Cisco AS5350XM and Cisco AS5400XM Universal Gateways

INCLUDING LICENSE AND WARRANTY

1 Cisco 90-Day Limited Hardware Warranty Terms

2 Documents, Equipment, and Tools

3 Install Chassis

4 Install Modules

5 Connect Cables

6 Power Up the Universal Gateway

7 Perform Initial Configuration

8 Slot Numbering

9 Obtaining Documentation

10 Documentation Feedback

11 Cisco Product Security Overview

12 Obtaining Technical Assistance

13 Obtaining Additional Publications and Information

1 Cisco 90-Day Limited Hardware Warranty Terms

There are special terms applicable to your hardware warranty and various services that you can use during the warranty period. Your formal Warranty Statement, including the warranties and license agreements applicable to Cisco software, is available on Cisco.com. Follow these steps to access and download the Cisco Information Packet and your warranty and license agreements from Cisco.com.

1. Launch your browser, and go to this URL:

http://www.cisco.com/univercd/cc/td/doc/es_inpck/cetrans.htm

The Warranties and License Agreements page appears.

2. To r e ad t he Cisco Information Packet, follow these steps:

a. Click the Information Packet Number field, and make sure that the part number 78-5235-03A0 is highlighted.

b. Select the language in which you would like to read the document.

c. Click Go.

The Cisco Limited Warranty and Software License page from the Information Packet appears.

d. Read the document online, or click the PDF icon to download and print the document in Adobe Portable Document

Format (PDF).

Note You must have Adobe Acrobat Reader to view and print PDF files. You can download the reader from Adobe’s

website: http://www.adobe.com

3. To read translated and localized warranty information about your product, follow these steps:

a. Enter this part number in the Warranty Document Number field:

78-5236-01C0

b. Select the language in which you would like to read the document.

c. Click Go.

The Cisco warranty page appears.

d. Review the document online, or click the PDF icon to download and print the document in Adobe Portable Document

Format (PDF).

You can also contact the Cisco service and support website for assistance:

http://www.cisco.com/public/Support_root.shtml

Duration of Hardware Warranty

Ninety (90) days.

Replacement, Repair, or Refund Policy for Hardware

Cisco or its service center will use commercially reasonable efforts to ship a replacement part within ten (10) working days after receipt of a Return Materials Authorization (RMA) request. Actual delivery times can vary, depending on the customer location.

Cisco reserves the right to refund the purchase price as its exclusive warranty remedy.

To Receive a Return Materials Authorization (RMA) Number

Contact the company from whom you purchased the product. If you purchased the product directly from Cisco, contact your Cisco Sales and Service Representative.

Complete the information below, and keep it for reference:

Company product purchased from

Company telephone number

Product model number

Product serial number

Maintenance contract number

2 Documents, Equipment, and Tools

User Documentation

All of the documents described here are available online and on the Documentation DVD. To be sure of obtaining the latest information, you should access the online documentation.

Note The information in this document applies to the Cisco AS5350XM and Cisco AS5400XM universal gateways.

To access online user documentation:

From Cisco.com at http://www.cisco.com, choose Technical Support & Documentation.

Cisco AS5350XM and Cisco AS5400XM Universal Gateway Documentation

Regulatory Compliance and Safety Information

The Regulatory Compliance and Safety Information document provides essential safety information applicable to your universal gateway. A printed copy of this document is shipped with this device.

You can access this document at Technical Support & Documentation > Product Support > Universal Gateways and Access Servers > Cisco AS5300 or Cisco AS5400 Series Universal Gateways > Install and Upgrade Guides.

Hardware Installation

The chassis installation guide provides additional detailed description, installation, and cabling information.

Software Configuration

The software configuration guide provides additional detailed configuration information.

Cisco IOS Software Documentation

Master Index to Software Documentation

The master index provides links to topics and commands for specific Cisco IOS software releases.

You can access these documents at Technical Support & Documentation > Product Support > Cisco IOS Software > Cisco IOS Software Release you are using > Master Index.

