CipherLab RS50 User Manual

RS50

Mobile Computer

(Android™ 6.0, Marshmallow)

Version 1.00

Preface

PREFACE

is the proprietary information of CIPHERLAB CO., LTD. and its respective legal owners; it is protected by copyright laws and international copyright treaties, as well as other intellectual property laws and treaties, with all rights reserved.

In no event and by no part shall thi s document be reproduced, stored in a retrieval system, or transmitted in any form or by any means including but not limited to electronic, mechanical, photocopying, and recording without the prior written consent of CIPHERLAB CO., LTD. Any reverse engineering of software is also prohibited.

DISCLAIMER

The information herein is subject to change without notice. The information and the intellectual property herein are confidential between you and CIPHERLAB CO., LTD. and remain the exclusive property of CIPHERLAB CO., LTD. and its respective legal owners. Should you find any problems in this document, please report them to CIPHERLAB in writing. CIPHERLAB does not warrant this document is error-free.

TRADEMARK RECOGNITION

CipherLab logo is a registered trademark of CIPHERLAB CO., LTD. All other brands, products and services, and trademark names are the property of their registered owners. The editorial use of these names is for identification as well as to the benefit of the owners, with no intention of infringement .

Google, Google Play, Android and other marks are trademarks of Google Inc.

CONTACT

For product consultancy and technical support, please contact CIPHERLAB’s sales representative in your local area. You may also visit CIPHERLAB web site for more information.

CIPHERLAB CO., LTD. Website: http://www.CipherLab.com

- 2 -

Important Notices

IMPORTANT NOTICES

FOR USA

FCC ID : Q3N-RS50

This equipment has been tested and found to comply with the l i mi ts for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

 Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circu it different from that to which

the receiver is connected.

 Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, an d (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate this equipment.

This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Find the certificate information from :

Setup  About Phone  Certificate

Tested to Comply

with FCC Standards

FOR HOME OR OFFICE USE

- 3 -

Important Notices

FOR PRODUCT WITH LASER

 This laser component emits FDA / IEC Class 2 laser light at

the exit port. Do NOT STARE INTO BEAM DIRECTLY.

 Do not aim the beam at the eyes.  Any adjustments or performance excluding those specified may

result in hazardous laser light exposure.

ENVIRONMENT

 Operate the handy terminal at ambient temperatures from -20 °C to 50 °C

and with humidity range from 10% to 90%.

 Store the device at ambient temperatures from -30 °C to 70 °C and with

humidity range from 5% to 95%.

 Charge the device at ambient temperatures from 0°C to 35°C.  This device is built with a dust-proof and splash-proof structure that

conforms to protection class IP67.

SPECIFIC ABSORPTION RATE (SAR) INFORMATION

The product complies with the FCC portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the products can be kept as far as possible from the user body or set the device to lower output power if such function is available.

The SAR test distance is Head (0 mm), Body (10 mm) and Hotspot (10 mm).

For body-worn operating conditions please use belt-clips, holsters, and/or accessories that have no metallic component in the assembly and must provide at least 10mm separation between the device and the user's body.

FCC SAR Value (Standard limit is 1.6 W/Kg)

USA (1g): Max. 1.54 W/Kg

A minimum separation distance of 0.5 cm must be maintained between the user’s body and the device, including the antenna during body-worn operation to comply with the RF exposure requirements in Europe. To compliance with RF Exposure requirements in Europe, third-party belt-clips, holsters or similar accessories used by this device should not contain any metallic components. The use of accessories that do not satisfy these requirements may not comply with RF exposure requirements, and should be avoided.

CE SAR Value (Standard limit is 2 W/Kg)

EU (10g): Max. 1.6 W/Kg

SAFETY PRECAUTIONS

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

 For people’s safety  Do not listen at high volume levels for long periods to prevent possible

hearing damage.

 Do not operate this device while walking, cycling or car driving.  For the equipment

- 4 -

Important Notices

 Do not use any batteries or charging devices which are not originally sold  Do not replace the battery with an incorrect type, to avoid the risk of heat

generation, fire, or explosion.

