G1

K1

G2

K2

D

N

E

K

G

C

H

M

BB

E FF

A

J

A1K2

K1

A1K2

A2

G1

K1

G2

K2

K1 A2

A1K2

.110 TAB

A1K2

(4 TYP.)

P - M8 THD

(2 TYP.)

L - DIA.

(4 TYP.)

Dimension Inches Millimeters

A 5.906 150
B 2.697±0.02 68.5±0.2
C 1.575 40
D 1.535 39
E 1.260 32
F 1.181 30

G 0.906 23

H 0.787 20
J 0.630 16
K 0.276 7
L 0.256±0.008 Dia. Dia. 6.5±0.2

M 0.236 6

N 0.197 5
P M8 Metric M8

*AIK2-AIK2 Connection made by external shorting bar.

Description:

Powerex Dual SCR
POW-R-BLOK™ Modules are
designed for use in applications
requiring phase control and
isolated packaging.The modules
are isolated for easy mounting
with other components on
common heatsinks.

Features:

M Isolated Mounting
M Glass Passivated Chips
M Metal Baseplate
M Low Thermal Impedance

Applications:

M Battery Supplies
M Bridge Circuits
M AC and DC Motor Control
M Tap Changers
M Lighting Control

Ordering Information:

Select the complete eight digit
module part number you desire
from the table below.
Example: CM530820 is a
800 Volt, 200 Ampere Dual SCR
POW-R-BLOK™ Module.

Voltage Current Rating

Type Volts (x100) Amperes (x10)

CM53 08 20

S-41

Powerex,Inc., 200 Hillis Street,Youngwood,Pennsylvania 15697-1800 [phone]

Dual SCR
POW-R-BLOK™ Modules

200 Amperes/800 Volts

CM530820

Outline Drawing

CM530820
Dual SCR POW-R-BLOK™ Modules

200 Amperes/800 Volts

S-42

Powerex,Inc., 200 Hillis Street,Youngwood,Pennsylvania 15697-1800 [phone]

CM530820
Dual SCR POW-R-BLOK™ Modules

200 Amperes/800 Volts

Absolute Maximum Ratings

Characteristics Symbol CM530820 Units

Peak Forward Blocking Voltage V

DRM

800 Volts

Transient Peak Forward Blocking Voltage (Non-Repetitive), t < 5ms V

DSM

960 Volts

DC Forward Blocking Voltage V

D(DC)

640 Volts

Peak Reverse Blocking Voltage V

RRM

800 Volts

Transient Peak Reverse Blocking Voltage (Non-Repetitive), t < 5ms V

RSM

960 Volts

DC Reverse Blocking Voltage V

R(DC)

640 Volts

RMS On-State Current I

T(RMS)

310 Amperes

Average On-State Current, TC= 65°C I

T(AV)

200 Amperes

Peak One-Cycle Surge (Non-Repetitive) On-State Current (60Hz) I

TSM

4000 Amperes

Peak One-Cycle Surge (Non-Repetitive) On-State Current (50Hz) I

TSM

3600 Amperes
I2t (for Fusing), 8.3 milliseconds I2t 67000 A2sec
Critical Rate-of-Rise of On-State Current* di/dt 100 Amperes/ms
Peak Gate Power Dissipation P

GM

10 Watts

Average Gate Power Dissipation P

G(AV)

3.0 Watts

Peak Forward Gate Voltage V

GFM

10 Volts

Peak Reverse Gate Voltage V

GRM

5.0 Volts

Peak Forward Gate Current I

GFM

4.0 Amperes

Storage Temperature T

STG

-40 to 125 °C

Operating Temperature T

j

-40 to 125 °C
Maximum Mounting Torque M6 Mounting Screw — 26 in.-lb.
Maximum Mounting Torque M8 Terminal Screw — 72 in.-lb.
Module Weight (Typical) — 300 Grams
V Isolation V

RMS

2000 Volts

*Tj= 125°C, IG= 1.0A, VD= 1/2 V

DRM

S-43

Powerex,Inc., 200 Hillis Street,Youngwood, Pennsylvania 15697-1800 [phone]

CM530820
Dual SCR POW-R-BLOK™ Modules

200 Amperes/800 Volts

Electrical and Thermal Characteristics, Tj= 25°C unless otherwise specified

Characteristics Symbol Test Conditions CM530820 Units

Blocking State Maximums

Forward Leakage Current, Peak I

DRM

Tj= 125°C, V

DRM

= Rated 30 mA

Reverse Leakage Current, Peak I

RRM

Tj= 125°C, V

RRM

= Rated 30 mA

Conducting State Maximums

Peak On-State Voltage V

TM

ITM=600A 1.3 Volts

Switching Minimums

Critical Rate-of-Rise of Off-State Voltage dv/dt Tj= 125°C, VD= 2/3 V

DRM

500 Volts/ms

Thermal Maximums

Thermal Resistance, Junction-to-Case R

u(J-C)

