Cisco D9854/D9854-I Advanced
Program Receiver Software Version
4.50 Installation and Configuration
Guide
Please Read This Entire Guide
Veuillez lire entièrement ce guide
Bitte das gesamte Handbuch durchlesen
Sírvase leer completamente la presente guía
Si prega di leggere completamente questa guida
Im portant
Please read this entire guide before you install or operate this product. Give
particular attention to all safety statements.
Im portant
Veuillez lire entièrement ce guide avant d'installer ou d'utiliser ce produit. Prêtez
une attention particulière à toutes les règles de sécurité.
Zu beachten
Bitte lesen Sie vor Aufstellen oder Inbetriebnahme des Gerätes dieses Handbuch in
seiner Gesamtheit durch. Achten Sie dabei besonders auf die Sicherheitshinweise.
Im portante
Sírvase leer la presente guía antes de instalar o emplear este producto. Preste
especial atención a todos los avisos de seguridad.
Im portante
Prima di installare o usare questo prodotto si prega di leggere completamente questa
guida, facendo particolare attenzione a tutte le dichiarazioni di sicurezza.
Notices
Trademark Acknowledgments
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its
affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this
URL: www.cisco.com/go/trademarks.
Manufactured under license from Dolby Laboratories. Dolby and the double-D
symbol are trademarks of Dolby Laboratories.
The DVB logo is a registered trademark of the DVB Project.
Other third party trademarks mentioned are the property of their respective owners.
The use of the word partner does not imply a partnership relationship between
Cisco and any other company. (1110R)
Publication Disclaimer
Cisco Systems, Inc. assumes no responsibility for errors or omissions that may
appear in this publication. We reserve the right to change this publication at any
time without notice. This document is not to be construed as conferring by
implication, estoppel, or otherwise any license or right under any copyright or
patent, whether or not the use of any information in this document employs an
invention claimed in any existing or later issued patent.
Copyright
© 2014 Cisco and/or its affiliates. All rights reserved.
Information in this publication is subject to change without notice. No part of this
publication may be reproduced or transmitted in any form, by photocopy,
microfilm, xerography, or any other means, or incorporated into any information
retrieval system, electronic or mechanical, for any purpose, without the express
permission of Cisco Systems, Inc.
AVC/MPEG-4/H.264 Products
With respect to each AVC/MPEG-4/H.264 product, Cisco is obligated to provide the
following notice:
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE
FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER TO (i)
ENCODE VIDEO IN COMPLIANCE WITH THE AVC STANDARD ("AVC VIDEO")
AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER
ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR
WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC
VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER
USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA,
L.L.C. SEE HTTP://WWW.MPEGLA.COM.
Accordingly, please be advised that service providers, content providers and
broadcasters are required to obtain a separate use license from MPEG LA prior to
any use of AVC/MPEG-4/H.264 encoders and/or decoders.
Safety Precautions
v
Safety Precautions
1 Read Instructions – All the safety and operating instructions should be read
before the product is operated.
2 Retain Instructions – The safety and operating instructions should be retained for
future reference.
3 Heed Warnings – All warnings on the product and in the operating instructions
should be adhered to.
4 Follow Instructions – All operating and use instructions should be followed.
5 Cleaning – Unplug this product from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Exception: A product that is meant for uninterrupted service and that, for some
specific reason, such as the possibility of the loss of an authorization code for a
CATV converter, is not intended to be unplugged by the user for cleaning or any
other purpose, may exclude the reference to unplugging the product in the
cleaning description above.
6 Attachments – Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7 Water and Moisture – Do not use this product near water – for example, near a
bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a
swimming pool; and the like.
Accessories – Do not place this product on an unstable cart, stand, tripod,
bracket, or table.
The product may fall, causing serious injury to a child or adult, and serious
damage to the product.
Safety Precautions
vi
Use only with a cart, stand, tripod, bracket, or table recommended by the
manufacturer, or sold with the product. Any mounting of the product should
follow the manufacturer’s instructions, and should use a mounting accessory
recommended by the manufacturer.
8 A product and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the product and cart
combination to overturn.
9 Ventilation – Slots and openings in the cabinet are provided for ventilation and
to ensure reliable operation of the product and to protect it from overheating,
and these openings must not be blocked or covered. The openings should never
be blocked by placing the product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer’s instructions
have been adhered to.
10 Power Sources – This product should be operated only from the type of power
source indicated on the marking label. If you are not sure of the type of power
supply to your home, consult your product dealer or local power company. For
products intended to operate from battery power, or other sources, refer to the
operating instructions.
11 Grounding or Polarization – This product may be equipped with a polarized
alternating-current line plug (a plug having one blade wider than the other). This
plug will fit into the power outlet only one way. This is a safety feature. If you
are unable to insert the plug fully into the outlet, try reversing the plug. If the
plug should still fail to fit, contact your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the polarized plug. Alternate Warnings –
This product is equipped with a three-wire grounding-type plug, a plug having a
third (grounding) pin. This plug will only fit into a grounding-type power outlet.
This is a safety feature. If you are unable to insert the plug into the outlet, contact
your electrician to replace your obsolete outlet. Do not defeat the safety purpose
of the grounding-type plug.
12 Power-Cord Protection – Power-supply cords should be routed so that they are
not likely to be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience receptacles, and the
point where they exit from the product.
Safety Precautions
vii
13 Protective Attachment Plug – The product is equipped with an attachment plug
having overload protection. This is a safety feature. See Instruction Manual for
replacement or resetting of protective device. If replacement of the plug is
required, be sure the service technician has used a replacement plug specified by
the manufacturer that has the same overload protection as the original plug.
14 Outdoor Antenna Grounding – If an outside antenna or cable system is
connected to the product, be sure the antenna or cable system is grounded so as
to provide some protection against voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA 70, provides
information with regard to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna-discharge unit, connection to
grounding electrodes, and requirements for the grounding electrode.
15 Lightning – For added protection for this product during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line surges.
16 Power Lines – An outside antenna system should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or where it can fall
into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits
as contact with them might be fatal.
17 Overloading – Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire or electric shock.
18 Object and Liquid Entry – Never push objects of any kind into this product
through openings as they may touch dangerous voltage points or short-out parts
that could result in a fire or electric shock. Never spill liquid of any kind on the
product.
Safety Precautions
viii
19 Servicing – Do not attempt to service this product yourself as opening or
You will find this symbol on the product and/or in the literature that
accompanies this product.
It indicates important operating or maintenance instructions.
removing covers may expose you to dangerous voltage or other hazards. Refer
all servicing to qualified service personnel.
20 Damage Requiring Service – Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the following conditions:
a When the power-supply cord or plug is damaged,
b If liquid has been spilled, or objects have fallen into the product,
c If the product has been exposed to rain or water,
d If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to
restore the product to its normal operation,
e If the product has been dropped or damaged in any way, and
f When the product exhibits a distinct change in performance – this indicates a
need for service.
21 Replacement Parts – When replacement parts are required, be sure the service
technician has used replacement parts specified by the manufacturer or have the
same characteristics as the original part. Unauthorized substitutions may result
in fire, electric shock, or other hazards.
22 Safety Check – Upon completion of any service or repairs to this product, ask the
service technician to perform safety checks to determine that the product is in
proper operating condition.
23 Wall or Ceiling Mounting – The product should be mounted to a wall or ceiling
only as recommended by the manufacturer.
24 Heat – The product should be situated away from heat sources such as radiators,
heat registers, stoves, or other products (including amplifiers) that produce heat.
Protect yourself from electric shock and your system from damage!
This product complies with international safety and design standards. Observe
all safety procedures that appear throughout this guide, and the safet y symbols
that are affixed to this product.
If circumstances impair the safe operation of this product, stop operation and
secure this product against further operation.
Avoid personal injury and product damage! Do not proceed beyond any symbol
until you fully understand the indicated conditions!
Safety Precautions
ix
You may find this symbol on the product and/or in the literature that
accompanies this product.
It indicates a live terminal; the symbol pointing to the terminal device.
You may find this symbol on the product and/or in the literature that
accompanies this product.
It indicates a protective earth terminal.
You may find this symbol on the product and/or in the literature that
accompanies this product.
It indicates excessive or dangerous heat.
Power
Important! This is a Class I product. You must earth this product. This
equipment may have up to two power supply cords. To reduce the risk of
electric shock, two power supply cords may have to be disconnected before
servicing.
This product plugs into a socket-outlet. The socket-outlet must be near this
product, and must be easily accessible.
Connect this product only to the power source that is indicated on the rear panel
of this product.
If this product does not have a mains power switch, the power cord serves this
purpose
Enclosure
Do not allow moisture to enter this product.
Do not open the enclosure of this product unless otherwise specified.
Do not push objects through openings in the enclosure of this product.
Cables
Always disconnect all power cables before servicing this product.
Always pull on the plug or the connector to disconnect a cable. Never pull on the
cable itself.
Do not walk on or place stress on cables or plugs.
Factory service
Refer service only to service personnel who are authorized by the factory.
Safety Precautions
x
Règles de sécurité
Ce symbole figure dans la documentation accompagnant ce produit. Il indique
d'importantes instructions de fonctionnement ou d'entretien.
Ce symbole peut être attaché à ce produit. Il indi que une borne sous tension;
la direction indique la borne.
Ce symbole peut être attaché à ce produit. Il indique une borne de terre de
protection.
Ce symbole peut être attaché à ce produit. Il indique une température
excessive ou dangereuse.
Protégez-vous des risques d'électrocution et protégez votre système contre les
endommagements éventuels.
Ce produit respecte les standards internationaux de sécurité et de conception.
Veuillez observer toutes les procédures de sécurité qui apparaissent dans ce guide,
ainsi que les symboles de sécurité qui figurent sur le produit.
Si, du fait des circonstances, ce produit cesse de fonctionner normalement, cessez de
l'utiliser et empêchez-en l'utilisation future.
Évitez le risque de blessures et de dommages aux produits! Ne procédez à aucune
tâche tant que vous n'aurez pas entièrement assimilé les conditions indiquées par un
symbole!
Alim entation
Important! Ce produit fait partie de la classe I. Vous devez le mettre à la terre.
Ce produit se branche dans une prise murale. Cette dernière doit être placée à
proximité du produit et doit être facilement accessible.
Ne branchez ce produit qu'à la source d'alimentation indiquée sur son panneau
arrière.
Si ce produit n'a pas d'interrupteur d'alimentation générale, le cordon
d'alimentation remplit ce rôle.
Enceinte
Ne laissez pas l'humidité pénétrer dans ce produit.
N'ouvrez pas l'enceinte de ce produit, sauf instructions contraires.
Ne forcez pas d'objets dans les ouvertures du boîtier.
Câbles
Débranchez toujours tous les cordons d'alimentation avant de réparer ce produit.
Tirez toujours sur la prise ou le connecteur pour débrancher un câble. Ne tirez
jamais directement sur le câble.
Safety Precautions
xi
Ne marchez pas sur les câbles ou les prises et n'y exercez aucune pression.
Dieses Symbol erscheint auf dem Gerät und/oder in der ihm beiliegenden
Literatur. Es bedeutet wichtige, zu beachtende Betriebs -oder
Wartungsanweisungen.
Wenn dieses Zeichen am Gerät angebracht ist, warnt es vor einer
spannungsführenden Stelle.
Dieses Symbol kennzeichnet auf dem Gerät die Anschlußstelle der
Sicherheitserde.
Wenn dieses Zeichen am Gerät angebracht ist, warnt es vor heißen Stellen, die
zu Verbr ennungen führen können.
Réparations effectuées à l'usine
Ne confiez les travaux de réparations qu'au personnel autorisé par l'usine.
Sicherheitsvorkehrungen
Schützen Sie sich gegen elektrischen Schlag, und Ihr Gerät gegen Beschädigung!
Dieses Gerät entspricht internationalen Sicherheits-und Ausführungsnormen.
Beachten Sie alle in diesem Handbuch enthaltenen Sicherheitshinweise sowie die
am Gerät angebrachten Warnzeichen.
Sollten örtliche Umstände den sicheren Betrieb dieses Gerätes beeinträchtigen,
schalten Sie es ab und sichern es gegen weitere Benutzung.
Vermeiden Sie Verletzungen sowie Beschädigung des Gerätes! Wenn Sie zu einem
der folgenden Warnzeichen gelangen, nicht weiterarbeiten, bis Sie seine Bedeutung
voll verstanden haben!
Netzspannung
Wichtig! Dieses Gerät ist ein Produkt der Schutzklasse I. Es muß geerdet werden.
Das Gerät ist an einer Steckdose anzuschließen. Diese muß sich leicht zugänglich
in unmittelbarer Nähe des Gerätes befinden.
Die Netzversorgung muß den auf der Rückwand des Gerätes angegebenen
Werten entsprechen.
Falls sich kein Hauptschalter am Gerät befindet, dient das Netzkabel diesem
Zweck.
Gehäuse
Das Innere des Gerätes ist vor Feuchtigkeit zu schützen.
Das Gehäuse ist nicht zu öffnen.
Niemals einen Gegenstand durch die Gehäuseöffnungen einführen!
Safety Precautions
x ii
Kabel
Encontrará este símbolo en el impr eso que acompaña a este producto. Este símbolo
indica instrucciones importantes de funcionamiento o mantenimiento.
Es posible que este símbolo esté pegado al producto. Este símbolo indica un
terminal vivo, la flecha apunta hacia el aparato terminal.
Podría encontrar este símbolo pegado al producto. Este símbolo indica un terminal
de protección de tierra.
Podría encontrar este símbolo pegado al producto. Este símbolo indica calor
excesivo o peligroso.
Vor jeglicher Wartung des Gerätes sind alle Kabel zu entfernen.
Hierzu grundsätzlich am Stecker oder Verbindungsstück und niemals am Kabel
selber ziehen.
Nicht auf die Kabel oder Stecker treten oder diese einer Zugbelastung aussetzen.
Hersteller-Wartung
Wartungsarbeiten sind nur durch vom Hersteller autorisierte Techniker
vorzunehmen.
Precauciones de seguridad
¡Protéjase contra la electrocución y proteja su sistema contra los daños!
Este producto cumple con los criterios internacionales de seguridad y diseño.
Observe todas los procedimientos de seguridad que aparecen en esta guía, y los
símbolos de seguridad adheridos a este producto.
Si las circunstancias impiden la operación segura de este producto, suspenda la
operación y asegure este producto para que no siga funcionando.
