WIRELESS IMAGER
Reference Manual
International Edition, Rev. C5
Revision History
Rev. No. Released Date Description
Rev. A Oct 16, 2009 First Release
Rev. A1 Oct 22, 2009
Rev. A2 Nov 27, 2009
Rev. A3 Mar 05, 2010
Rev. A4 Apr 27, 2010
Rev. A5 Jun 28, 2010
Page 6 Revise “Clone Function” operation method.
Page 68 Add “Save Configuration” and “Master Default” to System Commands.
Page 53 “Bluetooth Device Name” – Modify user define characters from 1 – 14 characters to
1 – 16 characters.
Page 69 Add “Indications”.
Page 25 Modify UPC-E/EAN-8 expansion and UPC-A standardization.
Page 43 Rename “Time Out Control” to “Serial Response Time-out”.
Page 45 Rename “Presentation Scanning Mode” to “Presentation Control”.
Page 48 Rename “Auto Power Off Duration” to “Light Source On Time”.
Add “Extremely short” option to Good Read Duration.
Page 49 Rename “Presentation Scanning Auto-sense” to “Presentation Auto-sense”.
Add “Presentation Sensitivity”
Page 38 Hands Free Time-out – Add “Disable”.
Page 43 Baud Rate – Add 57.6K BPS and 115.2K BPS.
Page 27 Add “UPC/EAN Security Level”.
Page 49 Add “Time Delay to Low Power Trigger”
Page 47 Add “Good Read Indicator”.
Page 48 Add “Scan Vo ting”.
Rev. A6 Sep 20, 2010
Wireless FuzzyScan
Reference Manual
Page 25,26 Rename ”Scan Voting” to “Supplement Scan Voting” and add “Supplement Scan
Voting” in Symbology Reading Control
Page 27 Add “EAN Supplement Control”
Page 38 Keyboard Layout – Add “Czech (QWERTY)”, remove “Universal”, and rename
Spain (QWERTY) to Spain (Spanish QWERTY), Latin America (QWERTY) to Spain
(Latin America, QWERTY)
Revision History
Rev. No. Released Date Description
Page 48 Remove ”Scan V oting” and add “Scan Rate Control ”
Rev. A6 Sep 20, 2010
Page 54 Add “<Scanned Data><Field Delimiter><Quantity>” parameter selection in Batch Data
Quantity Output Format.
Rev. A7 Nov 10, 2010
Rev. A8 Jan 2, 2011
Rev. A9 Mar 04, 2011 Page 44 Baud Rate – Revise 57.6K BPS and 115.2K BPS option code from 6.7. to 8.9.
Rev. B1 Mar 22, 2011
Rev. B2 Jul 22, 2011
Page 44 Baud Rate – Cancel Baud Rate 300/600 BPS.
Page 47 Buzzer Tone Adjust – Modify No power-on beep behavior. The setting of No
power-on beep will impact both Bluetooth Scanner and Smart Cradle.
Add “Beeping Control” setting.
Page 23 Add ”Code 39 Security Level”.
Page 45 Add “NAK Retry Count”.
Add “ACK/NAK Tran smission Indication”.
Page 69 Add “Numeric Bar Codes ”.
Page 73 Add “Connecting Apple iOS Devices Quick Sets”.
Page 19, 29, 34, 67 UCC/EAN-128 was renamed GS1-128.
Page 45 Rename “ACK/NAK Tran smission Indication” to “ACK Indication”.
Page 45 Rename the 2 parameters of the “ACK Indication”.
(Disable→ Disable ACK Time-out Indication, Enable→ Enable ACK Time-out
Indication)
Page 45 Add 2 new parameters to “ACK Indication”.(Disable ACK Indication, Enable ACK
Indication)
Wireless FuzzyScan
Reference Manual
Page 47 Add 6 parameters to “Serial response time -out”. (800 m seconds, 3 seconds, 4
seconds, 8 seconds, 10 seconds, 15 seconds)
Page 47 Cancel the parameter "User defined value (seconds)” of “Serial response time
-out”.
Page 54 Add “Laser Aiming Control” function.
Revision History
Rev. No. Released Date Description
Rev. B3 Nov 04, 2011
Rev. B4 Jan 03, 2012
Rev. B5 Mar 05, 2012
Rev. B6 Jul 25, 2012
Rev. B7 Aug 20, 2013
Page 3, 5, 10 “Paging/ Reset button” is changed from 3 seconds to 5 se conds.
Page 24 Add a new function “Codabar Check Digit Settings”
Page 49 Cancel 1 parameter of “Code 39/Code 128 Emulation”.(Disable standard cod 39
emulation - -0)
Page 49 Change of default setting to Enable standard code 39 skip emulation in “Code 39/
Code 128 Emulation”.
(Disable standard code 39 emulation (0)→ Enable standard code 39 skip
emulation (1))
Page 56 Add 3 new functions:”1D Barcode Forward-reading Indication”, “1D Barcode
Backward-reading Indication”, “1D Barcode Direction Indication Transmission”
Page 18 Add ”USB HID Legacy” option for “Host Interface Selection”.
Page 23 Add “Code 128 security level”
Page 49 Restore the behavior and default setting of the Code39/Code 128 Emulation in
“Wand/Laser Emulation Control” function.
Page 56 Add “LED illumination Control” and “LED Illumination Delay” functions for Trigger
Mode and Low Power Mode.
Page 21 Modify “Readable Bar Code Setting” section
Page 69 Modify “Symbology ID Table”
Rev. C1
Wireless FuzzyScan
Reference Manual
Jan 15, 2014
Jan 23, 2014
Support 2D Functions
Page 2 Change the indicator of full charged status to “steady green”
Page 7 Add “HID Legacy Mode” and HID Mode with Passkey”
Page 10 Add “Sleep Mode” and “Power Off”
Page 11 Modified “Quantity Feature” of Batch Scanning
Page 69 Modified “Presentation Sensitivity”
Revision History
Rev. No. Released Date Description
Support 1D Pocket Scanner
Page 21: Add “USB EFT Terminal Mode” for “Host Interface Selection”.
Rev. C2 May 08, 2014
Page 96 add “USB HID Legacy Mode” Host Interface Quick Set Command.
Page 97 Add “Abort” Quick Set Command
Rev. C3 May 09, 2014
Rev. C4 Feb. 06, 2015
Rev. C5 Mar. 09, 2015
Page 16 Add “Clear All Scanned Data” Command.
Page 50 Add “MaxiCode Setting”
Page 13 Add “Paging Function”
Page 71 Add “Radio Connection Beeps”
Page 73 Add “HID Mode Transmit Delay”
Page 85 Remove “HID Link Quality Setting” and add “Link Quality Control”
Wireless FuzzyScan
Reference Manual
© Copyright PC Worth Int’l Co., Ltd
Cino makes no warranty of any kind with regard to this publication, including, but not limited to, the implied warranty of
merchantability and fitness for any particular purpose. Cino shall not be liable for errors contained herein or for incidental
consequential damages in connection with the furnishing, performance, or use of this publication. This publication contains
proprietary information that is protected by copyright. All rights are reserved. No part of this publication may be photocopied,
reproduced or translated into any language, in any forms, in an electronic retrieval system or otherwise, without prior written
permission of Cino. All product information and specifications shown in this document may be changed without prior notice.
Warranty
Cino warrants its products against defects in workmanship and materials from the date of shipment, provided that the
product is operated under normal and proper conditions. The warranty provisions and durations are furnished by different
warranty programs. The above warranty does not apply to any product which has been (i) misused; (ii) damaged by accident
or negligence; (iii) modified or altered by the purchaser or other party; (iv) repaired or tampered by unauthorized
representatives; (v) operated or stored beyond the specified operational and environmental parameters; (vi) applied
software, accessories or parts are not supplied by Cino; (vii) damaged by circumstances out of Cino’s control, such as, but
not limited to, lightning or fluctuation in electrical power. Any defective product must follow the warranty program and RMA
procedures to return Cino for inspection.
Regulatory
EN61000-6-2, EN61000-6-3, EN60950-1, EN301 489-1, EN301 489-17, EN300 328
Wireless FuzzyScan
Reference Manual
FCC part 15B, FCC part 15C
EN55022, EN55024
CNS13438, CNS14336
AS/NZS CISPR 22:2009 Class B
Clause 2, Article 58-2 of Radio Waves Act
V.3/2011.04, Technical Requirements, Class B ITE
LED Eye Safety IEC62471 Exempt group
Laser Eye Safety IEC60825-1 Class 1
LP0002
MIC T401
Wireless FuzzyScan
Reference Manual
Table of Contents
Getting Started
Getting Familiar with Your FuzzyScan 1
Preparation before Using 3
Decide Your Radio Link Mode 5
Use FuzzyScan in PAIR Mode 6
Use FuzzyScan in PICO Mode 7
Use FuzzyScan in HID Mode 9
Use FuzzyScan in SPP Mode 10
Out-of-range Scanning/Presentation Scanning/Sleep Mode & Power Off 12
Batch Scanning (Inventory Mode) 14
Configure Your FuzzyScan
Bar Code Programming Manual 16
Programming Procedures 18
Host Interface Selection 22
Symbology Reading Control 23
Keyboard Interface Control 54
Serial Interface Control 59
Wand/Laser Emulation Control 63
Operation Control 65
Condensed DataWizard 86
Appendix
Symbology ID Table 94
Keyboard Function Code Table 96
ASCII Input Shortcut 97
Link Mode Quick Set/Operation Mode Quick Set 98
Host Interface Quick Set 99
Option Codes 100
System Commands 102
Indications 103
Wireless FuzzyScan
Reference Manual
Getting Started
Getting Familiar with Your FuzzyScan
Thank you for choosing Cino FuzzyScan Bluetooth Cordless Image Scanner. Powered by the combination of cutting-edge
FuzzyScan Imaging Technology and Bluetooth wireless technology, it not only provides outstanding reading performan ce,
but also delivers the convenience and freedom of mobility. It’s ideal for a broad range of applications to unleash your
productivity with ease. This document provides a quick reference for installation and operation. The complete document ation
is available at www.cino.com.tw.
A770BT Series HB211x Smart Cradle
Central Indicator
Side Indicators
Paging/Reset Button
USB Bus Power Switch
Host Interface Port
DC Power Jack
F780BT & L780BT HB2100 USB Charging Cradle
F680BT & L680BT
Wireless FuzzyScan
Reference Manual
Link Indicator
Status Indicator
Beeper
Scan Window
Trigger
Battery Cavity
End Cap
Central Power Indicator
Reserved
USB Bus Power Switch
USB Port
DC Power Jack
1
Px680BT Scanner
Getting Started
Status Indicator
Power/Link Indicators
Reserved
Function Key 1
Function Key 2
Reserved
Trigger
Battery Cover
Reset Key
Micro USB Port
Scan Window
Wireless FuzzyScan
Reference Manual
Central Indicator
Side Indicators (HB3112 only)
USB Bus Power Switch
Mounting Holes
DC Power Jack
Paging/Reset Key
Host Interface Port (HB3112)
USB Port (HB3100)
2
Getting Started
Preparation before Using – Gun type Scanners
Install the Battery
Charging the Battery
Ensure the battery contacts of the battery pack are facing the charging contacts inside
the battery cavity.
Slide the battery pack into the battery cavity until hearing a click sound before locking it
with the end cap. The scanner will give 4 beeps when the battery pack is installed
properly if the battery pack still has power.
Secure the end cap with the screw provided.
Choose an appropriate plug and slot it into the power adapter cavity until it is locked.
Then plug the AC power plug into the AC wall socket.
Plug the DC power cord of power supply unit into the DC Jack of the cradle. The smart
cradle emits the power-on beeps and the central indicator gives one blue blink. If you
use the charging cradle, the central power indicator turns steady blue.
Place the scanner on the cradle. The status indicator of scanner turns steady red if the
battery is not fully charged. When the battery is fully charged, the status indicator of
scanner turns steady green.
Please charge the new battery pack for 8 hours before its first use.
Use USB Bus Power
Wireless FuzzyScan
Reference Manual
If USB 3.0 is available in your host device, both battery charging and regular operation
can be supported by the USB Bus Power without using external power supply.
If only USB 2.0 is available in your host device, we recommend using external power
supply as power source, because the power supplied from USB2.0 is not enough to
support both battery charging and regular operation simultaneously.
If you want to use this feature, please slide the USB bus power switch to “ON”. Then
connect the cradle to the host device via USB cable.
3
Getting Started
Preparation before Using – Pocket Scanners
Install the Battery
Take off the battery cover from the scanner by removing two blue tapes.
Ensure the battery contacts of the battery pack are facing the charging contacts inside
the battery cavity. Then click the battery pack into the battery cavity carefully.
Place the battery cover in the right orientation onto the back of the scanner. Screw in
and tighten the four shipped M2 screws in sequence by a small screw-driver in the
clockwise direction.
Charging the Battery via Power Supply Unit
Choose the right plug and slot it into the power supply unit cavity until a “click” is heard.
Then plug the power supply unit into the wall outlet
Please make sure the USB bus power switch is in “OFF” position.
Plug the DC connector of the power supply unit into the DC Jack of the cradle. The
cradle emits four beeps. For the Smart cradle, the central indicator blinks blue once
and side indicators lights red. For the charging cradle, the central indicator lights blue.
Charge the Battery via USB 3.0 Port
Wireless FuzzyScan
Reference Manual
Place the scanner onto the cradle. When the battery is fully charged, the status
indicator of scanner will light green.
The scanner can also be charged via the USB 3.0 port without the power supply unit.
You can connect the cradle to USB 3.0 port of host device by a USB cable, then slide
the USB bus power switch to “ON”. After that, place the scanner onto the cradle.
The scanner can also be charged via its micro USB port by connecting the micro USB
cable to USB 3.0 port of host device or the commercial USB power adapter connected
to the wall socket.
4
Getting Started
Decide Your Radio Link Mode
The FuzzyScan Bluetooth image scanner provides several radio link modes to communicate with most host devices. When
the Bluetooth-enabled host device is not available, it can work with the smart cradle in PAIR mode (peer-to-peer connection)
or PICO mode (multiple connections) to provide a plug-and-play cordless migration of your existing non-Bluetooth-enabled
devices. Moreover, you are also able to use the scanner to work with Bluetooth-enabled host devices via SPP mode or HID
mode.
When the radio link is disconnected, the scanner is capable of reconnecting the radio link automat ically when it returns to the
communication coverage. But please note that this feature is not available in SPP slave mode. If you would like to change
the radio link mode, please scan the “Uninstall” command to reset the scanner to uninstall state.
