BGS2-E/BGS2-W
Version: 01.300
DocId: BGS2_HIO_v01.300
Hardware Interface Overview
GENERAL NOTE
THE USE OF THE PRODUCT INCLUDING THE SOFTWARE AND DOCUMENTATION (THE "PRODUCT") IS SUBJECT TO THE RELEASE NOTE PROVIDED TOGETHER WITH PRODUCT. IN ANY
EVENT THE PROVISIONS OF THE RELEASE NOTE SHALL PREVAIL. THIS DOCUMENT CONTAINS
INFORMATION ON CINTERION PRODUCTS. THE SPECIFICATIONS IN THIS DOCUMENT ARE SUBJECT TO CHANGE AT CINTERION'S DISCRETION. CINTERION WIRELESS MODULES GMBH
GRANTS A NON-EXCLUSIVE RIGHT TO USE THE PRODUCT. THE RECIPIENT SHALL NOT TRANSFER, COPY, MODIFY, TRANSLATE, REVERSE ENGINEER, CREATE DERIVATIVE WORKS; DISASSEMBLE OR DECOMPILE THE PRODUCT OR OTHERWISE USE THE PRODUCT EXCEPT AS
SPECIFICALLY AUTHORIZED. THE PRODUCT AND THIS DOCUMENT ARE PROVIDED ON AN "AS
IS" BASIS ONLY AND MAY CONTAIN DEFICIENCIES OR INADEQUACIES. TO THE MAXIMUM
EXTENT PERMITTED BY APPLICABLE LAW, CINTERION WIRELESS MODULES GMBH DISCLAIMS
ALL WARRANTIES AND LIABILITIES. THE RECIPIENT UNDERTAKES FOR AN UNLIMITED PERIOD
OF TIME TO OBSERVE SECRECY REGARDING ANY INFORMATION AND DATA PROVIDED TO HIM
IN THE CONTEXT OF THE DELIVERY OF THE PRODUCT. THIS GENERAL NOTE SHALL BE GOVERNED AND CONSTRUED ACCORDING TO GERMAN LAW.
Copyright
Transmittal, reproduction, dissemination and/or editing of this document as well as utilization of its contents and communication thereof to others without express authorization are prohibited. Offenders will be
held liable for payment of damages. All rights created by patent grant or registration of a utility model or
design patent are reserved.
Copyright © 2011, Cinterion Wireless Modules GmbH
Trademark Notice
Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries. All other registered trademarks or trademarks mentioned in this document are property of their respective owners.
BGS2_HIO_v01.300 Page 2 of 29 2011-03-08
Confidential / Released
BGS2-E/BGS2-W Hardware Interface Overview
2
Document Name:
BGS2-E/BGS2-W Hardware Interface Overview
Version:
01.300
Date:
2011-03-08
DocId:
BGS2_HIO_v01.300
Status
Confidential / Released
BGS2-E/BGS2-W Hardware Interface Overview
Contents
29
BGS2_HIO_v01.300 Page 3 of 29 2011-03-08
Confidential / Released
Contents
1 Introduction.................................................................................................................6
1.1 Related Documents ........................................................................................... 6
1.2 Terms and Abbreviations ................................................................................... 6
1.3 Regulatory and Type Approval Information ..................................................... 10
1.3.1 Directives and Standards.................................................................... 10
1.3.2 SAR requirements specific to portable mobiles .................................. 13
1.3.3 Safety Precautions.............................................................................. 14
2 Product Concept....................................................................................................... 15
2.1 Key Features at a Glance ................................................................................ 15
3 Application Interface.................................................................................................17
3.1 Operating Modes ............................................................................................. 18
4 Antenna Interface......................................................................................................19
5 Electrical, Reliability and Radio Characteristics....................................................20
5.1 Absolute Maximum Ratings ............................................................................. 20
5.2 Operating Temperatures.................................................................................. 21
5.3 Storage Conditions .......................................................................................... 22
5.4 Reliability Characteristics................................................................................. 23
5.5 Pad Assignment .............................................................................................. 24
5.6 Power Supply Ratings...................................................................................... 26
6 Mechanics, Mounting and Packaging..................................................................... 27
6.1 Mechanical Dimensions of BGS2-E/BGS2-W.................................................. 27
7 Reference Approval.................................................................................................. 28
7.1 Reference Equipment for Type Approval......................................................... 28
7.2 Compliance with FCC and IC Rules and Regulations ..................................... 29
BGS2-E/BGS2-W Hardware Interface Overview
Tab l e s
110
BGS2_HIO_v01.300 Page 4 of 110 2011-03-08
Confidential / Released
Tables
Table 1: Directives ....................................................................................................... 10
Table 2: Standards of North American type approval .................................................. 10
Table 3: Standards of European type approval............................................................ 10
Table 4: Requirements of quality ................................................................................. 11
Table 5: Standards of the Ministry of Information Industry of the
People’s Republic of China............................................................................ 11
Table 6: Toxic or hazardous substances or elements with defined concentration limits 12
Table 7: Overview of operating modes ........................................................................ 18
Table 8: Return loss in the active band........................................................................ 19
Table 9: Absolute maximum ratings............................................................................. 20
Table 10: Board temperature ......................................................................................... 21
Table 11: Ambient temperature according to IEC 60068-2 (w/o forced air circulation).. 21
Table 12: Ambient temperature with forced air circulation (air speed 0.9m/s)............... 21
Table 13: Storage conditions ......................................................................................... 22
Table 14: Summary of reliability test conditions............................................................. 23
Table 15: Pad assignments............................................................................................ 25
Table 16: Power supply ratings...................................................................................... 26
BGS2-E/BGS2-W Hardware Interface Overview
Figures
110
BGS2_HIO_v01.300 Page 5 of 110 2011-03-08
Confidential / Released
Figures
Figure 1: Numbering plan for connecting pads (bottom view)....................................... 24
Figure 2: BGS2-E/BGS2-W– top and bottom view........................................................ 27
Figure 3: Reference equipment for Type Approval ....................................................... 28
BGS2-E/BGS2-W Hardware Interface Overview
1 Introduction
14
BGS2_HIO_v01.300 Page 6 of 29 2011-03-08
Confidential / Released
1 Introduction
This document1 describes the hardware of the Cinterion BGS2-E/BGS2-W module that connects to the cellular device application and the air interface. It helps you quickly retrieve interface specifications, electrical and mechanical details and information on the requirements to be
considered for integrating further components.
