Radio 3.0/Uconnect® 3.0
Owner’s Manual Supplement
SECTION PAGE
SAFETY GUIDELINES .........................................................3
1
INTRODUCTION .............................................................9
2
RADIO MODE ...............................................................23
3
MEDIA MODE ..............................................................29
4
UCONNECT PHONE ..........................................................35
5
UCONNECT 3.0 VOICE RECOGNITION QUICK TIPS ................................43
6
TABLE OF CONTENTS
1
2
3
4
5
6
SAFETY GUIDELINES
CONTENTS
䡵 SAFETY GUIDELINES .....................4
䡵 CYBERSECURITY ........................7
1
4 SAFETY GUIDELINES
SAFETY GUIDELINES
WARNING!
ALWAYS drive safely with your hands on the
steering wheel. You have full responsibility and
assume all risks related to the use of the Uconnect
features and applications in this vehicle. Only use
Uconnect when it is safe to do so. Failure to do so
may result in an accident involving serious injury
or death.
All persons should read this manual carefully before
using the radio system. It contains instructions on how to
use the system in a safe and effective manner.
Please read and follow these safety precautions. Failure
to do so may result in injury or property damage.
• Glance at the screen only when safe to do so. If
prolonged viewing of the screen is necessary, park in a
safe location and set the parking brake.
• Stop use immediately if a problem occurs. Failure to
do so may cause injury or damage to the product.
Return it to your authorized dealer to repair.
• Make certain that the volume level of the system is set
to a level that still allows you to hear outside traffic
and emergency vehicles.
Safe Usage Of The Uconnect System
• Read all instructions in this manual carefully before
using your system to ensure proper usage!
• Your system is a sophisticated electronic device. Do
not let young children use your system.
• Permanent hearing loss may occur if you play your
music or the system at loud volumes. Exercise caution
when setting the volume on your system.
SAFETY GUIDELINES 5
isopropyl alcohol and water solution ratio of 50:50. Be
sure to follow the solvent manufacturer’s precautions
and directions.
1
• Keep drinks, rain, and other sources of moisture away
from your system. Besides damage to your system,
moisture can cause electric shocks as with any electronic device.
Touchscreen
• Do not touch the screen with any hard or sharp objects
(pen, USB stick, jewelry, etc.) which could scratch the
touchscreen surface!
• Do not spray any liquid or caustic chemicals directly
on the screen! Use a clean and dry micro fiber lens
cleaning cloth in order to clean the touchscreen.
• If necessary, use a lint-free cloth dampened with a
cleaning solution, such as isopropyl alcohol or an
Disc Player
• Do not insert any damaged, warped, scratched or dirty
discs into the disc player.
• Discs that have been modified with an adhesive label
should not be used in the disc player.
• Do not insert more than one disc at a time into the
player slot.
FCC Declaration
This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
6 SAFETY GUIDELINES
this device must accept any interference received, including interference that may cause undesired operation.
• Increase the separation between the equipment and
receiver.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
• Consult the dealer or an experienced radio technician
for help.
Safety Information
Exposure to Radio Frequency Radiation:
The radiated output power of the this internal wireless
radio is far below the FCC radio frequency exposure
limits. Nevertheless, the wireless radio shall be used in
such a manner that the radio is 20 cm (200 mm) or further
from the human body.
The internal wireless radio operates within guidelines
found in radio frequency safety standards and recommendations, which reflect the consensus of the scientific
community.
The radio manufacturer believes the internal wireless
radio is safe for use by consumers. The level of energy
emitted is far less than the electromagnetic energy emitted by wireless devices such as mobile phones. However,
the use of wireless radios may be restricted in some
situations or environments, such as aboard airplanes. If
you are unsure of restrictions, you are encouraged to ask
for authorization before turning on the wireless radio.
CYBERSECURITY
Your vehicle may be a connected vehicle and may be
equipped with both wired and wireless networks. These
networks allow your vehicle to send and receive information. This information allows systems and features in
your vehicle to function properly.
SAFETY GUIDELINES 7
Your vehicle may be equipped with certain security
features to reduce the risk of unauthorized and unlawful
access to vehicle systems and wireless communications.
Vehicle software technology continues to evolve over
time and FCA US LLC, working with its suppliers,
evaluates and takes appropriate steps as needed. Similar
to a computer or other devices, your vehicle may require
software updates to improve the usability and performance of your systems or to reduce the potential risk of
unauthorized and unlawful access to your vehicle systems.
