FUZZYSCAN WIRELESS IMAGER

Cino FUZZYSCAN WIRELESS IMAGER REFERENCE MANUAL International Edition, REV A8

WIRELESS IMAGER
Reference Manual
International Edition, Rev. A8
Wireless FuzzyScan
Spain (QWERTY) to Spain (Spanish QWERTY), Latin America (QWERTY) to
Revision History
Rev. No. Released Date Description
Rev. A Oct 16, 2009 First Release
Rev. A1 Oct 22, 2009
Rev. A2 Nov 27, 2009
Rev. A3 Mar 05, 2010
Rev. A4 Apr 27, 2010
Rev. A5 Jun 28, 2010
Rev. A6 Sep 20, 2010
Page 6 Revise “Clone Function” operation method. Page 68 Add “Save Configuration” and “Master Default” to System Commands.
Page 53 “Bluetooth Device Name” – Modify user define characters from 1 – 14
characters to 1 – 16 characters.
Page 69 Add “Indications”.
Page 25 Modify UPC-E/EAN-8 expansion and UPC-A standardization. Page 43 Rename “Time Out Control” to “Serial Response Time-out”. Page 45 Rename “Presentation Scanning Mode” to “Presentation Control”. Page 48 Rename “Auto Power Off Duration” to “Light Source On Time”.
Add “Extremely short” option to Good Read Duration. Page 49 Rename “Presentation Scanning Auto-sense” to “Presentation Auto-sense”. Add “Presentation Sensitivity”
Page 38 Hands Free Time-out – Add “Disable”. Page 43 Baud Rate – Add 57.6K BPS and 115.2K BPS.
Page 27 Add “UPC/EAN Security Level”. Page 49 Add “Time Delay to Low Power Trigger” Page 47 Add “Good Read Indicator”. Page 48 Add “Scan Voting”.
Page 25,26 Rename ”Scan Voting” to “Supplement Scan Voting” and add “Supplement
Scan Voting” in Symbology Reading Control
Page 27 Add “EAN Supplement Control” Page 38 Keyboard Layout – Add “Czech (QWERTY)”, remove “Universal”, and rename
Spain (Latin America, QWERTY)
Wireless FuzzyScan
parameter selection in Batch Data
Revision History
Rev. No. Released Date Description
Page 48 Remove ”Scan Voting” and add “Scan Rate Control ”
Rev. A6 Sep 20, 2010
Page 54 Add “<Scanned Data><Field Delimiter><Quantity>”
Quantity Output Format
Rev. A7 Nov 10, 2010
Rev. A8 Jan 2, 2011
Page 44 Baud Rate – Cancel Baud Rate 300/600 BPS.
Page 47 Buzzer Tone Adjust – Modify No power-on beep behavior. The setting of
No power-on beep will impact both Bluetooth Scanner and Smart Cradle. Add “Beeping Control” setting.
Wireless FuzzyScan
© Copyright Cino Group © Copyright PC Worth Int’l Co., Ltd
Cino makes no warranty of any kind with regard to this publication, including, but not limited to, the implied warranty of merchantability and fitness for any particular purpose. Cino shall not be liable for errors contained herein or for incidental consequential damages in connection with the furnishing, performance, or use of this publication. This publication contains proprietary information that is protected by copyright. All rights are reserved. No part of this publication may be photocopied, reproduced or translated into any language, in any forms, in an electronic retrieval system or otherwise, without prior written permission of Cino. All product information and specifications shown in this document may be changed without prior notice.
Warranty
Cino warrants its products against defects in workmanship and materials from the date of shipment, provided that the product is operated under normal and proper conditions. The warranty provisions and durations are furnished by different warranty programs. The above warranty does not apply to any product which has been (i) misused; (ii) damaged by accident or negligence; (iii) modified or altered by the purchaser or other party; (iv) repaired or tampered by unauthorized representatives; (v) operated or stored beyond the specified operational and environmental parameters; (vi) applied software, accessories or parts are not supplied by Cino; (vii) damaged by circumstances out of Cino’s control, such as, but not limited to, lightning or fluctuation in electrical power. Any defective product must follow the warranty program and RMA procedures to return Cino for inspection.
