Cisco 7600 MIB Specifications

This chapter describes the Management Information Base (MIB) on the Cisco 7600 Series router. It
includes the following sections:

• Cisco 7600 MIBs, page 3-1

• CISCO 7600 MIB Categories, page 3-1

–

–

–

• MIB Version String Description, page 3-2

Cisco 7600 MIBs

Supported and Verified MIBs, page 3-1

Supported and Unverified MIBs, page 3-2

Unverified or Unsupported MIBs, page 3-2

CHAP T E R

3

Each MIB description lists relevant constraints about the MIB’s implementation on the Cisco 7600
router platform. Any objects not listed in a table are implemented as defined in the MIB. For detailed
MIB descriptions, see the standard MIB.

Note Not all MIBs included in a Cisco IOS software release are fully supported by the router. Some MIBs are

not supported at all. Other MIBs might work, but they have not been tested on the router. In addition,
some MIBs are deprecated but cannot be removed from the software. When a MIB is included in the
image, this does not necessarily mean it is supported by the Cisco 7600 platform.

To determine which MIBs are included in other releases, see the “Using Cisco IOS MIB Tools” section

on page 2-1.

CISCO 7600 MIB Categories

The MIBs in the c7600 Image on the Cisco 7600 Series router are categorized into three types:

Supported and Verified MIBs

The MIB exists in the image, the code is implemented, and Cisco has verified that all the supported
objects work properly. These MIBs are tested for Cisco 7600 router.

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-1

Cisco 7600 MIBs

Supported and Unverified MIBs

The MIB exists in the image, the code is implemented, but we have not verified if it is working properly.
In other words, the user may get something if they query the MIB. However, the information may be
correct or incorrect because the MIB has not been tested. These MIBs are not tested for Cisco 7600
router support.

Unverified or Unsupported MIBs

The MIB exists in the image but is either not tested or not supported. These MIBs are neither tested nor
supported for Cisco 7600 routers.

MIB Version String Description

The MIB version string indicates the date and time that the module was most recently modified. The
format is YYMMDDHHMMZ or YYYYMMDDHHMMZ where

• YY - last 2 digits of the year (only years between 1900-1999)

• YYYY - all 4 digits of the year (any year)

Chapter 3 Cisco 7600 MIB Specifications

• MM - month (01 through 12)

• DD - day of the month (01 through 31)

• HH - hours (00 through 23)

• MM - minutes (00 through 59)

• Z - denotes UTC/GMT (the ASCII character Z) Coordinated Universal Time (UTC, formerly

Greenwich Mean Time). This datatype stores the datetime fields YEAR, MONTH, DAY, HOUR,
MINUTE, SECOND, TIMEZONE_HOUR, and TIMEZONE_MINUTE.

Note For example, 9592192015Z and 199509122015Z represent 8:15 GMT on 19 February 1995.

Years after 1999 use the four digit format. Years 1900-1999 may use the 2 or 4 digit format.

Note In the following table you might see the term Revision not available. This term refers to the MIB module

that does not have a recorded time stamp indicating the latest modification.

MIBs in 7600 Series Routers

Table 3-1 lists the MIBs in 7600 Series Routers:

Table 3-1 MIBs in 7600 Series Routers

3-2

Supported and

MIB

ATM-MIB

12.2(18)SXF3 9406072245

•

• 12.2(33)SRA 9406072245

Cisco 7600 Series Router MIB Specifications Guide

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

• 12.2(33)SRB 9406072245

• 12.2(33)SRC 9406072245

BGP4-MIB

12.2(18)SXF3 9405050000Z

•

• 12.2(33)SRA 9405050000Z

• 12.2(33)SRB 9405050000Z

• 12.2(33)SRC 9405050000Z

BRIDGE-MIB

12.2(18)SXF3 Revision not

•

Verified

available

• 12.2(33)SRA Revision not

available

• 12.2(33)SRB Revision not

available

• 12.2(33)SRC Revision not

available

CISCO-802-TAP-MIB

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB 200403110000Z

• 12.2(33)SRC 200403110000Z

CISCO-AAA-SESSION-MIB

12.2(18)SXF3 9911160000Z

•

• 12.2(33)SRA 9911160000Z

• 12.2(33)SRB 9911160000Z

• 12.2(33)SRC 200603210000Z

CISCO-AAL5-MIB

•

12.2(18)SXF3 200309220000Z

• 12.2(33)SRA 200309220000Z

• 12.2(33)SRB 200309220000Z

• 12.2(33)SRC 200309220000Z

CISCO-ACCESS-ENV­MON-MIB

• 12.2(18)SXF3 9808050000Z

• 12.2(33)SRA 9808050000Z

• 12.2(33)SRB 9808050000Z

• 12.2(33)SRC 9808050000Z

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-3

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

CISCO-ALPS-MIB

12.2(18)SXF3 200001280000Z

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-ASPP-MIB

12.2(18)SXF3 9508210000Z

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-ATM-EXT-MIB

12.2(18)SXF3 9706200000Z

•

• 12.2(33)SRA 200301060000

• 12.2(33)SRB 200301060000

• 12.2(33)SRC 200301060000

CISCO-ATM-PVC-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 9711180000Z

•

• 12.2(33)SRA 9711180000Z

• 12.2(33)SRB 9711180000Z

• 12.2(33)SRC 9711180000Z

CISCO-ATM-PVC­TRAP-EXTN-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200303240000Z

CISCO-ATM-QOS-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200206100000Z

CISCO-BCP-MIB

12.2(18)SXF3 200408310000Z

•

• 12.2(33)SRA 200408310000Z

• 12.2(33)SRB 200408310000Z

• 12.2(33)SRC 200408310000Z

3-4

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

CISCO-BGP-POL­ICY-ACCOUNTING-MIB

• 12.2(18)SXF3 9912170000Z

• 12.2(33)SRA 200207260000Z

• 12.2(33)SRB 200207260000Z

• 12.2(33)SRC 200207260000Z

CISCO-BGP4-MIB

12.2(18)SXF3 200108130000Z

•

• 12.2(33)SRA 200302240000Z

• 12.2(33)SRB 200302240000Z

• 12.2(33)SRC 200302240000Z

CISCO-BRIDGE-EXT-MIB

12.2(18)SXF3 200408230000Z

•

• 12.2(33)SRA 200408230000Z

• 12.2(33)SRB 200408230000Z

• 12.2(33)SRC 200408230000Z

CISCO-BSC-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 9701250000Z

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-BSTUN-MIB

12.2(18)SXF3 9701220000Z

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-BULK-FILE-MIB

12.2(18)SXF3 9810291700Z

•

• 12.2(33)SRA 9810291700Z

• 12.2(33)SRB 9810291700Z

• 12.2(33)SRC 200108220000Z

CISCO-CABLE-DIAG-MIB

12.2(18)SXF3 200409130000Z

•

• 12.2(33)SRA 200409130000Z

• 12.2(33)SRB 200409130000Z

• 12.2(33)SRC 200409130000Z

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-5

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

CISCO-CALLHOME-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200704060000Z

CISCO-CAR-MIB

12.2(18)SXF3 0002180000Z

•

• 12.2(33)SRA 0002180000Z

• 12.2(33)SRB 0002180000Z

• 12.2(33)SRC 0002180000Z

CISCO-CASA-FA-MIB

12.2(18)SXF3 200209180000Z

•

• 12.2(33)SRA 200209180000Z

• 12.2(33)SRB 200209180000Z

• 12.2(33)SRC 200209180000Z

CISCO-CASA-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 200209180000Z

•

• 12.2(33)SRA 200209180000Z

• 12.2(33)SRB 200209180000Z

• 12.2(33)SRC 200209180000Z

CISCO-CAT6K-CROSS­BAR-MIB

12.2(18)SXF3 200411190000Z

•

• 12.2(33)SRA 200411190000Z

• 12.2(33)SRB 200411190000Z

• 12.2(33)SRC 200411190000Z

CISCO-CDP-MIB

12.2(18)SXF3 9812100000Z

•

• 12.2(33)SRA 200503210000Z

• 12.2(33)SRB 200503210000Z

• 12.2(33)SRC 200503210000Z

CISCO-CEF-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200601300000Z

3-6

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

CISCO-CIRCUIT-INTER­FACE-MIB

• 12.2(18)SXF3 200005090000Z

• 12.2(33)SRA 200005090000Z

• 12.2(33)SRB 200005090000Z

• 12.2(33)SRC 200005090000Z

CISCO-CLASS-BASED-QOS­MIB

12.2(18)SXF3 200012080000Z

•

• 12.2(33)SRA 200404120000Z

• 12.2(33)SRB 200404120000Z

• 12.2(33)SRC 200404120000Z

CISCO-CONFIG-COPY-MIB

12.2(18)SXF3 9701150000Z

•

• 12.2(33)SRA 200403170000Z

• 12.2(33)SRB 200403170000Z

• 12.2(33)SRC 200608220000Z

CISCO-CONFIG-MAN-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 9511280000Z

•

• 12.2(33)SRA 9511280000Z

• 12.2(33)SRB 200406180000Z

• 12.2(33)SRC 200608220000Z

CISCO-CONTEXT-MAP­PING-MIB

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB 200503170000Z

• 12.2(33)SRC 200503170000Z

CISCO-CSG-MIB

•

12.2(18)SXF3 200302200000Z

• 12.2(33)SRA 200302200000Z

• 12.2(33)SRB 200302200000Z

• 12.2(33)SRC 200302200000Z

CISCO-DATA-COLLEC­TION-MIB

•

12.2(18)SXF3 Y

• 12.2(33)SRA 200210300530Z

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-7

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

• 12.2(33)SRB 200210300530Z

• 12.2(33)SRC 200210300530Z

CISCO-DIAL-CONTROL-MIB

12.2(18)SXF3 9801161546Z

•

• 12.2(33)SRA 9801161546Z

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-DLCSW-MIB

12.2(18)SXF3 9702190000Z

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-DLSW-EXT-MIB

12.2(18)SXF3 9703110000Z

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-DLSW-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 9506300900Z

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-DSPU-MIB

•

12.2(18)SXF3 9508150000Z

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-EIGRP-MIB

•

12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-EMBED­DED-EVENT-MGR-MIB

•

12.2(18)SXF3 200304160000Z

• 12.2(33)SRA 200304160000Z

3-8

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

• 12.2(33)SRB 200304160000Z

• 12.2(33)SRC 200304160000Z

CISCO-ENHANCED-IMAGE-M
IB

• 12.2(18)SXF3 200501060000Z

• 12.2(33)SRA 200501060000Z

• 12.2(33)SRB 200501060000Z

• 12.2(33)SRC 200501060000Z

CISCO-ENHANCED-MEM­ORY-POOL-MIB

• 12.2(18)SXF3 200106050000Z

• 12.2(33)SRA 200302240000Z

• 12.2(33)SRB 200302240000Z

• 12.2(33)SRC 200302240000Z

CISCO-ENTITY-ALARM-MIB

12.2(18)SXF3 9907062150Z

•

• 12.2(33)SRA 9907062150Z

• 12.2(33)SRB 9907062150Z

• 12.2(33)SRC 9907062150Z

CISCO-ENTITY-ASSET-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 200207231600Z

•

• 12.2(33)SRA 200207231600Z

• 12.2(33)SRB 200207231600Z

• 12.2(33)SRC 200207231600Z

CISCO-ENTITY-EXT-MIB

12.2(18)SXF3 200104050000Z

•

• 12.2(33)SRA 200104050000Z

• 12.2(33)SRB 200104050000Z

• 12.2(33)SRC 200104050000Z

CISCO-ENTITY-FRU-CON­TROL-MIB

•

12.2(18)SXF3 200310230000Z

• 12.2(33)SRA 200310230000Z

• 12.2(33)SRB 200310230000Z

• 12.2(33)SRC 200310230000Z

CISCO-ENTITY-SENSOR-MIB

12.2(18)SXF3 200301070000Z

•

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-9

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

• 12.2(33)SRA 200509080000Z

• 12.2(33)SRB 200601010000Z

• 12.2(33)SRC 200601010000Z

CISCO-ENTITY-VENDOR­TYPE-OID-MIB

• 12.2(18)SXF3 200204051400Z

• 12.2(33)SRA 200204051400Z

• 12.2(33)SRB 200204051400Z

• 12.2(33)SRC 200505050930Z

CISCO-ENVMON-MIB

12.2(18)SXF3 200207170000Z

•

• 12.2(33)SRA 200207170000Z

• 12.2(33)SRB 200207170000Z

• 12.2(33)SRC 200207170000Z

CISCO-ERM-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB 200602110000Z

• 12.2(33)SRC 200602110000Z

CISCO-ETHER-CFM-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

3-10

12.2(18)SXF3 Y

•

• 12.2(33)SRA 200412280000Z

• 12.2(33)SRB 200412280000Z

• 12.2(33)SRC 200412280000Z

CISCO-FLASH-MIB

12.2(18)SXF3 200301311234Z

•

• 12.2(33)SRA 200301311234Z

• 12.2(33)SRB 200403180000Z

• 12.2(33)SRC 200403180000Z

CISCO-FLEX-LINKS-MIB

12.2(18)SXF3 200504250000Z

•

• 12.2(33)SRA 200504250000Z

• 12.2(33)SRB 200504250000Z

• 12.2(33)SRC 200504250000Z

CISCO-FRAME-RELAY-MIB

12.2(18)SXF3 200005220000Z

•

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

• 12.2(33)SRA 200005220000Z

• 12.2(33)SRB 200005220000Z

• 12.2(33)SRC 200010130000Z

CISCO-FRAS-HOST-MIB

12.2(18)SXF3 9703100000Z

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-FTP-CLIENT-MIB

12.2(18)SXF3 9710091700Z

•

• 12.2(33)SRA 9710091700Z

• 12.2(33)SRB 9710091700Z

• 12.2(33)SRC 9710091700Z

CISCO-HSRP-EXT-MIB

12.2(18)SXF3 9808030000Z

•

• 12.2(33)SRA 9808030000Z

• 12.2(33)SRB 9808030000Z

• 12.2(33)SRC 9808030000Z

CISCO-HSRP-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 9808030000Z

•

• 12.2(33)SRA 9808030000Z

• 12.2(33)SRB 9808030000Z

• 12.2(33)SRC 9808030000Z

CISCO-IETF-ATM2-PVC­TRAP-MIB

• 12.2(18)SXF3 200303240000Z

• 12.2(33)SRA 200303240000Z

• 12.2(33)SRB 200303240000Z

• 12.2(33)SRC 9802030000Z

CISCO-IETF-ATM2-PVC­TRAP-MIB-EXTN

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200007110000Z

CISCO-IETF-DHCP-SERVER-E
XT-MIB

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-11

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200703151200Z

CISCO-IETF-DHCP-SERVER-M
IB

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200703270000Z

CISCO-IETF-FRR-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA 200211051200Z

• 12.2(33)SRB 200211051200Z

• 12.2(33)SRC 200211051200Z

CISCO-IETF-IP-FOR­WARD-MIB

• 12.2(18)SXF3 200201240000Z

• 12.2(33)SRA 200201240000Z

• 12.2(33)SRB 200201240000Z

• 12.2(33)SRC Y

CISCO-IETF-IP-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

3-12

12.2(18)SXF3 200203040000Z

•

• 12.2(33)SRA 200203040000Z

• 12.2(33)SRB 200203040000Z

• 12.2(33)SRC Y

CISCO-IETF-ISIS-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB 200508161200Z

• 12.2(33)SRC Y

CISCO-IETF-PPVPN-MPLS-VP
N-MIB

• 12.2(18)SXF3 Y

• 12.2(33)SRA 200304171200Z

• 12.2(33)SRB 200304171200Z

• 12.2(33)SRC 200304171200Z

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

CISCO-IETF-PW-ATM-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB 200504191200Z

• 12.2(33)SRC 200504191200Z

CISCO-IETF-PW-ENET-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA 200209221200Z

• 12.2(33)SRB 200209221200Z

• 12.2(33)SRC 200209221200Z

CISCO-IETF-PW-FR-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB 200312160000Z

• 12.2(33)SRC 200312160000Z

CISCO-IETF-PW-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 Y

•

• 12.2(33)SRA 200403171200Z

• 12.2(33)SRB 200403171200Z

• 12.2(33)SRC 200403171200Z

CISCO-IETF-PW-MPLS-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA 200302261200Z

• 12.2(33)SRB 200302261200Z

• 12.2(33)SRC 200302261200Z

CISCO-IETF-PW-TC-MIB

•

12.2(18)SXF3 Y

• 12.2(33)SRA 200302261200Z

• 12.2(33)SRB 200302261200Z

• 12.2(33)SRC 200302261200Z

CISCO-IETF-PW-TDM-MIB

•

12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB 200607210000Z

• 12.2(33)SRC 200607210000Z

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-13

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

CISCO-IF-EXTENSION-MIB

12.2(18)SXF3 200308120000Z

•

• 12.2(33)SRA 200308120000Z

• 12.2(33)SRB 200311140000Z

• 12.2(33)SRC 200311140000Z

CISCO-IMAGE-MIB

12.2(18)SXF3 9508150000Z

•

• 12.2(33)SRA 9508150000Z

• 12.2(33)SRB 9508150000Z

• 12.2(33)SRC 9508150000Z

CISCO-IMAGE-TC-MIB

12.2(18)SXF3 200501120000Z

•

• 12.2(33)SRA 200501120000Z

• 12.2(33)SRB 200501120000Z

• 12.2(33)SRC 200501120000Z

CISCO-IP-STAT-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 9707180000Z

•

• 12.2(33)SRA 200112202300Z

• 12.2(33)SRB 200112202300Z

• 12.2(33)SRC 200112202300Z

CISCO-IP-STAT-MIB

12.2(18)SXF3 200012220000Z

•

• 12.2(33)SRA 200503070000Z

• 12.2(33)SRB 200503070000Z

• 12.2(33)SRC 200503070000Z

CISCO-IP-TAP-MIB

•

12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB 200403110000Z

• 12.2(33)SRC 200403110000Z

CISCO-IP-URPF-MIB

•

12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200411120000Z

3-14

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

CISCO-IPSEC-FLOW-MONI­TOR-MIB

• 12.2(18)SXF3 200010131800Z

• 12.2(33)SRA 200010131800Z

• 12.2(33)SRB 200010131800Z

• 12.2(33)SRC 200010131800Z

CISCO-IPSEC-MIB

12.2(18)SXF3 200008071139Z

•

• 12.2(33)SRA 200008071139Z

• 12.2(33)SRB 200008071139Z

• 12.2(33)SRC 200008071139Z

CISCO-IPSLA-ETHERNET-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200602080000Z

CISCO-L2-CONTROL-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 200306011700Z

