Release Notes for Cisco AS5200 Universal
Access Servers for Cisco IOS Release 11.2 P
March 7, 2002
These release notes for Cisco AS5200 universal access servers support Cisco IOS Release 11.2(26) P.
These release notes are updated to describe new memory requirements, hardware support, software
platform deferrals, and changes to the microcode or modem code and related documents.
For a list of all the software caveats that apply to Cisco IOS Release 11.2(26) P, see Caveats for
Cisco IOS Release 11.2 P that accompanies these release notes. The caveats document is updated for
every maintenance release and is also located on Cisco.com and the Documentation CD-ROM.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 11.2 on Cisco.com
and the Documentation CD-ROM.
These release notes describe the following topics:
• Introduction, page 2
• System Requirements, page 2
• New and Changed Information, page 9
• Important Notes, page 12
• Caveats, page 13
• Related Documentation, page 14
• Obtaining Documentation, page 18
• Obtaining Technical Assistance, page 19
Corporate Headquarters: Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
Copyright © 2002. Cisco Systems, Inc. All rights reserved.
78-5214-15 Rev. A0
Introduction
Introduction
The Cisco AS5200 universal access server is a multifaceted data communications platform that provides
all the functions of an access server, a router, modems, and terminal adapters (TAs) in a modular chassis.
Mid-sized organizations or service providers requiring centralized processing capabilities for mobile
users and telecommuters will benefit the most using the Cisco AS5200 universal access server.
With its optimization for high-speed modem access, the Cisco AS5200 universal access server is ideally
suited for all traditional dial-up applications, such as host access, electronic mail, file transfer, and
dial-in access to a local area network.
For information on new features and Cisco IOS commands supported by Cisco IOS Release 11.2(26) P,
see the “New and Changed Information” section on page 9 and the “Related Documentation” section on
page 14.
System Requirements
This section describes the system requirements for Cisco IOS Release 11.2 P:
• Memory Recommendations, page 2
• Supported Hardware, page 3
• Determining the Software Version, page 3
• Upgrading to a New Software Release, page 3
• Feature Set Tables, page 4
Memory Recommendations
Table 1 lists the memory recommendations for the Cisco AS5200.
Note Beginning with Cisco IOS Release 10.3, some software image sizes exceed 4 MB and, when
compressed, exceed 2 MB. Also, some systems now require more than 1 MB of main system memory
for data structure tables.
Table 1 Memory Recommendations for the Cisco AS5200
Image Name
IP c5200-i-l 8 MB 8 MB Flash
2
IP Plus
Desktop c5200-d-lt 8 MB 8 MB Flash
Desktop Plus c5200-ds-l 8 MB 8 MB Flash
Enterprise c5200-j-l 16 MB 8 MB Flash
Enterprise Plus c5200-js-l 16 MB 8 MB Flash
1. When a system is running from Flash memory, you cannot update the system while it is running. You
2. IP Plus for the Cisco AS5200 includes protocol translation, MMP, VPDN, V.120, RMON, Managed
must use the Flash memory load helper.
Modems, and IBM (if IBM is not already included).
Software
c5200-is-l 8 MB 8 MB Flash
Recommended
Flash Memory
Recommended
DRAM Memory
Runs
From
1
Release Notes for Cisco AS5200 Universal Access Servers for Cisco IOS Release 11.2 P
2
78-5214-15 Rev. A0
Supported Hardware
Cisco IOS Release 11.2 P supports the Cisco AS5200. Tabl e 2 lists the interfaces and supported modem
cards.
For detailed descriptions of the new hardware features, see the “New and Changed Information” section
on page 9.
