Vishay High Power Products
Phase Control Thyristors
VS30ASR..N Series
PRODUCT SUMMARY
Junction size Ø 30 mm
class 400/600 V
V
RRM
Passivation process Diffused junction
FEATURES
• Converter type thyristor
• Anode metal - nickel plate molybdenum disc
• Rubber passivated junctions
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Maximum on-state voltage V
Maximum repetitive reverse voltage V
Maximum required DC gate current to trigger I
Maximum required DC gate voltage to trigger V
Maximum holding current I
Typical latching current I
TM
RRM
GT
GT
H
L
TJ = 25 °C, IT = 1000 A 1.25
TJ = 125 °C, I
T
= 25 °C, I
J
TJ = 25 °C
TJ = 25 °C, anode supply 12 V, resistive load
RRM
RRM
= 50 mA
= 10 mA
400/600
200 mA
3.0 V
600
1000
V
mA
MECHANICAL DATA
Nominal back metal composition (thickness) Al (130 kÅ)
Nominal front metal composition Nickel plate molybdenum disc
Chip dimensions Ø 30 mm (see dimensions - link at the end of datasheet)
Recommended storage environment Storage in original container, in desiccated nitrogen, with no contamination
ORDERING INFORMATION TABLE
Device code
Dimensions http://www.vishay.com/doc?95160
Document Number: 93897 For technical questions, contact: ind-modules@vishay.com
Revision: 22-Apr-08 1
VS 30 A S R 06 N
51324
67
1 - Vishay HPP device
2 - Chip dimension in millimeters
- Device identifier between chip with same diameter
3
- Type of device: S = Converter type thyristor
4
- Passivation: R = Rubber for all junctions
5
- Voltage code x 100 = V
6
7
- Metallization: N = Nickel plate molybdenum disc (anode)
Al (cathode)
LINKS TO RELATED DOCUMENTS
RRM
Available class
04 = 400 V
06 = 600 V