•

• 12.2(33)SRA 200306011700Z

• 12.2(33)SRB 200306011700Z

• 12.2(33)SRC 200306011700Z

CISCO-L2-TUNNEL-CON­FIG-MIB

12.2(18)SXF3 200205311000Z

•

• 12.2(33)SRA 200205311000Z

• 12.2(33)SRB 200205311000Z

• 12.2(33)SRC 200205311000Z

CISCO-L2L3-INTER­FACE-CONFIG-MIB

•

12.2(18)SXF3 200005101900Z

• 12.2(33)SRA 200005101900Z

• 12.2(33)SRB 200005101900Z

• 12.2(33)SRC 200005101900Z

CISCO-LAG-MIB

12.2(18)SXF3 200212130000Z

•

• 12.2(33)SRA 200212130000Z

• 12.2(33)SRB 200212130000Z

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-15

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

• 12.2(33)SRC 200212130000Z

CISCO-MAC-NOTIFICA­TION-MIB

• 12.2(18)SXF3 200303210000Z

• 12.2(33)SRA 200303210000Z

• 12.2(33)SRB 200303210000Z

• 12.2(33)SRC 200706110000Z

CISCO-MEMORY-POOL-MIB

12.2(18)SXF3 9602120000Z

•

• 12.2(33)SRA 9602120000Z

• 12.2(33)SRB 9602120000Z

• 12.2(33)SRC 9602120000Z

CISCO-MVPN-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA 200402231200Z

• 12.2(33)SRB 200402231200Z

• 12.2(33)SRC 200402231200Z

CISCO-NAC-NAD-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB 200602150000Z

• 12.2(33)SRC 200602150000Z

CISCO-NDE-MIB

12.2(18)SXF3 200108080000Z

•

• 12.2(33)SRA 200108080000Z

• 12.2(33)SRB 200108080000Z

• 12.2(33)SRC 200108080000Z

CISCO-NETFLOW-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB 200503270000Z

• 12.2(33)SRC Y

CISCO-NTP-MIB

12.2(18)SXF3 200202200000Z

•

• 12.2(33)SRA 200307070000Z

• 12.2(33)SRB 200307070000Z

3-16

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

• 12.2(33)SRC 200307070000Z

CISCO-OSPF-MIB

12.2(18)SXF3 200301280000Z

•

• 12.2(33)SRA 200301280000Z

• 12.2(33)SRB 200301280000Z

• 12.2(33)SRC 200301280000Z

CISCO-OSPF-TRAP-MIB

12.2(18)SXF3 200302270000Z

•

• 12.2(33)SRA 200302270000Z

• 12.2(33)SRB 200302270000Z

• 12.2(33)SRC 200302270000Z

CISCO-PAE-MIB

12.2(18)SXF3 200105241016Z

•

• 12.2(33)SRA 200302260000Z

• 12.2(33)SRB 200604120000Z

• 12.2(33)SRC 200604120000Z

CISCO-PAGP-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 9903030000Z

•

• 12.2(33)SRA 9903030000Z

• 12.2(33)SRB 9903030000Z

• 12.2(33)SRC 9903030000Z

CISCO-PIM-MIB

•

12.2(18)SXF3 200011020000Z

• 12.2(33)SRA 200011020000Z

• 12.2(33)SRB 200011020000Z

• 12.2(33)SRC 200011020000Z

CISCO-PING-MIB

•

12.2(18)SXF3 200108280000Z

• 12.2(33)SRA 200108280000Z

• 12.2(33)SRB 200108280000Z

• 12.2(33)SRC 200108280000Z

CISCO-POLICY-GROUP-MIB

•

12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB 200601131600Z

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-17

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

• 12.2(33)SRC 200601131600Z

CISCO-PORT-SECURITY-MIB

12.2(18)SXF3 200504190000Z

•

• 12.2(33)SRA 200504190000Z

• 12.2(33)SRB 200504190000Z

• 12.2(33)SRC 200504190000Z

CISCO-PPPOE-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200102200000Z

CISCO-PRIVATE-VLAN-MIB

12.2(18)SXF3 200207240000Z

•

• 12.2(33)SRA 200207240000Z

• 12.2(33)SRB 200207240000Z

• 12.2(33)SRC 200207240000Z

CISCO-PROCESS-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 200105180000Z

•

• 12.2(33)SRA 200301220000Z

• 12.2(33)SRB 200301220000Z

• 12.2(33)SRC 200301220000Z

CISCO-PRODUCTS-MIB

•

12.2(18)SXF3 200204051400Z

• 12.2(33)SRA 200204051400Z

• 12.2(33)SRB 200204051400Z

• 12.2(33)SRC 200505051930Z

CISCO-QINQ-VLAN-MIB

•

12.2(18)SXF3 200411290000Z

• 12.2(33)SRA 200411290000Z

• 12.2(33)SRB 200411290000Z

• 12.2(33)SRC 200411290000Z

CISCO-QLLC01-MIB

•

12.2(18)SXF3 9411090000Z

• 12.2(33)SRA Y

• 12.2(33)SRB Y

3-18

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

• 12.2(33)SRC Y

CISCO-QUEUE-MIB

12.2(18)SXF3 9505310000Z

•

• 12.2(33)SRA 9505310000Z

• 12.2(33)SRB 9505310000Z

• 12.2(33)SRC 9505310000Z

CISCO-RESILIENT-ETHER­NET-PROTOCOL-MIB

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200705220000Z

CISCO-RF-MIB

12.2(18)SXF3 200107200000Z

•

• 12.2(33)SRA 200404030000Z

• 12.2(33)SRB 200404030000Z

• 12.2(33)SRC 200404030000Z

CISCO-RMON-CONFIG-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 200501240000Z

•

• 12.2(33)SRA 200501240000Z

• 12.2(33)SRB 200602210000Z

• 12.2(33)SRC 200602210000Z

CISCO-RSRB-MIB

12.2(18)SXF3 9508210000Z

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-RTTMON-MIB

12.2(18)SXF3 0104230000Z

•

• 12.2(33)SRA 200401200000Z

• 12.2(33)SRB 200603020000Z

• 12.2(33)SRC 200603020000Z

CISCO-RTTMON-IP-EXT-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-19

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

• 12.2(33)SRC 200608020000Z

CISCO-SDLLC-MIB

12.2(18)SXF3 9508210000Z

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-SLB-EXT-MIB

12.2(18)SXF3 200302111000Z

•

• 12.2(33)SRA 200302111000Z

• 12.2(33)SRB 200302111000Z

• 12.2(33)SRC 200302111000Z

CISCO-SLB-MIB

12.2(18)SXF3 200203180000Z

•

• 12.2(33)SRA 200203180000Z

• 12.2(33)SRB 200203180000Z

• 12.2(33)SRC 200203180000Z

CISCO-SMI-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 200011012246Z

•

• 12.2(33)SRA 200011012246Z

• 12.2(33)SRB 200011012246Z

• 12.2(33)SRC 200011012246Z

CISCO-SNADLC-CONV01-MIB

•

12.2(18)SXF3 9504120000Z

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-SNAPSHOT-MIB

•

12.2(18)SXF3 9508150000Z

• 12.2(33)SRA 9508150000Z

• 12.2(33)SRB 9508150000Z

• 12.2(33)SRC 9508150000Z

CISCO-SNMP-TAR­GET-EXT-MIB

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB 200404010000Z

3-20

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

• 12.2(33)SRC 200404010000Z

CISCO-SONET-MIB

12.2(18)SXF3 200205220000Z

•

• 12.2(33)SRA 200205220000Z

• 12.2(33)SRB 200205220000Z

• 12.2(33)SRC 200205220000Z

CISCO-SRP-MIB

12.2(18)SXF3 200103280000Z

•

• 12.2(33)SRA 200103280000Z

• 12.2(33)SRB 200103280000Z

• 12.2(33)SRC Y

CISCO-STACK-MIB

12.2(18)SXF3 200305290000Z

•

• 12.2(33)SRA 200305290000Z

• 12.2(33)SRB 200305290000Z

• 12.2(33)SRC 200305290000Z

CISCO-STP-EXTEN­SIONS-MIB

• 12.2(18)SXF3 200503020000Z

• 12.2(33)SRA 200503020000Z

• 12.2(33)SRB 200503020000Z

• 12.2(33)SRC 200503020000Z

CISCO-STUN-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

OL-4077-07

12.2(18)SXF3 9508210000Z

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-SVI-AUTOSTATE-MIB

12.2(18)SXF3 200311130000Z

•

• 12.2(33)SRA 200311130000Z

• 12.2(33)SRB 200311130000Z

• 12.2(33)SRC 200311130000Z

CISCO-SWITCH-ENGINE-MIB

12.2(18)SXF3 200311070000Z

•

• 12.2(33)SRA 200311070000Z

• 12.2(33)SRB 200311070000Z

Cisco 7600 Series Router MIB Specifications Guide

3-21

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

• 12.2(33)SRC 200311070000Z

CISCO-SWITCH-QOS-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200609180000Z

CISCO-SYSLOG-MIB

12.2(18)SXF3 9508070000Z

•

• 12.2(33)SRA 9508070000Z

• 12.2(33)SRB 9508070000Z

• 12.2(33)SRC 9508070000Z

CISCO-TAP2-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB 200611270000Z

• 12.2(33)SRC 200611270000Z

CISCO-TC

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 200404140000Z

•

• 12.2(33)SRA 200404140000Z

• 12.2(33)SRB 200404140000Z

• 12.2(33)SRC 200404140000Z

CISCO-TCP-MIB

•

12.2(18)SXF3 200111120000Z

• 12.2(33)SRA 200111120000Z

• 12.2(33)SRB 200111120000Z

• 12.2(33)SRC 200111120000Z

CISCO-UDLDP-MIB

•

12.2(18)SXF3 200302210000Z

• 12.2(33)SRA 200302210000Z

• 12.2(33)SRB 200302210000Z

• 12.2(33)SRC 200302210000Z

CISCO-VINES-MIB

•

12.2(18)SXF3 9506070000Z

• 12.2(33)SRA Y

• 12.2(33)SRB Y

3-22

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

• 12.2(33)SRC Y

CISCO-VLAN-IFTABLE-RELA­TIONSHIP-MIB

• 12.2(18)SXF3 9904010530Z

• 12.2(33)SRA 9904010530Z

• 12.2(33)SRB 9904010530Z

• 12.2(33)SRC 9904010530Z

CISCO-VLAN-MEMBER­SHIP-MIB

12.2(18)SXF3 200404070000Z

•

• 12.2(33)SRA 200404070000Z

• 12.2(33)SRB 200404070000Z

• 12.2(33)SRC 200404070000Z

CISCO-VLAN-TRANSLA­TION-MIB

•

12.2(18)SXF3 200406010000Z

• 12.2(33)SRA 200406010000Z

• 12.2(33)SRB 200406010000Z

• 12.2(33)SRC 200406010000Z

CISCO-VOICE-ANA­LOG-IF-MIB

• 12.2(18)SXF3 200201210000Z

• 12.2(33)SRA 200201210000Z

• 12.2(33)SRB 200201210000Z

• 12.2(33)SRC Y

CISCO-VOICE-COM­MON-DIAL-CONTROL-MIB

• 12.2(18)SXF3 200109050000Z

• 12.2(33)SRA 200109050000Z

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-VOICE-DIAL-CON­TROL-MIB

•

12.2(18)SXF3 200004190000Z

• 12.2(33)SRA 200004190000Z

• 12.2(33)SRB Not Included

• 12.2(33)SRC Not Included

CISCO-VOICE-IF-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-23

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

• 12.2(18)SXF3 9909140000Z

• 12.2(33)SRA 9909140000Z

• 12.2(33)SRB 9909140000Z

• 12.2(33)SRC Y

CISCO-VPDN-MGMT-EXT-MI
B

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200706040000Z

CISCO-VPDN-MGMT-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200601200000Z

CISCO-VTP-MIB

12.2(18)SXF3 200311210000Z

•

• 12.2(33)SRA 200311210000Z

• 12.2(33)SRB 200311210000Z

• 12.2(33)SRC 200311210000Z

DIAL-CONTROL-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

3-24

12.2(18)SXF3 9609231544Z

•

• 12.2(33)SRA 9609231544Z

• 12.2(33)SRB 9609231544Z

• 12.2(33)SRC Y

DIFFSERV-DSCP-TC

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB 200205090000Z

• 12.2(33)SRC 200205090000Z

DIFFSERV-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB 200202070000Z

• 12.2(33)SRC 200202070000Z

DLSW-MIB

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

• 12.2(18)SXF3 9512050000Z

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

DS1-MIB (RFC 1406, 2495,

2495)

• 12.2(18)SXF3 Revision not

Verified

Supported and
Unverified

Unsupported or
Unverified

available

• 12.2(33)SRA 9808011830Z

• 12.2(33)SRB 9808011830Z

• 12.2(33)SRC 9808011830Z

DS3-MIB (RFC 1407)

12.2(18)SXF3 Revision not

•

available

• 12.2(33)SRA 9808012130

• 12.2(33)SRB 9808012130

• 12.2(33)SRC 9808012130

ENTITY-MIB (RFC 2737)

Not in

12.2(18)SXF3 9912070000Z

•

• 12.2(33)SRA 9912070000Z

• 12.2(33)SRB 9912070000Z

• 12.2(33)SRC 9912070000Z

ENTITY-SENSOR-MIB

12.2(18)SXF3 200212160000Z

•

• 12.2(33)SRA 200212160000Z

• 12.2(33)SRB 200212160000Z

• 12.2(33)SRC 200212160000Z

ETHERLIKE-MIB (RFC 2665,

3635)

12.2(18)SXF3 9908240400Z

•

• 12.2(33)SRA 9908240400Z

• 12.2(33)SRB 200309190000Z

• 12.2(33)SRC 200309190000Z

EVENT-MIB

12.2(18)SXF3 9902221700Z

•

• 12.2(33)SRA 200010160000Z

• 12.2(33)SRB 200010160000Z

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-25

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

• 12.2(33)SRC 200010160000Z

EXPRESSION-MIB

12.2(18)SXF3 9802251700Z

•

• 12.2(33)SRA 9802251700Z

• 12.2(33)SRB 9802251700Z

• 12.2(33)SRC 9802251700Z

FR-MFR-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200011300000Z

HC-RMON-MIB

12.2(18)SXF3 9702120000Z

•

• 12.2(33)SRA 9702120000Z

• 12.2(33)SRB 9702120000Z

• 12.2(33)SRC 9702120000Z

IEEE8021-CFM-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB 200608220100Z

• 12.2(33)SRC 200608220100Z

IEEE8021-PAE-MIB

•

12.2(18)SXF3 200101160000Z

• 12.2(33)SRA 200101160000Z

• 12.2(33)SRB 200101160000Z

• 12.2(33)SRC 200101160000Z

IEEE8023-LAG-MIB

•

12.2(18)SXF3 200006270000Z

• 12.2(33)SRA 200006270000Z

• 12.2(33)SRB 200006270000Z

• 12.2(33)SRC 200006270000Z

IF-MIB (RFC 2863)

•

12.2(18)SXF3 9611031355Z

• 12.2(33)SRA 9611031355Z

• 12.2(33)SRB 9611031355Z

3-26

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

• 12.2(33)SRC 9611031355Z

IGMP-MIB

12.2(18)SXF3 9712180000Z

•

• 12.2(33)SRA 9712180000Z

• 12.2(33)SRB 9712180000Z

• 12.2(33)SRC 9712180000Z

IMA-MIB

12.2(18)SXF3 9804011315Z

•

• 12.2(33)SRA 9804011315Z

• 12.2(33)SRB 9804011315Z

• 12.2(33)SRC 9804011315Z

INT-SERV-GUARANTEED-MIB

12.2(18)SXF3 9511030500Z

•

• 12.2(33)SRA 9511030500Z

• 12.2(33)SRB 9511030500Z

• 12.2(33)SRC 9511030500Z

INT-SERV-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 9710030642Z

•

• 12.2(33)SRA 9710030642Z

• 12.2(33)SRB 9710030642Z

• 12.2(33)SRC 9710030642Z

INTEGRATED-SERVICES-MIB

•

12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB 9511030500Z

• 12.2(33)SRC 9511030500Z

IP-FORWARD-MIB

•

12.2(18)SXF3 Y

• 12.2(33)SRA 9609190000Z

• 12.2(33)SRB 9609190000Z

• 12.2(33)SRC 200602010000Z

IP-MIB

•

12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB 200404260000Z

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-27

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

• 12.2(33)SRC 200602020000Z

IPMROUTE-MIB

12.2(18)SXF3 9902080000Z

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

IPMROUTE-STD-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA 200009220000Z

• 12.2(33)SRB 200009220000Z

• 12.2(33)SRC 200009220000Z

LLDP-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB 200505060000Z

• 12.2(33)SRC 200505060000Z

MPLS-LDP-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 200108161200Z

•

• 12.2(33)SRA 200108161200Z

• 12.2(33)SRB Y

• 12.2(33)SRC Y

MPLS-LDP-ATM-STD-MIB
(RFC 3815)

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB 200406030000Z

• 12.2(33)SRC 200406030000Z

MPLS-LDP-GENERIC-STD-MI
B (RFC 3815)

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB 200406030000Z

• 12.2(33)SRC 200406030000Z

MPLS-LDP-STD-MIB (RFC

3815)

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

3-28

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

• 12.2(33)SRB 200406030000Z

• 12.2(33)SRC 200406030000Z

MPLS-LSR-MIB

12.2(18)SXF3 200004261200Z

•

• 12.2(33)SRA 200004261200Z

• 12.2(33)SRB Y

• 12.2(33)SRC Y

MPLS-LSR-STD-MIB (RFC

3031)

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB 200406030000Z

• 12.2(33)SRC 200406030000Z

MPLS-L3VPN-STD-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200601230000Z

