CipherLab 9500CE1 User Manual

Reference Manual
9500CE Terminal
Terminal
Version 1.03
Printed on 19 March, 2008
Copyright Notice
Copyright © 2006 CIPHERLAB CO., LTD.
All rights reserved
Due to continued product development this information may change without notice. The information and intellectual property contained herein is confidential between CIPHERLAB and the client and remains the exclusive property of CIPHERLAB CO., LTD. If you find any problems in the documentation, please report them to us in writing. CIPHERLAB does not warrant that this document is error-free.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise without the prior written permission of CIPHERLAB CO., LTD.
For product consultancy and technical support, please contact your local sales representative. Also, you may visit our web site for more information.
The CipherLab logo is a registered trademark of CIPHERLAB CO., LTD.
Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and/or other countries.
Bluetooth is a trademark of Bluetooth SIG, Inc., U.S.A.
Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are hereby acknowledged.
The editorial use of these names is for identification as well as to the benefit of the owners, with no intention of infringement.
CIPHERLAB CO., LTD.
Website: http://www.cipherlab.com
II
FCC Regulations
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator &your body. It only operated in hand-held used. If you only transfer data to Host by WLAN, please keep the minimum distance 20cm between machine & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Important Safety Precautions
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS The use of any batteries or charging devices, which are not originally sold or manufactured by
CipherLab, will void your warranty and may cause damage to human body or the product itself.
The charging and communication cradle uses an AC power adaptor. A socket outlet shall be installed
near the equipment and shall be easily accessible. The power adaptor should comply with L.P.S test. Make sure there is stable power supply for the terminal or its peripherals to operate properly.
DO NOT disassemble, incinerate or short circuit the battery pack. DO NOT expose the terminal or the battery pack to any flammable sources. Under no circumstances, internal components are self-serviceable. Per FDA and IEC standards, the scan engines described in this manual are not given a laser
classification. However, the following precautions should be observed:
CAUTION
This laser component emits FDA/IEC Class 2 laser light at the exit port. Do not stare into beam.
III
Care & Maintenance
This terminal is intended for industrial use. The terminal is rated IP 64, however, it may do damage to
the terminal when being exposed to extreme temperatures or soaked wet.
When the body of the terminal gets dirty, use a clean and wet cloth to wipe off the dust. DO NOT
use/mix any bleach or cleaner. Always keep the LCD dry.
For a liquid crystal display (LCD) or touch screen, use a clean, non-abrasive, lint-free cloth to wipe dust
off the screen. DO NOT use any pointed or sharp object to move against the surface.
Battery disposal – For green-environment issue, it is important that batteries should be recycled in a
proper way.
If you want to put away the terminal for a period of time, download the collected data to a host computer,
and then take out the battery pack. Store the terminal and battery pack separately.
When the terminal resumes its work, the main and backup batteries will take a certain time to become
fully charged.
If you shall find the terminal malfunctioning, write down the specific scenario and consult your local
sales representative.
Industry Canada - Class B This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled "Digital Apparatus," ICES-003 of Industry Canada.
Cet appareil numerique respecte les limites de bruits radioelectriques applicables aux appareils numeriques de Classe B prescrites dans la norme sur le material brouilleur: "Appareils Numeriques," NMB-003 edictee par l'Industrie. (1) this device may not cause interference,and (2) this device must accept any interference, including interference that may cause undesired operation of the device."
IV
Power Management
For any portable device, power management is a critical issue especially when you are on the road. Below are some tips to help you save battery power.
To speed up charging the terminal, turn off the terminal and seat it in the cradle. Bring a second battery pack on the road. Stop wireless connectivity, Bluetooth, 802.11b/g that is not in use.
The power to the wireless modules, 802.11b/g, is controlled by PwrMg.exe (the Wireless Power
Manager), which can be found on the taskbar (
To save power, go to Start > Settings > Control Panel for related settings:
Double-tap the Display icon
1. Tap the Backlight tab.
2. Select one or both of the check boxes to automatically turn off the LCD backlight when using batteries or external power. From the appropriate list, select the amount of time the device should be idle before the backlight is turned off.
