Chroma-Q Studio One 100 V Users Manual

Chroma-Q®
Studio One 100 V™
User Manual
PN: 638-0702
www.chroma
-
q.com
Warranty Statement
Chroma-Q warrants to the original purchaser, with proof of purchase, that its delivered products shall be free from defects in
material and workmanship under normal use for a period of 12 months from date of shipment.
Chroma-Q will repair, or at its option, provide an equivalent item or replace, the defective product during the stated warranty
period. This warranty applies only to the repair or replacement of the product and only when the product is properly handled,
installed and maintained according to Chroma-Q instructions. This warranty excludes defects resulting from improper
handling, storage, installation, acts of God, fire, vandalism or civil disturbances. Purchaser must notify Chroma-Q in writing
within 14 days of noticing the defect. This warranty excludes field labour or service charges related to the repair or replacement of the product.
The warranty contained herein shall not extend to any finished goods or spare parts from which any serial number has been
removed or which have been damaged or rendered defective (a) as a result of normal wear and tear, wilful or accidental
damage, negligence, misuse or abuse; (b) due to water or moisture, lightning, windstorm, abnormal voltage, harmonic
distortion, dust, dirt, corrosion or other external causes; (c) by operation outside the specifications contained in the user
documentation; (d) by the use of spare parts not manufactured or sold by Chroma-Q or by the connection or integration of
other equipment or software not approved by Chroma-Q unless the Customer provides acceptable proof to Chroma-Q that
the defect or damage was not caused by the above; (e) by modification, repair or service by anyone other than Chroma-Q,
who has not applied for and been approved by Chroma-Q to do such modification, repair or service unless the Customer
provides acceptable proof to Chroma-Q that the defect or damage was not caused by the above; (f) due to procedures,
deviating from procedures specified by Chroma-Q or (g) due to failure to store, install, test, commission, maintain, operate or
use finished goods and spare parts in a safe and reasonable manner and in accordance with Chroma-Q’s instructions (h) by repair or replacement of engines without factory training.
The warranty contained herein shall not apply to finished goods or spare parts which are sold “as is”, as “second-hand”, as
used”, as “demo” or under similar qualifications or to Consumables (“Consumables” is defined as any part(s) of goods or
part(s) for use with goods, which part(s) of goods or part(s) for use with goods are consumed during the operation of the
goods and which part(s) of goods or part(s) for use with goods require replacement from time to time by a user such as, but not limited to, light bulbs).
The warranty contained herein shall not apply, unless the total purchase price for the defective finished goods or spare parts
has been paid by the due date for payment.
The warranty contained herein applies only to the original purchaser and are not assignable or transferable to any
subsequent purchaser or end-user.
This warranty is subject to the shipment of the goods, within the warranty period, to the Chroma-Q warranty returns
department, by the purchaser, at the purchasers’ expense. If no fault is found, Chroma-Q will charge the purchaser for the subsequent return of the goods.
Chroma-Q reserves the right to change the warranty period without prior notice and without incurring obligation and expressly disclaims all warranties not stated in this limited warranty.
Studio One 100 V User Manual 1 V1.0 September 2015
www.chroma
-
q.com
Disclaimer
The information contained herein is offered in good faith and is believed to be accurate. However, because conditions and
methods of use of our products are beyond our control, this information should not be used in substitution for customer's
tests to ensure that Chroma-Q products are safe, effective, and fully satisfactory for the intended end use. Suggestions of
use shall not be taken as inducements to infringe any patent. Chroma-Q sole warranty is that the product will meet the sales
specifications in effect at the time of shipment. Your exclusive remedy for breach of such warranty is limited to refund of
purchase price or replacement of any product shown to be other than as warranted.
Chroma-Q reserves the right to change or make alteration to devices and their functionality without notice due to our ongoing research and development.
The Chroma-Q Studio One 100 range has been designed specifically for the lighting industry. Regular maintenance should be performed to ensure that the products perform well in the entertainment environment.
If you experience any difficulties with any Chroma-Q products please contact your selling dealer. If your selling dealer is
unable to help please contact support@chroma-q.com. If the selling dealer is unable to satisfy your servicing needs, please
contact the following, for full factory service:
Outside North America: North America:
Tel: +44 (0)1494 446000 Tel: 416-255-9494
Fax: +44 (0)1494 461024 Fax: 416-255-3514
support@chroma-q.com support@chroma-q.com
For further information please visit the Chroma-Q website at www.chroma-q.com.
Chroma-Q and Studio One 100 V are trademarks, for more information on this visit www.chroma-q.com/trademarks.