MPLS-TC-MIB

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

12.2(18)SXF3 Y

•

• 12.2(33)SRA 200101041200Z

• 12.2(33)SRB 200101041200Z

• 12.2(33)SRC 200101041200Z

MPLS-TE-MIB

12.2(18)SXF3 200011211200Z

•

• 12.2(33)SRA 200011211200Z

• 12.2(33)SRB 200011211200Z

• 12.2(33)SRC 200011211200Z

MPLS-VPN-MIB

12.2(18)SXF3 200110151200Z

•

• 12.2(33)SRA 200110151200Z

• 12.2(33)SRB 200110151200Z

• 12.2(33)SRC 200110151200Z

MSDP-MIB

12.2(18)SXF3 9912160000Z

•

• 12.2(33)SRA 9912160000Z

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-29

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

• 12.2(33)SRB 9912160000Z

• 12.2(33)SRC 9912160000Z

NOTIFICATION-LOG-MIB

12.2(18)SXF3 200011270000Z

•

• 12.2(33)SRA 200011270000Z

• 12.2(33)SRB 200011270000Z

• 12.2(33)SRC 200011270000Z

NOVELL-IPX-MIB

12.2(18)SXF3 Revision not

•

Verified

Supported and
Unverified

Unsupported or
Unverified

available

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

NOVELL-NLSP-MIB

12.2(18)SXF3 Revision not

•

available

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

NOVELL-RIPSAP-MIB

Not in

12.2(18)SXF3 Revision not

•

available

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

OLD-CISCO-APPLETALK-MIB

•

12.2(18)SXF3 Revision not
available

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

OLD-CISCO-CHASSIS-MIB

•

12.2(18)SXF3 Revision not

available

• 12.2(33)SRA Revision not

available

3-30

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

• 12.2(33)SRB Revision not

Verified

Supported and
Unverified

Unsupported or
Unverified

available

• 12.2(33)SRC Revision not

available

OLD-CISCO-CPU-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB Revision not

available

• 12.2(33)SRC Revision not

available

OLD-CISCO-DECNET-MIB

12.2(18)SXF3 Revision not

•

available

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

OLD-CISCO-INTER­FACES-MIB

• 12.2(18)SXF3 Revision not

available

• 12.2(33)SRA Revision not

available

• 12.2(33)SRB Revision not

available

• 12.2(33)SRC Revision not

available

OLD-CISCO-IP-MIB

Not in

OL-4077-07

12.2(18)SXF3 Revision not

•

available

• 12.2(33)SRA Revision not

available

• 12.2(33)SRB Revision not

available

• 12.2(33)SRC Revision not

available

OLD-CISCO-MEMORY-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

Cisco 7600 Series Router MIB Specifications Guide

3-31

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

• 12.2(33)SRB Revision not

Verified

Supported and
Unverified

Unsupported or
Unverified

available

• 12.2(33)SRC Revision not

available

OLD-CISCO-NOVELL-MIB

12.2(18)SXF3 Revision not

•

available

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

OLD-CISCO-SYS-MIB

12.2(18)SXF3 Revision not

•

available

• 12.2(33)SRA Revision not

available

• 12.2(33)SRB Y

• 12.2(33)SRC Y

OLD-CISCO-SYSTEM-MIB

Not in

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB Revision not

available

• 12.2(33)SRC Revision not

available

OLD-CISCO-TCP-MIB

•

12.2(18)SXF3 Revision not
available

• 12.2(33)SRA Revision not

available

• 12.2(33)SRB Revision not

available

• 12.2(33)SRC Revision not

available

OLD-CISCO-TS-MIB

•

12.2(18)SXF3 Revision not
available

• 12.2(33)SRA Revision not

available

3-32

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

• 12.2(33)SRB Revision not

Verified

Supported and
Unverified

Unsupported or
Unverified

available

• 12.2(33)SRC Revision not

available

OLD-CISCO-VINES-MIB

12.2(18)SXF3 Revision not

•

available

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

OLD-CISCO-XNS-MIB

12.2(18)SXF3 Revision not

•

available

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

OSPF-MIB

Not in

12.2(18)SXF3 9501201225Z

•

• 12.2(33)SRA 9501201225Z

• 12.2(33)SRB 9501201225Z

• 12.2(33)SRC 9501201225Z

OSPF-TRAP-MIB

12.2(18)SXF3 9501201225Z

•

• 12.2(33)SRA 9501201225Z

• 12.2(33)SRB 9501201225Z

• 12.2(33)SRC 9501201225Z

PIM-MIB (RFC 2934)

•

12.2(18)SXF3 200009280000Z

• 12.2(33)SRA 200009280000Z

• 12.2(33)SRB 200009280000Z

• 12.2(33)SRC 200009280000Z

RFC1213-MIB

•

12.2(18)SXF3 Revision not
available

• 12.2(33)SRA Revision not

available

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-33

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

• 12.2(33)SRB Revision not

Verified

Supported and
Unverified

Unsupported or
Unverified

available

• 12.2(33)SRC Revision not

available

RFC1243-MIB (Appletalk)

12.2(18)SXF3 Revision not

•

available

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

RFC1315-MIB (Frame Relay)

12.2(18)SXF3 Revision not

•

available

• 12.2(33)SRA Revision not

available

• 12.2(33)SRB Revision not

available

• 12.2(33)SRC Revision not

available

RFC1381-MIB (X25 LAPB)

Not in

12.2(18)SXF3 Revision not

•

available

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

RFC1382-MIB (X25 Packet
Layer)

• 12.2(18)SXF3 Revision not

available

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

RFC2006-MIB (MIP)

12.2(18)SXF3 9606040000Z

•

• 12.2(33)SRA 9606040000Z

• 12.2(33)SRB 9606040000Z

• 12.2(33)SRC 9606040000Z

RMON-MIB (RFC 1757)

3-34

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

• 12.2(18)SXF3 Revision not

Verified

Supported and
Unverified

Unsupported or
Unverified

available

• 12.2(33)SRA Revision not

available

• 12.2(33)SRB Revision not

available

• 12.2(33)SRC Revision not

available

RMON2-MIB (RFC 2021)

12.2(18)SXF3 9605270000Z

•

• 12.2(33)SRA 9605270000Z

• 12.2(33)SRB 9605270000Z

• 12.2(33)SRC 9605270000Z

RS-232-MIB

12.2(18)SXF3 9405261700Z

•

• 12.2(33)SRA 9405261700Z

• 12.2(33)SRB 9405261700Z

• 12.2(33)SRC 9405261700Z

RSVP-MIB

Not in

12.2(18)SXF3 9808251820Z

•

• 12.2(33)SRA 9808251820Z

• 12.2(33)SRB 9808251820Z

• 12.2(33)SRC 9808251820Z

SMON-MIB

•

12.2(18)SXF3 9812160000Z

• 12.2(33)SRA 9812160000Z

• 12.2(33)SRB 9812160000Z

• 12.2(33)SRC 9812160000Z

SNA-SDLC-MIB

•

12.2(18)SXF3 9411150000Z

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

SNMP-COMMUNITY-MIB
(RFC 2576)

•

12.2(18)SXF3 Revision not
available

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-35

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

• 12.2(33)SRA Revision not

Verified

available

• 12.2(33)SRB Revision not

available

• 12.2(33)SRC Revision not

available

SNMP-FRAMEWORK-MIB
(RFC 2571)

• 12.2(18)SXF3 9901190000Z

• 12.2(33)SRA 9901190000Z

• 12.2(33)SRB 9901190000Z

• 12.2(33)SRC 9901190000Z

SNMP-MPD-MIB (RFC 2572)

12.2(18)SXF3 9905041636Z

•

• 12.2(33)SRA 9905041636Z

• 12.2(33)SRB 9905041636Z

• 12.2(33)SRC 9905041636Z

SNMP-NOTIFICATION-MIB
(RFC 2573)

• 12.2(18)SXF3 9808040000Z

• 12.2(33)SRA 9808040000Z

• 12.2(33)SRB 9808040000Z

• 12.2(33)SRC 9808040000Z

SNMP-PROXY-MIB

Supported and
Unverified

Unsupported or
Unverified

Not in

3-36

12.2(18)SXF3 9808040000Z

•

• 12.2(33)SRA 9808040000Z

• 12.2(33)SRB 9808040000Z

• 12.2(33)SRC 9808040000Z

SNMP-TARGET-MIB (RFC

2573)

•

12.2(18)SXF3 9808040000Z

• 12.2(33)SRA 9808040000Z

• 12.2(33)SRB 9808040000Z

• 12.2(33)SRC 9808040000Z

SNMP-USM-MIB (RFC 2574)

12.2(18)SXF3 9901200000Z

•

• 12.2(33)SRA 9901200000Z

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB

• 12.2(33)SRB 9901200000Z

• 12.2(33)SRC 9901200000Z

SNMP-VACM-MIB (RFC 2575)

12.2(18)SXF3 9901200000Z

•

• 12.2(33)SRA 9901200000Z

• 12.2(33)SRB 9901200000Z

• 12.2(33)SRC 9901200000Z

SNMPV2-MIB (RFC 1907)

12.2(18)SXF3 9511090000Z

•

• 12.2(33)SRA 9511090000Z

• 12.2(33)SRB 9511090000Z

• 12.2(33)SRC 9511090000Z

SONET-MIB (RFC 1595, 2558)

12.2(18)SXF3 9401030000Z

•

• 12.2(33)SRA 9810190000Z

• 12.2(33)SRB 9810190000Z

• 12.2(33)SRC 9810190000Z

SOURCE-ROUTING-MIB (RFC

1525)

• 12.2(18)SXF3 Revision not

Verified

Supported and
Unverified

Unsupported or
Unverified

available

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

TCP-MIB

Not in

OL-4077-07

12.2(18)SXF3 9411010000Z

•

• 12.2(33)SRA 9411010000Z

• 12.2(33)SRB 9411010000Z

• 12.2(33)SRC 9411010000Z

TUNNEL-MIB

12.2(18)SXF3 Y

•

• 12.2(33)SRA Y

• 12.2(33)SRB 200505160000Z

• 12.2(33)SRC 200505160000Z

UDP-MIB

12.2(18)SXF3 9411010000Z

•

Cisco 7600 Series Router MIB Specifications Guide

3-37

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-1 MIBs in 7600 Series Routers (continued)

Supported and

MIB

• 12.2(33)SRA 9411010000Z

• 12.2(33)SRB 9411010000Z

• 12.2(33)SRC 9411010000Z

Verified

Supported and
Unverified

Unsupported or
Unverified

Not in

3-38

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

MIB Notification Names in 7600 Series Routers

Table 3-2 lists the Notification Names associated with MIBs in 7600 Series Routers:

Table 3-2 MIB Notification names in 7600 Series Routers

Cisco 7600 MIBs

MIB Notification Name

BGP4-MIB

bgpEstablished,

Supported and
Verified

Supported and
Unverified

Unsupported or
Unverified

bgpBackwardTransition

• 12.2(18)SXF3 9405050000Z

• 12.2(33)SRA 9405050000Z

• 12.2(33)SRB 9405050000Z

• 12.2(33)SRC 9405050000Z

BRIDGE-MIB

newRoot,
topologyChange

• 12.2(18)SXF3 Revision not

available

• 12.2(33)SRA Revision not

available

• 12.2(33)SRB Revision not

available

• 12.2(33)SRC Revision not

available

CISCO-ALPS-MIB

alpsPeerStatusChange,
alpsCktStatusChange,
alpsAscuStatusChange,
alpsPeerConnStatusChange,
alpsCktOpenFailure,
alpsCktPartialReject

• 12.2(18)SXF3 200001280000Z

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

Not in

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-39

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

MIB Notification Name

CISCO-ATM-PVC­TRAP-EXTN-MIB

catmIntfPvcUpTrap,
catmIntfPvcOAMFailureTrap,

Supported and
Verified

Supported and
Unverified

Unsupported or
Unverified

catmIntfPvcSegCCOAMFail­ureTrap,
catmIntfPvcEndCCOAMFail­ureTrap,
catmIntfPvcAISRDIOAMFail­ureTrap,
catmIntfPvcAnyOAMFailure­Trap,
catmIntfPvcOAMRecoverTrap,
catmIntfPvcSegCCOAMReco­verTrap,
catmIntfPvcEndCCOAMReco­verTrap,
catmIntfPvcAISRDIOAMRe­coverTrap,
catmIntfPvcAnyOAMRecover­Trap,
catmIntfPvcUp2Trap,
catmIntfPvcDownTrap,
catmIntfPvcSegAISRDIFail­ureTrap,
catmIntfPvcEndAISRDIFail­ureTrap,
catmIntfPvcSegAISRDIReco­verTrap,
catmIntfPvcEndAISRDIReco­verTrap

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200303240000Z

CISCO-BGP4-MIB

cbgpFsmStateChange,
cbgpBackwardTransition,
cbgpPrefixThresholdExceeded,
cbgpPrefixThresholdClear

• 12.2(18)SXF3 200108130000Z

• 12.2(33)SRA 200302240000Z

• 12.2(33)SRB 200302240000Z

• 12.2(33)SRC 200302240000Z

CISCO-BSTUN-MIB

bstunPeerStateChangeNotifica­tion

• 12.2(18)SXF3 9701220000Z

Not in

3-40

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB Notification Name

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-BULK-FILE-MIB

• 12.2(18)SXF3 9810291700Z

• 12.2(33)SRA 9810291700Z

• 12.2(33)SRB 9810291700Z

• 12.2(33)SRC 200108220000Z

CISCO-CALLHOME-MIB

cbfDefineFileCompletion

ccmSmtpServerFailNotif,

Verified

Supported and
Unverified

Unsupported or
Unverified

ccmAlertGroupTypeAddedNo­tif,
ccmAlertGroupTypeDeleted­Notif,
ccmSmtpMsgSendFailNotif

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200704060000Z

CISCO-CAT6K-CROSS­BAR-MIB

cc6kxbarIntBusCRCErrExcdN
otif,
cc6kxbarIntBusCRCErrRcvrdN
otif,
cc6kxbarSwBusStatusChangeN
otif

• 12.2(18)SXF3 200411190000Z

• 12.2(33)SRA 200411190000Z

• 12.2(33)SRB 200411190000Z

• 12.2(33)SRC 200411190000Z

CISCO-CEF-MIB

cefResourceFailure,
cefPeerStateChange,
cefPeerFIBStateChange,
cefInconsistencyDetection

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200601300000Z

CISCO-CONFIG-COPY-MIB

• 12.2(18)SXF3 9701150000Z

• 12.2(33)SRA 200403170000Z

ccCopyCompletion

Not in

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-41

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

Supported and

MIB Notification Name

• 12.2(33)SRB 200403170000Z

• 12.2(33)SRC 200608220000Z

CISCO-CONFIG-MAN-MIB

ciscoConfigManEvent,

Verified

Supported and
Unverified

Unsupported or
Unverified

ccmCLIRunningCon­figChanged,
ccmCTIDRolledOver

• 12.2(18)SXF3 9511280000Z

• 12.2(33)SRA 9511280000Z

• 12.2(33)SRB 200406180000Z

• 12.2(33)SRC 200608220000Z

CISCO-DATA-COLLEC­TION-MIB

• 12.2(18)SXF3 Y

• 12.2(33)SRA 200210300530Z

• 12.2(33)SRB 200210300530Z

• 12.2(33)SRC 200210300530Z

CISCO-DLSW-EXT-MIB

cdcVFileCollectionError,
cdcFileXferComplete

cdeTrapTConnUpDown,
cdeTrapCircuitUpDown

• 12.2(18)SXF3 9703110000Z

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-DLSW-MIB

ciscoDlswTrapTConnPartner­Reject,
ciscoDlswTrapTConnProtVio­lation,
ciscoDlswTrapTConnUp,
ciscoDlswTrapTConnDown,
ciscoDlswTrapCircuitUp,
ciscoDlswTrapCircuitDown

• 12.2(18)SXF3 9506300900Z

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

Not in

3-42

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

Cisco 7600 MIBs

MIB Notification Name

CISCO-DSPU-MIB

dspuPuStateChangeTrap,

Supported and
Verified

Supported and
Unverified

Unsupported or
Unverified

dspuPuActivationFailureTrap,
newdspuPuStateChangeTrap,
newdspuPuActivationFailure­Trap,
dspuLuStateChangeTrap,
newdspuLuStateChangeTrap,
dspuLuActivationFailureTrap,
dspuSapStateChangeTrap

• 12.2(18)SXF3 9508150000Z

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-ENHANCED-MEM­ORY-POOL-MIB

• 12.2(18)SXF3 200106050000Z

• 12.2(33)SRA 200302240000Z

• 12.2(33)SRB 200302240000Z

• 12.2(33)SRC 200302240000Z

CISCO-ENTITY-ALARM-MIB

cempMemBufferNotify

ceAlarmAsserted,
ceAlarmCleared

• 12.2(18)SXF3 9907062150Z

• 12.2(33)SRA 9907062150Z

• 12.2(33)SRB 9907062150Z

• 12.2(33)SRC 9907062150Z

CISCO-ENTITY-FRU-CON­TROL-MIB

cefcModuleStatusChange,
cefcPowerStatusChange,
cefcFRUInserted,
cefcFRURemoved

• 12.2(18)SXF3 200310230000Z

• 12.2(33)SRA 200310230000Z

• 12.2(33)SRB 200310230000Z

• 12.2(33)SRC 200310230000Z

CISCO-ENTITY-SEN­SOR-MIB

• 12.2(18)SXF3 200301070000Z

• 12.2(33)SRA 200509080000Z

• 12.2(33)SRB 200601010000Z

• 12.2(33)SRC 200601010000Z

entSensorThresholdNotifica­tion

Not in

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-43

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

MIB Notification Name

CISCO-ENVMON-MIB

ciscoEnvMonShutdownNotifi-

Supported and
Verified

Supported and
Unverified

Unsupported or
Unverified

cation,
ciscoEnvMonFanNotification,
ciscoEnvMonFanStatus­ChangeNotif,
ciscoEnvMonRedundantSup­plyNotification,
ciscoEnvMonSuppStatus­ChangeNotif,
ciscoEnvMonTemperatureNoti­fication

• 12.2(18)SXF3 200207170000Z

• 12.2(33)SRA 200207170000Z

• 12.2(33)SRB 200207170000Z

• 12.2(33)SRC 200207170000Z

CISCO-ERM-MIB

ciscoErmGlobalPolicyViola­tion,
ciscoErmLocalPolicyViolation

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB 200602110000Z

• 12.2(33)SRC 200602110000Z

CISCO-ETHER-CFM-MIB

cEtherCfmCcMepUp,
cEtherCfmCcMepDown,
cEtherCfmCcCrossconnect,
cEtherCfmCcLoop,
cEtherCfmCcConfigError,
cEtherCfmXCheckMissing,
cEtherCfmXCheckUnknown,
cEtherCfmXCheckServiceUp

• 12.2(18)SXF3 Y

• 12.2(33)SRA 200412280000Z

• 12.2(33)SRB 200412280000Z

• 12.2(33)SRC 200412280000Z

CISCO-FLASH-MIB

ciscoFlashCopyCompletion­Trap,
ciscoFlashDeviceChangeTrap,
ciscoFlashDeviceInsertedNotif,
ciscoFlashDeviceRemovedNo­tif,
ciscoFlashMiscOpCompletion­Trap

Not in

3-44

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB Notification Name

• 12.2(18)SXF3 200301311234Z

• 12.2(33)SRA 200301311234Z

• 12.2(33)SRB 200403180000Z

• 12.2(33)SRC 200403180000Z

CISCO-FLEX-LINKS-MIB

• 12.2(18)SXF3 200504250000Z

• 12.2(33)SRA 200504250000Z

• 12.2(33)SRB 200504250000Z

• 12.2(33)SRC 200504250000Z

CISCO-HSRP-MIB

• 12.2(18)SXF3 9808030000Z

• 12.2(33)SRA 9808030000Z

• 12.2(33)SRB 9808030000Z

• 12.2(33)SRC 9808030000Z

CISCO-IETF-ATM2-PVC­TRAP-MIB-EXTN

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200007110000Z

CISCO-IETF-DHCP-SERVER­EXT-MIB

cflIfStatusChangeNotif

cHsrpStateChange

atmIntfPvcUpTrap,
atmIntfPvcOAMFailureTrap

cDhcpv4ServerIfLeaseLimitEx
ceeded,

Verified

Supported and
Unverified

Unsupported or
Unverified

cDhcpv4ServerSubnetFreeAddr
essLow,
cDhcpv4ServerSubnetFreeAddr
essHigh

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200703151200Z

CISCO-IETF-DHCP-SERVER­MIB

cDhcpv4ServerFreeAddressLo
w,
cDhcpv4ServerFreeAddressHig
h,
cDhcpv4ServerStartTime,
cDhcpv4ServerStopTime,
cDhcpv4ServerDuplicateAddre
ss