¡Evite lastimarse y evite dañar el producto! No avance más allá de cualquier símbolo
hasta comprender completamente las condiciones indicadas!
Alim entación
Importante! Este es un producto de Clase I. Tiene que estar conectado a tierra.
Este producto se conecta a un enchufe. El enchufe necesita estar cerca del
producto y ser fácilmente accesible.
Conecte este producto únicamente a la fuente de suministro eléctrico indicada en
el panel posterior del producto.
Si el producto no tiene interruptor para la linea principal, utilice el cordón toma
de corriente para este propósito.
Safety Precautions
x iii
Cubierta
Questo simbolo, che appare nella letteratura di accompagnamento del
prodotto, indica importanti istruzioni d'uso e di manutenzione.
Sul prodotto potete vedere questo simbolo che indica un dispositivo terminale
sotto tensione; la freccia punta verso il dispositivo.
Potrete trovare il presente simbolo applicato a questo prodotto. Questo
simbolo indica un terminale protettivo di messa a terra.
Potrete trovare il presente simbolo attaccato a questo prodotto. Questo
simbolo indica un calore eccessivo o pericoloso.
No permita que la humedad penetre en este producto.
No abra la cubierta del producto a menos que se indique lo contrario.
No introduzca objetos a través de las aberturas de la cubierta del producto.
Cables
Siempre desconectar todos los cables eléctricos antes de revisar o reparar el
producto.
Tire siempre del enchufe o del conector para desconectar un cable. Nunca tire del
cable mismo.
No camine ni aplique presión sobre los cables o enchufes..
Revisión y reparación de fábrica
Solo personal aprobado por la fábrica puede darle servicio al producto.
Precauzioni di sicurezza
Proteggetevi da scosse elettriche e proteggete il vostro sistema da possibili danni!
Questo prodotto soddisfa le norme internazionali per la sicurezza ed il design.
Seguite tutte le procedure di sicurezza contenute in questa guida e i simboli di
sicurezza applicati al prodotto.
Se circostanze avverse compromettono la sicurezza d'uso di questo prodotto,
interrompetene l'uso e assicuratevi che il prodotto non venga più utilizzato.
Evitare infortuni alla persona e danni al prodotto! Non procedere oltre a qualunque
simbolo fino a quando non si siano comprese pienamente le condizioni indicate!
Alim entazione
Importante! Questo prodotto è di Classe I. Va messo a terra.
Questo prodotto si inserisce in una presa di corrente. La presa di corrente deve
essere in prossimità del prodotto, e deve essere facilmente accessibile.
Safety Precautions
x iv
Collegare questo prodotto solamente alla fonte di alimentazione indicata sul
pannello posteriore di questo prodotto.
Se questo prodotto non è dotato di un interruttore principale, il cavo di
alimentazione funge a questo scopo.
Chiusura
Proteggete da umidità questo prodotto.
Non aprire la chiusura di questo prodotto a meno che non sia specificato
diversamente. Non inserire oggetti attraverso le fessure della chiusura.
Cavi
Staccare sempre tutti i cavi di alimentazione prima di svolgere l'assistenza
tecnica al prodotto.
Per scollegare un cavo tirate la spina o il connettore, non tirare mai il cavo stesso.
Non calpestare o sottoporre a sollecitazioni i cavi o le prese.
Riparazionoi di fabbrica
Per le riparazioni contattate solamente personale tecnico autoizzato dalla
fabbrica.
Contents
Safety Precautions v
About This Guide xxiii
Objective............................................................................................................. xxiii
Audienc e ............................................................................................................ xxiii
Required Knowledge......................................................................................... xxiii
Chapter 1 Introduction 1
D9854/D9854-I Advanced Program Receiver................................................................... 2
Key Features ............................................................................................................ 2
Transport Stream Inputs/Outputs..................................................................................... 5
DVB-ASI Output..................................................................................................... 5
MPEGoIP Output ................................................................................................... 5
MPE Output ............................................................................................................ 5
HD-SDI Outputs ..................................................................................................... 6
MPEGoIP Input....................................................................................................... 6
Disaster Recovery................................................................................................................ 8
Local Settings .......................................................................................................... 8
Uplink P rofile Settings ........................................................................................... 9
NIT Retu ne Recovery ........................................................................................................ 11
Chapter 2 Quick Setup - Read Me First! 13
Connecting the Receiver to Other Equipm ent ................................................................ 14
Maintena nce of EMC Compliance....................................................................... 15
Setting up for Network Connection ................................................................................. 16
Quick Setup Instructions for RF Acquisition .................................................................. 17
Assigning a Program Channel to a PE (Program E ntry) ................................................ 19
ASI Out............................................................................................................................... 20
Setting up the HD-SDI Outputs (SDI Model, with SD/HD-SDI and AES outputs) .... 21
Setting up the MOIP Outputs........................................................................................... 22
Setting the DP M Mode...................................................................................................... 23
Chapter 3 Installation 25
Rack Installation ................................................................................................................ 26
Power Connection ................................................................................................ 26
Mechanical Loading ............................................................................................. 26
Elevated Operating Ambient Temperature ........................................................ 26
x vi
Equipotential Bonding ......................................................................................... 27
Installing the D9854/D9854-I Receiver............................................................................ 28
Rack Mounted....................................................................................................... 28
Cooling .................................................................................................................. 28
Grounding ............................................................................................................. 28
Mounting the D9854/D9854-I Receiver to a Rack.............................................. 28
Connecting AC Power to the D9854/D9854-I Receiver..................................... 29
D9854/D9854-I Receiver Rear Connector Pa nel ............................................................. 30
Connecting the Input/Output Signals............................................................................. 32
Connecting the RF Inputs .................................................................................... 32
Connecting the ASI Input .................................................................................... 32
Connecting the Video Outputs ............................................................................ 32
Connecting the Audio Outputs ........................................................................... 33
Connecting the Ethernet Management Interface................................................ 34
Connecting the IP TS Input/Output ................................................................... 34
Connecting the ASI Output ................................................................................. 34
External Ala rm System Co nnector ...................................................................... 35
Connecting the RS-232 Data Interface................................................................. 35
Cue Tone/Cue Trigger Interface ......................................................................... 36
Configuring Op en-collector Outputs .................................................................. 37
Setting Adm in User Privileges via a Telnet/SSH Connection....................................... 38
Administrator User Privileges ............................................................................. 38
Starting a Telnet/SSH Session ............................................................................. 38
Adding a New User.............................................................................................. 39
Deleting a User...................................................................................................... 39
Changing a Username .......................................................................................... 39
Changing a Password (allowed by all Users) ..................................................... 40
Printing the List of Users...................................................................................... 40
Resetting the Login Credentials .......................................................................... 40
Common Interface Modules ............................................................................................. 41
Chapter 4 Front Panel Operation 43
About the Front Panel ....................................................................................................... 44
LCD........................................................................................................................ 44
Keypad .................................................................................................................. 44
CI Slots................................................................................................................... 44
Front Panel LEDs .................................................................................................. 44
Navigation/S election Keypad ............................................................................. 45
Locking/Unlocking the Front Panel ................................................................................ 48
Startup Screen.................................................................................................................... 49
Main Structure ...................................................................................................... 49
Channel Authorization Status ............................................................................. 49
LCD Panel ............................................................................................................. 49
LCD Symbol .......................................................................................................... 50
Assigning Program to the Program Entry .......................................................... 51
Deleting a Program from the Program Entry ..................................................... 52
Main Menu......................................................................................................................... 53
Status Menu ....................................................................................................................... 54
Status Menu: General ........................................................................................... 55
Status Menu: Services ........................................................................................... 56
Status Menu: TS Input .......................................................................................... 59
Status Menu: TS Output ....................................................................................... 64
Status Menu - IP.................................................................................................... 64
Status Menu - D/R ............................................................................................... 67
Setup Menu ........................................................................................................................ 70
Setup Menu: Admin ............................................................................................. 71
Setup Menu: TS Input........................................................................................... 76
Setup Menu: IP...................................................................................................... 87
Setup Menu: Services ........................................................................................... 95
Setup Menu: Common Interface (CI) ................................................................ 108
Setup Menu: Outputs ......................................................................................... 112
Setup Menu: CA ................................................................................................. 137
Setup Menu: Alarm/Wa rning ........................................................................... 139
Setup Menu: Noise Cutoffs ................................................................................ 141
Setup Menu: D/R ............................................................................................... 143
About Menu..................................................................................................................... 147
General ................................................................................................................ 147
Licenses ............................................................................................................... 148
Features ............................................................................................................... 148
Versions Menu................................................................................................................. 149
Diagnostics Menu............................................................................................................ 152
Alarms/Warnings .............................................................................................. 152
Logs...................................................................................................................... 152
PSI - Frequ ency Plan........................................................................................... 153
PSI - Channels ..................................................................................................... 153
PSI - Tables .......................................................................................................... 154
Power On............................................................................................................. 154
Health Monitor ................................................................................................... 155
Chapter 5 Web GUI Setup and Monitoring 157
Logging On to the Web Interface ................................................................................... 158
D9854/D9854-I Summary Overview ............................................................................. 159
Shortcuts .............................................................................................................. 159
Modules............................................................................................................... 160
Auto-Refresh ....................................................................................................... 160
Alarms/Warnings .............................................................................................. 160
D9854/D9854-I Menus .................................................................................................... 162
D9854/D9854-I Web GUI Environment ........................................................................ 164
Window Buttons ................................................................................................. 164
Setting up Input Information ......................................................................................... 165
Setting up the RF Input ...................................................................................... 165
Validating the Orbital Position .......................................................................... 167
x viii
Reacquiring the Network Information.............................................................. 168
Viewing the Current Input Status ..................................................................... 168
Setting up the ASI Input..................................................................................... 170
Configuring t he IP Input .................................................................................... 171
Setting up SI Receive Parameters ...................................................................... 178
Setting up Muting Threshold Controls ............................................................. 181
Viewing the Input Status.................................................................................... 183
Configuring t he Disaster Recovery Settings ..................................................... 183
Viewing the Disaster Recovery Status .............................................................. 187
Setting up the Channel Selections ..................................................................... 192
Viewing the Channel Status............................................................................... 193
Configuring t he Common Interface (CI) Information ..................................... 195
Viewing the Common Interface (CI) Status...................................................... 199
Viewing the CA Status ....................................................................................... 200
Setting up the BISS Mode................................................................................... 201
Viewing the PSI Tables....................................................................................... 202
Viewing PSI Frequency Table Information....................................................... 203
Viewing the PSI Channels.................................................................................. 204
Viewing the PID Input Status ............................................................................ 205
Setting up Audio and Video Information...................................................................... 206
Setting up the Video Parameters ....................................................................... 206
Setting up Captions ............................................................................................ 208
Setting up Subtitles............................................................................................. 209
Setting up the VBI ............................................................................................... 211
Setting up Audio Parameters ............................................................................. 212
Setting up Cueing Parameters ........................................................................... 217
Setting up Cue Tone Test ................................................................................... 219
Setting up Cue Tones.......................................................................................... 220
Setting up SDI ..................................................................................................... 221
Setting up Services to be Decoded by the D9854/D9854-I Receiver............... 223
Configuring Transport Stream Information.................................................................. 224
Configuring t he ASI Output .............................................................................. 224
Configuring t he DPM ASI Details ..................................................................... 230
Viewing the ASI Output Transport Status........................................................ 236
Configuring t he MPEGoIP Output.................................................................... 237
Configuring t he DPM MPEGoIP Output Details ............................................. 251
Viewing the MPEG Output Transport Status................................................... 258
Typical set up for Digital Program Mapping (DPM) ....................................... 258
Configuring System Settings .......................................................................................... 261
Viewing the System Identification .................................................................... 261
Viewing Hardware Features and Software Lic ense Information ................... 262
Setting up IP Information................................................................................... 263
Setting up IP Unicast Routing Information ...................................................... 269
Configuring t he MPE Settings ........................................................................... 271
Setting up SNMP I nformation and Trap Destinations .................................... 273
Configuring Time/Clock Settings ..................................................................... 275
Viewing the Alarm/Warning Status................................................................. 277
Setting up Alarms a nd Warnings ...................................................................... 279
Viewing Alarm/ Warning History .................................................................... 282
Viewing Version I nformation ............................................................................ 283
Setting up Import/Export File Information ..................................................... 287
Setting up Import/Export FTP Information ..................................................... 288
Managing D9854/D9854-I Web GUI Accounts................................................ 290
Configuring Lock Level Settings ....................................................................... 294
Configuring Front Panel Settings ...................................................................... 296
Viewing Support Information ........................................................................................ 297
Viewing Contact Information ............................................................................ 297
Viewing Diagnostic Logs ................................................................................... 298
Viewing the Usage Cou nters ............................................................................. 299
Viewing Operating Board Temp eratures ......................................................... 300
Viewing Alarm/ Warning History .................................................................... 301
Loading a Software Version............................................................................... 302
Chapter 6 Service and Maintenance 305
D9854/D9854-I Receiver Alarm Messages .................................................................... 306
Alarms ................................................................................................................. 306
Warnings ............................................................................................................. 347
Chapter 7 Customer Information 369
Appendix A Technical Specifications 371
L-Band Input and Processing ......................................................................................... 372
General ................................................................................................................ 372
LNB LO Stability................................................................................................. 372
LNB Power and Control..................................................................................... 373
DVB-S/DVB-S2................................................................................................... 373
Video Inputs/Outputs and Processing.......................................................................... 376
General ................................................................................................................ 376
Video Outputs..................................................................................................... 376
Embedded Data in SDI ....................................................................................... 379
Audio Outputs .................................................................................................... 380
Conditional Acc ess ............................................................................................. 380
Transport Stream Inputs/Outputs................................................................................. 381
ASI Output .......................................................................................................... 381
MPEGoIP Output ............................................................................................... 381
MPE Output ........................................................................................................ 382
MPEGoIP Input (D9854-I only) ......................................................................... 382
ASI Input ............................................................................................................. 383
Control, Management and Data Interfaces ................................................................... 384
Ethernet Management Interface ........................................................................ 384
Ethernet Data Interface....................................................................................... 384
xx
RS-232 Data Interface ......................................................................................... 384
Alarm Interface ................................................................................................... 384
Contact Closure Interface ................................................................................... 385
Power and General Specifications.................................................................................. 386
General ................................................................................................................ 386
Power................................................................................................................... 386
Mechanical .......................................................................................................... 387
Environment ....................................................................................................... 387
Appendix B Default Settings and Lock Levels 389
Factory Default Settings and Lock Levels ..................................................................... 390
Administration.................................................................................................... 390
ASI Input ............................................................................................................. 391
RF Input ............................................................................................................... 391
IP Input................................................................................................................ 392
Tune Mode .......................................................................................................... 393
Disaster Recovery ............................................................................................... 393
IP .......................................................................................................................... 394
Trap Destinations ............................................................................................... 395
Protocols .............................................................................................................. 395
Video.................................................................................................................... 395
Audio ................................................................................................................... 396
VBI ....................................................................................................................... 396
Subtitles ............................................................................................................... 396
Decode ................................................................................................................. 397
CI.......................................................................................................................... 397
Cueing ................................................................................................................. 397
TS Out - ASI ........................................................................................................ 398
TS Out - MOIP .................................................................................................... 398
DPM - ASI ........................................................................................................... 399
Options ................................................................................................................ 401
Alarm/Warning.................................................................................................. 401
Noise Cutoff ........................................................................................................ 402
DPM Default Settings for Different Output Modes...................................................... 403
Appendix C Compliance 407
Applicable Standards and Notices ................................................................................. 408
Safety ................................................................................................................... 408
EMC ..................................................................................................................... 408
Electromagnetic Compatibility Regulatory Requirements .............................. 408
FCC Notices ........................................................................................................ 409
Industry Canada Notice ..................................................................................... 409
Unauthorized Modifications.............................................................................. 409
Declaration of Conformity.............................................................................................. 410
Index 411
About This Guide
x x iii
About This Guide
Objective
This guide describes how to install, use and maintain the Cisco D9854/D9854-I
Advanced Program Receiver.