1.1 Related Documents
[1] BGS2-E/BGS2-W AT Command Set
[2] BGS2-E/BGS2-W Release Note
1.2 Terms and Abbreviations
1. The document is effective only if listed in the appropriate Release Notes as part of the technical
documentation delivered with your Cinterion product.
Abbreviation Description
ADC Analog-to-digital converter
AGC Automatic Gain Control
ANSI American National Standards Institute
ARFCN Absolute Radio Frequency Channel Number
ARP Antenna Reference Point
ASC0/ASC1 Asynchronous Controller. Abbreviations used for first and second serial interface of
BGS2-E/BGS2-W
B Thermistor Constant
BER Bit Error Rate
BTS Base Transceiver Station
CB or CBM Cell Broadcast Message
CE Conformité Européene (European Conformity)
CHAP Challenge Handshake Authentication Protocol
CPU Central Processing Unit
CS Coding Scheme
CSD Circuit Switched Data
CTS Clear to Send
DAC Digital-to-Analog Converter
DAI Digital Audio Interface
dBm0 Digital level, 3.14dBm0 corresponds to full scale, see ITU G.711, A-law
DCE Data Communication Equipment (typically modems, e.g. Cinterion GSM module)
DCS 1800 Digital Cellular System, also referred to as PCN
BGS2-E/BGS2-W Hardware Interface Overview
1.2 Terms and Abbreviations
14
BGS2_HIO_v01.300 Page 7 of 29 2011-03-08
Confidential / Released
DRX Discontinuous Reception
DSB Development Support Box
DSP Digital Signal Processor
DSR Data Set Ready
DTE Data Terminal Equipment (typically computer, terminal, printer or, for example, GSM
application)
DTR Data Terminal Ready
DTX Discontinuous Transmission
EFR Enhanced Full Rate
EGSM Enhanced GSM
EIRP Equivalent Isotropic Radiated Power
EMC Electromagnetic Compatibility
ERP Effective Radiated Power
ESD Electrostatic Discharge
ETS European Telecommunication Standard
FCC Federal Communications Commission (U.S.)
FDMA Frequency Division Multiple Access
FR Full Rate
GMSK Gaussian Minimum Shift Keying
GPIO General Purpose Input/Output
GPRS General Packet Radio Service
GSM Global Standard for Mobile Communications
HiZ High Impedance
HR Half Rate
I/O Input/Output
IC Integrated Circuit
IMEI International Mobile Equipment Identity
ISO International Standards Organization
ITU International Telecommunications Union
kbps kbits per second
LED Light Emitting Diode
Li-Ion/Li+ Lithium-Ion
Li battery Rechargeable Lithium Ion or Lithium Polymer battery
Mbps Mbits per second
MMI Man Machine Interface
MO Mobile Originated
MS Mobile Station (GSM module), also referred to as TE
MSISDN Mobile Station International ISDN number
Abbreviation Description
BGS2-E/BGS2-W Hardware Interface Overview
1.2 Terms and Abbreviations
14
BGS2_HIO_v01.300 Page 8 of 29 2011-03-08
Confidential / Released
MT Mobile Terminated
NTC Negative Temperature Coefficient
OEM Original Equipment Manufacturer
PA Power Amplifier
PAP Password Authentication Protocol
PBCCH Packet Switched Broadcast Control Channel
PCB Printed Circuit Board
PCL Power Control Level
PCM Pulse Code Modulation
PCN Personal Communications Network, also referred to as DCS 1800
PCS Personal Communication System, also referred to as GSM 1900
PDU Protocol Data Unit
PLL Phase Locked Loop
PPP Point-to-point protocol
PSK Phase Shift Keying
PSU Power Supply Unit
PWM Pulse Width Modulation
R&TTE Radio and Telecommunication Terminal Equipment
RAM Random Access Memory
RF Radio Frequency
RMS Root Mean Square (value)
RoHS Restriction of the use of certain hazardous substances in electrical and electronic
equipment.