Regulatory
LED Eye Safety
FCC part 15B, FCC part 15C
EN55022, EN55024, EN60950-1, EN301 489-1 & 489-17, EN300 328
CNS13438, CNS14336
LP0002
MIC T401
IEC60825-1, EN60825-1
Wireless FuzzyScan
Table of Contents
Getting Started
Getting Familiar with Your FuzzyScan 1 Preparation before Using 2 Decide Your Radio Link Mode 3 Using FuzzyScan in PAIR Mode 4 Using FuzzyScan in PICO Mode 5 Using FuzzyScan in HID Mode 7 Using FuzzyScan in SPP Mode 8 Out-of-range Scanning/Presentation Scanning/Paging Function 10 Batch Scanning (Inventory Mode) 11
Configure Your FuzzyScan
Bar Code Programming Manual 13 Programming Procedures 14 Host Interface Selection 18 Symbology Reading Control 19 Keyboard Interface Control 38 Serial Interface Control 42 Wand/Laser Emulation Control 45 Operation Control 46 Condensed DataWizard 56
Appendix
Symbology ID Table 63 Keyboard Function Code Table 64 ASCII Input Shortcut 65 Link Mode Quick Set/Operation Mode Quick Set 66 Host Interface Quick Set 67 Option Codes 68 System Commands 69 Indications 70
Wireless FuzzyScan
Getting Started
Getting Familiar with Your FuzzyScan
Thank you for choosing Cino FuzzyScan Bluetooth Cordless Image Scanner. Powered by the combination of cutting-edge FuzzyScan 2.0 Imaging Technology and Bluetooth 2.1 EDR wireless technology, it not only provides outstanding reading performance, but also delivers the convenience and freedom of mobility. This document provides a quick reference for installation and operation purposes. The complete documentation is available at www.cino.com.tw.
F700BT Series Scanner HB2110 Smart Cradle (Base)
F600BT Series Scanner HB2100 Charging Cradle (Base)
Link Indicator
Status Indicator
Beeper
Scan Window
Trigger
Reset Button
Battery Cavity
End Cap
Center Indicator
Side Indicators
Paging/Reset Button
Host Interface Port
DC Power Jack
Power Indicator
Reserved
Reserved
DC Power Jack
1
Wireless FuzzyScan
Preparation before Using
power plugs in your power supply kit. Choose the appropriate local
Plug the DC power cord of the power supply unit into the DC power jack of the cradle.
one
lease check the power indicator of the
if
Ensure the battery co
of the battery pack are facing the charging contacts inside
e battery pack into the battery cavity until hearing a click sound before locking it
with the end cap.
beeps when the battery pack is installed
Install the Battery
Charging the Battery
Slide th
properly if the battery pack still has power.
Secure the end cap with the screw provided, and make sure the end cap is secured properly before using the scanner.
There are 4 different plug and slot it onto the power adapter cavity until it is locked.
Plug the AC power plug into the appropriate AC wall socket.
The smart cradle will issue the power on beeps and the center indicator will give blue blink. If you use the charging cradle, p charging cradle turns steady blue.
Place the scanner on the cradle. The status indicator of scanner will turn steady red the battery is not fully charged. When the battery is fully charged, the status indicator of scanner will flash green at regular interval.
Getting Started
ntacts
the battery cavity.
The scanner will give 4
Please charge the new battery pack for 8 hours prior to the first use.
2
Wireless FuzzyScan
Getting Started
Decide Your Radio Link Mode
The FuzzyScan Bluetooth image scanner provides several radio link modes to communicate with most host devices. When the Bluetooth-enabled host device is not available, it can work with the smart cradle in PAIR mode (one to one connection) or PICO mode (multiple connections) to provide a plug-and-play cordless migration of your existing non-Bluetooth-enabled IT assets. Moreover, you are also able to use the scanner to work with Bluetooth-enabled host devices via SPP master/slave modes and HID mode.