PAIR Mode
If the Bluetooth device is not available in your existing system, PAIR mode is the simplest plug-and-play solution. In this
mode, a smart cradle can only work with one scanner. The smart cradle not only provides the Bluetooth radio link with the
scanner, but also offers the legacy cabled interfaces to the host device, including USB HID, USB COM, PS/2(DOS/V)
Keyboard Wedge and RS232 Serial.
PICO Mode
For the requirement of multiple connections, up to 7 scanners can be connected to one smart cradle concurrently. If you
would like to un-pair all scanners paired with the smart cradle, please press and hold the paging/reset button of the smart
cradle for more than 5 seconds. If you just want to un-pair part of the paired scanners, please take those paired scanners to
scan the “Uninstall” command one by one.
HID Mode
Through the most useful HID service, the scanner can work as a Bluetooth Keyboard. In this mode, the scanner will be
discoverable by the radio connection request issued by the remote host device. For some cases, you may be requested to
enter the Passkey (PIN) to establish the Bluetooth connection for security purpose.
SPP Master/Slave Mode
Through the standard SPP service, the scanner can work as a Bluetooth Serial Device. In SPP master mode, the scanner
initiates the radio connection request to the remote slave device. In SPP slave mode, the scanner will be discoverable by the
radio connection request issued by the remote host device.
Wireless FuzzyScan
Reference Manual
5
Getting Started
Use FuzzyScan in PAIR Mode
Ensure the battery is fully charged. You may refer to the section of Preparations before Using for details.
Please choose your desired interface cable, then plug it into the host interface port of the smart cradle and connect it to
the host device.
Turn on the power of your host device.
Power on or wake up the scanner by pressing the Trigger key if the scanner is power-off or in sleep state.
This scanner is pre-paired with the shipped smart cradle, so you will see the link indicators of scanner blink blue per 2.5
seconds, and the central indicator of the smart cradle light blue. If the scanner and smart cradle are not paired, the
status indicator of scanner and the side indicators of smart cradle blink red and green alternatively (in “Uninstall” state).
Please follow step 6 to establish the connection.
USB
PS/2 RS232
Scan “PAIR mode” command. The status indicator of scanner will turn steady red immediately.
Place the scanner on the smart cradle, then you will hear one short beep to indicate the pairing process is activated. The
scanner will emit continuous short clicks and the link indicator of scanner will flash blue quickly during the p airing process.
When you hear 4 beeps in ascending tone, the pairing process is comple ted. You will see that the link indicator of scanner
gives 1 blue blink per 2.5 seconds and the central indicator of the smart cradle lights blue.
If the scanner pairing process failed or it’s not placed on the smart cradle within 20 seconds, you will hear 2 “Di-do Di-do”
beeps to warn the failure of pairing, the scanner will return to uninstall state automatically.
Scan the corresponding host interface quick set command to complete the installation.
Wireless FuzzyScan
Reference Manual
Uninstall PAIR Mode
The default host interface of smart cradle is preset to USB HID. If you want to set the host interface to USB COM, you
have to install the USB virtual COM driver into your host device before using the scanner. Please visit CINO website to
download the driver.
6
Getting Started
Use FuzzyScan in PICO Mode
Ensure the battery is fully charged and choose your desired interface cable, then plug it into the host interface port of the
smart cradle and connect it to the host device.
Turn on the power of your host device.
Ensure the side indicators of the smart cradle blink red and green alternatively (in “Uninstall” st ate). If the smart cradle
is paired with other scanners, please press and hold the paging/reset button for more than 5 seconds to un-pair all
paired scanners. Then the smart cradle will return to uninstall state automatically.
Prepare the scanners you desire to pair with smart cradle. Power or wake up the scanner by pressing the Trigger key if
the scanner is power-off or in sleep state. Ensure the status indicator of each scanner blinks red and green
alternatively (in “Uninstall” state). If the scanner is not in uninstall state, please scan the “Uninstall” command to un-pair
the scanner, then scan the “PICO mode” command, and the status indicator of scanner will light red.
USB PS/2 RS232
Place the scanner onto the smart cradle, then you will hear one short beep to indicate the pairing process is activated.
The scanner will emit continuous short clicks and the link indicator of scanner will flash blue quickly during the pairing
process. When you hear 4 beeps in ascending tone, the pairing process is completed. You will see that the link indicator
of scanner blinks blue once per 2.5 seconds; the central indicator of the smart cradle lights blue and its side indicators
light green.
If the scanner pairing process failed or it’s not placed on the smart cradle within 20 seconds, you will hear 2 “Di-do Di-do”
beeps to warn the failure of pairing, the scanner will return to uninstall state automatically.
Please scan the corresponding host interface quick set command to complete the installation. Then repeat the same
procedure to pair other scanners with the smart cradle.
Wireless FuzzyScan
Reference Manual
Uninstall PICO Mode
For user’s convenience, the smart cradle will automatically assign the ID numbers to each scanner. Please scan the
System Information command to check the assigned ID number of each scanner.
7
Getting Started
Clone Fu nction
For the user’s convenience, the clone function will help you to clone the host interface related parameters (please refer to
following table for details) from one of the paired scanners to the rest of paired scanners under PICO mode. You can use
one of the paired scanners to set the host interface related parameters first and then scan “Save Configuration” command.
After that, please take the other paired scanners to scan “Clone” command one by one to clone the host interface related
parameters.
Please ensure to keep those paired scanners in connected status when you use the Clone function. Because the host
interface related parameters can’t be cloned to the paired scanner in disconnected status.
Save Configuration Clone
The below host interface related parameters will be impacted by clone function:
Data Transmission Parameter Serial Interface Control
Field Delimiter Handshaking Protocol
Wireless FuzzyScan
Reference Manual
Data Transmission Format Intermessage Delay
Host Interface Control Interfunction Delay
Host interface Selection Intercharacter Delay
Keyboard Interface Control Baud Rate
Keyboard Layout Data Frame
Intermessage Delay Time Out Control
Interfunction Delay Wand Emulation Control
Intercharacter Delay Output Polarity
Caps Lock Control Initial Signal State
Caps Lock Release Control Margin Time
Function Key Emulation Module Time
Key Pad Emulation Narrow/Wide Ratio
Upper/Lower Case Code39 Emulation
8
Getting Started
y
Use FuzzyScan in HID Mode
Ensure the battery is fully charged. Power on the scanner by pressing the Trigger key within radio range if the scanner is
power-off or in sleep state, and ensure the status indicator of scanner gives alternative red and green blinks (in
“Uninstall” state). If the scanner is not in uninstall state, please scan the “Uninstall” command first.
Uninstall
If your remote host is equipped with latest Bluetooth drivers, or it’s an iOS or Android device, you are recommended to
use “HID Mode” for quick pairing. If necessary, you may use “HID Mode with Passkey” to establish a more secure
connection, If you frequently experienced the problem in using HID mode, please try “ HID Legacy Mode” instead.
HID Mode
HID Legacy Mode HID Mode with Passke
Once you scan one of above commands, the link indicator of scanner will blink blue 3 times per 2 seconds during
searching process. You have to execute the Bluetooth Discovery procedure to find available Bluetooth device, then select
“F(L/A)xxxBT-xxxx” or “PF(L/A)xxxBT-xxx”.
If you use “HID Mode”, please go to step 5.
If you use “HID Mode with Passkey”, you will be requested to enter the Passkey (PIN) on the remote host. Please enter
the Passkey (PIN) accordingly by scanning the “Option Code” (Page 97), and then scan the “FIN (Finish)” to end the
Passkey entry, then go to step 5.
If you scan “HID Legacy Mode”, the Passkey (PIN) may be requested. Please enter “00000000” (default setting). You will
see “Keyboard on F(L/A)xxxBT-xxxx” or “Keyboard on PF(L/A)xxxBT-xxxx”. Please double click this HID service to
establish the connection between scanner and remote host device.
The scanner will emit 4 beeps in ascending tone to indicate the connection is established. At the same time, the link
indicator of scanner will blink blue once per 2.5 seconds to indicate the scanner is in radio-connected state.
Please note that if the scanner is not connected to the host device within 1 minute after scanning the above command,,
the scanner will go to sleep automatically. You can just press the trigger to wake up the scanner to continue the
installation.
The installation procedure may vary depending on different remote host devices, operating systems and the Bluetooth
drivers. Please consult your professional IT consultant to obtain necessary support. For more detailed information,
please visit CINO website.
Wireless FuzzyScan
Reference Manual
9
Getting Started
Use FuzzyScan in SPP Mode
Establish SPP Master Connection
Ensure the battery is fully charged. Please go to the folder “Hardware” located in Bluetooth Advanced Setting of the
remote host device to check its device MAC address. Then prepare a 12-character Code 128 bar code of the remote host
device MAC address, or follow the step 4 to input MAC address by scanning 12 option codes.
Ensure a virtual COM port is available in your remote host for connecting the scanner. If not, please go to the folder
“Local Services” located in Bluetooth Advanced Setting. Click the “Add Serial Services” to add one more Bluetooth
COM port.
Power on or wake up the scanner by pressing the Trigger key within radio coverage if the scanner is power-off or in sleep
status, and ensure the status indicator of scanner blinks red and green blinks alternatively (in “Uninstall” state). If the
scanner is not in uninstall state, please scan the “Uninstall” command first, then scan the “SPP Master Mode” command.
The status indicator of scanner will turn steady red immediately.
Uninstall SPP Master Mode
Scan a 12-character MAC address barcode, or scan 12 option codes and “FIN” command to confirm your inputs. The
scanner will emit continuous short clicks and the link indicator of the scanner will blink blue quickly during the radio
connecting process. If the PIN Code or Passkey is requested, please enter “00000000” (default setting).
The scanner will emit 4 beeps in ascending tone to indicate the radio is connected. At the same time, the link indicator of
scanner will blink blue once per 2.5 seconds to indicate the scanner is in radio-connected state.
Please note that if the scanner failed to connect to the host device within 30 seconds, the link indicator will blink blue 3
times per 2 seconds. But the scanner is still continuing to discover the host device for another 30 seconds before go to
sleep. In the interim, you still can scan “Uninstall” command to revert the scanner to uninstall st ate . If the scan ner goes to
sleep already, you just need to press the trigger to wake up the scanner to continue the installation.
Wireless FuzzyScan
Reference Manual
The above procedures are based on popular Windows environment. But the installation procedure may vary
depending on different remote host devices, operating systems and the Bluetooth drivers. Please consult your
professional IT consultant to obtain necessary support if any problem has been encountered during the installation
processes. For more detailed information, please visit CINO website.
10
Getting Started
Establish SPP Slave Connection
Ensure the battery is fully charged and a virtual COM port is available in your remote host for connecting the scanner. If
not, please go to the folder “Client Applications” located in Bluetooth Advanced Setting. Click the “Add COM Port” to
add one more Bluetooth COM port.
Power on or wake up the scanner by pressing the Trigger key within radio coverage if the scanner is power-off or in sleep
state, and ensure the status indicator of scanner blinks red and green alternatively (in “Uninstall” state). If the scanner
is not in uninstall state, please scan the “Uninstall” command first. Then scan the “SPP Slave Mode” command, and the
link indicator of scanner will blink blue 3 times per 2 seconds during searching process.
Uninstall SPP Slave Mode
You have to execute the Bluetooth Discovery procedure to find all available Bluetooth device list in your remote host. You
will see ‘F(L/A)xxxBT-xxxx’’ or ‘PF(L/A)xxxBT-xxxx’’ is shown in the list if the scanner is successfully discovered.
Double click the “F(L/A)xxxBT-xxxx” or ‘PF(L/A)xxxBT-xxxx’’ on the discovered Bluetooth devices. If the PIN Code or
Passkey is requested for security connection, please enter “00000000” (default setting). You will see “Serial Port on
F(L/A)xxxBT-xxxx” or ‘PF(L/A)xxxBT-xxxx’’. Please double click this SPP service to establish the connection between
scanner and remote host device.
The scanner will emit 4 beeps in ascending tone to indicate the connection is established. At the same time, the link
indicator of scanner will blink blue once per 2.5 seconds to indicate the scanner is in radio-connected state.
Please note that if the scanner is not connected to the host device within 1 minute after scanning the “SPP Slave Mode”
command, the scanner will go to sleep automatically. You can just press the trigger to wake up the scanner to continue
the installation.
Wireless FuzzyScan
Reference Manual
The above procedures are based on popular Windows environment. But the installation procedures may vary
depending on different remote host devices, operating systems and the Bluetooth sof tware drivers. Please consult your
professional IT consultant to obtain necessary support if any problem has been encountered during the installation
processes. For more detailed information, please visit CINO website.
11
Getting Started
Out-of-range Scanning
When the radio connection is established between scanner and remote host device, the scanner will transmit each scanned
data right after scanning the barcode. However, the scanner is preset not to scan any barcode data when it loses the radio
connection with the remote host device.
If you enable the out-of-range scanning function, the scanner is able to continue scanning barcode data while it is out of
radio coverage. All scanned data will be temporarily stored into the memory buffer until radio link resumed.
Enable Out-of-range Scannning Disable Out-of-range Scanning ◆
In case of the scanner is out of radio coverage, you will hear 4 beeps in descending tone to indicate the radio connection lost.
The link indicator of scanner will blink blue 3 times per 2 seconds. Once the scanner is back to radio coverage, you will
hear 4 beeps in ascending tone to indicate the radio connection rebuilt and the scanner will blink blue once per 2.5
seconds. At the same time, all stored scanned data will be transmitted automatically right after the radio link is resumed.
Presentation Scanning (Gun type only)
The Presentation Scanning is designed for hand-free applications for user’s convenience. If the “Presentation Scanning
Auto-sense” function is enabled, the scanner is capable of automatically switching to presentation mode as soon as you
place it onto the SmartStand or cradle.
Wireless FuzzyScan
Reference Manual
Enable Auto-sense Disable Auto-sense ◆
12
Getting Started
Paging Function
The Paging function is helpful for you to locate the paired smart cradle or scanner. If you would like to page the paired smart
cradle, you can scan “Paging” command. If you would like to page the paired scanner, you can press the paging/reset button
of the smart cradle no longer than 3 seconds.
Paging
Paging/Reset Button
Sleep Mode & Power Off
The scanner is preset to enter “Sleep Mode” if the scanner is not used after the user-defined time-out duration. Meanwhile,
pocket scanner can also be entered “sleep mode” instantly by pressing Function Key 1 twice (each time lasts more than
one second)
When the scanner is under sleep mode, it is preset to enter “Power Off” automatically if it’s not woke up after time-out
duration. For pocket scanner user, you can also power off the pocket scanner by pressing and holding the Function Key 1
for more than 3 seconds.