ROM Read-only Memory
RTC Real Time Clock
RTS Request to Send
Rx Receive Direction
SAR Specific Absorption Rate
SAW Surface Accoustic Wave
SELV Safety Extra Low Voltage
SIM Subscriber Identification Module
SMD Surface Mount Device
SMS Short Message Service
SMT Surface Mount Technology
SRAM Static Random Access Memory
TA Terminal adapter (e.g. GSM module)
TDMA Time Division Multiple Access
TE Terminal Equipment, also referred to as DTE
Abbreviation Description
BGS2-E/BGS2-W Hardware Interface Overview
1.2 Terms and Abbreviations
14
BGS2_HIO_v01.300 Page 9 of 29 2011-03-08
Confidential / Released
Tx Transmit Direction
UART Universal asynchronous receiver-transmitter
URC Unsolicited Result Code
USSD Unstructured Supplementary Service Data
VSWR Voltage Standing Wave Ratio
Abbreviation Description
BGS2-E/BGS2-W Hardware Interface Overview
1.3 Regulatory and Type Approval Information
14
BGS2_HIO_v01.300 Page 10 of 29 2011-03-08
Confidential / Released
1.3 Regulatory and Type Approval Information
1.3.1 Directives and Standards
BGS2-E/BGS2-W is designed to comply with the directives and standards listed below.
It is the responsibility of the application manufacturer to ensure compliance of the final product
with all provisions of the applicable directives and standards as well as with the technical specifications provided in the "BGS2-E/BGS2-W Hardware Interface Description".
1
1. Manufacturers of applications which can be used in the US shall ensure that their applications have a
PTCRB approval. For this purpose they can refer to the PTCRB approval of the respective module.
Table 1: Directives
1999/05/EC Directive of the European Parliament and of the council of 9 March 1999
on radio equipment and telecommunications terminal equipment and the
mutual recognition of their conformity (in short referred to as R&TTE Directive 1999/5/EC).
The product is labeled with the CE conformity mark
2002/95/EC Directive of the European Parliament and of the Council
of 27 January 2003 on the restriction of the use of certain
hazardous substances in electrical and electronic equipment (RoHS)
Table 2: Standards of North American type approval
1
1. Applies for the quad band module variant BGS2-W only.
CFR Title 47 Code of Federal Regulations, Part 22 and Part 24 (Telecommunications,
PCS); US Equipment Authorization FCC
UL 60 950-1 Product Safety Certification (Safety requirements)
NAPRD.03 V5.4 Overview of PCS Type certification review board Mobile Equipment Type
Certification and IMEI control
PCS Type Certification Review board (PTCRB)
RSS132 (Issue2)
RSS133 (Issue5)
Canadian Standard
Table 3: Standards of European type approval
3GPP TS 51.010-1 Digital cellular telecommunications system (Phase 2); Mobile Station (MS)
conformance specification
ETSI EN 301 511 V9.0.2 Candidate Harmonized European Standard (Telecommunications series)
Global System for Mobile communications (GSM); Harmonized standard
for mobile stations in the GSM 900 and DCS 1800 bands covering essential requirements under article 3.2 of the R&TTE directive (1999/5/EC)
(GSM 13.11 version 7.0.1 Release 1998)
GCF-CC V3.40 Global Certification Forum - Certification Criteria
BGS2-E/BGS2-W Hardware Interface Overview
1.3 Regulatory and Type Approval Information
14
BGS2_HIO_v01.300 Page 11 of 29 2011-03-08
Confidential / Released
ETSI EN 301 489-1
V1.8.1
Candidate Harmonized European Standard (Telecommunications series)
Electro Magnetic Compatibility and Radio spectrum Matters (ERM); Electro Magnetic Compatibility (EMC) standard for radio equipment and services; Part 1: Common Technical Requirements
ETSI EN 301 489-7
V1.3.1
Candidate Harmonized European Standard (Telecommunications series)
Electro Magnetic Compatibility and Radio spectrum Matters (ERM); Electro Magnetic Compatibility (EMC) standard for radio equipment and services; Part 7: Specific conditions for mobile and portable radio and
ancillary equipment of digital cellular radio telecommunications systems
(GSM and DCS)
EN 60950-1:2006 Safety of information technology equipment
Table 4: Requirements of quality
IEC 60068 Environmental testing
DIN EN 60529 IP codes
Table 5: Standards of the Ministry of Information Industry of the People’s Republic of China
SJ/T 11363-2006 “Requirements for Concentration Limits for Certain Hazardous Sub-
stances in Electronic Information Products” (2006-06).
SJ/T 11364-2006 “Marking for Control of Pollution Caused by Electronic
Information Products” (2006-06).
According to the “Chinese Administration on the Control
of Pollution caused by Electronic Information Products”
(ACPEIP) the EPUP, i.e., Environmental Protection Use
Period, of this product is 20 years as per the symbol
shown here, unless otherwise marked. The EPUP is valid only as long as
the product is operated within the operating limits described in the Cinterion Wireless Modules Hardware Interface Description.
Please see Table 6 for an overview of toxic or hazardous substances or
elements that might be contained in product parts in concentrations
above the limits defined by SJ/T 11363-2006.