After losing the radio link, the scanner is capable of resuming the radio connection automatically while it returns to the communication coverage. But please note that this feature is not available in SPP slave mode. If you would like to change the radio link mode, you have to scan the “Uninstall” command to revert the scanner to uninstall state.
PAIR Mode
If the Bluetooth device is not available in your existing system, this is the simplest plug-and-play solution. In this mode, one scanner can only work with one smart cradle. The smart cradle not only provides the Bluetooth radio link with the scanner, but also offers the legacy cabled interfaces to the host device, including USB HID, USB COM, PS/2(DOS/V) Keyboard Wedge and RS232 Serial.
PICO Mode
For the requirement of multiple connections, up to 7 scanners can be connected to one smart cradle concurrently. If you would like to un-pair all paired scanners and smart cradle, you can simply press and hold the paging/reset button of the smart cradle for over 3 seconds. If you just want to un-pair part of the paired scanners, please take those paired scanners to scan the “Uninstall” command one by one.
HID Mode
Through the most helpful HID service, the scanner can work like a Bluetooth keyboard. In this mode, the scanner is discoverable by the radio connection request issued by a remote host device. For security purpose, you will be requested to input the PIN Code to establish the Bluetooth connection in most time.
SPP Master/Slave Mode
Through the standard SPP service, the scanner can work like a serial input device. In SPP master mode, the scanner initiates the radio connection request to a remote slave device. In SPP slave mode, the scanner is discoverable by the radio connection request issued by a remote master device.
3
Wireless FuzzyScan
Getting Started
Using FuzzyScan in PAIR Mode
Ensure the battery is fully charged. You may refer to the section of Preparations before Using for details.
Please choose your desired interface cable, then plug it into the host interface port of the smart cradle and connect it to the host device.
USB
Turn on the power of your host device.
Please note that the scanner has been pre-paired already, if the scanner is shipped together with the smart cradle. You will see the link indicator of scanner gives 1 blue blink per 2.5 seconds and the middle indicator of smart cradle turns steady blue. If the scanner and smart cradle just give alternating red and green blinks (in “Uninstall” state), please follow steps 5-6 to establish the connection between the scanner and the smart cradle.
Scan “PAIR mode” command. The status indicator of scanner will turn steady red.
PS/2 RS232
Uninstall
PAIR Mode
Place the scanner on the smart cradle, then you will hear one short beep to indicate the pairing process is activated. The scanner will give continuous short clicks and the link indicator of scanner will flash blue quickly during the pairing process. When you hear 4 beeps in ascending tone, the pairing process is completed. You will see the link indicator of scanner giving 1 blue blink per 2.5 seconds and the center indicator of the smart cradle turning steady blue.
If the scanner pairing process failed or it’s not placed on the smart cradle within 20 seconds, you will hear 2 “Di-do Di-do” beeps to indicate pair failure, the scanner will return to uninstall state automatically.
Scan the corresponding host interface quick set command to complete the installation.
The default host interface of smart cradle is preset to USB HID. If you want to set the host interface to USB COM, you have to
install the USB virtual COM driver into your host device before using the scanner. Please visit the CINO website to download
the software driver.
4
Wireless FuzzyScan
Getting Started
Using FuzzyScan in PICO Mode
Ensure the battery is fully charged and choose your desired interface cable, then plug it into the host interface port of the smart cradle and connect it to the host device.
Turn on the power of your host device.
Ensure the side indicators of the smart cradle give alternative red and green blinks (in “Uninstall” state). If the smart cradle is paired with other scanners, you can press and hold the paging/reset button for over 3 seconds to un-pair all paired scanners. Then the smart cradle will return to uninstall state automatically.
Prepare the scanners you desire to pair with smart cradle. Ensure the status indicator of each scanner give alternative red and green blinks (in “Uninstall” state). If the scanner is not in uninstall state, please scan the “Uninstall” command to un-pair the scanner. Then scan the “PICO mode” command, and the status indicator of scanner will turn steady red.