You can have your scanner entered “Sleep Mode” or “Power Off” by scanning the following “Sleep Mode” or “Power Off”
command.
If you would like to power on or wake up the scanner , please press the trigger key.
Wireless FuzzyScan
Reference Manual
Sleep Mode Power Off
13
Getting Started
Batch Scanning (Inventory Mode)
Thanks to the specially designed Batch Scanning function, the scanner is capable of storing the barcode data. It is an ideal
cost-saving solution for inventory applications.
Once you scan the ““Enter Batch Scanning” command to activate this function, all scanned barcode data will be stored into
the memory storage, and the status indicator of scanner will give green blink at regular interval during batch scanning. You
can scan and store the barcode data till the memory storage is full. If the storage is full, you will hear 2 long beeps and the
status indicator will give 2 red blinks to indicate out of storage.
If you use pocket scanner, you can also press and hold the Function Key 2 for more than 3 seconds to enter Batch
Scanning, by which 3 beeps will be heard and the status indicator of the scanner will blink green at regular interval during
batch scanning.
To exit the batch scanning, please scan the “Exit Batch Scanning” command. If you use pocket scanner, you can also exit
the batch scanning by pressing and holding Function Key 2 for more than 3 seconds.
Enter Batch Scanning Exit Batching Scanning
Using Quantity Fe ature
The scanner supports quantity feature when it enters batch scanning. When you use quantity feature, the quantity
information and scanned barcode data will be stored into the memory storage together. You can enter the quantity
information from 1 to 9999 by scanning the following quantity commands right after you scanned the barcode data.
Wireless FuzzyScan
Reference Manual
Quantity 0 Quantity 5
Quantity 3 Quantity 8
Quantity 1 Quantity 6
Quantity 4 Quantity 9
Quantity 2 Quantity 7
14
Getting Started
There are three ways to output the stored barcode data and quantity information. The preset output format is to transmit
stored data as many times as the quantity indicated.But you still can set the scanner to output stored barcode data together
with quantity information in two fields, and a preset delimter”，” will be output in between. To fulfill different application
requirements, both the delimiter and output sequency can be changed as well.
As many times as the quantity indicates ◆ <Quantity><Field Delimiter><Scanned Data>
<Scanned Data><Field Delimiter><Quantity>
How to Transmit Stored Data
The scanner is preset to transmit all the stored data by scanning the “Transmit Stored Data” command. During the
transmission, the scanner will emit continuous short clicks and the link indicator will blink blue. Then the scanner will give
two short beeps after data transmission is completed.
Transmit Stored Data
But you are still able to set the scanner to transmit the stored data by placing the scanner onto the cradle as well.
Scan Barcode Command ◆ Place Scanner onto the Cradle
How to Delete Scanned Data
The scanner is preset to keep all the stored data until you scan the “Clear All Stored Data” command. But you are still able to
change the setting to “Auto Delete Stored Data after Transmission” as well.
Wireless FuzzyScan
Reference Manual
Scan command or Place Scanner onto theCradle
Clear All Stored Data
15
Getting Started
Auto Delete Stored Data
after Transmission
If you scanned a wrong barcode, the “Delete Last Scanned Data’’ command is helpful to recover mistake. By scanning the
‘’Delete Last Scanned Data’’ command, the last stored data can be deleted. If you use pocket scanner, you can also delete
the last scanned data by pressing the Function Key 2 twice.
Delete Last Scanned Data
Keep Stored Data after
Transmission ◆
Wireless FuzzyScan
Reference Manual
16
Configure Your FuzzyScan
Bar Code Programming Menu
The FuzzyScan bar code commands are specially designed
Proprietary bar code labels which allow you to set the
FuzzyScan internal programming parameters. There are
System Command, Family Code and Option Code for
programming purpose.
Each programmable family and bar code command label is
listed on the same page with major system commands. The
detailed explanations and special programming flowchart are
printed on facing or following pages. You can read the
explanation and set the FuzzyScan concurrently.
A supplemental bar code command menu incorporates the
bar code command labels of System Command and Option
Code. As you set the FuzzyScan, open the bar code
command menu to find the option code page. You may scan
the desired family code and option code to set FuzzyScan. If
you want to change the programming family for multiple
settings, you need only turn over the programming page to
find next desired programming family.
System Command
The System Command is the highest level bar code
command which directs FuzzyScan to perform immediate
operations, such as entering programming mode
(PROGRAM), exiting programming mode (EXIT), listing
system information (SYSLIST), recovering to factory
preset configurations (M_DEFAULT), and so on. Please
note that all system commands will take a few seconds to
complete the operations. User must wait for the
completion beeps before scanning another bar code.
Family Code
The Family Code is scanned to select the user desired
programming family. FuzzyScan has already provided
more than one hundred programming families to meet any
specific requirements.
Option Code
The Option Codes is a set of bar code commands
represented by “0–9”, “A–F” and finishing selection (FIN).
For most setting, you must select at least one option code
following the family code selection to set the desired
parameter for the selected programming family.
Wireless FuzzyScan
Reference Manual
17
Configure Your FuzzyScan
Programming Procedures
As you scan the bar code command to select the desired
parameters, information about the final selected parameters
represented by the bar code commands are stored in the
FuzzyScan’s internal Flash Memory ASIC or non-volatile
memory. If you turn off the unit, the Flash Memory ASIC or
non-volatile memory retains all programming options. You
need not re-program the FuzzyScan if you want to keep the
existing configurations in the next power on.
The programming procedures of FuzzyScan are designed
as simple as possible for ease of setting. Most
programming families take the Single Scan Selection
programming procedure. But several programming families
have more complex and flexible programmable options,
and you must take Multiple Scans Selection, Cycling
Scan Selection or Dual Level Selection to complete their
programming procedures. Each kind of programming
procedure is listed in the following pages for your reference.
Please give careful attention to become familiar with each
programming procedure.
If the programming family must take multiple scans
selection, cycling scan selection, or dual level selection
procedures, the family of the programming menu will be
marked with the matched representing symbol of
Programming Category (P.C.) in bold font listed in the
following table. You can easily find the bold mark in the
programming menu, and refer to their flowcharts for details.
Before setting the FuzzyScan, please also refer to the
“Beeping Indications” listed in Appendix to understand the
details of programming beeping indications. It will be very
helpful for you to know the existing status while you are
programming the FuzzyScan.
Conventions of Programming Menu
Conventions Descriptions
P.C. Programming Category
( ) Necessary Option Code
[ ] Selectable Option Code
Factory Default Value
: Single scan selection
SS
MS : Multiple scans selection
CS : Cycling scan selection
DS : Dual level scan selection
Wireless FuzzyScan
Reference Manual
18
Configure Your FuzzyScan
Program & End
parameters in Flash Memory ASIC or non-volatile memory,
FuzzyScan will enter programming mode,
and inhibit all non-programming functions.
FuzzyScan will exit programming mode, and store all
then issue the completion beeping.
Please note that the FuzzyScan will take 3-4 seconds to
store parameters in internal Flash Memory ASIC or
non-volatile memory after you scan the “END”. Please
don’t turn off the power before the completion beeping. It
may destroy all configured parameters.
Scan
“
PROGRAM”
Scan
“
”
END
System List, Group & Master Default
FuzzyScan will list the product information and
revision number to host via selected host interface,
then issue the completion beeping.
FuzzyScan will recover all programmable
parameters into factory preset configurations,
then issue the completion beeping.
Scan
“
SYSLIST”
Scan
M_DEFAULT
“
”
Wireless FuzzyScan
Reference Manual
19
Configure Your FuzzyScan
Single scan selection
One of
One of
Yes
Scan
“
PROGRAM
Scan
Family
Scan
Option
Repeat
Selection
Scan
“
END
”
Codes
Codes
No
”
Enter programming mode.
Select one of desired
programming families.
Select one option code of
desired parameter.
Want to select another
programming family?
Exit programming m ode.
Multiple scans selection
Yes
One of
Several
Scan
“
PROGRAM”
Scan
Family
Codes
Scan One or
Option
Codes
Repeat
Selection
No
Scan
“
”
END
Enter programming mode.
Select one of desired
programm ing fam ilies.
1. Select on e or several
option codes to select
desired parameters.
2. If it’s necessary, scan
“FIN” to terminate
option co de selection .
Want to select another
programm ing fam ily?
Exit programming mode.
Wireless FuzzyScan
Reference Manual
20
Configure Your FuzzyScan
Cycling scan selection
Yes
One of
One of
Scan
“PROGRAM”
Scan
Family
Codes
Scan
Option
Scan “
Codes
FIN
”
Repeat
Selection
No
Scan
“
”
END
Enter programming mode.
Select one of desi r ed
programm ing families.
Cycling select one or
several optio n codes of
desired parameters as
“Single” or “Multiple”
scans selection.
Finish cycling selection.
(If necessary)
Want to select another
programm ing family?
Exit programming mode.
Dual level selection
One of
Several
Several
Yes
Scan
“
PROGRAM”
Scan
Family
(
) Scan
1st
Option
(
) Scan One or
2nd
Option
Repeat
Selection
Scan
“
END”
Codes
No
Codes
Codes
Enter programming mode.
Select one of desi r ed
programm ing families.
Select several option co des
of desired parameters.
1. Select on e or several
option codes of desired
parameters.
2. If it’s necessary, scan
“FIN” to terminate
option code selection.
Want to select another
programm ing family?
Exit programming mode.
Wireless FuzzyScan
Reference Manual
21
Configure Your FuzzyScan
Host Interface Selection
PROGRAM
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
MS
Host Interface Selection
A series doesn’t support Wand emulation, Laser emulation, USB HID Legacy and USB EFT Terminal Mode.
IBM PS/2, 25-30 series keyboard wedge interface
MS
Standard/TTL RS-232 peer-to-peer serial
MS
Wand emulation
MS
USB Com Port Emulation
MS
PS/2 (DOS/V) direct link (keyboard replacement)
MS
PS/2 (DOS/V) keyboard wedge turbo mode
MS
PS/2 (DOS/V) keyboard wedge standard mode
MS
Laser emulation
MS
USB HID standard mode
MS
USB HID turbo mode
MS
USB HID Legacy
MS
USB EFT Terminal Mode
02
06
08
09
10
13
14
17
18
19
20
21
Wireless FuzzyScan
Reference Manual
22
Configure Your FuzzyScan
Symbology Reading Control
♦ User Defined Symbol ID ♦
Family Code Selection P.C Parameter Selection Option Code 2nd Option Code
Symbol ID : 1 character
DS Code 128 (default=B)
GS1-128 (default=C)
UPC-A (default=A)
EAN-13 (default=F)
Codabar/NW-7 (default=D)
Code 39/Code 32 (default=G)
Code 93 (default=H)
Standard/Industrial 2 of 5 (default=I)
Interleaved 2 of 5 (default=J)
Matrix 2 of 5 (default=K)
China Postal Code (default=L)
German Postal Code (default=M)
IATA (default=O)
Code 11 (default=P)
MSI/Plessey (default=R)
UK/Plessey (default=S)
Telepen (default=T)
GS1 DataBar (default=X)
UPC-E (default=E)
EAN-8 (default=N)
Trioptic Code 39 (default=W)
UCC Coupon Extended Code (default=Z)
PDF417/Micro PDF417 (default=V)
Codablock F (default=Y)
Code 16K (default=Q)
Code 49 (default=U)
Korea Post Code (default=a)
QR & Micro QR Code (default=b)
Data Matrix (default=c)
Maxi Code (default=d)
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
28
29
30
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
Wireless FuzzyScan
Reference Manual
23
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code 2nd Option Code
Symbol ID : 1 character
DS Aztec Code (default=e)
Chinese Sensible (default=f)
Australian Post (default=g)
British Post (default=h)
Intelligent Mail (USPS 4CB/One Code) (default=j)
Japan Post (default=k)
Netherlands KIX Post (default=l)
US Planet (default=m)
US Postnet (default=o)
♦ User Defined Symbol ID ♦
31
32
33
34
36
37
38
39
41
F_DEFAULT
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
(1 character)
Wireless FuzzyScan
Reference Manual
24
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
SS
Disable symbology ID transmission
SS
Enable prefix CINO symbology ID transmission
SS
Enable suffix CINO symbology ID transmission
SS
Symbology ID Transmission
Enable both prefix and suffix CINO symbology ID transmission
SS
Enable prefix AIM symbology ID transmission
SS
Enable suffix AIM symbology ID transmission
SS
Enable both prefix and suffix AIM symbology ID transmission
♦ Symbology ID Transmission ♦
F_DEFAULT
0
1
2
3
4
5
6
Wireless FuzzyScan
Reference Manual
25
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ Readable Bar Code Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Cod e
Readable Symbology Setting
Remember to scan “FIN” to terminate
this selection. But if you select the
“Auto”, FuzzyScan will terminate this
selection automatically.
SS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
CS
Auto
Code 128 *
GS1-128 *
UPC-A *
UPC-E *
EAN-13 *
EAN-8 *
Codabar/NW-7 *
Code 39 *
Trioptic Code 39
Standard/Industrial 2 of 5
Matrix 2 of 5
Interleaved 2 of 5 *
China Postal Code
Germany Postal Code
Code 93 *
Code 11
MSI/Plessey
UK/Plessey
Telepen
GS1 DataBar (RSS-14) *
IATA
PDF417 * /Micro PDF417
Codablock F
Code 16K
Code 49
Korea Post Code
QR Code */ Micro QR Code *
Data Matrix *
MaxiCode
Aztec Code *
Chinese Sensible (Han Xin) Code
00
01
31
02
03
04
05
06
07
47
08
38
48
58
68
09
10
11
12
13
14
15
17
18
19
20
21
A0
A1
A2
A3
A4
Wireless FuzzyScan
Reference Manual
26
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Cod e
CS
Readable Symbology Setting
If your application is known, you may select those known symbologies only to increase the reading speed and decrease the possibility of reading error. Furthermore, to add
the “Symbology ID” into the transmitted data is also helpful to identify the specific symbology.
Above symbologies marketed with * are enabled as default. When you select “Auto”, the scanner only reads those symbologies marked with *.
When you set the minimum and maximum length of each symbology, please note the data length of scanned bar code doesn’t include start/stop characters.