The risk of unauthorized and unlawful access to your
vehicle systems may still exist, even if the most recent
version of vehicle software (such as Uconnect software) is
installed.
1
8 SAFETY GUIDELINES
WARNING!
• It is not possible to know or to predict all of the
possible outcomes if your vehicle’s systems are
breached. It may be possible that vehicle systems,
including safety related systems, could be impaired or a loss of vehicle control could occur that
may result in an accident involving serious injury
or death.
• ONLY insert media (e.g., USB, SD card, or CD) into
your vehicle if it came from a trusted source. Media
of unknown origin could possibly contain malicious software, and if installed in your vehicle, it
may increase the possibility for vehicle systems to
be breached.
• As always, if you experience unusual vehicle behavior, take your vehicle to your nearest authorized
dealer immediately.
NOTE:
• FCA or your dealer may contact you directly regarding
software updates.
• To help further improve vehicle security and minimize
the potential risk of a security breach, vehicle owners
should:
• Routinely check
www.driveuconnect.com/software-update
to learn about available Uconnect software updates.
• Only connect and use trusted media devices
(e.g. personal mobile phones, USBs, CDs).
Privacy of any wireless and wired communications cannot be assured. Third parties may unlawfully intercept
information and private communications without your
consent. For further information, refer to “Onboard Diagnostic System (OBD II) Cybersecurity” in “Maintaining
Your Vehicle” in your Owner ’s Manual on the DVD.
INTRODUCTION
CONTENTS
䡵 RADIO 3.0.............................10
䡵 RADIO 3.0.............................14
2
䡵 Uconnect 3.0 SYSTEM VOICE COMMAND .....18
10 INTRODUCTION
RADIO 3.0
WARNING!
ALWAYS drive safely with your hands on the
steering wheel. You have full responsibility and
assume all risks related to the use of the Uconnect
features and applications in this vehicle. Only use
Uconnect when it is safe to do so. Failure to do so
may result in an accident involving serious injury
or death.
INTRODUCTION 11
2
12 INTRODUCTION
1 — RADIO
4 — MENU
Push the RADIO button on the faceplate to enter the
Radio Mode. The different tuner modes; AM, FM and
SXM (if equipped) can be selected by pushing the RADIO
button on the faceplate until the desired tuner mode is
displayed.
2 — INFO
Push the INFO button on the faceplate for a RBDS station
(one with call letters displayed). The radio will return a
Radio Text message broadcast from an FM station (FM
mode only).
3 — AUDIO
Push the AUDIO button on the faceplate to adjust the
Bass, Mid Range, Treble, Balance or Fade.
Push the MENU button on the faceplate to scroll between
the setting sub-menus.
5 — ENTER/BROWSE & TUNE/SCROLL
Push the ENTER/BROWSE button to accept a highlighted
selection on the screen. Rotate the TUNE/SCROLL knob to
scroll through a list or tune a radio station.
6 — PRESETS 1–6
These buttons on the faceplate tune the radio to the
stations that you commit to memory AM (A, B, C), FM
(A, B, C) and Satellite (A, B, C) — 18 AM, 18 FM and 18
SAT stations.
7 — BACK
Push the BACK button on the faceplate to return to a
previous menu or screen.
8 — SEEK UP
Push the SEEK UP button on the faceplate to tune the
radio to the next listenable station or channel.
9 — SEEK DOWN
Push the SEEK DOWN button on the faceplate to tune
the radio to the previous listenable station or channel.
10 — PLAY/PAUSE/MUTE
Push to Play, Pause or Mute the music.
11 — ON/VOLUME
Push the ON/VOLUME control knob to turn on the
radio. Push the ON/VOLUME control knob a second
time to turn off the radio.
INTRODUCTION 13
The volume control turns continuously (360 degrees) in
either direction without stopping. Turning the ON/
VOLUME control knob to the right increases the volume
and to the left decreases it.
12 — A-B-C
Push the A-B-C button on the faceplate to select the A, B
or C preset list.
13 — MEDIA
Pushing the MEDIA button on the faceplate will allow
you to switch from AM/FM/SXM modes to Media mode
(CD – if equipped, USB/iPod, AUX).
2
14 INTRODUCTION
RADIO 3.0
WARNING!