USB PS/2 RS232
Uninstall
Place the scanner on the smart cradle, then you will hear one short beep to indicate the pairing process is activated. The scanner will give continuous short clicks and the link indicator of scanner will flash blue quickly during the pairing process. When you hear 4 beeps in ascending tone, the pairing process is completed. You will see the link indicator of scanner giving 1 blue blink per 2.5 seconds, the center indicator of the smart cradle turning steady blue and its side indicators turning steady green.
If the scanner pairing process failed or it’s not placed on the smart cradle within 20 seconds, you will hear 2 “Di-do Di-do” beeps to indicate pair failure, the scanner will return to uninstall state automatically.
Scan the corresponding host interface quick set command to complete the installation.
Please follow the same procedures to pair the other scanners with the smart cradle.
For user’s convenience, the smart cradle will automatically assign the ID numbers to each scanner. After completed all pairing processes, you can scan the “System Information” command to check the assigned ID number of each scanner.
5
PICO Mode
Wireless FuzzyScan
Getting Started
Clone Function
For the user’s convenience, the clone function will help you to clone the host interface related parameters (please refer to following table for details) from one of the paired scanners to the rest of paired scanners under PICO mode. You can use one of the paired scanners to set the host interface related parameters first and then scan “Save Configuration” command. After that, please take the other paired scanners to scan “Clone” command one by one to clone the host interface related parameters.
Please ensure to keep those paired scanners in connected status when you use the “Clone” function. Because the host
interface related parameters can’t be cloned to the paired scanner in disconnected status.
Save Configuration
The below host interface related parameters will be impacted by clone function:
Data Transmission Parameter Serial Interface Control
Field Delimiter Handshaking Protocol
Data Transmission Format Intermessage Delay
Host Interface Control Interfunction Delay
Host interface Selection Intercharacter Delay
Keyboard Interface Control Baud Rate
Keyboard Layout Data Frame
Intermessage Delay Time Out Control
Interfunction Delay Wand Emulation Control
Intercharacter Delay Output Polarity
Caps Lock Control Initial Signal State
Caps Lock Release Control Margin Time
Function Key Emulation Module Time
Key Pad Emulation Narrow/Wide Ratio
Clone
Upper/Lower Case Code39 Emulation
6
Wireless FuzzyScan
Getting Started
Using FuzzyScan in HID Mode
Ensure the battery is fully charged. Power on the scanner within radio range and ensure the status indicator of scanner gives alternating red and green blinks (in “Uninstall” state). If the scanner is not in uninstall state, please scan the “Uninstall” command first. Then scan the “HID Mode” command, and the link indicator of scanner will give 3 blue blinks per 2 seconds.
Uninstall
Execute the Bluetooth Discovery procedure to find all available Bluetooth devices in your remote host. You will see ‘’CINO FxxxBT-xxxx’’ is shown in the list if the scanner is successfully discovered already.
Double click the “CINO FxxxBT-xxxx” in the discovered Bluetooth device list. If the PIN Code or Passkey is requested for security connection, please enter “00000000” (default setting). You will see “Keyboard on CINO FxxxBT-xxxx”, and double click this HID service to establish the connection between the scanner and the remote host device.
The scanner will give 4 beeps in ascending tone to indicate the radio is connected. At the same time, the link indicator of scanner will give 1 blue blink per 2.5 seconds to indicate the scanner is in radio-connected state.
Please note that if the scanner is not connected to the host device within 1 minute after scanning the “HID Mode” command, the scanner will go to sleep automatically. You just need to press the trigger to wake up the scanner to continue the installation.
1. The installation procedures vary on different remote host devices, operation systems and the Bluetooth software driver.
Please consult your professional IT consultant to obtain necessary support if any problem has been encountered during
the installation processes.
2. While using HID mode, beware of potential error in the data transmitted at the same time when radio link quality is poor.
You are suggested to use the scanner under the communication coverage all the times.
HID Mode
7
Wireless FuzzyScan
Getting Started
Using FuzzyScan in SPP Mode
Establish SPP Master Connection
Ensure the battery is fully charged. Please go to the folder of “Hardware” located in Bluetooth Advanced Setting of the remote host device to check its device MAC address. Then prepare a 12-character Code 128 barcode of the remote host device MAC address, or follow the step 4 to input MAC address by scanning 12 option codes.