Table 3: Standards of European type approval
BGS2-E/BGS2-W Hardware Interface Overview
1.3 Regulatory and Type Approval Information
14
BGS2_HIO_v01.300 Page 12 of 29 2011-03-08
Confidential / Released
Table 6: Toxic or hazardous substances or elements with defined concentration limits
BGS2-E/BGS2-W Hardware Interface Overview
1.3 Regulatory and Type Approval Information
14
BGS2_HIO_v01.300 Page 13 of 29 2011-03-08
Confidential / Released
1.3.2 SAR requirements specific to portable mobiles
Mobile phones, PDAs or other portable transmitters and receivers incorporating a GSM module
must be in accordance with the guidelines for human exposure to radio frequency energy. This
requires the Specific Absorption Rate (SAR) of portable BGS2-E/BGS2-W based applications
to be evaluated and approved for compliance with national and/or international regulations.
Since the SAR value varies significantly with the individual product design manufacturers are
advised to submit their product for approval if designed for portable use. For European and US
markets the relevant directives are mentioned below. It is the responsibility of the manufacturer
of the final product to verify whether or not further standards, recommendations or directives
are in force outside these areas.
Products intended for sale on US markets
1
ES 59005/ANSI C95.1 Considerations for evaluation of human exposure to Electromagnetic
Fields (EMFs) from Mobile Telecommunication Equipment (MTE) in the
frequency range 30MHz - 6GHz
Products intended for sale on European markets
EN 50360 Product standard to demonstrate the compliance of mobile phones with
the basic restrictions related to human exposure to electromagnetic
fields (300MHz - 3GHz)
1. Applies for the quad band module variant BGS2-W only.
BGS2-E/BGS2-W Hardware Interface Overview
1.3 Regulatory and Type Approval Information
14
BGS2_HIO_v01.300 Page 14 of 29 2011-03-08
Confidential / Released
1.3.3 Safety Precautions
The following safety precautions must be observed during all phases of the operation, usage,
service or repair of any cellular terminal or mobile incorporating BGS2-E/BGS2-W. Manufacturers of the cellular terminal are advised to convey the following safety information to users
and operating personnel and to incorporate these guidelines into all manuals supplied with the
product. Failure to comply with these precautions violates safety standards of design, manufacture and intended use of the product. Cinterion Wireless Modules assumes no liability for
customer’s failure to comply with these precautions.
When in a hospital or other health care facility, observe the restrictions on the use of
mobiles. Switch the cellular terminal or mobile off, if instructed to do so by the guidelines posted in sensitive areas. Medical equipment may be sensitive to RF energy.
The operation of cardiac pacemakers, other implanted medical equipment and hearing aids can be affected by interference from cellular terminals or mobiles placed close
to the device. If in doubt about potential danger, contact the physician or the manufacturer of the device to verify that the equipment is properly shielded. Pacemaker
patients are advised to keep their hand-held mobile away from the pacemaker, while
it is on.
Switch off the cellular terminal or mobile before boarding an aircraft. Make sure it cannot be switched on inadvertently. The operation of wireless appliances in an aircraft is
forbidden to prevent interference with communications systems. Failure to observe
these instructions may lead to the suspension or denial of cellular services to the
offender, legal action, or both.
Do not operate the cellular terminal or mobile in the presence of flammable gases or
fumes. Switch off the cellular terminal when you are near petrol stations, fuel depots,
chemical plants or where blasting operations are in progress. Operation of any electrical equipment in potentially explosive atmospheres can constitute a safety hazard.
Your cellular terminal or mobile receives and transmits radio frequency energy while
switched on. Remember that interference can occur if it is used close to TV sets,
radios, computers or inadequately shielded equipment. Follow any special regulations
and always switch off the cellular terminal or mobile wherever forbidden, or when you
suspect that it may cause interference or danger.
Road safety comes first! Do not use a hand-held cellular terminal or mobile when driving a vehicle, unless it is securely mounted in a holder for speakerphone operation.
Before making a call with a hand-held terminal or mobile, park the vehicle.
Speakerphones must be installed by qualified personnel. Faulty installation or operation can constitute a safety hazard.
IMPORTANT!
Cellular terminals or mobiles operate using radio signals and cellular networks.
Because of this, connection cannot be guaranteed at all times under all conditions.
Therefore, you should never rely solely upon any wireless device for essential communications, for example emergency calls.
Remember, in order to make or receive calls, the cellular terminal or mobile must be
switched on and in a service area with adequate cellular signal strength.
Some networks do not allow for emergency calls if certain network services or phone
features are in use (e.g. lock functions, fixed dialing etc.). You may need to deactivate
those features before you can make an emergency call.
Some networks require that a valid SIM card be properly inserted in the cellular terminal or mobile.