ALWAYS drive safely with your hands on the
steering wheel. You have full responsibility and
assume all risks related to the use of the Uconnect
features and applications in this vehicle. Only use
Uconnect when it is safe to do so. Failure to do so
may result in an accident involving serious injury
or death.
INTRODUCTION 15
2
16 INTRODUCTION
1 — RADIO
4 — ENTER/BROWSE & TUNE/SCROLL
Push the RADIO button on the faceplate to enter the
Radio Mode. The different tuner modes; AM and FM can
be selected by pushing the RADIO button on the faceplate until the desired tuner mode is displayed.
2 — INFO
Push the INFO button on the faceplate for a RBDS station
(one with call letters displayed). The radio will return a
Radio Text message broadcast from an FM station (FM
mode only).
3 — A-B-C
Push the A-B-C button on the faceplate to select the A, B
or C preset list.
Push the ENTER/BROWSE button to accept a highlighted selection on the screen. Rotate the TUNE/
SCROLL rotary knob to scroll through a list or tune a
radio station.
5 — SEEK UP
Push the SEEK UP button on the faceplate to tune the
radio to the next listenable station or channel.
6 — BACK
Push the BACK button on the faceplate to return to a
previous menu or screen.
7 — MENU
Push the MENU button on the faceplate to scroll between
the setting sub-menus.
8 — PLAY/PAUSE/MUTE
Push to Play, Pause or Mute the music.
9 — AUDIO
Push the AUDIO button on the faceplate to adjust the
Bass, Mid Range, Treble, Balance or Fade.
10 — SEEK DOWN
Push the SEEK DOWN button on the faceplate to tune
the radio to the previous listenable station or channel.
INTRODUCTION 17
The electronic volume control turns continuously (360
degrees) in either direction without stopping. Turning the
ON/VOLUME control knob to the right increases the
volume and to the left decreases it.
12 — PRESETS 1–6
These buttons on the faceplate tune the radio to the
stations that you commit to memory AM (A, B, C), FM
(A, B, C) — 18 AM and 18 FM stations.
13 — MEDIA
2
11 — ON/VOLUME
Push the ON/VOLUME control knob to turn on the
radio. Push the ON/VOLUME control knob a second
time to turn off the radio.
Pushing the MEDIA button on the faceplate will allow
you to switch from AM and FM modes to Media mode
(CD – if equipped, USB/iPOD, AUX).
18 INTRODUCTION
Uconnect 3.0 SYSTEM VOICE COMMAND
WARNING!
ALWAYS drive safely with your hands on the
steering wheel. You have full responsibility and
assume all risks related to the use of the Uconnect
features and applications in this vehicle. Only use
Uconnect when it is safe to do so. Failure to do so
may result in an accident involving serious injury
or death.
INTRODUCTION 19
2
20 INTRODUCTION
1 — RADIO
5 — PRESETS 1–5
Push the RADIO button on the faceplate to enter the
Radio Mode. The different tuner modes; AM, FM and
SXM (if equipped) can be selected by pushing the RADIO
button on the faceplate until the desired tuner mode is
displayed.
2 — PHONE PICK UP
Push the PHONE PICK UP button to initiate or answer a
phone call, send or receive a text.
3 — PHONE HANG UP
Push the PHONE HANG UP button to end a call.
4 — A-B-C
Push the A-B-C button on the faceplate to select the A, B
or C preset list.
These buttons on the faceplate tune the radio to the
stations that you commit to memory AM (A, B, C), FM
(A, B, C) and Satellite (A, B, C) — 18 AM, 18 FM and 18
SAT stations.
6 — ENTER/BROWSE & TUNE/SCROLL
Push the ENTER/BROWSE button to accept a highlighted
selection on the screen. Rotate the TUNE/SCROLL knob to
scroll through a list or tune a radio station.
7 — SEEK UP
Push the SEEK UP button on the faceplate to tune the
radio to the next listenable station or channel.
8 — BACK
Push the BACK button on the faceplate to return to a
previous menu or screen.
9 — MENU
INTRODUCTION 21
13 — ON/VOLUME
Push the MENU button on the faceplate to scroll between
the setting sub-menus.
10 — INFO
Push the INFO button on the faceplate for a RBDS station
(one with call letters displayed). The radio will return a
Radio Text message broadcast from an FM station (FM
mode only).