Note: The guide describes all available options for the D9854/D9854 -I receiver. Your
D9854/D9854-I receiver may only have some of the features described in this guide.
Audience
The audience of this manual includes users (operators) and service personnel who
are responsible for the installation, configuration, operation, monitoring and service
of the D9854/D9854-I receiver.
Required Knowledge
To use this documentation, the user should have a basic knowledge of the
technology used in relation to this product. Service personnel should have
additional skills and be familiar with cabling, electronic circuitry, and wiring
practices.
This guide is intended for operators who are responsible for the configuration,
remote operation and maintenance of the D9854/D9854 -I receiver.
1
Overview
This chapter is a general introduction to the Cisco D9854/D9854-I
Advanced Program Receiver. It describes the most common
applications and interfaces of the receiver.
1 Chapter 1
Introduction
In This Chapter
D9854/D9854-I Advanced Program Receiver....................................2
Transport Stream Inputs/Outputs......................................................5
Disaster Recovery.................................................................................8
NIT Retune Recovery .........................................................................11
Chapter 1 Intr oduction
2
D9854/D9854-I Advanced Program Receiver
The D9854/D9854-I Advanced Program Receiver is designed for satellite content
distribution applications requiring DVB-S and DVB-S2 reception capabilities with
advanced digital outputs for digital tier program distribution. A built-in decoder
will be capable of decoding a MPEG-2 or MPEG-4 High Definition (HD) program for
analog monitoring or high-quality HD-SDI output version will be available for reencode applications.
The ASI transport output or the MPEGoIP output (optional for the D9854) will
provide a number of output modes including the capability of carrying a decrypted
program for digital tier distribution. This helps ensure that compressed video
programs are efficiently distributed to households equipped with digital set-top
boxes. Digital Program Insertion (DPI) information will also be available along with
the video and audio PIDs (Packet Identifiers) for external ad insertion in compressed
digital format.
In addition to the D9854 features, the D9854 -I includes MPEGoIP input, SPTS for
MPEGoIP Output, Input/Output Redundancy, and Forward Error Correction (FEC)
capabilities. The MPEG over IP input allows a decoder to process the UDP and RTP
encapsulated MPEG transport streams received from the IP/ETH-based terrestrial
network. The incoming transport stream can be either MPTS or SPTS. The FEC
decoder supports decoding of one (1D scheme, column only) or two (2D scheme,
column and row) FEC streams per flow.
Key Features
The D9854/D9854-I receiver provides the following key features:
Four L-band inputs
New H/W with up to 180 Mbps throughput/bandwidth
MPEGoIP Input with Redundancy (1 MPTS or 1 SPTS)
MPEGoIP Output with Redundancy (1 MPTS or 16 SPTS)
Supports Forward Error Correction (FEC) based on SMPTE 2022 for MPEGoIP
input and Output
DVB-S quaternary phase shift keying (QPSK) demodulation
DVB-S2 QPSK and eight phase shift keying (8PSK) demodulation
Cisco PowerVu conditional access with Data Encryption Standard (DES) or DVB
descrambling
Support for Basic Interoperable Scrambling System (BISS) conditional access
DVB-CI support for CAM-based conditional access
D9854/D9854-I Advanced Pr ogr am Receiver
3
4:2:0 HD MPEG-4 AVC and MPEG-2 1080i and 720p decoding
4:2:0 SD MPEG-4 AVC and MPEG-2 decoding
Aspect ratio conversion (4:3, 16:9, 14:9) with Active Format Descriptor (AFD)
control for SD programs
AFD support for down-conversion of HD programs with aspect ratio conversion
User-configurable redundant ASI, SDI, or HD-SDI outputs
SDI or HD-SDI video output with embedded audio
Closed captioning support for EIA-608 and EIA-708
MPEG and Dolby Digital audio decoding
DVB or Imitext subtitling
Four audio outputs providing either two stereo pairs or four mono channels of
balanced, audio, each with the ability to use part of the output for applications
such as second audio program (SAP), cue tones, etc.
Utility data up to 38.4 kbps using RS-232
Uplink addressable decoder output control, including vertical blanking interval
(VBI) data, audio routing, DPI, and ASI output)
Fingerprint trigger
Field upgradeable software and security
Simple Network Management Protocol (SNMP) for setup, control, and
monitoring
Front panel liquid crystal display (LCD) for control and monitoring
Web browser interface for easy setup, control, and monitoring
DVB-VBI and SCTE-127 support
CAM Interface software
Dual-tone multifrequent (DTMF) cue tone and cue trigger outputs for
advertisement insertion
Digital program mapping providing uplink control for service replacements in
blackout areas
Cisco Live Event Controller support
On Screen Display support on baseband output.
Satellite Disaster Recovery support with Cisco PowerVu Network Center uplink
control (Release 12.5 or later)
Chapter 1 Intr oduction
4
SCTE-104 pass-through support on SDI output
NIT Retune Recovery
Transport Stream Inputs/Outputs
5
Transport Stream Inputs/Outputs
DVB-ASI Output
The D9854/D9854-I receiver has one DVB-ASI output. This output can be used as an
input for a DVB-T transmitter or other types of DVB-ASI reception equipment.
MPEGoIP Output
The MPEGoIP output provides a number of output modes including the capability
of carrying a decrypted program for digital tier distribution. This helps ensure that
compressed video programs are efficiently distributed to households equipped with
digital set-top boxes. Digital Program Insertion (DPI) information will also be
available along with the video and audio PIDs (Packet Identifiers) for external ad insertion in compressed digital format.
The diagram below shows an example of the D9854/D9854 -I receiver used in an
MPEGoIP application.
MPE Output
The Multiprotocol Encapsulation (MPE) output provides a means to carry packet
oriented IP protocols on top of a transport stream. The MPE output receives IP
packets from the transport stream and the IP data can be sent through an Ethernet
switch to an IP router or directly to a receiving device.
Chapter 1 Intr oduction
6
The diagram below shows an example of the D9854/D9854 -I receiver used in an
MPE application.
HD-SDI Outputs
The D9854/D9854-I Advanced Program Receiver is designed for satellite content
distribution applications requiring DVB-S and DVB-S2 reception capabilities with
advanced digital outputs for digital tier program distribution. A built-in decoder is
capable of decoding an MPEG-2 or MPEG-4 High Definition (HD) program for
analog monitoring. A high-quality HD-SDI output version is available for reencoding applications.
The diagram below shows an example of the D9854/D9854 -I receiver used in HDSDI monitoring applications.
MPEGoIP Input
Note: The MPEGoIP Input is supported in the D9854-I only.
The MPEGoIP input allows a decoder to process User Datagram Protocol (UDP) or
Real-time Transport Protocol (RTP)-encapsulated MPEG transport streams
(protected streams) from the IP/Ethernet network. The incoming stream is either
MPTS or Single Program Transport Stream (SPTS).
Transport Stream Inputs/Outputs
7
The diagram below shows an example of the D9854-I receiver receiving MPEGoIP
transport streams:
Chapter 1 Intr oduction
8
Disaster Recovery
Program
Entry
Origin Transport
Channel Number
Backup 1
Transport
Channel
Number
Backup 2
Transport
Channel
Number
Backup 3
Transport
Channel
Number
PE1
101
11
101
801
PE2 2 12 - 1005
In the event of a transmission failure on the primary feed, the disaster recovery
allows for continued programming, with limited to no downtime. The failure
condition could be triggered by one of the following events:
RF Lock Loss
Unstable RF signal
Transport Loss (RF locked, but no transport stream packets and NUL L packets
received)
There are two types of disaster recovery implementations: Local or Uplink. Local
uses the disaster recovery settings configured on the D9854/D9854 -I receiver. Uplink
uses the disaster recovery profile settings configured on the PowerVu Network
Center (PNC). This is optional and PNC Software Version 12.5 is required.
Local Settings
The local disaster recovery settings are used if the PNC uplink is set to allow local
disaster recovery and the disaster recovery profile on the unit is set to local. Once the
receiver detects a failure after the configured signal loss timeout, it will initiate a
disaster recovery search based on the search path determined by the disaster
recovery configuration. A DR symbol is displayed on the front panel, and the
D9854/D9854-I web GUI displays a D/R in progress status. During a disaster, the
receiver will attempt to tune to a different backup transport, based on the search
path configured. The origin transport consists of origin transport tuning parameters
and PE service IDs, configured in the Input menus. For more information on the
Input parameters, see RF1, RF2, RF3, RF4 (RFx) Input (on page 77) for the front
panel, and Setting up the RF Input (on page 165) for the web GUI.
Note: If you perform a master PE channel change during a disaster recovery search,
the search will end, the current tuning parameters will be locked, and the current
channel will become the origin channel. If you perform a tuning change during a
disaster recovery search, the search will end, the current user tuning parameters will
become the origin tuning parameters, and the origin may be updated by any of the
NIT updates that follow.
For example, the disaster recovery is configured as follows:
Disaster Recover y
9
When disaster occurs, the receiver will tune to channel 11, as defined on the Backup
1 transport.
If the acquisition is successful on the backup 1 transport (PAT is received), the
receiver will set PE 1 to channel 11 and PE2 to channel 12 and declare that the
disaster is over.
If the acquisition fails or there is no signal lock on the backup 1 transport, the
receiver will continue to search for the next backup transport for PE1 (Backup 2
transport). If the acquisition is successful on the backup 2 transport, the receiver will
set PE1 to channel 101, but leave PE2 to channel 2 because PE2 is not specified for
Backup 2 transport.
If the acquisition fails or there is no signal lock on the backup 2 transport, it will
continue the search path and set PE1 to channel 801 and PE2 to channel 1005 if the
acquisition is successful on the backup 3 transport. However, if the acquisition fails
or there is no signal lock on the backup 3 transport, the search path will continue to
the origin transport. The search path will cycle through origin, backup 1, backup 2,
and backup 3 infinitely.
The search path is shown in the Disaster Recovery Status information on the front
panel and web GUI.
By default, the disaster recovery is enabled. To set up and view the disaster recovery
parameters using the front panel, see Setup Menu: D/R (on page 143) and Status
Menu - D/R (on page 67). To set up and view the disaster recovery parameters using
the web GUI, see Configuring the Disaster Recovery Settings (on page 183) and
Viewing the Disaster Recovery Status (on page 187).
Uplink Profile Settings
Once the receiver detects a failure after the configured signal loss timeout (defined
by the uplink), it will initiate a disaster recovery using the PNC uplink Disaster
Recovery Profile settings. If the PNC uplink is set to allow local disaster recovery,
the disaster recovery profile setting on the unit determines the disaster recovery
setting to use (local or uplink). If the PNC uplink does not allow local disaster
recovery, the uplink disaster recovery profile is used, even if the disaster recovery
profile setting on the unit is set to local. If the unit is not connected to the PNC
uplink, an error message is triggered and it will use the local disaster recovery
settings, if enabled.
During a disaster recovery, the PNC sends the Disaster Recovery Table (DRT) to the
receiver, along with the backup locations. The DRT is a table of data structures sent
from the PNC to the unit through the satellite uplink. For more information on t he
uplink disaster recovery, contact your PNC uplink administrator.
Chapter 1 Intr oduction
10
By default, the disaster recovery is enabled. To set up and view the disaster recovery
parameters using the front panel, see Setup Menu: D/R (on page 143) and Status
Menu - D/R (on page 67). To set up and view the disaster recovery parameters using
the web GUI, see Configuring the Disaster Recovery Settings (on page 183) and
Viewing the Disaster Recovery Status (on page 187).
NIT Retune Recover y
11
NIT Retune Recovery
The Network Information Table (NIT) retune recovery occurs when the tuning
parameters on the uplink do not result in a successful tuning lock (for example,
modulator settings or transponder signal strength).
The receiver will try to tune to the new signal (NIT), and if it does not lock to the
new signal during an initial engagement delay of five minutes, it will revert back to
the original signal. If it cannot lock to the original signal, it will try the new signal
again and attempt to lock within an engagement delay period that is twice the value
of the current disaster recovery Signal Lock Timer (see Viewing the Disaster
Recovery Status (on page 187)). The unit will continue to alternate between the new
signal and the original signal for up to one hour. If the unit does not lock to a signal
after one hour, it will trigger a disaster recovery. The unit must stay locked to the
new signal (NIT) for a minimum of ten minutes.
If another NIT is received before the ten minute timer, the ten minute timer is
canceled, the initial engagement delay period for the next NIT retune resets back to
the engagement period that is twice the value of the current disaster recovery Signal
Lock Timer, and the NIT retune process restarts.
If the existing signal remains locked during and after the ten minute period, and no
other NIT was received during that period, the current locked signal (NIT) becomes
the default NIT, the initial engagement period for a future NIT retune is reset back to
five minutes, and the unit is then ready for a future NIT retune.
