Support Information for Cisco Routers
This chapter contains Virtual Network Element (VNE) support information for Cisco ANA 3.6 for the
following Cisco devices:
• Cisco 7200 Series Routers, page 9
• Cisco 7600 Series Routers, page 15
• Cisco 12000 Series Routers, page 21
• Cisco XR 12000 Series Routers, page 29
• Cisco Carrier Routing System (CRS-1) Routers, page 35
For information about the technologies supported by each of these VNEs, see Supported Technologies
on Cisco Routers, page 42.
Note For information about the syslogs and traps supported by Cisco ANA 3.6 on Cisco IOS/IOX devices, see
Cisco Active Network Abstraction Fault Management User Guide, Version 3.6.
Cisco 7200 Series Routers
OL-14112-01
This section includes the following information about Cisco 7200 Series routers:
• Cisco 7200 Series—Supported Software Versions, page 10
• Cisco 7200 Series—Supported Topologies, page 11
• Cisco 7200 Series—Supported Modules, page 11
• Cisco 7200 Series—Supported Technologies, page 13
• Cisco 7200 Series—Supported Service Events, page 14
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
9
Cisco 7200 Series Routers
Cisco 7200 Series—Supported Software Versions
Table 7 lists the supported software versions for Cisco 7200 Series routers in Cisco ANA 3.6.
Table 7 Supported Software Versions for Cisco 7200 Series Routers
Certification
Software Version
IOS 12.0(26)S6 S
IOS 12.0(27)S1 S
IOS 12.0(32)S6 S
IOS 12.1(10)E S
IOS 12.1(19)E6 S
IOS 12.1(1a) S
IOS 12.2(12) V
IOS 12.2(15)B V
IOS 12.2(15)T5 V
IOS 12.2(18.2) V
IOS 12.2(33)SRA V
IOS 12.2(34.* S
IOS 12.2(37* S
IOS 12.2(40* S
IOS 12.3(10) V
IOS 12.3(12.10) V
IOS 12.3(15a) V
IOS 12.3(3)B1 V
IOS 12.3(7)XI7a V
IOS 12.3* S
IOS 12.4* S
IOS 11.3(7)T V
IOS 12.0(22)S5 V
IOS 12.0(23)S3.0619 V
IOS 12.0(23)S4 V
IOS 12.0(23)S6 V
IOS 12.0(23)S6.0412 V
IOS 12.0(24)S3 V
IOS 12.0(25)S2 V
IOS 12.0(26)S4 V
IOS 12.0(26)S5 V
IOS 11.3(7)T V
Level
Support Information for Cisco Routers
10
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Table 7 Supported Software Versions for Cisco 7200 Series Routers (continued)
Certification
Software Version
Level
IOS 12.0(26)S6 V
IOS 12.0(27)S1 V
IOS 12.4(11)T1 V
Note Software versions marked with an asterisk (representing a wildcard) are supported by Cisco ANA 3.6.
Specific software versions that have been tested and verified are listed individually and marked as V.
Cisco 7200 Series—Supported Topologies
The following topologies are supported for Cisco 7200 Series routers in Cisco ANA 3.6:
• ATM counters
• IP
• Ethernet
Cisco 7200 Series Routers
• CDP
• MPLS
Cisco 7200 Series—Supported Modules
Table 8 lists the supported modules for Cisco 7200 Series routers in Cisco ANA 3.6.
Table 8 Supported Modules for Cisco 7200 Series Routers
Module Name Module Description
CX-FEIP-1FX 1-port fast ethernet interface processor (100FX) S
FEIP2-DSW 2-Port Fast Ethernet IP with Dist. Switching S
PA-FE-TX 1-Port Fast Ethernet 100BaseTx Port Adapter S
PA-4R-DTR 4-port dedicated Token Ring, 4/16 Mbps, half
duplex(HDX) or full duplex (FDX)
PA-2T3+ Two-port clear-channel DS3 port adap S
VIP2-50 VIP2; Model 50 S
GEIP Gigabit Ethernet Interface Processor S
PA-4R-DTR 4-port Token Ring Port Adapter S
PA-8E 8-Port 10BaseT Ethernet Port Adapter S
PA-4E 4-Port 10BaseT Ethernet Port Adapter S
NPE-100 Cisco 7200 Series Network Processing Engine
100
Certification
Level
S
S
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
11
Cisco 7200 Series Routers
Support Information for Cisco Routers
Table 8 Supported Modules for Cisco 7200 Series Routers (continued)
Module Name Module Description
NSE-1 Cisco 7200 Series Network Services Engine,
NSE-1
NPE-150 Cisco 7200 Series Network Processing Engine
150
NPE-200 Network Processing Engine NPE-200 S
NPE-300 Network Processing Engine NPE-300 S
NPE-225 Cisco 7200 Network Processing Engine
NPE-225
C7200-I/O-GE+E Cisco 7200 Series 1-Port Gigabit Ethernet and
1-Port Ethernet Input/Output Controller
C7200-I/O-2FE/E Cisco 7200 Series 2-Port 10/100 Auto-Sensing
Fast Ethernet Input/Output Controller
ATM WAN OC3+ (MM) /PA-A1 ATM WAN OC3+ (MM) Port adapter, 1 port.
Port adapter
C7200-IO I/O controller with no Ethernet port S
NPE-400 Cisco 7200VXR Network Processing Engine
NPE-400, including 256 MB SDRAM
NPE-G1 Cisco 7200 Series NPE-G1 including 256 MB
default DRAM and 64 MB default flash memory
PA-MC-8E1 8-port MultiChannel E1 Port Adapter S
PA-MC-E3 1-port MultiChannel E3 Port Adapter S
PA-MC-2T(1) 2-port multichannel T1 with integrated channel
service units (CSUs)/DSUs
PA-2FE-TX 2-Port Fast Ethernet 100Base TX Port Adapter S
PA-T3+ One-port clear-channel DS3 port adapter S
PA-POS-OC3SMI Single-Mode Intermediate Reach PoS, OC3 Port
Adapter
PA-POS-OC3MM MultiMode PoS, OC3 Port Adapter S
PA-POS-OC3SML Single-Mode Long Reach PoS, OC3 Port
Adapter
PA-MC-2T(3) Two-port enhanced multichannel T3 port adapter S
PA-A6-OC3SMI 1-Port Enhanced ATM OC3c/STM1 Singlemode
(IR) Port Adapter
PA-FE-FX 1-Port Fast Ethernet 100BaseFx Port Adapter S
RSP4 Route Switch Processor 4 S
PA-MC-8TE1 8 port multichannel T1/E1 8PRI port adapter S
CX-CIP2-ECAP1 Second-generation Channel Interface Processor
with single ESCON channel and single parallel
channel
Certification
Level
S
S
S
S
S
S
S
S
S
S
S
S
S
12
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Table 8 Supported Modules for Cisco 7200 Series Routers (continued)
Module Name Module Description
VIP6-80 Services Accelerator Versatile Interface
PA-MC-2E1/120 2-Port Multichannel E1/PRI Port Adapter S
PA-MC-T3+ Single port enhanced multichannel T3 port
CX-FEIP-1FX 1-port fast ethernet interface processor (100TX) S
PA-A3-OC3SML Single port ATM OC3c/STM1 Single Mode
PA-A3-OC3SMI Single port ATM OC3c/STM1 Single Mode (IR)
PA-A3-OC3MM Single port ATM OC3c/STM1 Multi Mode Port
OSM-1OC48-POS-SI+ 1-port OC-48/STM-16 SONET/SDH enhanced
WS-X6582-2PA Enhanced FlexWAN Module, Fabric-enabled S
WS-X6582-2PA FlexWAN Module S
PA-GE Gigabit Ethernet Port Adapter S
Cisco 7200 Series Routers
Certification
Level
S
Processor 6-80
S
adapter
S
(LR) Port Adapter
S
Port Adapter
S
Adapter
S
OSM, single-mode, intermediate-reach with 4
GE
Note For detailed information about the specific technologies and attributes supported by this NE, see
Cisco 7200 Series—Supported Technologies, page 13.
Cisco 7200 Series—Supported Technologies
The following technologies are supported by the Cisco 7200 Series in Cisco ANA 3.6:
• Base Logical Components, page 43
• Layer 1, page 43
• IP, page 44
• Routing Protocols, page 46
• Ethernet (Physical), page 47
• Physical Equipment, page 47
• Ethernet (Logical), page 48
• ATM, page 48
• Frame Relay, page 50
• HDLC, page 52
• MPLS, page 52
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
13
Cisco 7200 Series Routers
• VPN, page 54
• QoS, page 55
Cisco 7200 Series—Supported Service Events
Table 9 lists the supported service events (also called service alarms) for Cisco 7200 Series routers in
Cisco ANA 3.6.
Table 9 Service Events for Cisco 7200 Series Routers
Event Name Expedited
Primary HSRP interface inactive/
active
Secondary HSRP interface inactive/
active
All ip interfaces down active ip
interfaces found
interface status down/up Y
card in/out Y
link down/up Y
Device Unreachable N
CPU Over Utilized N
Memory Over utilize N
Device Unsupported N
Discard Packets N
Dropped Packets N
Module Unsupported N
Port Flapping N
Port Down Y
Rx Over utilized N
Tx Over utilized N
VPN leak N
Cloud Problem N
Broken LSP discovered N
MPLS Black hole N
Layer 2 Tunnel Down N
MPLS TE Tunnel Down/Flapping N
BGP Neighbor Down N
Card up/down Y
N
N
Y
Support Information for Cisco Routers
14
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Cisco 7600 Series Routers
This section includes the following information about Cisco 7600 Series routers:
• Cisco 7600 Series—Supported Software Versions, page 15
• Cisco 7600 Series—Supported Topologies, page 15
• Cisco 7600 Series—Supported Modules, page 16
• Cisco 7600 Series—Supported Technologies, page 20
• Cisco 7600 Series—Supported Service Events, page 20
Cisco 7600 Series—Supported Software Versions
Table 10 lists the supported software versions for Cisco 7600 Series routers in Cisco ANA 3.6.
Table 10 Supported Software Versions for Cisco 7600 Series Routers
Certification
Software Version
IOS 12.2(18)SXD V
IOS 12.2(18)SXD5 V
IOS 12.2(18)SXE6b V
IOS 12.2(33)SRA V
IOS 12.2(33)SRA2 V
IOS 12.2(33)SRB V
IOS 12.2(18)SXE* S
IOS 12.2(18)SXF* S
IOS 12.2(33* S
IOS 12.3* S
IOS 12.4* S
Level
Cisco 7600 Series Routers
Note Software versions marked with an asterisk (representing a wildcard) are supported by Cisco ANA 3.6.
Specific software versions that have been tested and verified are listed individually and marked as V.
Cisco 7600 Series—Supported Topologies
The following topologies are supported for Cisco 7600 Series routers in Cisco ANA 3.6:
• IP
• MAC
• CDP
• MPLS
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
15
Cisco 7600 Series Routers
Cisco 7600 Series—Supported Modules
Table 11 lists the supported modules for Cisco 7600 Series routers in Cisco ANA 3.6.