11 — PLAY/PAUSE/MUTE
Push to Play, Pause or Mute music or Mute an active
phone call.
12 — SEEK DOWN
Push the SEEK DOWN button on the faceplate to tune
the radio to the previous listenable station or channel.
Push the ON/VOLUME control knob to turn on the
radio. Push the ON/VOLUME control knob a second
time to turn off the radio.
The volume control turns continuously (360 degrees) in
either direction without stopping. Turning the ON/
VOLUME control knob to the right increases the volume
and to the left decreases it.
14 — MEDIA
Pushing the MEDIA button on the faceplate will allow
you to switch from AM/FM/SXM modes to Media mode
(CD – if equipped, USB/iPod, AUX).
2
RADIO MODE
CONTENTS
䡵 OPERATING RADIO MODE ................24
▫ ON/OFF Volume Control.................24
▫ Setting Presets.........................25
▫ SiriusXM Satellite Radio Mode — If Equipped . .25
3
▫ ENTER/BROWSE & TUNE/SCROLL Control . .24
▫ Seek Functions ........................24
▫ Audio ..............................26
24 RADIO MODE
OPERATING RADIO MODE
The radio is equipped with the following modes:
• FM
• AM
• SXM SiriusXM Satellite Radio (if equipped)
Push the RADIO button on the faceplate to enter the
Radio Mode. The different tuner modes; AM, FM, and
SXM, can then be selected by pushing the RADIO button
until the desired tuner mode is displayed.
ON/OFF Volume Control
Push the ON/OFF Volume Control knob to turn on the
radio. Push the ON/OFF Volume Control knob a second
time to turn off the radio.
When the audio system is turned on, the sound will be
set at the same volume level as last played.
ENTER/BROWSE & TUNE/SCROLL Control
Turn the rotary TUNE/SCROLL control knob clockwise
to increase or counterclockwise to decrease the radio
station frequency.
When scrolling a list, push the ENTER/BROWSE button
on the faceplate to choose a selection.
Seek Functions
SEEK UP
Push and release the SEEK UP
button on the faceplate to tune the radio to the next listenable station or
channel.
During a SEEK UP function, if the radio reaches the
starting station after passing through the entire band two
times, the radio will stop at the station where it began.
SEEK DOWN
Push and release the SEEK DOWN
faceplate to tune the radio to the next listenable station
or channel.
button on the
RADIO MODE 25
The Radio stores up to 18 presets in each of the Radio
modes. Push the A-B-C button on the faceplate to select
the A, B or C preset list.
SiriusXM Satellite Radio Mode — If Equipped
During a SEEK DOWN function, if the radio reaches the
starting station after passing through the entire band two
times, the radio will stop at the station where it began.
Setting Presets
The Presets are available for all Radio Modes, and are
activated by pushing any of the six PRESET buttons on
the faceplate.
When you are receiving a station that you wish to
commit into memory, push and hold the desired numbered button on the faceplate for more that two seconds
or until you hear a confirmation beep.
SiriusXM Satellite Radio uses direct satellite-to-receiver
broadcasting technology to provide clear digital sound,
coast to coast. The subscription service provider is
SiriusXM Satellite Radio. This service offers over 130
channels of music, sports, news, entertainment, and
programming for children, directly from its satellites and
broadcasting studios. A one-year SiriusXM Satellite Radio subscription is included.
SiriusXM and all related marks and logos are trademarks of
SiriusXM Radio Inc. and its subsidiaries. SiriusXM Satellite
Radio requires a subscription, sold separately after trial
subscription included with vehicle purchase. Prices and
programming are provided by SiriusXM and are subject
3
26 RADIO MODE
to change. Subscriptions governed by Terms & Conditions
available at
www.siriusxm.com/customeragreement
SiriusXM Radio U.S. service only available to those at
least 18 years of age in the 48 contiguous United States,
D.C., and PR. Service available in Canada; see
www.siriusxm.ca
.
This functionality is only available for radios equipped
with a Satellite receiver. In order to receive satellite radio,
the vehicle needs to be outside with a clear view to the
sky.
If the screen shows Acquiring Signal, you may have to
change the vehicle’s position to receive a signal. In most
cases, the satellite radio does not receive a signal in
underground parking garages or tunnels.
Audio
.
Push the AUDIO button on the faceplate to enter the
Audio Menu. Turning the TUNE/SCROLL knob, highlight the desired selection.