Configuration Guides

The Cisco IOS software configuration guides provide detailed configuration procedures and examples.

You can access these documents at Technical Support & Documentation > Product Support > Cisco IOS Software > Cisco IOS Software Release you are using > Configuration Guides.

Command References

The Cisco IOS software command references provide detailed information about each command.

You can access these documents at Technical Support & Documentation > Product Support > Cisco IOS Software > Cisco IOS Software Release you are using > Command References.

New Feature Documentation

New feature documentation contains detailed information about new features introduced in specific Cisco IOS releases.

You can access these documents at Technical Support & Documentation > Product Support > Cisco IOS Software > Cisco IOS Software Release you are using > Feature Guides.

If you have an account on Cisco.com, you can get updated information about platform support for features by accessing Feature Navigator at the following URL:

http://www.cisco.com/go/fn

Release Notes

Cisco IOS release notes for all platforms provide up-to-date information about specific Cisco IOS software releases.

You can access these documents at Technical Support & Documentation > Product Support > Cisco IOS Software > Cisco IOS Software Release you are using > Release Notes.

Items Included with Cisco AS5350XM and Cisco AS5400XM Universal Gateways

• 19-inch (48.26-cm) and 24-inch (60.96-cm) rack-mount kits

• Rubber feet for desktop installation

• RJ-45-to-DB-9 female DTE adapter (labeled TERMINAL)

• RJ-45-to-DB-25 female DTE adapter (labeled TERMINAL)

• RJ-45-to-DB-25 male DCE adapter (labeled MODEM)

• RJ-45-to-RJ-45 rollover console cable

• ESD-preventive wrist strap

• Nylon cable ties

• Cable tie holder

• Grounding lug

• Cisco Information Package

Items Not Included

Individual items in this list may be required for your particular application:

• Straight-through RJ-45-to-RJ-45 cable for an Ethernet connection

• Straight-through RJ-45-to-RJ-45 cables for T1 connections

• E1 cables for E1 connections

• Ethernet hub, Gigabit Ethernet switch, or PC with a network interface card for Ethernet LAN connections

• PC running terminal emulation software for local administrative access

• Modem for remote administrative access

• One breakout cable consisting of a 36-pin connector connected to eight RJ-45 adapters for CT1/CE1 connections

• 75-ohm coaxial cable for a CT3 connection

3 Install Chassis

Note The information in this document applies to the Cisco AS5350XM and Cisco AS5400XM universal gateways.

Safety Information

For safety information you need to know before working on your Cisco universal gateway, see the Regulatory Compliance and Safety Information document that accompanied this device.

Setting Up the Chassis

You can install the chassis in a rack or set it on a desktop. Select the procedure that best meets the needs of your network:

• Rack-Mounting the Chassis, page 5

• Desktop Installation, page 7

Warning

This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

Statement 1017

Rack-Mounting the Chassis

This section describes how to rack-mount the chassis. The universal gateway arrives with 19-inch (48.26-cm) rack-mount brackets and larger brackets for use with a 23-inch (58.42-cm) or 24-inch (60.96-cm) rack.

Figure 1 Cisco AS5350XM Universal Gateway Rack-Mount Brackets

Bracket for 23-inch rackBracket for 19-inch rack

Figure 2 Cisco AS5400XM Universal Gateway Rack-Mount Brackets

36012

H6028

Bracket for 23- or 24-inch rackBracket for 19-inch rack

The following information will help you plan your equipment rack configuration:

• Enclosed racks must have adequate ventilation. Ensure that the rack is not congested, because each unit generates heat. An enclosed rack should have louvered sides and a fan to provide cooling air. Heat generated by equipment near the bottom of the rack can be drawn upward into the intake ports of the equipment above.

• When mounting a chassis in an open rack, ensure that the rack frame does not block the intake or exhaust ports. If the

chassis is installed on slides, check the position of the chassis when it is seated in the rack.