Ensure a virtual COM port is available in your remote host for connecting the scanner. If not, please go to the folder of “Local Services” located in Bluetooth Advanced Setting. Click the “Add Serial Services” to add one more Bluetooth COM port.
Power on the scanner within radio range and ensure the status indicator of scanner gives alternating red and green blinks (in “Uninstall” state). If the scanner is not in uninstall state, please scan the “Uninstall” command first. Then scan the “SPP Master Mode” command, and the status indicator of scanner will turn steady red.
Uninstall
Scan a 12-character MAC address barcode, or scan 12 option codes and “FIN” command to confirm your inputs. The scanner will give continuous short clicks and the link indicator of the scanner will flash blue quickly during the radio connecting process. If the PIN Code or Passkey is requested for security connection, please enter “00000000” (default setting).
The scanner will give 4 beeps in ascending tone to indicate the radio is connected. At the same time, the link indicator of scanner will give 1 blue blink per 2.5 seconds to indicate the scanner is in radio-connected state.
Please note that if the scanner failed to connect to the host device within 30 seconds, the link indicator will give 3 blue blinks per 2 seconds. But the scanner is still continuing to discover the host device for another 30 seconds before go to sleep. In the interim, you still can scan “Uninstall” command to revert the scanner to uninstall state. If the scanner goes to sleep already, you just need to press the trigger to wake up the scanner to continue the installation.
The installation procedures vary on different remote host devices, operating systems and the Bluetooth software driver.
Please consult your professional IT consultant to obtain necessary support if any problem has been encountered during the
installation processes.
8
SPP Master Mode
Wireless FuzzyScan
Getting Started
Establish SPP Slave Connection
Ensure the battery is fully charged and a virtual COM port is available in your remote host for connecting the scanner. If not, please go to the folder of “Client Applications” located in Bluetooth Advanced Setting. Click the “Add COM Port” to add one more Bluetooth COM port.
Power on the scanner within radio range and ensure the status indicator of scanner gives alternating red and green blinks (in “Uninstall” state). If the scanner is not in uninstall state, please scan the “Uninstall” command first. Then scan the “SPP Slave Mode” command, and the link indicator of scanner will give 3 blue blinks per 2 seconds.
Uninstall
Execute the Bluetooth Discovery procedure to find all available Bluetooth device list in your remote host. You will see ‘’CINO FxxxBT-xxxx’’ is shown in the list if the scanner is successfully discovered already.
Double click the “CINO FxxxBT-xxxx” on the discovered Bluetooth devices. If the PIN Code or Passkey is requested for security connection, please enter “00000000” (default setting). You will see “Serial Port on CINO FxxxBT-xxxx”, and double click this SPP service to establish the connection between the scanner and the remote host device.
The scanner will give 4 beeps in ascending tone to indicate the radio is connected. At the same time, the link indicator of scanner will give 1 blue blink per 2.5 seconds to indicate the scanner is in radio-connected state.
Please note that if the scanner is not connected to the host device within 1 minute, the scanner will go to sleep. You can press the trigger to wake up the scanner to continue the installation.
The installation procedures vary on different remote host devices, operating systems and the Bluetooth software drivers.
Please consult your professional IT consultant to obtain necessary support if any problem has been encountered during the
installation processes.
SPP Slave Mode
9
Wireless FuzzyScan
Getting Started
Out-of-range Scanning
When the radio is connected between the scanner and the remote host device, the scanner will transmit each scanned data right after scanning the barcode. However, the scanner is preset for unable to scan any barcode data when it loses the radio connection with the remote host device.
If you enable the out-of-range scanning function, the scanner is able to continue scanning barcode data while it is out of working range. All scanned data will be temporarily stored into the memory buffer until radio link resumed.
