Voltage Current Rating

Type Volts (x100) Amperes (x30)

CD41 08 30

D-95

CD410830

Powerex,Inc., 200 Hillis Street,Youngwood,Pennsylvania 15697-1800 [phone]

A
B

123

D

H

K - DIA.

(2 TYP.)

C

G

J

1

E

2

L - M5 THD

E

(3 TYP.)

F

A

CD410830

3

Dual Diode
POW-R-BLOK™ Modules

30 Amperes/800 Volts

Dual Diode
POW-R-BLOK™ Modules

30 Amperes/800 Volts

Description:

Powerex Dual Diode
POW-R-BLOK™ Modules are
designed for use in applications
requiring AC to DC rectification in
isolated packaging.The modules
are isolated for easy mounting
with other components on com­mon heatsinks. POW-R-BLOK™
has been tested and recognized
by Underwriters Laboratories
(QQQX2 Power Switching
Semiconductors).

Features:

M Isolated Mounting

Outline Drawing

Dimension Inches Millimeters

A 3.681 Max. 93.5 Max.
B 3.150 80
C 1.181 Max. 30 Max.
D 1.024 Max. 26 Max.
E 0.787 20
F 0.827 21
G 0.689 17.5
H 0.492 12.5
J 0.256 6.5
K 0.256 Dia. Dia. 6.5
L M5 Metr ic M5

M Glass Passivated Chips
M Metal Baseplate
M Low Thermal Impedance
M UL Recognized A

Applications:

M Battery Supplies
M AC and DC Motor Power

Supplies

Ordering Information:

Select the complete eight digit
module part number you desire
from the table below.
Example: CD410830 is an
800 Volt, 30 Ampere Dual Diode
POW-R-BLOK™ Module.

D-96

Powerex,Inc., 200 Hillis Street,Youngwood,Pennsylvania 15697-1800 [phone]

CD410830
Dual Diode POW-R-BLOK™ Modules

30 Amperes/800 Volts

Absolute Maximum Ratings

Characteristics Symbol CD410830 Units

Peak Reverse Blocking Voltage V

RRM

800 Volts

Transient Peak Reverse Blocking Voltage (Non-Repetitive), t < 5ms V

RSM

960 Volts

DC Reverse Blocking Voltage V

R(DC)

640 Volts

RMS On-State Current I

F(RMS)

47 Amperes

Average On-State Current, TC= 92°C I

F(AV)

30 Amperes

Peak One-Cycle Surge (Non-Repetitive) On-State Current (60Hz) I

FSM

600 Amperes

Peak One-Cycle Surge (Non-Repetitive) On-State Current (50Hz) I

FSM

545 Amperes
I2t (for Fusing), 8.3 milliseconds I2t 1500 A2sec
Storage Temperature T

STG

-40 to 125 °C

Operating Temperature T

j

-40 to 125 °C
Maximum Mounting Torque M6 Mounting Screw — 26 in.-lb.
Maximum Mounting Torque M5 Terminal Screw — 17 in.-lb.
Module Weight (Typical) — 160 Grams
V Isolation V

RMS

2000 Volts

D-97

Powerex,Inc., 200 Hillis Street,Youngwood,Pennsylvania 15697-1800 [phone]

CD410830
Dual Diode POW-R-BLOK™ Modules

30 Amperes/800 Volts

Electrical and Thermal Characteristics, Tj= 25°C unless otherwise specified

Characteristics Symbol Test Conditions CD410830 Units

Blocking State Maximums

Reverse Leakage Current, Peak I

RRM

Tj= 150°C, V

RRM

= Rated 4.0 mA

Conducting State Maximums

Peak On-State Voltage V

FM

IFM= 90A 1.4 Volts

Thermal Maximums

Thermal Resistance, Junction-to-Case R

u(J-C)

Per Module 0.8 °C/Watt

Thermal Resistance, Case-to-Sink (Lubricated) R

u(C-S)

Per Module 0.2 °C/Watt

D-98

Powerex,Inc., 200 Hillis Street,Youngwood,Pennsylvania 15697-1800 [phone]

CD410830
Dual Diode POW-R-BLOK™ Modules

30 Amperes/800 Volts

INSTANTANEOUS ON-STATE CURRENT, IFM,

(AMPERES)

MAXIMUM

ON-STATE CHARACTERISTICS

10

0

10

1

10

2

10

3

Tj = 25oC

INSTANTANEOUS ON-STATE VOLTAGE, V

FM

, (VOLTS)

0

0.8

1.6

2.4

3.2

4.0

CYCLES AT 60 HZ

MAXIMUM PEAK SURGE (NON-REPETITIVE)

CURRENT, I

FSM

, (AMPERES)

MAXIMUM ALLOWABLE PEAK SURGE

(NON-REPETITIVE) CURRENT

0

200

400

600

800

1000

10

0

10

1

10

2

MAXIMUM

ALLOWABLE CASE TEMPERATURE

AVERAGE ON-STATE CURRENT, I

F(AV)

,

(AMPERES)

MAXIMUM ALLOWABLE CASE TEMPERATURE, T

C

, (

o

C)

03020 50

40

60

80

100

120

140

10 40

RESISTIVE
INDUCTIVE
LOAD

DC
SINGLE-PHASE
THREE-PHASE

OPERATION

MAXIMUM

ON-STATE POWER DISSIPATION

AVERAGE ON-STATE CURRENT, I

F(AV)

,

(AMPERES)

03020 50

0

20

40

60

80

100

10 40

MAXIMUM POWER DISSIPATION, P

AV(MAX)

, (WATTS)

RESISTIVE
INDUCTIVE
LOAD

DC
SINGLE-PHASE
THREE-PHASE

OPERATION

TIME, t, (SECONDS)

TRANSIENT THERMAL IMPEDANCE

CHARACTERISTICS (JUNCTION-TO-CASE)

0

0.2

0.4

0.6

0.8

1.0

TRANSIENT THERMAL IMPEDANCE, Z

u(J-C)

(t), (

o

C/WATT)

10

0

10

1

10

-3

10

-2

10

-1

10

0