Australian Post
CS
British Post
CS
Intelligent Mail barcode
CS
Japanese Post
CS
KIX Post
CS
Planet Code
CS
Postnet
♦ Readable Bar Code Setting ♦
F_DEFAULT
B0
B1
B3
B4
B5
B6
B8
Wireless FuzzyScan
Reference Manual
27
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ Code 39/Code 32 Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
Code 39 Family Setting
Trioptic Code 39 Setting
Disable Code 39
SS
Enable Code 39
SS
SS
Select Standard Code 39 as primary format
SS
Select Full ASCII Code 39 as primary format
SS
Select Code 32 (PARAF, Italian Pharmaceutical) as primary format
SS
Disable start/stop symbol transmission
SS
Enable start/stop symbol transmission
SS
Disable Code 32 leading A transmission
SS
Enable Code 32 leading A transmission
SS
Disable MOD 43 check digit verification
SS
Enable MOD 43 check digit verification
SS
Disable check digit transmission
SS
Enable check digit transmission
SS
Disable Code 39 buffering
SS
Enable Code 39 buffering
SS
Disable Trioptic Code 39
SS
Enable Trioptic Code 39
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
0
1
Code 39 Min. Length
Code 39 Max. Length
Trioptic Code 39 and Code 39 Full ASCII cannot be enabled simultaneously.
Wireless FuzzyScan
Reference Manual
SS
Default (01)
MS
01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
SS
Default (98)
MS
98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
FIN
(2 digits)
FIN
(2 digits)
28
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
SS
SS
SS
SS
Level 0
Level 1
Level 2
Level 3
Code 39 Security Level
Code 39 Security Level
The scanner offers four levels of decode security for Code39 bar codes:
Level 0: If you are experiencing misread of poorly-printed or serious out-of-spec. bar codes in level 1, please select level 0.
Level 1: If you are experiencing misread of poorly-printed or out-of-spec. bar codes in level 2, please select level 1.
Level 2: This is the default setting which allows the scanner to operate fastest, while providing sufficient security in decoding “in-spec” Code39 bar codes.
Level 3: If you failed to read poorly-printed or out-of-spec. bar codes in level 2, please select level 3. This is the most aggressive setting and may increase the misread.
♦ Code 39 Setting ♦
F_DEFAULT
0
1
2
3
Wireless FuzzyScan
Reference Manual
29
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ Codabar/NW-7 Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
Codabar Setting
Codabar Check Digit Settings
Disable Codabar
SS
Enable Codabar
SS
SS
Select Codabar standard format
SS
Select Codabar ABC format
SS
Select Codabar CLSI format
SS
Select Codabar CX format
SS
Disable start/stop symbol transmission
SS
Enable ABCD/ABCD start/stop symbol transmission
SS
Enable abcd/abcd start/stop symbol transmission
SS
Enable ABCD/TN*E start/stop symbol transmission
SS
Enable abcd/tn*e start/stop symbol transmission
SS
Disable check digit verification
SS
Enable check digit verification
SS
Disable check digit transmission
SS
Enable check digit transmission
SS
Modulus 16
SS
Modulus 10/weight 3
SS
Modulus 11
SS
Modulus 10/weight 2
SS
7 check DR
SS
Weight Modulus 11
SS
Runes (Modulus 10/weight 2)
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
0
1
2
3
4
5
6
Codabar Min. Length
Wireless FuzzyScan
Reference Manual
SS
Default (04)
MS
01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
FIN
(2 digits)
30
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
SS
Codabar Max. Length
Default (98)
MS
98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
♦ Codabar/NW-7 Setting ♦
F_DEFAULT
FIN
(2 digits)
Wireless FuzzyScan
Reference Manual
31
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ UPC-A & UPC-E Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
Disable UPC-A
UPC Family Setting
When enable UPC-E expansion, the UPC-E decoded data will be converted to UPC-A format and affected by related setting, such as UPC standardization, UPC numeric
system, UPC-A check digit transmission.
UPC-E & EAN-8 Expansion : Expand the 8-digit UPC-E and 8-digit ENA-8 to 12-digit UPC-A and 13-digit EAN-13.
UPC-A/E Standardization : Expand the 12-digit UPC-A to 13-digit EAN-13 with 1 zero insertion.
UPC Lead 1 Numeric System : Enable to read UPC leading with the 1 numeric system, you must enable this option.
WPC Selection
(UPC/EAN/CAN)
UPC-A 12 - 1 - 1 + 2 + 5 + 1 0
UPC-E 8 - 1 - 1 + 2 + 5 + 1 + 4
EAN-13 13 - 1 NC + 2 + 5 NC 0
EAN-8 8 - 1 NC + 2 + 5 NC + 5
Basic Length
SS
Enable UPC-A
SS
SS
Disable UPC-E
SS
Enable UPC-E
SS
Disable UPC-E expansion
SS
Enable UPC-E expansion
SS
Disable UPC standardization
SS
Enable UPC standardization
SS
Disable UPC numeric system
SS
Enable UPC numeric system
SS
Disable UPC-A check digit transmission
SS
Enable UPC-A check digit transmission
SS
Disable UPC-E check digit transmission
SS
Enable UPC-E check digit transmission
SS
Disable UPC “leading 1” portion
SS
Enable UPC “leading 1” portion
Disable
Check Digit
Disable
Numeric System
With 2-digit
Addendum
With 5-digit
Addendum
Enable
Standardization
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
Enable
Expansion
Wireless FuzzyScan
Reference Manual
32
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ UPC-A & UPC-E Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
UPC Supplement Setting
UPC/EAN Security Level
Supplement Scan Voting
SS
Select UPC without supplement digits
SS
Select UPC with only 2 supplement digits
SS
Select UPC with only 5 supplement digits
SS
Select UPC with 2/5 supplement digits
SS
Disable force supplement digits output
SS
Enable force supplement digits output
SS
UPC Family Addenda Separator Off
SS
UPC Family Addenda Separator On
SS
Level 0
SS
Level 1
Level 2
SS
Only available for UPC-A & EAN-13
SS
None
SS
Level 1
SS
Level 2
SS
Level 3
SS
Level 4
SS
Level 5
SS
Level 6
Level 7
Level 8
Level 9
Level 10
Level 11
Level 12
Level 13
0
1
2
3
4
5
6
7
0
1
2
0
1
2
3
4
5
6
7
8
9
A
B
C
D
UPC/EAN Security Level
The scanner offers three levels of decode security for UPC/EAN bar codes:
Level 0: If you are experiencing misread of poorly-printed or out-of-spec. bar codes, especially in characters 1, 2, 7, and 8 in level 1, please select level 0. Selection of this
security level may significantly impair the decoding ability of the scanner.
Level 1: This is the default setting which allows the scanner to operate fastest, while providing sufficient security in decoding “in-spec” UPC/EAN bar codes.
Level 2: If you are experiencing misread of poorly-printed, soiled or damage bar codes in level 1, please select le vel 2. This is the most aggressive setting and may
increase the misread.
The Supplement Scan Voting is the number of times the same UPC/EAN with 2/5 supplement digits has to be decoded before it is transmitted. It is helpful when decoding
a mix of UPC/EAN symbols with and without supplement digits. This function is effective when you select UPC/EAN with only 2 supplement digits, UPC/EAN with only 5
supplement digits or UPC/EAN with 2/5 supplement digits. The default value is Level 3. When you select higher level, it may impact the reading speed on poorly-printed,
low contrast or damage barcode labels.
Wireless FuzzyScan
Reference Manual
33
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ EAN Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
EAN Setting
EAN Supplement Setting
Disable EAN-13
SS
Enable EAN-13
SS
SS
Disable EAN-8
SS
Enable EAN-8
SS
Disable EAN-8 expansion
SS
Enable EAN-8 expansion
SS
Disable EAN-13 check digit transmission
SS
Enable EAN-13 check digit transmission
SS
Disable EAN-8 check digit transmission
SS
Enable EAN-8 check digit transmission
SS
Disable ISBN/ISSN Conversion reading check
SS
Enable ISBN/ISSN Conversion reading check
SS
Select EAN without supplement digits
SS
Select EAN with only 2 supplement digits
SS
Select EAN with only 5 supplement digits
SS
Select EAN with 2/5 supplement digits
SS
Disable force supplement digits output
SS
Enable force supplement digits output
SS
EAN Addenda Separator Off
SS
EAN Addenda Separator On
0
1
2
3
4
5
6
7
8
9
A
B
0
1
2
3
4
5
6
7
Supplement Scan Voting
The Supplement Scan Voting is the number of times the same UPC/EAN with 2/5 supplement digits has to be decoded before it is transmitted. It is helpful when decoding
a mix of UPC/EAN symbols with and without supplement digits. This function is effective when you select UPC/EAN with only 2 supplement digits, UPC/EAN with only 5
supplement digits or UPC/EAN with 2/5 supplement digits. The default value is Level 3. When you select higher level, it may impact the reading speed on poorly-printed,
low contrast or damage barcode labels.
Wireless FuzzyScan
Reference Manual
SS
None
SS
Level 1
SS
SS
SS
SS
SS
Level 2
Level 3
Level 4
Level 5
Level 6
34
Level 7
Level 8
Level 9
Level 10
Level 11
Level 12
Level 13
0
1
2
3
4
5
6
7
8
9
A
B
C
D
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ EAN Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
SS
UPC/EAN Security Level
EAN Supplement Control
UPC/EAN Security Level
The scanner offers three levels of decode security for UPC/EAN bar codes:
Level 0: If you are experiencing misread of poorly-printed or out-of-spec. bar codes, especially in characters 1, 2, 7, and 8 in level 1, please select level 0. Selection of this
security level may significantly impair the decoding ability of the scanner.
Level 1: This is the default setting which allows the scanner to operate fastest, while providing sufficient security in decoding “in-spec” UPC/EAN bar codes.
Level 2: If you are experiencing misread of poorly-printed, soiled or damage bar codes in level 1, please select le vel 2. This is the most aggressive setting and may
increase the misread.
EAN Supplement Control
If you select EAN with only 2, or 5 or 2/5 supplement digits and enable 491 prefix supplement digit output, the scanner will transmit EAN with 2, or 5 or 2/5 supplement
digits bar codes starting with 491 prefix. The EAN without supplement digit will not be transmitted.
If you select EAN with only 2, or 5 or 2/5 supplement digits and enable the other except 491 prefix supplement digit output, the scanner will transmit EAN with 2, or 5, or 2/5
supplement digits bar codes starting with specific prefix. The EAN without supplement digit will be transmitted.
Level 0
SS
Level 1
Level 2
SS
Only available for UPC-A & EAN-13
SS
Disable all specific prefix supplement digital output
SS
Enable all specific prefix supplement digital output
SS
Enable 491 Supplement Digit Output
SS
Enable 978/979 Supplement Digit Output
SS
Enable 977 Supplement Digit Output
SS
Enable 378/379 Supplement Digit Output
SS
Enable 414/419 Supplement Digit Output
SS
Enable 434/439 Supplement Digit Output
0
1
2
0
1
2
3
4
5
6
7
Wireless FuzzyScan
Reference Manual
35
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
UCC Coupon Extended Code
UCC Coupon Extended Code
When UCC coupon extended code function is enabled, scanner decodes UPC-A barcodes starting with digit “5”, EAN-13 barcodes starting with digit “99” and GS1-128
Coupon Codes. UPC-A, EAN-13 and EAN-128 must be enabled to scan all types of Coupon Codes.
SS
SS
♦ UCC Coupon Extended Code Setting ♦
Disable UCC Coupon Extended Code
Enable UCC Coupon Extended Code
F_DEFAULT
0
1
Wireless FuzzyScan
Reference Manual
36
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ IATA & Interleaved 2 of 5 Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
IATA Setting
Interleaved 2 of 5 Setting
Disable IATA
SS
Enable IATA
SS
SS
Select 15-digit fixed length IATA checking
SS
Select variable length IATA
SS
Disable check digit verification
SS
Enable check digit automatic verification
SS
Enable S/N checking digit verification only
SS
Enable CPN checking digit verification only
SS
Enable CPN, Airline and S/N check digit verification
SS
Disable check digit transmission
SS
Enable check digit transmission
SS
Disable start/stop symbol transmission
SS
Enable start/stop symbol transmission
SS
Disable Interleaved 2 of 5
SS
Enable Interleaved 2 of 5
SS
Select Interleaved 2 of 5 as primary format
SS
Select German Postal Code as primary format
SS
No check character
SS
Validate USS check digit
SS
Validate OPCC check digit
SS
Disable check digit transmission
SS
Enable check digit transmission
0
1
2
3
4
5
6
7
8
9
A
B
C
0
1
2
3
4
5
6
7
8
Wireless FuzzyScan
Reference Manual
37
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ Code 25 Family Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
Code 25 Setting
Code 25 Family Min. Length
Code 25 Family Max. Length
SS
Disable Standard/Industrial 2 of 5
SS
Enable Standard/Industrial 2 of 5
SS
Disable Matrix 2 of 5
SS
Enable Matrix 2 of 5
SS
Disable China Postal Code
SS
Enable China Postal Code
SS
Disable check digit verification
SS
Enable check digit verification
SS
Disable check digit transmission
SS
Enable check digit transmission
SS
Default (04)
MS
01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
SS
Default (98)
MS
98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
0
1
2
3
4
5
6
7
8
9
FIN
(2 digits)
FIN
(2 digits)
For Code25 setting, we recommend you to select only one type of Code 25 or set the maximum/minimum bar code length. To decode all types of Code 25 or to variable
length of Code 25 will increase the possibility of reading error.
Wireless FuzzyScan
Reference Manual
38
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ Code 11 & Code 93 Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
SS
Code 11 Setting
Code 11 Min. Length
Code 11 Max. Length
Code 93 Setting
Disable Code 11
SS
Enable Code 11
SS
Disable check digit verification
SS
Select 1-check digit verification
SS
Select 2-check digit verification
SS
Disable check digit transmission
SS
Enable check digit transmission
SS
Default (04)
MS
01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
SS
Default (98)
MS
98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
SS
Disable Code 93
SS
Enable Code 93
SS
Disable check digit transmission
SS
Enable check digit transmission
0
1
2
3
4
5
6
FIN
(2 digits)
FIN
(2 digits)
0
1
2
3
Code 93 Min. Length
Code 93 Max. Length
Wireless FuzzyScan
Reference Manual
SS
Default (01)
MS
01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
SS
Default (98)
MS
98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
FIN
(2 digits)
FIN
(2 digits)
39
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ MSI/Plessey Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
MSI/Plessey Setting
MSI/Plessey Min. Length
MSI/Plessey Max. Length
SS
Disable MSI/Plessy
SS
Enable MSI/Plessy
SS
Select MOD 10 check digit
SS
Select MOD 10-10 check digit
SS
Select MOD 11-10 check digit
SS
Disable check digit transmission
SS
Enable check digit transmission
SS
Default (04)
MS
01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
SS
Default (98)
MS
98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
0
1
2
3
4
5
6
FIN
(2 digits)
FIN
(2 digits)
Wireless FuzzyScan
Reference Manual
40
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ Code 128 Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
SS
Code 128 Setting
Code 128 Min. Length
Code 128 Max. Length
Code 128 Security Level
Disable Code 128 and GS1-128
SS
Enable Code 128 and GS1-128
SS
ISBT Concatenation Off
SS
ISBT Concatenation On
SS
Default (01)
MS
01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
SS
Default (98)
MS
98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
SS
Level 0
SS
Level 1
0
1
2
3
FIN
(2 digits)
FIN
(2 digits)
0
1
Code 128 Security Level
The scanner offers two levels of decode security for Code128 bar codes:
Level 0: If you are experiencing misread of poor-printed or out-of-spec. bar code in level1, please select level 0.