Table 11 Supported Modules for Cisco 7600 Series Routers
Module Name Module Description
WS-SUP720-3BXL Supervisor Engine 720 with PFC3BXL V
WS-SUP720-3B Supervisor Engine 720 with PFC3B V
WS-SUP32-10GE-3B Supervisor Engine 32 S
WS-SUP32-GE-3B Supervisor Engine 32 S
WS-X6700-CFC Centralized Forwarding Card S
WS-F6K-PFC3BXL Policy Feature Card 3BXL (PFC3BXL) V
WS-F6K-PFC3CXL Policy Feature Card 3CXL (PFC3CXL) S
WS-F6700-DFC3BXL Distributed Forwarding Card 3BXL
(DFC3BXL) for use on CEF720 modules
WS-F6700-DFC3CXL Distributed Forwarding Card 3CXL
(DFC3CXL) for use on CEF720 modules
WS-F6700-DFC3C Distributed Forwarding Card 3C (DFC3C) for
use on CEF720 modules
WS-X6704-10GE 4-port 10-Gigabit Ethernet S
WS-X6502-10GE 1-port 10-Gigabit Ethernet S
WS-G6488 10GBASE-LR serial 1310 nm long-reach OIM S
WS-G6483 10GBASE-ER serial 1550 nm extended-reach
OIM
XENPAK-10GB-SR 10GBASE-SR Serial 850-nm short-reach
multimode fiber (MMF)
XENPAK-10GB-ER 10GBASE-ER Serial 1550-nm extended-reach,
single-mode fiber (SMF), dispersion-shifted
fiber (DSF)
WS-X6748-SFP 48-port Gigabit Ethernet SFP S
WS-X6724-SFP 24-port Gigabit Ethernet SFP S
WS-X6816-GBIC 16-port Gigabit Ethernet GBIC S
WS-X6516A-GBIC 16-port Gigabit Ethernet GBIC S
WS-X6516-GBIC 16-port Gigabit Ethernet GBIC S
WS-X6416-GBIC 16-port Gigabit Ethernet GBIC S
WS-X6316-GE-TX 16-port Gigabit Ethernet RJ-45 S
WS-X6408A-GBIC 8-port Gigabit Ethernet GBIC Enhanced QoS
Module
WS-X6408-GBIC 8-port Gigabit Ethernet GBIC S
WS-F6K-FE48X2-AF IEEE 802.3af PoE daughtercard S
Support Information for Cisco Routers
Certification
Level
S
S
S
S
S
S
S
16
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Table 11 Supported Modules for Cisco 7600 Series Routers (continued)
Module Name Module Description
WS-F6K-GE48-AF IEEE 802.3af PoE daughtercard S
WS-F6K-VPWR-GE PoE Daughtercard S
WS-F6K-VPWR PoE Daughtercard S
WS-X6748-GE-TX 48 port 10/100/1000 RJ-45 Ethernet Switching
WS-X6548-GE-TX 48 port 10/100/1000 RJ-45 Ethernet Switching
WS-X6148A-GE-TX 48 port 10/100/1000 RJ-45 Ethernet Switching
WS-X6148-GE-TX 48 port 10/100/1000 RJ-45 Ethernet Switching
WS-X6516-GE-TX 16 port 10/100/1000 Base-T Ethernet Switching
WS-X6148-FE-SFP 48 port 100BASE-FX Fast Ethernet Switching
WS-X6324-100FX-SM 24 port 100FX SingleMode Fast Ethernet
WS-X6548-RJ-45 48 port 10/100TX RJ-45 Ethernet/Fast Ethernet
WS-X6548-RJ-21 48 port 10/100TX RJ-21 Ethernet/Fast Ethernet
WS-X6148X2-RJ-45 96 port 10/100TX RJ-45 Ethernet/Fast Ethernet
WS-X6196-RJ-21 96 port 10/100TX RJ-21 Ethernet/Fast Ethernet
WS-X6348-RJ-45 48 port 10/100TX RJ-45 Ethernet/Fast Ethernet
WS-X6248-RJ-45 48 port 10/100TX RJ-45 Ethernet/Fast Ethernet
WS-X6248A-TEL 48 port 10/100TX RJ-21 Enhanced Ethernet/Fast
WS-X6248-TEL 48 port 10/100TX RJ-21 Ethernet/Fast Ethernet
WS-X6148-RJ-45 48 port 10/100TX RJ-45 Ethernet/Fast Ethernet
WS-X6148A-RJ-45 48 port 10/100TX RJ-45 Ethernet/Fast Ethernet
WS-X6148-RJ-21 48 port 10/100TX RJ-21 Ethernet/Fast Ethernet
OSM-2+4GE-WAN+ 4-port Gigabit Ethernet WAN (GBIC) with two
Cisco 7600 Series Routers
Certification
Level
S
Module
S
Module
S
Module
S
Module
S
Module
S
Module
S
Switching Module
S
Switching Module
S
Switching Module
S
Switching Module
S
Switching Module
S
Switching Module
S
Switching Module
S
Ethernet Switching Module
S
Switching Module
S
Switching Module
S
Switching Module
S
Switching Module
S
Layer 2 LAN ports; CEF256
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
17
Cisco 7600 Series Routers
Support Information for Cisco Routers
Table 11 Supported Modules for Cisco 7600 Series Routers (continued)
Module Name Module Description
OSM-1OC48-POS-SI+ Enhanced 1-port OC-48/STM-16 SONET/SDH
OSM, SM-IR
OSM-1OC48-POS-SL+ Enhanced 1-port OC-48/STM-16 SONET/SDH
OSM, SM-LR
OSM-1OC48-POS-SS+ Enhanced 1-port OC-48/STM-16 SONET/SDH
OSM, SM-SR
OSM-4OC12-POS-SI+ Enhanced 4-port OC-12c/STM-4c POS, SM-IR;
CEF256
OSM-2OC12-POS-SI+ Enhanced 2-port OC-12c/STM-4c POS, SM-IR;
CEF256
OSM-4OC3-POS-SI+ Enhanced 4-port OC-3c/STM-1c POS, SM-IR; S
OSM-1CHOC12T3-SI 1-port channelized OC-12, SM-IR S
OSM-12CT3T1 12-port channelized/unchannelized CT3-T1 S
OSM-2OC12-ATM-MM+ Enhanced 2-port OC-12/STM-4 ATM OSM,
MM
OSM-2OC12-ATM-SI+ Enhanced 2-port OC-12/STM-4 ATM OSM,
SM-IR
7600-SIP-600 SPA Interface Processor-600 S
7600-SIP-400 SPA Interface Processor-400 S
7600-SIP-200 SPA Interface Processor-200 S
SPA-1XTENGE-XFP 1-port 10 Gigabit Ethernet SPA, LANPHY XFP
Optics
SPA-10X1GE 10-port Gigabit Ethernet SPA, SFP Optics S
SPA-10X1GE-V2 10-port Gigabit Ethernet SPA, SFP Optics S
SPA-5X1GE 5-port Gigabit Ethernet SPA, SFP Optics S
SPA-2X1GE 2-port Gigabit Ethernet SPA, SFP Optics S
SPA-2X1GE-V2 2-port Gigabit Ethernet SPA, SFP Optics S
SPA-4X1FE-TX-V2 4-port 10/100 Ethernet SPA TX S
SPA-8X1FE-TX-V2 8-port 10/100 Ethernet SPA TX S
SPA-2XOC3-POS 2-port OC-3c/STM-1c POS SPA S
SPA-4XOC3-POS 4-port OC-3c/STM-1c POS SPA S
SPA-1XOC12-POS 1-port OC-12c/STM-4c POS SPA S
SPA-OC192POS-LR 1-port OC-192c/STM-64 POS/RPR SPA,
SM-LR
SPA-OC192POS-XFP 1-port OC-192c/STM-64 POS/RPR SPA, XFP
Optics
SPA-2XOC48POSRPR 2 port OC-48 POS/RPR SPA with SFP Optics S
SPA-4XOC48POSRPR 4-port OC-48c/STM-16 POS/DPT/RPR SPA S
Certification
Level
S
S
S
S
S
S
S
S
S
S
18
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Table 11 Supported Modules for Cisco 7600 Series Routers (continued)
Module Name Module Description
SPA-2XOC3-ATM 2-port OC-3c/STM-1c ATM SPA S
SPA-4XOC3-ATM 4-port OC-3c/STM-1c ATM SPA S
SPA-1XOC12-ATM 1-Port OC-12c/STM-4c ATM SPA S
SPA-1XOC48-ATM 1 port OC-48c/STM-16 ATM SPA S
SPA-8XCHT1E1 8-Port Channelized T1/E1 SPA S
SPA-2XT3/E3 2-port Clear Channel T3/E3 SPA S
SPA-4XT3/E3 4-port Clear Channel T3/E3 SPA S
SPA-2XCT3/DS0 2-port Channelized T3 to DS0 SPA S
SPA-4XCT3/DS0 4-port Channelized T3 to DS0 SPA S
SPA-1XCHSTM1/OC3 1-port Channelized STM1/OC3 to DS0 SPA S
SPA-24CHT1-CE-ATM 24-Port Channelized T1/E1/J1 ATM CEoP SPA S
WS-X6582-2PA Enhanced FlexWAN Module; S
PA-2FE-TX, -FX 2-port Fast Ethernet port adapter S
PA-1FE-TX, -FX 1-port Fast Ethernet port adapter S
PA-POS-2OC3 2-port POS OC3c/STM1 port adapter S
SFP-OC3-MM Short range, multimode fiber S
SFP-OC3-IR1 Intermediate range, single-mode fiber S
SFP-OC3-LR1 Long range, single-mode fiber S
PA-A3-T3 ATM with traffic shaping port adapters S
PA-A3-E3 ATM with traffic shaping port adapters S
PA-4T+ T1/E1 port adapters S
PA-MC-8T1 T1/E1 port adapters S
PA-MC-4T1 T1/E1 port adapters S
PA-MC-STM-1 Multichannel STM-1 port adapters S
WS-SVC-MWAM-1 Multi-Processor WAN Application Module S
WS-SVC-NAM-1 Network Analysis module 1 S
WS-SVC-NAM-2 Network Analysis module 2 S
WS-C6509-E-FAN High-capacity fan tray S
WS-CAC-6000W 6000W AC power supply S
Cisco 7600 Series Routers
Certification
Level
OL-14112-01
Note For detailed information about the specific technologies and attributes supported by this NE, see
Cisco 7600 Series—Supported Technologies, page 20.
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
19
Cisco 7600 Series Routers
Cisco 7600 Series—Supported Technologies
The following technologies are supported by the Cisco 7600 Series in Cisco ANA 3.6:
• Base Logical Components, page 43
• Layer 1, page 43
• IP, page 44
• Routing Protocols, page 46
• Ethernet (Physical), page 47
• Physical Equipment, page 47
• Ethernet (Logical), page 48
• ATM, page 48
• Frame Relay, page 50
• HDLC, page 52
• MPLS, page 52
• VPN, page 54
Support Information for Cisco Routers
• QoS, page 55
• Q-in-Q (Switch Port), page 56
• Q-in-Q (Routed Switch), page 57
• STP, page 57
Cisco 7600 Series—Supported Service Events
Table 12 lists the supported service events (also called service alarms) for Cisco 7600 Series routers in
Cisco ANA 3.6.
Table 12 Service Events for Cisco 7600 Series Routers
Event Name Expedited
Primary HSRP interface inactive/
active
Secondary HSRP interface inactive/
active
All ip interfaces down active ip
interfaces found
interface status down/up Y
card in/out Y
link down/up Y
Device Unreachable N
CPU Over Utilized N
Memory Over utilize N
Device Unsupported N
N
N
Y
20
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Table 12 Service Events for Cisco 7600 Series Routers (continued)
Event Name Expedited
Discard Packets N
Dropped Packets N
Module Unsupported N
Port Flapping N
Port Down Y
Rx Over utilized N
Tx Over utilized N
VPN leak N
Cloud Problem N
Broken LSP discovered N
MPLS Black hole N
Layer 2 Tunnel Down N
MPLS TE Tunnel Down/Flapping N
BGP Neighbor Down N
Card up/down Y
Cisco 12000 Series Routers
Cisco 12000 Series Routers
This section includes the following information about Cisco 12000 Series routers:
• Cisco 12000 Series—Supported Software Versions, page 21
• Cisco 12000 Series—Supported Topologies, page 22
• Cisco 12000 Series—Supported Modules, page 23
• Cisco 12000 Series—Supported Technologies, page 27
• Cisco 12000 Series—Supported Service Events, page 28
Cisco 12000 Series—Supported Software Versions
Table 13 lists the supported software versions for Cisco 12000 Series routers in Cisco ANA 3.6.