• Baffles can isolate exhaust air from intake air, which also helps to draw cooling air through the chassis. The best placement of the baffles depends on the airflow patterns in the rack, which can be found by experimenting with different configurations.

• When equipment installed in a rack (particularly in an enclosed rack) fails, try operating the equipment by itself, if possible. Power down other equipment in the rack (and in adjacent racks) to allow the unit under test a maximum of cooling air and clean power.

• Install the chassis and external devices to which it will connect in a contiguous stack.

Required Tools and Equipment

You need the following tools and equipment to rack-mount the chassis:

• Number 2 Phillips screwdriver (not included)

• Medium flat-blade screwdriver (not included)

• Screws for attaching the chassis to the rack (not included)

• Standard rack-mount brackets (included)

• Screws for attaching the brackets to the chassis (included)

Attaching Brackets

Attach the mounting brackets to the chassis as shown, using the screws provided. Attach the second bracket to the opposite side of the chassis.

Note The chassis may be installed with either the front panel or the back panel facing forward.

Figure 3 Cisco AS5350XM Universal Gateway Bracket Installation—Front Panel Forward (19-Inch Rack)

35669

Figure 4 Cisco AS5400XM Universal Gateway Bracket Installation—Front Panel Forward (19-Inch Rack)

H10643

Installation in a Rack

Install the chassis in the rack. Rack-mounting screws are not provided. Use two screws for each side (supplied with the rack).

Figure 5 Installing the Cisco AS5350XM Universal Gateway in a Rack (19-Inch Rack)

35659

Figure 6 Installing the Cisco AS5400XM Universal Gateway in a Rack (19-Inch Rack)

29034

Desktop Installation

For desktop or shelf mounting, use the rubber “feet” shipped on a black adhesive strip with the chassis. They protect the chassis and provide a nonskid surface.

The location of the chassis is extremely important for proper operation. Equipment placed too close together, inadequate ventilation, and inaccessible panels can cause malfunctions and shutdowns, and can make maintenance difficult. The following information will help you to plan the location of the chassis:

• Plan for access to both front and back panels of the chassis.

• Ensure that the room where the chassis operates has adequate ventilation. Remember that electrical equipment generates

heat. Ambient air temperature may not cool equipment to acceptable operating temperatures without adequate ventilation.

To attach the rubber feet, follow these steps:

Step 1 Locate the rubber feet that shipped with the chassis.

Step 2 Place the universal gateway upside-down on a smooth, flat surface.

Step 3 Peel the rubber feet off the black adhesive strip, and attach them adhesive-side-down at each corner of the underside of

the chassis.

Step 4 Place the universal gateway top-side-up on a flat, smooth, secure surface.

Caution Do not place anything on top of the universal gateway that weighs more than 10 lb (4.5 kg). Excessive weight on

top could damage the chassis.

Chassis Ground Connection

You must connect the chassis to a reliable earth ground by using the ground lug (provided) and size AWG 6 (13 mm2) wire.

To attach the chassis ground, follow these steps:

Step 1 Strip one end of the ground wire to expose approximately 0.75 in. (20 mm) of conductor.

Step 2 Crimp the ground wire to the ground lug, using a crimp tool of the appropriate size.

Step 3 Attach the ground lug to the chassis as shown in Figure 7 and Figure 8. Use a medium flat-blade screwdriver and the

screws supplied with the ground lug. Tighten the screws to a torque of 8 to 10 in-lb (0.9 to 1.1 N-m).

Figure 7 Cisco AS5350XM Universal Gateway Ground Lug Attachment

Ground lug attachment

Figure 8 Cisco AS5400XM Universal Gateway Ground Lug Attachment

Ground lug attachment

Step 4 Connect the other end of the ground wire to a suitable grounding point at your site.

82735

82734

4 Install Modules

Note The information in this document applies to the Cisco AS5350XM and Cisco AS5400XM universal gateways.

Note The Cisco AS5350XM and Cisco AS5400XM universal gateways come with carrier cards and feature cards already

installed. If you are not installing additional carrier cards or feature cards, proceed to the “Connect Cables” section on page 15.

