Page 1
JF005….. A/V MULTI-FUNCTIONAL STAND
Page 2
JF005SC….. A/V MULTI-FUNCTIONAL STAND
Page 3
JF005BC….. A/V MULTI-FUNCTIONAL STAND
Page 4
JF005BB….. A/V MULTI-FUNCTIONAL STAND
Page 5
IMPORTANT CUSTOMER
INFORMATION
BEFORE ASSEMBLING THIS UNIT
PLEASE READ THESE INSTRUCTIONS CAREFULLY AND
ENSURE THAT ALL ITEMS IN THE CONTENTS LIST HAVE
BEEN INCLUDED IN THIS PACK.
DO NOT ATTEMPT TO ASSEMBLE THIS UNIT WITH
SCREWS OR FITTINGS OTHER THAN THOSE PROVIDED.
DO NOT EXCEED MAX. SAFE
LOADING OF THE GLASS SHELVES
10mm TOP-85kg
6mm SHELVES-25kg
DO NOT STRIKE THE GLASS WITH HARD OR POINTED
ITEMS.
DO NOT SIT OR STAND UPON THE GLASS SURFACES.
SHOULD YOU HAVE ANY MISSING / DAMAGED PARTS
OR HAVE ANY DIFFICULTY IN ASSEMBLY, PLEASE CALL
THE NUMBER BELOW.
HELP LINE NUMBER: 01443 816982
ASSEMBLY INSTRUCTIONS JF005
Please view our full range of products at:- www.jualfurnishings.co.uk
COMPONENTS
LIST
Cam
Bolt
25mm
Bolt
x2
x2
6
7
50mm
Bolt
146mm
Tube
Shroud
Screws
x8
x6
x10
8
10
9
Top Glass
(4 x silver discs)
Middle Glass
(2 x holes)
x1
x3
2
1
Bottom Glass
(4 x holes)
x1
3
Shroud
Large MDF Panel
Small MDF Panel
x1
x1
4
5
Non-slip
Pad
x2
13
Alen
Key
Cam
Locks
Glass
Clamp
Glass Clamp
Fixing Screw
x1
x2
x3
14
16
15
Foot
Bolt
x2
17
Cable
tie
x3
x3
18
19
132mm
Foot
x2
12
248mm
Tube
x2
11
Plastic
Spacer
x16
20
Page 6
1
25mm
Bolt
x2
7
146mm
Tube
x2
10
2
Top Glass
146mm
Tube
x2
10
Plastic
Spacer
Plastic
Spacer
x4 x4
20 20
50mm
Bolt
50mm
Bolt
x2 x2
8 8
4
Middle Glass
5
6 7 8
Middle Glass
Cam
Locks
x2
16
REAR
FRONT
Large
MDF Panel
5
x1
Glass
Clamp
x3
15
3
Plastic
Spacer
x2
20
50mm
Bolt
x2
8
Cam
Bolt
x2
6
x1
5
Large
MDF Panel
Ensure arrow on cam locks
are facing down when
tightening cam bolt.
Bottom Glass
Plastic
Spacer
x4
20
50mm
Bolt
x2
8
248mm
Tube
11
Foot
Bolt
x2
17
5
Small
MDF Panel
x1
x2
132mm
Foot
x2
12
Plastic
Spacer
Non-slip
Pad
x2
x2
20
13
10
146mm
Tube
x2
Cable
Ties
x3
13
Fix cables using cable ties.
9
Shroud
Shroud
Screws
x1
x10
4
9
Fix the cable cover after all
the wires are connected.
10
248mm Tubes