3. Then, tap the [Advanced] button to view more backlight options.
4. In the Settings tab, you can dim the LCD backlight when in a well-lit working area for AC and battery powered respectively.
Double-tap the Power icon
1. Tap the Schemes tab.
2. Select the desired power scheme and options for suspending operation when not in use.
).
V
Contents
ࡸآࡳᆠ஼᧘Ζ
Copyright Notice II
FCC Regulations III
Important Safety Precautions III
Care & Maintenance IV
Power Management V
i
Preface 1
Revision History.......................................................................................................ᙑᎄ!
CHAPTER 1 - Introduction 3
1.1 Unpacking the package...........................................................................................................................3
1.2 Options....................................................................................................................................................3
1.3 Product Highlights..................................................................................................................................4
1.4 Nomenclature..........................................................................................................................................5
1.4.1 9500CE Terminal .....................................................................................................................5
1.4.2 Accessories & Peripherals........................................................................................................6
1.4.3 Dimensions...............................................................................................................................7
1.5 Features...................................................................................................................................................8
1.5.1 Battery ......................................................................................................................................8
1.5.2 CPU ........................................................................................................................................11
1.5.3 Memory & Calendar...............................................................................................................11
1.5.4 Keypad....................................................................................................................................13
1.5.5 LCD........................................................................................................................................16
1.5.6 Status LED..............................................................................................................................19
1.5.7 Speaker ...................................................................................................................................19
1.5.8 Vibrator ..................................................................................................................................19
1.5.9 Reader.....................................................................................................................................20
1.5.10 Wireless Support...................................................................................................................22
1.5.11 Resistance.............................................................................................................................22
ii Contents
CHAPTER 2 - Installation 23
2.1 Main & Backup Batteries .....................................................................................................................24
2.2 Hand Strap ............................................................................................................................................26
2.3 Pistol Grip.............................................................................................................................................27
2.4 Cradle....................................................................................................................................................28
2.4.1 Status Indicators .....................................................................................................................28
2.4.2 Communication Ports .............................................................................................................29
CHAPTER 3 - Windows CE Basics 31
3.1 General..................................................................................................................................................32
3.1.1 Device Configuration .............................................................................................................33
3.1.2 Turn On/Off............................................................................................................................34
3.1.3 Desktop Window....................................................................................................................34
3.1.4 Input Methods.........................................................................................................................38
3.2 System Reset.........................................................................................................................................39
3.2.1 Soft Reset................................................................................................................................39
3.2.2 Hard Reset ..............................................................................................................................39
3.3 Firmware Update ..................................................................................................................................40
3.4 ActiveSync with a Computer................................................................................................................41
3.5 Quick Launch a Program......................................................................................................................42
3.5.1 Add a Program........................................................................................................................42
3.5.2 Add a Subfolder......................................................................................................................45
3.5.3 Exit a Program........................................................................................................................46
3.5.4 Switch between Programs.......................................................................................................46
3.6 Install a New Program ..........................................................................................................................47
3.6.1 Add/Remove Programs...........................................................................................................47
3.6.2 Copy & Paste..........................................................................................................................47
3.7 Uninstall a Program ..............................................................................................................................48
3.7.1 ActiveSync: Add/Remove Programs ......................................................................................48
3.7.2 Control Panel > Remove Programs ........................................................................................48
3.8 Backup & Restore Programs.................................................................................................................50
CHAPTER 4 - Configuration 51