To change the uplink tuning parameters, contact your PNC uplink administrator.
13
Overview
This chapter provides a quick setup for your Cisco D9854/D9854 -I
Advanced Program Receiver. If you are unsure about which receiver
settings to use, contact your local service provider for assistance.
2 Chapter 2
Quick Setup - Read Me First!
In This Chapter
Connecting the Rec eiver to Other Equipm ent .................................14
Setting up for Network Connection..................................................16
Quick Setup Instructions for RF Acquisition ...................................17
Assigning a Program Channel to a PE (Program E ntry) .................19
ASI Out................................................................................................20
Setting up the HD-SDI Outputs (SDI Model, with SD/HD-SDI
and AES outputs) ...............................................................................21
Setting up the MOIP Outputs............................................................22
Setting the DPM Mode.......................................................................23
Chapter 2 Quick Setup - Read Me Fir st!
14
Connecting the Receiver to Other Equipment
The following displays the rear panel of the D9854 Base Model:
The following displays the rear panel of the D9854 SDI Model, with SD/HD-SDI and
AES outputs:
The following displays the rear panel of the D9854-I:
1 Connect the L-Band signal to RF1. 13V or 18V LNB power is only available on
the RF1 port. The factory default setting for LNB power is OFF.
2 Connect the ASI OUT port to an ASI device for digital tier applications.
3 Connect the Composite Video Output to a video monitor.
4 Connect the terminal block balanced audio outputs labeled AUDIO 1 and
AUDIO 2 to monitoring equipment.
Connecting the Receiver to Other Equipment
15
5 Apply power by connecting the receiver to a power outlet. The message
“Application Starting” will appear on the front panel. The boot process
approximately 1 minute for the unit to initialize. When ready, the front panel
display shows the startup screen.
6 The Ethernet Management port supports the following network protocols:
Telnet, SSHv2, HTTP, HTTPS, SNMPv2, Syslog/DTX, SNTP, FTP (client side),
TFTP, and MPEGoIP output (D9854 only).
7 Connect the HD-SDI outputs (M1 and M2) to HD compatible signal processing
equipment or HD signal monitoring equipment, if applicable.
Maintenance of EMC Compliance
The power cord (consisting of appliance coupler, flexible cord, and plug) supplied
with this product meets the requirements for use in the country for which this
product was purchased. In general, the power cord must be approved by an
acceptable, accredited agency responsible for evaluation in the country where the
product will be used.
Double-shielded (braid/foil or braid/braid) cables should be used for all ASI I/O
and RF inputs. Single-shield cables are acceptable for all other inputs and outputs.
For terminal block (Alarms) I/O, no shielding is required.
Chapter 2 Quick Setup - Read Me Fir st!
16
Setting up for Network Connection
1 Press MENU to display the Main menu.
2 Press to go to the Setup menu. Press SELECT. Press twice to select the IP
menu. Press SELECT twice to go to the IP menu.
3 Use the arrow keys to navigate up and down the IP menu, and the arrow
keys to move across the IP menu to set the IP Address, Mask and Gateway
parameters. Use the number keys to directly enter numbers in the fields. For
more information on keypad operation, see Keypad Convention.
4 Press SELECT each time to save the changes. Press MENU four times to return
to the startup screen.
Quick Setup Instr uctions for RF Acquisition
17
Quick Setup Instructions for RF Acquisition
1 Press MENU to display the Main menu.
2 Press to go to the Setup menu. Press SELECT. Press to move to the TS Input
menu. Press SELECT.
3 To setup the ASI input port, go to Step 4. To setup the RF1 input port, go to Step
5.
4 Press SELECT three times. Press to set the ASI port to Act (Activate). Press
SELECT. Go to Step 11.
5 Press SELECT. Press to go to RF1. Press SELECT twice. Use to set the RF1
port parameter to Act (Activate). Press SELECT.
6 Press to move to the LO1, LO2, Crossover menu. Verify these parameters for
your application. If no change is needed, go to Step 7. If required, you may
modify these settings. Use to move to the parameter that you want to modify.
Press SELECT. Use the numerical keypad to enter new frequencies. Press
SELECT.
7 Press five times to move to the Modulation and Rolloff menu. Press SELECT.
Use to choose DVB-S or DVB-S2. Press SELECT. If DVB-S2 is used, press to
choose Rolloff. Press SELECT. Use to choose the value. Press SELECT.
8 Press to move to the Freq., Sym Rate, and FEC menu. Press SELECT. Enter the
RF frequency. Press SELECT. Press to move to the Sym. Rate menu. Press
SELECT. Enter the symbol rate. Press SELECT. If DVB-S2 is used, proceed to
Step 9. If DVB-S is used, press to set up the FEC. Press SELECT. Use to
select AUTO. Press SELECT.
9 Press twice to move to the Net ID menu. Press to choose Net ID. Press
SELECT. Enter the value. Press SELECT.
10 Press . Press SELECT. Use to change the LNB power, if needed. Only the
RF1 port is capable of providing 13V or 18V. Press SELECT.
11 Press MENU three times to acquire the network. The receiver will search for the
signal and display “Acquisition Successful”. It will find the first available
channel on the network.
12 Press to move to Save & Exit. Press SELECT. Save & Exit will return you to the
Main: Setup menu; Abandon & Exit will go back to the last menu accessed with
the original parameters; Cancel will go back to the last menu accessed with
changes saved.
Chapter 2 Quick Setup - Read Me Fir st!
18
13 If the front LED is solid green, the unit is authorized. Proceed with Assigning a
Program Channel to a PE (Program Entry). If the front LED is flashing green, the
unit is unauthorized. Please contact your service provider and provide the
Tracking ID number for authorization. The Tracking ID can be found on the
ABOUT menu. To locate the Tracking ID, press MENU, press twice, and then
press SELECT twice. Make a note of the Tracking ID number. Press MENU three
times to return to the startup screen.
Assigning a Pr ogr am Channel to a PE (Progr am Entry)
19
Assigning a Program Channel to a PE (Program Entry)
1 At the start-up screen, PE1 is initially displayed.
2 Press ADV and use the keys to scroll through the available program entries.
3 Press ADV again to select the channel number.
4 Use the keys to scroll through the available program channels or directly
enter the channel number using the 0 to 9 keys; press SELECT to save the
channel selection.
Important: In addition to ASI out availability on all models, your unit will be
configured for either HD-SDI or MOIP output. Please follow the procedure for your
model to configure the outputs.
Chapter 2 Quick Setup - Read Me Fir st!
20
ASI Out
1 Press MENU to move to the Main Menu.
2 Press to move to the Setup menu. Press SELECT.
3 Press to move to the Outputs menu. Press SELECT.
4 Press to move to the TS Out menu. Press SELECT.
5 Press SELECT to access the ASI menu. Press . Press SELECT. Use to select
6 Press SELECT. Press to select Yes if requested to "RESYNC ALL?". Press
7 Press to move to Descramble Mode menu. Press SELECT. Use to select the
8 Press to move to Insert Null Packet. Press SELECT. Use to change the
9 Press APPLY. Press SELECT.
10 Press MENU five times to return to the startup menu.
the output mode. The factory default is No Output. We recommend to set the
Output Mode to MAP Svc Chans Only.
SELECT.
scrambling mode. Press SELECT.
mode to Yes. Press SELECT.
Setting up the HD-SDI Outputs (SDI Model, with SD/HD-SDI and AES outputs)
21
Setting up the HD-SDI Outputs (SDI Model, with SD/HD-SDI and AES outputs)
The following displays the rear panel of the D9854 SDI Model and D9854-I, with
SD/HD-SDI and AES outputs:
1 Press MENU.
2 Press to move to the Setup menu. Press SELECT.
3 Press three times to move to the Services menu. Press SELECT.
4 Press SELECT to enter the Video menu.
5 Press SELECT to enter the PV Format menu, then use to navigate and
configure the output. Press SELECT to save the changes.
6 Press down arrow to move to the SD Format menu. Press SELECT to enter the
menu and use to navigate and configure the output. Press SELECT to save
the changes.
7 Press MENU two times. Press to move to the Outputs Menu. Press SELECT.
Press two times to enter the M1/M2 Menu. Press SELECT. Press SELECT and
use to enter ASI or SDI output on port 1. Press SELECT to save changes.
Press to move to M2. Press SELECT and use to enter ASI or SDI output on
port 2. Press MENU repeatedly to return to the startup screen.
Chapter 2 Quick Setup - Read Me Fir st!
22
Setting up the MOIP Outputs
The following displays the rear panel of the D9854 Base Model:
1 Press MENU to move to the Main Menu.
2 Press to move to the Setup menu. Press SELECT.
3 Press to move to the Outputs menu. Press SELECT.
4 Press to move to the TS Out menu. Press SELECT.
5 Press to move to the MOIP menu. Press SELECT. Press . Press SELECT for
Rate Control. Use to select User. Selecting Auto for Rate Control results in the
device setting the output rate to be the same as the input rate. Press SELECT.
Note: You can set the User Rate in Step 9.
6 Press to move to the Output Mode. Press SELECT. Use to choose the
output mode for your application. Press SELECT.
7 Press to move to Descrambling Mode menu. Press SELECT. Use to select
the scrambling mode. Press SELECT.
8 Press . Press to move to Insert Null Packet. Press SELECT. Use to change
the selection to No. Press SELECT.
9 Press to move to the MOIP Streams menu and press SELECT.
10 Move to the User Rate menu. Press SELECT and use the keypad to enter the
desired bit rate. Press SELECT to save changes.
11 Press two times. Press SELECT. Use to change the selection to UDP or RTP.
Press SELECT.
12 Press . Press SELECT. Enter the Destination Address using the keypad. Press
SELECT. Press to move to UDPPort. Press SELECT and enter the port number
using the keypad. Press SELECT to save the change. Press to move to SrcPort.
Press SELECT and enter the port number using the keypad. Press SELECT to
save the change. The default is zero, which allows the system to assign a port.
13 Press two times. Press two times to move to PCR@IP Start menu. Press
SELECT. Press to set value to No. Press SELECT to save the value.
14 Press MENU to exit the menu level and save the changes.
Setting the DPM Mode
23
Setting the DPM Mode
LCD Setting
Description
Drop
Removes the service and its associated PMT reference
from the transport output.
Pass
Permits the source content and PMT reference to appear
in the transport output with the same references unless
the source material is mapped on another PE.
Map
Provides the flexibility to define all the outgoing PID
numbers for a PE, including those not currently on
transmission.
A program can be set to one of three Digital Program Mapping (DPM) modes, either
Drop, Pass or Map respectively. For more information, see TS Out - DPM (on page
124).
1 Press MENU to display the Main Menu.
2 Press to move to the Setup menu. Press SELECT.
3 Press five times to move to the Outputs menu. Press SELECT.
4 Press to move to the TS Out menu. Press SELECT.
5 Press twice to move to the DPM menu. Press SELECT.
6 Press SELECT to access the Global menu.
7 Press SELECT to choose ASI for Resync All. Press and then press SELECT to
continue.
8 Press MENU. Press to move to the ASI menu. Press SELECT. Verify the PE1
”InCh” and ”OutCh” programs.
9 Press three times to choose Act. Press SELECT. Use to select the DPM
action for the PID associated with the PE. Press SELECT. Press APPLY. Press
SELECT to save the changes.
10 Press MENU six times to return to the start-up screen.
25
Introduction
This chapter contains the information for technicians installing the
Cisco D9854/D9854-I Advanced Program Receiver.
Qualified Personnel
Only appropriately qualified and trained service personnel should
attempt to install, operate, or maintain the D9854/D9854-I receiver.
WARNING:
Allow only authorized and qualified service personnel to install,
operate, maintain, and service this product. Otherwise, personal
injury or equipment damage may occur.
3 Chapter 3
Installation
In This Chapter
Rack Installation .................................................................................26
Installing the D9854/D9854-I Receiver.............................................28
D9854/D9854-I Receiver Rear Connector Pa nel ..............................30
Connecting the Input/Output Signals..............................................32
Setting Adm in User Privileges via a Telnet/SSH Connection........38
Common Interface Modules ..............................................................41
Chapter 3 Instal lation
26
Rack Installation
WARNING:
Make sure that at least one end of the power cable(s) remains
easily accessible for unplugging, if you need to switch off the unit.
For example: Ensure that the socket outlet is installed near the
product.
WARNING:
To avoid electrical shock, connect the three-prong plug on this
product to an earth-grounded three-pin socket outlet only.
WARNING:
Avoid personal injury and damage to this equipment. Mounting this equipment in the
rack should be such that a hazardous condition is not caused due to uneven mechanical
loading.
CAUTION:
If installed in a closed or multi-unit rack assembly, the operating ambient temperature
of the rack environment may be greater than room ambient temperature. Therefore,
install this equipment in an environment compatible with the manufacturer's
maximum rated ambient temperature.
Power Connection
To operate the receiver, you must connect it to an AC power source. For information
about connecting the chassis to AC power, see Appendix B - Technical Specifications
(on page 371).
As Cisco units are designed for continuous operation, some products do not have a
power switch. In this case, the mains cord and/or DC power supply cable serve(s) as
the mains disconnect device.
Mechanical Loading
Make sure that the rack is placed on a stable surface. If the rack has stabilizing
devices, install these stabilizing devices before mounting any equipment in the rack.
Elevated Operating Ambient Temperature
Only install this equipment in a humidity- and temperature-controlled environment
that meets the requirements given in this equipment's technical specifications.
Rack Installation
27
Equipotential Bonding
If this equipment is equipped with an external chassis terminal marked with the IEC
60417-5020 chassis icon ( ), or 5017 ( ), the installer should refer to CENELEC
standard EN 50083-1 or IEC standard IEC 60728-11 for correct equipotential bonding
connection instructions.
Chapter 3 Instal lation
28
Installing the D9854/D9854-I Receiver
CAUTION:
The inlet air temperature must not exceed 50°C/122°F at any time.
Rack Mounted
The D9854/D9854-I receiver is a 1U unit with connector access at the rear panel. The
receiver is intended for mounting in a standard 19" rack with minimum 1U spacing
between units to allow adequate ventilation/air flow.
The D9854/D9854-I receiver is vented from front to back. Multiple units can be
stacked in a rack, provided that adequate cooling is available.
Cooling
The unit is cooled by the use of internal fans. The air intake is from the front and the
air outlet is on the rear.
Note: Adequate cooling must be provided equaling 107 W (maximum) at 25°C per
unit to avoid overheating.