The Audio Menu shows the following options for you to
customize the audio settings:
• Treble, Mid, Bass, Fade And Balance — Select the
desired setting to adjust, then push the ENTER/
BROWSE button. Turn the TUNE/SCROLL knob to
adjust the setting + or – 9. Push the BACK button on
the faceplate when done.
• Speed Adjusted Volume (If Equipped) — Select
“Speed Adjusted Volume” and push the ENTER/
BROWSE button. Turn the TUNE/SCROLL knob to
adjust the setting to Off, 1, 2, or 3. Push the BACK
button on the faceplate when done.
• Loudness (If Equipped) — Select “Loudness” and
push the ENTER/BROWSE button to mark the check
box on or off. Push the BACK button on the faceplate
when done.
• AUX Volume Offset (If Equipped) — Select “AUX
Volume Offset” and push the ENTER/BROWSE button. Turn the TUNE/SCROLL knob to adjust the
setting + or – 3. Push the BACK button on the faceplate
when done.
RADIO MODE 27
3
MEDIA MODE
CONTENTS
䡵 OPERATING MEDIA MODE ................30
▫ Disc Mode ...........................31
▫ Common Media Functions ................30
▫ Source ..............................30
▫ Info ................................31
▫ Audio ..............................31
▫ USB/iPod Mode .......................32
4
▫ AUX Mode ...........................32
▫ Bluetooth Mode .......................33
30 MEDIA MODE
OPERATING MEDIA MODE
Media Mode is entered by pushing the MEDIA button on
the faceplate located to the left of the display. Once in
Media Mode, press the MEDIA button in order to select
the desired media source.
Common Media Functions
SEEK UP
Push and release the SEEK UP
/SEEK DOWN
button on the face-
plate for the next selection.
Push and release the SEEK DOWN
button on the
faceplate to return to the beginning of the current
selection, or return to the beginning of the previous
selection if the Media is within the first three seconds
of the current selection.
Fast SEEK UP
Push and hold the SEEK UP
button on the faceplate
and the desired mode will begin to fast forward
through the current track until the button on the
faceplate is released.
Fast SEEK DOWN
Push and hold the SEEK DOWN
button on the
faceplate and the desired mode will begin to rewind
through the current track until the button on the
faceplate is released.
Source
Push the MEDIA button on the faceplate to select the
desired audio source, disc (if equipped), AUX or USB.
Info
MEDIA MODE 31
Inserting Compact Disc
Push the INFO button on the faceplate to display the
current track information.
Audio
Refer to “Radio Mode” for adjusting the audio settings.
Disc Mode
If equipped, the vehicle may have a remote disc player
located in the lower center console storage bin.
Disc Mode is entered by either inserting a disc or by
pushing the MEDIA button on the faceplate located to the
left of the display. Once in Media Mode, select “Disc
Mode.”
Gently insert one disc into the disc player following the
illustration indicated on the player. The disc will automatically be pulled into the disc player and the disc icon
will illuminate on the radio display. If a disc does not go
into the slot more than 1.0 inch (2.5 cm), a disc may
already be loaded and must be ejected before a new disc
can be loaded.
If you insert a disc with the ignition ON and the radio
ON, the unit will switch to CD/Disc mode and begin to
play when you insert the disc. The display will show the
track number and index time in minutes and seconds.
Play will begin at the start of track 1.
Eject Button — Ejecting A Disc
Push the EJECT button on the faceplate to eject the disc.
If you have ejected a disc and have not removed it within
4
32 MEDIA MODE
10 seconds, it will be reloaded. If the disc is not removed,
the radio will reinsert the disc but will not play it.
A disc can be ejected with the radio and ignition OFF.
USB/iPod Mode
USB/iPod Mode is entered by either inserting a USB
Jump Drive or iPod cable into the USB port, or by
pushing the MEDIA button on the faceplate located to the
left of the display. Once in Media Mode, push the MEDIA
button and select USB/iPod.
Inserting USB/iPod Device
Gently insert the USB/iPod device into the USB port. If
you insert a USB/iPod device with the ignition ON and
the radio ON, the unit will switch to USB/iPod mode and
begin to play when you insert the device. The display
will show the track number, and index time in minutes
and seconds. Play will begin at the start of track 1.