Level 1: This is the default setting which allows the scanner to operate fastest, while providing sufficient security in decoding "in-spec." Code128 bar codes.
Wireless FuzzyScan
Reference Manual
41
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Cod e
SS
GS1-128 Setting
GS1-128 Min. Length
GS1-128 Max. Length
Disable GS1-128
SS
Enable GS1-128
SS
Default (01)
MS
01-Maximum
Scan 2 digits from the option code chart in Appendix; then FuzzyScan will terminate
this selection automatically.
SS
Default (98)
MS
98-Minimum
Scan 2 digits from the option code chart in Appendix; then FuzzyScan will terminate
this selection automatically.
♦ GS1-128 Setting ♦
F_DEFAULT
0
1
FIN
(2 digits)
FIN
(2 digits)
Wireless FuzzyScan
Reference Manual
42
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ UK/Plessey Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
SS
UK/Plessey Setting
UK/Plessey Min. Length
UK/Plessey Max. Length
Disable UK/Plessey
SS
Enable UK/Plessey
SS
Select UK/Plessey Standard Format
SS
Select UK/Plessey CLSI Format
SS
Disable Convert X to A-F
SS
Enable Convert X to A-F
SS
Disable check digit transmission
SS
Enable check digit transmission
SS
Default (04)
MS
01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
SS
Default (98)
MS
98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
0
1
2
3
4
5
6
7
FIN
(2 digits)
FIN
(2 digits)
Wireless FuzzyScan
Reference Manual
43
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ Telepen Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
SS
Telepen Setting
Telepen Min. Length
Telepen Max. Length
Disable Telepen
SS
Enable Telepen
SS
Select Telepen Numeric mode
SS
Select Telepen Full ASCII mode
SS
Disable check digit transmission
SS
Enable check digit transmission
SS
Default (04)
MS
01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
SS
Default (98)
MS
98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
0
1
2
3
4
5
FIN
(2 digits)
FIN
(2 digits)
Wireless FuzzyScan
Reference Manual
44
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ GS1 DataBar Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
SS
GS1 DataBar Setting
GS1 DataBar Min. Length
GS1 DataBar Max. Length
Disable GS1 DataBar (RSS-14)
SS
Enable GS1 DataBar (RSS-14)
SS
Disable GS1 DataBar Limited
SS
Enable GS1 DataBar Limited
SS
Disable GS1 DataBar Expanded
SS
Enable GS1 DataBar Expanded
SS
Default (04)
MS
01- Maximum
Only available for Expanded GS1 Databar.
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
SS
Default (74)
MS
74-Minimum
Only available for Expanded GS1 Databar.
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
0
1
2
3
4
5
FIN
(2 digits)
FIN
(2 digits)
Wireless FuzzyScan
Reference Manual
45
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Cod e
SS
Composite Codes Setting
Codablock F Setting
PDF417/Micro PDF417 Setting
Disable composite codes
SS
Enable composite codes
SS
UPC Composite Mode: UPC never linked
SS
UPC Composite Mode: UPC always linked
If UPC Composite Mode: UPC never linked is selected, UPC barcodes are
transmitted whether MicroPDF417 symbol is detected or not.
If UPC Composite Mode: UPC always linked is selected, UPC barcodes are only
transmitted when the MicroPDF417 is detected.
SS
Disable
SS
Enable
SS
Disable PDF417
SS
Enable PDF417
SS
Disable MicroPDF417
SS
Enable MicroPDF417
♦ Composite Codes, Codablock F
PDF417/MicroPDF417 & Setting ♦
F_DEFAULT
0
1
2
3
0
1
0
1
2
3
Wireless FuzzyScan
Reference Manual
46
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ Code 16K & Code 49 Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Cod e
Code 16K Setting
Disable Code 16K
SS
Enable Code 16K
0
1
SS
Code 16K Min. Length
Code 16K Max. Length
Code 49 Setting
SS
Default (01)
MS
01-Maximum
Scan 3 digits from the option code chart in Appendix; then FuzzyScan will terminate
this selection automatically.
SS
Default (160)
MS
160-Minimum
Scan 3 digits from the option code chart in Appendix; then FuzzyScan will terminate
this selection automatically.
SS
Disable Code 49
SS
Enable Code 49
FIN
(3 digits)
FIN
(3 digits)
0
1
Code 49 Min. Length
Code 49 Max. Length
Wireless FuzzyScan
Reference Manual
SS
Default (01)
MS
01-Maximum
Scan 2 digits from the option code chart in Appendix; then FuzzyScan will terminate
this selection automatically.
SS
Default (81)
MS
81-Minimum
Scan 2 digits from the option code chart in Appendix; then FuzzyScan will terminate
this selection automatically.
FIN
(2 digits)
FIN
(2 digits)
47
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ QR Code Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Cod e
QR Code Setting
QR Code Min. Length
QR Code Max. Length
SS
Disable QR Code
SS
Enable QR Code
Disable MicroQR Code
Enable MicroQR Code
Disable QR Code Append
Enable QR Code Append
Disable QR Code Inverse Reading
Enable QR Code Inverse Reading
Auto detect QR Code Inverse Reading
SS
Default (01)
MS
01-Maximum
Scan 4 digits from the option code chart in Appendix; then FuzzyScan will terminate
this selection automatically.
SS
Default (7089)
MS
7089-Minimum
Scan 4 digits from the option code chart in Appendix; then FuzzyScan will terminate
this selection automatically.
0
1
2
3
4
5
6
7
8
FIN
(4 digits)
FIN
(4 digits)
Wireless FuzzyScan
Reference Manual
48
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ Data Matrix Setting ♦
F_DEFAULT
11Family Code Selection P.C Parameter Selection Option Code
Data Matrix Setting
Data Matrix Min. Length
Data Matrix Max. Length
Disable Data Matrix
SS
Enable Data Matrix
SS
Disable Data Matrix Inverse Reading
SS
Enable Data Matrix Inverse Reading
SS
Auto Detect Data Matrix Inverse Reading
SS
Disable Data Matrix Mirror Images
SS
Enable Data Matrix Mirror Images
SS
Auto Detect Data Matrix Mirror Images
SS
Default (01)
MS
01-Maximum
Scan 4 digits from the option code chart in Appendix; then FuzzyScan will terminate
this selection automatically.
SS
Default (3116)
MS
3116-Minimum
Scan 4 digits from the option code chart in Appendix; then FuzzyScan will terminate
this selection automatically.
0
1
4
5
6
7
8
9
FIN
(4 digits)
FIN
(4 digits)
SS
Wireless FuzzyScan
Reference Manual
49
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
SS
MaxiCode Setting
MaxiCode Min. Length
MaxiCode Max. Length
Disable MaxiCode
SS
Enable MaxiCode
SS
Default (01)
MS
01-Maximum
Scan 3 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
SS
Default (150)
MS
150-Minimum
Scan 3 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
♦MaxiCode Setting ♦
F_DEFAULT
FIN
(3 digits)
FIN
(3 digits)
0
1
Wireless FuzzyScan
Reference Manual
50
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
SS
Aztec Code Setting
Aztec Code Min. Length
Aztec Code Max. Length
Disable Aztec Code
SS
Enable Aztec Code
SS
Default (01)
MS
01-Maximum
Scan 4 digits from the option code chart in Appendix; then FuzzyScan will terminate
this selection automatically.
SS
Default (3832)
MS
3832-Minimum
Scan 4 digits from the option code chart in Appendix; then FuzzyScan will terminate
this selection automatically.
♦ Aztec Code Setting ♦
F_DEFAULT
0
1
FIN
(4 digits)
FIN
(4 digits)
Wireless FuzzyScan
Reference Manual
51
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
♦ Australian Post, US Planet, US Postnet,
British Post & Japan Post Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Cod e
Australian Post Setting
US Planet Setting
US Postnet Setting
British Post Setting
Disable Australian Post
SS
Enable Australian Post
SS
SS
Raw format Output
SS
Numeric Encoding Output (N Encoding Table)
SS
Alphanumeric Encoding Output (C Encoding Table)
SS
Auto-discriminate Output (Combination C & N Encoding Table)
SS
Disable US Planet
SS
Enable US Planet
SS
Disable Check Digit Transmission
SS
Enable Check Digit Transmission
SS
Disable US Postnet
SS
Enable US Postnet
SS
Disable Check Digit Transmission
SS
Enable Check Digit Transmission
SS
Disable British Post
SS
Enable British Post
SS
Disable Check Digit Transmission
SS
Enable Check Digit Transmission
0
1
2
3
4
5
0
1
2
3
0
1
2
3
0
1
2
3
Japan Post Setting
Australian Post Setting: Auto-discriminate output option increase the risk of misread because the encoded data format does not specify the Encoding Table used for
encoding.
Wireless FuzzyScan
Reference Manual
SS
Disable Japan Post
SS
Enable Japan Post
0
1
52
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Cod e
Netherlands KIX Code Setting
Intelligent Mail Setting
(USPS 4CB/One Code)
Korea Post Code Setting
SS
SS
SS
SS
SS
SS
♦ Netherlands KIX Code, Intelligent Mail
& Korea Post Code Setting ♦
Disable Netherlands KIX Code
Enable Netherlands KIX Code
Disable Intelligent Mail
Enable Intelligent Mail
Disable
Enable
Length fixed in 6 characters.
F_DEFAULT
0
1
0
1
0
1
Wireless FuzzyScan
Reference Manual
53
Configure Your FuzzyScan
Keyboard Interface Control
PROGRAM
♦ Keyboard Layout (Language) Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Cod e
Keyboard Layout
USA (QWERTY)
SS
France (AZERTY)
SS
Germany (QWERTZ)
SS
United Kingdom - UK (QWERTY)
SS
Canadian French (QWERTY)
SS
Spain (Spanish, QWERTY)
SS
Sweden/Finland (QWERTY)
SS
Portugal (QWERTY)
SS
Norway (QWERTY)
SS
Spain (Latin America, QWERTY)
SS
Italy (QWERTY)
SS
Netherlands (QWERTY)
SS
Denmark (QWERTY)
SS
Belgium (AZERTY)
SS
Switzerland-Germany (QWERTZ)
SS
Iceland (QWERTY)
SS
Japan (DOS/V)
SS
Czech (QWERTY)
SS
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
Please refer to the ASCII/HEX Table listed in the Appendix to determine HEX codes for characters, symbols, and functions to be used as preamble or postamble.
To set preamble or postamble as function key output, you must enable the “Function Key Emulation” feature as listed in page 3-25 first.
Keyboard Interface Message String :
Preamble Data Length Prefix Symbol ID Scanned Data Suffix Symbol ID Postamble Record Suffix
1-15 characters 2-4 digits 1 or 3 characters Variable length 1 or 3 characters 1-15 characters 1 character
Wireless FuzzyScan
Reference Manual
54
Configure Your FuzzyScan
Keyboard Interface Control
PROGRAM
♦ Record Suffix, Preamble, Postamble,
FNC1 Transmit & Caps Lock ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
SS
Record Suffix
Preamble
Postamble
FNC1 Symbol Char. Transmit
None
SS
RETURN
SS
TAB
SS
SPACE
SS
ENTER (Numeric Key Pad)
SS
User defined character (1 character)
SS
None
MS
1-15 characters
Maximum 15-character input; scan “FIN” to terminate this selection.
SS
None
MS
1-15 characters
Maximum 15-character input; scan “FIN” to terminate this selection.
SS
Disable
SS
Enable
0
1
2
3
4
5, (00-7F)
FIN
[00-7F], [FIN]
FIN
[00-7F], [FIN]
0
1
Caps Lock Control
Caps Lock Release Control
Wireless FuzzyScan
Reference Manual
SS
“Caps Lock Off” State
SS
“Caps Lock On” State
SS
Auto Detect (PC/AT, PS/2, Keyboard Replacement and DOS/V Machines only)
SS
“Caps Lock On, Caps Off”
SS
“Caps Lock On, Shift Off”
0
1
2
0
1
55
Configure Your FuzzyScan
FNC1 Symbol Char. Transmit: When this function is enabled and the FNC1 is contained in scanned data, the scanner transmits the FNC1 to the host. Chart of theFNC1
is provided in Appendix- Keyboard Function Code Table. When the scanner interface is set to keyboard, the scan code is converted to corresponding key function before it
is transmitted.
The function of “Caps Lock Control” and “Key Pad Emulation” are only available for IBM PC/AT, PS/VP, PS/2 series personal computers and compatible machines.
While selecting the other host interfaces, these selections don’t perform the above functions for you.
Please check the actual Caps Lock state in use while software application is running. If the Caps Lock state is off, select “Caps Lock Off” state, then FuzzyScan will
perform normal data transmission. If the Caps Lock state is on, select “Caps Lock On” state. Select “Auto Detect”, FuzzyScan will perform special transmission
handshaking without changing the status of Caps Lock switch.
Wireless FuzzyScan
Reference Manual
56
Configure Your FuzzyScan
Keyboard Interface Control
PROGRAM
♦ Delay Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
Intermessage Delay
SS
MS
Intercharacter Delay
SS
MS
Interfunction Delay
SS
MS
Intermessage Delay is a time delay between messages output by FuzzyScan. Increasing this delay will help host applications process the incoming data on time.
Intercharacter Delay is a time delay between data characters output by FuzzyScan. These two parameters are used to synchronize data communication when : 1) the data
transmission speed is too fast, characters may be skipped; 2) multitasking operation system or host computers in a network may slow down the keyboard handling; 3)
various notebook or desktop PC systems require different timing parameter settings. Please always add one extra unit as safety margin when adjusting these two
parameters.
Interfunction Delay is a time delay between the transmissions of each segment of the message string.
Intermessage Delay, Intercharacter Delay and Interfunction Delay are unconfigurable under SPP and HID modes
None
1-99 (x10) msec.
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
None
1-99 (x5) msec.
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
None
1-99 (x5) msec.
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
.