Grounding
You must ensure that the unit is properly connected to ground to meet safety and
EMC requirements. Before any other connection is made, the unit must be connected
to a protected ground terminal as described below:
Via the three wire power cord of the AC power supply. This connection is
mandatory.
In addition, via the protective ground terminal on the rear panel of the unit. This
connection provides additional protection of the equipment.
Mounting the D9854/D9854-I Receiver to a Rack
1 Mount L-brackets in the rack to support each unit to be installed.
2 Place the receiver in its position in the rack.
3 Mount the receiver securely to the rack by securing the mounting flanges to the
rack using the four screws provided.
4 Make sure the air outlet holes on the back of the receiver are not obstructed to
allow air flow from the front to the back of the chass is.
Installing the D9854/D9854 -I Receiver
29
Connecting AC Power to the D9854/D9854-I Receiver
1 Connect the power cord (supplied with the D9854/D9854 -I receiver) between the
rear panel power receptacle and a 100 to 120/200 to 240 V AC power outlet.
2 Make sure that the power cable is connected to protective ground. See
Grounding (on page 28) for more information.
The unit is equipped with one power supply located in the rear of the chassis. Note
the location of the power supply in the event of alarms/warnings resulting in
replacement of a power supply. Alarm messages appear in the Message Log.
Chapter 3 Instal lation
30
D9854/D9854-I Receiver Rear Connector Panel
Connector
Description
Type
RF Inputs
Each input accepts an LNB signal input.
RF1 provides LNB power for use when no
external LNB power source is available. RF2
to RF4 require an external LNB power
source.
F
The following diagrams show the rear connector panel of the D9854 base model:
The following displays the rear connector panel of the D9854, with SDI, SD/HD -SDI,
and AES outputs:
The following displays the rear connector panel of the D9854 -I receiver, with SDI
and MPEGoIP Input:
The following table describes the function and type of the various connectors.
D9854/D9854-I Receiver Rear Connector Panel
31
Connector
Description
Type
ASI Input
Asynchronous Serial Interface Input.
BNC
ASI Output
One Asynchronous Serial Interface Output.
BNC
TS Outputs
TS Inputs/Outputs
(D9854-I only)
This is for the MPEGoIP and MPE outputs.
The MPEGoIP output transmits the
decrypted transport stream encapsulated in
IP packets to a groomer for distribution. The
MPE output receives and outputs the IP
data packets from the incoming transport
stream.
The MPEGoIP input (D9854-I only) allows
the decoder to receive its streams from the
terrestrial IP network.
RJ-45
Management
Supports the following network protocols:
Telnet, SSHv2, HTTP, HTTPS, SNMPv2,
Syslog/DTX, SNTP, FTP (client side), TFTP,
and MPEGoIP output (D9854 only).
RJ-45
HD-SDI Outputs
M1 and M2 provide HD serial digital video
with embedded audio output for HD
applications according to SMPTE-292M.
BNC
RS-232 Data
RS-232 data output: 7 bits, even parity, 1
stop bit, up to 38.4 kb/s. These outputs are
user-configurable via the Setup menu on
the front panel.
9-pin sub-D female
Cue Tone/Cue Trigger
Relay Outputs
Program relay provides programmed
responses for alarms, cue trigger states for
ad-insertion equipment, or a cue tone
output for connection to ad-insertion
equipment.
15-pin sub-D female
Composite Video
Outputs
CVBS 1 and CVBS 2 provide two identical
SD composite video outputs for monitoring
applications.
BNC
Component Video
Outputs
SD to HD upconverted component video
output for HD monitoring applications.
BNC
AES-3id Audio Outputs
AES-3id outputs. One output for each stereo
channel.
BNC
Balanced Audio Outputs
Audio 1 and Audio 2 provide two stereo
pairs or four mono channels.
Terminal Blocks
Ground
Screw.
Grounding point for
the receiver
Power
AC power.
IEC 60320 Sheet 14
Chapter 3 Instal lation
32
Connecting the Input/Output Signals
Connector
Interface type
Connector type
SMPTE-292M
BNC female
Connecting the RF Inputs
Connect up to four LNB RF cables to the RF connectors labeled RF1 through RF4 on
the rear of the unit.
Use 75-ohm (braid/foil or braid/braid), low insertion loss coaxial cable.
Each input accepts an LNB signal input. RF2 to RF4 require an external LNB power
source.
Connecting the ASI Input
If desired, connect to the ASI IN port to an asynchronous serial interface for uplink
monitoring.
Connecting the Video Outputs
The video output connectors are of the BNC type.
The following table shows the video connector:
Connecting the Component Video Output
Connect a video monitor to the connectors labeled Pr, Pb, and Y.
Connecting the Composite Video Output
Connect a video monitor to the CVSB 1 and CVSB 2 connectors. The two outputs are
identical. Use a 75-ohm double-braided coax cable.
Connecting the HD-SDI Outputs
Connect HD rebroadcast equipment to the connectors labeled M1 and M2, and/or if
required, connect them to a video monitor.
There are two connectors to provide active loop-through possibility.
Connecting the Input/Output Signals
33
Connecting the Audio Outputs
Connector
Interface type
Connector type
AES-292M
BNC female
Connector
Connector type
Terminal Block
Connectors for the Digital Audio Output
The configuration of the D9854/D9854-I receiver outputs two stereo channels. The
receiver also supports encoding of audio embedded in the HD-SDI video signal.
The following drawing shows the audio connector.
Note: The digital audio output is always 75-ohm single-ended.
Connecting the Digital Audio Outputs
Connect digital audio output broadcast equipment to the AES -3id connectors. The
two stereo channels are useful for Dolby Digital 5.1 passthrough applications. Use a
high-quality, double-shielded RJ6 coaxial cable.
Hint: For digital audio connections, use a balanced cable designed for 110 -ohm AESEBU digital audio.
Connecting the Balanced Audio Output
1 Connect the AUDIO 1 and AUDIO 2 balanced audio outputs to monitoring
equipment. Use a multi-conductor, pluggable cable from the receiver's AUDIO 1
and AUDIO 2 (Left and Right) terminals to your equipment, as shown in the
following illustration.
2 Feed the stripped ends of the positive, negative and ground wires into the
appropriate terminals as labeled, and then screw the terminal screws (located on
the top of the terminal block) finger tight to each wire.
Chapter 3 Instal lation
34
Connecting the Ethernet Management Interface
The RJ-45 interface for 100/1000BASE-T Ethernet is currently intended for
upgrading/downloading the software application. You must set up t he IP address,
the default gateway and the subnet mask to match the network connection. This is
done through the front panel menu. For further information, see Setting up for
Network Connection (on page 16).
Note: Proper cables are required for reliable Ethernet operation; to run up to a
maximum segment length of 100 m and up to 100BASE-T, the cable has to comply
with the EIA/TIA Category 5 (or higher) wire specifications, and for 1000BASE -T,
Category 6 is required. For EMC protection, shielded cables must be used.
1 Connect an RJ-45 cable between the Ethernet connector on the D9854/D9854 -I
receiver and the Ethernet port of your PC.
2 Set up the IP address on the D9854/D9854-I receiver (via the front panel
display). For information on setting up the IP address via the front panel, see
Setting up for Network Connection (on page 16).
Connecting the IP TS Input/Output
Note: The TS IN/OUT ports are only applicable for the D9854 -I only.
The RJ-45 interface IP TS OUT (D9854) or TS IN/OUT (D9854-I) is a 100/1000BASET Ethernet. It is intended for both MPEGoIP and MPE outputs, and/or MPEGoIP
input. The MPEGoIP output of the transport stream is encapsulated in the IP packets
to a groomer (for example, Cisco D9900 Digital Content Manager) for distribution.
The MPE output receives IP packets from the transport stream. The MPEGoIP input
receives transport streams from the IP network.
Note: For reliable Ethernet operation; to run over a maximum segment length of 100
m and up to 100BASE-T, the cable has to comply with the EIA/TIA Category 5 (or
higher) wire specifications, and for 1000BASE-T, Category 6 is required.
Connect a crossed RJ-45 cable between the Ethernet connector (DATA port only) on
the D9854/D9854-I receiver and the Ethernet port of the equipment after the
D9854/D9854-I receiver. The equipment after the D9854/D9854-I receiver could be
an IP router or a switch.
Connecting the ASI Output
Connect the output signal from the D9854/D9854-I receiver ASI OUT connector.
Use a Belden “Brilliance” cable with foil/braid construction. The shield must
provide 99% or better shielding effectiveness.
The equipment after the D9854/D9854-I receiver could be a Cisco D9887B HDTV
Receiver.
Connecting the Input/Output Signals
35
External Alarm System Connector
Connector
Normally
closed pin
Common pin
Normally open
pin
Relay Mode
1
15
10
CUE TONE/RELAY
11
10
15
Trigger
15
10
11
Alarm (default)
The D9854/D9854-I receiver and Alarm relay functionality. See Cue Tone/Cue
Trigger Interface (on page 36) for more information on Cue Tone and Cue Trigger
equipment connections. These outputs are user-configurable via the Setup Menu on
the front panel.
The Alarm output connector is a 15-pin sub-D female connector. The following
diagram shows the connector and the pin allocation table for the A larm output pins.
The connector pin states depend on the selected Relay Mode. The Relay Mode is set
on the front panel via the Main: Setup: Outputs menu.
Changing the Relay Mode for Alarm Monitoring
The Alarm relay is a program relay that can be configured to provide programmed
responses for alarms, warnings, cue trigger states for ad-insertion equipment, or a
cue tone output for connection to ad-insertion equipment. As a default, the Alarm
Relay is configured for Alarm mode.
1 On the front panel menu, go to the Main: Setup: Outputs, and select Cueing.
2 Use the down arrow key to scroll through the menu to Relay Mode.
3 Change the state to Alarm and press the Select key to save the new setting. As a
result, the rear panel connector pin states will change to that shown in the table
below for Alarm mode.
Note: A Normally closed state implies the state when power is applied to the relay
in a normal operating state, without a trigger or alarm condition present.
Connecting the RS-232 Data Interface
The DCE DB-9 female connector is intended for low-speed data: 7 bits, even parity, 1
stop bit, up to 38.4 kb/s (default). These outputs are user-configurable via the Setup
Menu on the front panel.
The interconnect cable from the D9854/D9854 -I receiver to a PC should be straight
through (for example, no handshaking), shielded and equipped with a DB-9 male
connector at one end to mate with the rear panel RS-232 Data interface, and a female
DB-9 connector to connect to the PC.
Chapter 3 Instal lation
36
RS-232 Data Connector Pin Allocation
Connector
Normally
closed pin
Common pin
1
9
1
Not connected
2
TxD
3
RxD
4
Not connected
5
Ground
6
Not connected
7
Not connected
8
Not connected
9
Not connected
Connector
Pin
Pin allocation
1
Cue Trig 1
2
Cue Trig 2
3
Cue Trig 3
4
Cue Trig 4
5
Cue Trig 5
6
Cue Trig 6
7
Cue Trig 7
8
Cue Trig 8
9
Not connected
10
Alarm - Ground
The table shows the RS-232 Data connector and the pin allocation:
Cue Tone/Cue Trigger Interface
The D9854/D9854-I receiver is equipped with a connector labeled Cue Tone/Relay
for alarm relay outputs for remote alarm signaling. This connector provides Cue
Tone, Cue Trigger and Alarm relay functionality. These outputs are userconfigurable via the Setup Menu on the front panel.
The connector is a 15-pin sub-D female connector. The following diagram shows the
connector and the pin allocation table for Cue Tone, Cue Trigger and Alarm relay
connections.
Connecting the Input/Output Signals
37
Connector
Pin
Pin allocation
11
Alarm - Normally open
12
Chassis ground
13
Cue Tone -
14
Cue Tone +
15
Alarm - Normally closed
Connecting the Cue Tone Interface
Connect the Cue Tone pins, 13 and 14 to a device to facilitate ad -insertion using
DTMF Analog Cue Tones.
Connecting the Cue Trigger Interface
Connect the Cue Trigger pins (1 to 8) to up to 8 serial control devices or a device to
control ad-insertion. These outputs are user-configurable on the front panel menu.
Configuring Open-collector Outputs
The D9854/D9854-I supports decoding of SCTE-35 messages with DTMF descriptor.
The D9854/D9854-I outputs tones or sets the open collector contacts according to the
content of the DTMF descriptor in the Cisco D9054 HDTV Encoder and the Cisco
D9036 Modular Encoding Platform. For information on the open-collector output
settings, see the Cisco D9054 HDTV Encoder Installation and Operation Guide and Cisco
D9036 Modular Encoding Platform Installation and Configuration Guide.
Chapter 3 Instal lation
38
Setting Admin User Privileges via a Telnet/SSH Connection
Administrator User Privileges
Up to 10 usernames/passwords can be defined for login use via a Telnet, SSH, or
web GUI (for example, HTTP) session on the D9854/D9854 -I receiver.
When a user tries to log in via a Telnet, SSH, or HTTP connection, the user is
required to provide a username and a password. The user is granted access only if
this username/password pair exists in the authentication table.
The factory preset "Admin" account has Admin privileges and is allowed to add new
users, delete users, change usernames, and modify its own passwords. Users with
non-Admin privileges (for example, User and Guest) are only allowed to modify
their own passwords.
Starting a Telnet/SSH Session
To start a communication session with the receiver, use a utility such as Tera Term
Pro or PuTTY.
Proceed as follows to log into a new connection using Tera Term:
1 In the New Connection window, enter the IP address in the Host field.
2 If you want to start a telnet session, select Telnet and enter 23 in the TCP Port#
field.
3 If you want to start an SSH session, select SSH and enter 22 in the TCP Port#
field.
4 Click OK.
5 If you started a Telnet session:
a At the Login prompt, type the username and press Enter.
b At the Password prompt, type the password and press Enter .
Note: The username and password are case-sensitive. The default username
is admin and the default password is localadmin.
c Type lr and press Enter.
6 If you started an SSH session:
a A Security Warning message is displayed (first time only). Select Add this
machine and its key to the known hosts list and click Continue. The SSH
Authentication window is displayed.
b In the User name field, type the username, admin.
Setting Admin User Privileges via a Telnet/SSH Connection
39
c In the Passphrase field, type the password, localadmin. Wait a few seconds,
Account Type
Enter
Access
Guest
3
View settings only.
User
2
View and edit settings.
