C702

r

Phase Control Thyristo

Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 [phone] 1000 Amperes 3200 Volts

The C702 is a medium voltage, high
current disc pack SCR employing a Bar
gate, amplifying gate structure. This
amplifying gate design allows the SCR to
be reliably operated at high di/dt and
high dv/dt conditions in phase control
applications.

FEATURES:

Low On-State Voltage
High di/dt Capability
High dv/dt Capability
Hermetic Ceramic Package

Excellent Surge and I

APPLICATIONS:

DC Power Supplies

ORDERING INFORMATION Motor Controls

AC Soft-Starters
Select the complete Part Number using the table below.
EXAMPLE: C702CB is a 3200V-1000A SCR with 200ma
IGT and 12 inch gate and cathode potential leads.

Voltage

PART

C702 2400V LD 1000A

Rating

V

DRM-VRRM

2600V LM
2800V LN
3000V CP

3200V CB

Voltage

Code

Current

Rating

I

tavg

2

t Ratings

Revised: 5/11/2004

Page 1