4.1 General Settings....................................................................................................................................51
4.2 Connections ..........................................................................................................................................54
4.2.1 USB Connection.....................................................................................................................56
4.2.2 AX88772 (Ethernet) ...............................................................................................................57
4.2.3 WLAN....................................................................................................................................58
4.2.4 BTPAN...................................................................................................................................62
CHAPTER 5 - Applications 63
5.1 Wireless Power Manager......................................................................................................................64
5.2 Bluetooth Manager ...............................................................................................................................65
5.2.1 Start Bluetooth Services .........................................................................................................65
5.2.2 Inquiry ....................................................................................................................................70
5.2.3 Pair..........................................................................................................................................71
5.2.4 Connect...................................................................................................................................73
5.2.5 Stop Bluetooth Services..........................................................................................................77
Contents iii
5.3 ReaderConfig........................................................................................................................................78
5.3.1 Configure Reader Settings......................................................................................................79
5.3.2 1D Reader - CCD / Laser........................................................................................................80
5.3.3 1D Reader - (Extra) Long Range Laser..................................................................................89
5.3.4 2D Reader...............................................................................................................................96
5.3.5 RFID Reader.........................................................................................................................106
5.4 Inbox...................................................................................................................................................107
5.4.1 Create an E-mail Box ...........................................................................................................107
5.4.2 Synchronize Inbox................................................................................................................110
Specifications 111
APPENDIX I - Comparison of Scan Modes 113
iv Contents
Table of Figures
Figure 1: Nomenclature (front & back).....................................................................................5
Figure 2: Nomenclature of accessories.......................................................................................6
Figure 3: Dimensions ...................................................................................................................7
Figure 4: 27-key layout ..............................................................................................................13
Figure 5: DIP switch for backup battery pack........................................................................24
Figure 6: Installing battery pack ..............................................................................................25
Figure 7: Installing hand strap .................................................................................................26
Figure 8: Installing pistol grip ..................................................................................................27
Figure 9: Cradle LEDs ..............................................................................................................28
Preface
Delivered in the same form factor of the 9500PPC Series running Windows Mobile 2003SE, the 9500CE Terminal Series is the newest member to the Mobile Computer family. As suggested by its model designation, it is designed to run Windows CE 5.0, and therefore, allows more flexibility in customization of applications.
CipherLab has integrated powerful utilities for data collection, processing, and transmission. Its large color transflective TFT display guarantees ease in reading in all lighting conditions. Built-in with Bluetooth and 802.11b/g technologies, delivers a total wireless solution.
The 9500CE Terminal Series is robust in construction to meet industry grade requirements, and has been found durable and resistant to shock, water, and dust. It is specifically designed for all-day, everyday use as well as for data-intensive applications in harsh environments.
1
This manual serves to guide you through how to install, configure, and operate the terminal. The Care & Maintenance section is specifically prepared for those who are in charge of taking care of the terminal.
We recommend you to keep one copy of the manual at hand for quick reference or maintenance purposes. To avoid any improper disposal or operation, please read the manual thoroughly before use.
Thank you for choosing CipherLab products!
C HAPTER 1
Introduction
This chapter explains the hardware parts and features of the 9500CE Terminal terminal.
1.1 Unpacking the package
The following items are included in the package. Save the box and packaging material for future use in case you need to store or ship the terminal.
9500CE Terminal Rechargeable Li-ion battery pack Stylus Hand strap Software CD (this Reference Manual is included)
3
Note: For battery charging, you will need to purchase a charging cradle separately.
1.2 Options
There are a number of optional accessories to enhance the total performance of the terminal. Refer to related sections for details on installation.
Accessories Features...
Reader
Rechargeable Battery Pack
Pistol Grip, Detachable
Charging & Communication Cradle
One scan engine:
1D - CCD, Laser, Long Range Laser, Extra Long Range Laser
And/or the RFID reader
Rechargeable Li battery for non-stop operation
Facilitating scanning with one hand
Charging of the terminal and one spare battery at the same time while transmitting/receiving data.
4 9500CE Terminal Reference Manual
1.3 Product Highlights
Microsoft Windows CE 5.0 software for operating system 520 MHz Intel PXA270 processor A color transflective TFT display delivers excellent visibility in all lighting conditions 128 MB non-volatile NAND flash memory to store OS and software programs
(part of the free space is used as a storage card called DiskOnChip)
128 MB SDRAM to store and run programs, as well as store program data Ergonomic design, ruggedized yet streamlined, with hand strap for secure hold Built tough to survive harsh environments - splash, dust & drop resistant Dual mode support - One scan engine (integrated barcode scanner/imager) plus one
RFID reader
Wireless connectivity includes Bluetooth and 802.11b/g Programmable feedback includes speaker and vibrator Accessories and peripherals include pistol grip, international AC charging cradle, etc.