Admin
1
View, edit settings, and add/delete user accounts.
until the Use rhosts to log in is disabled.
Note: The username and password are case-sensitive. The default username
is admin and the default password is localadmin.
d Click OK.
7 Type lr and press Enter.
Adding a New User
1 At the admin prompt, type pwd add_user and press Enter.
2 At the NEW USERNAME prompt, type a new username and press Enter.
3 At the NEW PASSWORD prompt, type a new password and press Enter.
Note: The new password must follow the rules configured in the Password
Complexity parameter. For more information, see To Change the User Login
Passwords (on page 290) for the web GUI or IP (on page 88) for the Front Panel.
4 At the CONFIRM NEW PASSWORD prompt, type the new password again and
press Enter.
Note: The New Password and Confirm New Password should be identical.
5 At the NEW USER PRIVILEGES prompt, enter the type of account you want to
assign the user. The following table illustrates the different login types:
6 At the ADMINISTRATOR PASSWORD prompt, type the administrator's
password and press Enter.
Deleting a User
1 At the admin prompt, type pwd del_user and press Enter.
2 At the USERNAME prompt, type the username you want to remove and press
Enter.
3 At the ADMINISTRATOR PASSWORD prompt, type in the administrator's
password and press Enter.
Changing a Username
Proceed as follows to modify a username:
1 At the admin prompt, type pwd username_change and press Enter.
Chapter 3 Instal lation
40
2 At the CURRENT USERNAME prompt, type the username you want to edit and
press Enter.
3 At the NEW USERNAME prompt, type the new username and press Enter.
Note: Ensure that the new username does not match any of the usernames
already defined in the authentication table.
4 At the ADMINISTRATOR PASSWORD prompt, type the administrator's
password and press Enter.
Changing a Password (allowed by all Users)
Passwords can be changed by all users.
1 At the admin prompt, type pwd password_change and press Enter.
2 At the CURRENT PASSWORD prompt, type the current login password you
want to change and press Enter.
3 At the NEW PASSWORD prompt, type a new login password and press Enter.
4 At the CONFIRM NEW PASSWORD prompt, type the new login password
again to confirm and press Enter.
Note: The new password and the confirm new password should be identical.
Each user, including the admin user, can modify only his own password.
Printing the List of Users
At the admin prompt, type pwd list_users and press Enter.
Note: Only usernames will be printed. Passwords will not be visible.
Resetting the Login Credentials
At any time, the user authentication table can be reset from the front panel. This
option is under the Setup: IP: IP menu. Scroll down to Reset Credentials and press
SELECT. Press and then press SELECT to confirm the operation. A new login
username and randomly generated password will be displayed on the front panel
display for approximately 30 seconds. The new account will have Admin privileges.
We recommend that this account be replaced by a login username and password
chosen by the administrator. To change the username and password, you must be an
Admin user. Refer to To Change the User Login Passwords (on page 290).
Note: After this recovery procedure, all existing user accounts will be lost.
Common Interface Modules
41
Common Interface Modules
The following is a list of all the supported CAMs:
SMiT Consumer Irdeto
- Hardware Version: 2.2.1
- Application Version: IRD-STD-3.7.0m-2
- Serial Number: 1004004052 and 1004004051
SMiT Professional Irdeto
- Hardware Version: 2.2.1
- Application Version: IRD-STD-3.7.0m-8
- Serial Number: 1103000494 and 1103000276
Conax Aston
- Hardware Version: 1.0100
- Application Version: 2.2300B
- Serial Number: 1900-237064
Conax Professional (SMiT)
- Hardware Version: 2.2.1 and 4.0.3
- Application Version: CNX-STD-2.5.9m8 and CNX-SECPLUSGRC-2.8.0m8
- Serial Number: 1104000101 and 1204069309
43
Overview
This chapter describes how to set up the Cisco D9854/D9854-I
Advanced Program Receiver using the front panel keys and display.
This information is primarily applicable for standalone operation.
4 Chapter 4
Front Panel Operation
In This Chapter
About the Front Panel ........................................................................44
Locking/U nlocking the Front Panel .................................................48
Startup Screen.....................................................................................49
Main Menu ..........................................................................................53
Status Menu ........................................................................................54
Setup Menu.........................................................................................70
About Menu......................................................................................147
Versions Menu ..................................................................................149
Diagnostics Menu .............................................................................152
Chapter 4 Fr ont Panel Oper ation
44
About the Front Panel
The D9854/D9854-I receiver is operated using controls and indicators on the front
panel. These include the numeric keypad, the Navigation/Selection keypad, the
LCD, the Alarm and Signal indicators. These are shown in the following illustration.
LCD
Keypad
CI Slots
The LCD provides information on the selections available at any menu level, current
settings for parameters, and certain status and alarm indications. This is a 2x40,
backlit LCD display. The top line may be status data or identifier information. I t can
also display optional functions available for tuning operations. The bottom line will
show selections or parameter values available using the navigation/selection
keypad. The items are selected by pressing the SELECT (center key) or the (down
arrow) key on the navigation/selection keypad.
The numeric keypad is used to enter alphanumeric values. The MENU key sets the
software to the initial menu and returns to the previous menu. The MENU key can
also be used to cancel a numeric entry at any point during the entry sequence, and
the (left arrow) key allows backspacing through the entry.
The CI slots allow the use of CAM (Conditional Access Module) Smart Card to
decrypt purchased programming. For setup information, see Setup Menu: Common
Interface (CI) (on page 108). For a list of supported CAMs, refer to Common
Interface Modules (on page 41).
Front Panel LEDs
The functions of the LEDs are described in the table below.
About the Front Panel
45
LED
Signal
State/Color
Explanation
ALARM
Red
Solid for five seconds indicates a Warning.
Red
Flashing indicates an Alarm.
SIGNAL
Green
Solid indicates all of the following conditions:
active RF inputs are enabled, locked to a
signal, and are not muted.
all outputs are operating without an error.
Green
Flashing indicates one of the following
conditions:
difficulty with an input, route, or output.
one or more of the inputs are not
synchronized.
one or more ASI outputs are routed, but
muted by a fault condition.
no RF signal is present or detected, or it is
muted.
receiver is not authorized to receive the
program.
Off
Off indicates all of the following conditions:
no RF input signal is available, enabled or
detected, or the input is muted.
no ASI input is present.
no valid inputs are available.
Navigation/Selection Keypad
Throughout this manual, there are references to parts of a keypad on the front of the
receiver.
The navigation keys (LEFT, RIGHT, UP, and DOWN) and the SELECT key are the
primary controllers. Each navigation key performs various functions, depending on
the current state of the menu system (that is, sometimes the left navigation key
backspaces over an entry and sometimes moves the cursor to a different menu item).
Once the cursor is over the desired function, pressing the SELECT (center key) key
selects the current item. Pressing the SELECT key stores any entered values.
Chapter 4 Fr ont Panel Oper ation
46
The following is the Navigation/Selection keypad, which changes its function,
Button
Function
LEFT Arrow key
When moving through menus,
highlights the menu item to
the left. When entering data,
moves the cursor to the left. In
some menus, backspaces over
the data entry.
RIGHT Arrow
key
When moving through menus,
highlights the menu item to
the right. When entering data,
moves the cursor to the right.
UP Arrow key
Highlights the menu item
above.
DOWN Arrow
key
Highlights the menu item
below.
SELECT key
Runs the highlighted
command or opens the
highlighted menu.
INFO key
Press the key on the lower left
of the numeric keypad for
context-sensitive help
messages, when available.
When entering characters in
numeric or alphanumeric
fields, this key can be used to
toggle between uppercase and
lowercase.
MENU key
Press the key on the lower
right of the numeric keypad.
Starts the on-screen display.
Also functions as the Escape
key so you can back out of
menus and data entry fields.
depending on the current state of the menu.
The table below describes the front panel buttons.
About the Front Panel
47
Button
Function
Alphanumeric
Entry
Pressing the numeric keys 2-9
once will enter the respective
digit into a data entry field.
Pressing these buttons again
will enter the first of the letters
displayed beside the number.
Repeatedly pressing the
button will toggle through all
of the key's possible choices.
When entering text, the 1
button can be used to insert
spaces (press twice).
To delete a character, press 0
twice.
ADV
Toggles between Program
Entry and Channel number.
MAP
Edit, insert, and delete Digital
Program Mapping (DPM)
Modes on Program Entries or
on PIDS within Program
Entries.
NAV
For future use.
Chapter 4 Fr ont Panel Oper ation
48
Locking/Unlocking the Front Panel
Depending on the default settings, the receiver is shipped with a locked or unlocked
front panel. You can lock or unlock the front panel using the front panel keypad.
1 From the Startup screen, press SELECT and then INFO. This will unlock the
front panel keypad and allow you to make changes to all the operating
parameters; however, if the keypad remains untouched for the duration of the
set timeout period (default is 60 seconds), the keypad will change back to the
Lock state unless you change the keypad state on the Admin Menu. Likewise
you can toggle the keypad lock state back using SELECT and INFO at any time
provided the KB Lock state on the Admin Menu is Enabled. For more
information on front panel keypad buttons, see Navigation/Selection Keypad (on
page 45).
Note: If the lock level is 3 or 4, you must enter a password to unlock the front
panel. For more information on lock level password, see Setup Menu: Admin (on
page 71).
2 To disable Lock completely, navigate to Setup, Admin, KB Lock in the LCD
display and press the SELECT key.
3 Change the KB Lock state from Enabled to Disabled.
4 The front panel will now be unlocked allowing you to change any of the
operating parameters.
To lock the front panel, perform the same procedure, except use to change
the state. In this case you will not be prompted to confirm the operation.
Startup Screen
49
Startup Screen
Auth Status
Description
Y
Indicates the channel is authorized.
N
Indicates the channel is not authorized.
LCD Setting
Description
PE
Program Entry (PE). The receiver supports up to 16
program entries.
Note: Only PE1 supports PowerVu descrambling. Do
not assign PowerVu channels to PE2 to PE16. If any
PowerVu channels are assigned to PE2 to PE16, all
Service PIDs associated with these channels will be
dropped from the transport output.
All 16 PEs can use the Conditional Access Modules
(CAMs).
12345
Channel for program monitoring.
Main Structure
At power on and initialization, the startup screen is displayed similar to that shown
below. The screen also indicates the signal status.
Channel Authorization Status
From the startup screen, press the right or left arrow keys on the front panel keypad
to move to the PE entry authorization status screen. This screen indicates whether
the selected channel is authorized.
LCD Panel
The LCD panel displays basic signal and program information in the LCD display,
as described in the following illustration:
Chapter 4 Fr ont Panel Oper ation
50
LCD Setting
Description
Channel name
Name of the monitored program.
RF
Active RF input port.
Note: ASI will be shown if the ASI input port is active.
Freq:
Downlink frequency of the tuned signal in GHz.
Lvl:
Signal level in dBm.
Marg:
Carrier-to-noise (C/N) margin in dB.
DEGD
The Degraded indicator only appears if there is
degraded tuning information in use. This occurs if the
SI tables are not consistent on the incoming stream. The
receiver will attempt to identify the service list based
on the information available. Check the SI acquisition
and stream information to ensure that the channels,
network, and tuning information are operating as
expected.
LCD Symbol
Description
The Hourglass indicates that parameters are being
saved in the background. You can continue to perform
any operation desired.
Note: If a power-cycle/interruption occurs while the
hourglass is displayed, some parameters may not be
saved. Refrain from powering off the unit while the
hourglass is displayed.
The Info symbol indicates that the INFO key is active.
In most cases, this will display contextual information
on the LCD screen.
The Select symbol indicates that the SELECT key is
active.
LCD Symbol
Various symbols will periodically appear in the top right-hand corner of the LCD
panel, indicating which user actions are currently acceptable. The following displays
the location of the symbol:
The following table describes the various symbols:
Startup Screen
51
LCD Symbol
Description
The Left/Right symbol indicates that the
RIGHT/LEFT arrow key is active; for example,
pressing the RIGHT/LEFT arrow key will have an
affect, such as moving the cursor to the right/left.
The up/down symbol indicates that the UP/DOWN
arrow key is active.
The Download In Progress (DL) symbol indicates that
the receiver is currently downloading a software
update and storing it into memory in the background.
Note: Service interruption occurs during a reboot,
which is always required when the receiver’s software
is updated.
The Download Trigger (DT) symbol indicates new
software is ready for download, but a download
trigger by the receiver is required before it will be
downloaded.
Note: Service interruption occurs during a reboot,
which is always required when the receiver’s software
is updated.
The Download symbol indicates that a software
download for a version of software already in memory
has been detected.
The Disaster Recovery (DR) symbol indicates that a
disaster is declared on the current receiver.
The NIT Retune (NR) symbol indicates that a NIT
retune recovery is in progress on the current receiver.
o
The Session Open symbol indicates that you are
changing a group of related items.
s
PE1 706 Channel Name
RF1 Freq:12.658 Lvl:-50 Marg:11.6
Ch #PE #
Assigning Program to the Program Entry
1 Press MENU until you display the startup screen.
The PE (Program Entry) channel is initially displayed.
Note: PE1 is the default.
Chapter 4 Fr ont Panel Oper ation
52
2 Press the ADV key to select PE1.
s
PE1 1 Channel Name
RF1 Freq:12.658 Lvl:-50 Marg:11.6
PE
s
PE1 1 Channel Name
RF1 Freq:12.658 Lvl:-50 Marg:11.6
Ch #
s
PE1 706 Channel Name
RF1 Freq:12.658 Lvl:-50 Marg:11.6
Ch #PE #
s
PE1 1 Channel Name
RF1 Freq:12.658 Lvl:-50 Marg:11.6
PE
3 Press to scroll through the available program entries.
4 Press ADV again to select the channel number.
5 Directly enter the channel number using the 0 to 9 keys and press SELECT to
apply the channel number, or press to scroll through the available channels.
Deleting a Program from the Program Entry
1 Press MENU until the startup screen appears.
The PE channel is initial displayed.
Note: PE1 is the default.
2 Press the ADV key to select PE1.
3 Press the to scroll through the available program entries.
4 Press ADV again to select the channel number.
5 Enter the channel number 0 with the numeric keys and press SELECT to apply
and delete the program.
Main Menu
53
Main Menu
Main Menu 1/2
Status Setup About Versions
i
s
Main Menu 2/2
Diagnostics
i
s
Operation of the D9854/D9854-I receiver begins at the Main menu. From the startup
screen, press the MENU key to view the Main menu.