Enable Out-of-range Scannning
In case of the scanner is out of working range, you will hear 4 beeps in descending tone to indicate the radio connection lost. The link indicator of scanner will give 3 blue blinks per 2 seconds. Once the scanner is back to working range, you will hear 4 beeps in ascending tone to indicate the radio connection rebuilt and the scanner will give 1 blue blink per 2.5 seconds. At the same time, all stored scanned data will be transmitted automatically right after the radio link is resumed.
Disable Out-of-range Scanning
◆◆◆◆
Presentation Scanning
The Presentation Scanning is designed for hand-free applications for user’s convenience. If the “Presentation Scanning Auto-sense” function is enabled, the scanner is capable of automatically switching to presentation mode when you place it onto the SmartStand or cradle.
Enable Presentation Scanning Auto-sense
Disable Presentation Scanning Auto-sense
◆◆◆◆
Paging Function
The paging function is helpful for you to locate the paired smart cradle or scanner. If you would like to page the paired smart cradle, you can scan “Paging” command. If you would like to page the paired scanner, you can press the paging/rest button of the smart cradle no longer than 3 seconds.
Paging
Paging/Reset Button
10
Wireless FuzzyScan
Getting Started
Batch Scanning (Inventory Mode)
Thanks to the specially designed Batch Scanning function, the scanner is capable of storing the barcode data up to 20,000 EAN-13 labels. It is an ideal cost-saving solution for inventory applications.
Once you scan the “Enter Batch Scanning” command to activate this function, all scanned barcode data will be stored into the memory storage, and the status indicator of scanner will give green blink at regular interval during batch scanning. You can scan and store the barcode data till the memory storage is full. If the storage is full, you will hear 2 long beeps and the status indicator will give 2 red blinks to indicate out of storage. To terminate the batch scanning, please scan the “Exit Batch Scanning” command.
Enter Batch Scanning
Exit Batching Scanning
How to Transmit Stored Data
The scanner is preset to scan the “Transmit Stored Data” command to transmit all stored data. During the transmission process, the scanner will give continuous short clicks and blue blinks. Then the scanner will give two short beeps after data transmission is completed.
Transmit Stored Data
But you are still able to set the scanner to transmit the stored data by placing the scanner onto the cradle as well.
Transmit Stored Data by Scanning
Barcode Command
◆◆◆◆
Transmit Stored Data by
Placing Scanner onto Cradle
The scanner is preset to keep all the stored data until you scan the “Clear All Stored Data” command. But you are still able to change the setting to “Auto Delete Stored Data after Transmission” as well.
Transmit Stored Data by Scanning Barcode
or Placing Scanner onto Cradle
Clear All Stored Data
11
Wireless FuzzyScan
Getting Started
Auto Delete Stored Data
after Transmission
Keep Stored Data after
Transmission
◆◆◆◆
If you scanned a wrong barcode, the “Delete Last Scanned Data’’ command is helpful to recover mistake. By scanning the ‘’Delete Last Scanned Data’’ command, the last stored data can be deleted.
Delete Last Scanned Data
Using Quantity Feature
If you want to input the quantity information of barcode data, you can enter the quantity from 1 to 9999 by scanning the quantity barcodes right after you scanned the barcode data. The quantity information will be stored into the memory storage together with the barcode data.
Quantity 0 Quantity 5
Quantity 3 Quantity 8
Quantity 1 Quantity 6
Quantity 4 Quantity 9
Quantity 2 Quantity 7
There are two ways to output the stored barcode data and quantity information. Please refer to following for details:
Stored data is transmitted as many times as the quantity indicated.
Stored data is transmitted together with quantity information in two fields. Please scan “Enable Quantity Field Transmission” command to enable this function. The preset delimiter is “
，，，，
“, but you are able to choose your desired one
from FuzzyScan Wireless Reference Manual for details.
Disable Quantity Field Transmission
◆◆◆◆
12
Enable Quantity Field Transmission
Wireless FuzzyS
can
Configure Your FuzzyScan
Bar Code Programming Menu
The FuzzyScan bar code commands are specially designed Proprietary bar code labels which allow you to set the FuzzyScan internal programming parameters. There are System Command, Family Code and Option Code for programming purpose.
