CM30TF-24H

Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 [phone]

A
B
C

BuPEuPBvPEvPBwPEwP

P

EJ

N

N

S - DIA.
(2 TYP.)

G

P

P

(BuP)*

GuP

EuP

u

(BuN)

GuN

EuN

N

* Parentheses indicate module marking

Outline Drawing and Circuit Diagram

Dimensions Inches Millimeters

A 5.0 127.0
B 4.33±0.01 110.0±0.3
C 3.86 98.0
D 2.20 56.0
E 1.57 40.0
F 1.12 28.5
G 1.04 26.5
H 1.01 25.6

J 0.98 25.0

uvw

B

uNEu

R

(BvP)

GvP

(BvN)

GvN

NBvNEvNBwNEwN

F F KM

R

L

.250 TAB

EvP

v

EvN

Dimensions Inches Millimeters

R

L

(BwP)

(BwN)

K 0.85 21.5
L 0.83 21.0
M 0.75 19.0
N 0.71 18.0
P 0.69 17.5
Q 0.65 16.5
R 0.3 7.5
S 0.22 Dia. Dia. 5.5

Q

.110 TAB

R

GwP

EwP

w

GwN

EwN

D

H

Six-IGBT IGBTMOD™
H-Series Module

30 Amperes/ 1200 Volts

Description:

Powerex IGBTMOD™ Modules
are designed for use in switching
applications. Each module consists
of six IGBT Transistors in a three
phase bridge configuration, with
each transistor having a reverse­connected super-fast recovery
free-wheel diode. All components
and interconnects are isolated
from the heat sinking baseplate,
offering simplified system assem­bly and thermal management.

Features:

□ Low Drive Power
□ Low V
□ Discrete Super-Fast Recovery

□ High Frequency Operation
□ Isolated Baseplate for Easy

Applications:

□ AC Motor Control
□ Motion/Servo Control
□ UPS
□ Welding Power Supplies
□ Laser Power Supplies

Ordering Information:

Example: Select the complete part
module number you desire from
the table below -i.e. CM30TF-24H
is a 1200V (V
Six-IGBT IGBTMOD™ Power
Module.

Type Current Rating V

CM 30 24

CE(sat)

(135ns) Free-Wheel Diode
(20-25kHz)
Heat Sinking

), 30 Ampere

CES

Amperes (30) Volts (x 50)

CES

331