• 12.2(18)SXF3 Y

Not in

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-45

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

Supported and

MIB Notification Name

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200703270000Z

CISCO-IETF-FRR-MIB

• 12.2(18)SXF3 Y

• 12.2(33)SRA 200211051200Z

• 12.2(33)SRB 200211051200Z

• 12.2(33)SRC 200211051200Z

CISCO-IETF-ISIS-MIB

cmplsFrrProtected

ciiDatabaseOverload,

Verified

Supported and
Unverified

Unsupported or
Unverified

ciiManualAddressDrops,
ciiCorruptedLSPDetected,
ciiAttemptToExceedMaxSe­quence,
ciiIDLenMismatch,
ciiMaxAreaAddressesMis­match,
ciiOwnLSPPurge,
ciiSequenceNumberSkip,
ciiAuthenticationTypeFailure,
ciiAuthenticationFailure,
ciiVersionSkew,
ciiAreaMismatch,
ciiRejectedAdjacency,
ciiLSPTooLargeToPropagate,
ciiOrigLSPBuffSizeMismatch,
ciiProtocolsSupportedMis­match,
ciiAdjacencyChange,
ciiLSPErrorDetected

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB 200508161200Z

• 12.2(33)SRC Y

CISCO-IETF-PPVPN-MPLS-V
PN-MIB

• 12.2(18)SXF3 Y

• 12.2(33)SRA 200304171200Z

• 12.2(33)SRB 200304171200Z

• 12.2(33)SRC 200304171200Z

CISCO-IETF-PW-MIB

cMplsNumVrfRo­uteMaxThreshCleared

cpwVcDown,
cpwVcUp

Not in

3-46

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB Notification Name

• 12.2(18)SXF3 Y

• 12.2(33)SRA 200403171200Z

• 12.2(33)SRB 200403171200Z

• 12.2(33)SRC 200403171200Z

CISCO-IP-STAT-MIB

ciscoIpMRouteMissingHeart-

Verified

Supported and
Unverified

Unsupported or
Unverified

Beats

• 12.2(18)SXF3 200012220000Z

• 12.2(33)SRA 200503070000Z

• 12.2(33)SRB 200503070000Z

• 12.2(33)SRC 200503070000Z

CISCO-L2-CONTROL-MIB

• 12.2(18)SXF3 200306011700Z

• 12.2(33)SRA 200306011700Z

• 12.2(33)SRB 200306011700Z

• 12.2(33)SRC 200306011700Z

CISCO-MAC-NOTIFICA­TION-MIB

clcVlanMacLimitNotif

cmnMacChangedNotification,
cmnMacMoveNotification,
cmnMacThresholdExceedNotif

• 12.2(18)SXF3 200303210000Z

• 12.2(33)SRA 200303210000Z

• 12.2(33)SRB 200303210000Z

• 12.2(33)SRC 200706110000Z

CISCO-MVPN-MIB

• 12.2(18)SXF3 Y

• 12.2(33)SRA 200402231200Z

• 12.2(33)SRB 200402231200Z

• 12.2(33)SRC 200402231200Z

ciscoMvpnMvrfChange

Not in

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-47

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

MIB Notification Name

CISCO-OSPF-TRAP-MIB

cospfIfConfigError,

Supported and
Verified

Supported and
Unverified

cospfVirtIfConfigError,
cospfTxRetransmit,
cospfVirtIfTxRetransmit,
cospfOriginateLsa,
cospfMaxAgeLsa,
cospfNssaTranslatorStatus­Change,
cospfShamLinkStateChange,
cospfShamLinksStateChange,
cospfShamLinkNbrState­Change,
cospfShamLinkConfigError,
cospfShamLinkAuthFailure,
cospfShamLinkRxBadPacket,
cospfShamLinkTxRetransmit

• 12.2(18)SXF3 200302270000Z

• 12.2(33)SRA 200302270000Z

• 12.2(33)SRB 200302270000Z

• 12.2(33)SRC 200302270000Z

CISCO-PAE-MIB

cpaeNoGuestVlanNotif,
cpaeNoAuthFailVlanNotif

• 12.2(18)SXF3 200105241016Z

• 12.2(33)SRA 200302260000Z

• 12.2(33)SRB 200604120000Z

• 12.2(33)SRC 200604120000Z

CISCO-PIM-MIB

pimNeighborLoss (RFC 2934),
ciscoPimInterfaceUp,
ciscoPimInterfaceDown,
ciscoPimRPMappingChange,
ciscoPimInvalidRegister,
ciscoPimInvalidJoinPrune

• 12.2(18)SXF3 200011020000Z

• 12.2(33)SRA 200011020000Z

• 12.2(33)SRB 200011020000Z

• 12.2(33)SRC 200011020000Z

CISCO-PING-MIB

• 12.2(18)SXF3 200108280000Z

• 12.2(33)SRA 200108280000Z

• 12.2(33)SRB 200108280000Z

• 12.2(33)SRC 200108280000Z

ciscoPingCompletion

Unsupported or
Unverified

Not in

3-48

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

Cisco 7600 MIBs

MIB Notification Name

CISCO-PORT-SECURITY-MIB

cpsIfVlanSecureMacAddrVio-

Supported and
Verified

Supported and
Unverified

Unsupported or
Unverified

lation,
cpsSecureMacAddrViolation

• 12.2(18)SXF3 200504190000Z

• 12.2(33)SRA 200504190000Z

• 12.2(33)SRB 200504190000Z

• 12.2(33)SRC 200504190000Z

CISCO-PPPOE-MIB

cPppoeSystemSessionThresh­oldTrap,
cPppoeVcSessionThreshold­Trap

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200102200000Z

CISCO-PROCESS-MIB

cpmCPURisingThreshold,
cpmCPUFallingThreshold

• 12.2(18)SXF3 200105180000Z

• 12.2(33)SRA 200301220000Z

• 12.2(33)SRB 200301220000Z

• 12.2(33)SRC 200301220000Z

CISCO-RESILIENT-ETHER­NET-PROTOCOL-MIB

crepLinkStatus,
crepPreemptionStatus,
crepPortRoleChange

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200705220000Z

CISCO-RF-MIB

ciscoRFSwactNotif,
ciscoRFProgressionNotif,
ciscoRFIssuStateNotif

• 12.2(18)SXF3 200107200000Z

• 12.2(33)SRA 200404030000Z

• 12.2(33)SRB 200404030000Z

• 12.2(33)SRC 200404030000Z

CISCO-RSRB-MIB

rsrbPeerStateChangeNotifica­tion

Not in

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-49

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

Supported and

MIB Notification Name

• 12.2(18)SXF3 9508210000Z

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-RTTMON-MIB

rttMonConnectionChangeNoti-

Verified

Supported and
Unverified

Unsupported or
Unverified

fication,
ttMonTimeoutNotification,
rttMonThresholdNotification

• 12.2(18)SXF3 0104230000Z

• 12.2(33)SRA 200401200000Z

• 12.2(33)SRB 200603020000Z

• 12.2(33)SRC 200603020000Z

CISCO-SDLLC-MIB

convSdllcPeerStateChangeNo­tification

• 12.2(18)SXF3 9508210000Z

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-SONET-MIB

ciscoSonetSectionStatus­Change,
ciscoSonetLineStatusChange,
ciscoSonetPathStatusChange

• 12.2(18)SXF3 200205220000Z

• 12.2(33)SRA 200205220000Z

• 12.2(33)SRB 200205220000Z

• 12.2(33)SRC 200205220000Z

CISCO-SRP-MIB

srpTrapRingWrapped,
srpTrapRingRestored

• 12.2(18)SXF3 200103280000Z

• 12.2(33)SRA 200103280000Z

• 12.2(33)SRB 200103280000Z

• 12.2(33)SRC Y

CISCO-STACK-MIB

moduleUp,
moduleDown,
chassisAlarmOn,
chassisAlarmOff

• 12.2(18)SXF3 200305290000Z

• 12.2(33)SRA 200305290000Z

Not in

3-50

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB Notification Name

• 12.2(33)SRB 200305290000Z

• 12.2(33)SRC 200305290000Z

CISCO-STP-EXTEN­SIONS-MIB

stpxInconsistencyUpdate,
stpxLoopInconsistencyUpdate,

Verified

Supported and
Unverified

Unsupported or
Unverified

stpxRootInconsistencyUpdate

• 12.2(18)SXF3 200503020000Z

• 12.2(33)SRA 200503020000Z

• 12.2(33)SRB 200503020000Z

• 12.2(33)SRC 200503020000Z

CISCO-STUN-MIB

stunPeerStateChangeNotifica­tion

• 12.2(18)SXF3 9508210000Z

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-SYSLOG-MIB

• 12.2(18)SXF3 9508070000Z

• 12.2(33)SRA 9508070000Z

• 12.2(33)SRB 9508070000Z

• 12.2(33)SRC 9508070000Z

CISCO-TAP2-MIB

clogMessageGenerated

ciscoTap2MIBActive,
ciscoTap2MediationTimedOut,
ciscoTap2MediationDebug,
ciscoTap2StreamDebug,
ciscoTap2Switchover

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB 200611270000Z

• 12.2(33)SRC 200611270000Z

CISCO-VLAN-MEMBER­SHIP-MIB

• 12.2(18)SXF3 200404070000Z

• 12.2(33)SRA 200404070000Z

• 12.2(33)SRB 200404070000Z

• 12.2(33)SRC 200404070000Z

CISCO-VOICE-COM­MON-DIAL-CONTROL-MIB

• 12.2(18)SXF3 200109050000Z

vmVmpsChange

cvdcPoorQoVNotification

Not in

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-51

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

Supported and

MIB Notification Name

• 12.2(33)SRA 200109050000Z

• 12.2(33)SRB Y

• 12.2(33)SRC Y

CISCO-VPDN-MGMT-MIB

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200601200000Z

CISCO-VTP-MIB

cvpdnNotifSession

vtpConfigDigestError,

Verified

Supported and
Unverified

Unsupported or
Unverified

vtpConfigRevNumberError,
vtpLocalModeChanged,
vlanTrunkPortDynamicStatus­Change,
vtpVlanCreated,
vtpVlanDeleted,
vtpVersionInUseChanged,
vtpVersionOneDeviceDetected

• 12.2(18)SXF3 200311210000Z

• 12.2(33)SRA 200311210000Z

• 12.2(33)SRB 200311210000Z

• 12.2(33)SRC 200311210000Z

DIAL-CONTROL-MIB

dialCtlPeerCallInformation,
dialCtlPeerCallSetup

• 12.2(18)SXF3 9609231544Z

• 12.2(33)SRA 9609231544Z

• 12.2(33)SRB 9609231544Z

• 12.2(33)SRC Y

DLSW-MIB

dlswTrapTConnPartnerReject,
dlswTrapTConnProtViolation,
dlswTrapTConnUp,
dlswTrapTConnDown,
dlswTrapCircuitUp,
dlswTrapCircuitDown

• 12.2(18)SXF3 9512050000Z

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC Y

DS1-MIB (RFC 1406, 2495,

2495)

dsx1LineStatusChange

Not in

3-52

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB Notification Name

• 12.2(18)SXF3 Revision not

Verified

Supported and
Unverified

Unsupported or
Unverified

available

• 12.2(33)SRA 9808011830Z

• 12.2(33)SRB 9808011830Z

• 12.2(33)SRC 9808011830Z

ENTITY-MIB (RFC 2737)

• 12.2(18)SXF3 9912070000Z

• 12.2(33)SRA 9912070000Z

• 12.2(33)SRB 9912070000Z

• 12.2(33)SRC 9912070000Z

EVENT-MIB

entConfigChange

mteTriggerFired,
mteTriggerRising,
mteTriggerFalling,
mteTriggerFailure,
mteEventSetFailure

• 12.2(18)SXF3 9902221700Z

• 12.2(33)SRA 200010160000Z

• 12.2(33)SRB 200010160000Z

• 12.2(33)SRC 200010160000Z

FR-MFR-MIB

mfrMibTrapBundleLinkMis­match

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200011300000Z

IEEE8021-CFM-MIB

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB 200608220100Z

• 12.2(33)SRC 200608220100Z

IF-MIB (RFC 2863)

dot1agCfmFaultAlarm

linkDown,
linkUp

• 12.2(18)SXF3 9611031355Z

• 12.2(33)SRA 9611031355Z

• 12.2(33)SRB 9611031355Z

• 12.2(33)SRC 9611031355Z

LLDP-MIB

lldpRemTablesChange

Not in

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-53

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

Supported and

MIB Notification Name

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB 200505060000Z

• 12.2(33)SRC 200505060000Z

MPLS-LDP-MIB

mplsLdpInitSesThresholdEx-

Verified

Supported and
Unverified

Unsupported or
Unverified

ceeded,
mplsLdpPVLMismatch,
mplsLdpSessionDown

• 12.2(18)SXF3 200108161200Z

• 12.2(33)SRA 200108161200Z

• 12.2(33)SRB Y

• 12.2(33)SRC Y

MPLS-LDP-STD-MIB (RFC

3815)

mplsLdpInitSessionThreshold­Exceeded,
mplsLdpPathVectorLimitMis­match,
mplsLdpSessionUp,
mplsLdpSessionDown

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB 200406030000Z

• 12.2(33)SRC 200406030000Z

MPLS-LSR-MIB

mplsXCUp,
mplsXCDown

• 12.2(18)SXF3 200004261200Z

• 12.2(33)SRA 200004261200Z

• 12.2(33)SRB Y

• 12.2(33)SRC Y

MPLS-LSR-STD-MIB (RFC

3031)

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB 200406030000Z

• 12.2(33)SRC 200406030000Z

mplsXCUp,
mplsXCDown

Not in

3-54

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

Cisco 7600 MIBs

MIB Notification Name

MPLS-L3VPN-STD-MIB

mplsL3VpnVrfUp,

Supported and
Verified

Supported and
Unverified

Unsupported or
Unverified

mplsL3VpnVrfDown,
mplsL3VpnVrfRouteMidThres
hExceeded,
mplsL3VpnVrfNumVrfRouteM
axThreshExceeded,
mplsL3VpnNumVrfSecIllglLbl
ThrshExcd,
mplsL3VpnNumVrfRouteMax
ThreshCleared

• 12.2(18)SXF3 Y

• 12.2(33)SRA Y

• 12.2(33)SRB Y

• 12.2(33)SRC 200601230000Z

MPLS-TE-MIB

mplsTunnelDown,
mplsTunnelUp,
mplsTunnelRerouted

• 12.2(18)SXF3 200011211200Z

• 12.2(33)SRA 200011211200Z

• 12.2(33)SRB 200011211200Z

• 12.2(33)SRC 200011211200Z

MPLS-VPN-MIB

mplsNumVrfRouteMidThresh­Exceeded,
mplsNumVrfRouteMaxThresh­Exceeded,
mplsNumVrfSecIllegalLa­belThreshExceeded,
mplsVrfIfDown,
mplsVrfIfUp

• 12.2(18)SXF3 200110151200Z

• 12.2(33)SRA 200110151200Z

• 12.2(33)SRB 200110151200Z

• 12.2(33)SRC 200110151200Z

MSDP-MIB

msdpEstablished,
msdpBackwardTransition

• 12.2(18)SXF3 9912160000Z

• 12.2(33)SRA 9912160000Z

• 12.2(33)SRB 9912160000Z

• 12.2(33)SRC 9912160000Z

Not in

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-55

Cisco 7600 MIBs

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

MIB Notification Name

OSPF-TRAP-MIB

ospfIfStateChange,

Supported and
Verified

Supported and
Unverified

Unsupported or
Unverified

ospfVirtIfStateChange,
ospfNbrStateChange,
ospfVirtNbrStateChange,
ospfIfConfigError,
ospfVirtIfConfigError,
ospfIfAuthFailure,
ospfVirtIfAuthFailure,
ospfIfRxBadPacket,
ospfVirtIfRxBadPacket,
ospfTxRetransmit,
ospfVirtIfTxRetransmit,
ospfOriginateLsa,
ospfMaxAgeLsa,
ospfLsdbOverflow,
ospfLsdbApproachingOverflow

• 12.2(18)SXF3 9501201225Z

• 12.2(33)SRA 9501201225Z

• 12.2(33)SRB 9501201225Z

• 12.2(33)SRC 9501201225Z

PIM-MIB (RFC 2934)

• 12.2(18)SXF3 200009280000Z

• 12.2(33)SRA 200009280000Z

• 12.2(33)SRB 200009280000Z

• 12.2(33)SRC 200009280000Z

RMON-MIB (RFC 1757)

pimNeighborLoss

fallingAlarm,
risingAlarm

• 12.2(18)SXF3 Revision not

available

• 12.2(33)SRA Revision not

available

• 12.2(33)SRB Revision not

available

• 12.2(33)SRC Revision not

available

SNA-SDLC-MIB

sdlcPortStatusChange,
sdlcLSStatusChange,
sdlcLSStatusChange1

• 12.2(18)SXF3 9411150000Z

• 12.2(33)SRA Y

Not in

3-56

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-2 MIB Notification names in 7600 Series Routers (continued)

Cisco 7600 MIBs

Supported and

MIB Notification Name

• 12.2(33)SRB Y

• 12.2(33)SRC Y

Note The 3rd 12.2(18)SXF rebuild (12.2(18)SXF3) release was used because later releases include features

Verified

Supported and
Unverified

Unsupported or
Unverified

not supported by c7600 SR releases. Feature parity is up to SXF3.

Not in

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-57

ATM-MIB

ATM-MIB

The ATM-MIB (RFC 1695) contains the ATM and ATM adaptation Layer 5 (AAL5) objects used to
manage logical and physical entities and the relationship between them, such as ATM interfaces, virtual
links, cross connects, and AAL5 entities and connections.

MIB Constraints

Table 3-3 lists the constraints that the Cisco 7600 Series router places on objects in the ATM-MIB. For

detailed definitions of MIB objects, see the MIB.

Table 3-3 ATM-MIB Constraints

MIB Object Notes

atmInterfaceDs3PlcpTable

atmInterfaceTCTable

atmTrafficDescrParamTable

atmVplTable

atmVclTable

Chapter 3 Cisco 7600 MIB Specifications

Not implemented.

Not implemented.

Read-only.

Not implemented.

BGP4-MIB

atmVclAdminStatus Read-only.

•

• atmVclReceiveTrafficDescrIndex Read-only.

• atmVclTransmitTrafficDescrIndex Read-only.

• atmVccAalType Read-only.

• atmVccAal5CpcsTransmitSduSize Read-only.

• atmVccAal5CpcsReceiveSduSize Read-only.

• atmVccAal5EncapsType Read-only.

• atmVclCrossConnectIdentifier Read-only.

• atmVclRowStatus Read-only.

atmVpCrossConnectTable

• atmVpCrossConnectIndexNext Not implemented.

atmVcCrossConnectTable

• atmVcCrossConnectIndexNext Not implemented.

* The ifType for the ifIndex used in the ATM-MIB tables must be type atm(37).