Each programmable family and bar code command label is listed on the same page with major system commands. The detailed explanations and special programming flowchart are printed on facing or following pages. You can read the explanation and set the FuzzyScan concurrently.
A supplemental bar code command menu incorporates the bar code command labels of System Command and Option Code. As you set the FuzzyScan, open the bar code command menu to find the option code page. You may scan the desired family code and option code to set FuzzyScan. If you want to change the programming family for multiple settings, you need only turn over the programming page to find next desired programming family.
System Command
System Command
System CommandSystem Command
The System Command is the highest level bar code command which directs FuzzyScan to perform immediate operations, such as entering programming mode (PROGRAM), exiting programming mode (EXIT), listing system information (SYSLIST), recovering to factory preset configurations (M_DEFAULT), and so on. Please note that all system commands will take a few seconds to complete the operations. User must wait for the completion beeps before scanning another bar code.
Family Code
Family Code
Family CodeFamily Code
The Family Code is scanned to select the user desired programming family. FuzzyScan has already provided more than one hundred programming families to meet any specific requirements.
Option Code
Option Code
Option CodeOption Code
The Option Codes is a set of bar code commands represented by “0–9”, “A–F” and finishing selection (FIN). For most setting, you must select at least one option code following the family code selection to set the desired parameter for the selected programming family.
13
Wireless FuzzyS
can
Configure Your FuzzyScan
Programming Procedures
Programming Procedures
Programming ProceduresProgramming Procedures
As you scan the bar code command to select the desired parameters, information about the final selected parameters represented by the bar code commands are stored in the FuzzyScan’s internal Flash Memory ASIC or non-volatile memory. If you turn off the unit, the Flash Memory ASIC or non-volatile memory retains all programming options. You need not re-program the FuzzyScan if you want to keep the existing configurations in the next power on.
The programming procedures of FuzzyScan are designed as simple as possible for ease of setting. Most programming families take the Single Scan Selection programming procedure. But several programming families have more complex and flexible programmable options, and you must take Multiple Scans Selection, Cycling Scan Selection or Dual Level Selection to complete their programming procedures. Each kind of programming procedure is listed in the following pages for your reference. Please give careful attention to become familiar with each programming procedure.
If the programming family must take multiple scans selection, cycling scan selection, or dual level selection procedures, the family of the programming menu will be marked with the matched representing symbol of Programming Category (P.C.) in bold font listed in the following table. You can easily find the bold mark in the programming menu, and refer to their flowcharts for details. Before setting the FuzzyScan, please also refer to the “Beeping Indications” listed in Appendix to understand the details of programming beeping indications. It will be very helpful for you to know the existing status while you are programming the FuzzyScan.
Conventions of Programming Menu
Conventions of Programming Menu
Conventions of Programming MenuConventions of Programming Menu
Conventions Descriptions

P.C. Programming Category
( ) Necessary Option Code
[ ] Selectable Option Code
Factory Default Value
: Signle scan selection
SS
MS : Multiple scans selection CS : Cycling scan selection DS : Dual level scan selection
14
Wireless FuzzyS
can
Configure Your FuzzyScan
Program & End
Program & End
Program & EndProgram & End
parameters in Flash Memory ASIC or non-volatile memory,
FuzzyScan will enter programming mode,
and inhibit all non-programming functions.
FuzzyScan will exit programming mode, and store all
then issue the completion beeping.
Please note that the FuzzyScan will take 3-4 seconds to store parameters in internal Flash Memory ASIC or non-volatile memory after you scan the “END”. Please don’t turn off the power before the completion beeping. It may destroy all configured parameters.
Scan
“
PROGRAM”
Scan
“
”
END
System List, Group & Master Default
System List, Group & Master Default
System List, Group & Master DefaultSystem List, Group & Master Default
FuzzyScan will list the product information and
revision number to host via selected host interface,
then issue the completion beeping.
FuzzyScan will recover all programmable
parameters into factory preset configurations,
then issue the completion beeping.