Chapter 1 5
1.4 Nomenclature
1.4.1 9500CE Terminal
Figure 1: Nomenclature (front & back)
6 9500CE Terminal Reference Manual
1.4.2 Accessories & Peripherals
Figure 2: Nomenclature of accessories
Chapter 1 7
1.4.3 Dimensions
Figure 3: Dimensions
8 9500CE Terminal Reference Manual
1.5 Features
1.5.1 Battery
Main Battery
This rechargeable 3.7 V/4000 mAh Li-ion battery pack serves as the main power.
Normally, it takes approximately four hours to fully charge the battery. The
charging time may vary by working condition.
During normal operation, the terminal can work for up to 16 hours.
Warning: Using backlight, wireless connectivity, and peripherals while on battery
power will substantially reduce battery life.
Backup Battery
The backup battery takes charge when the main battery is removed or drained out.
If fully charged, it will help retain data in SDRAM and maintain the system running
in suspend mode for at least 30 minutes without the main battery. In the meantime, you have to replace the main battery as soon as possible.
Battery Charge
Initial Charging
The main and backup batteries may not be charged to full for shipment. When you first receive the package, you will need to charge batteries to full before using the terminal.
Note: To charge the batteries for the first time, it requires approximately 8 hours.
After the initial charging, it takes only 4 hours to charge the batteries to full.
Because the internal backup battery is constantly charged from the main battery, the initial charging requires installing the battery pack to the terminal and then seating the terminal in the cradle for charging. This will have both the main and backup batteries charged at the same time.
Note: To charge the backup battery, make sure that you slide the DIP switch inside the
battery compartment to the ON position.
Chapter 1 9
Caution of Low Battery Charge
The battery pack is the only power source for the terminal to work. It also charges the backup battery so that the data stored in SDRAM can be retained properly. Therefore, when the main battery charge goes low, replace the battery pack with a charged one or seat it in the cradle for charging as soon as possible. Always save data before it is too late.
Warning: Data loss may occur with SDRAM during low battery condition. Always
save data before running out of power or keep a fresh battery for replacement.
Battery Status Icons
Status Icons Description
Main battery is low.
Main battery is very low.
Power Properties
The system can be set to three different states to conserve power:
User Idle state
System Idle state
Suspend state
Start > Settings > Control Panel and double-tap the Power icon
1. In the Battery tab, you can always monitor the charging status.
2. Tap the Schemes tab.
3. Select the desired power scheme and options for suspending operation when not in use. The time choices represent the amount of time that must pass before the system will switch to the next power conservation state.
Backup battery is low.
Backup battery is very low.
Main battery is charging.
10 9500CE Terminal Reference Manual
To conserve more power, you may go to Start > Settings > Control Panel and double-tap the Display icon to configure the backlight setting.
Chapter 1 11
1.5.2 CPU
Built to run Windows CE 5.0, the 9500CE Terminal terminal is equipped with an Intel X-Scale 520 MHz RISC microprocessor.
1.5.3 Memory & Calendar
Read-only Memory (ROM)
A total of 128 megabytes flash memory.
Mostly, it is for storing OS (Windows CE 5.0) and custom application programs.
Yet a small portion of the memory is referred to as DiskOnChip, which can store data and
programs that you wish to retain even after a hard reset.
Random-access Memory (RAM)
A total of 128 megabytes SDRAM.
It is used for storing and running programs, as well as storing program data.
Its contents will be retained by the backup battery.
Calendar
Equipped with a calendar chip for accurate time/date logging.
Non-stop operation is provided through the backup battery.
Caution of Data Loss
When the main battery is removed or drained out, the backup battery is to retain the contents of SDRAM and maintain the OS in suspend mode for at least 30 minutes, on condition that the backup battery has already been fully charged.
If the terminal is to be put away for a couple of days, you should be aware that data loss occurs when both the main and backup batteries discharge completely. It is necessary to backup data and files before putting away the terminal.
12 9500CE Terminal Reference Manual
System Properties - Memory tab
Start > Settings > Control Panel and double-tap the System icon
1. In the Memory tab, it displays the current capacity and usage of the 128 MB onboard SDRAM. (Left below)
2. You may tap, hold, and drag the slider to re-allocate the memory.
SDRAM
128 MB onboard It refers to the memory
DiskOnChip Properties
(Desktop) My Device > DiskOnChip
Tap and hold the DiskOnChip icon and select Properties from the pop-up menu.