The rights and ownership of all trademarks are recognised.
Important Notice:
As per the requirements in the Occupational Safety and Health Administration standards for product approval, please refer to
the OSHA web pages http://www.osha.gov/dts/otpca/nrtl/ for information on the list of Nationally Recognized Testing Laboratories (NRTLs) and the scope of recognition.
Studio One 100 V User Manual 2 V1.0 September 2015
www.chroma
-
q.com
Table of Contents
1.
1.
Product overview
1.1.
2.
2.
2.2.
Product overview ................................
Product overviewProduct overview
Operation
Operation ................................
OperationOperation
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
.................................... 4444
................................................................
...........................................
................................................................
........... 5555
......................
2.1 Unpacking the Units ....................................................................................................................................... 5
2.2 Cabling ......................................................................................................................................................... 5
2.3 Mounting ...................................................................................................................................................... 5
2.4 Optics ........................................................................................................................................................... 5
2.5 Control ......................................................................................................................................................... 6
2.6 DMX Protocol .............................................................................................................................................. 13
2.7 Thermal Performance .................................................................................................................................. 13
3.
3.
Troubleshooting
3.3.
4.
4.
4.4.
5.
5.
5.5.
Troubleshooting ................................
TroubleshootingTroubleshooting
Specification
Specification ................................
SpecificationSpecification
4.1 Technical Specifications ............................................................................................................................... 14
4.2 Drawings – Dimensions ............................................................................................................................... 15
Ma
Maintenance
intenance ................................
MaMa
intenanceintenance
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................ 13
................................................................
.....................................
................................................................
.....................................
................................................................
13
1313
..... 14
14
..........
1414
..... 15
15
..........
1515
Studio One 100 V User Manual 3 V1.0 September 2015
www.chroma
-
q.com
1. Product overview
The new Chroma based fixture, for the most demanding applications.
Utilising core LED technology from the Chroma-Q premium performance lighting range, the multi-purpose fixture is ideal for a wide range of environments and provides a powerful, creative lighting tool.
The Studio One's custom optical design and fully homogenised output provides a smooth, uniform and defined 18° beam.
Theatrical grade dimming emulates the extremely smooth dimming curve of tungsten fixtures.
The Studio One 100 offers adjustable dimming frequencies to ensure flicker-free operation on cameras.
With the advanced feature set also including convection cooling for silent operation and a versatile mounting yoke, the Studio
One 100 is suitable for numerous TV, film, studio, exhibition & entertainment lighting applications - complementing the popular Chroma-Q Studio Force™ and Studio Force Phosphor™ LED fixtures ranges.
With a simple to use Infra-Red remote control included with each fixture, you can be up and running within minutes without
the requirement of a lighting console - saving time and labour with instant access to pre-set colour temperatures, on/off, dimming and effects.
Chroma----Q® Studio One 100™
ChromaChroma
Q® Studio One 100™ LED Par is designed to deliver the highest quality of white light from an LED
Q® Studio One 100™Q® Studio One 100™
To enable maximum flexibility with users' existing production inventory, the Studio One accepts industry-standard 6.25" accessories such as egg crates, barndoors and top hats.
Note: HANDHELD COLOUR METERS
Handheld Colour Meters provide a limited measuring range for LED fixtures, which results in inconsistent and unreliable data.
All photometric values listed in this document are based on testing and measurements conducted by certified independent laboratories with reference to the IES standards.
Studio One 100 V User Manual 4 V1.0 September 2015
www.chroma
-
q.com
2. Operation
2.1 Unpacking the Units
The Studio One 100 V package includes 1 unit fixture, power cord, power connector, colour frame, a Quick Start Guide and an IR Remote.
We recommend that you keep the original packaging in case the item needs to be returned.
2.2 Cabling
The Studio One 100 V is built with chassis mount powerCon connectors for power input and through; chassis mount XLR 5­pin connectors for DMX control data input and through.
The enclosure is ground bonded.
XLR 5-pin Cable:
Pin# Function
1 Ground (Screen) 2
Data Minus
3
Data Plus
4
Spare Data Minus
5
Spare Data Plus
Power Cable:
International
Colour Code
Green and Yellow Green Earth (E) Ground (Green) Blue White Neutral (N) Neutral (Silver) Brown Black Live (L) Hot (Gold)
Important Notice: The use of an opto-splitter for DMX signal distribution is highly recommended when several fixtures are
not plugged into the same power source.