Table 2 Supported Interfaces for the Cisco AS5200
Modem Cards And Interfaces Product Description
Modem Cards
Supported LAN/WAN Interfaces
System Requirements
56K
V.34 Modems
V.110 terminal adapter (TA)
V.90 modems
Ethernet (AUI)
EIA/TIA-232
X.21
V. 3 5
EIA/TIA-449
EIA-530
ISDN PRI
E1-G.703/G.704
Channelized T1
Channelized E1
Synchronous serial
Determining the Software Version
To determine the version of Cisco IOS software running on your Cisco AS5200, log in to the access
server and enter the show version EXEC command:
Router> show version
Cisco Internetwork Operating System Software
IOS (tm) 11.2 P Software (C5200-JS-N), Version 11.2(26) P, RELEASE SOFTWARE
Upgrading to a New Software Release
For general information about upgrading to a new software release, see Upgrading the Cisco IOS
Software Release in Cisco Routers and Modems located at:
http://www.cisco.com/warp/public/620/6.html
Release Notes for Cisco AS5200 Universal Access Servers for Cisco IOS Release 11.2 P
78-5214-15 Rev. A0
3
System Requirements
Feature Set Tables
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the
platform. Each feature set contains a specific set of Cisco IOS features.
Caution Cisco IOS images with strong encryption (including, but not limited to 168-bit [3DES] data
encryption feature sets) are subject to United States government export controls and have limited
distribution. Strong encryption images to be installed outside the United States are likely to require
an export license. Customer orders may be denied or subject to delay due to United States
government regulations. When applicable, purchaser/user must obtain local import and use
authorizations for all encryption strengths. Please contact your sales representative or distributor for
more information, or send an e-mail to export@cisco.com.
Table 3 lists the features and feature sets supported by the Cisco AS5200 in Cisco IOS Release 11.2 P
and uses the following conventions:
• No—The feature is not supported in the software image.
• Basic—This feature is offered in the basic feature set.
• Plus—This feature is offered in the Plus feature set, not in the basic feature set.
Note This table might not be cumulative or list all the features in each image. You can find the most current
Cisco IOS documentation on Cisco.com. These electronic documents may contain updates and
modifications made after the hardcopy documents were printed. If you have a Cisco.com login
account, you can find image and release information regarding features prior to
Cisco IOS Release 11.2(26) P by using the Feature Navigator tool at: http://www.cisco.com/go/fn.
Table 3 Feature Sets Supported for the Cisco AS5200
Feature Images by Feature Sets
Desktop
Features
LAN Support
IP Routing
(IP/IPX/AT/DEC) Enterprise
Apollo Domain No No Basic
AppleTalk 1 and 2
2
No Basic Basic
Banyan VINES No No Basic
Concurrent routing and bridging (CRB) Basic Basic Basic
DECnet IV No Basic Basic
DECnet V No No Basic
GRE Basic Basic Basic
Integrated routing and bridging (IRB)
3
Basic Basic Basic
IP Basic Basic Basic
LAN extension host Basic Basic Basic
Multiring Basic Basic Basic
Novell IPX
4
No Basic Basic
1
Release Notes for Cisco AS5200 Universal Access Servers for Cisco IOS Release 11.2 P
4
78-5214-15 Rev. A0
Table 3 Feature Sets Supported for the Cisco AS5200 (continued)
Feature Images by Feature Sets
Desktop
Features
IP Routing
(IP/IPX/AT/DEC) Enterprise
OSI No No Basic
Source-route bridging (SRB) No No Basic
Transparent and translational bridging Basic Basic Basic
XNS No No Basic
WAN Services
Combinet Packet Protocol (CPP) Basic Basic Basic
Dialer profiles Basic Basic Basic
Frame Relay Basic Basic Basic
Frame Relay SVC Support (DTE) No No Basic