BGS2-E/BGS2-W Hardware Interface Overview
2 Product Concept
16
BGS2_HIO_v01.300 Page 15 of 29 2011-03-08
Confidential / Released
2 Product Concept
2.1 Key Features at a Glance
Feature Implementation
General
Frequency bands Dual band (BGS2-E): GSM 900/1800MHz
Quad band (BGS2-W): GSM 850/900/1800/1900MHz
GSM class Small MS
Output power (according
to Release 99, V5)
Class 4 (+33dBm ±2dB) for EGSM850 (quad band only)
Class 4 (+33dBm ±2dB) for EGSM900
Class 1 (+30dBm ±2dB) for GSM1800
Class 1 (+30dBm ±2dB) for GSM1900 (quad band only)
Power supply 3.3V to 4.5V
Operating temperature
(board temperature)
Normal operation: -30°C to +85°C
Restricted operation: -40°C to -30°C, +85°C to +90°C
Physical Dimensions: 27.6mm x 18.8mm x 2.7mm
Weight: approx. 3 g
RoHS All hardware components fully compliant with EU RoHS Directive
GSM/GPRS features
Data transfer GPRS:
• Multislot Class 8 (dual band) or 10 (quad band)
• Full PBCCH support
• Mobile Station Class B
• Coding Scheme 1 – 4
CSD:
• V.110, RLP, non-transparent
• 2.4, 4.8, 9.6, 14.4kbps
•USSD
PPP-stack for GPRS data transfer
SMS Point-to-point MT and MO
Cell broadcast
Text and PDU mode
Storage: SIM card plus 25 SMS locations in mobile equipment
Transmission of SMS alternatively over CSD or GPRS. Preferred mode can
be user defined.
Fax Group 3; Class 1
Audio Speech codecs:
• Half rate HR (ETS 06.20)
• Full rate FR (ETS 06.10)
• Enhanced full rate EFR (ETS 06.50/06.60/06.80)
• Adaptive Multi Rate AMR
Handsfree operation, echo cancellation, noise suppression,
7 different ringing tones/melodies
BGS2-E/BGS2-W Hardware Interface Overview
2.1 Key Features at a Glance
16
BGS2_HIO_v01.300 Page 16 of 29 2011-03-08
Confidential / Released
Software
AT commands Hayes 3GPP TS 27.007, TS 27.005, Cinterion
AT commands for RIL compatibility
Microsoft™ compatibility RIL for Pocket PC and Smartphone
SIM Application Toolkit SAT Release 99
TCP/IP stack Protocols: TCP server/client, UDP, HTTP, FTP, SMTP, POP3
Access by AT commands
Firmware update Generic update from host application over ASC0 or ASC1.
Interfaces
Module interface Surface mount device with solderable connection pads (SMT application
interface).
Land grid array (LGA) technology ensures high solder joint reliability and
provides the possibility to use an optional module mounting socket.
2 serial interfaces ASC0:
• 8-wire modem interface with status and control lines, unbalanced, asynchronous
• Adjustable baud rates: 1,200bps to 230,400bps
• Autobauding: 1,200bps to 230
,400bps
• Supports RTS0/CTS0 hardware handshake and software XON/XOFF
flow control.
• Multiplex ability according to GSM 07.10 Multiplexer Protocol.
ASC1:
• 4-wire, unbalanced asynchronous interface
• Adjustable baud rates: 1,200bps to 230,400bps
• Supports RTS1/CTS1 hardware handshake and software XON/XOFF
flow control
Audio 1 analog interface (with microphone feeding)
UICC interface Supported SIM/USIM cards: 3V, 1.8V
External SIM card reader has to be connected via interface connector (note
that card reader is not part of BGS2-E/BGS2-W)
GPIO interface GPIO interface with 10 GPIO lines. The GPIO interface is shared with an
I2C interface, LED signalling and PWM functionality.
Antenna 50
Power on/off, Reset
Power on/off Switch-on by hardware signal ON
Switch-off by AT command (AT^SMSO)
Automatic switch-off in case of critical temperature and voltage conditions.
Reset Orderly shutdown and reset by AT command
Special features
Real time clock Timer functions via AT commands
Phonebook SIM and phone
TTY/CTM support Integrated CTM modem
Feature Implementation
BGS2-E/BGS2-W Hardware Interface Overview
3 Application Interface
18
BGS2_HIO_v01.300 Page 17 of 29 2011-03-08
Confidential / Released
3 Application Interface
BGS2-E/BGS2-W is equipped with an SMT application interface that connects to the external
application. The host interface incorporates several sub-interfaces: power supply, SIM interface, serial interface ASC0, serial interface ASC1, analog audio interface, GPIO interface, I
2
C
interface and PWM interface (for details see Chapter 2 and Section 5.5).
BGS2-E/BGS2-W Hardware Interface Overview
3.1 Operating Modes
18
BGS2_HIO_v01.300 Page 18 of 29 2011-03-08
Confidential / Released
3.1 Operating Modes
The table below briefly summarizes the various operating modes referred to in the following
chapters.
Table 7: Overview of operating modes
Normal operation GSM/GPRS SLEEP Various power save modes set with AT+CFUN command.
Software is active to minimum extent. If the module was
registered to the GSM network in IDLE mode, it is registered
and paging with the BTS in SLEEP mode, too. Power saving can be chosen at different levels: The NON-CYCLIC
SLEEP mode (AT+CFUN=0) disables the AT interface. The
CYCLIC SLEEP modes AT+CFUN=7 and 9 alternatingly
activate and deactivate the AT interfaces to allow permanent access to all AT commands.
GSM IDLE Software is active. Once registered to the GSM network,
paging with BTS is carried out. The module is ready to send
and receive.
GSM TALK Connection between two subscribers is in progress. Power
consumption depends on network coverage individual settings, such as DTX off/on, FR/EFR/HR, hopping
sequences, antenna.
GPRS IDLE Module is ready for GPRS data transfer, but no data is cur-
rently sent or received. Power consumption depends on
network settings and GPRS configuration (e.g. multislot settings).