FIN
(2 digits)
FIN
(2 digits)
FIN
(2 digits)
Wireless FuzzyScan
Reference Manual
57
Configure Your FuzzyScan
Keyboard Interface Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
Function Key Emulation
Key Pad Emulation
Upper/Lower Case
SS
SS
SS
SS
SS
SS
SS
SS
♦ Emulation Setting, Key Pad Emulation &
Upper/Lower Case Setting ♦
Enable ASCII 00-31 code as keyboard function code output
Ctrl-Output
Refer to Appendix – Keyboard Function Code Table for details.
Disable key pad emulation
Enable numeric output as key pad (Num Lock On) output
Normal case (neglect the upper/lower case control)
Inverse case (change all characters output to inverse case)
Upper case (force all characters output as upper case)
Lower case (force all characters output as lower case)
F_DEFAULT
0
1
0
1
0
1
2
3
Wireless FuzzyScan
Reference Manual
58
Configure Your FuzzyScan
Key
Serial Interface Control
PROGRAM
♦ Record Suffix, Preamble ,Postamble Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
STX/ETX Control
Record Suffix
Preamble
Postamble
SS
Disable STX/ETX transmission
SS
Enable STX/ETX transmission
STX/ETX are two characters used to indicate the starting and ending of the total
data frame transmitted via serial interface.
SS
None
SS
CR (0DH)
SS
LF (0AH)
SS
CRLF (0D0AH)
SS
TAB (09H)
SS
SPACE (20H)
MS
User defined character (1 character)
SS
None
MS
1-15 characters
Maximum 15-character input; scan “FIN” to terminate this selection.
SS
None
MS
1-15 characters
Maximum 15-character input; scan “FIN” to terminate this selection.
0
1
0
1
2
3
4
5
6, (00-7F)
FIN
[00-7F], [FIN]
FIN
[00-7F], [FIN]
FNC1 Symbol Char. Transmit
Serial Interface Message String (RS232, USB COM) :
STX Preamble Data Length Prefix Symbol ID Scanned Data Suffix Symbol ID Postamble ETX Record Suffix
1 character
Wireless FuzzyScan
Reference Manual
SS
Disable
SS
1-15 characters 2-4 digits 1 or 3 characters Variable length 1 or 3 characters 1-15 characters 1 character 1 character
When this function is enabled and the FNC1 is contained in scanned data, the
scanner transmits the FNC1 to the host. Chart of the FNC1 is provided in Appendix –
scan code is converted to corresponding key function before it is transmitted
Enable
board Function Code Table. When the scanner interface is set to keyboard, the
59
0
1
Configure Your FuzzyScan
Serial Interface Control
PROGRAM
♦ Delay Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
Intermessage Delay
SS
MS
Intercharacter Delay
SS
MS
Interfunction Delay
SS
MS
Intermessage Delay is a time delay between messages output by FuzzyScan. Increasing this delay will help host applications process the incoming data on time.
Intercharacter Delay is a time delay between data characters output by FuzzyScan. These two parameters are used to synchronize data communication when : 1) the data
transmission speed is too fast, characters may be skipped; 2) multitasking operation system or host computers in a network may slow down the keyboard handling; 3)
various notebook or desktop PC systems require different timing parameter settings. Please always add one extra unit as safety margin when adjusting these two
parameters.
Interfunction Delay is a time delay between the transmissions of each segment of the message string.
Intermessage Delay, Intercharacter Delay and Interfunction Delay are unconfigurable under SPP and HID modes.
None
1-99 (x10) msec.
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
None
1-99 (x5) msec.
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
None
1-99 (x5) msec.
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
FIN
(2 digits)
FIN
(2 digits)
FIN
(2 digits)
Wireless FuzzyScan
Reference Manual
60
Configure Your FuzzyScan
Serial Interface Control
PROGRAM
♦ Protocol, ACK/NAK Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
Handshaking Protocol
NAK Retry Count
SS
None (free running mode)
SS
RTS/CTS (hardware handshaking)
SS
ACK/NAK (software handshaking)
SS
Xon/Xoff (software handshaking)
SS
3 times
SS
0~255 times
0
1
2
3
FIN
(3 digits)
SS
ACK Indication
USB COM doesn’t support RTS/CTS handshaking protocol.
When the ACK/NAK Software Handshaking option is selected, the FuzzyScan waits for an ACK (acknowledge) or NAK (not acknowledge) from the host computer after
each data transmission. If the NAK is received, FuzzyScan will re-send the data until receiving ACK.
ACK/NAK handshaking protocol is workable under following conditions:
1) Pair mode by using RS232 or USB COM interface.
2) SPP master or slave mode.
NAK Retry Count
After transmitting data, the scanner expects a NAK response from the host up to the preset “Serial Response Time-out”. If the scanner doesn’t get a response, the scanner
will issue an error indication and discard the data. When a NAK is received, the scanner transmits the same data again and waits for either an ACK or NAK. The scanner
issues an error indication and discards the data under following two conditions:
1) After preset NAK retry counts is received within the preset serial response time-out.
2) If the preset time-out is up but the preset NAK retry counts haven’t come to the end.
The default retry counts are three times. If you program “0 time”, the scanner won’t resend the data to the host when the scanner receives a NAK. The scanner will discard
the data. If you program “255 times”, the scanner can receive unlimited NAKs from the host within the pre-set serial response time-out.
This function is not available for batch mode. When you enable this function in on-line mode, the out-of-range function will be disable automatically.
ACK Indication:
Disable: There’s neither LED nor beeping indication for this setting.
Enable: There’s a specific LED and beeping indication for this setting.
Disable ACK Time-out Indication
SS
Enable ACK Time-out Indication
SS
Disable ACK Indication
SS
Enable ACK Indication
0
1
2
3
Wireless FuzzyScan
Reference Manual
61
Configure Your FuzzyScan
Serial Interface Control
PROGRAM
♦Time Out Setting, Baud Rate, Data Frame ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
SS
Serial Response Time-out
Baud Rate (BPS)
Data Frame
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
None
200 mseconds
500 mseconds
800 mseconds
1 second
2 seconds
38.4K BPS
19.2K BPS
9600 BPS
4800 BPS
8, None, 1
8, Odd, 1
8, Even, 1
8, Space, 1
8, Mark, 1
8, None, 2
7, Odd, 1
7, Even, 1
3 seconds
4 seconds
5 seconds
8 seconds
10 seconds
15 seconds
2400 BPS
1200 BPS
57.6K BPS
115.2K BPS
7, Space, 1
7, Mark, 1
7, None, 2
7, Odd, 2
7, Even, 2
7, Space, 2
7, Mark, 2
0
1
2
3
4
5
0
1
2
3
0
1
2
3
4
5
6
7
6
7
8
9
A
B
4
5
8
9
8
9
A
B
C
D
E
When the RTS/CTS Hardware Handshaking option is selected, the RTS (request to send) and CTS (clear to send) signals will be issued before normal data
communication. This option is very helpful to ensure the reliability of data communication.
The Serial Response Time-out is a pre-defined delay time for FuzzyScan to wait for handshaking, acknowledgment or non-acknowledgment from the host
computer.
Wireless FuzzyScan
Reference Manual
62
Configure Your FuzzyScan
Wand/L aser Emulation Control
[
PROGRAM
♦ Output Polarity, Signal State, Margin/Module Time ♦
(F, L, PF & PL Series)
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Cod e
Output Polarity
Initial Signal State
Margin Time
Module Time
SS
High level (5Vdc) on Bar (low level on Space)
SS
Low level (0Vdc) on Bar (high level on Space)
Determine the output voltage level for both bar and space.
SS
High Level (5Vdc)
SS
Low Level (0Vdc)
Determine the initial state of output voltage level.
SS
10 msec.
SS
15 msec.
SS
SS
SS
SS
SS
SS
SS
20 msec.
25 msec.
30 msec.
Extremely short
Short
Medium
Long
0
1
0
1
0
1
2
3
4
0
1
2
3
Narrow/Wide Ratio
Wireless FuzzyScan
Reference Manual
1:2
1:2.5
1:3
0
1
2
63
SS
SS
SS
Configure Your FuzzyScan
Wand/L aser Emulation Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Cod e
Code 39/Code 128 Emulation
[ Code 39 Skip] : When this option is selected, all scanned data will be translated as Standard Code 39 wand/laser emulation output. If any lowe r case characters a re read,
they will be translated to upper case characters. Any other characters that are not available in Code 39 symbology set will be skipped.
[ Code 39 Replace] : Any character not normally available in the standard Code 39 symbology set, will be translated as Space.
♦ Output Polarity, Signal State, Margin/Module Time ♦
SS
Disable standard Code 39 emulation
SS
Enable standard Code 39 skip emulation
SS
Enable standard Code 39 replace emulation
SS
Enable Full ASCII Code 39 emulation
SS
Enable Code 128 emulation
(F, L, PF & PL Series)
F_DEFAULT
0
1
2
3
4
Wireless FuzzyScan
Reference Manual
64
Configure Your FuzzyScan
Operation Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
SS
Operation Mode
Trigger Mode (Low Power Triggering) the scanner goes into standby state after scanning the bar code. You must press the trigger to turn on the light source of the
scanner before scanning the bar code.
Presentation Mode (Auto Detection) Presentation mode uses ambient light to detect the bar codes. The light source is off until the scanner detects an image which is
similar to a barcode. Then the light source turns on automatically to read the bar code. If the light level in the room is not high enough, Presentation Mode may not work
properly. You can choose different level of “Presentation Sensitivity” to meet your application (Please refer to the setting of “Presentation Sensitivity”).
PF/PL series do not support “Presentation Mode”.
Trigger mode
SS
Presentation mode
♦ Operation Mode ♦
F_DEFAULT
1
2
Wireless FuzzyScan
Reference Manual
65
Configure Your FuzzyScan
Operation Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
Batch Reading
Batch Reading: When this function is enabled, you can scan multiple barcodes one by one continuously upon one trigger event. The scanner reports a good read beep and
indication only if all bar codes set by the “Batch Reading Rule” are read. Otherwise, the scanner reports an error beep and indication. The scanned data will be transmitted
according to the preset sequence which is defined in “Batch Reading Rule” regardless the scanned order of those barcodes.
Batch Reading function is only available Trigger Mode.
Batch Reading is not available when Multiple Read Mode or Center Alignment is turned on.
Batch Reading Rule:
- To set the Batch Reading rule
1. Scan the PROGRAM symbol.
2. Scan the Batch Reading symbol (Family Code).
3. Use the Option Code to define the preset Batch Reading rule.
4. Scan the FIN symbol.
5. Scan the END symbol to save your Batch Reading rule.
Note: Scan the ABORT and END symbol to exit without saving any Batch Reading rule setting.
- When you scan “None”, the preset Batch Reading Rule will be cancelled.
- Batch Reading Rule Syntax:
[n] [Element 1] FF [Element 2] FF [Element 3] FF …[Element n] FF
Where n is the number of elements in the overall rule. The number of elements is up to 16.FF indicates the end of one element.
- Element structure:
[Cino ID Hex value] [Code length] [Character match(es)]
Where:
[Cino ID Hex value]
Length: 2 byte
Please find Cino ID hex value from Symbology ID Table in appendix. Locate the Hex value for the symbology and scan the 2 digit hex values from the Option
Code.
Note: 99 is the universal number, indicating all symbologies.
SS None
Batch Reading rule input ( 01-16 rules)
(A Series)
♦ Batch Reading ♦
F_DEFAULT
[FIN]
[Rules] [FIN]
Wireless FuzzyScan
Reference Manual
66
Configure Your FuzzyScan
[Code length]
Length: 4 byte
Specify what length of data output will be acceptable for this symbology. When you calculate the length, you must consider the whole data string which includes the
programmed Preamble, Postamble, Scanned Data Length, Prefix/Suffix Symbol ID or AIM ID. Scan the four digit data length from the Option Code.
Note: 40 characters is entered as 0040; 9999 is a universal number, indicating all lengths.
[Character match]
Length: 2-8 byte
You can refer to HEX/ASCII Reference Table to find the Hex value that represents the character(s) you want to match. Use the Option Code to scan the
alphanumeric combination that represents the ASCII characters. You can match up to 4 characters which are counted from the start character of the whole Data
String.
Note: When setting the matched character(s), you must match the content of the whole Data String, including the programmed Preamble, Postamble, Scanned
Data Length, Prefix/Suffi Symbol ID OR AIM ID if you had defined. FF is the universal character, indicating all characters.
- Batch Reading rule example
In this example, you are scanning Code 39, Code 128, and Code 93 bar codes, but you would like to output the data in following sequence:
Code 128 - Code 39 - Code 93
Wireless FuzzyScan
Reference Manual
B-CODE39
A-CODE128
C-CODE93
67
Configure Your FuzzyScan
You would set up the Batch Reading rule with the following command line:
[PROGRAM] [Batch Reading] [0301999941FF07999942FF09999943FF] [FIN] [END]
The breakdown of the command line is shown below:
03 The number of elements in the overall rule
01 Code identifier of Code 128
9999 Code length that must match for Code 128, 9999 = all lengths
41 Start character match for Code 128, 41h = “A”
FF End of first code
07 Code identifier of Code 39
9999 Code length that must match for Code 39, 9999 = all lengths
42 Start character that must match for Code 39, 42h = “B”
FF End of second code
To program the previous exampl e using specific lengths, you would have to count the programmed Preamble, Postamble, Scanned Data Length, Prefix/Suffix
Symbol ID OR AIM ID if you had defined as part of the length. If you enable the Suffix Symbol ID of symbology, you would add one character to the previous
example’s length.
You would set up the Batch Reading rule with the following command line:
[PROGRAM] [Batch Reading] [0301001041FF070009FF09000943FF] [FIN] [END]
Wireless FuzzyScan
Reference Manual
09 Code identifier of Code 93
9999 Code length that must match for Code 93, 9999 = all lengths
43 Start character match for Code 93, 43h = “C”
FF End of third code
68
The breakdown of the command line is shown below:
03 The number of elements in the overall rule
01 Code identifier of Code 128
0010 Code length that must match for Code 128
A-CODE128 sample length (9) plus Suffix Symbol ID (1) = 10
41 Start character match for Code 128, 41h = “A”
FF End of first code
07 Code identifier of Code 39
0009 Code length that must match for Code 39
B-CODE39 sample length (8) plus Suffix Symbol ID (1) = 9
FF
Universal matched character, indicating all character
Also indicate end of second code
09 Code identifier of Code 93
0009 Code length that must match for Code 93
C-CODE93 sample length (8) plus Suffix Symbol ID (1) = 9
43 Start character match for Code 93, 43h = “C”
Configure Your FuzzyScan
Note: If the [Character match(es)] is set to “FF”, the following “FF” which indicated the end of the code was not need to set.