Select the desired function by moving the cursor left or right by pressing the LEFT or
RIGHT arrow key. Once a selection is made by pressing the SELECT key, the LCD
presents the second menu level for the selected function. Succeeding levels for each
function include all the hierarchical levels for the function in the front panel LCD.
Chapter 4 Fr ont Panel Oper ation
54
Status Menu
To view the Status menu from the Main menu, press the SELECT key. The Status
menu indicates the status of the input and output signals, the video and audio
services, and allows you to browse and/or configure the alarms and warnings.
The Status menu is split into four parts; General, Services, TS Input, TS Output, and
IP. Each parameter is described in this section. For instructions on how to select and
store settings, see About the Front Panel (on page 44).
The Status menu has the following structure:
Status Menu
55
Status Menu: General
Menu Item
Description
Parameters
Input
Indicates the currently selected input
source.
RF1 to RF4, ASI, or IP.
Status
Indicates whether the input signal is
locked.
Locked - Indicates the receiver is
locked to a carrier with no valid
content.
Lock+Sig - Indicates the receiver
is locked to a carrier with valid
content.
No Lock - Indicates the receiver
is not locked to a carrier.
Rate (Mbps)
Indicates the bit rate of the input transport
stream, in Mbps.
–
Level (dBm)
Indicates the strength of the received
signal level, in dBm.
–
PE
Select the Program Entry to view.
PE1 to PE16.
Mode
Indicates how the program is scrambled.
Unkn, DES, DVB, BISS1, BISS2,
or BISS3.
Auth
Indicates whether the receiver is
authorized to receive the program.
Yes or No.
Enc
Indicates whether the received program is
encrypted.
Yes or No.
Scr
Indicates whether the received program is
scrambled.
Yes or No.
CA System
Indicates the type of Conditional Access
(CA) system used by the program.
SA, BISS, or FTA (Free To Air).
Video
Indicates the video encoding, format, and
resolution of the received program.
MPEG1, MPEG2, or H264 format
with a resolution of:
SD480i/2997, SD480i/3000,
SD576i/2500, HD720p/5000,
HD720p/5994, HD720p/6000,
HD1080i/2500, HD1080i/2997,
or HD1080i/3000
Unknown or Unsupported.
Rate (Mbps)
Indicates the bit rate of the received video
stream, in Mbps.
–
Alarms
Displays the number of active alarms.
–
Warnings
Indicates the number of active warnings.
–
Chapter 4 Fr ont Panel Oper ation
56
Menu Item
Description
Parameters
Browse
Select to view the current active alarms
and warnings, including additional details.
–
Clear All
Select to clear all the active alarms and
warnings. You will be prompted to verify
whether you want to clear all the alarms
and warnings.
Abort, Continue. Select Abort to
cancel the operation or Continue
to clear all the warnings and
alarms.
Current Date and
Time
Displays the current SNTP date and time,
if available. Otherwise, the current TDT
date and time is displayed.
Note: This is displayed as local time.
–
Current TDT Date
and Time
Displays the current TDT (Time and Date
Table) date and time received from the
DVB stream.
Note: This is displayed as local time.
–
Current SNTP Date
and Time
Displays the current SNTP (Simple
Networking Time Protocol) date and time
if IRD receives a valid reply from the NTP
server.
Note: This is displayed as local time.
–
Menu Item
Description
Parameters
Video
Indicates the video encoding, format,
and resolution of the received
program.
MPEG1, MPEG2, or H264 format
with a resolution of: SD480i/2997,
SD480i/3000, SD576i/2500,
HD720p/5000, HD720p/5994,
HD720p/6000, HD1080i/2500,
HD1080i/2997, or HD1080i/3000
Unknown, or Unsupported
Rate (Mbps)
Indicates the bit rate of the received
video stream, in Mbps.
3:2 Pulldown
Indicates whether the 3:2 pulldown is
detected, was recently detected, or
not detected in the input video
stream.
Yes, No or Recent
Status Menu: Services
Video
Status Menu
57
Menu Item
Description
Parameters
FPS
Indicates the frame rate of the input
video stream.
Typically 25.0, 29.97, 30.0, 50.0,
59.94, 60.0, unknown or
unsupported
Stream AR
Indicates the aspect ratio of the
incoming video stream.
4:3, 14:9 or 16:9
Act Conv
Displays the actual applied aspect
ratio conversion.
None, 4:3 L/B, 4:3 P/B, 14:9, 14:9,
4:3 F/H or 16:9 F/W
Menu Item
Description
Parameters
AUD
Indicates the current audio decoder
status.
AUD1 for audio channel Aud1.
AUD2 for audio channel Aud2.
AUD1 to AUD4 for two stereo
audio channels.
Format
Indicates the format of the audio
input stream.
None, Sine, Pink, Beep, MPEG1L1,
MPEG1L2, MPEG2L1, MPEG2L2,
AC3, LOAS AAC, ADTS AAC,
LOAS HEAAC, ADTS HEAAC, or
DDP
BR (Kbps)
Indicates the bit rate of the audio
input stream, in kbps.
Buffer
Indicates the buffer level of the input
audio stream, in bytes.
SFR (Kkz)
Indicates the sample rate of the input
audio stream, in kHz.
32.0, 44.1, or 48.0 kHz
DDP IND
Indicates the presence of Dolby
Digital Plus frames within a Dolby
Digital Plus audio stream.
OFF or ON
DUAL-MONO IND
Indicates the presence of dual mono
audio outputs in the audio stream. If
the dual mono indicator is set to ON,
the left and right outputs will
correspond to mono channel 1 and
mono channel 2 respectively.
OFF or ON
Audio
Chapter 4 Fr ont Panel Oper ation
58
Menu Item
Description
Parameters
Interlaced
Displays whether the video is
interlaced.
Yes or No
Frames
Displays the number of frames per
second.
–
Lines
Displays the video resolution
(number of lines per frame).
–
Words
Displays the number of VANC words
per line.
–
First/Last/Switch
Displays the range of inactive video
lines (First to Last) for the current
video format. The VANC data is
inserted in the video line(s), following
the Switch line. The numbers are for
the top field if it is an interlaced
video, or for the frame if it is a
progressive video.
Note: The SMPTE standard
recommends using lines starting from
Switch line + 2.
–
Multiline
Displays whether Multiline VANC
insertion is supported. For D9854
with SDI units, this is only supported
in the current FPGA implementation
(R00.00.05). If a previous FPGA
version is installed, Multiline is not
supported until you upgrade the
FPGA.
Yes - It will follow the user
selections in SDI setup. For more
information, see SDI (on page 104).
No - All the services are inserted
into a single line.
Menu Item
Description
Parameters
Service ID
Lists all the services.
EIA-708, AFD, DPI, SMPTE-2031,
Multi-OP47, and SDP-OP47
SDI - Global
Note: This feature is for D9854-I and D9854 with SDI only.
SDI - VANC Services
Note: This feature is for D9854-I and D9854 with SDI only.
Status Menu
59
Menu Item
Description
Parameters
Act
Displays whether the selected service
is inserted.
Yes - The selected service is
inserted.
No - The selected service is not
enabled by the user or not present.
Adj
Displays the line number where
the selected service is expected to
be inserted by the hardware (for
the top field if it is an interlaced
video, or for the frame if it is a
progressive video). If Multiline is
not supported, the Adj value is set
to Switch line + 2. For more
information, see SDI - Global (on
page 57).
–
L-F1/L-F2
Displays which line on Field 1 and
Field 2 the selected service is present.
If the service is not inserted, 0 is
displayed.
–
Lines
Displays the number of video lines
used to send data for the selected
service.
–
Avg Data
Displays the number of words per
frame the selected service occupies.
–
Pkt OK
Displays the number of transmitted
data packets, per frame, for the
selected service.
–
Pkt Drop
Displays the number of dropped data
packets for the selected service.
–
Menu Item
Description
Parameters
Input
Indicates the active input port receiving
the signal.
RF1, RF2, RF3, RF4, ASI, or IP
Status Menu: TS Input
Input
Chapter 4 Fr ont Panel Oper ation
60
Menu Item
Description
Parameters
Status
Indicates the current signal lock status
for the input.
Locked - Indicates the receiver is
locked to a carrier with no valid
content.
Lock+Sig - Indicates the receiver is
locked to a carrier with valid
content.
No Lock - Indicates the receiver is
not locked to a carrier.
Rate (Mbps)
Indicates the bit rate of the received
input signal.
in Mbps
Level (dBm)
Indicates the signal level of the received
signal.
in dBm
SymRate
Indicates the Symbol Rate of the
received signal.
in Msymbols/second
FEC
Indicates the FEC (Forward Error
Correction) rate of the received signal.
N/A, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6,
7/8, 8/9 or 9/10
Modulation
Indicates the modulation type for the
received signal.
N/A, QPSK, 8PSK, DVB-S, DVBS2 or 16QAM
Pol
Indicates the signal polarization setting.
This setting is only applicable when
LNB Power is set to H-NIT or V-NIT.
The selected setting must match the
polarization of the transmitted signal.
Horiz (Horizontal), Vert (Vertical)
or Auto
IQ Tuner
Indicates the IQ (Input Signal Inversion)
for the received signal.
Inv or NonInv
IQ Status
Indicates the input signal spectrum
inversion setting (IQ), which allows the
operator to track and select inverted
and non-inverted digital signals.
Auto, Opposite, or Normal
Dnlk Freq (GHz)
Indicates the current downlink
frequency.
in GHz
L-Band
Indicates the current L-Band frequency.
in MHz
Pilot Present
Indicates whether a Pilot is present for
the received signal. The Pilot is set on
the modulator for input signal
synchronization purposes.
Yes, No, or N/A
C/N (dB)
Indicates the current Carrier-to-Noise
ratio.
in dB
Status Menu
61
Menu Item
Description
Parameters
C/N Margin (dB)
Indicates the current Carrier-to-Noise
Margin for the received signal. The
Carrier-to-Noise margin is the actual
distance that C/N is from the noise
threshold.
Values can be displayed in the
range of -32.0 to +30.0 dB.
PER
Indicates the current PER (Packet Error
Rate) of the received signal (DVB-S2).
–
PVBER
Indicates the PV (Post-Viterbi) BER for
the received signal (DVB-S).
–
LDPCBER
Indicates the LDPC (Low Density Parity
Check) error rate for the received signal
(DVB-S2).
–
AFC (MHz)
Indicates the current Automatic
Frequency Control count.
in MHz
UEC
Indicates the current Uncorrected Error
Count for the received signal.
–
CEC
Indicates the current Corrected Error
Count for the received signal (DVB-S).
–
Clear Counts
Select this option to clear the error
counters.
–
ASI Link
Indicates whether there is a transport
stream link error.
Error, Ok, or N/A
Transport
Indicates the current transport
synchronization status.
Error, Ok, or N/A
Packet Size
Indicates the packet size (in bytes) for
the ASI input.
188, 204, or N/A
Net Name
Indicates the name assigned to the
network.
Up to 12 alphanumeric characters.
NetID
Indicates the Network ID of the uplink
signal the receiver is to receive when
using the selected preset. The receiver’s
Network ID must match the Network
ID associated with the transmitted
signal that identifies the NIT to be used.
Note: Each network must be assigned a
unique ID (number).
1 to 65535
TxID
Indicates the Transport ID.
1 to 65535
LNB Stat
Indicates the current Low Noise Block
(LNB) connection status.
No Load, Over Loaded, Over
Temperature, Short Circuit,
Disabled, Normal or N/A
Chapter 4 Fr ont Panel Oper ation
62
Menu Item
Description
Parameters
Polar
Indicates the polarity of the LNB Power
supply.
Off, 13V, or 18V
LO Select
Indicates whether a 22 kHz tone is
available on input port RF1. This is
applicable for dual-band applications.
On or Off
Menu Item
Description
Parameters
PE
Select the Program Entry to view.
PE1 to PE16
Stream
Indicates the name assigned to the
Program Entry.
Up to 4 alphanumeric
characters
Detail
Indicates any detail associated with
the program PID (e.g., MPG2 PID).
MPG1 VID, MPG2 VID, 422
VID, H264 VID, HD VID, MPG4
VID, MPG AUD, MPG2 AUD,
DVB AC3, DVB DDP, AAC
AUD, HEAAC, AUD, MPG4
AUD, DBE AUD, DTS AUD,
DVB TXT, DVB VBI, DVB
SUBT, DVB ASYN, DVB SYNS,
DVB SYND, DVB MPE, DVB
DCAR, DVB OCAR, SA VBI,
ATSC AC3, ATSC DDP, SA
UTLD, SCTE DPI, SA HSD, SA
CDDL, SA WBD, SA SUBT,
ECM, EMM, PCR, or
UNKNOWN
PID
Indicates the program PID number.
1 to 8191
Present
Indicates whether the PID is present
in the incoming stream.
Yes or No
Menu Item
Description
Parameters
PE
Select the Program Entry number to
view.
PE1 to PE16
Program PIDs
Program Status
Status Menu
63
Menu Item
Description
Parameters
SR Status
This displays the status of an
alternate authorized
program/service from the same
transport stream when the receiver
is not authorized to view the
primary program. This is an uplink
initiated function that maps the
alternate service to the original
(primary) service PIDs, replacing
the original service with the
alternate service at the digital
transport output. No local
intervention is required by the
receiver operator for provision of
this service replacement feature.
Not Started - Indicates that an event has
not started.
Primary - Indicates that a service
replacement event is active, but the
primary program is being displayed.
Alternate - Indicates that a service
replacement event is active, and that the
receiver has tuned to and is displaying
the alternate program/event as it is not
authorized to view the scheduled event.
SR Event Type
Indicates the type of service
replacement event.
None - Indicates that no service
replacement event is scheduled.
Scheduled - Indicates that all receivers
will tune to the alternate program at the
scheduled time. This status applies to
PE1 (PowerVu) only.
CA - Indicates that only receivers
unauthorized to view the scheduled
program will tune to the alternate
program according to the selected
authorization tier bits. This status
applies to PE1 (PowerVu) only.
Cue Trigger - Indicates that only
receivers authorized by the Cue Trigger
mask will tune to the scheduled
program/event. Cue triggers can only
be initiated/controlled on PE1 (i.e.,
PowerVu).
SR Event Start
Displays the start time of the
service replacement event when
one is scheduled; otherwise, the
default start time is displayed. The
default start time is 2007/09/01
00:00:00.