For additional information about installing carrier cards and feature cards, see the Cisco AS5350XM and Cisco AS5400XM Universal Gateways Card Installation Guide.

Installing Carrier Cards

Caution The carrier cards that carry the feature cards are not hot-swappable. Removing or replacing a carrier card while

the system is still powered up may cause permanent damage to electronic circuits on the card.

Warning

Do not work on the system or connect or disconnect cables during periods of lightning activity.

Before opening the unit, disconnect the telephone-network cables to avoid contact with telephone-network voltages.

Statement 1041

Statement 1001

Installing a Carrier Card

If you need to install a carrier card, follow these steps:

Step 1 Make sure the chassis is powered down.

Warning

Step 2 Attach an ESD-preventive wrist strap.

Step 3 Slide the carrier card into the slot until it touches the backplane connector. (See Figure 9 and Figure 10.)

Before working on a chassis or working near power supplies, unplug the power cord on AC units; disconnect the power at the circuit breaker on DC units.

Statement 12

Figure 9 Install the Carrier Card in the Cisco AS5350XM Universal Gateway

36004

Figure 10 Install the Carrier Card in the Cisco AS5400XM Universal Gateway

37161

Step 4 Align the captive screws with their holes, and seat the card completely.

Step 5 Tighten the two captive screws to secure the carrier card to the chassis. (See Figure 11 and Figure 12.)

Figure 11 Tighten the Captive Screws on the Cisco AS5350XM Universal Gateway

36005

Captive screw

Figure 12 Tighten the Captive Screws on the Cisco AS5400XM Universal Gateway

Captive

screw

Captive

screw

37162

Step 6 If the carrier card has a blank feature card slot, install a blank cover over the open feature card slot to ensure proper

airflow inside the chassis.

Figure 13 Blank Feature Card Cover

36033

Step 7 For AC-powered units, reconnect the AC power cord. For DC-powered units, reinstate power at the circuit breaker. For

more information on the AC and DC power supplies, see the chassis installation guide. To access the chassis installation guide, see the “Documents, Equipment, and Tools” section on page 3.

Step 8 Reconnect all interface cables.

Installing Feature Cards

For detailed information on installing and connecting feature cards, see the Cisco AS5350XM and Cisco AS5400XM Universal Gateways Card Installation Guide.

Warning

The telecommunications lines must be disconnected 1) before unplugging the main power connector and/or 2) while the housing is open.

Do not work on the system or connect or disconnect cables during periods of lightning activity.

Statement 89

Statement 1001

Note When you replace a feature card with a new feature card of the same type in the same slot, the system software

recognizes the new trunk interfaces and brings them up automatically. If you replace the existing feature card with a new feature card of a different type, you must reconfigure the system. For configuration details, see the

Cisco AS5350XM and Cisco AS5400XM Universal Gateways Software Configuration Guide.

Note The Cisco AS5350XM and Cisco AS5400XM universal gateways does not support the mixing of T1 and E1 feature

cards in the same chassis. For more information about mixing WAN feature cards, see the

Cisco AS5350XM and

Cisco AS5400XM Universal Gateways Card Installation Guide.

To install a feature card, follow these steps:

Step 1 Attach an ESD-preventive wrist strap.

Step 2 Slide the feature card into the slot until the connector pins make contact with the carrier card backplane connector. (See

Figure 14 and Figure 15.)

Figure 14 Installing a Feature Card in a Cisco AS5350XM Universal Gateway

2 PRI

ACT

36816

Figure 15 Installing a Feature Card in a Cisco AS5400XM Universal Gateway

37165

Step 3 Align the captive screws with their holes, and seat the card completely.

Step 4 Tighten the screws to secure the feature card to the chassis. (See Figure 16 and Figure 17.)