- Structure of Data String
(RS232/USB COM
Wireless FuzzyScan
Reference Manual
FF End of third code
STX
interface)
1 character 1-15 characters 2-4 digits 1 or 3 characters Variable length 1 or 3 characters 1-15 characters 1 character
Preamble Scanned Data
Length
Prefix Symbol ID
Or
Prefix AIM Symbol ID
Scanned Data modified
by DataWizard
Suffix Symbol ID
Or
Suffix AIM Symbol ID
Postamble
ETX
(RS232/USB COM
interface)
69
Configure Your FuzzyScan
Operation Control
PROGRAM
♦ Buzzer, Indicator, Vibrator, 1D Code Inverse Reading ♦
(All Series)
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
SS
Buzzer Tone Adjust
Power On Indicator
Good Read Indicator
Vibrator Control
Buzzer tone – mute
SS
Buzzer tone – low
SS
Buzzer tone – medium
SS
Buzzer tone – high
SS
Buzzer tone - extremely high
SS
Power-on beep
SS
No power-on beep
SS
Disable (LED off)
SS
LED steady on
SS
LED flash
SS
Disable
SS
Enable
SS
Disable
SS
Enable
Optional function, only available for vibrator model.
0
1
2
3
4
5
6
0
1
2
0
1
0
1
1D Barcode Inverse Reading
Wireless FuzzyScan
Reference Manual
SS
SS
Disable
Enable
0
1
70
Configure Your FuzzyScan
Operation Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
Beeping Control
Radio Connection Beeps
♦ Buzzer, Indicator, Vibrator, 1D Code Inverse Reading ♦
SS
Radio Connected/ Disconnected Beep On
SS
Radio Connected/ Disconnected Beep Off
SS
Battery Power Low Beep On
SS
Battery Power Low Beep Off
SS
Four ascending tone / Four descending tone
SS
Low-high two beeps / High-low two beeps
(All Series)
F_DEFAULT
0
1
2
3
0
1
Wireless FuzzyScan
Reference Manual
71
Configure Your FuzzyScan
Operation Control
PROGRAM
♦ Dollar Sign Control, Redundancy, Control ♦
(All Series)
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
Dollar Sign Control
Redundancy
Beeping Control
Dollar sign output as “ $ “
SS
Dollar sign output as “￥“
SS
Dollar sign output as “ € “
SS
Dollar sign output as “ £ “
SS
Dollar sign output as “ ¢ “
SS
None
SS
Level 1
SS
Level 2
SS
Level 3
SS
Level 4
SS
Level 5
To prevent potential miss reading.
SS
Radio Connected/ Disconnected Beep On
SS
Radio Connected/ Disconnected Beep Off
SS
Battery Power Low Beep On
SS
Battery Power Low Beep Off
0
1
2
3
4
0
1
2
3
4
5
0
1
2
3
SS
The Redundancy is the number of times the same bar code label has to be decoded before it is transmitted.
Wireless FuzzyScan
Reference Manual
72
Configure Your FuzzyScan
Operation Control
PROGRAM
(All Series)
♦ Delay Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
Reread Delay
(Double Scan Verification)
Good Read Delay
HID Mode Transmit Delay
SS
Disable
SS
Immediate time out
SS
Short time out
SS
Medium time out
SS
Long time out
SS
Force verification
SS
None
SS
200 msec.
SS
500 msec.
SS
1 sec.
SS
1.5 sec.
SS
2 sec.
SS
3 sec.
SS
None
MS
1-250 msec.
Scan 3 digits from the option code chart in Appendix, then FuzzyScan will terminate
this selection automatically.
FIN
(3 digits)
0
1
2
3
4
5
0
1
2
3
4
5
6
The Reread Delay (Double Scan Verification) is designed to inhibit FuzzyScan from reading the same bar code label twice in pre-defined short duration. Force Verification
will not allow reading of the same bar code twice.
This Good Read Delay is the minimum amount of time before the scanner can read another bar code.
Wireless FuzzyScan
Reference Manual
73
Configure Your FuzzyScan
Operation Control
PROGRAM
♦ Time-out Setting, Good Read Duration ♦
(All Series)
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
Short
Medium
Long
Extremely long
Short
Medium
Long
Extremely long
Disable
Short
Medium
Long
Extremely long
Extremely short
1 sec
3 secs
5 secs
7 secs
9 secs
Immediate
Light Source On Time
Hands Free Time-out
Good Read Duration
Time Delay to Low Power Trigger
The Light Source On Time is a pre-defined light source time out counter for Alternative Mode, Presentation Mode and Level Mode. The scanner keeps the light source on
till the pre-defined light source on time is up. You can adjust this parameter to meet your own application requirement.
The Presentation Mode is referred to as “hands free” mode. The hands free mode will be automatically changed to manual trigger mode when you press the trigger. You
can remain the scanner in manual trigger mode by setting the Hands Free Time-Out. Once the time-out duration is up (if there’s no any trigger operation), the imager will
revert to the original hands free mode.
The Time Delay to Low Power Trigger sets the time for scanner to enter low power trigger mode after any scanning activity.
0
1
2
3
0
1
2
3
4
0
1
2
3
4
0
1
2
3
4
5
Wireless FuzzyScan
Reference Manual
74
Configure Your FuzzyScan
Operation Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
Presentation Auto-sense
Presentation Sensitivity
When enable the Presentation Auto-sense, the scanner can be switched between hands free scanning and hand-held scanning automatically when working with the
SmartStand or cradle.
The Presentation Sensitivity is used to configure the sensitivity level when the scanner is set as presentation mode. The higher lever means higher sensitivity for detecting
the barcode.
♦ Presentation Scanning Setting, Laser Aiming Control ♦
SS
Disable
SS
Enable
SS
Level 1
SS
Level 2
SS
Level 3
SS
Level 4
SS
Level 5
(All Series)
Level 6
Level 7
F_DEFAULT
0
1
0
1
2
3
4
5
6
Wireless FuzzyScan
Reference Manual
75
Configure Your FuzzyScan
Operation Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
SS
SS
Dynamic
Fixed
Scan Rate Control
Scan Rate Control: The scanner will have better motion tolerance when you select “Fixed” scan rate. It’s suitable for application which needs higher motion tolerance on
the move. But this may impact to the reading distance.
(F, L, PF & PL Series)
♦ Scan Rate Control, ♦
F_DEFAULT
0
1
Wireless FuzzyScan
Reference Manual
76
Configure Your FuzzyScan
Operation Control
PROGRAM
♦ Smart stand Power Off Timeout, Laser Aiming Control,
(L & PL Series)
F_DEFAULT
LED Illumination Control ♦
Family Code Selection P.C Parameter Selection Option Code
SS
SmartStand Power Off Timeout
Laser Aiming Control
LED Illumination Control
LED Illumination Delay
3 mins
SS
5 mins
SS
10 mins
Only available for FuuzzyScan Laser model
SS
Disable
SS
Enable
Only available for L series laser imaging scanner.
SS
Always on
SS
Intelligent Mode
Only available for L& PL Series.
SS
100 ms
SS
150 ms
SS
200 ms
SS
250 ms
SS
300 ms
Only available for L & PL Series.
0
1
2
0
1
0
1
0
1
2
3
4
The SmartStand Power Off Timeout is a pre-defined duration for scanner’s light source on time when the scanner is placed on SmartStand. While the scanner is placed
on SmartStand, the scanner’s will be switched from hand-held scanning to presentation scanning and the light source will be forced on automatically. The light source will
be off when the pre-defined duration is up.
Laser Aiming Control: You can disable or enable laser aiming line when you scan PDF barcode
LED Illumination Control : When you enable “always on“, the LED illumination will be always on when you press the trigger. When you enable “intelligent mode”, the
scanner will emit the laser aiming line first, the LED illumination will be turned on after the preset LED illumination delay. Intelligent mode is recommended to be used in
regular ambient light environment.
Wireless FuzzyScan
Reference Manual
77
Configure Your FuzzyScan
Operation Control
(A Series)
F_DEFAULT
PROGRAM
♦ Aiming Control, Delay Aiming & Decode Aiming Control ♦
Family Code Selection P.C Parameter Selection Option Cod e
SS
Illumination Control
Presentation Background Lighting
SS
SS
SS
Disable
Enable
LEDs Off
LEDs On
SS
Aiming Control
Delay Aiming Time-out Control
Regular Aiming
SS
Intelligent Aiming
SS
Delay Aiming Control
SS
200 ms
SS
400 ms
SS
800 ms
SS
1 sec
1.5 secs.
2 secs.
3 secs.
4 secs.
0
1
2
3
0
1
0
1
0
1
2
4
5
6
7
Decode Aiming Control
The Illumination Control is only available for hand-held mode.
Presentation Background Lighting Control: You can enable or disable presentation background lighting of the scanner according to the ambient light condition in
presentation mode. When the ambient light is dim or dark, you can enable this function to turn on the scanner’s LED illumination at a dim level. This is helpful for scanner to
detect the motion of scene.
The Aiming Control is only available for trigger mode. In Intelligent Aiming, the aiming light is turned on when the scanner is lifted. A trigger pull activates decoding process.
After 2 seconds of inactivity, the aiming light will be shut off. Delay Aiming Control allows a delay time for the operator to aim the scanner before the image is taken. During
the delay time, the aiming light will be on, but the LED illumination won’t be turned on until the delay time is up.
The Delay Aiming Time-out Control is only available for trigger mode. You can use Delay Aiming Time-out Control to set the delay time.
Wireless FuzzyScan
Reference Manual
SS
Disable in Hand-Held mode
SS
Enable in Hand-Held mode
SS
Disable in Hand-Free mode
SS
Enable in Hand-Free mode
0
1
2
3
78
Configure Your FuzzyScan
Operation Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Cod e
Center Alignment
Unique Bar Code Reporting
Center Alignment: When this function is enabled, the scanner only decodes barcode(s) around aiming line.
Unique Bar Code Reporting: When this function is enabled, the scanner only outputs unique barcode when the trigger is pressed. This function is workable when Multiple
Read mode is selected.
♦ Center Alignment, Unique Bar Code Reporting ♦
SS
Disable in Hand-Held Mode
SS
Enable in Hand-Held Mode
SS
Disable in Hand-Free Mode
SS
Enable in Hand-free Mode
SS
SS
Disable
Enable
(A Series)
F_DEFAULT
0
1
2
3
0
1
Wireless FuzzyScan
Reference Manual
79
Configure Your FuzzyScan
Operation Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
Out-of-range Scanning
Link Supervision Time-out
Out-of-range Scanning When radio link is built between the scanner and remote host device, the scanner will transmit each scanned data right after scanning the barcode
data. However, the scanner is preset for unable to scan any barcode data when it loses the radio connection. You can enable the Out-of-range Scanning function to
continue scanning barcode data into memory buffer until radio link resumed.
The Link Supervision Time-out is a pre-defined radio link supervision timeout setting. The scanner will supervise the radio link status every preset seconds.
.
♦ Out-of-range Scanning, Link Supervision Time-out ♦
SS
Disable
SS
Enable
SS
1 sec
SS
SS
SS
SS
3 secs
5 secs
7 secs
9 secs
Only available in PAIR & PICO modes
(All Series)
F_DEFAULT
0
1
0
1
2
3
4
Wireless FuzzyScan
Reference Manual
80
Configure Your FuzzyScan
Operation Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
Sleep Time-out of Connect State
Sleep Time-out of Disconnect State
Power Off Time-out
The Sleep Time-out Control can be set under radio connection or disconnection state. If the scanner is not used within the preset time-out duration, it will automatically
enter “Sleep Mode” for power saving purpose. You are able to disable this function by setting the time-out duration to “0”.
The Power Off Time-out Control: When the scanner is under Sleep Mode, it is preset to enter Power Off automatically if it‘s not woke up after time-out duration. If you
would like to wake up the scanner, please press the trigger button. Meanwhile, you are able to disable this function by setting the time-out duration to “0”.
♦ Sleep Time-out Control, Power Off Time-out Control ♦
SS
6 (x5) minutes
MS
0-99 (x5) minutes
If you don’t want the scanner to enter sleep mode, please set time-out to “0”
SS
1 minute
MS
0-99 minutes
If you don’t want the scanner to enter sleep mode, please set time-out to “0”
SS
6 (x5) minutes
MS
0-12 minutes
If you don’t want the scanner to enter power off mode, please set time-out to “0”
(All Series)
F_DEFAULT
FIN
(2 digits)
FIN
(2 digits)
FIN
(2 digits)
Wireless FuzzyScan
Reference Manual
81
Configure Your FuzzyScan
Operation Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
SS
Batch Scanning Link Control
Stored Data Transmission
Delete Stored Data after
Transmission
The Batch Scanning Link Control is a pre-defined radio option to control the radio-on or radio-off status under batch scanning operation. Please note that if the radio
disable is activated, the radio link will be disconnected once you enter batching scanning. The radio link will be resumed when you transmit the stored data or exit batch
scanning.
The Stored Data Transmission is a pre-defined approach when you want to transmit the scanned data under batch scanning operation. You can transmit the scanned data
by placing the scanner onto the cradle or scanning “Transmit Stored Data” command, or by either one of both methods.
In batching scanning, the default setting of Delete Stored Data after Transmission is disable. The scanner will keep all stored data after transmission until you scan the
“Clear All Stored Data” command. You are also able to delete all stored data after transmission automatically by enabling this function.
Radio disable
SS
Radio enable
SS
All
SS
On cradle
SS
Scan barcode
SS
Disable
SS
Enable
♦ Batch Scanning Setting ♦
(All Series)
F_DEFAULT
0
1
0
1
2
0
1
Wireless FuzzyScan
Reference Manual
82
Configure Your FuzzyScan
Operation Control
PROGRAM
♦ Batch Scanning Data Transmission Setting ♦
(All Series)
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
Field Delimiter
Batch Data Quantity Output Format
SS
SS
SS
SS
SS
SS
SS
SS
SS
None
，
SPACE
–
．
User define
As many times as the quantity indicates
<Quantity><Field Delimiter><Scanned Data>
<Scanned Data><Field Delimiter><Quantity>
0
1
2
3
4
5, [00-7F]
0
1
2
SS
Data Transmission Format
The Field Delimiter is used to separate the specific information and scanned data into two fields. You can choose desired delimiter format.
The Batch Data Quantity Output Format If you want to input the quantity information of barcode data, you can enter the quantity from 1 to 9999 by scanning the quantity
barcodes right after you scanned the barcode data. The quantity information will be stored into the memory storage together with the barcode data. There are three ways to
output the stored barcode data and quantity information.
In PICO mode, up to 7 scanners can be connected with one smart cradle. The Data Transmission Format can help user to identify the source of the transmitted data.