AUX Mode
AUX Mode is entered by inserting an AUX device using
a cable with a 3.5 mm stereo audio jack into the AUX
port, or by pushing MEDIA button on the faceplate
located to the left of the display. Once in Media Mode,
push the MEDIA button and select “AUX.”
Inserting Auxiliary Device
Gently insert the auxiliary device cable into the AUX
port. If you insert an auxiliary device with the ignition
ON and the radio ON, the unit will switch to AUX mode
and begin to play when you insert the device cable.
Controlling The Auxiliary Device
The control of the auxiliary device (e.g., selecting playlists, play, fast forward, etc.) cannot be provided by the
radio; use the device controls instead. Adjust the volume
with the ON/OFF VOLUME rotary knob, or with the
volume of the attached device.
NOTE: The vehicle radio unit is acting as the amplifier
for audio output from the auxiliary device. Therefore if
the volume control on the auxiliary device is set too low,
there will be insufficient audio signal for the radio unit to
play the music on the device.
Bluetooth Mode
MEDIA MODE 33
See the “Pairing Procedure” in this manual for further
details.
Once the Bluetooth device is paired to the Uconnect
system, push the MEDIA button located on the faceplate.
Once in Media Mode, press the “Source” button on the
touchscreen and select “Bluetooth.”
Bluetooth Streaming Audio (BTSA) or Bluetooth Mode is
entered by pairing a Bluetooth device containing music
to the Uconnect system.
Before proceeding, the Bluetooth device must be paired
with the Uconnect Phone to communicate with the
Uconnect system.
NOTE: For mobile phone compatibility and pairing
instructions, please visit
UconnectPhone.com
.
4
UCONNECT PHONE
CONTENTS
䡵 OPERATING UCONNECT PHONE ...........36
▫ Receiving A Call — Accept (And End) .......40
▫ Pairing A Phone .......................37
▫ Phonebook Download — Phonebook Transfer
From Mobile Phone.....................39
▫ Making A Phone Call ...................40
▫ Mute (Or Unmute) Microphone During Call . . .41
▫ Transfer Ongoing Call Between Handset And
Vehicle ..............................41
▫ Changing The Volume ...................41
5
36 UCONNECT PHONE
WARNING!
ALWAYS drive safely with your hands on the
wheel. You have full responsibility and assume all
risks related to the use of the Uconnect features
and applications in this vehicle. Only use
Uconnect when it is safe to do so. Failure to do so
may result in an accident involving serious injury
or death.
OPERATING UCONNECT PHONE
The Uconnect Phone is a voice-activated, hands-free,
in-vehicle communications system with Voice Command
Capability (see Voice Command section).
The Uconnect Phone allows you to dial a phone number
with your mobile phone using simple voice commands.
NOTE: The Uconnect Phone requires a mobile phone
equipped with the Bluetooth Hands-Free Profile.
To check mobile phone compatibility please visit
UconnectPhone.com
Uconnect System Support:
• U.S. residents - visit
1-877-855-8400 (24 hours a day 7 days a week)
• Canadian residents call 1-800-465-2001 (English) or
1-800-387-9983 (French) or visit
Mon. – Fri., 8:00 am – 8:00 pm, ET
Sat., 9:00 am – 5:00 pm, ET
Sun., Closed
.
DriveUconnect.com
or call
DriveUconnect.ca
UCONNECT PHONE 37
WARNING!
Any voice commanded system should be used
only in safe driving conditions following all applicable laws. Your attention should be focused on
safely operating the vehicle. Failure to do so may
result in a collision causing serious injury or
death.
Pairing A Phone
To begin using your Uconnect Phone, you must pair your
compatible Bluetooth enabled mobile phone. Mobile
phone pairing is the process of establishing a wireless
connection between a cellular phone and the Uconnect
system.
5
38 UCONNECT PHONE
To complete the pairing process, you will need to reference your mobile phone Owner’s Manual. Please visit
UconnectPhone.com
for complete mobile phone com-
patibility information.
NOTE:
• You must have Bluetooth enabled on your phone to
complete this procedure.
• The vehicle must be in PARK.
1. Place the ignition in the ACC or ON position.
2. Push the “Phone” button on the faceplate.
NOTE: If there is no phones currently connected with the
system, a pop-up will appear asking if you would like to
pair a mobile phone.
3. Select “Yes” to begin the pairing process.
4. Search for available devices on your Bluetooth enabled
mobile phone.
• Press the Settings button on your mobile phone.
