning with SNMP
● HNAP server 1.2+
Independent Computer
Security Association (ICSA)
firewall compliant
● Web filtering: pop-ups, cookies, Java, and ActiveX scripts
● Intrusion detection and prevention: WAN ping blocking, IP fragment blocking, port scan detection, TCP port
probe, and UDP port probe
● DoS protection: inbound, outbound, WAN interface, LAN interface, SYN flood, Ping of Death, Smurf, Bonk,
Jolt, Land, Nestea, Newtear, Syndrop, Teardrop, WinNuke, and OOBNuke (invalid TCP urgent pointer),
x1234, Saihyousen, Oshare, ARP flood, TCP hijacking, Christmas Tree, SYN/FIN (jackal), BackOffice (UDP
32337), NetBus, and ICMP flooding
● IP address, port number, and MAC address filtering
● TCP flags and ICMP types fragmentation
● Connection creation and teardown
● Timestamps and payload modification
● Per-user policies
● Keyword blocking
● Domain name blocking
● Time of day filters
● MAC address filtering
Table 3. Back-Panel Features
Figure 4. Cisco Model DPC3941B Business Gateway Bottom Panel
(Image Below May Vary from Actual Product)
Table 4. Bottom-Panel Features
Product Specifications

© 2015 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 5 of 7
● Filtering activity
● Session tracking
● User notification through email alert and SNMP traps
● NAPT, NAT, and pass-through (Layer 2) operational modes
● RFC3489 (STUN) "port-restricted cone NAT" behavior
● RIP v1/v2 with MD5
● Static routes
● Port forwarding
● Port triggering
● UPnP IGD 1.0
● IPSec pass-through
● L2TP pass-through
● PPTP pass-through
● ALG support: mIRC, PIRCH, MS NetMeeting, Net2phone, AOL and MSN Messenger, Yahoo Messenger,
Go2Call, Hotline Server, Visual IRC, CuSeeme, AT&T Instant, Messenger Anywhere, Active Worlds, Buddy
Phone Calista IP Phone, Delta Three PC to Phone, Dial Pad, Dwyco Video Conferencing, OrbitRC, Xircon,
Netscape Chat, FTP, H.323, and ICQ
● 3x3 2.4 and 5 GHz dual-band, concurrent wireless access point
● 6 internal antennas
● Wi-Fi-compliant security (WPA2-Enterprise, WPA2-PSK, WPA-Enterprise, WPA-PSK, and WEP)
● Wireless multimedia quality of service (WMM-QoS)
● WMM power save
● WPS
● Wireless bridging- Wireless Distribution System (WDS)- that allows connection to “range extender products”
● RADIUS authentication (client, EAP-TLS, EAP-TTLS, EAP-PEAP, and EAP-MD5)
● MBSSID (8 SSIDs with unique NAT scopes per radio)
● Wi-Fi "hot spot" support (static DHCP IP scope over tunnel)
Operating frequency range
(1) frequency agile block tuner, full-band capture
8 demodulators, each demodulator: 64 QAM or 256 QAM
● 8 downstream channels, each 6 MHz channel: UP to 24 downstream channels
42.88 Mbps for 256 QAM and 30.34 Mbps for 64 QAM
Operating frequency range
5 to 42 MHz (optional 5 to 65 MHz, or 5 to 85 MHz)
QPSK, 8 QAM, 16 QAM, 32 QAM, 64 QAM or ATDMA, and 128 QAM or SCDMA

© 2015 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 6 of 7
Maximum data rate per
channel
QPSK
16 QAM
QPSK
16 QAM
32 QAM
64 QAM
16 QAM
32 QAM
64 QAM
1.6
1.6
3.2
3.2
3.2
3.2
6.4
6.4
6.4
2.56
5.12
5.12
10.2
12.8
15.4
20.5
25.6
30.7
Maximum operating level
TDMA
SCDMA
QPSK
8 QAM
16 QAM
32 QAM
64 QAM
QPSK
8 QAM
16 QAM
32 QAM
64 QAM
128 QAM
+61 dBmV
+58 dBmV
+58 dBmV
+57 dBmV
+57 dBmV
+56 dBmV
+56 dBmV
+56 dBmV
+56 dBmV
+56 dBmV
+56 dBmV
+58 dBmV
+55 dBmV
+55 dBmV
+54 dBmV
+54 dBmV
+53 dBmV
+53 dBmV
+53 dBmV
+53 dBmV
+53 dBmV
+53 dBmV
+55 dBmV
+52 dBmV
+52 dBmV
+51 dBmV
+51 dBmV
+53 dBmV
+53 dBmV
+53 dBmV
+53 dBmV
+53 dBmV
+53 dBmV
Power consumption
(modem module)
Gigabit Ethernet (auto-negotiate with auto-MDIX): RJ-45 Ethernet (4)
Optional with some part numbers: USB 2.0 and USB Type 2 (2)
0 to 95% RH noncondensing
-4 to 158˚F (-20 to 70˚C)
Designed to meet the
following standards
DOCSIS 3.0
IEEE 802.11ac
WPA2, WPA, and WEP
WMM, WPS
Regulatory and safety
approvals
As required per country where the Cisco Model DPC3941B will be used.

© 2015 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 7 of 7
Cisco Model DPC3941B DOCSIS 3.0 8x4 Wireless Business Gateway. Includes:
● 802.11ac Wireless Access Point, dual-band concurrent 3x3
● Power cord, North America (nonpolarized)
Power cord, 2 conductors, NEMA 1-15 to C7, North America (polarized)
2600 mAh Lithium-Ion battery
3000 mAh Lithium-Ion battery
Printed in USA C78-734440-00 04/15
Ordering Information
To place an order, visit the Cisco Ordering Home Page and refer to Table 5 and Table 6.
Table 5. Ordering Information
Optional & Replacement Components Ordering Information
Table 6. Optional & Replacement Components