The BGP4-MIB (RFC 1657) provides access to information related to the implementation of the Border
Gateway Protocol (BGP). The MIB provides:

• BGP configuration information

Not implemented.

Not implemented.

3-58

• Information about BGP peers and messages exchanged with them

• Information about advertised networks

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

BRIDGE-MIB

The BRIDGE-MIB contains objects to manage Media Access Control (MAC) bridges between Local
Area Network (LAN) segments, as defined by the IEEE 802.1D-1990 standard. This MIB is extracted
from RFC 1493 and is intended for use with network management protocols in TCP/IP based internets.

CISCO-802-TAP-MIB

The CISCO-802-TAP-MIB contains object to manage IEEE 802 intercept.

CISCO-AAA-SESSION-MIB

The CISCO-AAA-SESSION-MIB contains information about accounting sessions based on
authentication, authorization, and accounting (AAA) protocols.

BRIDGE-MIB

CISCO-AAL5-MIB

The CISCO-AAL5-MIB contains performance statistics for ATM adaptation Layer 5 (AAL5) virtual
channel connections (VCCs). This MIB provides statistics not found in the aal5VccTable in RFC 1695
(for example, packets and octets received and transmitted on the VCC).

CISCO-ACCESS-ENVMON-MIB

The CISCO-ACCESS-ENVMON-MIB indicates the reason for a power supply failure, which is
information that is not provided in the ciscoEnvMonSupplyStatusTable in the CISCO-ENVMON-MIB.
The CISCO-ACCESS-ENVMON-MIB also defines temperature and voltage notifications to replace
those in CISCO-ENVMON-MIB.

CISCO-ALPS-MIB

The CISCO-ALPS-MIB provides Cisco airline protocol support for IBM-P1024B(ALC) and
Unisys-P1024C(UTS) protocol encapsulation over TCP/IP. The MIB contains configuration and
operational information for the protocol, which provides a tunneling mechanism to transport airline
protocol data across a Cisco router-based TCP/IP network to an X.25-attached mainframe.

CISCO-ASPP-MIB

The CISCO-ASPP-MIB provides configuration and operational information on asynchronous-polled
protocols such as the asynchronous security protocols that alarm monitoring companies use.

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-59

CISCO-ATM-EXT-MIB

CISCO-ATM-EXT-MIB

The CISCO-ATM-EXT-MIB contains extensions to the Cisco ATM module that are used to manage
ATM entities. It provides additional AAL5 performance statistics for a virtual channel connection (VCC)
on an ATM interface.

Note The cAal5VccExtTable augments the aal5VccTable of the ATM-MIB. The aal5VccTable contains

additional AAL5 performance parameters.

CISCO-ATM-PVC-MIB

The CISCO-ATM-PVC-MIB contains objects to configure a permanent virtual circuit (PVC) on an
ATM uplink card, and bind the PVC to a virtual LAN (VLAN). This allows the PVC to carry bridged
PDUs (BPDUs) using the encapsulation method described in RFC 1483, which is an alternative to using
LAN emulation to transfer BPDUs.

Chapter 3 Cisco 7600 MIB Specifications

CISCO-ATM-PVCTRAP-EXTN-MIB

The CISCO-ATM-PVCTRAP-EXTN-MIB supplements to the CISCO-IETF-ATM2-PVCTRAP-MIB.

CISCO-ATM-QOS-MIB

The CISCO-ATM-QOS-MIB is created to provide ATM QoS information in the following areas:

• Traffic shaping on a per-VC basis

• Traffic shaping on a per-VP basis

• Per-VC queuing/buffering.

CISCO-BCP-MIB

The CISCO-BCP-MIB (based on RFC 2878) (Bridging Control Protocol) contains objects to configure,
enable, and disable bridge modules on both ends of point-to-point links. The Cisco 7600 series Internet
router uses the BCP for transporting Ethernet frames over SONET and DPT networks. The BCP-MIB
manages and monitors Bridge Control Protocol configuration and information on subnetwork interfaces
using the family of Point-to-Point Protocols.

MIB Constraints

Table 3-4 lists the constraints that the router places on objects in the CISCO-BCP-MIB. For detailed

definitions of MIB objects, see the MIB.

Cisco 7600 Series Router MIB Specifications Guide

3-60

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-4 CISCO-BCP-MIB Constraints

MIB Object Notes

bcpConfigTable

bcpConfigBridgeIdControl Read-only. Always disabled

•

• bcpConfigBridgeId Always 0. BcpConfigBridgeIdControl must be enabled

• bcpConfigLineIdControl Read-only. Always disabled

• bcpConfigLineId Always 0. BcpConfigLineIdControl must be enabled to

• bcpConfigMacSupport Read-only. Always disabled

• bcpConfigMacType Always 0. BcpConfigMacControl must be enabled to

• bcpConfigTinygram Read-only. Always disabled

• bcpConfigMacAddressControl Read-only. Always disabled

• bcpConfigMacAddress Read-only. Always 0000.0000.0000, since this is

• bcpConfigSpanTreeControl Read-only. Always disabled

• bcpConfigSpanTree Read-only. Always null (0).

* If there is an entry in the ifTable with ifType ppp(23), there will be an entry in both the bcpOperTable and

bcpConfigTable.

* The CISCO-BCP-MIB supports interfaces configured with bridge-enabled only, which means if no “bridge-enable” is

configured, there will be no such entry for this interface when the user pulls the bcpOperTable or bcpConfigTable
by SNMP.

CISCO-BGP-POLICY-ACCOUNTING-MIB

to have value.

have value.

have value.

meaningful only if BcpConfigMacAddressControl is
enabled.

BcpConfigSpanTreeControl must be enabled to have
value.

CISCO-BGP-POLICY-ACCOUNTING-MIB

The CISCO-BGP-POLICY-ACCOUNTING-MIB contains BGP policy-based accounting information
(such as ingress traffic on an interface), which can be used for billing purposes. The MIB provides
support for BGP Policy Accounting, which enables you to classify IP traffic into different classes and to
maintain statistics for each traffic class.

The MIB contains counts of the number of bytes and packets of each traffic type on each input interface.
This information can be used to charge customers according to the route that their traffic travels.

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

3-61

CISCO-BGP4-MIB

CISCO-BGP4-MIB

The CISCO-BGP4-MIB provides access to information related to the implementation of the Border
Gateway Protocol (BGP). The MIB provides:

• BGP configuration information

• Information about BGP peers and messages exchanged with them

• Information about advertised networks

CISCO-BRIDGE-EXT-MIB

The CISCO-BRIDGE-EXT-MIB extends the BRIDGE-MIB specified in RFC 1493.

CISCO-BSC-MIB

The CISCO-BSC-MIB contains objects to manage binary synchronous communications (BSC) on the
router, including BSC ports (serial interfaces) and BSC control units (stations on a port).

Chapter 3 Cisco 7600 MIB Specifications

CISCO-BSTUN-MIB

The CISCO-BSTUN-MIB contains objects to manage Block Serial Tunnels (BSTUNs) on the router.
The MIB provides global BSTUN information and contains configuration and operational information
to manage BSTUN groups, ports, and routes.

CISCO-BULK-FILE-MIB

The CISCO-BULK-FILE-MIB contains objects to create and delete files of SNMP data for bulk-file
transfer.

MIB Constraints

Table 3-5 lists the constraints that the router places on objects in the CISCO-BULK-FILE-MIB. For detailed

definitions of MIB objects, see the MIB.

Table 3-5 CISCO-BULK-FILE-MIB Constraints

MIB Object Notes

cbfDefineFileTable

•

cbfDefinedFileStorage Only ephemeral type of file storage is supported.

Note The ephemeral bulk file created can be moved to

a remote FTP server using
CISCO-FTP-CLIENT-MIB.

3-62

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-5 CISCO-BULK-FILE-MIB Constraints

MIB Object Notes

• cbfDefinedFileFormat Only bulkBinary and bulkASCII file formats are

Note:

The cbfDefienFileTable has objects that are required for defining a bulk file and for controlling its creation. The

cbfDefineObjectTable has information regarding the contents (SNMP data) that go into the bulk file.

When an entry in the cbfDefineFileTable and its corresponding entries in the cbfDefineObjectTable are active, then

cbfDefineFileNow can then be set to create. This causes a bulkFile to be created as defined in cbfDefineFileTable
and it will also create an entry in the cbfStatusFileTable.

CISCO-CABLE-DIAG-MIB

The CISCO-CABLE-DIAG-MIB module defines objects for managing cable diagnostic test capabilities
supported by the Cisco devices.

Cable diagnostic tests are tests intended to exercise the functional integrity of the cable attached to a
physical interface

CISCO-CABLE-DIAG-MIB

supported.

CISCO-CALLHOME-MIB

The CISCO-CALLHOME-MIB module provides functionality to manage Call Home feature within the
framework of Call Home architecture.

A customer might be deploying network solutions to run mission critical applications such as storage
solutions that require high availability. Such customers need runtime support for their networking
products. Cisco Call Home feature enables a system experiencing Hardware/Software problem to
automatically send relevant failure information to the Support Center. The Support Center can use this
information to provide immediate help in the form of troubleshooting or hardware replacement. This
feature also provides functionality that allow storage systems to send performance, accounting, and
system health information.

CISCO-CAR-MIB

The CISCO-CAR-MIB contains information about the Committed Access Rate (CAR) assigned to router
interfaces. The CAR is used to control the rate of traffic on an interface for packet switching purposes.
The MIB provides information about how the router is to handle traffic that conforms and exceeds the
CAR on the interface.

CISCO-CASA-FA-MIB

OL-4077-07

The CISCO-CASA-FA-MIB is used in conjunction with the CISCO-CASA-MIB to manage a
Cisco Appliance Services Architecture (CASA) forwarding agent (FA).

Cisco 7600 Series Router MIB Specifications Guide

3-63

CISCO-CASA-MIB

The CASA protocol allows appliances (software entities such as web caches, firewalls, and load
balancers) to control the behavior of forwarding agents (hardware devices such as switches and routers).
The appliance tells forwarding agents how to handle packets based on their source and destination
IP addresses and ports, and IP protocol fields (this information is called an affinity).

CISCO-CASA-MIB

The CISCO-CASA-MIB contains objects to manage a Cisco Appliance Services Architecture (CASA)
entity (such as a manager or a forwarding agent). The MIB contains objects to configure CASA, and to
retrieve status and operational information about the fixed affinity cache.

The CASA protocol allows appliances (software entities such as web caches, firewalls, and load
balancers) to control the behavior of forwarding agents (hardware devices such as switches and routers).
The appliance tells forwarding agents how to handle packets based on their source and destination
IP addresses and ports, and IP protocol fields (this information is called an affinity).

CISCO-CAT6K-CROSSBAR-MIB

Chapter 3 Cisco 7600 MIB Specifications

The CISCO-CAT6K-CROSSBAR-MIB contains objects to configure and manage the crossbar-switching
fabric module on Cisco Catalyst 6500 family switches.

CISCO-CDP-MIB

The CISCO-CDP-MIB contains objects to manage the Cisco Discovery Protocol (CDP) on the router.

CISCO-CEF-MIB

The CISCO-CEF-MIB contains objects to configure and monitor CEF related objects.

CISCO-CIRCUIT-INTERFACE-MIB

The CISCO-CIRCUIT-INTERFACE-MIB contains objects to configure the circuit description for an
interface. The circuit description identifies circuits on interfaces such as ATM and Frame Relay, and
might be used, for example, to correlate performance statistics on the corresponding interfaces.

CISCO-CLASS-BASED-QOS-MIB

3-64

The CISCO-CLASS-BASED-QOS-MIB provides only read access to quality of service
(QoS) configuration information and statistics for Cisco platforms that support the modular Quality of
Service command-line interface (modular QoS CLI).

To understand how to navigate the CISCO-CLASS-BASED-QOS-MIB tables, it is important to
understand the relationship among different QoS objects. QoS objects consists of:

• Match Statement – the specific match criteria to identify packets for classification purposes.

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

• Class Map – a user-defined traffic class that contains 1 or more match statements used to classify

packets into different categories.

• Feature Action – a QoS feature. Features include police, traffic shaping, queueing, random detect,

and packet marking. After the traffic has been classified we apply actions to each traffic class.

• Policy Map – a user-defined policy that associates a Qos feature action to the user-define class map.

• Service Policy – a policy map that has been attached to an interface.

The MIB uses the following indices to identify QoS features and distinguish among instances of those
features:

• cbQosObjectsIndex – identifies each QoS feature on the router.

• cbQoSConfigIndex n- identifies a type of QoS configuration. This index is shared by QoS objects

that have identical configuration.

• cbQosPolicyIndex – uniquely identifies a service policy.

QoS MIB information is stored in:

• Configuration instances – includes all class maps, policy map, match statements, and feature action

configuration parameters. Might have multiple identical instances. Multiple instances of the same
QoS feature share a single configuration object, which is identified by cbQosConfigIndex.

• Runtime Statistics instances—Includes summary counts and rates by traffic class before and after

any configured QoS policies are enforced. In addition, detailed feature-specific statistics are
available for select PolicyMap features. Each has a unique runtime instance. Multiple instances of
a QoS feature have a separate statistics object. Run-time instances of QoS objects are each assigned
a unique identifier (cbQosObjectsIndex) to distinguish among multiple objects with matching
configurations.

CISCO-CONFIG-COPY-MIB

CISCO-CONFIG-COPY-MIB

The CISCO-CONFIG-COPY-MIB contains objects to copy configuration files on the router. For
example, the MIB enables the SNMP agent to copy:

• Configuration files to and from the network

• The running configuration to the startup configuration and startup to running

• The startup or running configuration files to and from a local Cisco IOS file system

CISCO-CONFIG-MAN-MIB

The CISCO-CONFIG-MAN-MIB contains objects to track and save changes to the router configuration.
The MIB represents a model of the configuration data that exists elsewhere in the router and in peripheral
devices. Its main purpose is to report changes to the running configuration through the
SNMP notification ciscoConfigManEvent.

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-65

CISCO-CONTEXT-MAPPING-MIB

CISCO-CONTEXT-MAPPING-MIB

The CISCO-CONTEXT-MAPPING-MIB module provides mapping tables which contain the
information that a single SNMP agent sometimes needs to support multiple instances of the same MIB
module. In such cases, network management applications need to know the specific data/identifier values
in each context. This is accomplished through the use of multiple SNMP contexts.

CISCO-CSG-MIB

The CISCO-CSG-MIB supports the Cisco Content Services Gateway (CSG) product. It includes five
traps and four tables that enable querying CSG resource statistics.

CISCO-DATA-COLLECTION-MIB

The CISCO-DATA-COLLECTION-MIB retrieves data periodically when the data displays as a set of
discontinuous rows spread across multiple tables. This MIB module facilitates data retrieval of tabular
objects. This MIB can be used for performance and accounting purposes, where several row instances
of a set of objects are polled over a period of time.

Chapter 3 Cisco 7600 MIB Specifications

The MIB provides the user a way to specify which objects and which instances are required. In addition
the MIB provides 2 ways in which this data can be retrieved.

MIB Constraints

Table 3-6 lists the constraints that the Cisco 7600 Series router places on objects in the

CISCO-DATA-COLLECTION-MIB. For detailed definitions of MIB objects, see the MIB. Any MIB
table or object not listed in this table is implemented as defined in the MIB.

Note Only traps are supported by the CISCO-DATA-COLLECTION-MIB.

Table 3-6 CISCO-DATA-COLLECTION-MIB Constraints

MIB Object Notes

cdcVFileTable

cdcVFileMgmtTable

cdcDGTable

cdcDGBaseObjectTable

cdcDGInstanceTable

cdcFileXferConfTable

• cdcVFilePersistentStorage

• cdcVFileMaxSizeHitsLimit.

Not implemented.

Not implemented.

Not implemented.

Not implemented.

Not implemented.

Not implemented.

These objects are not implemented.

3-66

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

CISCO-DIAL-CONTROL-MIB

The CISCO-DIAL-CONTROL-MIB stores past call information. This MIB is an extension of RFC 2128.

CISCO-DLCSW-MIB

The CISCO-DLCSW-MIB contains objects to manage Frame-Relay access support (FRAS) sessions to
the end-user station. The MIB applies only to downstream or end-user sessions. It does not apply to
upstream or host-end sessions, which are managed through the FRAS-HOST-MIB.

CISCO-DLSW-EXT-MIB

The CISCO-DLSW-EXT-MIB is an extension to the CISCO-DLSW-MIB. It contains objects to manage
Cisco specific data-link switching (DLSw) protocol enhancements. DLSW provides a way to transport
Systems Network Architecture (SNA) and NetBIOS traffic over an IP network.

CISCO-DIAL-CONTROL-MIB

CISCO-DLSW-MIB

The CISCO-DLSW-MIB contains objects to manage Data Link Switches.

CISCO-DSPU-MIB

The CISCO-DSPU-MIB contains objects to configure and manage Cisco downstream physical
unit (DSPU) objects.

CISCO-EIGRP-MIB

The CISCO-EIGRP-MIB contains objects to manage Enhanced Interior Gateway Protocol (EIGRP).
EIGRP is a Cisco proprietary distance vector routing protocol, based on the Diffusing Update Algorithm
(DUAL). DUAL defines the method to identify loop-free paths through a network.

CISCO-EMBEDDED-EVENT-MGR-MIB

The CISCO-EMBEDDED-EVENT-MGR-MIB provides descriptions and stores events generated by the
Cisco Embedded Event Manager. The Cisco Embedded Event Manager detects hardware and software
faults and other events such as OIRs for the system.

CISCO-ENHANCED-IMAGE-MIB

The CISCO-ENHANCED-IMAGE-MIB provides information about events running on the system. The
MIB modular operating systems.

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-67

CISCO-ENHANCED-MEMORY-POOL-MIB

CISCO-ENHANCED-MEMORY-POOL-MIB

The CISCO-ENHANCED-MEMORY-POOL-MIB contains objects to monitor memory pools on all of
the physical entities on a managed system. Represents the different types of memory pools that may be
present in a managed device. Memory use information is provided to users at three different intervals of
time: 1 minute, 5 minutes, and 10 minutes. Memory pools can be categorized into two groups, predefined
pools and dynamic pools. The following pool types are currently predefined:

• 1:Processor memory

• 2:I/O memory

• 3:PCI memory

• 4:Fast memory

• 5:Multibus memory

Dynamic pools have a pool type value greater than any of the predefined types listed above. Only the
processor pool is required to be supported by all devices. Support for other pool types is dependent on
the device being managed. For detailed definitions of the CISCO-ENHANCED-MEMORY-POOL-MIB
objects, see the MIB.

Chapter 3 Cisco 7600 MIB Specifications

MIB Constraints

Table 3-7 lists the constraints that the Cisco 7600 Series router places on objects in the

CISCO-ENHANCED-MEMORY-POOL-MIB. For detailed definitions of MIB objects, see the MIB.

Table 3-7 CISCO-ENHANCED-MEMORY-POOL-MIB Constraints

MIB Object Notes

ciscoMemoryPoolTable

•

cempMemPoolType Values are:

• processorMemory(2)

• ioMemory(3)

• cempMemPoolAlternate Always 0.

• cempMemPoolPlatformMemory Always 0.