In the Properties tab, it displays the current capacity and usage of DiskOnChip. (Right
below)
The DiskOnChip is part of the onboard 128 MB flash memory. Because the flash
memory is non-volatile, data or programs stored in DiskOnChip will not be erased after a hard reset.
Storage memory (left) Program memory (right)
It refers to the memory allocated for file and data storage.
allocated for running
programs.
Chapter 1 13
1.5.4 Keypad
The terminal is equipped with a physical keypad that consists of 27 keys. Silicon rubber has been chosen for their durability and prompt feedback.
The layout of the 27-key keypad includes alphanumeric, assorted characters, etc. This keypad is set to numeric mode by default.
Figure 4: 27-key layout
Note: Functionality of keys is application-dependent.
14 9500CE Terminal Reference Manual
Keypad Settings
first, and then
The LED backlight of keypad is turned off by default. It can be toggled ON/OFF by
the key combination: [Func] + [0].
Start > Settings > Control Panel and double-tap the Keyboard icon
The Character Repeat functionality is enabled by default. You may cancel the check
box to disable it. When enabled, tap, hold, and drag the slider for a desired Repeat Delay and Repeat Rate.
Warning: Using backlight while on battery power will substantially reduce battery
life. It is suggested to turn on the keypad backlight while working in a dark area.
Task Key
The [Task] key on the keypad is set to trigger Windows Explorer.
To launch Windows Explorer, press
on the keypad.
Alpha Key
This alphanumeric keypad is set to numeric mode by default. The Alpha key serves as a toggle among numeric, alpha (lower-case alphabetic), and ALPHA (upper-case alphabetic) modes.
Note: It is not necessary to hold down the [Alpha] key.
The alpha icon will appear on the status bar in a sequence as shown below.
Status Icon Alpha Key Input Mode
N/A Numbers
Press
Press
one time
two times
Small letters
Capital letters
Note: If you are using the software keypad via SIP, tap CAP (Caps Lock) to toggle
between upper case and lower case alphabetic modes.
Chapter 1 15
Func Key
The [Func] (function) key serves as a modifier key.
1. To enable this modifier key, press
on the keypad.
A circular icon of the letter "F" will appear on the status bar. This modifier key is hold down as long as the icon is displayed.
2. Now press another key to get the value of key combination (say, press [1] to get the value of F1). The icon will go off now.
3. To get the value of another key combination modified by the [Func] key, repeat the above steps.
4. To abort the key modification, press
again, and the icon will go off.
Note: It is not necessary to hold down the [Func] key.
The functionality of each key combination is application-dependent. Below is a list of the factory setting for a variety of key combinations.
Press
Key Combination Action
first, and then press one of the following keys for a specific function:
PgUp (red-coded): move text up one screenful
PgDn (red-coded): move text down one screenful
Home (red-coded): move to the beginning of screen or document
End (red-coded): move to the end of screen or document
Toggle ON/OFF the backlight of keypad only
Turn ON the backlight of LCD and decrease its luminosity
Turn ON the backlight of LCD and increase its luminosity
16 9500CE Terminal Reference Manual
1.5.5 LCD
The terminal comes with a 3.5” TFT graphic LCD, 240 by 320 pixels resolutions. The LED backlight of screen, which helps ease reading under dim environments, can be controlled manually and automatically.
Warning: Using backlight while on battery power will substantially reduce battery
life. It is suggested to dim the backlight while working in a well-lit area or automatically turn off the terminal when not in use.
LCD Settings
first, and then
The LED backlight of the screen can be turned on and adjusted decreasingly by the
key combination: [Func] + [–].
It is not necessary to hold down the [Func] key; keep pressing the [–] key until the
luminosity is decreased to a desired level.
first, and then
The LED backlight of the screen can be turned on and adjusted increasingly by the
key combination: [Func] + [•].
It is not necessary to hold down the [Func] key; keep pressing the [] key until the
luminosity is increased to a desired level.
Display Properties
Start > Settings > Control Panel and double-tap the Display icon
1. Tap the Backlight tab. (Left below)
2. Select one or both of the check boxes to automatically turn off the LCD backlight when using batteries or external power. From the appropriate list, select the amount of time the device should be idle before the backlight is turned off.