 Do not disassemble, incinerate or short circuit the battery.  Do not touch the contact pins of the battery pack.  Do not expose the handy terminal or battery to any flammable sources.  Do not expose the handy terminal to extreme temperatures or soak it in

water.

 Do not use any pointed or sharp objects against the screen surface.  Do not use the styluses which are not supplied, to prevent possible scratches

to the touch screen.

 Water residue on the touch screen may cause abnormal behaviors or the fall

of its sensitivity levels.

 On the surface of the terminal and the barcode reading window, the fog or

water drops caused by low temperatures may influence barcode reading.

 Do not use bleaches or cleaners to clean the device. Use a clean, wet cloth

instead.

BATTERY

 The main battery may not be charged to full for shipment. Charge the main

battery to full before using the handy terminal for the first time.

 Main battery: The main battery powers the handy terminal to work. It takes

approximately 4 hours to charge an empty main battery to full. The charging LED above the screen will light up in red while charging and will turn green when charging is complete.

 When the main battery is removed, RTC retention w ill be maintained for at

least 30 minutes.

 Backup battery: The backup battery is mounted on the main board. Its role is

to temporarily keep the handy terminal in suspension when the main battery is drained out so data in DRAM will be retained. The backup battery takes approximately 3.5 hours to charge to full by the main battery or power adapter.

 It is recommended to charge the battery at room temperature (18°C to 25°C)

for optimal performance.

 Battery charging stops when ambient temperature drops below 0°C or

exceeds 40°C.

 In order to prevent system from shutting down after the battery is drained

out, keep a fresh battery for replacement at all times, or connect the handy terminal to an external power.

 If there are drippings or dust on the device or battery pack, wipe them away

with a soft clean cloth before battery replacement.

 Turn off the power before battery replacement.  If you want to put away the handy terminal for a period of time, remove the

battery pack from the handy terminal’s battery compartment. Store the handy terminal and battery pack separately.

 Recycle batteries in a proper way for the green-environment issue.

SCANNER

 Scan a 1D barcode

- 5 -

Important Notices

 1) Open ReaderConfig and tap Scan Test on the menu bar.  2) Aim the scanning window at the barcode to read. Move the device,

having the barcode located in the center of the scanning area.

 3) Press any of the two side triggers. The scanning light beams to re ad the

printed barcodes. The buzzer beeps after scanning. The scanning light goes off once the data is decoded, or when the decode timeout period has passed.

 Scan a 2D barcode  1) Open ReaderConfig and tap Scan Test on the menu bar.  2) Aim the scanning window at the barcode to read. Move the device,

having the barcode located in the center of the scanning area.

 3) Press any of the two side triggers. The scanning light beams to re ad the

printed barcodes. The buzzer beeps after scanning. The scanning light goes off once the data is decoded, or when the decode timeout period has passed.

- 6 -

Important Notices

CONNECTION

 Via Bluetooth or WLAN  Connection may fail when the handy terminal is around other wireless

machines or power cables as the radio frequencies of those may cause interferences.

 If communication fails, move the devices much closer to each other, and try

to communicate again

 After turning on, Bluetooth power is sustained even when the handy terminal

is suspended. However, if the power mode is switched to Airplane Mode, Bluetooth power will be turned off regardless of the settings.

 Not Charging could be the result of battery damage, battery’s failure to touch

the connector or AC plug coming off.

 Charging error could be due to high battery temperature.

CARE & MAINTENANCE

 When the body of the handy terminal gets dirty, use a clean, wet cloth to

wipe off dust and debris. DO NOT use bleaches or cleaners.

 Use a clean, non-abrasive, lint-free cloth to wipe dust off the LCD touch

screen. DO NOT use any pointed or sharp objects against the surface. Always keep the LCD dry.

 If you want to put away the handy terminal for a period of time, download the

collected data to a host computer, and then remove the battery pack from the handy terminal’s battery compartment. Store the handy terminal and battery pack separately.

 If you encounter malfunction on the handy terminal, write down the specific

scenario and consult your local sales representative.

- 7 -