• Select Bluetooth and ensure it is enabled. Once
enabled, the mobile phone will begin to search for
Bluetooth connections.
5. If No is selected, and you still would like to pair a
mobile phone, press the “Settings” button from the
Uconnect Phone main screen.
• Select “Paired Phones” then press the “Add Device”
button on the touchscreen.
• Search for available devices on your Bluetooth enabled mobile phone (see below). When prompted on
the phone, select “Uconnect” and accept the connection request.
6. Uconnect Phone will display an in progress screen
while the system is connecting.
7. When your mobile phone finds the Uconnect system,
select “Uconnect.”
UCONNECT PHONE 39
Phonebook Download — Phonebook Transfer From Mobile Phone
8. When prompted on the mobile phone, accept the
connection request from Uconnect Phone.
NOTE: Some mobile phones will require you to enter the
PIN number.
9. When the pairing process has successfully completed,
the system will prompt you to choose whether or not
this is your favorite phone. Selecting “Yes” will make
this phone the highest priority. This phone will take
precedence over other paired phones within range and
will connect to the Uconnect system automatically
when entering the vehicle. Only one mobile phone
and/or one Bluetooth audio device can be connected
to the Uconnect system at a time. If “No” is selected,
simply select “Uconnect” from the mobile phone/
audio device Bluetooth screen, and the Uconnect
system will reconnect to the Bluetooth device.
If equipped and specifically supported by your phone,
Uconnect Phone will ask you if you want to download
names (text names) and number entries from your mobile
phone’s phonebook. Specific Bluetooth Phones with
Phone Book Access Profile may support this feature. See
UconnectPhone.com
NOTE:
• Download and update, if supported, begins as soon
as the Bluetooth wireless phone connection is made to
the Uconnect Phone, for example, after you start the
vehicle.
• You may be asked for permission to initiate the phonebook download.
for supported phones.
5
40 UCONNECT PHONE
• A maximum of 2,000 contact names with six numbers
per contact will be downloaded and updated every
time a phone is connected to the Uconnect Phone.
• Depending on the maximum number of entries downloaded, there may be a short delay before the latest
downloaded names can be used. Until then, if available, the previously downloaded phonebook is available for use.
• Only the phonebook of the currently connected mobile
phone is accessible.
• Only the mobile phones phonebook is downloaded.
SIM card phonebook is not part of the Mobile
phonebook.
• This downloaded phonebook cannot be edited or
deleted on the Uconnect Phone. These can only be
edited on the mobile phone. The changes are transferred and updated to Uconnect Phone on the next
phone connection.
Making A Phone Call
1. Push the PHONE button on the steering wheel.
2. After the BEEP, say “dial” (or “call” a full name or
phone number).
Receiving A Call — Accept (And End)
1. When an incoming call rings or is announced on
Uconnect, push the PHONE button on the faceplate.
2. To end a call, push the PHONE button on steering
wheel or the PHONE button on the faceplate.
Mute (Or Unmute) Microphone During Call
UCONNECT PHONE 41
Changing The Volume
• Push the “Play/Pause/Mute” hard button on the radio
or during a call, push the VOICE COMMAND button
on the steering wheel. After the BEEP, say “mute” (or
“mute off”).
Transfer Ongoing Call Between Handset And Vehicle
• With a call in progress use the browse/enter scroll
wheel to select “transfer” then press the enter button
or push the “Phone Pickup” button on the steering
wheel controls during a call, push the VOICE COMMAND button on the steering wheel. After the BEEP,
say “transfer call.”
1. Start a dialogue by pushing the PHONE button on the
faceplate, then adjust the volume during a normal call.
2. Use the radio ON/VOLUME rotary knob to adjust the
volume to a comfortable level while the Uconnect
system is speaking. Please note the volume setting for
Uconnect phone is different than the audio system
volume setting.
5
UCONNECT 3.0 VOICE RECOGNITION QUICK TIPS
CONTENTS
䡵 UCONNECT VOICE RECOGNITION .........44
▫ Radio ...............................47
▫ Introducing Uconnect ...................44
▫ Get Started ...........................45
▫ Basic Voice Commands ..................46
▫ Media ..............................47
▫ Phone ..............................48
▫ Additional Information ..................48
6
44 UCONNECT 3.0 VOICE RECOGNITION QUICK TIPS
UCONNECT VOICE RECOGNITION
Introducing Uconnect
Start using Uconnect Voice Recognition with these helpful quick tips. It provides the key Voice Commands and
tips you need to know to control your Uconnect 3.0
system.
