Cisco Systems DPC3008CC User Manual
User Guide
Linksys DPC3008/EPC3008
Cable Modem
Linksys DPC3008/EPC3008
Contents
Contents
Notices
About this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Where to find more help . . . . . . . . . . . . . . . . . . . . . . . . . .1
Software and firmware use . . . . . . . . . . . . . . . . . . . . . . . .1
Important Safety Instructions
Notice to installers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Important safety instructions . . . . . . . . . . . . . . . . . . . . . . .3
Regulatory compliance statements . . . . . . . . . . . . . . . . . . .5
CE compliance 6
Product Overview
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
DOCSIS 8
Connections 8
Design and function 8
Management 9
Front panel 9
Back panel 9
Installing Your Modem
Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
System requirements for Internet service 10
Getting a high-speed Internet account 10
If you already have a high-speed Internet account 10
Modem information 10
Positioning your modem. . . . . . . . . . . . . . . . . . . . . . . . . 10
Wall-mounting the modem (optional) 11
Installing the modem . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connect devices to the modem 12
Connect the modem 13
Understanding the Front Panel
Indicators
Indicator charts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Normal operations (power up) 14
Normal operations (AC power applied) 14
Special conditions 14
FAQs and Troubleshooting
Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . 15
Common troubleshooting issues 17
Tips for improved performance 18
i
i
Linksys DPC3008/EPC3008
Notices
Notices
About this guide
This guide provides instructions and recommendations for installing,
configuring, operating, maintaining, and troubleshooting the DPC3008 and
EPC3008 DOCSIS 3.0 cable modems.
All features described in this guide are standard to these models of cable
modems unless otherwise noted. For the purpose of this guide, whenever
a feature or option applies to only a specific model, the model number is
specified. If a model number is not specified, then the feature or option applies
to both of the models.
Where to find more help
In addition to this User Guide, you can find help at Linksys.com/support.
Software and firmware use
Important Safety Instructions
Notice to installers
The servicing instructions in this notice are for use by qualified service personnel
only. To reduce the risk of electric shock, do not perform any servicing other
than that contained in the operating instructions, unless you are qualified to
do so.
The software described in this document is protected by copyright law and
furnished to you under a license agreement. You may only use or copy this
software in accordance with the terms of your license agreement.
The firmware in this equipment is protected by copyright law. You may only
use the firmware in the equipment in which it is provided. Any reproduction or
distribution of this firmware, or any portion of it, without our express written
consent is prohibited.
1
1
Linksys DPC3008/EPC3008
Notice à l’attention des installateurs de réseaux
câblés
Les instructions relatives aux interventions d’entretien, fournies dans la
présente notice, s’adressent exclusivement au personnel technique qualifié.
Pour réduire les risques de chocs électriques, n’effectuer aucune intervention
autre que celles décrites dans le mode d’emploi et les instructions relatives au
fonctionnement, à moins que vous ne soyez qualifié pour ce faire.
Important Safety Instructions
Aviso a los instaladores de sistemas CATV
Las instrucciones de reparación contenidas en el presente aviso son para uso
exclusivo por parte de personal de mantenimiento cualificado. Con el fin de
reducir el riesgo de descarga eléctrica, no realice ninguna otra operación de
reparación distinta a las contenidas en las instrucciones de funcionamiento, a
menos que posea la cualificación necesaria para hacerlo.
Mitteilung für CATV-Techniker
Die in dieser Mitteilung aufgeführten Wartungsanweisungen sind ausschließlich
für qualifiziertes Fachpersonal bestimmt. Um die Gefahr eines elektrischen
Schlags zu reduzieren, sollten Sie keine Wartungsarbeiten durchführen, die
nicht ausdrücklich in der Bedienungsanleitung aufgeführt sind, außer Sie sind
zur Durchführung solcher Arbeiten qualifiziert.
2
Linksys DPC3008/EPC3008
Important Safety Instructions
Important safety instructions
1.
Read these instructions.
2.
Keep these instructions.
3.
Heed all warnings.
4.
Follow all instructions.
5.
Do not use this apparatus near water.
6.
Clean only with dry cloth.
7.
Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8.
Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9.
Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement
of the obsolete outlet.
10.
Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11.
Only use attachments/accessories specified by the manufacturer.
12.
Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to
avoid injury from tip-over.
13.
Unplug this apparatus during lightning storms or when
unused for long periods of time.
14.
Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as a powersupply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
Power source warning
A label on this product indicates the correct power source for this product.
Operate this product only from an electrical outlet with the voltage and
frequency indicated on the product label. If you are uncertain of the type of
power supply to your home or business, consult your service provider or your
local power company.
The AC inlet on the unit must remain accessible and operable at all times.
Ground the product
WARNING
Avoid electric shock and fire hazard! If this product connects to
coaxial cable wiring, make sure the cable system is grounded
(earthed). Grounding provides some protection against voltage
surges and built-up static charges.
Outdoor grounding system
If this product connects to an outdoor antenna or cable system, be sure the
antenna or cable system is grounded (earthed). This provides some protection
against voltage surges and built-up static charges.
Article 810 of the National Electric Code (NEC) ANSI/NFPA No. 70-1990, provides
the following information:
• Grounding of the mast and supporting structure
• Grounding the lead-in wire to an antenna discharge unit
• Size of the grounding conductors
• Location of the antenna-discharge unit
• Connection to grounding electrodes
• Requirements for the grounding electrodes (see the following antenna
grounding diagram as recommended by NEC ANSI/NFPA 70)
3
Linksys DPC3008/EPC3008
Important Safety Instructions
WARNING
Avoid electric shock and fire hazard! Do not locate an outside
antenna system in the vicinity of overhead power lines or power
circuits. Touching power lines or circuits might be fatal.
Eliminate AC mains overloads
WARNING
Avoid electric shock and fire hazard! Do not overload AC mains,
outlets, extension cords, or integral convenience receptacles.
For products that require battery power or other power sources
to operate them, refer to the operating instructions for those
products.
Provide ventilation and select a location
• Remove all packaging material before applying power to the product.
• Do not place this product on a bed, sofa, rug, or similar surface.
• Do not place this product on an unstable surface.
• Do not install this product in an enclosure, such as a bookcase or rack,
unless the installation provides proper ventilation.
• Do not place entertainment devices (such as VCRs or DVDs), lamps,
books, vases with liquids, or other objects on top of this product.
• Do not block ventilation openings.
Protect the product from lightning
In addition to disconnecting the AC power from the wall outlet, disconnect the
signal inputs.
Verify the power source from the On/Off power light
When the on/off power light is not on, the modem may still be connected to the
power source. The light may go out when the modem is turned off, regardless
of whether it is still plugged into an AC power source.
4
Linksys DPC3008/EPC3008
Important Safety Instructions
Protect from exposure to moisture and foreign
objects
WARNINGS
• Avoid electric shock and fire hazard! Do not expose this
product to dripping or splashing liquids, rain, or moisture.
Objects filled with liquids, such as vases, should not be placed
on this apparatus.
• Avoid electric shock and fire hazard! Unplug this product
before cleaning. Do not use a liquid cleaner or an aerosol
cleaner. Do not use a magnetic/static cleaning device (dust
remover) to clean this product
• Avoid electric shock and fire hazard! Never push objects
through the openings in this product. Foreign objects can
cause electrical shorts that can result in electric shock or fire.
Service warnings
WARNING
Avoid electric shock! Do not open the cover of this product.
Opening or removing the cover may expose you to dangerous
voltages. If you open the cover, your warranty will be void. This
product contains no user-serviceable parts.
Check product safety
Upon completion of any service or repairs to this product, the service
technician must perform safety checks to determine that this product is in
proper operating condition.
Regulatory compliance statements
United States FCC compliance
This device has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against such interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy. If not installed and used in accordance with the instructions, it may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment OFF and ON, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the service provider or an experienced radio/television
technician for help.
Any changes or modifications not expressly approved by Cisco Systems, Inc.,
could void the user’s authority to operate the equipment.
The information shown in the FCC Declaration of Conformity paragraph below
is a requirement of the FCC and is intended to supply you with information
regarding the FCC approval of this device. The phone numbers listed are for FCC-
related questions only and not intended for questions regarding the connection or
operation for this device. Please contact your service provider for any questions you
may have regarding the operation or installation of this device.
Protect the product when moving it
Always disconnect the power source when moving the product or connecting
or disconnecting cables.
5
Loading...