You can choose to transmit the scanned data leading with MAC address or pre-assigned ID.
Example format: <MAC address><Field Delimiter><Data> or <ID><Field Delimiter><Data>.
Disable (scanned data only)
SS
Leading with MAC address (MAC address and scanned data)
SS
Leading with ID No. (scanner ID and scanned data)
Only available for RS232, USB HID and USB COM interface in PAIR & PICO modes
0
1
2
Wireless FuzzyScan
Reference Manual
83
Configure Your FuzzyScan
Operation Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
Bluetooth Device Name
Bluetooth PIN Code
Bluetooth Authentication
The default Bluetooth Device Name for F/L series is “F(L)xxxBT-xxxx”, and for PF/PL series is PF(L)xxxBT-xxxx, you will be able to change the device name by scanning
HEX values (1-16 characters).
The default Bluetooth Device Name for A series is “AxxxBT-xxxx”, you will be able to change the device name by scanning HEX values (1-32 characters).
The default Bluetooth PIN Code is “00000000”, you will be able to change the PIN Code by scanning HEX values (1-8 numbers).
The Bluetooth Authentication You can enable or disable the Bluetooth Authentication between the scanner and remote host device. If this function is enabled, when the
scanner wants to connect itself and sends the data to the host device, the host device has to return a link key shared between the scanner and the host device.
SS
MS
SS
MS
SS
SS
♦ Bluetooth Device Name & Security Setting♦
Default device name
User define;
F/L series: 1-16 characters
A series: 1-32 characters
Default Bluetooth PIN Code
User define, 1-8 numbers
Disable
Enable
(All Series)
F_DEFAULT
FIN
[00-7F], FIN
FIN
[30-39], FIN
0
1
Wireless FuzzyScan
Reference Manual
84
Configure Your FuzzyScan
Operation Control
PROGRAM
Family Code Selection P.C Parameter Selection Option Code
SS
SS
SS
SS
SS
SS
SS
Disable
Enable
Disable
Level 1
Level 2
Level 3
Level 4
Bluetooth Power Saving Mode
Link Quality Control
The Bluetooth Power Saving Mode Bluetooth module will enter low consumption mode when you enable this function.
Link Quality Control: This function is only available for SPP and HID mode. When you use the scanner in the boundary of radio signal, you can enable this function to
increase the reliability of data transmission. But this function will affect the communication distance. The level is higher, the communication distance is shorter.
♦ Bluetooth Other Settings ♦
F_DEFAULT
0
1
0
1
2
3
4
Wireless FuzzyScan
Reference Manual
85
Configure Your FuzzyScan
Condensed DataWizard
PROGRAM
♦ Preamble, Postamble, Data Length & Symbol ID Trans. ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
Preamble
SS
MS
Postamble
SS
MS
Data Length Transmission
SS
SS
Symbology ID Transmission
DataWizard is the most powerful, Artificial-Intelligence based data editing expert system provided specially for the FuzzyScan family bar code readers. Through DataWizard,
you can process the scanned data prior the transmissions in many ways as: Insert, Delete, Match, Verify, Replace, Reorganize, and Repeat Transmission. It will help
you to arrange the transmission of scanned data to any specific format without software modification.
Due to the resources used by this system, Full-feature DataWizard is only supported by PowerTool. Through the PowerTool, all settings and configurations can be done
on-screen, under Windows 95/98/NT/2000/XP environment.
A Condensed Version DataWizard is provided by each FuzzyScan series. Through this menu, the condensed DataWizard can be utilized via bar code menu readings with
ease.
Please note that all “Character” input should be referred to the ASCII/HEX Table listed in Appendix to find matched HEX value.
If you have any problem to use DataWizard, please refer to following pages for details and consult your local FuzzyScan vendor or our web site for any assistance.
SS
SS
SS
SS
SS
SS
SS
None
1-15 characters
Maximum 15-character input; scan “FIN” to terminate this selection.
None
1-15 characters
Maximum 15-character input; scan “FIN” to terminate this selection.
Disable
Enable 2 digits data length transmission
If data length exceeds 99, 3-digit data length will be transmitted.
Disable symbology ID transmission
Enable prefix symbology ID transmission
Enable suffix symbology ID transmission
Enable both prefix and suffix symbology ID transmission
Enable prefix AIM symbology ID transmission
Enable suffix AIM symbology ID transmission
Enable both prefix and suffix AIM symbology ID transmission
FIN
[00-7F], [FIN]
FIN
[00-7F], [FIN]
0
1
0
1
2
3
4
5
6
Wireless FuzzyScan
Reference Manual
86
Configure Your FuzzyScan
Condensed DataWizard
PROGRAM
♦ Data Formatter Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code 2nd Option Code
Formatter Control
1st Insertion
2nd Insertion
3rd Insertion
SS
MS
MS
SS
DS
SS
DS
SS
DS
Disable
Select one bar code symbology
Select all bar code symbologies
Disable
Enable
2-digits identified position; max. 3 insertion characters
Disable
Enable
2-digits identified position; max. 3 insertion characters
Disable
Enable
2-digits identified position; max. 3 insertion characters
FIN
(2 digits)
00
FIN
(2 digits)
position
FIN
(2 digits)
position
FIN
(2 digits)
position
automatic termination
automatic termination
[1-3 characters], [FIN]
[1-3 characters], [FIN]
[1-3 characters], [FIN]
The Data Formatter is used to edit the scanned raw data prior to transmitting the data to the host computers or terminals. It allows you to select desired bar code
symbologies for formatter control, and provides Multiple Position Insertion and Multiple Character Insertion (max three characters) in the identified position.
While the Data Formatter is enabled, it arranges only scanned data without Preamble, Postamble, STX, ETX, Data Length, Prefix/Suffix Symbolology ID or Record
Suffix. All of the above programmable parameters perform the same function depending on your setting.
Regarding the “Bar Code Selection” and “Position Calculation” of data formatter, please refer to page 60 for details.
Please note that all “Character” input should be referred to the ASCII/HEX Table listed in Appendix to find matched HEX value.
Wireless FuzzyScan
Reference Manual
4th Insertion
SS
DS
Disable
Enable
2-digits identified position; max. 3 insertion characters
87
FIN
(2 digits)
position
[1-3 characters], [FIN]
Configure Your FuzzyScan
Condensed DataWizard
PROGRAM
♦ Data Verifier Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code 2nd Option Code
Verifier Control
Identified Data Length
1st Identified Character
2nd Identified Character
SS
MS
MS
SS
MS
SS
DS
SS
DS
Disable
Select one bar code symbology
Select all bar code symbologies
Disable
Enable
Determine the identified data length for verification.
Disable
Enable
2-digits checking position; 1 identified character
Disable
Enable
2-digits checking position; 1 identified character
FIN
(2 digits)
00
FIN
(2 digits)
FIN
(2 digits)
position
FIN
(2 digits)
position
automatic termination
automatic termination
[00-7F]
[00-7F]
3rd Identified Character
The Data Verifier is used to provide advanced verification for error-free scanning and to work as an Embedded Data Transmitting Filter.
All data must conform to the Identified Bar Code Symbologies, Identified Data Length, and one to three Identified Characters in the checking position. Otherwise, the
FuzzyScan will not transmit the data to the host computers or terminals, but will instead issue 3 long beeps for verification error and skip the scanned data.
The Data Verifier checks only scanned data without Preamble, Postamble, STX, ETX, Data Length, Prefix/Suffix Symbology ID or Record Suffix.
Regarding the “Bar Code Selection” and “Position Calculation” of Data Verifier, please refer to page 60 for details.
Please note that all “Character” input should be referred to the ASCII/HEX Table listed in Appendix to find matched HEX value.
Wireless FuzzyScan
Reference Manual
SS
DS
Disable
Enable
2-digits checking position; 1 identified character
88
FIN
(2 digits)
position
[00-7F]
Configure Your FuzzyScan
Condensed DataWizard
PROGRAM
♦ Data Replacer Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code 2nd Option Code
Replacer Control
1st Replacement
2nd Replacement
3rd Replacement
SS
MS
MS
SS
DS
SS
DS
SS
DS
Disable
Select one bar code symbology
Select all bar code symbologies
Disable
Enable
2-digits identified position; 1 replacement character
Disable
Enable
2-digits identified position; 1 replacement character
Disable
Enable
2-digits identified position; 1 replacement character
FIN
(2 digits)
00
FIN
(2 digits)
position
FIN
(2 digits)
position
FIN
(2 digits)
position
automatic termination
automatic termination
[00-7F]
[00-7F]
[00-7F]
The Data Replacer is used to edit the scanned raw data prior to transmitting the data to the host computers or terminals. It allows you to select desired bar code
symbologies for replacer control, and provides Multiple Position Replcement in the identified position.
All data must conform to the Identified Bar Code Symbologies, and one to three Identified Characters in the identified position While the Data Replacer is enabled, it
arranges only scanned data without Preamble, Postamble, STX, ETX, Data Length, Prefix/Suffix Symbology ID or Record Suffix.
Regarding the “Bar Code Selection” and “Position Calculation” of Data Replacer, please refer to page 60 for details.
Please note that all “Character” input should be referred to the ASCII/HEX Table listed in Appendix to find mathced HEX value.
Wireless FuzzyScan
Reference Manual
89
Configure Your FuzzyScan
Condensed DataWizard
PROGRAM
♦ Data Organizer Setting ♦
F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code 2nd Option Code
Organizer Control
1st Organization
2nd Organization
Include/Exclude Control
SS
MS
MS
SS
DS
SS
DS
SS
DS
Disable
Select one bar code symbology
Select all bar code symbologies
Disable
Enable
2-digits identified position;
Forward/backward data transmission setting
Disable
Enable
2-digits identified position;
Forward/backward data transmission setting
Transmitted data excluded the data of identified position
Transmitted data included the data of identified position
FIN
(2 digits)
00
FIN
(2 digits)
position
direction
FIN
(2 digits)
position
direction
0
1
automatic termination
automatic termination
0 (Forward)
1 (Backward)
0 (Forward)
1 (Backward)
The Data Organizer is used to edit the scanned raw data prior to transmitting the data to the host computers or terminals. It allows you to select desired bar code
symbologies for organizer control, and provides maximum two identified positions to send the data forward or backward. It also allows you to control the transmitted data
including or excluding the data of identification position. Please refer to the application example listed in page 60 for details.
While the Data Organizer is enabled, it arranges only scanned data without Preamble, Postamble, STX, ETX, Data Length, Prefix/Suffix Symbology ID or Record
Suffix.
Regarding the “Bar Code Selection” and “Position Calculation” of Data Organizer, please refer to page 60 for details.
Please note that all “Character” input should be referred to the ASCII/HEX Table.
Wireless FuzzyScan
Reference Manual
90
Configure Your FuzzyScan
Select a Bar Code Symbology
You can select one or all types of bar code symbologies to
use Condensed DataWizard for advanced transmission
arrangement. If you scan “00” to select all types, the
FuzzyScan will arrange all incoming data to meet your
pre-defined format. If you want to select only one type bar
code, please select one of the option code listed below.
1D Bar Code Symbology
Code 128 01 Matrix 2 of 5 38
GS1-128 31 Interleaved 2 of 5 48
UPC-A 02 China Postal Code 58
UPC-A with 2 supplement 32 German Postal Code 68
UPC-A with 5 supplement 42 Standard/Industrial 2 of 5 08
UPC-E 03 Code 93 09
UPC-E with 2 supplement 33 Code 11 10
UPC-E with 5 supplement 43 MSI/Plessey 11
EAN-13 04 UK/Plessey 12
EAN-13 with 2 supplement 34 Telepen 13
EAN-13 with 5 supplement 44 GS1 DataBar 14
EAN-8 05 IATA 15
EAN-8 with 2 supplement 35 Coupon Code 16
EAN-8 with 5 supplement 45 PDF417 17
Codabar/NW-7 06 Codablock F 18
Code 39 07 Code 16K 19
Code 32 37 Code 49 20
Trioptic Code 39 47 GS1 DataBar Limited 22
GS1 DataBar Expanded 23
Composite Codes 24
Micro PDF417 25
2D Bar Code Symbology
QR Code A0 MaxiCode A2
MicroQR Code A0 Aztec Code A3
DataMatrix A1 Chinese Sensible Code A4
GS1 DataMatrix A5
Postal Code
Korea Post Code 21 Japanese Post B4
Australian Post B0 KIX Post B5
British Post B1 Planet Code B6
Intelligent Mail barcode B3 Postnet B8
Position Calculation
[Data Formatter]
If there is a 5-character input data string, refer to the
following to calculate the actual position for insertion:
X X X X X
00 01 02 03 04 05
[Data Verifier, Data Replacer, Data Organizer]
If there is a 11-character data string, please refer to the
following to calculate the actual position for identification.
X X X X X X X X X X X
00 01 02 03 04 05 06 07 08 09 10
Wireless FuzzyScan
Reference Manual
91
Configure Your FuzzyScan
Application Example
If your bar code label is a 16-digit Interleaved 2 of 5 which
includes the information of 6-digit date code, 6-digit serial
number and 4-digit unit price, you want the FuzzyScan do the
following for you without software modification:
Apply only Interleaved 2 of 5 to the condensed
DataWizard.
Check bar code is actually with 16-digit length.
Allow bar code output whose date code is leading with “9”.
Three outputs with “TAB” suffix.
The date code output should skip “9” and replaced it by
“A”.
The serial number output should be led with “SN”.
The unit price output should be skipped the first 2 digits.
Programming Procedure
[Data Verifier]
Scan “Program” to enter the programming mode.
Scan “Verifier Control” and set bar code symbology to
“48” (Interleaved 2 of 5).
Scan “Identified Data Length” and set the length to
“16”.
Scan “1st Identified Character” and set the identified
position to “00”, then set the identified character to “39”
(Hex Code of 9).
[Data Formatter]
Scan “Formatter Control” and set bar code symbology
to “48”.
Test Bar Code : 9 8 1 0 2 5
Actual Output : A81025[TAB]SN123456[TAB]76[TAB]
Wireless FuzzyScan
Reference Manual
1 2 3 4 5 6 9 8 7 6
Scan 1st Insertion” and set the identified position to
“06”, then inserted characters to “09” (Hex Code of
92
TAB), “53” (Hex Code of S), “4E” (Hex Code of N).
Scan “2nd Insertion” and set the identified position to
“12”, then inserted character to “09”. In the final, you
must scan “FIN” (Finish) code to terminate this
selection.
Scan “3rd Insertion” and set the identified position to
“16”, then inserted character to “09”. In the final, you
must scan “FIN” (Finish) code to terminate this
selection.
Loading...