3. Then, tap the [Advanced] button. (Right below)
4. In the Settings tab, you can select the luminosity of backlight when it is set to be automatically turned on by pressing any key or tapping the screen. Tap, hold, and drag the slider for AC and battery powered respectively. For more luminosity, move the slider to the right.
Chapter 1 17
To conserve more power, you may go to Start > Settings > Control Panel and double-tap the Power icon to configure the power-saving setting.
18 9500CE Terminal Reference Manual
Stylus Properties
This LCD is also a touch screen that can be calibrated through screen alignment.
Warning: DO NOT use any pointed or sharp objects to move against the surface of
the screen.
Start > Settings > Control Panel and double-tap the Stylus icon
1. Tap the Calibration tab.
2. Tap the [Recalibrate] button.
Chapter 1 19
1.5.6 Status LED
The tri-color LED on top of the [Scan] button is used to provide information on status of battery charging or Bluetooth connection.
Tasks Green LED Red LED Green & Red Blue
Low battery --- Flashing --- ---
Terminal charging --- On --- ---
Charging done On --- --- ---
Charging error --- --- Flashing ---
Bluetooth connection enabled --- --- --- On
1.5.7 Speaker
The speaker, a low power transducer type, can be used for playing sounds applied to events in Windows and programs, as well as playing audio files such as .WAV files. In addition, it can be programmed for status feedback.
1.5.8 Vibrator
The terminal is integrated with a vibrator, which is software programmable for feedback. This can be helpful when working in noisy environments.
20 9500CE Terminal Reference Manual
1.5.9 Reader
A wide variety of scan engines is available for delivering flexibility to meet different requirements.
Types of Reader Scan Engine
1D Barcode Reader
2D Barcode Reader
CCD (Long Range Imager)
Laser scan engine
Long Range Laser scan engine
Extra Long Range Laser scan engine (with aiming beam)
2D scan engine
RFID
Tags supported include:
Standard
ISO 14443A
ISO 14443B
ISO 15693
ICODE® (Phillips)
Labels
Mifare Standard 1K
Mifare Standard 4K
Mifare Ultralight
Mifare DESFire
Mifare S50
SLE44R35
SLE66R35
SRIX 4K
ICODE SLI
SRF55V02P
SRF55V02S
SRF55V10P
TI Tag-it HF-I
ICODE
Dual Mode Support
The terminal allows the co-existence of one integrated scan engine and the RFID reader.
Chapter 1 21
Symbologies Enabled
Depending on the scan engine integrated (check the “Active Device” setting in
ReaderConfig
symbologies as shown below. If you need to scan barcodes that are encoded in a different symbology, use the ReaderConfig tool to enable the symbology first.
Active Device Symbologies Enabled
1D Reader The scan engine can be CCD or Laser.
1D Long Range Laser
2D Reader The scan engine can read linear and 2D barcodes.
), the terminal is capable of scanning barcodes of a number of
Code 39
Industrial 25
Interleaved 25
Codabar
UPC / EAN
Code 93
Code 128
The scan engine can be Long Range Laser or Extra Long Range Laser.
Code 39
Interleaved 25
UPC / EAN
Code 128
RSS-14
Code 39
Interleaved 25
UPC / EAN
Code 128
RSS-14
Postal Codes
PDF417
Data Matrix
MaxiCode
QR Code
22 9500CE Terminal Reference Manual
1.5.10 Wireless Support
The 9500CE Terminal terminal supports state-of-the-art wireless technologies, Bluetooth and 802.11b/g, so that it is able to send/receive data in real time in an efficient way.
1.5.11 Resistance
Shock
The terminal is designed for harsh industrial environments, and is proved to survive drop test by the following criteria:
Surface type: concrete
Distance to surface: 1.5 meters
Drop times: multiple
Splash & Dust
The terminal is sealed against moisture and dust to industry standard IP 64.
6 = Totally protected against dust
4 = Protection against water sprayed from all directions. That is, limited ingress is
permitted.
Warning: If additional memory card or peripheral is not factory-installed, the Ingress
Protection rating of enclosures may not be the same as claimed.
Loading...
+ 93 hidden pages