North American
Colour Code
Connections
2.3 Mounting
The Studio One 100 V is built with a split yoke system for floor mounting and overhead hanging applications. Secure the fixture with a safety bond when hung. A provision for a fixing hold is built into the fixture.
2.4 Optics
The Studio One 100 V is built with an optical lens that provides a fully homogenised beam angle of approximately ~ 18°.
Studio One 100 V User Manual 5 V1.0 September 2015
www.chroma
-
q.com
2.5 Control
The Studio One 100 V is controlled remotely via ANSI E1.11 USITT DMX512-A protocol or can operate as a standalone unit
with the wireless IR Remote. The control functions can be accessed through the LCD display at the rear of the fixture with 4
push buttons.
Back Arrow (Enter) Stores the menu choice
Up Arrow Increases (+) the mode level or value
Down Arrow Decreases (-) the mode level or value
Exit Back to the previous menu
Power-Up Display:
On power-up, the display shows the Brand, Model Name and Software Version for 5 seconds then goes on to show the Main
Menu. The Main Menu shows:
Model Name
DMX Status
DMX Address
Set Control Personality (Mode)
Number of Assigned Channels
Display Mode:
The LCD is backlit when you access the menus. This will switch off when left undisturbed for 10 seconds.
Personality:
The Studio One 100 V features a single Warm and Cold White LED engine which can be controlled through four Personality
modes:
Studio One 100 V User Manual 6 V1.0 September 2015
www.chroma
-
q.com
Display Ch Description
1-CTI 2 1 channel controls Color Temperature adjustment for all LEDs and 1 channel for Intensity control of all
LEDs. 2-WW CW 2 1 channel controls all Warm White LEDs and 1 channel controls all Cold White LEDs. 3-Master The unit is set as the Master unit. All settings of the Master unit will be repeated on all Slave units. 4-Slave The unit is set as the Slave unit. All settings of the Slave units follow the Master unit.
Wireless IR Remote:
The Studio One 100 V can be controlled via wireless IR Remote in standalone operation. The fixture is set in IR Remote
control by selecting IR Remote in the menu No DMX Present. Point the IR Remote towards the fixture.
The IR Remote features buttons for the following control options:
On and Off
Fade In and Out
White
Color and Effects Buttons applicable to the Color One 100 units:
15 Colors
4 Effects: Full Color Scroll (Flash), Warm Color Scroll (Strobe),
Fade In/Fade Out, and Cold Color Scroll (Smooth)
Studio One 100 V User Manual 7 V1.0 September 2015
www.chroma
-
q.com
Control Menu
Use the Up
Up and Down
Press Enter
Enter to select a control menu option
EnterEnter
Press Enter
Enter to save the setting, display shows Done and returns to the previous menu
EnterEnter
Press Exit
Exit to return to the previous menu without saving
ExitExit
The display goes back to the Main Menu
Down arrows to navigate the control menu options
UpUp
DownDown
Studio One 100 V User Manual 8 V1.0 September 2015
www.chroma
-
q.com
Main Menu
The Main Menu displays the following:
Model name
DMX status
DMX start address
Personality (Control Mode)
Number of assigned channels
To set the DMX start address,
1. From the Main Menu, press Enter
2. Press Up
3. Press Enter
Up or Down
Down to adjust the DMX start address.
UpUp
DownDown
Enter to save.
EnterEnter
Display shows Done and returns to the Main Menu.
1-Personality
The Studio One 100 V can be set to operate in DMX controlled and standalone modes. Refer to the list below for details.
To set the Personality,
1. From the Main Menu, press Up
2. Press Enter
3. Press Enter
Enter and then Up
Enter Enter
Enter to save.
EnterEnter
The display shows Done, returns to 1-Personality and then the Main Menu.
Personality – Software Version 1.6
Display Ch Description
1-CTI 2 Color Temperature + Intensity
2-WW CW 2 Warm White + Cold White
3-Master 0 Set as master unit in standalone
4-Slave 0 Set as slave unit in standalone
Enter....
EnterEnter
Up or Down
Down to access 1-Personality.
UpUp
DownDown
Up or Down
Down to select the mode.
UpUp
DownDown
Studio One 100 V User Manual 9 V1.0 September 2015
www.chroma
-
q.com
2-No DMX Present
If DMX control signal from an external source is not detected, various standalone output options can be selected:
1-OFF Fixture has no light output
2-Hold Last Fixture holds the last valid DMX state
3-IR Remote Fixture is controlled via remote infrared control unit
4-Look 1 Fixture snaps to saved Look
5-Look 2 Fixture snaps to saved Look
6-Look 3 Fixture snaps to saved Look
7-Look 4 Fixture snaps to saved Look
8-Look 5 Fixture snaps to saved Look
To set the option when there is No DMX Present,
1. From the Main Menu, press Up
2. Press Enter
3. Press Enter
Enter, then press Up
EnterEnter
Enter to save.