–
SR Event End
Displays the end time of the service
replacement event when one is
scheduled; otherwise, the default
end time is displayed. The default
end time is 2007/09/01 00:00:00.
–
Chapter 4 Fr ont Panel Oper ation
64
Status Menu: TS Output
Menu Item
Description
Parameters
Output
Indicates the output type.
ASI or MPEGoIP
Rate (Mbps)
Indicates the current output bit rate.
0 to 206 Mbps
Free (Mbps)
Indicates the available bandwidth, in Mbps
(without stuffing).
Output Status
Status Menu - IP
To view the IP menu from the Status menu, press the RIGHT arrow key four times.
The IP menu provides Link, Redundancy, and MOIP status information.
The IP menu has the following structure:
Link Status
The Link Status parameters display the port information, such as the status, speed,
duplex, and crossover. For D9854, port 1 is the management port and port 2 is the
data port. For D9854-I, port 1 is the management port, port 2 is the Data1 port, and
port 3 is the Data2 port.
Status Menu
65
Menu Item
Description
Parameters
Ports in Use
The current output port in use.
None, Data1, Data2, or
Both
Change Reasons
Description of the reason for the last redundancy
status change.
Link, Setup, or
Setup+Link
Change Date &
Time
Displays the last date and time the redundancy
status changed.
YYYY/MM/DD
HH:MM:SS
Menu Item
Description
Parameters
Engine Error
Indicates a critical hardware error that may require
a unit reboot.
Yes or No
Stream Overflow
Indicates the MPEG over IP transport stream(s)
overflow status.
Yes or No
Combined User
Rate
Displays the combined output bit rate for all the
configured streams (including FEC).
Actual Rate Port
1/2
Displays the current output bit rates for Data1 and
Data2 ports (including FEC).
0 to 206 Mbps
Menu Item
Description
Parameters
PE ID
Displays the program entry channel.
1 to 16
Stream Port1/Port2
Indicates the stream status of the Management and
Data ports (D9854), or Data1 and Data2 ports
(D9854-I).
Stopped, Suspended,
Active, or Muted
Content Overflow
Indicates if the rate of the transport stream(s) to be
encapsulated (including FEC) is higher than the
configured output bit rate.
Yes or No
Link Overflow
Indicates if the configured output bit rate
(including FEC) is close or higher than the current
Ethernet link speed for the Ethernet port used for
MPEGoIP output.
Yes or No
Redundancy Status
Note: This feature is for D9854-I only.
MOIP Out Global Status
MOIP Out Stream Status
Chapter 4 Fr ont Panel Oper ation
66
MOIP In Redundancy Status
Menu Item
Description
Parameters
Port In Use
The current input port in use.
Data1 or Data2
Change Reason
Description of the reason for the last redundancy
status change.
None, Setup,
EthLinkStatus, TS
Status, ProgStatus
Change Date &
Time
Displays the last date and time the redundancy
status changed.
YYYY/MM/DD
HH:MM:SS
Menu Item
Description
Parameters
Data1/Data2
Source Host
When locked, this displays the source/host IP
address of the originator. If the signal is not locked,
it will display N/A.
–
Data1/Data2 MOIP
Type
Displays the encapsulation type of transport
stream received from the DATA1 or DATA2 port.
UDP or RTP
Menu Item
Description
Parameters
FEC Rate
Displays the input stream bit rate, reported by the
FEC decoder.
in Mbps
CEC
Indicates the current Corrected Error Count for the
received signal.
–
PER
Indicates the current Packet Error Rate of the
received signal.
–
FEC Rows(D)
Displays the number of FEC rows.
0 to 20
Present
Displays whether the FEC rows stream is present.
Yes or No
Col(L)
Displays the number of FEC columns
0 to 20
Present
Displays whether the FEC columns stream is
present.
Yes or No
FEC Overhead
Displays the FEC overhead, compared to the
transport stream bit rate, in percentage.
–
Note: This feature is for D9854-I only.
MOIP In IP Source Status
Note: This is for D9854-I only.
MOIP In FEC Status
Note: This is for D9854-I only.
Status Menu
67
Menu Item
Description
Parameters
Latency (ms)
Displays the delay that is introduced by the FEC
decoder, in milliseconds.
–
Status Menu - D/R
To view the D/R (Disaster Recovery) menu from the Status menu, press the RIGHT
arrow key five times. The D/R menu provides the current disaster recovery status
information. For more information on disaster recovery, see Disaster Recovery (on
page 8).
The DR menu has the following structure:
Chapter 4 Fr ont Panel Oper ation
68
Global Status
Menu Item
Description
Parameters
State
Displays the current disaster recovery status. For
more information on the statuses, see Viewing the
Disaster Recovery Status (on page 187).
No Disaster - D/R
Ready, D/R in
progress, D/R disabled
- Maintenance Mode,
D/R disabled, No
Disaster - D/R Ready
(Transport Only), No
Disaster - D/R Not
Ready (No Search
Path), No Disaster D/R Not Ready
(Malformed DRT), D/R
in progress (Transport
Only), D/R in progress
(No search path), D/R
in progress - D/R Not
Ready (Malformed
DRT), NIT Retune
Recovery in progress,
Goto RF n OK/FAIL/No Action,
Goto Backup n OK/FAIL/No Action,
Goto Origin OK/FAIL/No Action,
Goto Preferred RF OK/FAIL/No Action
Configured By
Displays the current disaster recovery setting.
User - The unit is using the disaster recovery
settings configured locally.
Uplink - The unit is using the PNC disaster
recovery profile.
User or Uplink
Signal Loss Timer
Indicates the time, in seconds, the unit must wait
(after detecting a signal loss) before declaring a
disaster.
If the Profile is set to User, it displays the time set
by the local unit.
If the Profile is set to Uplink, it displays the time
set by the PNC uplink. But if the unit is not
connected to the uplink, the default value of the
unit is displayed.
5 to 2160000
Status Menu
69
Menu Item
Description
Parameters
Signal Lock Timer
Indicates the time, in seconds, the unit must wait
for a signal lock before declaring that the signal is
not usable and move on to the next search location
in the search path.
If the Profile is set to User, it displays the time set
by the local unit.
If the Profile is set to Uplink, it displays the time
set by the PNC uplink. But if the unit is not
connected to the uplink, the default value of the
unit is displayed.
5 to 255
Verify Timer
Indicates the time, in seconds, the unit must wait
for the PAT table to verify the signal has a valid
transport.
If the Profile is set to User, it displays the time set
by the local unit.
If the Profile is set to Uplink, it displays the time
set by the PNC uplink. But if the unit is not
connected to the uplink, the default value of the
unit is displayed.
10 to 255
Menu Item
Description
Parameters
PE
Displays the program entry.
PE1 to PE16
Backup Channel
Displays the channel number assigned to the
selected backup transport.
–
Transport #
Displays the backup transport number for the
program entry selected.
1, 2, or 3
Menu Item
Description
Parameters
Backup
Indicates the configured backup transport entry
number.
1, 2, or 3
Input, NetId, Freq
(GHz), SymRate,
FEC, OrbPos, E/W,
Pol, Modulation,
Rolloff, Config by
For information on the tuning parameters, see
Status Menu: TS Input (on page 59).
Note: The RF input must be configured to match
the bandwidth of the backup parameters.
–
Backup Channel Status
Backup Transport Status
Chapter 4 Fr ont Panel Oper ation
70
Setup Menu
To view the Setup menu from the Main menu, press the RIGHT arrow key once and
the SELECT key. The Setup menu is split into nine parts; Administration, TS Input,
IP, Services, CI, Outputs, CA, Alarms/Warnings, and Noise Cutoff. For instructions
on how to select and store settings, see About the Front Panel (on page 44).
The Setup menu allows you to set all the parameters associated with the following:
Administration - lock level, password, factory reset, keypad lock, download
mode and date and time
TS Input - frequency parameters for acquiring and locking on to an RF signal, or
receiving an ASI input
IP - parameters for setting up the Ethernet ports
Services - audio video, captions, and VBI
CI - parameters to decrypt programming available from service provider
programmers via CAM Smart Cards
Outputs - alarm relays, cue tone/cue trigger setup, parameters for setting up the
transport stream out, which includes DPM
CA - conditional access
Alarms/Warnings - enables alarms/warnings traps and relays
Noise Cutoff - muting thresholds
D/R - global, backup channel, and backup transport parameters for disaster
recovery
The Setup menu has the following structure:
Setup Menu
71
Setup Menu: Admin
Menu Item
Description
Parameters
Lock Level
Sets the front panel interface lock
level.
For information on each of the lock
levels, see Factory Default
Settings and Lock Levels (on page
390).
0, 1, 2, 3, or 4
To view the Admin menu from the Setup menu, press the SELECT key.
For instructions on how to select and store settings, see About the Front Panel (on
page 44).
The Admin menu has the following structure:
Chapter 4 Fr ont Panel Oper ation
72
Menu Item
Description
Parameters
Password
Enter the password to successfully
set the current lock level.
Depending on the unit, the default
password for all lock levels is 1234.
For more information on the
default password, contact Cisco
customer support.
–
Old Pwd, New Pwd,
Confirm Pwd
To change the password, enter the
old password (Old Pwd). Next,
enter the new password (New
Pwd, four digits in the range from
0000 to 9999) and re-enter the new
password for confirmation
(Confirm Pwd). To change the
password, the receiver must be in
Lock Level 0. Depending on the
unit, the default password is 1234.
For more information on the
default password, contact Cisco
customer support.
–
Factory Reset
Select this option to perform a
reset of receiver settings back to
the factory set (default) values. A
warning message prompts you to
confirm the operation.
Reboots Unit - you are
prompted to verify the
operation.
Abort or Continue
Clear FWD tables
Select to clear settings that are only
used in older applications.
Reverting back to an older
application will revet to the default
values of the cleared settings. A
warning message prompts you to
confirm the operation.
Abort or Continue
Reboot
Allows you to reboot the receiver.
You will be asked to confirm the
operation.
Select Continue to reboot the
receiver or Abort to cancel the
operation.
KB Lock
Select whether to lock the front
panel keypad after a time of
disuse.
Enabled or Disabled
KB Lock Timeout
If KB Lock is enabled, you can sets
the keypad lock timeout period, in
seconds. The keypad will lock after
the set period of disuse. Avoid
setting the period to a short
duration when the keypad is used
often.
5 to 1800 seconds. The default is
60 seconds.
Setup Menu
73
Menu Item
Description
Parameters
LCD Contrast
Adjusts the contrast of the LCD
menu panel.
1 (lowest contrast) to 30 (highest
contrast)
DL Mode
Set the unforced over-the-air
download mode.
Always - Unforced download
will be accepted and saved in
memory.
Once - An unforced download
will be accepted, followed by a
reboot of the receiver, and the
DL Mode will change to Never.
Never - Unforced downloads
will not be accepted.
Note: Forced downloads
(initiated by the uplink) are
always accepted and always
result in a reboot of the receiver.
Service interruption will occur!
Limit Version
Indicates the oldest version of the
application that can be installed on
the current unit. Older
applications will not be installed.
Read-only alphanumeric value
DL Status
Indicates the current download
state.
Init - Download component is
being initialized. You cannot
perform a download while in
this state.
Ready - Download component
is ready to receive downloads.
Buffer - Download in progress.
The CDTs are being received.
Program - The application is
being written to flash.
Swap - The IRD is swapping to
a new application and it will
reboot.
Shutdown - The IRD is shutting
down and it will reboot.
App Erase - An application is
being erased from the flash.
FPGA Erase - A Field
Programmable Gate Array
(FPGA) code is being erased
from the flash.
Chapter 4 Fr ont Panel Oper ation
74
Menu Item
Description
Parameters
Type
The type of download being
performed.
None - No download is being
performed.
Rear Panel - The rear panel
download is being performed.
HTTP - An HTTP download
from the web GUI is being
performed.
Over Air - An over-the-air
download is being performed.
Bank
The type of code being
downloaded.
App 5514 - Currently
downloading code for app5514
on the HDR/HDR2 board.
App 7109 - Currently
downloading code for app7109
on the HDR/HDR2 board.
FPGA 7109 - Currently
downloading FPGA code to the
HDR/HDR2 board.
Note: The FPGA download
does not occur over-the-air.
CDT#
Indicates the total number of
expected code tables in the current
download.
Read-only numeric value.
Recv
Displays the number of code tables
received since the last completed
or aborted download, or power-
cycle.
Read-only numeric value.
Reject
Displays the number of code tables
rejected. Tables are rejected
whenever validation fails due to
things like CRC failure or incorrect
code or receiver type.
Read-only numeric value.
Command
Select a command to issue to the
current download. This command
is for over-the-air downloads only.
It has no effect on the rear panel or
HTTP downloads.
Abort - Stops a download that
is currently being received.
Restart - Restarts a previously
aborted download.
Note: The download does not
resume from where it was
aborted, but restarts from the
beginning.
None - No action is to be
performed.
Setup Menu
75
Menu Item
Description
Parameters
Date Format
Select the date format.
YYYY_MM_DD,
DD_MM_YYYY, or
MM_DD_YYYY
Time Format
Select the time format.
24Hr, 24Hr SuspendZero, 12Hr,
12Hr SuspendZero. The
SuspendZero options omit the
leading zero.
GMT Off
Select the local time zone offset
relative to the GMT time. The time
information in the transmitted
stream is broadcast as GMT time
and changing this setting will
allow the unit to correctly display
the local time.
+13:00, +12:00, +11:00, +10:00,
+09:30, +09:00, +08:00, +07:00,
+06:30, +06:00, +05:45, +05:30,
+05:00, +04:30, +04:00, +03:30,
+03:00, +02:00, +01:00, GMT,
-01:00, -02:00, -03:30, -04:00,
-05:00, -06:00, -07:00, -08:00,
-09:00, -10:00, -11:00, -12:00
Chapter 4 Fr ont Panel Oper ation
76
Setup Menu: TS Input
Menu Item
Description
Parameters
ASI Active
Select whether to tune to the ASI input.
Note: Setting a new input to be active
will deactivate the currently active
input.
Act or No
To view the TS (Transport Stream) Input menu from the Main menu, press the
RIGHT arrow key once and then the SELECT key to reach the Setup menu. Then
press the RIGHT arrow key once and the SELECT key to view the TS Input menu.
For instructions on how to select and store settings, see About the Front Panel (on
page 44).
The TS Input menu has the following structure:
ASI Input