Table 13 Supported Software Versions for Cisco 12000 Series Routers
Certification
Software Version
IOS 12.0(23)S3 V
IOS 12.0(26)S V
IOS 12.0(26)S1 V
Level
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
21
Cisco 12000 Series Routers
Table 13 Supported Software Versions for Cisco 12000 Series Routers (continued)
Software Version
IOS 12.0(26)S2 V
IOS 12.0(26)S3 V
IOS 12.0(26)S4 V
IOS 12.0(26)S5 V
IOS 12.0(26)S6 V
IOS 12.0(31)S V
IOS 12.0(31)S3 V
IOS 12.0(32)SY V
IOS 12.0(32)SY2 V
IOS 12.0(27* S
IOS 12.0(28* S
IOS 12.0(30* S
IOS 12.0(31* S
IOS 12.0(32* S
IOS 12.1* S
IOS 12.2* S
Support Information for Cisco Routers
Certification
Level
Note Software versions marked with an asterisk (representing a wildcard) are supported by Cisco ANA 3.6.
Specific software versions that have been tested and verified are listed individually and marked as V.
Cisco 12000 Series—Supported Topologies
The following topologies are supported for Cisco 12000 Series routers in Cisco ANA 3.6:
• ATM counters
• IP
• MAC
• CDP
• MPLS
22
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Cisco 12000 Series—Supported Modules
Table 14 lists the supported modules for Cisco 12000 Series routers in Cisco ANA 3.6.
Table 14 Supported Modules for Cisco 12000 Series Routers
Module Name Module Description
GSR16/80-SFC OC48 Switch Fabric Card for 12016 chassis V
GSR16/80-CSC OC48 Clock Scheduler Card for 12016 chassis V
GSR16-ALRM Cisco 12016 GSR Alarm Card V
8FE-TX-RJ45 8-Port Fast Ethernet Line Card V
8FE-FX-SC 8-Port Fast Ethernet Line Card V
4OC12X/POS-M-SC-B 5 port (Quad) OC-12 POS Card, Single Mode,
Short Reach
OC-48E/POS-SR-SC-B 2 Port Packet Over Sonet OC-48, Single Mode,
Short Reach, SC Connector Card
OC12/SRP-IR-SC-B 2 Port OC-12 Single Mode SRP Intermediate
Reach Line Card
OC12/SRP-MM-SC-B 2 Port OC-12 Multi Mode SRP Line Card V
OC48X/POS-LR-SC One-Port OC-48c/STM-16c POS/SDH ISE Line
Card, Long Reach
4OC12/POS-IR-SC-B Enhanced 4 port OC-12 Intermediate Reach Line
Card
6CT3-SMB 18 Port Copper DS3 Interface Line Card V
12DS3-SMB 24 Port Copper DS3 Interface Line Card V
3GE-GBIC-SC 4 Port Gigabit Ethernet Line Card (trident) V
GSR10-AC-PDU Cisco 12410 AC Power Distribution Unit (spare) V
4OC48E/POS-SR-SC 5 Port (Quad) Enhanced OC-48 Short Reach SC
Connector Line Card
4OC48E/POS-LR-SC 5 Port (Quad) Enhanced OC-48 Long Reach FC
Connector Line Card
PRP-1 Performance Route Processor-1 V
PRP-2 Cisco XR 12000 and 12000 Series Performance
Router Processor-2
OC48X/POS-SR-SC One-Port OC-48c/STM-16c POS/SDH ISE Line
Card, Short Reach
4OC12X/POS-I-SC-B 4 Port OC12 SM Intermediate Reach POS V
16-OC3X/POS-IR-LC 16-Port Packet-Over-SONET OC-3/STM-1 with
Extended Feature Set Line Card (concatenated)
CHOC12/DS1-IR-SC Cisco 12000 Series 1-Port Channelized
OC-12c/STM-4
PRP-3 Performance Route Processor-2 V
Cisco 12000 Series Routers
Certification
Level
V
V
V
V
V
V
V
V
V
V
V
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
23
Cisco 12000 Series Routers
Table 14 Supported Modules for Cisco 12000 Series Routers (continued)
Support Information for Cisco Routers
Module Name Module Description
PRP-4 Cisco XR 12000 and 12000 Series Performance
Router Processor-3
12000-SIP-401 V
GSR-8FE-FX 8 port Fast Ethernet card with Fiber Interface V
SSRP-OC48-SM-SR 1 Port OC-48 SRP Single Mode Short Reach
Line Card
SSRP-OC48-SM-LR 1 Port OC-48 SRP Single Mode Long Reach
Line Card
POS-QOC12-MM-SR 4 port (Quad) OC-12 POS Card, Single Mode,
Short Reach
POS-OC48-SM-SR-SC 1 Port Packet Over Sonet OC-48, Single Mode,
Short Reach, SC Connector Card
SRP-OC12-SM-IR 1 Port OC-12 Single Mode SRP Intermediate
Reach Line Card
SRP-OC12-MM 1 Port OC-12 Multi Mode SRP Line Card V
POS-EN-OC48-SR-SC Enhanced OC-48 Short Reach SC Connector
Line Card
POS-EN-OC48-LR-SC Enhanced OC-48 Long Reach SC Connector
Line Card
POS-EN-QOC12-IR Enhanced 4 port OC-12 Intermediate Reach Line
Card
COPPER-6DS3 6 Port Copper DS3 Interface Line Card V
COPPER-12DS3 12 Port Copper DS3 Interface Line Card V
GSR-SFC16 Switch Fabric Card V
GSR-CSC16 Scheduler/Fabric Card V
GSR-3GE 3 Port Gigabit Ethernet Line Card (trident) V
GSR-ALARM16 GSR-Alarm V
POS-EN-QOC48-SM-SR-SC 4 Port (Quad) Enhanced OC-48 Short Reach SC
Connector Line Card
POS-EN-QOC48-SM-LR-SC 4 Port (Quad) Enhanced OC-48 Long Reach SC
Connector Line Card
POS-EN-QOC48-SM-LR-FC 4 Port (Quad) Enhanced OC-48 Long Reach FC
Connector Line Card
GSR-SFC16-OC192 GSR 12406 Switch Fabric Card V
GSR-CSC16-OC192 GSR 12406 Clock Scheduler Card V
CPU-GSR-PRP1 V
CPU-GSR-PRP2 V
GSR-RP GSR RoMman Recovery V
GSR-ALARM10 GSR Alarm module V
Certification
Level
V
V
V
V
V
V
V
V
V
V
V
V
24
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Table 14 Supported Modules for Cisco 12000 Series Routers (continued)
Module Name Module Description
GSR-E48-POS-OC48-SM-SR-SC GSR, Edge Engine 48 Port OC-48 SRP Single
GSR-E48-POS-OC48-SM-LR-SCGSR 12406 Switch Fabric Card V
GSR-E48-POS-QOC12-SM-IR-SC4 Port OC12 SM Intermediate Reach POS V
GSR-E48-POS-16OC3-SM-IR-LC16 Port OC3 SM Intermediate Reach POS V
GSR-SFC6 GSR Switch Fabric Card V
GSR-CSC6 GSR Clock Scheduler V
GSR-ALARM6 GSR Alarm module V
GSR-SFC12410 GSR 12410 Switch Fabric Card V
GSR-CLOCK-OC192 GSR Clock Scheduler V
GSR-CSC12410 GSR 12410 Clock scheduler V
GSR-E-OC192-SM-SR-SC Enhanced 1 Port OC 192 Short Reach 2 FC
GSR-E-QOC48-SM-LR-SC 4 Port Enhanced OC 48 Short Reach SC
GSR-E-QOC48-SM-SR-SC 4 Port Enhanced OC 48 Short Reach SC
GSR-GEFE GSR General Fan V
GSR-PA-3GE GSR 3 port Port Adapter V
GSR-E48-ATM-4OC12-SM-IR-SCGSR Edge Engine 48, ATM, 4 ports
GSR-E48-ATM-4OC12-MM-SR
-SC
GSR-8FE-TX 8 port Fast Ethernet card with Copper Interface V
GSR-8FE-FX 8 port Fast Ethernet card with Fiber Interface V
SSRP-OC48-SM-LR 1 Port OC-48 SRP Single Mode Long Reach
POS-QOC12-MM-SR 1 Port OC-12 Single Mode SRP Intermediate
POS-OC48-SM-SR-SC 1 Port Packet Over Sonet OC-48, Single Mode,
SRP-OC12-SM-IR 1 Port OC-12 Single Mode SRP Intermediate
SRP-OC12-MM 1 Port OC-12 Multi Mode SRP Line Card V
Cisco 12000 Series Routers
Mode Long Reach Line Card
Connector LineCard
Connector Line Card
Connector Line Card
OC12/STM4 Single Mode Intermediate Reach
Line Card
GSR Edge Engine 48, ATM, 4 port
OC12/STM4Multi Mode Short Reach Line Card
Line Card
Reach Line Card
Short Reach, SC Connector Card
Reach Line Card
Certification
Level
V
V
V
V
V
V
V
V
V
V
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
25
Cisco 12000 Series Routers
Table 14 Supported Modules for Cisco 12000 Series Routers (continued)
Support Information for Cisco Routers
Module Name Module Description
POS-EN-OC48-SR-SC Enhanced OC-48 Short Reach SC Connector
Line Card
POS-EN-OC48-LR-SC Enhanced OC-48 Long Reach SC Connector
Line Card
POS-EN-QOC12-IR Enhanced 4 port OC-12 Intermediate Reach Line
Card
COPPER-6DS3 6 Port Copper DS3 Interface Line Card V
COPPER-12DS3 12 Port Copper DS3 Interface Line Card V
GSR-SFC16 GSR 12016 Switch Fabric Card V
GSR-CSC16 GSR 12016 Clock Scheduler Card V
GSR-3GE 3 Port Gigabit Ethernet Line Card (trident) V
GSR-ALARM16 GSR Alarm module V
POS-EN-QOC48-SM-SR-SC 4 Port (Quad) Enhanced OC-48 Short Reach SC
Connector Line Card
GSR-SFC16-OC192 GSR 12016 OC192 Switch Fabric Card V
GSR-CSC16-OC192 GSR 12016 OC192 Clock Scheduler Card V
GSR-SFC GSR Switch Fabric Card V
GSR-CSC GSR Clock Scheduler Card V
SPA-4XCT3/DS0 4-port Channelized T3 to DS0 Shared Port
Adapter
SPA-1XTENGE-XFP 1-port 10Gigabit Ethernet Shared Port Adapter
XFP based
SPA-5X1GE 5-Port Gigabit Ethernet SPA S
SPA-5X1GE-V2 5-Port Gigabit Ethernet SPA S
SPA-2X1GE 2 ports Gigabit Ethernet Shared Port Adapters S
SPA-2X1GE-V2 2 ports Gigabit Ethernet Shared Port Adapters S
SPA-2XOC48POS/RPR 2-port OC48/STM16 POS/RPR Shared Port
Adapters
SPA-1X10GE-L-V2 Cisco 1-Port 10GE LAN-PHY Shared Port
Adapter
SPA-4XOC12-POS 4-port OC-12/STM-4 POS Shared Port Adapters S
SPA-1XOC48POS/RPR Port OC-48c/STM-16c POS/RPR Shared Port
Adapter
SPA-2XOC12-POS 2-Port OC-3c/STM-1 and OC-12c/STM-4 POS
SPA
SPA-8XOC12-POS 8-Port OC-12c/STM-4 Multirate POS SPA S
SPA-OC192POS-LR 1-port OC192/STM64 POS/RPR SMLR Optics S
SPA-OC192POS-VSR 1-port OC192/STM64 POS/RPR VSR Optics S
Certification
Level
V
V
V
V
V
S
S
S
S
S
26
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Table 14 Supported Modules for Cisco 12000 Series Routers (continued)
Module Name Module Description
SPA-2XT3/E3 2-port Clear Channel T3/E3 Shared Port Adapter S
SPA-4XT3/E3 4-port Clear Channel T3/E3 Shared Port Adapter S
SPA-8XCHT1/E1 8-port Channelized T1/E1 to DS0 Shared Port
Adapter
SPA-2XCT3/DS0 2-port Channelized T3 to DS0 Shared Port
Adapter
Note For detailed information about the specific technologies and attributes supported by this NE, see
Cisco 12000 Series—Supported Technologies, page 27.