GPRS DATA GPRS data transfer in progress. Power consumption
depends on network settings (e.g. power control level),
uplink/downlink data rates, GPRS configuration (e.g. used
multislot settings) and reduction of maximum output power.
Power Down Normal shutdown after sending the AT^SMSO command.
Only a voltage regulator is active for powering the RTC. Software is not active.
Interfaces are not accessible.
Operating voltage (connected to BATT+) remains applied.
Alarm mode Restricted operation launched by RTC alert function while the module is in Power
Down mode. Module will not be registered to GSM network. Limited number of AT
commands is accessible.
BGS2-E/BGS2-W Hardware Interface Overview
4 Antenna Interface
19
BGS2_HIO_v01.300 Page 19 of 29 2011-03-08
Confidential / Released
4 Antenna Interface
The RF interface has an impedance of 50Ω. BGS2-E/BGS2-W is capable of sustaining a total
mismatch at the antenna lines without any damage, even when transmitting at maximum RF
power.
The external antenna must be matched properly to achieve best performance regarding radiated power, modulation accuracy and harmonic suppression. Antenna matching networks are
not included on the BGS2-E/BGS2-W module and should be placed in the host application if
the antenna does not have an impendance of 50Ω.
Regarding the return loss BGS2-E/BGS2-W provides the following values in the active band:
Table 8: Return loss in the active band
State of module Return loss of module Recommended return loss of application
Receive >
8dB > 12dB
Transmit not applicable >
12dB
BGS2-E/BGS2-W Hardware Interface Overview
5 Electrical, Reliability and Radio Characteristics
26
BGS2_HIO_v01.300 Page 20 of 29 2011-03-08
Confidential / Released
5 Electrical, Reliability and Radio Characteristics
5.1 Absolute Maximum Ratings
The absolute maximum ratings stated in Table 9 are stress ratings under any conditions.
Stresses beyond any of these limits will cause permanent damage to BGS2-E/BGS2-W.
Table 9: Absolute maximum ratings
Parameter Min Max Unit
Supply voltage BATT+ -0.3 +6.0 V
Voltage at all digital lines in Power Down mode -0.3 +0.3 V
Voltage at digital lines 1.8V domain in normal operation -0.3 +2.2 V
Voltage at digital lines VDIG domain (1.8V) in normal operation
-0.3 +2.2 V
Voltage at digital lines VDIG domain (2.85V) in normal operation
-0.3 +3.3 V
Voltage at SIM interface, CCVCC 1.8V in normal Operation -0.3 +2.2 V
Voltage at SIM interface, CCVCC 2.85V in normal Operation -0.3 +3.3 V
Voltage at analog lines in normal operation -0.3 +3.0 V
Voltage at analog lines in Power Down mode -0.3 +0.3 V
VDDLP -0.3 +2.5 V
BGS2-E/BGS2-W Hardware Interface Overview
5.2 Operating Temperatures
26
BGS2_HIO_v01.300 Page 21 of 29 2011-03-08
Confidential / Released
5.2 Operating Temperatures
Please note that the module’s lifetime, i.e., the MTTF (mean time to failure) may be reduced, if
operated outside the restriced temperature range. A special URC reports whether the module
enters or leaves the restriced temperature range (see [1]; AT^SCTM).
Note that within the specified operating temperature ranges the board temperature may vary
to a great extent depending on operating mode, used frequency band, radio output power and
current supply voltage.
When data are transmitted over GPRS the quad band module variant automatically reverts to
a lower Multislot Class if the temperature rises to the limit specified for normal operation and,
vice versa, returns to the higher Multislot Class if the temperature is back to normal.
Table 10: Board temperature
Parameter Min Typ Max Unit
Normal operation -30 +25 +85 °C
Restricted operation -40 to -30 +85 to +90 °C
Automatic shutdown
1
Temperature measured on BGS2-E/BGS2-W
board
1. Due to temperature measurement uncertainty, a tolerance of ±3°C on the thresholds may occur.
<-40 --- >+90 °C
Table 11: Ambient temperature according to IEC 60068-2 (w/o forced air circulation)
Parameter Min Typ Max Unit
GSM Call @ max. RF-Power -40 +75 °C
GPRS Class 8 @ max. RF-Power -40 +75 °C
GPRS Class 10 @ max. RF-Power (quad band only) -40 +60 °C
Table 12: Ambient temperature with forced air circulation (air speed 0.9m/s)
Parameter Min Typ Max Unit
GSM Call @ max. RF-Power -40 +80 °C
GPRS Class 8 @ max. RF-Power -40 +80 °C
GPRS Class 10 @ max. RF-Power (quad band only) -40 +70 °C
BGS2-E/BGS2-W Hardware Interface Overview
5.3 Storage Conditions
26
BGS2_HIO_v01.300 Page 22 of 29 2011-03-08
Confidential / Released
5.3 Storage Conditions
BGS2-E/BGS2-W modules, as delivered in tape and reel carriers, must be stored in sealed,
moisture barrier anti-static bags. The conditions stated below are only valid for modules in their
original packed state in weather protected, non-temperature-controlled storage locations. Normal storage time under these conditions is 12 months maximum.