MIB Usage Values for Cisco FlexWAN and FlexWAN2 Cards

There are two types of memory available on the Enhanced FlexWAN cards, processor and PCI. Only the
processorMemory(2) and ioMemory (3) pool types are supported. Ta b le 3-8 lists the memory pool names
corresponding to each pool type:

3-68

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-8 CISCO-ENHANCED-MEMORY-POOL-MIB Usage Values in the cempMemPoolTable

CISCO-ENTITY-ALARM-MIB

cempMemPoolType

processorMemory

ioMemory

CISCO-ENTITY-ALARM-MIB

The CISCO-ENTITY-ALARM-MIB enables the Cisco 7600 Series router to monitor alarms generated
by system components, such as the chassis, slots, modules, power supplies, fans, and ports.

MIB Constraints

Tabl e 3-9 lists the constraints that the Cisco 7600 Series router WAN modules place on objects in the

CISCO-ENTITY-ALARM-MIB. For detailed definitions of MIB objects, see the MIB.

Table 3-9 CISCO-ENTITY-ALARM-MIB Constraints

MIB Object Notes

ceAlarmTable

cempMemPoolName

• Processor 0

• Processor 1

• I/O is 0

• I/O is 1

ceAlarmFilterProfile Not implemented.

•

• ceAlarmFilterProfileIndexNext Not implemented.

ceAlarmFilterProfileTable

ceAlarmDescrTable

Not implemented.

ceAlarmDescrSeverity Read-only.

ENTITY-MIB Table, entPhysicalTable, identifies the physical system components in the router. The
following list describes the table objects that describe the alarms for the CISCO-ENTITY-ALARM-MIB:

• Physical entity—The component in the Cisco 7600 router that generates the alarm.

• ceAlarmDescrVendorType—The object specifies an identifier (typically an enterprise-specific OID)

that uniquely identifies the vendor type of those physical entities that this alarm description applies
to.

• Alarm severity—Each alarm type defined by a vendor type and employed by the system is assigned

an associated severity:

–

Critical—Indicates a severe, service-affecting condition has occurred and that immediate
corrective action is imperative, regardless of the time of day or day of the week. For example,
online insertion and removal or loss of signal failure when a physical port link is down.

–

Major—Used for hardware or software conditions. Indicates a serious disruption of service or
the malfunctioning or failure of important hardware. Requires immediate attention and response
of a technician to restore or maintain system stability. The urgency is less than in critical
situations because of a lesser effect on service or system performance.

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-69

CISCO-ENTITY-ALARM-MIB

• Alarm description text—Specifies a readable message describing the alarm.

• Alarm type—Identifies the type of alarm that is generated. An arbitrary integer value that uniquely

Table 3-10 lists the alarm descriptions and severity levels for the Cisco 7600 router FlexWAN PA T3/E3

ports.

Table 3-10 Alarms Supported for Cisco 7600 Router FlexWAN PA T3/E3 Ports

Physical Entity ceAlarmDescrVendorType

FlexWAN PA T3/3E
ports

Chapter 3 Cisco 7600 MIB Specifications

–

Minor—Used for troubles that do not have a serious effect on service to customers or for alarms
in hardware that are not essential to the operation of the system.

–

Info—Notification about a condition that could lead to an impending problem or notification of
an event that improves operation.

The syntax values are: critical(1), major(2), minor(3), info(4)

identifies an event relative to a physical entity in the Cisco 7600 router. Values 0 through 255.

ceAlarmDescr
Severity ceAlarmDescrText

cevPortT3
cevPortE3
cevPortDsE3Atm

major Transmitter is sending remote

alarm

major Transmitter is sending AIS

major Receiver has loss of signal

major Receiver is receiving AIS

major Receiver has loss of frame

major Receiver has remote alarm

major Receiver has idle signal

major Other failure

major Physical port link down

info Physical port administrative

state down

3-70

Table 3-11 lists the alarm descriptions and severity levels for the Cisco 7600 router ATM and packet over

SONET ports.

Table 3-11 Alarms Supported for Cisco 7600 Router ATM and POS Ports

Physical Entity ceAlarmDescrVendorType

ATM and POS ports cevPortATM

cevPortPOS
cevPortChSonet

Cisco 7600 Series Router MIB Specifications Guide

ceAlarmDescr
Severity ceAlarmDescrText

critical Section loss of signal failure

critical Section loss of frame failure

critical Section out of frame alignment

minor J0 trace byte mismatch

minor Section bit interleaved parity

major Line alarm indication signal

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-11 Alarms Supported for Cisco 7600 Router ATM and POS Ports (continued)

Physical Entity ceAlarmDescrVendorType

CISCO-ENTITY-ALARM-MIB

ceAlarmDescr
Severity ceAlarmDescrText

major Line remote failure indication

minor Line bit interleaved parity

minor Line far end block errors

critical Path alarm indication signal

critical Path remote failure indication

critical Path loss of pointer

minor Path bit interleaved parity

minor Path far end block errors

minor Protection switching byte

failure

minor Path pointer justifications

minor Path positive pointer stuff event

minor Path negative pointer stuff

event

major Path payload label mismatch

major Path unequipped payload label

zero

minor Path trace identifier mismatch

minor Path trace identifier unstable

minor Count of number of times APS

bytes changed

minor Receiver data out of lock

critical Signal failure alarm

critical Signal degrade alarm

minor Signal failure alarm and B3

errors

minor Signal degrade alarm and B3

errors

critical Threshold cross alarm–B1

critical Threshold cross alarm–B2

critical Threshold cross alarm–B3

critical Loss of multiframe

OL-4077-07

Table 3-12 lists the alarm descriptions and severity levels for the Cisco 7600 router serial port adapters.

Cisco 7600 Series Router MIB Specifications Guide

3-71

CISCO-ENTITY-ALARM-MIB

Table 3-12 Alarms Supported for Cisco 7600 Router Serial Port Adapters

Physical Entity ceAlarmDescrVendorType

Serial port adapter
ports

Table 3-13 lists the alarm descriptions and severity levels for the Cisco 7600 router FlexWAN PA T1 and

E1 ports.

Table 3-13 Alarms Supported for Cisco 7600 Router FlexWAN PA T1/E1 Port Adapter Ports

Physical Entity ceAlarmDescrVendorType

FlexWAN PA T1
and E1 ports

cevPortHSSI
cevPortCBusSerial

cevPortT1
cevPortE1

Chapter 3 Cisco 7600 MIB Specifications

ceAlarmDescr
Severity ceAlarmDescrText

minor Physical port link down

Info Physical port administrative

state down

ceAlarmDescr
Severity ceAlarmDescrText

minor Transmitter is sending remote

alarm

minor Transmitter is sending AIS

minor Transmitter is sending TS16

LOMF alarm

minor Receiver has loss of multiframe in

TS16

minor Receiver has loss of signal

minor Receiver is receiving AIS

minor Receiver has loss of frame

minor Receiver has remote alarm

minor Receiver is getting AIS in TS16

minor Receiver has remote TS16 LOMF

alarm

minor Other failure

minor Physical port link down

info Physical port administrative state

down

3-72

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-14 lists the alarm descriptions and severity levels for the Cisco 7600 router FlexWAN

T1/E1 IMA ports.

Table 3-14 Alarms Supported for Cisco 7600 Router FlexWAN T1/E1 IMA Ports

Physical Entity ceAlarmDescrVendorType

FlexWAN T1/E1
IMA ports

cevPortT1ImaLink
cevPortE1ImaLink

CISCO-ENTITY-ASSET-MIB

ceAlarmDescr
Severity ceAlarmDescrText

minor Transmitter is sending remote

alarm

minor Transmitter is sending AIS

minor Receiver has loss of signal

minor Receiver is receiving AIS

minor Receiver has loss of frame

minor Receiver has remote alarm

minor Other failure

minor Physical port link down

info Physical port administrative

state down

CISCO-ENTITY-ASSET-MIB

The CISCO-ENTITY-ASSET-MIB provides asset tracking information for the physical components in
the ENTITY-MIB (RFC2737) entPhysicalTable.

The ceAssetTable contains an entry (ceAssetEntry) for each physical component on the router. Each
entry provides information about the component, such as its orderable part number, serial number,
hardware revision, manufacturing assembly number, and manufacturing revision.

Most physical components are programmed with a standard Cisco generic ID PROM value that specifies
asset information for the component. If possible, the MIB accesses the component’s ID PROM
information.

MIB Constraints

Table 3-15 lists the constraints that the Cisco 7600 Series router places on objects in the

CISCO-ENTITY-ASSET-MIB.

Table 3-15 CISCO-ENTITY-ASSET-MIB Object Constraints

MIB Object Notes

ceAssetTable

ceAssetOrderablePartNumber Not implemented

ceAssetSerialNumber Not implemented

ceAssetHardwareRevision Not implemented

ceAssetFirmwareRevision Not implemented

ceAssetsSoftwareRevision Not implemented

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-73

CISCO-ENTITY-EXT-MIB

MIB Object Notes

ceAssetAlias Not implemented

ceAssetTag Not implemented

ceAssetIsFRU Not implemented

CISCO-ENTITY-EXT-MIB

The CISCO-ENTITY-EXT-MIB contains extensions for the processor modules listed in the
ENTITY-MIB entPhysicalTable. A processor module is any physical entity that has a CPU, RAM, and
NVRAM, and can load a boot image and save a configuration. The extensions in this MIB provide
information such as RAM and NVRAM sizes, configuration register settings, and bootload image name
for each processor module.

CISCO-ENTITY-FRU-CONTROL-MIB

Chapter 3 Cisco 7600 MIB Specifications

The CISCO-ENTITY-FRU-CONTROL-MIB contains objects to configure and monitor the status of
field replaceable units (FRUs) on the Cisco 7600 Series router listed in the ENTITY-MIB
entPhysicalTable. An FRU is a hardware component (such as a line card and module, fan, or power
supply) that can be replaced on site. This MIB is applicable to SIP and SPA modules for this release.

MIB Constraints

Table 3-16 lists the constraints that the router places on objects in the

CISCO-ENTITY-FRU-CONTROL-MIB.

Table 3-16 CISCO-ENTITY-FRU-CONTROL-MIB Constraints

MIB Object Notes

cefcModuleTable

•

• cefcModuleOperStatus unknown(1)

• cefcModuleResetReason unknown(1)

• cefcModuleLastClearConfigTime Not implemented.

• cefcModuleResetReasonDescription Not implemented.

• cefcModuleStateChangeReasonDescr Not implemented.

• cefcModuleUpTime Not implemented.

cefcModuleTable
cefcFRUPowerStatusTable

cefcModuleAdminStatus enabled(1) for read and write.

reset(3) for write only.

ok(2)
failed(7)

powerUp(2)
manualReset(5)

3-74

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

CISCO-ENTITY-SENSOR-MIB

The CISCO-ENTITY-SENSOR-MIB contains objects that support the monitoring of sensors. The MIB
is applicable to sensors present in various modules and to the sensors present in the DWDM GBICs and
XENPAK transceivers. This MIB allows you to monitor sensor values and thresholds on sensors that are
discovered by the ENTITY-MIB.

MIB Constraints

Table 3-17 lists CISCO-ENTITY-SENSOR-MIB constraints. For detailed definitions of MIB objects,

see the MIB.

Table 3-17 CISCO-ENTITY-SENSOR-MIB Constraints

MIB Object Notes

entSensorThresholdTable

entSensorThresholdRelation Read-only.

•

• entSensorThresholdSeverity Read-only.

• entSensorThresholdValue Read-only.

CISCO-ENTITY-SENSOR-MIB

MIB Usage Values for Cisco Transceivers

The tables in this section lists each type of sensor’s value represented in the entSensorValueTable and
the entSensorThresholdTable.

Table 3-18 lists CISCO-ENTITY-SENSOR-MIB sensor objects and their usage values for Cisco 7600

transceivers in the entSensorValueTable.

Table 3-18 CISCO-ENTITY-SENSOR-MIB Usage Values in the entSensorValueTable for Cisco

Transceivers

MIB Sensor Object Notes

Module Temperature Sensor

entSensorType celsius(8)

•

• entSensorScale units(9)

• entSensorPrecision 1

• entSensorStatus ok(1)

• entSensorValue Reports most recent measurement seen by the sensor.

• entSensorValueTimeStamp Value indicates the age of the value reported by

• entSensorValueUpdateRate Value indicates the rate that the agent updates

Module Voltage Sensor

entSensorValue object.

entSensorValue (in seconds). For example, 60 seconds.

OL-4077-07

entSensorType volts(DC)4

•

• entSensorScale units(9)

Cisco 7600 Series Router MIB Specifications Guide

3-75

CISCO-ENTITY-SENSOR-MIB

Table 3-18 CISCO-ENTITY-SENSOR-MIB Usage Values in the entSensorValueTable for Cisco

MIB Sensor Object Notes

• entSensorPrecision 1

• entSensorStatus ok(1)

• entSensorValue Reports most recent measurement seen by the sensor.

• entSensorValueTimeStamp Value indicates the age of the value reported by

• entSensorValueUpdateRate Value indicates the rate that the agent updates

Tx Laser Current Sensor

•

• entSensorScale milli(8)

• entSensorPrecision 1

• entSensorStatus ok(1)

• entSensorValue Reports most recent measurement seen by the sensor.

• entSensorValueTimeStamp Value indicates the age of the value reported by

• entSensorValueUpdateRate Value indicates the rate that the agent updates

Transmit Power Sensor (Optical Tx)

Receive Power Sensor (Optical Rx)

•

• entSensorScale units(9)

• entSensorPrecision 1

• entSensorStatus ok(1)

• entSensorValue Reports most recent measurement seen by the sensor.

• entSensorValueTimeStamp Value indicates the age of the value reported by

• entSensorValueUpdateRate Value indicates the rate that the agent updates

Chapter 3 Cisco 7600 MIB Specifications

Transceivers (continued)

entSensorValue object.

entSensorValue in seconds.

entSensorType amperes(5)

entSensorValue object.

entSensorValue (in seconds). For example, 60 seconds.

entSensorType dBm(14)

entSensorValue object.

entSensorValue (in seconds). For example, 60 seconds.

3-76

Each Cisco transceiver sensor has 4 threshold values corresponding to the four alarm states listed in

Table 3-19 and Ta ble 3- 20. The entSensorValueTable is indexed by both entPhysicalIndex and

entSensorThresholdIndex. Cisco 7600 entSensorThresholdIndices range from 1 to 4. For N/A (not
applicable), a value of zero is returned.

Table 3-19 lists the default values for the Cisco GBIC transceivers in the entSensorThresholdTable.

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-19 Default Values in the entSensorThreshold Table for DWDM GBIC Transceivers

MIB Sensor Object High Alarm High Warning Low Warning Low Alarm

Temperature 70.0 60.0 5.0 0.0

Voltage 5.5 5.2 4.7 4.5

Tx Bias Current 60.0 40.0 10.0 5.0

Tx Optical Power 3.4 3.2 -0.3 -0.5

Rx Optical Power 5.9 -6.7 -28.5 -28.5

Table 3-20 lists the default values for the Cisco XENPAK transceivers in the entSensorThresholdTable.

Table 3-20 Default Values in the entSensorThreshold Table for XENPAK Transceivers

MIB Sensor Object High Alarm High Warning Low Warning Low Alarm

Temperature 70.0 60.0 5.00.0 0.0

Voltage Not applicable. Not applicable. Not applicable. Not applicable.

Tx Bias Current 80.0 75.0 15.0 10.0

Tx Optical Power 2.0 0.9 -4.0 -9.7

Rx Optical Power 2.0 0.4 -11.9 -15.0

CISCO-ENTITY-VENDORTYPE-OID-MIB

CISCO-ENTITY-VENDORTYPE-OID-MIB

The CISCO-ENTITY-VENDORTYPE-OID-MIB defines the object identifiers (OIDs) assigned to
various Cisco 7600 Series router components. The OIDs in this MIB are used by the entPhysicalTable
of the ENTITY-MIB as values for the entPhysicalVendorType field in the entPhysicalTable. Each OID
uniquely identifies a type of physical entity, such as a chassis, Optical Services Module, FlexWAN card,
SPAs, and SIPs.

CISCO-ENVMON-MIB

The CISCO-ENVMON-MIB contains information about the status of environmental sensors (for
voltage, temperature, and power supplies). It also contains MIB objects to enable and disable
notifications for changes to the status of these sensors.

Note The CISCO-ENVMON-MIB is not supported by the shared port adapters (SPAs).

MIB Constraints

Table 3-21 lists the constraints that the Cisco 7600 Series router places on objects in the

CISCO-ENVMON-MIB.

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-77

CISCO-ERM-MIB

Chapter 3 Cisco 7600 MIB Specifications

F

Table 3-21 CISCO-ENVMON-MIB Constraints

MIB Object Notes

ciscoEnvMonVoltageStatusTable

ciscoEnvMonVoltageStatusDescr Not implemented.

•

• ciscoEnvMonVoltageStatusValue Not implemented.

• ciscoEnvMonVoltageThresholdLow Not implemented.

• ciscoEnvMonVoltageThresholdHigh Not implemented.

• ciscoEnvMonVoltageLastShutdown Not implemented.

• ciscoEnvMonVoltageState Not implemented.

• ciscoEnvMonEnableVoltageNotification Not implemented.

CISCO-ENVMON-MIB Usage

The command show environment can be used to check environmental status through the CLI. The
objects defined in ciscoEnvMonMIBNotificationEnables can be set to true using CLI command
snmp-server enable traps environment.

CISCO-ERM-MIB

The CISCO-ERM-MIB is for the Embedded Resource Manager (ERM framework which helps in
effectively managing resources such as cpu, memory, buffers, etc).

CISCO-ETHER-CFM-MIB

The CISCO-ETHER-CFM-MIB defines the managed objects and notifications for Ethernet Connectivity
Fault Management (CFM). CFM is an end-to-end per service instance Ethernet layer Operations,
Administration and Management (OAM) protocol.

CISCO-FLASH-MIB

The CISCO-FLASH-MIB contains objects to manage flash cards and flash-card operations.

CISCO-FLEX-LINKS-MIB

The CISCO-FLEX-LINKS-MIB is for configuration and status query of Flex Links feature on the Cisco
device.

Flex Links are a pair of a Layer 2 interfaces, where one interface is configured to act as a backup to the
other. The feature provides an alternative solution to the Spanning Tree Protocol (STP), allowing users
to turn off STP and still provide basic link redundancy.

3-78

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Flex Links are typically configured in service provider or enterprise networks where users do not want
to run STP on the device.

CISCO-FRAME-RELAY-MIB

The CISCO-FRAME-RELAY-MIB contains Frame Relay information that is specific to Cisco products
or that is missing from RFC 1315.

MIB Constraints

Table 3-22 lists the constraints that the Cisco 7600 Series router places on objects in the

CISCO-FRAME-RELAY-MIB. Unless noted otherwise, the Cisco 7600 implementation of a MIB
follows the standard. Any objects not listed in a table are implemented as defined in the MIB.

Note Frame relay SVCs are not currently supported in Cisco 7600.