Key Features:
• 3” display
• Three buttons on either side of the display
WARNING!
Any voice commanded system should be used
only in safe driving conditions following all applicable laws. Your attention should be focused on
(Continued)
WARNING! (Continued)
safely operating the vehicle. Failure to do so may
result in a collision causing serious injury or
death.
Get Started
1. Visit
UconnectPhone.com
to check mobile device and
feature compatibility and to find phone pairing instructions.
2. Reduce background noise. Wind and passenger conversations are examples of noise that may impact
recognition.
3. Speak clearly at a normal pace and volume while
facing straight ahead. The microphone is positioned
on the rearview mirror and aimed at the driver.
4. Each time you give a Voice Command, you must first
push either the VR or PHONE button, wait until after
the beep, then say your Voice Command.
5. You can interrupt the help message or system prompts
by pushing the VR or PHONE button and saying a
Voice Command from current category.
UCONNECT 3.0 VOICE RECOGNITION QUICK TIPS 45
All you need to control your Uconnect system with your
voice are the buttons on your steering wheel.
6
1 — Push To Begin Radio Or Media Functions
2 — Push To Initiate, Answer, Or End A Phone Call, Send Or Receive A Text
46 UCONNECT 3.0 VOICE RECOGNITION QUICK TIPS
Basic Voice Commands
The basic Voice Commands below can be given at any
point while using your Uconnect system.
1 — Push To Initiate Or To Answer A Phone Call, Send Or Receive A Text
2 — Push To Begin Radio Or Media Functions
3 — Push To End Call
Push the VR button
. After the beep, sayѧ
• Cancel to stop a current voice session
• Help to hear a list of suggested Voice Commands
• Repeat to listen to the system prompts again
Notice the visual cues that inform you of your voice
recognition system’s status. Cues appear on the screen.
Radio
UCONNECT 3.0 VOICE RECOGNITION QUICK TIPS 47
Media
Use your voice to quickly get to the AM, FM or SiriusXM
Satellite Radio stations you would like to hear. (Subscription or included SiriusXM Satellite Radio trial required.)
Push the VR button
• Tune to ninety-five-point-five FM
• Tune to Satellite Channel Hits 1
TIP: At any time, if you are not sure of what to say or
want to learn a Voice Command, push the VR button
and say “Help.” The system will provide you with
a list of commands.
. After the beep, sayѧ
Uconnect offers connections via USB, SD, Bluetooth and
Auxiliary ports (If Equipped). Voice operation is only
available for connected USB and iPod devices. (Remote
CD player optional and not available on all vehicles.)
Push the VR button
following commands and follow the prompts to
switch your media source or choose an artist.
• Change source to Bluetooth
• Change source to iPod
• Change source to USB
• Play artist Beethoven; Play album Greatest Hits; Play
song Moonlight Sonata; Play genre Classical
. After the beep, say one of the
6
48 UCONNECT 3.0 VOICE RECOGNITION QUICK TIPS
Phone
Additional Information
Making and answering hands-free phone calls is easy
with Uconnect. Check
UconnectPhone.com
for mobile
phone compatibility and pairing instructions.
Push the PHONE button
. After the beep, say one of
the following commands:
• Call John Smith
• Dial 123-456-7890 and follow the system prompts
• Redial (call previous outgoing phone number)
• Call back (call previous incoming phone number)
TIP: When providing a Voice Command, push the
PHONE button
and say “Call,” then pronounce the
name exactly as it appears in your phone book. When
a contact has multiple phone numbers, you can say
“Call John Smith work.”
© 2015 FCA US LLC. All rights reserved. Mopar and
Uconnect are registered trademarks and Mopar Owner
Connect is a trademark of FCA US LLC. Android is a
trademark of Google Inc.
DriveUconnect.com
16UC3-526-AC
Third Edition Rev 1
Radio 3.0/Uconnect® 3.0
Printed in the USA
©2015 FCA US LLC. All Rights Reserved.
Chrysler, Dodge, Jeep, Ram and Mopar are registered trademarks of FCA US LLC.
FIAT is a registered trademark of Fiat Group Marketing
& Corporate Communication S.p.A., used under license by FCA US LLC.
Loading...
