Dimension Inches Millimeters

A 2.76 70
B 2.244±0.010 57±0.25
C 1.57 40
D 1.10 28
E 0.94 24
F 0.87 22
G 0.79 20
H 0.59 15
J 0.57 14.5
K 0.53 13.5

L 0.39 10
M 0.31 8
N 0.20 5

P 0.18 Dia. Dia. 4.5
Q Metric M4 M4

Description:

Pow ere x Three-Phase Diode
Bridge Modules are designed for
use in applications requiring rectifi­cation of three-phase AC lines into
DC voltage. Each module consists
of six diodes and the interconnect
required to form a complete three­phase bridge circuit. Each diode is
electrically insulated from the
mounting baseplate for easy
mounting onto a common heatsink
with other components.

Features:

M Isolated Mounting
M Metal Baseplate
M Low Thermal Impedance

Applications:

M AC and DC Motor Control
M Inverters
M UPS

Ordering Information:

Select the complete eight digit
module part number you desire
from the table below.
Example: MEB00806 is an
800 Volt, 60 Ampere Three-Phase
Diode Bridge Module.

Voltage Current Rating

Type Volts (x100) Amperes (x10)

MEB0 08 06

D-71

Powerex,Inc., 200 Hillis Street,Youngwood,Pennsylvania 15697-1800 [phone]

Three-Phase
Diode Bridge Module

60 Amperes/800 Volts

MEB00806

Outline Drawing

MEB00806
Three-Phase Diode Bridge Module

60 Amperes/800 Volts

A

D

J

L

P - DIA.
(2 TYP.)

Q - M4 THD.
(5 TYP.)

K

M

H

H

B

N

G

C

E

F

D-72

Powerex,Inc., 200 Hillis Street,Youngwood,Pennsylvania 15697-1800 [phone]

MEB00806
Three-Phase Diode Bridge Module

60 Amperes/800 Volts

Absolute Maximum Ratings

Characteristics Symbol MEB00806 Units

Peak Reverse Blocking Voltage V

RRM

800 Volts

Transient Peak Reverse Blocking Voltage (Non-Repetitive), t < 5ms V

RSM

960 Volts

DC Current, Tj= 1050°C I

FM

60 Amperes

Peak Half-Cycle Surge (Non-Repetitive) On-State Current (60Hz) I

FSM

1000 Amperes

Junction Temperature T

j

-40 to 150 °C

Storage Temperature T

STG

-40 to 125 °C
Maximum Mounting Torque M4 Mounting Screw — 12 in.-lb.
Maximum Mounting Torque M4 Terminal Screw — 12 in.-lb.
Module Weight (Typical) — 100 Grams
V Isolation V

RMS

2000 Volts

D-73

Powerex,Inc., 200 Hillis Street,Youngwood,Pennsylvania 15697-1800 [phone]

MEB00806
Three-Phase Diode Bridge Module

60 Amperes/800 Volts

Electrical and Thermal Characteristics, Tj= 25°C unless otherwise specified

Characteristics Symbol Test Conditions MEB00806 Units

Blocking State Maximums

Reverse Leakage Current, Peak I

RRM

Tj= 150°C, VD= 800V 10 mA

Conducting State Maximums

Peak On-State Voltage V

FM

IFM= 100A 1.3 Volts

Thermal Maximums

Thermal Resistance, Junction-to-Case R

Thermal Resistance, Case-to-Sink (Lubricated) R

u(J-C)

u(C-S)

Per Module 0.31 °C/Watt
Per Module 0.09 °C/Watt

D-74

Powerex,Inc., 200 Hillis Street,Youngwood,Pennsylvania 15697-1800 [phone]

MEB00806
Three-Phase Diode Bridge Module

60 Amperes/800 Volts

INSTANTANEOUS ON-STATE CURRENT, I

TM

, (AMPERES)

MAXIMUM

ON-STATE CHARACTERISTICS

INSTANTANEOUS ON-STATE VOLTAGE, VTM, (VOLTS)

0.6 1.0 1.4 1.8 2.2 2.6

10

0

10

1

10

2

10

3

Tj = 25oC

CYCLES AT 60 HZ

MAXIMUM PEAK SURGE (NON-REPETITIVE)

CURRENT, I

FSM

, (AMPERES)

MAXIMUM ALLOWABLE PEAK SURGE

(NON-REPETITIVE) CURRENT

0

200

400

600

800

1000

10

0

10

1

10

2

MAXIMUM

ALLOWABLE CASE TEMPERATURE

DC OUTPUT CURRENT, IO, (AMPERES)

MAXIMUM ALLOWABLE CASE TEMPERATURE, T

C

, (

o

C)

010 5020 30 40 60 70 80

70

80

90

100

110

120

130

140

150

MAXIMUM

ON-STATE POWER DISSIPATION

DC OUTPUT CURRENT, IO, (AMPERES)

MAXIMUM POWER DISSIPATION, P

AV(MAX)

, (WATTS)

010 5020 30 40 60 70 80

0

20

40

60

80

100

120

140

160