Figure 16 Tighten the Captive Screws on the Cisco AS5350XM Universal Gateway

Chassis

ACT

Captive

screw

2 PRI

Carrier

Captive

screw

DFC

card

Figure 17 Tighten the Captive Screws on the Cisco AS5400XM Universal Gateway

Captive

screw

Captive

screw

36817

37170

Step 5 Check the card LEDs to verify that the card is working properly. The following table summarizes the LED functions

for the feature cards.

Ta b l e 1 L E D s

Feature Card LED State Description

T1 or E1 feature card

ACTIVITY (ACT) Fast flicker (green) The feature card is up and running.

Slow flicker (green) The feature card is not yet fully functional.

OK/MAINT Green The feature card has passed initial power-up diagnostics tests

and is operating normally.

Yellow • The feature card is busied out, but there are active calls.

Once all the calls are terminated the feature card will be powered off.

• The feature card is not functioning correctly.

Off All calls associated with the card have been shut down, and it

is safe to remove the card with the system powered on.

• Remote Alarm (RA)

• Local Alarm (LA)

• Loopback (LB)

On (yellow) One LED below each T1/E1 port indicates one of the

following:

• A local or remote loopback diagnostic test is running on the associated T1 port.

• An alarm has been received on the associated T1/E1 port, indicating loss of signal (LOS) or loss of multiframe alignment (LOF) at the local or remote node.

Table 1 LEDs (continued)

Feature Card LED State Description

CT3 feature card

ACTIVITY (ACT) Fast flicker The feature card is up and running.

Slow flicker The feature card is not yet fully functional.

OK/MAINT On (green) The feature card passed initial power-up diagnostics tests and

is operating normally.

Yellow • The feature card is busied out, but there are active calls.

Once all the calls are terminated the feature card will be powered off.

• The feature card is not functioning correctly.

Off All calls associated with the feature card have been shut down,

and it is safe to remove the card with the system powered on.

M13 Alarm (MA) On One of the following is present on the T3 line:

• Received alarm indication signal (RAIS)

• Loss of signal (LOS)

• Receive RED alarm (RRED)

• Far-end receive failure (RFERF)

Off The operating condition is normal.

Remote Alarm (RA) On A T1 alarm condition has been encountered by software.

Off The operating condition is normal.

Local Alarm (LA) On A T1 alarm condition has been encountered by software for a

particular port.

Off The operating condition is normal.

T3 EN/DIS Green A CT3 feature card line connection exists, enabling normal

operation.

Yellow Normal operation is disabled.

Low signal (LOS) On The T3 line interface unit (LIU) is experiencing a loss of signal.

Off Remains off when operating condition is normal.

Universal port and dial-only feature card

Network Loop (LOOP)

ACTIVITY (ACT) Flickering There is call activity on the feature card.

OK/MAINT Green The feature card passed initial power-up diagnostic tests and

On At least one T1 is unavailable.

Off The operating condition is normal.

is operating normally.

Yellow • The feature card is busied out, but there are active calls.

Once all the calls are terminated the feature card will be powered off.

• The feature card is not functioning correctly.

Off All calls associated with the feature card have been shut down,

and it is safe to remove the card with the system powered on.

Table 1 LEDs (continued)

Feature Card LED State Description

Voice f e atur e card

1. To display information about an M13 alarm, use the show controllers t3 user EXEC command.

ACTIVITY Green (blinking) There is call activity on the feature card.

Off There is no activity on the feature card.

OK/MAINT Green The feature card passed initial power-up diagnostic tests and

is operating normally.

Yellow • The feature card is busied out, but there are active calls.

Once all the calls are terminated the feature card will be powered off.

• The feature card is not functioning correctly.

Off All calls associated with the feature card have been shut down,

and it is safe to remove the card with the system powered on.

5 Connect Cables

Note The information in this document applies to the Cisco AS5350XM and Cisco AS5400XM universal gateways.

System Management and Power Connections

The connections described here provide electrical power and management access. For cable pinouts, see the chassis and card installation guides for the Cisco AS5350XM and Cisco AS5400XM universal gateways.