CISCO-FRAME-RELAY-MIB

Table 3-22 CISCO-FRAME-RELAY-MIB Constraints

MIB Object Notes

cfrCircuitTable

cfrCircuitType Supported value is pvc(1).

•

cfrExtCircuitTable

cfrExtCircuitMinThroughputOut Supported for QoS. Otherwise value is 0.

•

• cfrExtCircuitMinThroughputIn Supported for QoS. Otherwise value is 0.

• cfrExtCircuitShapeByteLimit Supported for QoS. Otherwise value is 0.

• cfrExtCircuithapeInterval Supported for QoS. Otherwise value is 0.

• cfrExtCircuitShapeByteIncrement Supported for QoS. Otherwise value is 0.

• cfrExtCircuitShapeActive Supported for QoS. Otherwise value is 0.

• cfrExtCircuitShapeAdapting Supported for QoS. Otherwise value is 0.

cfrMapTable

cfrMapType Values are:

•

• static(1)

• dynamic(2)

cfrSvcTable

Not implemented.

CISCO-FRAS-HOST-MIB

The CISCO-FRAS-HOST-MIB contains objects specific to upstream or host-end sessions.

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-79

CISCO-FTP-CLIENT-MIB

CISCO-FTP-CLIENT-MIB

The CISCO-FTP-CLIENT-MIB contains objects to invoke File Transfer Protocol (FTP) operations for
network management. This MIB has no known constraints and all objects are implemented as defined in
the MIB.

CISCO-HSRP-EXT-MIB

The CISCO-HSRP-EXT-MIB provides an extension to the CISCO-HSRP-MIB which defines the Cisco
Hot Standby Router Protocol (HSRP), which is defined in RFC 2281. The extensions cover assigning of
secondary IP addresses and modifying an HSRP group’s priority.

CISCO-HSRP-MIB

The CISCO-HSRP-MIB contains objects to configure and manage the Cisco Hot Standby Router
Protocol (HSRP), which is defined in RFC 2281.

Chapter 3 Cisco 7600 MIB Specifications

CISCO-IETF-ATM2-PVCTRAP-MIB-EXTN

The CISCO-IETF-ATM2-PVCTRAP-MIB-EXTN MIB supplements the
CISCO-IETF-ATM2-PVCTRAP-MIB.

CISCO-IETF-ATM2-PVCTRAP-MIB

The CISCO-IETF-ATM2-PVCTRAP-MIB supplements the ATM-MIB. It implements the virtual
channel link (VCL) section of the IETF document “draft-ietf-atommib-atm2-11.txt,” Section 9 ATM
Related Trap Support.

CISCO-IETF-DHCP-SERVER-EXT-MIB

The CISCO-IETF-DHCP-SERVER-EXT-MIB is an extension of the
CISCO-IETF-DHCP-SERVER-MIB.

CISCO-IETF-DHCP-SERVER-MIB

The CISCO-IETF-DHCP-SERVER-MIB contains objects for the entities implementing the server side
of the Bootstrap Protocol (BOOTP) and the Dynamic Host Configuration protocol (DHCP) for Internet
Protocol version 4(IPv4). This MIB does not include support for updating Dynamic DNS (DDNS) and
DHCP Failover Protocol.

3-80

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

CISCO-IETF-FRR-MIB

The CISCO-IETF-FRR-MIB contains managed object definitions for MPLS Fast Reroute (FRR).

CISCO-IETF-IP-MIB

The CISCO-IETF-IP-MIB contains objects to manage the Internet Protocol (IPv6), but not IP routes. The
MIB also contains objects to manage the Internet Control Message Protocol (ICMP). It is based on the
IETF document draft-ietf-ipngwg-rfc2011-update-00.txt and supports read-only.

Note This MIB only supports IPv6 interfaces.

Table 3-23 lists constraints that the Cisco 7600 Series router places on objects in the

CISCO-IETF-IP-MIB.

Table 3-23 CISCO-IETF-IP-MIB Constraints

CISCO-IETF-FRR-MIB

MIB Object Notes

• cIpv6Forwarding Read-only.

• cIpv6DefaultHopLimit Read-only.

cIpv6InterfaceTable

cIpv6InterfaceIdentifier Read-only.

•

• cIpv6InterfaceIdentifierLength Read-only.

cIpAddressPfxTable

cIpAddressPfxOrigin Read-only.

•

Va lu e s:

• other(1)

• manual(2)

cIpAddressTable

cIpAddressOrigin Read-only.

•

Va lu e s:

• other(1)

• manual(2)

• wellknown(3)

• cIpAddressStatus Read-only. Value is depracated(2). No longer

supported

cInetNetToMediaTable

OL-4077-07

cInetNetToMediaPhysAddress Read-only.

•

Cisco 7600 Series Router MIB Specifications Guide

3-81

CISCO-IETF-ISIS-MIB

Table 3-23 CISCO-IETF-IP-MIB Constraints (continued)

MIB Object Notes

• cInetNetToMediaType Read-only.

• cInetNetToMediaState Read-only. Value is invalid(5). Not supported.

cInetIcmpTable

cInetIcmpOutErrors Not Implemented.

•

CISCO-IETF-ISIS-MIB

The CISCO-IETF-ISIS-MIB contains objects to manage IS-IS Routing protocol described in ISO 10589.
IS-IS Routing protocol is used to construct routing tables for IP networks, as described in RFC 1195.

Chapter 3 Cisco 7600 MIB Specifications

Va lu e s:

• other(1)

• dynamic(3)

• static(4)

CISCO-IETF-IP-FORWARD-MIB

The CISCO-IETF-IP-FORWARD-MIB contains objects to manage multipath IP (IPv6) routes in a
classless interdomain routing (CIDR) environment. This MIB is based on the IETF document
draft-ietf-ipngwg-rfc2096-update-00.txt and supports read-only.

CISCO-IETF-PPVPN-MPLS-VPN-MIB

The CISCO-IETF-PPVPN-MPLS-VPN-MIB is an extension of the MPLS-VPN-MIB. It contains a new
notification, mplsNumVrfRouteMaxThreshCleared, which was added with
MPLS-VPN-MIB-DRAFT-05.

CISCO-IETF-PW-ATM-MIB

The CISCO-IETF-PW-ATM-MIB contains managed object definitions for Pseudo Wire emulation of
ATM over Packet Switched Networks(PSN).

CISCO-IETF-PW-ENET-MIB

The CISCO-IETF-PW-ENET-MIB describes a model for managing Ethernet point-to-point pseudo wire
services over a Packet Switched Network (PSN).

3-82

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

CISCO-IETF-PW-FR-MIB

The CISCO-IETF-PW-FR-MIB describes network management objects defined for FRoPW services
over a Packet Switched Network (PSN).

CISCO-IETF-PW-MIB

The CISCO-IETF-PW-MIB contains managed object definitions for Pseudo Wire operation.

CISCO-IETF-PW-MPLS-MIB

The CISCO-IETF-PW-MPLS-MIB complements the CISCO-IETF-PW-MIB for PW operation over
MPLS.

CISCO-IETF-PW-FR-MIB

CISCO-IETF-PW-TC-MIB

The CISCO-IETF-PW-TC-MIB provides Textual Conventions and OBJECT-IDENTITY Objects to be
used PW services.

CISCO-IETF-PW-TDM-MIB

The CISCO-IETF-PW-TDM-MIB contains managed object definitions for encapsulating TDM (T1,E1,
T3, E3, NxDS0) as pseudo-wires over packet-switching networks (PSN)

CISCO-IF-EXTENSION-MIB

The CISCO-IF-EXTENSION-MIB contains objects that provide additional interface-related
information that is not available in the IF-MIB (RFC 2863).

Table 3-24 lists constraints for Cisco 7600 WAN interfaces.

Table 3-24 CISCO-IF-EXTENSION-MIB Constraints

MIB Object Notes

cielInterfaceTable

•

cieIfDhcpMode Not implemented.

• cieIfMtu Not implemented.

• cieIfContextName Not implemented.

• cieIfKeepAliveEnabled Not supported for ATM interfaces.

cieSystemMtu

cieIfUtilTable

cieIfDot1dBaseMappingTable

Not implemented.

Not implemented.

Not implemented.

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-83

CISCO-IMAGE-MIB

Table 3-24 CISCO-IF-EXTENSION-MIB Constraints (continued)

MIB Object Notes

cieIfDot1qCustomerEtherTypeTable

cieIfNameMappingTable

1 Some objects defined in cieIfPacketStatsTable and cieIfInterfaceTable are applicable to physical interfaces

only. As a result, this table may be sparse for non-physical interfaces.

2 ATM interfaces do not support the cieIfKeepAliveEnabled object.

CISCO-IMAGE-MIB

The CISCO-IMAGE-MIB contains objects which identify the capabilities and characteristics of the
Cisco IOS image.

CISCO-IMAGE-TC-MIB

Chapter 3 Cisco 7600 MIB Specifications

Not implemented.

Not implemented.

The CISCO-IMAGE-TC-MIB defines the textual conventions used in the enhanced image MIB.''

CISCO-IP-STAT-MIB

The CISCO-IP-STAT-MIB contains objects to manage the collection and display of IP statistics,
categorized by IP precedence and the Media Access Control (MAC) address associated with IP packets.
To use the MIB to access additional IP statistics, you can issue the ip accounting mac-address and
ip accounting precedence commands at the CLI.CISCO-IPMROUTE-MIB

The CISCO-IPMROUTE-MIB contains objects to manage IP multicast routing on the router.

CISCO-IPSEC-FLOW-MONITOR-MIB

The CISCO-IPSEC-FLOW-MONITOR-MIB allows monitoring of the structures in IPSec-based Virtual
Private Networks.

CISCO-IP-TAP-MIB

The CISCO-IP-TAP-MIB manages Cisco's intercept feature for IP. This MIB is used along with
CISCO-TAP2-MIB to intercept IP traffic.

CISCO-IP-URPF-MIB

The CISCO-IP-URPF-MIB contains objects to manage Unicast Reverse Path Forwarding (URPF).
URPF validates the source address of IP packets received on an interface to prevent Denial of Service
attacks based on IP address spoofing.

Cisco 7600 Series Router MIB Specifications Guide

3-84

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

CISCO-IPSEC-MIB

The CISCO-IPSEC-MIB models the Cisco implementation-specific attributes of a Cisco entity that
implements IPsec.

CISCO-IPSLA-ETHERNET-MIB

The CISCO-IPSLA-ETHERNET-MIB contains objects to manage IP SLA Auto-Ethernet-CFM
operations and EthernetJitter statistics. IP SLA is a capability which utilizes active monitoring for
network performance. It can be used for network troubleshooting, network assessment, and health
monitoring. EthernetJitter is used to measure metrics such as RTT, Jitter, frame loss, and one-way
latency by sending multiple enhanced CFM frames at specified interval to a particular MEP.

CISCO-L2-CONTROL-MIB

The CISCO-L2-CONTROL-MIB contains objects that provide a n control feature for devices with
Layer 2 functions such as the VLAN MAC limit control. The MIB controls the number of MAC address
entries for each VLAN so that the forwarding table is not depleted.

CISCO-IPSEC-MIB

CISCO-L2-TUNNEL-CONFIG-MIB

The CISCO-L2-TUNNEL-CONFIG-MIB contains objects to configure and manage Layer 2 tunnels on
the router. Tunneling allows separate local networks to appear as a single virtual LAN (VLAN). The
networks are connected through an ISP, which tunnels the packets from one network to another, making
it appear as if both networks are a single network.

CISCO-L2L3-INTERFACE-CONFIG-MIB

The CISCO-L2L3-INTERFACE-CONFIG-MIB contains objects to configure the operation mode of
router interfaces and to monitor their status. You can configure a router interface to operate in routed(1)
or switchport(2) mode:

• Routed(1) mode—Layer 3 protocols are used to direct traffic across the interface.

• Switchport(2) mode—Layer 2 protocols are used to direct traffic across the interface. This mode can

be configured manually, or negotiated by the dynamic trunking protocol (DTP) or the dynamic
interswitch link (DISL) protocol. The interface can be configured to operate in access mode, trunk
mode, or multimode.

CISCO-LAG-MIB

The CISCO-LAG-MIB contains objects to manage link aggregation (LAG) on the router, as defined by
IEEE Standard 802.3ad. The MIB contains link aggregation information that is not included in the
IEEE8023-LAG-MIB or that is specific to Cisco products.

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-85

CISCO-MAC-NOTIFICATION-MIB

CISCO-MAC-NOTIFICATION-MIB

The CISCO-MAC-NOTIFICATION-MIB is for configuration of the MAC notification feature. MAC
notification is a mechanism to inform monitoring devices when there are MAC addresses learnt or
removed from the forwarding database of the monitored devices.

CISCO-MEMORY-POOL-MIB

The CISCO-MEMORY-POOL-MIB contains objects that represents the different types of memory pools
that may be present in a managed device. Memory pools are categorized into two groups:

• Predefined pools

• Dynamic pools

CISCO-MVPN-MIB

Chapter 3 Cisco 7600 MIB Specifications

The CISCO-MVPN-MIB contains managed object definitions for Cisco implementation of multicast in
VPNs defined by the Internet draft: draft-rosen-vpn-mcast-05.txt.

CISCO-NAC-NAD-MIB

The CISCO-NAC-NAD-MIB is for the configuration of a Network Access Device (NAD) on the Cisco
Network Admission Control (NAC) system.

CISCO-NDE-MIB

The CISCO-NDE-MIB contains objects to configure and monitor the operation of the NetFlow Data
Export (NDE) feature. A network flow is a unidirectional sequence of packets between a pair of source
and destination endpoints, which are identified by IP address and transport layer application port
number. NetFlow uses the IP protocol type, type of service (ToS), and input interface identifier to
uniquely identify network flows.

CISCO-NETFLOW-MIB

The CISCO-NETFLOW-MIB provides a simple and easy method to get NetFlow cache information,
current NetFlow configuration and statistics.

3-86

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

CISCO-NTP-MIB

The CISCO-NTP-MIB contains objects to monitor a Network Time Protocol (NTP) server. NTP is used
to synchronize timekeeping among a set of distributed time servers and clients. Primary time servers,
which are synchronized to national time standards, are connected to widely accessible resources such as
backbone gateways. These primary servers send timekeeping information to other time servers, and
perform clock checking to eliminate timekeeping errors due to equipment or propagation failures.

CISCO-OSPF-MIB

The CISCO-OSPF-MIB contains objects for managing OSPF implementation. Most of the MIB
definitions are based on the IETF draft < draft-ietf-ospf-mib-update-05.txt > and includes support for
OSPF Sham link. The CISCO-OSPF-MIB is an extension to the OSPF-MIB defined in RFC 1850.

CISCO-OSPF-TRAP-MIB

CISCO-NTP-MIB

The CISCO-OSPF-TRAP-MIB contains new and modified notification objects and events, which are
defined in the latest version for OSPF MIB IETF draft draftietf-ospf-mib-update-05.txt in addition to
support for OSPF Sham link.

CISCO-PAE-MIB

The CISCO-PAE-MIB contains objects to manage port access entities (PAEs) on the router, as defined
by IEEE Std 802.1x. The MIB contains PAE information that is not included in the IEEE8021-PAE-MIB
or that is specific to Cisco products.

CISCO-PAGP-MIB

The CISCO-PAGP-MIB contains objects to configure and manage Fast Etherchannel and the Port
Aggregation Protocol (PAgP) on the router. These features allow two or more physical interfaces to be
aggregated together to form a single agport that behaves like a single interface, but that has improved
bandwidth and availability over each of the physical interfaces.

Note You can also monitor interfaces, agports, and related statistics through the ifStackTable and the ifTable

(IF-MIB).

CISCO-PIM-MIB

The CISCO-PIM-MIB defines Cisco specific objects and variables for managing Protocol Independent
Multicast (PIM) on the router. These MIB definitions are an extension of those in RFC 2934, which is
the IETF PIM MIB.

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-87

CISCO-PING-MIB

CISCO-PING-MIB

The CISCO-PING-MIB contains objects to manage ping requests on the router.

CISCO-POLICY-GROUP-MIB

The CISCO-POLICY-GROUP-MIB is used for configuration of policy and policy group. A policy group
can be described as a set of entities identified by IP addresses or other means. Members of a policy group
will be subjected to the same policy.

CISCO-PORT-SECURITY-MIB

The CISCO-PORT-SECURITY-MIB is used for managing Cisco Port Security

Chapter 3 Cisco 7600 MIB Specifications

CISCO-PPPOE-MIB

The CISCO-PRIVATE-VLAN-MIB contains objects to manage Cisco PPPoE sessions.

CISCO-PRIVATE-VLAN-MIB

The CISCO-PRIVATE-VLAN-MIB contains objects to manage the private virtual LAN (VLAN) feature
on the router.

CISCO-PROCESS-MIB

The CISCO-PROCESS-MIB displays memory and CPU usage on the router and describes active system
processes. CPU utilization presents a status of how busy the system is. The numbers are a ratio of the
current idle time over the longest idle time (this information should be used as an estimate only).

MIB Constraints

Table 3-25 lists the constraints that the Cisco 7600 Series router places on objects in the

CISCO-PROCESS-MIB.

3-88

Table 3-25 CISCO-PROCESS-MIB Constraints

MIB Object Notes

cpmProcessTable

cpmProcExtPriority Read-only.

•

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

CISCO-PROCESS-MIB Usage

The CISCO-PROCESS-MIB supports the 7600 WAN Cards (FlexWANs, OSM, SIPs) cards. These cards
have one or two CPUs. The CISCO-PROCESS-MIB contains information for each CPU present.

The cpmCPUTotal5sec, cpmCPUTotal1min, and cpmCPUTotal5min objects have been deprecated and
replaced by cpmCPUTotal5secRev, cpmCPUTotal1minRev, and cpmCPUTotal5minRev respectively.

Note When an object is deprecated it does not mean that an object instance may not be returned. For these

deprecated objects, object instances are returned. However, their returned values must be ignored. The
values returned by the new objects must be used.

CISCO-PRODUCTS-MIB

The CISCO-PRODUCTS-MIB lists the object identifiers (OIDs) assigned to Cisco hardware platforms.
The following OIDs are supported:

• cisco7603 (1.3.6.1.4.1.9.1.401)

CISCO-PRODUCTS-MIB

• cisco7606 (1.3.6.1.4.1.9.1.402)

• cisco7609 (1.3.6.1.4.1.9.1.509)

• cisco7613 (1.3.6.1.4.1.9.1.528)

• cisco7604 (1.3.6.1.4.1.9.1.658)

• cisco7609s (1.3.6.1.4.1.9.1.835)

• cisco7603s (1.3.6.1.4.1.9.1.862)

• cisco7606s (1.3.6.1.4.1.9.1.863)

This MIB is included in the Cisco 7600 executable image, but its support is unverified.

CISCO-QINQ-VLAN-MIB

The CISCO-QINQ-VLAN-MIB describes configuration and monitoring capabilities relating to

802.1QinQ interfaces.

MIB Constraints

Table 3-26 lists the constraints that the Cisco 7600 Series router places on objects in the

CISCO-QINQ-VLAN-MIB.