Cisco 12000 Series—Supported Technologies
Cisco 12000 Series Routers
Certification
Level
S
S
The following technologies are supported by the Cisco 12000 Series in Cisco ANA 3.6:
• Base Logical Components, page 43
• Layer 1, page 43
• IP, page 44
• Routing Protocols, page 46
• Ethernet (Physical), page 47
• Physical Equipment, page 47
• Ethernet (Logical), page 48
• ATM, page 48
• Frame Relay, page 50
• HDLC, page 52
• MPLS, page 52
• VPN, page 54
• QoS, page 55
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
27
Cisco 12000 Series Routers
Cisco 12000 Series—Supported Service Events
Table 15 lists the supported service events (also called service alarms) for Cisco 12000 Series routers in
Cisco ANA 3.6.
Table 15 Service Events for Cisco 12000 Series Routers
Event Name Expedited
Primary HSRP interface inactive/
active
Secondary HSRP interface inactive/
active
All ip interfaces down active ip
interfaces found
interface status down/up Y
card in/out Y
link down/up Y
Device Unreachable N
CPU Over Utilized N
Memory Over utilize N
Device Unsupported N
Discard Packets N
Dropped Packets N
Module Unsupported N
Port Flapping N
Port Down Y
Rx Over utilized N
Tx Over utilized N
VPN leak N
Cloud Problem N
Broken LSP discovered N
MPLS Black hole N
Layer 2 Tunnel Down N
MPLS TE Tunnel Down/Flapping N
BGP Neighbor Down N
Card up/down Y
N
N
Y
Support Information for Cisco Routers
28
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Cisco XR 12000 Series Routers
This section includes the following information about Cisco XR 12000 Series routers:
• Cisco XR 12000 Series—Supported Software Versions, page 29
• Cisco XR 12000 Series—Supported Topologies, page 29
• Cisco XR 12000 Series—Supported Modules, page 30
• Cisco XR 12000 Series—Supported Technologies, page 34
• Cisco XR 12000 Series—Supported Service Events, page 34
Cisco XR 12000 Series—Supported Software Versions
Table 16 lists the supported software versions for Cisco XR 12000 Series routers in Cisco ANA 3.6.
Table 16 Supported Software Versions for Cisco XR 12000 Series Routers
Certification
Software Version
IOX 3.4.0 V
IOX 3.4.1 V
IOX 3.4.* S
Level
Cisco XR 12000 Series Routers
Note Software versions marked with an asterisk (representing a wildcard) are supported by Cisco ANA 3.6.
Specific software versions that have been tested and verified are listed individually and marked as V.
Cisco XR 12000 Series—Supported Topologies
The following topologies are supported for Cisco XR 12000 Series routers in Cisco ANA 3.6:
• IP
• MAC
• CDP
• MPLS
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
29
Cisco XR 12000 Series Routers
Cisco XR 12000 Series—Supported Modules
Table 17 lists the supported modules for Cisco XR 12000 Series routers in Cisco ANA 3.6.
Table 17 Supported Modules for Cisco XR 12000 Series Routers
Module Name Module Description
GSR16/80-SFC OC48 Switch Fabric Card for 12016 chassis V
GSR16/80-CSC OC48 Clock Scheduler Card for 12016 chassis V
GSR16-ALRM Cisco 12016 GSR Alarm Card V
8FE-TX-RJ45 8-Port Fast Ethernet Line Card V
8FE-FX-SC 8-Port Fast Ethernet Line Card V
4OC12X/POS-M-SC-B 5 port (Quad) OC-12 POS Card, Single Mode,
Short Reach
OC-48E/POS-SR-SC-B 2 Port Packet Over Sonet OC-48, Single Mode,
Short Reach, SC Connector Card
OC12/SRP-IR-SC-B 2 Port OC-12 Single Mode SRP Intermediate
Reach Line Card
OC12/SRP-MM-SC-B 2 Port OC-12 Multi Mode SRP Line Card V
OC48X/POS-LR-SC One-Port OC-48c/STM-16c POS/SDH ISE Line
Card, Long Reach
4OC12/POS-IR-SC-B Enhanced 4 port OC-12 Intermediate Reach Line
Card
6CT3-SMB 18 Port Copper DS3 Interface Line Card V
12DS3-SMB 24 Port Copper DS3 Interface Line Card V
3GE-GBIC-SC 4 Port Gigabit Ethernet Line Card (trident) V
GSR10-AC-PDU Cisco 12410 AC Power Distribution Unit (spare) V
4OC48E/POS-SR-SC 5 Port (Quad) Enhanced OC-48 Short Reach SC
Connector Line Card
4OC48E/POS-LR-SC 5 Port (Quad) Enhanced OC-48 Long Reach FC
Connector Line Card
PRP-1 Performance Route Processor-1 V
PRP-2 Cisco XR 12000 and 12000 Series Performance
Router Processor-2
OC48X/POS-SR-SC One-Port OC-48c/STM-16c POS/SDH ISE Line
Card, Short Reach
4OC12X/POS-I-SC-B 4 Port OC12 SM Intermediate Reach POS V
16-OC3X/POS-IR-LC 16-Port Packet-Over-SONET OC-3/STM-1 with
Extended Feature Set Line Card (concatenated)
CHOC12/DS1-IR-SC Cisco 12000 Series 1-Port Channelized
OC-12c/STM-4
PRP-3 Performance Route Processor-2 V
Support Information for Cisco Routers
Certification
Level
V
V
V
V
V
V
V
V
V
V
V
30
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Table 17 Supported Modules for Cisco XR 12000 Series Routers (continued)
Module Name Module Description
PRP-4 Cisco XR 12000 and 12000 Series Performance
12000-SIP-401 V
GSR-8FE-FX 8 port Fast Ethernet card with Fiber Interface V
SSRP-OC48-SM-SR 1 Port OC-48 SRP Single Mode Short Reach
SSRP-OC48-SM-LR 1 Port OC-48 SRP Single Mode Long Reach
POS-QOC12-MM-SR 4 port (Quad) OC-12 POS Card, Single Mode,
POS-OC48-SM-SR-SC 1 Port Packet Over Sonet OC-48, Single Mode,
SRP-OC12-SM-IR 1 Port OC-12 Single Mode SRP Intermediate
SRP-OC12-MM 1 Port OC-12 Multi Mode SRP Line Card V
POS-EN-OC48-SR-SC Enhanced OC-48 Short Reach SC Connector
POS-EN-OC48-LR-SC Enhanced OC-48 Long Reach SC Connector
POS-EN-QOC12-IR Enhanced 4 port OC-12 Intermediate Reach Line
COPPER-6DS3 6 Port Copper DS3 Interface Line Card V
COPPER-12DS3 12 Port Copper DS3 Interface Line Card V
GSR-SFC16 Switch Fabric Card V
GSR-CSC16 Scheduler/Fabric Card V
GSR-3GE 3 Port Gigabit Ethernet Line Card (trident) V
GSR-ALARM16 GSR-Alarm V
POS-EN-QOC48-SM-SR-SC 4 Port (Quad) Enhanced OC-48 Short Reach SC
POS-EN-QOC48-SM-LR-SC 4 Port (Quad) Enhanced OC-48 Long Reach SC
POS-EN-QOC48-SM-LR-FC 4 Port (Quad) Enhanced OC-48 Long Reach FC
GSR-SFC16-OC192 GSR 12406 Switch Fabric Card V
GSR-CSC16-OC192 GSR 12406 Clock Scheduler Card V
CPU-GSR-PRP1 V
CPU-GSR-PRP2 V
GSR-RP GSR RoMman Recovery V
GSR-ALARM10 GSR Alarm module V
Cisco XR 12000 Series Routers
Certification
Level
V
Router Processor-3
V
Line Card
V
Line Card
V
Short Reach
V
Short Reach, SC Connector Card
V
Reach Line Card
V
Line Card
V
Line Card
V
Card
V
Connector Line Card
V
Connector Line Card
V
Connector Line Card
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
31
Cisco XR 12000 Series Routers
Table 17 Supported Modules for Cisco XR 12000 Series Routers (continued)
Module Name Module Description
GSR-E48-POS-OC48-SM-SR-SC GSR, Edge Engine 48 Port OC-48 SRP Single
GSR-E48-POS-OC48-SM-LR-SCGSR 12406 Switch Fabric Card V
GSR-E48-POS-QOC12-SM-IR-SC4 Port OC12 SM Intermediate Reach POS V
GSR-E48-POS-16OC3-SM-IR-LC16 Port OC3 SM Intermediate Reach POS V
GSR-SFC6 GSR Switch Fabric Card V
GSR-CSC6 GSR Clock Scheduler V
GSR-ALARM6 GSR Alarm module V
GSR-SFC12410 GSR 12410 Switch Fabric Card V
GSR-CLOCK-OC192 GSR Clock Scheduler V
GSR-CSC12410 GSR 12410 Clock scheduler V
GSR-E-OC192-SM-SR-SC Enhanced 1 Port OC 192 Short Reach 2 FC
GSR-E-QOC48-SM-LR-SC 4 Port Enhanced OC 48 Short Reach SC
GSR-E-QOC48-SM-SR-SC 4 Port Enhanced OC 48 Short Reach SC
GSR-GEFE GSR General Fan V
GSR-PA-3GE GSR 3 port Port Adapter V
GSR-E48-ATM-4OC12-SM-IR-SCGSR Edge Engine 48, ATM, 4 ports
GSR-E48-ATM-4OC12-MM-SR
-SC
GSR-8FE-TX 8 port Fast Ethernet card with Copper Interface V
GSR-8FE-FX 8 port Fast Ethernet card with Fiber Interface V
SSRP-OC48-SM-LR 1 Port OC-48 SRP Single Mode Long Reach
POS-QOC12-MM-SR 1 Port OC-12 Single Mode SRP Intermediate
POS-OC48-SM-SR-SC 1 Port Packet Over Sonet OC-48, Single Mode,
SRP-OC12-SM-IR 1 Port OC-12 Single Mode SRP Intermediate
SRP-OC12-MM 1 Port OC-12 Multi Mode SRP Line Card V
Support Information for Cisco Routers
Mode Long Reach Line Card
Connector Line Card
Connector Line Card
Connector Line Card
OC12/STM4 Single Mode Intermediate Reach
Line Card
GSR Edge Engine 48, ATM, 4 port
OC12/STM4Multi Mode Short Reach Line Card
Line Card
Reach Line Card
Short Reach, SC Connector Card
Reach Line Card
Certification
Level
V
V
V
V
V
V
V
V
V
V
32
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Table 17 Supported Modules for Cisco XR 12000 Series Routers (continued)
Module Name Module Description
POS-EN-OC48-SR-SC Enhanced OC-48 Short Reach SC Connector
POS-EN-OC48-LR-SC Enhanced OC-48 Long Reach SC Connector
POS-EN-QOC12-IR Enhanced 4 port OC-12 Intermediate Reach Line
COPPER-6DS3 6 Port Copper DS3 Interface Line Card V
COPPER-12DS3 12 Port Copper DS3 Interface Line Card V
GSR-SFC16 GSR 12016 Switch Fabric Card V
GSR-CSC16 GSR 12016 Clock Scheduler Card V
GSR-3GE 3 Port Gigabit Ethernet Line Card (trident) V
GSR-ALARM16 GSR Alarm module V
POS-EN-QOC48-SM-SR-SC 4 Port (Quad) Enhanced OC-48 Short Reach SC
GSR-SFC16-OC192 GSR 12016 OC192 Switch Fabric Card V
GSR-CSC16-OC192 GSR 12016 OC192 Clock Scheduler Card V
GSR-SFC GSR Switch Fabric Card V
GSR-CSC GSR Clock Scheduler Card V
SPA-4XCT3/DS0 4-port Channelized T3 to DS0 Shared Port
SPA-1XTENGE-XFP 1-port 10Gigabit Ethernet Shared Port Adapter
SPA-5X1GE 5-Port Gigabit Ethernet SPA S
SPA-5X1GE-V2 5-Port Gigabit Ethernet SPA S
SPA-2X1GE 2 ports Gigabit Ethernet Shared Port Adapters S
SPA-2X1GE-V2 2 ports Gigabit Ethernet Shared Port Adapters S
SPA-2XOC48POS/RPR 2-port OC48/STM16 POS/RPR Shared Port