You can access these documents at Technical Support & Documentation > Product Support > Universal Gateways and Access Servers > Cisco AS5300 or Cisco AS5400 Series Universal Gateways > Install and Upgrade Guides.

The following table summarizes the power and management cable connections.

Table 2 Power and Management Cable Connections

Color or

Port or Connection

Console Light blue PC or ASCII terminal communication

Auxiliary Black Modem for remote access RJ-45-to-RJ-45 rollover cable and a

Power (AC) Power

Power (DC) See the “Connect DC Power” section on page 28 for instructions about the DC power

Bantam jack port Test device

Alarm Alarm device 12 or 14 AWG copper wire

BITS port Signal generator Coax cable

Type Connection Cable

RJ-45-to-RJ-45 rollover cable (included)

port (usually labeled COM)

100 to 240 VAC, 50 to 60 Hz Grounding power cord (included).

cable

connections.

and terminal adapter (included).

modem adapter (included).

WAN, LAN, and Voice Connections

The following table summarizes the WAN, LAN, and voice connections.

Table 3 WAN, LAN and Voice Connections

Port or Connection Color or Type Connection Cable

Ethernet RJ-45, yellow Ethernet hub or Gigabit Ethernet

switch

T1 or E1 WAN RJ-45 T1 or E1 network RJ-45-to-DB-15

36-pin serial 8-port interface cable

CT3 WAN BNC T3 network BNC to BNC

Straight-through Ethernet

RJ-45 to BNC interface cable for unbalanced connections

RJ-45 to Twinax interface cable for balanced connections

RJ-45-to-RJ-45

RJ-45 to bare wire

Connect a Console Terminal

Use the console terminal for local administrative access to the universal gateway. You can connect a terminal only to the console port. You can use the auxiliary port to connect a terminal or a modem for remote access to the universal gateway.

To connect a terminal (an ASCII terminal or a PC running terminal emulation software) to the console port on a Cisco AS5350XM or Cisco AS5400XM universal gateway, follow this procedure.

Step 1 Connect the terminal to the console port by using an RJ-45 rollover cable and an RJ-45-to-DB-25 or RJ-45-to-DB-9

adapter. (See Figure 18 and Figure 19.) The adapters provided are labeled TERMINAL. The adapters and the rollover cable are included in the accessory kit that ships with the universal gateway.

Figure 18 Connecting the Cisco AS5350XM Universal Gateway to a Console Terminal

Console port

(RJ-45)

35676

RJ-45-to-RJ-45

rollover cable

PC (laptop)

RJ-45

Figure 19 Connecting the Cisco AS5400XM Universal Gateway to a Console Terminal

Console port

(RJ-45)

RJ-45-to-RJ-45 rollover cable

PC (laptop)

RJ-45

30845

Step 2 Configure your terminal or PC terminal emulation software for 9600 baud, 8 data bits, no parity, and 1 stop bit. To

configure the console port, see the

Guide

Cisco AS5350XM and Cisco AS5400XM Universal Gateways Software Configuration

Connect to an Ethernet Network

Connect the universal gateway to an Ethernet network by using a straight-through RJ-45-to-RJ-45 Ethernet cable to connect the Gigabit Ethernet port to an Ethernet hub or Gigabit Ethernet switch. (See Figure 20 and Figure 21.)

Figure 20 Connecting the Cisco AS5350XM Universal Gateway to an Ethernet Hub

Figure 21 Connecting the Cisco AS5400XM Universal Gateway to an Ethernet Hub

GE1 10/100/1000BASE-T port

Ethernet hub

Straight-through Ethernet cable

122115

GE1 10/100/1000BASE-T port

Ethernet hub

Straight-through Ethernet cable

Connect to a WAN

Warning

The telecommunications lines must be disconnected 1) before unplugging the main power connector and/or 2) while the housing is open.

Statement 89

Hazardous network voltages are present in WAN ports regardless of whether power to the unit is OFF or ON. To avoid electric shock, use caution when working near WAN ports. When detaching cables, detach the end away from the unit first.

To reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord.

Statement 1026

Statement 1023

The ISDN connection is regarded as a source of voltage that should be inaccessible to user contact. Do not attempt to tamper with or open any public telephone operator (PTO)-provided equipment or connection hardware. Any hardwired connection (other than by a nonremovable, connect-one-time-only plug) must be made only by PTO staff or suitably trained engineers.

Statement 23

To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telephone-network voltage (TNV) circuits. LAN ports contain SELV circuits, and WAN ports contain TNV circuits. Some LAN and WAN ports both use RJ-45 connectors. Use caution when connecting cables.

Statement 1021

Warning

Incorrect connection of this or connected equipment to a general purpose outlet could result in a hazardous situation.

Statement 87

You can connect the Cisco AS5350XM and Cisco AS5400XM universal gateways to a WAN in the following ways:

• Connect each T1/PRI port to an RJ-45 jack with a straight-through RJ-45-to-RJ-45 cable. (See Figure 22, Figure 23, and Figure 24.)

Figure 22 Connecting a 2-Port or 4-Port Feature Card on the Cisco AS5350XM Universal Gateway to an RJ-45 Jack

Straight-through

RJ-45-to-RJ-45 cable

RJ-45 jack

35672

Figure 23 Connecting an 8-Port Feature Card on the Cisco AS5350XM Universal Gateway to an RJ-45 Jack

56057

T1/E1 8 PRI

connector

Straight-through

RJ-45-to-RJ-45 cable

RJ-45 jack

Figure 24 Connecting an 8-Port Feature Card on the Cisco AS5400XM Universal Gateway to an RJ-45 Jack

30848

T1/E1 8 PRI

connector

Straight-through

RJ-45-to-RJ-45 cable

RJ-45 jack

Note For other T1 cabling options, see the card installation guide for the Cisco AS5350XM and Cisco AS5400XM universal

gateways. You can access this document at Technical Support & Documentation > Product Support > Universal

Gateways and Access Servers > Cisco AS5300 or Cisco AS5400 Series Universal Gateways > Install and Upgrade Guides.

• Connect each E1/PRI port to an RJ-45 jack with a straight-through RJ-45-to-RJ-45 cable. (See Figure 25, Figure 26, and

Figure 27.)

Note If you choose a port with 75-ohm input impedance, use an RJ-45-to-75-ohm coaxial cable adapter and plug it into

that port. Use software commands to choose a particular port and the line termination on that port. For information on software commands, see the

Cisco AS5350XM and Cisco AS5400XM Universal Gateways Software

Configuration Guide.

Warning

The E1 interface card may only be installed in an ACA-permitted customer equipment or a Data Terminal Equipment (DTE) that is exempted from ACA’s permit requirements. The customer equipment must only be housed in a cabinet that has screw-down lids to stop user access to overvoltages on the customer equipment. The customer equipment has circuitry that may have telecommunications network voltages on them.

Figure 25 Connecting a 2-Port or 4-Port Feature Card on the Cisco AS5350XM Universal Gateway to an RJ-45 Jack

RJ-45 jack

E1 cable

Statement 90

35673

+ 47 hidden pages

Cisco Systems AS5400XM User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1 Cisco 90-Day Limited Hardware Warranty Terms

2 Documents, Equipment, and Tools

User Documentation

Cisco AS5350XM and Cisco AS5400XM Universal Gateway Documentation

Cisco IOS Software Documentation

Items Included with Cisco AS5350XM and Cisco AS5400XM Universal Gateways

Items Not Included

3 Install Chassis

Safety Information

Setting Up the Chassis

Rack-Mounting the Chassis

Desktop Installation

Chassis Ground Connection

4 Install Modules

Installing Carrier Cards

Installing a Carrier Card

Installing Feature Cards

5 Connect Cables

System Management and Power Connections

WAN, LAN, and Voice Connections

Connect a Console Terminal

Connect to an Ethernet Network

Connect to a WAN