Per Module 0.2 °C/Watt

Thermal Resistance, Case-to-Sink (Lubricated) R

u(C-S)

Per Module 0.05 °C/Watt

Gate Parameters Maximums

Gate Current-to-Trigger I

GT

VD= 6V, RL= 2Ω 100 mA

Gate Voltage-to-Trigger V

GT

VD= 6V, RL= 2Ω 3.0 Volts

Non-Trigger ing Gate Voltage V

GDM

Tj= 125°C, VD= 1/2 V

DRM

0.25 Volts

S-44

Powerex,Inc., 200 Hillis Street,Youngwood, Pennsylvania 15697-1800 [phone]

CM530820
Dual SCR POW-R-BLOK™ Modules

200 Amperes/800 Volts

INSTANTANEOUS ON-STATE CURRENT, ITM,

(AMPERES)

MAXIMUM

ON-STATE CHARACTERISTICS

0.5
10

1

2.5

10

2

10

3

10

4

Tj = 125oC

INSTANTANEOUS ON-STATE VOLTAGE, V

TM

, (VOLTS)

2.0

1.5

1.0

CYCLES AT 60 HZ

MAXIMUM PEAK SURGE (NON-REPETITIVE)

CURRENT, I

TSM

, (AMPERES)

MAXIMUM ALLOWABLE PEAK SURGE

(NON-REPETITIVE) CURRENT

0

10

1

10

2

10

0

4000

3000

2000

1000

MAXIMUM ALLOWABLE CASE TEMPERATURE

(SINUSOIDAL WAVEFORM)

AVERAGE ON-STATE CURRENT, I

T(AV)

,

(AMPERES)

MAXIMUM ALLOWABLE CASE TEMPERATURE, T

C

, (

o

C)

0

360

o

u

RESISTIVE, INDUCTIVE

LOAD PER SINGLE

ELEMENT

200

50

120

o

u = 30o60o90

o

180

o

60

70

80

90

100

110

120

130

50 100 150

MAXIMUM ON-STATE POWER DISSIPATION

(SINUSOIDAL WAVEFORM)

AVERAGE ON-STATE CURRENT, I

T(AV)

,

(AMPERES)

MAXIMUM POWER DISSIPATION, P

AV(MAX)

, (WATTS)

0

0

400

360

o

u

RESISTIVE, INDUCTIVE LOAD
PER SINGLE ELEMENT

200

100

200

300

u = 30

o

120

o

180

o

60

o

90

o

50 100 150

60

o

50

MAXIMUM ALLOWABLE CASE TEMPERATURE

(RECTANGULAR WAVEFORM)

AVERAGE ON-STATE CURRENT, I

T(AV)

,

(AMPERES)

MAXIMUM ALLOWABLE CASE TEMPERATURE, T

C

, (

o

C)

0

60

70

80

90

100

110

120

130

360

o

u

RESISTIVE,
INDUCTIVE
LOAD PER
SINGLE
ELEMENT

100 200 300 400

120

o

u = 30o90

o

180

o

270

o

MAXIMUM AVERAGE ON-STATE POWER

DISSIPATION (RECTANGULAR WAVEFORM)

AVERAGE ON-STATE CURRENT, I

T(AV)

,

(AMPERES)

MAXIMUM POWER DISSIPATION, P

AV(MAX)

, (WATTS)

0

360

o

u

RESISTIVE, INDUCTIVE LOAD
PER SINGLE ELEMENT

0

400

300

200

100

100 200 300 400

120

o

180

o

270

o

u = 30

o

60

o

90

o

TIME, t, (SECONDS)

TRANSIENT THERMAL IMPEDANCE

CHARACTERISTICS (JUNCTION-TO-CASE)

0

10

-3

0.25

10

-2

10

-1

10

0

TRANSIENT THERMAL IMPEDANCE, Z

u(J-C)

(t), (

o

C/WATT)

10

0

10

1

0.20

0.15

0.10

0.05

INSTANTANEOUS GATE CURRENT, IG, (mA)

TRIGGERING

CHARACTERISTICS

10

1

10

2

10

3

10

4

INSTANTANEOUS GATE VOLTAGE, V

G

, (VOLTS)

10

-1

10

0

10

1

10

2

VGT = 3.0V

I

GFM

=

4.0A

PGM = 10W

V

GDM

= 0.25V

V

GFM

= 10V

IGT = 100mA

Tj = 25oC

P

G(AV)

=

3.0W