SPA-1X10GE-L-V2 Cisco 1-Port 10GE LAN-PHY Shared Port
SPA-4XOC12-POS 4-port OC-12/STM-4 POS Shared Port Adapters S
SPA-1XOC48POS/RPR Port OC-48c/STM-16c POS/RPR Shared Port
SPA-2XOC12-POS 2-Port OC-3c/STM-1 and OC-12c/STM-4 POS
SPA-8XOC12-POS 8-Port OC-12c/STM-4 Multirate POS SPA S
SPA-OC192POS-LR 1-port OC192/STM64 POS/RPR SMLR Optics S
SPA-OC192POS-VSR 1-port OC192/STM64 POS/RPR VSR Optics S
Cisco XR 12000 Series Routers
Certification
Level
V
Line Card
V
Line Card
V
Card
V
Connector Line Card
V
Adapter
S
XFP based
S
Adapters
S
Adapter
S
Adapter
S
SPA
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
33
Cisco XR 12000 Series Routers
Table 17 Supported Modules for Cisco XR 12000 Series Routers (continued)
Module Name Module Description
SPA-2XT3/E3 2-port Clear Channel T3/E3 Shared Port Adapter S
SPA-4XT3/E3 4-port Clear Channel T3/E3 Shared Port Adapter S
SPA-8XCHT1/E1 8-port Channelized T1/E1 to DS0 Shared Port
Adapter
SPA-2XCT3/DS0 2-port Channelized T3 to DS0 Shared Port
Adapter
Note For detailed information about the specific technologies and attributes supported by this NE, see
Cisco XR 12000 Series—Supported Technologies, page 34.
Cisco XR 12000 Series—Supported Technologies
Support Information for Cisco Routers
Certification
Level
S
S
The following technologies are supported by the Cisco XR 12000 Series in Cisco ANA 3.6:
• Base Logical Components, page 43
• Layer 1, page 43
• IP, page 44
• Routing Protocols, page 46
• Ethernet (Physical), page 47
• Physical Equipment, page 47
• Ethernet (Logical), page 48
• MPLS, page 52
• VPN, page 54
• QoS, page 55
Cisco XR 12000 Series—Supported Service Events
Table 18 lists the supported service events (also called service alarms) for Cisco XR 12000 Series
routers in Cisco ANA 3.6.
Table 18 Service Events for Cisco XR 12000 Series Routers
34
Event Name Expedited
All ip interfaces down active ip
Y
interfaces found
interface status down/up Y
card in/out Y
link down/up Y
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Table 18 Service Events for Cisco XR 12000 Series Routers (continued)
Event Name Expedited
Device Unreachable N
CPU Over Utilized N
Memory Over utilize N
Device Unsupported N
Discard Packets N
Dropped Packets N
Module Unsupported N
Port Flapping N
Port Down Y
Rx Over utilized N
Tx Over utilized N
VPN leak N
Cloud Problem N
Broken LSP discovered N
MPLS Black hole N
BGP Neighbor Down N
Card up/down Y
Cisco Carrier Routing System (CRS-1) Routers
Cisco Carrier Routing System (CRS-1) Routers
This section includes the following information about Cisco Carrier Routing System (CRS-1) routers:
• Cisco Carrier Routing System (CRS-1)—Supported Software Versions, page 36
• Cisco Carrier Routing System (CRS-1)—Supported Topologies, page 36
• Cisco Carrier Routing System (CRS-1)—Supported Modules, page 36
• Cisco Carrier Routing System (CRS-1)—Supported Technologies, page 40
• Cisco Carrier Routing System (CRS-1)—Supported Service Events, page 40
• Cisco Carrier Routing System (CRS-1)—Additional Information, page 41
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
35
Support Information for Cisco Routers
Cisco Carrier Routing System (CRS-1) Routers
Cisco Carrier Routing System (CRS-1)—Supported Software Versions
Table 19 lists the supported software versions for Cisco Carrier Routing System (CRS-1) routers in
Cisco ANA 3.6.
Table 19 Supported Software Versions for Cisco Carrier Routing System (CRS-1) Routers
Certification
Software Version
IOX 3.4.0 V
IOX 3.4.1 V
IOX 3.4.* S
Note Software versions marked with an asterisk (representing a wildcard) are supported by Cisco ANA 3.6.
Specific software versions that have been tested and verified are listed individually and marked as V.
Level
Cisco Carrier Routing System (CRS-1)—Supported Topologies
The following topologies are supported for Cisco Carrier Routing System (CRS-1) routers in
Cisco ANA 3.6:
• IP
• MAC
• CDP
• MPLS
Cisco Carrier Routing System (CRS-1)—Supported Modules
Table 20 lists the supported modules for Cisco Carrier Routing System (CRS-1) routers in
Cisco ANA 3.6.
Table 20 Supported Modules for Cisco Carrier Routing System (CRS-1) Routers
Module Name Module Description
CRS-16-LCC 16 slots Line Card Chassis V
CRS-8-LCC 8 slots Line Card Chassis V
CRS-4-CH 4 slots Chassis V
8-10GbE 8x10 Gigabite Ethernet port V
CRS-16-RP Module Crs1 16 slots RP V
CRS-16-RP-B Module Crs1 16 slots RP - B V
CRS-8-RP Module Crs1 8 slots RP V
CRS1-SIP-800 Module Crs1 SPA Interface Card V
Certification
Level
36
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Table 20 Supported Modules for Cisco Carrier Routing System (CRS-1) Routers (continued)
Module Name Module Description
SPA-8X1GE 8-port Gigabit Ethernet Shared Port Adapter V
SPA-8X1GE-V2 8-port Gigabit Ethernet Shared Port Adapter V
16OC48-POS/DPT Cisco CRS-1 Series 16xOC48/STM16
CRS-8-FC/S Cisco CRS-1 Series 8 Slots Fabric Card Single V
CRS-FCC Cisco CRS-1 Series Fabric Card Chassis Only V
CRS-16-FC/M Cisco CRS-1 Series 16 Slots Fabric Card / Multi V
CRS-16-FC/S Cisco CRS-1 Series 16 Slots Fabric Card Single V
CRS-16-LCC-FAN-CT Cisco CRS-1 Series LC Chassis Fan Controler V
CRS-16-ALARM Cisco CRS-1 Series 16 Slots Alarm V
CRS-DRP-CPU Cisco CRS-1 Series Distributed Route Processor V
CRS-DRP-B-CPU Cisco CRS-1 Series Distributed Route Processor V
CRS-DRP-PLIM Cisco CRS-1 Series Distributed Route Processor
CRS-DRP-B-PLIM Cisco CRS-1 Series Distributed Route Processor
CRS-MSC Cisco CRS-1 Series Modular Service Card V
CRS-MSC-B Cisco CRS-1 Series Modular Service Card V
4OC192-POS/DPT-IR Cisco CRS-1 Series 4xOC192/STM64
4OC192-POS/DPT-SR Cisco CRS-1 Series 4xOC192/STM64
4OC192-POS/DPT-LR 4OC192-POS DPT V
4OC192-POS/DPT-VS 4OC192-POS DPT V
4-10GE-ITU/C Module Crs1 4x10 Ge CDwdm Plim V
SPA-4XOC3-POS 4-Port OC-3c/STM-1 POS SPA V
SPA-4XOC3-POS-V2 4-Port OC-3c/STM-1 POS SPA V
SPA-OC192POS-XFP 1-port OC192/STM64 POS/RPR XFP Optics V
SPA-8XOC3-POS 8-Port OC-3c/STM-1 POS SPA V
1OC768-ITU/C 1 port OC768-POS-DWDM Plim V
CRS-FCC-SFC Switch fabric card (fabric card chassis) S2
CRS-FCC-LED Fiber module LED card S
CRS-16-LCC-PS-ACD AC Delta power shelf for line card chassis S
CRS-16-LCC-PS-ACW AC Wye power shelf for line card chassis S
CRS-16-LCC-PS-DC DC power shelf for line card chassis S
Cisco Carrier Routing System (CRS-1) Routers
Certification
Level
V
POS/DPT Interface Module
V
Front Accsry
V
Front Accsry
V
POS/DPT Interface Module/IR
V
POS/DPT Interface Module/SR
S
switch fabric cards
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
37
Cisco Carrier Routing System (CRS-1) Routers
Table 20 Supported Modules for Cisco Carrier Routing System (CRS-1) Routers (continued)
Module Name Module Description
CRS-16-AC-RECT Cisco CRS-1 Series AC Pwr Rectifier for 16 slot
CRS-16-DC-PEM DC power entry module for line card chassis S
CRS-8-AC-RECT Cisco CRS-1 AC rectifier module S
CRS-8-DC-PEM DC power entry module for line card chassis S
CRS-8-LCC-ACD Power Supply Crs 1 8 Slots AC Delta S
CRS-8-LCC-ACW Power Supply Crs 1 8 Slots ACW S
CRS-8-LCC-DC Cisco CRS-1 Series 8 slots with redundant DC
CRS-8-LCC-PDU-ACD Cisco CRS-1 Series AC Delta PDU for CRS-8
CRS-8-LCC-PDU-ACW AC Wye PDU S
CRS-8-LCC-PDU-DC DC PDU S
CRS-FCC-PS-ACD CRS-1 Fabric Chassis AC Delta Power Supply S
CRS-FCC-PS-ACW CRS-1 Fabric Chassis AC Wye Option S
CRS-FCC-PS-DC DC power shelf S
CRS-4-AC-SHELF AC Power shelf S
CRS-4-DC-INPUT DC power input shelf S
CRS-4-DC-SUPPLY DC power supplies S
CRS-4-AC-SUPPLY AC power supplies S
CRS-FCC-FAN-TR Cisco CRS-1 FCC fan tray with fans S
CRS-16-LCC-FAN-TR Cisco CRS-1 16 Slots FCC fan tray with fans S
CRS-8-LCC-FAN-TR Cisco CRS-1 8 Slots FCC fan tray with fans S
CRS-4-FAN-TR Cisco CRS-1 4 Slots FCC fan tray with fans S
SPA-10X1GE 10-Port Gigabit Ethernet SPA S
SPA-10X1GE-V2 10-Port Gigabit Ethernet SPA S
SPA-1XTENGE-XFP 1-port 10 Gigabit Ethernet Shared Port Adapter
SPA-5X1GE 5-Port Gigabit Ethernet SPA S
SPA-5X1GE-V2 5-Port Gigabit Ethernet SPA S
SPA-2X1GE 2 ports Gigabit Ethernet Shared Port Adapters S
SPA-2X1GE-V2 2 ports Gigabit Ethernet Shared Port Adapters S
SPA-2XOC48POS/RPR 3 Ports OC-48c/STM-16c POS/RPR Shared Port
SPA-1X10GE-L-V2 Cisco 1-Port 10GE LAN-PHY Shared Port
Support Information for Cisco Routers
Certification
Level
S
LCC and FCC
S
power
S
LCC
S
XFP based
S
Adapter
S
Adapter
38
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Table 20 Supported Modules for Cisco Carrier Routing System (CRS-1) Routers (continued)
Module Name Module Description
SPA-4XOC12-POS 4-Port OC-3c/STM-1 and OC-12c/STM-4 POS
SPA-1XOC48POS/RPR Port OC-48c/STM-16c POS/RPR Shared Port
SPA-4XOC48POS/RPR Port OC-48c/STM-16c POS/RPR Shared Port
CRS-FCC-SC/GEW Module Crs 1 Fcc SC Ge S
SPA-2XOC12-POS 2-Port OC-3c/STM-1 and OC-12c/STM-4 POS
SPA-8XOC12-POS 8-Port OC-12c/STM-4 Multirate POS SPA S
SPA-OC192POS-LR 1-PORT OC-192C/STM-64C POS/RPR
SPA-OC192POS-VSR 1-PORT OC-192C/STM-64C POS/RPR
SPA-2XT3/E3 2-Port T3/E3 Serial SPA S
SPA-4XT3/E3 4-Port T3/E3 Serial SPA S
SPA-8XCHT1/E1 8-Port Channelized T1/E1 SPA S
SPA-2XCT3/DS0 2-Port Channelized T3 SPA S
CRS-FCC-SC Module Crs 1 16 mS 2 Fan Ctrllrer Fabric S