Table 13: Storage conditions
Type Condition Unit Reference
Air temperature: Low
High
-25
+40
°C IPC/JEDEC J-STD-033A
Humidity relative: Low
High
10
90 at 40°C
%
IPC/JEDEC J-STD-033A
Air pressure: Low
High
70
106
kPa IEC TR 60271-3-1: 1K4
IEC TR 60271-3-1: 1K4
Movement of surrounding air 1.0 m/s IEC TR 60271-3-1: 1K4
Water: rain, dripping, icing and
frosting
Not allowed --- ---
Radiation: Solar
Heat
1120
600
W/m
2
ETS 300 019-2-1: T1.2, IEC 60068-2-2 Bb
ETS 300 019-2-1: T1.2, IEC 60068-2-2 Bb
Chemically active substances Not
recommended
IEC TR 60271-3-1: 1C1L
Mechanically active substances Not
recommended
IEC TR 60271-3-1: 1S1
Vibration sinusoidal:
Displacement
Acceleration
Frequency range
1.5
5
2-9 9-200
mm
m/s
2
Hz
IEC TR 60271-3-1: 1M2
Shocks:
Shock spectrum
Duration
Acceleration
semi-sinusoidal
1
50
ms
m/s
2
IEC 60068-2-27 Ea
BGS2-E/BGS2-W Hardware Interface Overview
5.4 Reliability Characteristics
26
BGS2_HIO_v01.300 Page 23 of 29 2011-03-08
Confidential / Released
5.4 Reliability Characteristics
The test conditions stated below are an extract of the complete test specifications.
Table 14: Summary of reliability test conditions
Type of test Conditions Standard
Vibration Frequency range: 10-20Hz; acceleration: 5g
Frequency range: 20-500Hz; acceleration: 20g
Duration: 20h per axis; 3 axes
DIN IEC 60068-2-6
1
1. For reliability tests in the frequency range 20-500Hz the Standard’s acceleration reference value was
increased to 20g.
Shock half-sinus Acceleration: 500g
Shock duration: 1msec
1 shock per axis
6 positions (± x, y and z)
DIN IEC 60068-2-27
Dry heat Temperature: +70 ±2°C
Test duration: 16h
Humidity in the test chamber: < 50%
EN 60068-2-2 Bb
ETS 300 019-2-7
Temperature
change (shock)
Low temperature: -40°C ±2°C
High temperature: +85°C ±2°C
Changeover time: < 30s (dual chamber system)
Test duration: 1h
Number of repetitions: 100
DIN IEC 60068-2-14 Na
ETS 300 019-2-7
Damp heat cyclic High temperature: +55°C ±2°C
Low temperature: +25°C ±2°C
Humidity: 93% ±3%
Number of repetitions: 6
Test duration: 12h + 12h
DIN IEC 60068-2-30 Db
ETS 300 019-2-5
Cold (constant
exposure)
Temperature: -40 ±2°C
Test duration: 16h
DIN IEC 60068-2-1
BGS2-E/BGS2-W Hardware Interface Overview
5.5 Pad Assignment
26
BGS2_HIO_v01.300 Page 24 of 29 2011-03-08
Confidential / Released
5.5 Pad Assignment
The SMT application interface on the BGS2-E/BGS2-W provides connecting pads to integrate
the module into external applications. Figure 1 shows the connecting pads’ numbering plan,
the following Table 15 lists the pads’ assignments.
Figure 1: Numbering plan for connecting pads (bottom view)
53
65
64
63
62
61
60
59
58
57
56
55
54
66
33
21
22
23
24
25
26
27
28
29
30
31
32
20
107
1009998979695949392
83 84 85 86 88 89 90 91
828180797877767574
73727170696867
106105104103102101
87
44
19181716151413121110987654321
343536373839404142434546474849505152
Supply pads: BATT+
Control pads
GND pads
Analog audio pads
ASC0 pads
ASC1 pads
SIM pads
GPIO pads
RF antenna pad
Do not use
ADC pad
Supply pads: Other
BGS2-E/BGS2-W Hardware Interface Overview
5.5 Pad Assignment
26
BGS2_HIO_v01.300 Page 25 of 29 2011-03-08
Confidential / Released
Signal pads that are not used should not be connected to an external application.
Table 15: Pad assignments
Pad no. Signal name Pad no. Signal name Pad no. Signal name
1
VMIC 23
Do not use
45 GND
2
EPN1 24
DSR0
46 GND
3
EPP1 25
DTR0
47 GND
4
GND 26
DCD0
48 GND
5
BATT+ 27
GPIO9/I2CDAT
49 GND
6
GND 28
GPIO10/I2CCLK
50 GND
7
ADC1 29
TXD1
51 GND
8
ON 30
RXD1
52 GND
9
GND 31
RTS1
53 BATT+
10 VDIG 32
CTS1
54 GND
11
RXD0 33
EMERG_RST
55 GND
12
CTS0 34
GND
56 GND
13
TXD0 35
V180
57 GND
14
RING0 36
GPIO8
58 GND
15
RTS0
37
GPIO7/PWM1
59 RF_OUT
16
VDDLP
38
GPIO6/PWM2
60 GND
17
CCRST 39
GPIO5/LED
61 GND
18
CCIN
40
GPIO4
62 GND
19
CCIO
41
GPIO3
63 GND
20
CCVCC
42
GPIO2
64 AGND
21
CCCLK
43
GPIO1
65 MICP1
22
V285 44 GND 66 MICN1
67-107 GND
1
1. The pads 67-107 are located at the centre of the module and should be connected to Ground except for
pad 106 that is only required for factory tests. Pad 106 must not be connected to the external application,
but should be left open.