OL-4077-07

Table 3-26 CISCO-QINQ-VLAN-MIB Constraints

MIB Object Notes

cqvTerminationTable

Not implemented. Cisco7600 does not
support QinQ Termination feature.

cqvTranslationTable

Cisco 7600 Series Router MIB Specifications Guide

3-89

CISCO-QLLC01-MIB

Table 3-26 CISCO-QINQ-VLAN-MIB Constraints (continued)

MIB Object Notes

• cqvTranslationTrunkPeVlanId Read-only.

• cqvTranslationTrunkCeVlanId Read-only.

• cqvTranslationType Read-only.

• cqvTranslationCosPBits Read-only.

• cqvTranslationRowStatus Read-only.

CISCO-QLLC01-MIB

The CISCO-QLLC01-MIB contains objects to configure and monitor logical connections for the
Qualified Logical Link Control (QLLC) protocol.

CISCO-QUEUE-MIB

Chapter 3 Cisco 7600 MIB Specifications

The CISCO-QUEUE-MIB contains objects to manage interface queues, which can be used for FIFO,
priority, custom, and fair queuing.

CISCO-RESILIENT-ETHERNET-PROTOCOL-MIB

The CISCO-RESILIENT-ETHERNET-PROTOCOL-MIB defines objects required for managing
Resilient Ethernet Protocol (REP). Resilient Ethernet Protocol (REP) is a Cisco proprietary protocol that
provides an alternative to Spanning Tree Protocol (STP). REP provides functionality to control network
loops, handle link failures, and improve convergence time.

CISCO-RF-MIB

The CISCO-RF-MIB provides configuration control and status for the Redundancy Framework (RF)
subsystem. RF provides a mechanism for logical redundancy of software functionality and is designed
to support 1:1 redundancy on processor cards (supervisor engines). Redundancy duplicates data
elements and software functions to provide an alternative in case of failure.

Note For information about the levels of redundancy and how to verify that the redundancy feature is available

on Cisco 7600 routers, see Appendix A, “Cisco Redundancy Features.”

MIB Constraints

Table 3-27 lists the constraints that the Cisco 7600 Series router places on objects in the

CISCO-RF-MIB.

Cisco 7600 Series Router MIB Specifications Guide

3-90

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-27 CISCO-RF-MIB Constraints

MIB Object Notes

cRFCfgGroup

cRFCfgSplitMode Object is deprecated.

•

• cRFCfgRedundancyMode Values: 6, 7, and 8.

• cRFCfgMaintenanceMode Read-only. Supported value is false(2).

cRFHistoryGroup

cRFHistory There are three switchover modes:

•

CISCO-RMON-CONFIG-MIB

CISCO-RMON-CONFIG-MIB

coldstandby, warmstandby, and hoststandby.
The only entries saved are those generated
from a hotstandby switchover.

The CISCO-RMON-CONFIG-MIB contains Cisco RMON configuration span extensions for the
standard IETF remote monitoring (RMON) MIBs.

CISCO-RSRB-MIB

The CISCO-RSRB-MIB contains objects used to manage remote source-route bridging (RSRB) on the
router. This MIB provides information about the attributes of the local-remote RSRB peer relationship.

CISCO-RTTMON-MIB

The CISCO-RTTMON-MIB contains objects to monitor network performance. The MIB provides
information about the response times of network resources and applications. Each conceptual round-trip
time (RTT) control row in the MIB represents a single probe, which is used to determine an entity’s
response time. The probe defines an RTT operation to perform (for example, an FTP or HTTP get
request), and the results indicate whether the operation succeeded or failed, and how long it took to
complete.

If you plan to schedule an RTT operation, see Ta ble 3- 28 for information about
rttMonScheduleAdminRttStartTime in the rttMonScheduleAdminTable.

Note An rttMonCtrlOperConnectionLostOccurred trap is generated when an RTT connection cannot be

established to the destination router because the router responder application is not running. However,
the trap is not generated if the physical connection to the router is lost.

MIB Constraints

Table 3-28 lists the constraints that the Cisco 7600 Series router places on objects in the

CISCO-RTTMON-MIB. For detailed definitions of MIB objects, see the MIB.

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-91

CISCO-RTTMON-IP-EXT-MIB

Table 3-28 CISCO-RTTMON-MIB Constraints

MIB Object Notes

RttMonProtocol Not supported:

rttMonApplAuthTable

rttMonCtrlAdminTable

• rttMonCtrlAdminRttType Supported values:

rttMonEchoAdminTable

Chapter 3 Cisco 7600 MIB Specifications

snaRUEcho
snaLU0EchoAppl

Not supported.

echo(1)
pathEcho(2)
udpEcho(5)
tcpConnect(6)
http(7)
dns(8)
jitter(9)
ftp(12)

All other values not supported.

rttMonEchoAdminProtocol Supported values:

•

rttMonScheduleAdminTable

rttMonScheduleAdminRttStartTime Before setting this object to a date/time value,

•

rttMonHistoryCollectionTable

CISCO-RTTMON-IP-EXT-MIB

The CISCO-RTTMON-IP-EXT-MIB contains extensions to tables in CISCO-RTTMON-MIB to support
IP-layer extensions including IPv6 addresses, information related to IPv6, and additional IP information.

ipIcmpEcho(2)
ipUdpEchoAppl(3)
ipTcpConn(24)
httpAppl(25)
dnsAppl(26)
jitterAppl(27)
ftpAppl(30)

All other values not supported.

make sure the ESR clock was set through the
CLI clock set command. Otherwise, the
scheduled RTT operation does not run.

HTTP and Jitter types not supported.

3-92

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

CISCO-SDLLC-MIB

The CISCO-SDLLC-MIB contains object to manage SDLC Logical Link Control (SDLLC). The MIB
contains read-only configuration and operational information for Cisco implementation of Synchronous
Data Link Control (SDLC) to Logical Link Control, type 2 (LLC2) media translation.

CISCO-SLB-EXT-MIB

The CISCO-SLB-EXT-MIB contains extensions to the Cisco server load-balancing MIB
(CISCO-SLB-MIB). Server load balancing enables the router to balance the processing of packets and
connections from a number of other devices, such as real servers, firewalls, or caches. An SLB device
determines how to handle incoming frames and connections according to the contents of the incoming
data and various configuration options.

CISCO-SLB-MIB

CISCO-SDLLC-MIB

The CISCO-SLB-MIB contains objects to manage server load-balancing (SLB) managers, such as those
provided by the Cisco IOS SLB product. The MIB includes objects for the manager-side implementation
of the Dynamic Feedback Protocol (DFP), which is used to obtain information about servers.

CISCO-SMI-MIB

The CISCO-SMI-MIB defines the structure of management information for Cisco enterprise MIBs.

CISCO-SNADLC-CONV01-MIB

The CISCO-SNADLC-CONV01-MIB contains objects that manage QLLC-to-SDLC and
QLLC-to-LLC2 conversion.

CISCO-SNAPSHOT-MIB

The CISCO-SNAPSHOT-MIB contains objects to manage snapshot routing, which helps improve the
use of system resources for static routing and routing for dedicated serial lines.

CISCO-SNMP-TARGET-EXT-MIB

The CISCO-SNMP-TARGET-EXT-MIB is an extension of the SNMP-TARGET-MIB specified in
RFC2273

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-93

CISCO-SONET-MIB

CISCO-SONET-MIB

The CISCO-SONET-MIB contains objects to describe SONET/SDH interfaces on the router. This MIB
is an extension to the standard SONET-MIB (RFC 2558). The CISCO-SONET-MIB has objects that
provide additional SONET related information not found in the SONET-MIB. For detailed definitions
of MIB objects, see the MIB.

MIB Constraints

The following CISCO-SONET-MIB tables are not implemented in the Cisco 7600 platform:

• csConfigTable

• csVTConfigTable

• csAPSConfigTable

• cssTranceTable

• cspTranceTable

Chapter 3 Cisco 7600 MIB Specifications

• csStatsTable

• cspConfigTable

Note Only the section, line, and path totals objects from the ciscoSonetStatsMIBGroup and the complete

ciscoSonetEnableGroup must be supported. All network elements containing one or more SONET
interfaces must implement this MIB.

CISCO-SRP-MIB

The CISCO-SRP-MIB contains objects that describe the spatial reuse protocol (SRP) interface layer.

CISCO-STACK-MIB

The CISCO-STACK-MIB provides configuration information and runtime status for router components.
On the Cisco 7600 Series router, the CISCO-STACK-MIB contains information about the chassis, ports,
and modules.

Note Before the ENTITY-MIB standardization, the OLD-CHASSIS-MIB and CISCO-STACK-MIB were

used to support physical entities. The CISCO-STACK-MIB is supported on the Cisco 7600 Series router
for LAN cards, OSM cards, and FlexWAN/SPAs. PAs, SIPs and SPAs and are not supported.

3-94

Table 3-29 lists the values that the Cisco 7600 Series router uses for module types.

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

Table 3-29 CISCO-STACK-MIB Module Type Values for the Cisco 7600 Series Router

MIB Object Notes

moduleTable

•

moduleType Module Type Part Number

CISCO-STP-EXTENSIONS-MIB

Enhanced OC-48/STM-16 POS/SDH OSM WAN ports

osm1oc48PosSSPlus(611) OSM-1OC-48-POS-SS+

osm1oc48PosSIPlus(612) OSM-1OC-48-POS-SI+

osm1oc48PosSLPlus(613) OSM-1OC-48-POS-SL+

Enhanced OC-12/STM-4 POS/SDH OSM WAN ports

osm2oc12PosMMPlus(608) OSM-2OC-12-POS-MM+

osm4oc12PosSIPlus(617) OSM-4OC-12-POS-SI+

Enhanced OC-12/ATM OSM WAN ports

osm2oc12AtmMMPlus(606) OSM-2OC-12-ATM-MM+

osm2oc12AtmSIPlus(607) OSM-2OC-12-ATM-SI+

Enhanced OC-3/STM-1 POS/SDH OSM WAN ports

osm16oc3PosSIPlus(610) OSM-16OC-3-POS-SI+

osm4oc3PosSIPlus(614) OSM-4OC-3-POS-SI+

osm8oc3PosSLPlus(615) OSM-8OC-3-POS-SL+

osm8oc3PosSIPlus(616) OSM-8OC-3-POS-SI+

Channelized DS3, GigE, and FlexWAN Modules

wsx6182pa(212) WS-X6182-2PA

osm12ct3DS0(600) OSM-12CT3/T1

osm24ct3DS0(287) OSM-24CT3/T1

osm4GeWanGbicPlus(603) OSM-2+4GE-WAN+

CISCO-STP-EXTENSIONS-MIB

The CISCO-STP-EXTENSIONS-MIB contains objects to manage Cisco extensions to the
Spanning-Tree Protocol (STP), which is defined by IEEE Std 802.1D.

CISCO-STUN-MIB

The CISCO-STUN-MIB contains objects to configure and monitor serial tunneling (STUN) on the
router. The MIB contains global STUN configuration and operational information, and objects to
manage STUN groups, ports, and routes.

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-95

CISCO-SVI-AUTOSTATE-MIB

CISCO-SVI-AUTOSTATE-MIB

The CISCO-SVI-AUTOSTATE-MIB is used for configuration of the switch virtual interface (SVI)
autostate feature. Autostate feature is a mechanism to calculate the state of a SVI dynamically when
some condition occurs such as a failure of a participating interface in that SVI.

CISCO-SWITCH-ENGINE-MIB

The CISCO-SWITCH-ENGINE-MIB contains objects to manage Cisco Layer 2 and 3 switches, such as
the Cisco 7600 Series router. Layer 2 and 3 switches can have a single (central) switching engine or
multiple (distributed) switching engines that are interconnected through a common switching fabric.

• In a central-switching engine model, all physical ports in the system are handled by the single

switching engine.

• In a distributed-switching model, each switching engine handles a set of local physical ports and

when necessary, uses the switching fabric to switch packets to other switching engines.

Chapter 3 Cisco 7600 MIB Specifications

CISCO-SWITCH-QOS-MIB

The CISCO-SWITCH-QOS-MIB extends the CISCO-CLASS-BASED-QOS-MIB by defining
configuration and statistics information specific to the quality of service (QoS) features of Layer2/3
switch functionality implemented in Cisco devices. This MIB is applicable to a device which is fully
within a single QoS domain; one or more boundaries with other QoS domains can be immediately
adjacent to this device.

CISCO-SYSLOG-MIB

The CISCO-SYSLOG-MIB contains all system log messages generated by the Cisco IOS software. The
MIB provides a way to access these syslog messages through SNMP. All Cisco IOS syslog messages
contain the message name and its severity, message text, the name of the entity generating the message,
and an optional time stamp. The MIB also contains a history of syslog messages and counts related to
syslog messages.

Note You can configure the Cisco 7600 Series router to send syslog messages to a ‘syslog’ server.

Note The MIB does not keep track of messages generated from debug commands entered through the

command line interface (CLI).

3-96

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

CISCO-TAP2-MIB

The CISCO-TAP2-MIB manages Cisco's intercept feature. This MIB replaces CISCO-TAP-MIB. This
MIB defines a generic stream table that contains fields common to all intercept types. Specific intercept
filters are defined in extension MIBs. The MIBs are CISCO-IP-TAP-MIB for IP intercepts,
CISCO-802-TAP-MIB for IEEE 802 intercepts and CISCO-USER-CONNECTION-TAP-MIB for
RADIUS-based user connection intercepts.

CISCO-TC

The CISCO-TC contains objects that define textual conventions used throughout Cisco enterprise MIBs.

CISCO-TCP-MIB

The CISCO-TCP-MIB contains objects to manage the Transmission Control Protocol (TCP) on the
router. This MIB is an extension to the IETF TCP MIB.

CISCO-TAP2-MIB

CISCO-UDLDP-MIB

The CISCO-UDLDP-MIB contains objects to configure and manage the Cisco Uni Direction Link
Detection Protocol (UDLDP) on the router.

CISCO-VINES-MIB

The CISCO-VINES-MIB provides Virtual Integrated Network Service (VINES) routing information.
The MIB also contains objects from the Cisco VINES command line interface.

CISCO-VLAN-IFTABLE-RELATIONSHIP-MIB

The CISCO-VLAN-IFTABLE-RELATIONSHIP-MIB contains VLAN-ID and ifIndex information for
each routed virtual LAN (VLAN) interface on the router. A routed VLAN interface is the router interface
or subinterface to which you attach the IP address used by the router on the VLAN. The MIB maps each
VLAN-ID to an ifIndex, which you can use to access the ipRouteTable to obtain the routing
configuration for the routed VLAN interface.

CISCO-VLAN-MEMBERSHIP-MIB

OL-4077-07

The CISCO-VLAN-MEMBERSHIP-MIB module provides management functions for the VLAN
Membership within the frame work of Cisco VLAN Architecture, Version 2.0. The MIB provides
information on VLAN Membership Policy Servers used by a device and VLAN membership
assignments of non-trunk bridge ports of the device.

Cisco 7600 Series Router MIB Specifications Guide

3-97

CISCO-VLAN-TRANSLATION-MIB

CISCO-VLAN-TRANSLATION-MIB

The CISCO-VLAN-TRANSLATION-MIB provides management of VLAN translations. VLAN
translation refers to the ability of the device to translate between different virtual LANs or between
VLAN and non-VLAN encapsulating interfaces at Layer 2. Translation is typically used for selective
inter-VLAN switching of non-routable protocols and to extend a single VLAN topology across hybrid
switching environments

CISCO-VOICE-ANALOG-IF-MIB

The CISCO-VOICE-ANALOG-IF-MIB manages the E&M, FXO, FXS interfaces in the router. The
analog voice interface MIB provides the standard configuration, timing parameters, telephony hook, and
ring status information on Cisco Analog Voice interface implementation. The following groups are
managed:

Analog interface general group

• E&M (recEive and transMit) interface group

• FXO (Foreign Exchange Office) interface group

• FXS (Foreign Exchange Station) interface group

Chapter 3 Cisco 7600 MIB Specifications

CISCO-VOICE-COMMON-DIAL-CONTROL-MIB

The CISCO-VOICE-COMMON-DIAL-CONTROL-MIB module contains voice related objects that are
common across more than one network encapsulation such as VoIP, VoATM, and VoFR.

CISCO-VOICE-DIAL-CONTROL-MIB

The CISCO-VOICE-DIAL-CONTROL-MIB module enhances the IETF Dial Control MIB (RFC 2128)
by providing management of voice telephony peers on both a circuit-switched telephony network, and
an IP data network.

CISCO-VOICE-IF-MIB

The CISCO-VOICE-IF-MIB module manages the common voice related parameters for both voice
analog and ISDN interfaces.

CISCO-VPDN-MGMT-EXT-MIB

The CISCO-VPDN-MGMT-EXT-MIB is a supplement to CISCO-VPDN-MGMT-MIB.

3-98

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07

Chapter 3 Cisco 7600 MIB Specifications

CISCO-VPDN-MGMT-MIB

The CISCO-VPDN-MGMT-MIB contains objects to manage the Virtual Private Dialup Network
(VPDN) feature of Cisco IOS. VPDN handles the forwarding of PPP links from an Internet Provider
(ISP) to a Home Gateway.

CISCO-VTP-MIB

The CISCO-VTP-MIB contains objects to configure and manage the VLAN Trunking Protocol (VTP)
and virtual LANs (VLANs) on the router.

CISCO-VPDN-MGMT-MIB

OL-4077-07

Cisco 7600 Series Router MIB Specifications Guide

3-99

DIAL-CONTROL-MIB

DIAL-CONTROL-MIB

The DIAL-CONTROL-MIB contains objects that describe peer information for demand access and
possibly other kinds of interfaces. Managing access circuits requires the following groups of
information:

• General configuration information.

• Information to describe peer configuration and peer statistics. In this respect, peer configuration

means information on how to connect to peers on outgoing calls, how to identify peers on incoming
calls, and other call related configuration information.

• Information to store active call information.

• Information to retain call history.

DIFFSERV-DSCP-TC

DIFFSERV-DSCP-TC contains the definitions of the textual conventions that should be used whenever
a Differentiated Services Code Point is used in a MIB.

Chapter 3 Cisco 7600 MIB Specifications

DIFFSERV-MIB

The DIFFSERV-MIB defines the objects necessary to manage a device that uses the Differentiated
Services Architecture described in RFC 2475.

DS1-MIB (RFC 1406, 2495, 2495)

The DS1-MIB module contains a description of DS1, E1, DS2, and E2 interfaces objects.

Note NOTE - Release 12.2(18)SXF and earlier support RFC1406. Release 12.2(33)SRA and later support

RFC 2495DS3-MIB

MIB Constraints

Table 3-30 describes constraints on objects from DS1-MIB definition. For detailed definitions of MIB

objects, see the MIB.

Table 3-30 DS1-MIB Constraints

MIB Object Notes

dsx1ConfigTable

3-100

•

dsx1LineStatusChangeTrapEnable Read-only.

• dsx1Channelization Read-only.

• dsx1LineLength Read-only.

Cisco 7600 Series Router MIB Specifications Guide

OL-4077-07