CRS-4-FC CRS-1 4-Slot Fabric Card S
1OC768-POS-SR 1-port OC-768c/STM-256c PLIM, with
CRS-FCC-OIM-1S Optical single interface module (OIM) S
CRS-FCC-FM-2S Optical dual interface module (OIM) S
CRS-FCC-SC-22GE CRS-1 fan controllers S
CRS-FCC-SC-GE 2-port Shelf controller Gigabit Ethernet S
4OC192-ITU/C Module Crs 1 4 ports OC192 C Dwdm Plim S
CRS-8-FC/D S
CRS-8-FC/M S
CRS-16-FC/D S
Cisco Carrier Routing System (CRS-1) Routers
Certification
Level
S
SPA
S
Adapter
S
Adapter
S
SPA
S
SHARED PORT ADAPTER
S
SHARED PORT ADAPTER
Cpu Crs 1 Asmp Route S
Cpu Crs 1 Dsmp Route S
Cpu Crs 1 SPFC S
S
short-reach optics (POS)
OL-14112-01
Note For detailed information about the specific technologies and attributes supported by this NE, see Cisco
Carrier Routing System (CRS-1)—Supported Technologies, page 40.
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
39
Support Information for Cisco Routers
Cisco Carrier Routing System (CRS-1) Routers
Cisco Carrier Routing System (CRS-1)—Supported Technologies
The following technologies are supported by the Cisco Carrier Routing System (CRS-1) in
Cisco ANA 3.6:
• Base Logical Components, page 43
• Layer 1, page 43
• IP, page 44
• Routing Protocols, page 46
• Ethernet (Physical), page 47
• Physical Equipment, page 47
• Ethernet (Logical), page 48
• MPLS, page 52
• VPN, page 54
• QoS, page 55
Cisco Carrier Routing System (CRS-1)—Supported Service Events
Table 21 lists the supported service events (also called service alarms) for Cisco Carrier Routing System
(CRS-1) routers in Cisco ANA 3.6.
Table 21 Service Events for Cisco Carrier Routing System (CRS-1) Routers
Event Name Expedited
All ip interfaces down active ip
interfaces found
interface status down/up Y
card in/out Y
link down/up Y
Device Unreachable N
CPU Over Utilized N
Memory Over utilize N
Device Unsupported N
Discard Packets N
Dropped Packets N
Module Unsupported N
Port Flapping N
Port Down Y
Rx Over utilized N
Tx Over utilized N
VPN leak N
Cloud Problem N
Y
40
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Cisco Carrier Routing System (CRS-1) Routers
Table 21 Service Events for Cisco Carrier Routing System (CRS-1) Routers (continued)
Event Name Expedited
Broken LSP discovered N
MPLS Black hole N
BGP Neighbor Down N
Card up/down Y
Cisco Carrier Routing System (CRS-1)—Additional Information
This section contains additional information about the Cisco Carrier Routing System (CRS-1) and
includes the following topics:
• Cisco Carrier Routing System (CRS-1) Prerequisite, page 41
• SDR Support for CRS-1, page 41
Cisco Carrier Routing System (CRS-1) Prerequisite
As a prerequisite for the CRS-1 VNE, install the Cisco IOS XR Manageability Package on top of the
IOS-XR version. In addition, the device configuration must contain the command, xml agent tty.
When creating the SNMP community, the SystemOwner should be specified.
SDR Support for CRS-1
Secure Domain Router (SDR) is supported as a separate independent VNE, with its own IP and login
sequence. When adding a SDR to Cisco ANA it is treated like any other network element, namely,
it is added as a new VNE using Cisco ANA Manage. The SDR IP address is attached to the active
DRP of the SDR (or the virtual IP, if it exists).
As a prerequisite for the CRS-1 VNE, install the Cisco IOS XR Manageability Package on top of
the IOS-XR version (XR 3.4 and 3.4.1). In addition, the device configuration must contain the
command, xml agent tty and when creating the SNMP community the SystemOwner should be
specified.
The IP address, snmp read community and telnet login sequence must be defined.
Cisco ANA uses the management network (if available) to manage the devices. The CRS platform
assigns specific management interfaces on the RP modules (DRP in the case of SDR). In order to
retrieve the IP address of these management interfaces, login to the device and run the command
show ipv4 interface brief | include Mgmt as shown in the example:
RP/0/RP1/CPU0:P1_CRS8#show ipv4 interface brief | include Mgmt
MgmtEth0/RP1/CPU0/0 1.60.34.104 Up Up
MgmtEth0/4/CPU0/0 unassigned Shutdown Down
MgmtEth0/4/CPU1/0 unassigned Shutdown Down
OL-14112-01
In a multiple (D)RP environments there is an option to configure a virtual management interface and
assign an IP address to it, so that the device is reachable via the same IP address no matter which
(D)RP is active. In such an environment, each (D)RP has its own IP address but it is not used in order
to access the device.
In order to get the virtual IP address, login to the device and run the command
ipv4 virtual address
as shown in the example:
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
show running-config
41
DRP/0/3/CPU0:CRS-PE1#show running-config ipv4 virtual address
ipv4 virtual address 10.52.123.11 255.255.255.0
If the SDR is managed in-band the management IP address should be supplied by the customer.
The owner SDR (namely, the main router) presents all the modules that are installed on the chassis,
excluding the ports that belong to other SDRs.
The VNE of the SDR only displays the modules that are associated with the SDR in the Inventory
window of Cisco ANA NetworkVision, it does not display the fabric, fan and power supply (namely,
the shared modules).
Supported Technologies on Cisco Routers
Support Information for Cisco Routers
The following sections list the objects and attributes that are supported on Cisco routers in
Cisco ANA 3.6 per technology:
• Base Logical Components, page 43
• Layer 1, page 43
• IP, page 44
• Routing Protocols, page 46
• Ethernet (Physical), page 47
• Physical Equipment, page 47
• Ethernet (Logical), page 48
• ATM, page 48
• Frame Relay, page 50
• HDLC, page 52
• MPLS, page 52
• VPN, page 54
• QoS, page 55
• Q-in-Q (Switch Port), page 56
• Q-in-Q (Routed Switch), page 57
• STP, page 57
42
Note For more information about the objects and attributes described in this chapter, see Cisco Active Network
Abstraction Technology Support and Information Model Reference Manual, Version 3.6.
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Base Logical Components
Table 22 summarizes base logical component support on Cisco routers in Cisco ANA 3.6.
Table 22 Base Logical Component Support on Cisco Routers
Supported Technologies on Cisco Routers
Attribute Scheme Polling Interval
Managed Element Object (IMO Name—IManagedElement)
7200
7600
12000
XR 12000
CRS-1
I P A d d r e s s P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
C o m m u n i c a t i o n S t a t eP r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
I n v e s t i g a t i o n S t a t e P r o d u c t / I P - C o r e YYYYY
E l e m e n t C a t e g o r y P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
E l e m e n t T y p e a n d K e yP r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
D e v i c e N a m e P r o d u c t / I P - C o r e YYYYY
S y s t e m N a m e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
S y s t e m D e s c r i p t i o n P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
U p T i m e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
S o f t w a r e V e r s i o n P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
V e n d o r I d e n t i t y P r o d u c t / I P - C o r e YYYYY
Memory and CPU
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Usage
A g e n t M e m o r y P r o d u c t / I P - C o r e YYYYY
Number of Device
Components
Number of Logical
Entries
Layer 1
Table 23 summarizes Layer 1 attribute support on Cisco routers in Cisco ANA 3.6.
Table 23 Layer 1 Attribute Support on Cisco Routers
Attribute Scheme Polling Interval
Physical Layer Object (IMO Name—IPhysicalLayer)
M e d i a T y p e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
C l o c k i n g S o u r c e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
M a x i m u m S p e e d P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
I s I n t e r n a l P o r t P r o d u c t / I P - C o r e YYYYY
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
7200
7600
12000
XR 12000
CRS-1
43
Supported Technologies on Cisco Routers
Table 23 Layer 1 Attribute Support on Cisco Routers (continued)
Support Information for Cisco Routers
Attribute Scheme Polling Interval
Maximum and
P r o d u c t / I P - C o r e YYYYY
7200
7600
12000
XR 12000
CRS-1
Minimum Discarded
Thresholds
Discarded Bandwidth
Maximum and
P r o d u c t / I P - C o r e YYYYY
Minimum Dropped
Thresholds
Dropped Bandwidth
Maximum and
P r o d u c t / I P - C o r e YYYYY
Minimum Input
Threshold
Input Bandwidth
Maximum and
P r o d u c t / I P - C o r e YYYYY
Minimum Output
Thresholds
Output Bandwidth
Discarded and Received
Input Data Counters
Product/IP-Core Topology
Layer 1
YYYYY
Counters
Dropped and Forward
Output Data Counters
Product/IP-Core Topology
Layer 1
YYYYY
Counters
A d m i n i s t r a t i v e S t a t u sP r o d u c t / I P - C o r eS t a t u s YYYYY
O p e r a t i o n a l S t a t u s P r o d u c t / I P - C o r eS t a t u s YYYYY
Last Changed Product/IP-Core Configuration Y Y
I A N A T y p e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
IP
Table 24 summarizes IP attribute support on Cisco routers in Cisco ANA 3.6.
