TO-247AC modified
PRODUCT SUMMARY
I
F(AV)
V
R
V
at 30 A at 125 °C 0.64 V
F
Vishay High Power Products
High Performance
Schottky Generation 5.0, 30 A
FEATURES
Base
cathode
2
13
Cathode
Anode
30 A
100 V
• 175 °C high performance Schottky diode
• Very low forward voltage drop
• Extremely low reverse leakage
• Optimized V
vs. IR trade off for high efficiency
F
• Increased ruggedness for reverse avalanche capability
• RBSOA available
• Negligible switching losses
• Submicron trench technology
• Full lead (Pb)-free and RoHS compliant devices
• Designed and qualified for industrial level
APPLICATIONS
• High efficiency SMPS
• Automotive
• High frequency switching
• Output rectification
• Reverse battery protection
• Freewheeling
• Dc-to-dc systems
• Increased power density systems
30PT100
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL CHARACTERISTICS VALUES UNITS
V
V
T
RRM
F
J
30 Apk, TJ = 125 °C (typical) 0.61
Range - 55 to 175 °C
100
V
VOLTAGE RATINGS
PARAMETER SYMBOL TEST CONDITIONS 30PT100 UNITS
Maximum DC reverse voltage V
TJ = 25 °C 100 V
R
ABSOLUTE MAXIMUM RATINGS
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Maximum average forward current I
Maximum peak one cycle
non-repetitive surge current
Non-repetitive avalanche energy E
Repetitive avalanche current I
F(AV)
I
FSM
AR
50 % duty cycle at TC = 156 °C, rectangular waveform 30
5 µs sine or 3 µs rect. pulse
10 ms sine or 6 ms rect. pulse 450
TJ = 25 °C, IAS = 3 A, L = 30 mH 135 mJ
AS
Limited by frequency of operation and time pulse duration so
< TJ max. IAS at TJ max. as a function of time pulse
that T
J
See fig. 8
Following any rated load
condition and with rated
V
applied
RRM
2200
I
T
J
at
AS
max.
A
A
Document Number: 94532 For technical questions, contact: diodes-tech@vishay.com
Revision: 24-Jul-08 1
www.vishay.com
30PT100
Vishay High Power Products
High Performance
Schottky Generation 5.0, 30 A
ELECTRICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS TYP. MAX. UNITS
30 A
Forward voltage drop V
FM
(1)
30 A
60 A - 0.9
60 A - 0.76
Reverse leakage current I
Junction capacitance C
Series inductance L
RM
T
= 125 °C TBD 15 mA
J
VR = 5 VDC (test signal range 100 kHz to 1 MHz) 25 °C 1650 - pF
T
Measured lead to lead 5 mm from package body 7.5 - nH
S
TJ = 25 °C
(1)
Maximum voltage rate of change dV/dt Rated V
R
T
= 25 °C
J
= 125 °C
T
J
V
= Rated VR
R
Note
(1)
Pulse width < 300 µs, duty cycle < 2 %
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Maximum junction and
storage temperature range
Maximum thermal resistance,
junction to case
Typical thermal resistance,
case to heatsink
Approximate weight
Mounting torque
minimum 6 (5)
maximum 12 (10)
Marking device Case style TO-247AC modified (JEDEC) 30PT100
, T
T
J
Stg
R
DC operation 0.8
thJC
R
thCS
Mounting surface, smooth and greased 0.25
-0.77
-0.64
- 200 µA
- 10 000 V/µs
- 55 to 175 °C
°C/W
6g
0.21 oz.
kgf · cm
(lbf · in)
V
www.vishay.com For technical questions, contact: diodes-tech@vishay.com
Document Number: 94532
2 Revision: 24-Jul-08