EnterEnter
Up or Down
Down to access 2-No DMX Present.
UpUp
DownDown
Up or Down
Down to select the option.
Up Up
DownDown
The display shows Done, returns to 2-No DMX Present and then the Main Menu.
Studio One 100 V User Manual 10 V1.0 September 2015
www.chroma
-
q.com
3-Look Store
In this mode,
5 internal preset Looks are available for stand-alone operation (see No DMX Present).
Looks created from an external DMX console can be recorded in any of the 5 Look numbers and will be
preserved on power down.
Looks that have been recorded can be modified in stand-alone operation.
Looks will be returned to default setting if reset is performed.
To recall a Look in stand-alone operation,
1. From the Main Menu, press Up
2. Press Enter
3. Press Up
4. Press and hold Enter
Enter and press Up
EnterEnter
Up or Down
Down to increase or decrease the color temperature “CT
UpUp
DownDown
Enter to save the Look, the display shows Recorded and the Look turns On.
EnterEnter
Up or Down
Down to access 3-Look Store.
UpUp
DownDown
Up or Down
Down to select from Look 1 to 5.
UpUp
DownDown
CT” and intensity “IIII” from 0 to 100.
CTCT
To record a Look created from a remote DMX console:
1. Set the fixture to the desired Personality.
2. Use an external DMX console to adjust the assigned channel levels and create the desired look or effect.
3. From the Main Menu, press Up
4. Press Enter
5. Press Enter
Enter, press Up
EnterEnter
Enter to record the Look and the display shows Recorded.
EnterEnter
Up or Down
UpUp
Up or Down
Down to select 3-Look Store
UpUp
DownDown
Down to select the Look number and the display shows Record?
DownDown
To create or modify a Look in stand-alone operation:
1. From the Main Menu, press Up
2. Press Enter
3. Press Enter
Enter, press Up
EnterEnter
Enter and the display shows “CT” and “I” (Color Temperature and Intensity) at the top row and the
EnterEnter
Up or Down
UpUp
Up or Down
Down to select 3-Look Store
UpUp
DownDown
Down to recall the Look number
DownDown
value below
4. Press Up
5. Press and hold Enter
Up or Down
Down to increase or decrease the Intensity value.
UpUp
DownDown
Enter until the display shows Recorded.
EnterEnter
Studio One 100 V User Manual 11 V1.0 September 2015
www.chroma
-
q.com
4-Technical
In this mode,
Software Version is displayed
DMX Data (value) of the channels are displayed
Internal temperature is displayed
The fixture can be set to 4 frequency options. The LED scan rate can be synchronised with the video
camera to avoid a flickering effect.
Frequency options:
750 Hz 1500 Hz 3000 Hz 6000 Hz
Calibration data of the channels are displayed
To display the Software Version,
1. From the Main Menu, press Up
2. Press Enter
Enter, the display shows the Software Version
EnterEnter
Up or Down
Down to access 4-Technical
UpUp
DownDown
To display DMX Data,
1. From the Main Menu, press Up
2. Press Enter
3. Press Enter
Enter, Up
Up or Down
EnterEnter
Enter, the display shows the DMX channel value
EnterEnter
Down and select DMX Data
UpUp
DownDown
Up or Down
Down to access 4-Technical
UpUp
DownDown
To display the temperature of the LED Engine in the fixture,
1. From the Main Menu, press Up
2. Press Enter
3. Press Enter
Enter, Up
Up or Down
EnterEnter
Enter, the display shows the LED Engine Temperature
EnterEnter
Down and select Temperature
UpUp
DownDown
Up or Down
Down to access 4-Technical
UpUp
DownDown
To set the Frequency,
1. From the Main Menu, press Up
2. Press Enter
3. Press Enter
4. Press Enter
Enter, Up
Up or Down
EnterEnter
UpUp
Enter, Up
Up or Down
EnterEnter
UpUp
Enter to save
EnterEnter
Down and select PWM Frequency
DownDown
Down and select a frequency option
DownDown
Up or Down
Down to access 4-Technical
UpUp
DownDown
The display shows Done and returns 4-Technical and then Main Menu.