Table 24 IP Attribute Support on Cisco Routers
Attribute Scheme Polling Interval
IP Interface Object (IMO Name—IIPInterface)
I P A d d r e s s P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
S u b n e t w o r k M a s k P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
I P I n t e r f a c e A d d r e s s e sP r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
44
7200
7600
12000
XR 12000
CRS-1
OL-14112-01
Support Information for Cisco Routers
Table 24 IP Attribute Support on Cisco Routers (continued)
Supported Technologies on Cisco Routers
Attribute Scheme Polling Interval
7200
7600
12000
XR 12000
CRS-1
I n t e r f a c e N a m e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
I n t e r f a c e D e s c r i p t i o nP r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
I P I n t e r f a c e S t a t e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
OSPF Interface Cost Y
Broadcast Address Y
MTU Y Y
Lookup Method
Address Resolution
Type
ARP Timeout
Secured ARP
ICMP Mask Reply
IGMP Proxy
H S R P G r o u p s P r o d u c t / I P - C o r e YYYYY
IP Multiplexing Table
IANA Type
Routing Entry Object (IMO Name—IRoutingEntry)
D e s t i n a t i o n I P S u b n e tP r o d u c t C o n f i g u r a t i o n YYYYY
N e x t H o p I P A d d r e s sP r o d u c t C o n f i g u r a t i o n YYYYY
T y p e P r o d u c t C o n f i g u r a t i o n YYYYY
R o u t i n g P r o t o c o l T y p eP r o d u c t C o n f i g u r a t i o n YYYYY
Outgoing Interface
P r o d u c t C o n f i g u r a t i o n YYYYY
Name
ARP Entry Object (IMO Name—IARPEntry)
I P A d d r e s s P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
M A C A d d r e s s P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
P o r t P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
E n t r y T y p e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
HSRP Group Entry Object (IMO Name—HSRPGroupEntry)
Group Number Product/IP-Core Configuration Y Y Y
Port Description Product/IP-Core Configuration Y Y Y
Priority Product/IP-Core Configuration Y Y Y
Coupled Router Product/IP-Core Configuration Y Y Y
State Product/IP-Core Configuration Y Y Y
Tracking Interfaces
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
45
Supported Technologies on Cisco Routers
Table 24 IP Attribute Support on Cisco Routers (continued)
Support Information for Cisco Routers
Attribute Scheme Polling Interval
7200
7600
12000
XR 12000
CRS-1
Virtual IP Address Product/IP-Core Configuration Y Y Y
Virtual MAC Address Product/IP-Core Configuration Y Y Y
Routing Protocols
Table 25 summarizes routing protocol attribute support on Cisco routers in Cisco ANA 3.6.
Table 25 Routing Protocol Attribute Support on Cisco Routers
Attribute Scheme Polling Interval
BGP Neighbor Entry Object (IMO Name—IBgpNeighborEntry)
R e m o t e I d e n t i f i e r P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Neighbor Type Y
Distributing Interfaces Y Y
R e m o t e A d d r e s s P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Remote Autonomous
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
System
S t a t u s P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
H o l d T i m e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
K e e p A l i v e T i m e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
OSPF Entry Object (IMO Name—IOspfEntry)
A r e a I d e n t i f i e r P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
I P A d d r e s s P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
T y p e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
A d m i n i s t r a t i v e S t a t u sP r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
O p e r a t i o n a l S t a t u s P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
7200
7600
12000
XR 12000
CRS-1
46
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Ethernet (Physical)
Table 26 summarizes support for physical Ethernet attributes on Cisco routers in Cisco ANA 3.6.
Table 26 Ethernet Physical Attribute Support on Cisco Routers
Supported Technologies on Cisco Routers
Attribute Scheme Polling Interval
Ethernet Channel Object (IMO Name—IEthernetChannel)
7200
7600
12000
XR 12000
CRS-1
C h a n n e l G r o u p P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Channel Bandwidth Product/IP-Core Configuration Y
I A N A T y p e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Ethernet Interface Object (IMO Name—IEthernet)
M A C A d d r e s s P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Duplex Mode
Output Flow Control
Input Flow Control
IANA Type Product/IP-Core Configuration Y Y Y Y
Physical Equipment
Table 27 summarizes physical equipment support on Cisco routers in Cisco ANA 3.6.
Table 27 Physical Equipment Support on Cisco Routers
Attribute Scheme Polling Interval
Module/Board Object (IMO Name—Imodule)
7200
7600
12000
XR 12000
CRS-1
M o d u l e N a m e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
M o d u l e D e s c r i p t i o n P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
S o f t w a r e V e r s i o n P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
O p e r a t i o n a l S t a t u s P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Hardware Type &
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Ve rs i on
Managed IP Address
Redundant Equipment Y Y Y
Configured
YYY
Redundancy
R e d u n d a n c y S t a t u s YYYY
Operational Status Last
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Changed
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
47
Supported Technologies on Cisco Routers
Table 27 Physical Equipment Support on Cisco Routers (continued)
Support Information for Cisco Routers
Attribute Scheme Polling Interval
Supported Physical
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
7200
7600
12000
XR 12000
CRS-1
Termination Points
Serial Number (soft
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
property)
Chassis Object (IMO Name—Ichassis)
Equipment Holder Type Product/IP-Core Y Y Y
Description Y Y
Serial Number Product/IP-Core Configuration Y Y
Ethernet (Logical)
Table 28 summarizes support for logical Ethernet attributes on Cisco routers in Cisco ANA 3.6.
Table 28 Ethernet Logical Attribute Support on Cisco Routers
Attribute Scheme Polling Interval
VLAN Encapsulation Object (IMO Name—IIEEE802)
V L A N I d e n t i f i c a t i o nP r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Binding Information
Binding Status
I A N A T y p e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Bridging Entry Object (IMO Name—IBridgeEntry)
Destination MAC
Y
Address
Outgoing Interface Y
7200
7600
12000
XR 12000
CRS-1
ATM
Table 29 summarizes support for Asynchronous Transfer Mode (ATM) attributes on Cisco routers in
Cisco ANA 3.6.
Table 29 ATM Attribute Support on Cisco Routers
Attribute Scheme Polling Interval
ATM Interface Object (IMO Name—IAtm)
ATM Address
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
48
7200
7600
12000
XR 12000
CRS-1
OL-14112-01
Support Information for Cisco Routers
Table 29 ATM Attribute Support on Cisco Routers (continued)
Supported Technologies on Cisco Routers
Attribute Scheme Polling Interval
7200
7600
12000
XR 12000
Interface Type Y Y
VP and VC Ranges Status
V C T a b l e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Cross-Connect Table
IANA Type Product/IP-Core Y Y
ATM VC Object (IMO Name—IAtmVc)
Virtual Chann el
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Identifier
V i r t u a l P a t h I d e n t i f i e rP r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Shaping Profile
Discarded and Received
Input Data Counters
Product/IP-Core Topology
Layer 2
YYYY
Counters
Dropped and Forward
Output Data Counters
Product/IP-Core Topology
Layer 2
YYYY
Counters
Ingress Traffic
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Descriptor
Egress Traffic
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Descriptor
A d m i n i s t r a t i v e S t a t u sP r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
O p e r a t i o n a l S t a t u s P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
IANA Type Y Y
Virtual Connection Encapsulation Object (IMO Name—IVcBasedEncapsulation)
Virtual Connection
Interface
Binding Information
B i n d i n g S t a t u s P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
I A N A T y p e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
ATM Traffic Descriptor Object (IMO Name—IAtmTrafficDescriptor)
T r a f f i c D e s c r i p t o r T y p e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
S e r v i c e C a t e g o r y P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
C e l l L o s s P r i o r i t y P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Cell Delay Variation
Cell Delay Variation
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Toleranc e
CRS-1
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
49
Supported Technologies on Cisco Routers
Table 29 ATM Attribute Support on Cisco Routers (continued)
Support Information for Cisco Routers
Attribute Scheme Polling Interval
Maximum High Priority
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
7200
7600
12000
XR 12000
and Aggregate Burst
Rates
Minimum High Priority
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
and Aggregate Cell
Rates
Sustainable High
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Priority and Aggregate
Cell Rates
Peak High Priority and
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Aggregate Cell Rates
Name
I n d e x YYYY
ATM Access Traffic Descriptor Object (IMO Name—IAtmAccessTrafficDescriptor)
Scope
Maximum Active VPCs
and VCCs
Maximum Supported
VPI and VCI Bits
Generic Flow Control
Mode
Police Mode
Name
Index
ATM Logical Interface Object (IMO Name—IAtmLogicalPort/Trunk)
Same as ATM interface Product/IP-Core Status
CRS-1
Frame Relay
Table 30 summarizes support for Frame Relay attributes on Cisco routers in Cisco ANA 3.6.
Table 30 Frame Relay Attribute Support on Cisco Routers
Attribute Scheme Polling Interval
Frame Relay Interface Object (IMO Name—Iframerelay/IFrTrunk)
Address Format
Maximum Supported
VCs
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
50
7200
7600
12000
XR 12000
CRS-1
OL-14112-01
Support Information for Cisco Routers
Table 30 Frame Relay Attribute Support on Cisco Routers (continued)
Supported Technologies on Cisco Routers
Attribute Scheme Polling Interval
7200
7600
12000
XR 12000
P r o t o c o l T y p e P r o d u c t / I P - C o r e YYYY
VC Table Product/IP-Core Y Y Y
Cross-Connect Table
IANA Type
Frame Relay VC Object (IMO Name—IFrVc)
Data Link Connection
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Identifier
T r a f f i c D e s c r i p t o r P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Discard and Received
Input Data Counters
Dropped and Forward
Output Data Counters
Ingress Traffic
YYYY
Descriptor
Egress Traffic
YYYY
Descriptor
A d m i n i s t r a t i v e S t a t u sP r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
O p e r a t i o n a l S t a t u s P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
IANA Type Product/IP-Core Y
Frame Relay Traffic Descriptor Object (IMO Name—IFRTrafficDescriptor)
Committed Rate Product/IP-Core Configuration YYYY
E x c e s s B u r s t R a t e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYY
Name
Index
Frame Relay Logical Interface Object (IMO Name—IFramerelayLogicalPort/Trunk)
Same as IFrameRelay Product/IP-Core Configuration Y Y
CRS-1
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
51
Supported Technologies on Cisco Routers
HDLC
Table 31 summarizes support for High-Level Data Link Control (HDLC) attributes on Cisco routers in
Cisco ANA 3.6.
Table 31 HDLC Attribute Support on Cisco Routers
Support Information for Cisco Routers
Attribute Scheme Polling Interval
High Level Data Link Control Encapsulation Object (IMO Name—IEncapsulation)
Virtual Connection
P r o d u c t / I P - C o r e YYYY
7200
7600
12000
XR 12000
CRS-1
Interface
Binding Information
B i n d i n g S t a t u s P r o d u c t / I P - C o r e YYYY
I A N A T y p e P r o d u c t / I P - C o r e YYYY
MPLS
Table 32 summarizes support for Multiprotocol Label Switching (MPLS) attributes on Cisco routers in
Cisco ANA 3.6.