Frame Relay traffic shaping Basic Basic Basic
Half bridge/half router for CPP and PPP Basic Basic Basic
HDLC Basic Basic Basic
IPXWAN 2.0 No Basic Basic
5
ISDN
Basic Basic Basic
Multichassis Multilink PPP (MMP) Plus Plus Plus
6
PPP
Basic Basic Basic
SMDS Basic Basic Basic
Switched 56 Basic Basic Basic
Virtual Private dialup Network (VPDN) Plus Plus Plus
7
X.25
WAN Optimization
Basic Basic Basic
Bandwidth-on-demand Basic Basic Basic
Custom and priority queuing Basic Basic Basic
Dial backup Basic Basic Basic
Dial-on-demand Basic Basic Basic
Header
8
, link, and payload compression
9
Basic Basic Basic
Snapshot routing Basic Basic Basic
Weighted fair queuing Basic Basic Basic
IP Routing
BGP Basic Basic Basic
10
BGP4
Basic Basic Basic
EGP Basic Basic Basic
Enhanced IGRP Basic Basic Basic
Enhanced IGRP Optimizations Basic Basic Basic
ES-IS No No Basic
System Requirements
1
78-5214-15 Rev. A0
Release Notes for Cisco AS5200 Universal Access Servers for Cisco IOS Release 11.2 P
5
System Requirements
Table 3 Feature Sets Supported for the Cisco AS5200 (continued)
Feature Images by Feature Sets
Desktop
Features
IP Routing
(IP/IPX/AT/DEC) Enterprise
IGRP Basic Basic Basic
IS-IS No No Basic
Named IP Access Control List Basic Basic Basic
Network Address Translation (NAT) Plus Plus Plus
NHRP Basic Basic Basic
On Demand Routing (ODR) Basic Basic Basic
OSPF Basic Basic Basic
OSPF Not-So-Stubby-Areas (NSSA) Basic Basic Basic
OSPF On Demand Circuit (RFC 1793) Basic Basic Basic
PIM Basic Basic Basic
Policy-based routing Basic Basic Basic
RIP Basic Basic Basic
RIP Version 2 Basic Basic Basic
Other Routing
AURP No Basic Basic
IPX RIP No Basic Basic
NLSP No Basic Basic
RTMP No Basic Basic
SMRP No Basic Basic
SRTP No No Basic
Multimedia and Quality of Service
Generic traffic shaping Basic Basic Basic
Random Early Detection (RED) Basic Basic Basic
Resource Reservation Protocol (RSVP) Basic Basic Basic
Management
AutoInstall Basic Basic Basic
Automatic modem configuration Basic Basic Basic
HTTP Server Basic Basic Basic
Modem Management Plus Plus Plus
RMON events and alarms
11
Basic Basic Basic
RMON full Plus Plus Plus
SNMP Basic Basic Basic
Telnet Basic Basic Basic
Security
Access lists Basic Basic Basic
1
Release Notes for Cisco AS5200 Universal Access Servers for Cisco IOS Release 11.2 P
6
78-5214-15 Rev. A0
Table 3 Feature Sets Supported for the Cisco AS5200 (continued)
Feature Images by Feature Sets
Desktop
Features
IP Routing
(IP/IPX/AT/DEC) Enterprise
Access security Basic Basic Basic
Extended access lists Basic Basic Basic
Kerberized login No No Basic
Kerberos V client support No No Basic
Lock and key Basic Basic Basic
MAC security for hubs Basic Basic Basic
MD5 routing authentication Basic Basic Basic
RADIUS Basic Basic Basic
TAC ACS +
IBM Support (optional)
APPN (optional)
12
2
Basic Basic Basic
No No No
BAN for SNA Frame Relay support Plus Plus Basic
Bisync Plus Plus Basic
Caching and filtering Plus Plus Basic
DLSw+
13
Plus Plus Basic
Downstream PU concentration (DSPU) Plus Plus Basic
Frame Relay SNA support (RFC 1490) Plus Plus Basic
Native Client Interface Architecture (NCIA) Server Plus Plus Basic
NetView Native Service Point Plus Plus Basic
QLLC Plus Plus Basic
Response Time Reporter (RTR) Plus Plus Basic
SDLC integration Plus Plus Basic
DLSw (RFC 1795) Plus Plus Basic
SDLC transport (STUN) Plus Plus Basic
SDLC-to-LAN conversion (SDLLC) Plus Plus Basic
SNA and NetBIOS WAN optimization
Plus Plus Basic
via local acknowledgment
SRB/RSRB
14
Plus Plus Basic
SRT Plus Plus Basic
TG/COS No No Basic
TN3270 No No Basic
System Requirements
1
78-5214-15 Rev. A0
Release Notes for Cisco AS5200 Universal Access Servers for Cisco IOS Release 11.2 P
7