To display the Calibration data,
1. From the Main Menu
2. Press Enter
Main Menu, press Up
Main MenuMain Menu
Enter, Up
Up or Down
EnterEnter
Down and select Calibration
UpUp
DownDown
Up or Down
Down to access 4-Technical
UpUp
DownDown
3. Calibration data of the channels are displayed
Studio One 100 V User Manual 12 V1.0 September 2015
www.chroma
-
q.com
5-Reset
To reset the fixture to the factory default settings,
1. From the Main Menu, press Up
2. Press Enter
3. Press and hold Enter
All control menu commands are reset to factory defaults:
DMX address 1
Personality CTI
No DMX Present Hold Last
Look Store 1
PWM Frequency 750Hz
Enter, display shows reset?
EnterEnter
Enter for 2 seconds, display shows Hold for 2 sec. and Done after 2 seconds, then
EnterEnter
back to the Main Menu.
Up or Down
Down to access 5-Reset
UpUp
DownDown
2.6 DMX Protocol
DMX Personality:
Studio
Studio One
One 100
OneOne
100 VVVV
100100
StudioStudio
V1.
V1.6666
V1.V1.
Channel 1 Color Temperature Warm White
Channel 2 Intensity Cold White
Total 2 DMX channels 2 DMX channels
1-CTI
[2 ch]
2-WW CW
[2 ch]
2.7 Thermal Performance
The internal cooling system of the Studio One fixture is by convection and built with automatic protection. The fixture’s
automatic protection reduces the output when the internal temperature reaches the maximum limit due to extreme ambient conditions.
3. Troubleshooting
Troubleshooting is a process of elimination. First, rule out the other field factors (i.e. bad connections, faulty cables and power supplies). For technical support and/or parts, please contact your selling dealer or the offices listed in this manual.
Symptom Possible Cause Solution
Fixture does not respond to DMX control.
Low LED output. Internal temperature is over the limit. Check area ventilation.
Set to wrong or different DMX address. Bad cable connecting DMX control and fixture. Bad in/through connection between adjacent fixtures.
Check DMX address and Mode settings. Check/replace DMX run from the console.
Studio One 100 V User Manual 13 V1.0 September 2015
www.chroma
-
q.com
4. Specification
4.1 Technical Specifications
Product Code CHSONE100V Net Dimensions**
(Without Fixings – W x H x D) Net Weight (Without Fixings) 3.8 kg / 8.5 lb Shipping Dimensions – Width x Height x Depth Shipping Weight 5.5 kg / 12 lb Power & Connections Power Supply Built-in Power Input Rating 100-240V AC 50-60Hz 125VA Power Factor 0.5 Power Consumption 58W @ 120/230V AC Idle Power Consumption 3.5W @ 120V AC; 5.6W @ 230V AC Inrush Current 15A @ 120V AC; 36A @ 230V AC Typical Power & Current Measurements done with all LEDs at maximum intensity. Measurements made at nominal
Power connector In/Out powerCon Data Connectors In/Out XLR 5-pin Control Protocol ANSI E1.11 USITT DMX 512-A Cooling System Convection Operating Temperature 0°C to 40°C Construction Cast machined aluminium Colour Black (custom colours available on request) Built-In Hardware Split yoke, 6.25” Accessory Holder IP Rating IP20 Approvals CISPR 15/EN55015& EN61547, FCC Part 15 Subpart B:2012 /
Control & Photometric LED Engines 1 LEDs Per Engine Warm White + Cold White Control Modes 2 channels Color Temperature + Intensity, 2 channels Warm White + Cold White
Dimming Curve Theatrical Wireless Control On / Off, Fade In, Fade Out Hot Lumen Output 2,100 Optics Fully Homogenised Beam Angle 18° (approx) Beam Distribution Symmetrical direct illumination CCT 3,000K - 6,100K CRI 86 Lamp Life L70 at 50,000 hours
For exact measurements please refer to the line drawings below
**
214mm x 267mm x 232mm / 8.5" x 10.5" x 9" (Full open yoke)
406mm x 228mm x 292mm / 16" x 9" x 11.5"
voltage. Allow for a deviation of +/- 10%.
ICES-003:2012, CSA C22.2, UL 1573, IEC 60598
Studio One 100 V User Manual 14 V1.0 September 2015
www.chroma
-
q.com
4.2 Drawings – Dimensions
5. Maintenance
With care, the Studio One 100 requires little maintenance. However, as the unit is likely to be used in a stage environment
we recommend periodical internal inspection and cleaning of any resulting dust and cracked oil residue. If the front enclosure requires cleaning, wipe with a mild detergent on a damp cloth.
Studio One 100 V User Manual 15 V1.0 September 2015
Loading...