Table 32 MPLS Attribute Support on Cisco Routers
Attribute Scheme Polling Interval
MPLS Interface Object (IMO Name—IMpls)
D i s t r i b u t i o n P r o t o c o lI P - C o r e YYYYY
Outer and Inner Labels Y
Traffic Engineering
I P - C o r e C o n f i g u r a t i o n YYYY
Properties
Resource Reservation
Properties
I A N A T y p e A u t o YYYY
MPLS TE Tunnel Interface Object (IMO Name—IMplsTETunnel)
Destination Address IP-Core Configuration Y Y Y
Outgoing Interface and
IP-Core Configuration Y Y Y
Label
Path Identification IP-Core Configuration Y Y Y
Requested Bandwidth IP-Core Configuration Y Y Y
Measured Average
IP-Core Configuration Y Y Y
Burst and Peak
Bandwidth
Setup and Hold Priority IP-Core Configuration Y Y Y
7200
7600
12000
XR 12000
CRS-1
52
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Table 32 MPLS Attribute Support on Cisco Routers (continued)
Supported Technologies on Cisco Routers
Attribute Scheme Polling Interval
7200
7600
Affinity Bits and Mask IP-Core Configuration Y Y Y
Automatic Route
IP-Core Configuration Y Y Y
Announcement Status
Optimization Lock
IP-Core Configuration Y Y Y
Down Status
Path Option IP-Core Configuration Y Y Y
Name IP-Core Configuration Y Y Y
Description IP-Core Configuration Y Y Y
Administrative Status IP-Core Configuration Y Y Y
Operational Status IP-Core Configuration Y Y Y
IANA Type Auto Y Y
Point-to-Point Layer 2 MPLS Tunnel Interface Object (IMO Name—IPTPLayer2MplsTunnel)
Local and Remote
IP-Core Configuration Y Y Y
Router Addresses
Local and Remote
IP-Core Configuration Y Y Y
Virtual Connection
Labels
Tunnel Identification IP-Core Configuration Y Y Y
Tunnel Status IP-Core Configuration Y Y Y
Local and Remote
Tunnel Interface
IANA Type Auto Y Y
MPLS TE Object (IMO Name—IMplsTEProperties)
Administrative Weight IP-Core Configuration Y Y Y
Attributes Identifier
Signaling Protocol IP-Core Configuration Y Y Y
Available Physical and
IP-Core Configuration Y Y Y
Reservable Bandwidth
Reserved Bandwidth IP-Core Configuration Y Y Y
MPLS TE Allocation Entry Object (IMO Name—IMplsTEPropertiesAllocationEntry)
Priority Level
Allocated and
Cumulative Bandwidth
RSVP Properties Object (IMO Name—IRsvpProperties)
Allocated Bandwidth
12000
XR 12000
CRS-1
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
53
Supported Technologies on Cisco Routers
Table 32 MPLS Attribute Support on Cisco Routers (continued)
Support Information for Cisco Routers
Attribute Scheme Polling Interval
7200
7600
12000
XR 12000
CRS-1
Maximum Per Flow and
Total Allowed
Bandwidth
LSE Entry Object (IMO Name—ILSEEntry)
I n c o m i n g L a b e l I P - C o r e C o n f i g u r a t i o n YYYYY
Outgoing Interface and
I P - C o r e C o n f i g u r a t i o n YYYYY
Label
S w i t c h i n g A c t i o n I P - C o r e C o n f i g u r a t i o n YYYYY
N e x t H o p I P A d d r e s sI P - C o r e C o n f i g u r a t i o n YYYYY
MPLS Aggregate Entry Object (IMO Name—IMplsAggregateEntry)
V i r t u a l R o u t i n g E n t i t yI P - C o r e C o n f i g u r a t i o n YYYYY
I n c o m i n g L a b e l I P - C o r e C o n f i g u r a t i o n YYYYY
Outgoing Interface and
I P - C o r e C o n f i g u r a t i o n YYYYY
Label
S w i t c h i n g A c t i o n I P - C o r e C o n f i g u r a t i o n YYYYY
N e x t H o p I P A d d r e s sI P - C o r e C o n f i g u r a t i o n YYYYY
MPLS TE Tunnel Segment Object (IMO Name—IMplsTESegment)
Segment Type IP-Core Configuration Y Y Y
Measured Average
IP-Core Configuration Y Y Y
Burst and Peak
Bandwidth
Path Identification IP-Core Configuration Y Y Y
Name IP-Core Configuration Y Y Y
VPN
Table 33 summarizes support for virtual private network (VPN) attributes on Cisco routers in
Cisco ANA 3.6.
Table 33 VPN Attribute Support on Cisco Routers
Attribute Scheme Polling Interval
VRF Entity Object (IMO Name—IVrf)
N a m e I P - C o r e C o n f i g u r a t i o n YYYYY
R o u t e D i s t i n g u i s h e r I P - C o r e C o n f i g u r a t i o n YYYYY
Virtual Routing Entry Object (IMO Name—IVrfEntry)
N e x t H o p B G P A d d r e s s I P - C o r e C o n f i g u r a t i o n YYYYY
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
54
7200
7600
12000
XR 12000
CRS-1
OL-14112-01
Support Information for Cisco Routers
Table 33 VPN Attribute Support on Cisco Routers (continued)
Supported Technologies on Cisco Routers
Attribute Scheme Polling Interval
Incoming and Outgoing
I P - C o r e C o n f i g u r a t i o n YYYYY
7200
7600
12000
XR 12000
CRS-1
Inner Label
O u t e r L a b e l I P - C o r e C o n f i g u r a t i o n YYYYY
D e s t i n a t i o n I P S u b n e tI P - C o r e C o n f i g u r a t i o n YYYYY
N e x t H o p I P A d d r e s sI P - C o r e C o n f i g u r a t i o n YYYYY
T y p e I P - C o r e C o n f i g u r a t i o n YYYYY
R o u t i n g P r o t o c o l T y p eI P - C o r e C o n f i g u r a t i o n YYYYY
Outgoing Interface
I P - C o r e C o n f i g u r a t i o n YYYYY
Name
Multi-Protocol BGP Entity Object (IMO Name—IMpBgp)
B G P I d e n t i f i e r I P - C o r e C o n f i g u r a t i o n YYYYY
Local Autonomous
I P - C o r e C o n f i g u r a t i o n YYYYY
System
Cross Virtual Routing Object (IMO Name—ICrossVrfRoutingEntry)
Outgoing Virtual
Routing Entity
Identifier
Incoming and Outgoing
Virtual Routing Tags
D e s t i n a t i o n I P S u b n e tP r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
N e x t H o p I P A d d r e s sP r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
T y p e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
R o u t i n g P r o t o c o l T y p eP r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Outgoing Interface
Name
QoS
Table 34 summarizes support for quality of service (QoS) attributes on Cisco routers in Cisco ANA 3.6.
Table 34 QoS Attribute Support on Cisco Routers
Attribute Scheme Polling Interval
Access List Entry Object (IMO Name—IAccessListEntry)
E n t r y I d e n t i f i c a t i o n P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
A c t i o n L o g i c P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
7200
7600
12000
XR 12000
CRS-1
55
Supported Technologies on Cisco Routers
Table 34 QoS Attribute Support on Cisco Routers (continued)
Support Information for Cisco Routers
Attribute Scheme Polling Interval
Source and Destination
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
7200
7600
12000
XR 12000
CRS-1
Address
Source and Destination
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Wildcard
P r o t o c o l T y p e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Source and Destination
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Port Ranges
Source and Destination
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Port Action
P r o t o c o l S p e c i f i c I n f oP r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Differential Services
P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Code Points
T y p e o f S e r v i c e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
P r e c e d e n c e P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
M a t c h e s P r o d u c t / I P - C o r eC o n f i g u r a t i o n YYYYY
Q-in-Q (Switch Port)
Table 35 summarizes support for Q-in-Q (also known as stacked VLAN) switch port attributes on Cisco
routers in Cisco ANA 3.6.
Table 35 Q-in-Q Switch Port Attribute Support on Cisco Routers
Attribute Scheme Polling Interval
VLAN Interface Object (IMO Name—IVlanInterface)
7200
Mode Product/IP-Core Configuration Y
Native Identification Product/IP-Core Configuration Y
Customer Edge
Identification
Service Provider
Identification
VLAN Table
IANA Type
VLAN Entry Object (IMO Name—IVlanEntry)
Identification Product/IP-Core Configuration Y
Encapsulation Type Product/IP-Core Configuration Y
7600
12000
XR 12000
CRS-1
56
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
Support Information for Cisco Routers
Q-in-Q (Routed Switch)
Table 36 summarizes support for Q-in-Q (also known as stacked VLAN) routed switch attributes on
Cisco routers in Cisco ANA 3.6.
Table 36 Q-in-Q Routed Switch Attribute Support on Cisco Routers
Supported Technologies on Cisco Routers
Attribute Scheme Polling Interval
VLAN Multiplexer Object (IMO Name—IVlanEncapMux)
7200
IANA Type Product/IP-Core Configuration Y
VLAN Encapsulation Object (IMO Name—IEEE802)
VLAN Identification
Binding Information
Binding Status
IANA Type Product/IP-Core Configuration Y
STP
Table 37 summarizes support for Spanning Tree Protocol (STP) attributes on Cisco routers in
Cisco ANA 3.6.
Table 37 STP Attribute Support on Cisco Routers
Attribute Scheme Polling Interval
STP Service Object (IMO Name—IStpService)
Protocol Type
Current and Bridge Product/IP-Core Status Y
Current and Bridge
Product/IP-Core Status Y
Hello Time
Current and Bridge
Product/IP-Core Status Y
Forward Delay
Bridge Information
Product/IP-Core Status Y
Table
MST Service Object (IMO Name—IMstService)
Protocol Properties
Same as IStpService
MST Properties Object (IMO Name—ImstProperties)
Force Version Product/IP-Core Status Y
Configuration Format,
Product/IP-Core Status Y
Region Name and
Revision Level
7200
7600
7600
12000
12000
XR 12000
XR 12000
CRS-1
CRS-1
OL-14112-01
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
57
Supported Technologies on Cisco Routers
Table 37 STP Attribute Support on Cisco Routers (continued)
Support Information for Cisco Routers
Attribute Scheme Polling Interval
7200
7600
12000
External Root Cost
Maximum Instances
STP Instance Information Object (IMO Name—IStpInstanceInfo)
Object Identification
Identification
Priority
Designated Parent and
Product/IP-Core Status Y
Root Bridges
Root Cost Product/IP-Core Status Y
Is Root Product/IP-Core Status Y
Root Port Identification Product/IP-Core Status Y
Port Information Table
MST Protocol Instance Information Object (IMO Name—IMstInstanceInfo)
Instance Identification Product/IP-Core Status Y
same as IStpBridgeInfo Y
Per VLAN Spanning Tree Protocol Instance Information Object (IMO Name—IPvstpInstanceInfo)
Protocol Type Product/IP-Core Configuration Y
Current and Bridge
Product/IP-Core Status Y
Maximum Age
Current and Bridge
Product/IP-Core Status Y
Hello Time
Current and Bridge
Product/IP-Core Status Y
Forward Delay
same as
Y
IStpInstanceInfo
RSTP Instance Information Object (IRstpInstanceInfo)
Force Version Product/IP-Core Configuration Y
same as
Y
IStpInstanceInfo
XR 12000
CRS-1
58
Cisco Active Network Abstraction 3.6 Virtual Network Element Reference Guide
OL-14112-01