BGS2-E/BGS2-W Hardware Interface Overview
5.6 Power Supply Ratings
26
BGS2_HIO_v01.300 Page 26 of 29 2011-03-08
Confidential / Released
5.6 Power Supply Ratings
Table 16: Power supply ratings
1
1. GSM850 and GSM1900 bands are applicable for the quad band module variant BGS2-W only.
Parameter
Description Conditions Min Typ Max Unit
BATT+ Supply voltage Voltage must stay within the min/
max values, including voltage
drop, ripple and spikes.
3.3 4.0 4.5 V
Voltage drop during
transmit burst
Normal condition, power control
level for P
out max
400 mV
Voltage ripple Normal condition, power control
level for P
out max
@ f<250kHz
@ f>250kHz
85
25
mVpp
I
VDDLP
OFF state supply
current
RTC backup
@ BATT+ = 0V
@ VDDLP = 2.3V
8.0 µA
Power Down mode 45 µA
I
BATT+
Average supply current
SLEEP mode, GSM2
@ DRX = 2
@ DRX = 5
@ DRX = 9
2. Measurements start 3 minutes after the module was switched ON,
Averaging times: SLEEP mode - 3 minutes; IDLE mode - 1.5 minutes,
Communication tester settings: no neighbour cells, no cell reselection etc.
2.1
1.5
1.1
mA
SLEEP mode, GPRS
2
@ DRX = 2
@ DRX = 5
@ DRX = 9
2.2
1.5
1.2
mA
IDLE mode
2
8.6 mA
TALK mode GSM
GSM850/EGSM 900
3
GSM 1800/1900
4
3. Power control level PCL 5
4. Power control level PCL 0
200
150
mA
DATA mode GPRS 1 TX, 4 Rx
GSM 850/EGSM 900
3
GSM 1800/1900
4
180
145
mA
DATA mode GPRS 2 Tx, 3 Rx
GSM 850/EGSM 900
3
GSM 1800/1900
4
330
260
mA
Peak supply current
(during transmission
slot every 4.6ms)
Power Control Level
GSM 850/EGSM 900
3
GSM 1800/1900
4
1.30
0.95
1.35
0.97
A
BGS2-E/BGS2-W Hardware Interface Overview
6 Mechanics, Mounting and Packaging
27
BGS2_HIO_v01.300 Page 27 of 29 2011-03-08
Confidential / Released
6 Mechanics, Mounting and Packaging
The following sections describe the mechanical dimensions of BGS2-E/BGS2-W and give recommendations for integrating BGS2-E/BGS2-W into the host application.
6.1 Mechanical Dimensions of BGS2-E/BGS2-W
Figure 2 shows the top and bottom view of BGS2-E/BGS2-W and provides an overview of the
board's mechanical dimensions.
Figure 2: BGS2-E/BGS2-W– top and bottom view
Product label
Top view
Bottom view
BGS2-E/BGS2-W Hardware Interface Overview
7 Reference Approval
29
BGS2_HIO_v01.300 Page 28 of 29 2011-03-08
Confidential / Released
7 Reference Approval
7.1 Reference Equipment for Type Approval
The Cinterion Wireless Modules reference setup submitted to type approve BGS2-E/BGS2-W
is shown in the following figure:
Figure 3: Reference equipment for Type Approval
BGS2 adapter
Antenna
GSM Antenna with 1m
cable
ASC0
PC
Power Supply
GSM / GPRS / UMTS
Base Station
DSB75
Evaluation module
extern connected via
flexible cable and
60to80 pin adapter
Audio Test System
Handset
ASC1
SIM card
SMA
SMA
RF reference point on
60to80 pin adapter
Audio
BGS2
BGS2
BGS2-E/BGS2-W Hardware Interface Overview
7.2 Compliance with FCC and IC Rules and Regulations
29
BGS2_HIO_v01.300 Page 29 of 29 2011-03-08
Confidential / Released
7.2 Compliance with FCC and IC Rules and Regulations
The Equipment Authorization Certification for the Cinterion Wireless Modules reference application described in Section 7.1 will be registered under the following identifiers
1
:
FCC Identifier: QIPBGS2
Industry Canada Certification Number: 7830A-BGS2
Granted to Cinterion Wireless Modules GmbH
Manufacturers of mobile or fixed devices incorporating BGS2-W modules are authorized to use
the FCC Grants and Industry Canada Certificates of the BGS2-W modules for their own final
products according to the conditions referenced in these documents. In this case, an FCC/ IC
label of the module shall be visible from the outside, or the host device shall bear a second label
stating "Contains FCC ID QIPBGS2", and accordingly “Contains IC 7830A-BGS2“.
IMPORTANT:
Manufacturers of portable applications incorporating BGS2-W modules are required to have
their final product certified and apply for their own FCC Grant and Industry Canada Certificate
related to the specific portable mobile. This is mandatory to meet the SAR requirements for portable mobiles (see Section 1.3.2 for detail).
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
1. Applies only for the quad band module variant BGS2-W.