Scan
“
SYSLIST”
Scan
“
M_DEFAULT
”
15
Wireless FuzzyS
can
Configure Your FuzzyScan
Single scan selection
Single scan selection
Single scan selectionSingle scan selection
One of
One of
Yes
Scan
“
PROGRAM
Scan
Family
Scan
Option
Repeat
Selection
Scan
“
END
”
Codes
Codes
No
”
Multiple scans selection
Multiple scans selection
Multiple scans selectionMultiple scans selection
Enter programming mode.
Select one of desired
programming families.
Select one option code of
desired parameter.
Want to select another
programming family?
Exit programming mode.
Yes
One of
Several
Scan
“
PROGRAM”
Scan
Family
Codes
Scan One or
Option
Codes
Repeat
Selection
No
Scan
“
”
END
Enter programming mode.
Select one of desired
programming families.
1. Select one or several
option codes to select
desired parameters.
2. If it’s necessary, scan
“FIN” to terminate
option code selection.
Want to select another
programming family?
Exit programming mode.
16
Wireless FuzzyS
can
Configure Your FuzzyScan
Cycling scan selection
Cycling scan selection
Cycling scan selectionCycling scan selection
Yes
One of
One of
Scan
“PROGRAM”
Scan
Family
Codes
Scan
Option
Scan “
Codes
FIN
”
Repeat
Selection
No
Scan
“
”
END
Enter programming mode.
Select one of desired
programming families.
Cycling select one or
several option codes of
desired parameters as
“Single” or “Multiple”
scans selection.
Finish cycling selection.
(If necessary)
Want to select another
programming family?
Exit programming mode.
Dual level selection
Dual level selection
Dual level selectionDual level selection
One of
Several
Several
Yes
Scan
“
PROGRAM”
Scan
Family
(
) Scan
1st
Option
(
) Scan One or
2nd
Option
Repeat
Selection
Scan
“
END”
Codes
No
Codes
Codes
Enter programming mode.
Select one of desired
programming families.
Select several option codes
of desired parameters.
1. Select one or several
option codes of desired
parameters.
2. If it’s necessary, scan
“FIN” to terminate
option code selection.
Want to select another
programming family?
Exit programming mode.
17
Wireless FuzzyS
can
Configure Your FuzzyScan
Host Interface Selection
PROGRAM
Family Code Selection P.C
Host Interface Selection
MS MS MS MS MS MS MS MS MS MS
Parameter Selection Option Code
IBM PS/2, 25-30 series keyboard wedge interface Standard/TTL RS-232 peer-to-peer serial Wand emulation USB Com Port Emulation PS/2 (DOS/V) direct link (keyboard replacement) PS/2 (DOS/V) keyboard wedge turbo mode PS/2 (DOS/V) keyboard wedge standard mode Laser emulation USB HID standard mode  USB HID turbo mode
F_DEFAULT
02 06 08 09 10 13 14 17 18 19
18
Wireless FuzzyS
can
Configure Your FuzzyScan
Symbology Reading Control
PROGRAM
Family Code Selection P.C
Symbol ID : 1 character
DS Code 128 (default=B)
♦♦♦♦ User Defined Symbol ID ♦♦♦♦
Parameter Selection Option Code 2nd Option Code
UCC/EAN-128 (default=C) UPC-A (default=A) EAN-13 (default=F) Codabar/NW-7 (default=D) Code 39/Code 32 (default=G) Code 93 (default=H) Standard/Industrial 2 of 5 (default=I) Interleaved 2 of 5 (default=J) Matrix 2 of 5 (default=K) China Postal Code (default=L) German Postal Code (default=M) IATA (default=O) Code 11 (default=P) MSI/Plessey (default=R) UK/Plessey (default=S) Telepen (default=T) GS1 DataBar (default=X) UPC-E (default=E) EAN-8 (default=N) Trioptic Code 39 (Default=W) UCC Coupon Extended Code (Default=Z) PDF417/Micro PDF417 (default=V) Codablock F (default=Y) Korea Post Code (default =a)
00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 26
F_DEFAULT
(1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character)
19
Loading...
+ 54 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
