CHiQ CSS602WD User Manual

USER MANUAL

FROST FREE
SIDE BY SIDE FRIDGE

Keep this manual in a safe location and use it for reference.

Read this manual carefully before commencing operation of this appliance,

and comply with the Terms and Conditions.

CSS602WD

CSS601SD

CSS600BD

www.chiq.com.au

ENGLISH

SAFETY INSTRUCTIONS

WARNING!

It is hazardous for anyone other than authorized service personnel to carry out servicing or repairs which involves the

removal of covers. To avoid the risk of an electric shock, do not attempt to repair this appliance yourself.

WARNING!

Risk of fire / flammable materials.

Safety tips

Do not use electrical appliances such as a hair dryer or heater to defrost your Freezer.
Containers with flammable gases or liquids can leak at low temperatures.
Do not store any containers with flammable materials, such as spray cans, fire extinguisher refill cartridges etc. in the

Freezer.

Do not place carbonated or fizzy drinks in the Freezer compartment. Ice lollies can cause “Frost/Freeze burns”. If

consumed straight from the Freezer.

Do not remove items from the Freezer compartment if your hands are damp/wet, as this could cause skin abrasions or

“Frost/Freezer burns”. Bottles and cans must not be placed in the Freezer compartment as they can burst when the
contents freeze.

Manufacturer’s recommended storage times should be adhered to. Refer to relevant instructions.
Do not allow children to tamper with the controls or play with the appliance. The appliance is heavy. Care should be

taken when moving it. It is dangerous to alter the specification or attempt to modify this product in any way.

Do not store inflammable gases or liquids inside your Freezer.

If the power cable is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in

order to avoid a hazard.

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.

This appliance is intended to be used in household and similar applications such as

·staff kitchen areas in shops, offices and other working environments;

·farm houses and by clients in hotels, motels and other residential type environments;

·bed and breakfast type environments;

·catering and similar non-retail applications.

Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by

the manufacturer.

Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of type

recommended by the manufacturer.

Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.Children should be supervised to ensure that they do not play with
the appliance.

– WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
– WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those

recommended by the manufacturer.

– WARNING: Do not damage the refrigerant circuit.
– WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of

the type recommended by the manufacturer.
– WARNING: Refrigerating appliances – in particular a refrigerator-freezer Type I – might not operate consistently
(possibility of defrosting of contents or temperature becoming too warm in the frozen food compartment) when sited for an
extended period of time below the cold end of the range of temperatures for which the refrigerating appliance is designed;
– WARNING:It is necessary that, for doors or lids fitted with locks and keys, the keys be kept out of the reach of children
and not in the vicinity of the refrigerating appliance, in order to prevent children from being locked inside.

– WARNING: The refrigerant used in your appliance and insulation materials requires special disposal procedures.
– WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.

– WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance

Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances.
To avoid contamination of food, please respect the following instructions:

–Opening the door for long periods can cause a significant increase of the temperature in the compartments of the
appliance.

–Clean regularly surfaces that can come in contact with food and accessible drainage systems.
–Clean water tanks if they have not been used for 48 h; flush the water system connected to a water supply if water has

not been drawn for 5 days.

–Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact with or drip onto other food.
–Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or making ice-cream and making ice

cubes.

–One-, two- and three-star compartments are not suitable for the freezing of fresh food.
–If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to

prevent mould developing within the appliance.

Electrical Connection

WARNING

This appliance should be properly grounded for your safety. The power cord of this appliance is equipped with a
three-prong plug which mates with the standard three prong wall outlets to minimize the possibility of electrical shock.
Do not, under any circumstances, cut or remove the third ground prong from the power cord supplied.
This refrigerator appliance requires a standard 220-240VAC 50/60Hzelectrical outlet with three-prong ground.
This refrigerator appliance is not designed to be used with an inverter.
The cord should be secured behind the appliance and not left exposed or dangling to prevent accidental injury.
Never unplug the refrigerator by pulling the power cord. Always grip the plug firmly and pull straight out from the
receptacle.
Do not use an extension cord with this appliance. If the power cord is too short, have a qualified electrician or service
technician install an outlet near the appliance. Use of an extension cord can negatively affect the performance of the unit.
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it
replaced by an authorized service center.

Climate Range

The information about the climate range of the appliance is provided on the rated plate. It indicates at which ambient
temperature (that is, the room temperature in which the appliance is working) the operation of the appliance is optimal
(proper).

Climate range

Permissible ambient temperature

SN

from +10°C to +32°C

N

from +16°C to +32°C

ST

from +16°C to +38°C

T

from +16°C to +43°C

Note：Given the limit values of the ambient temperature range for the climate classes for which the refrigerating appliance
is designed and the fact that the internal temperatures could be affected by such factors as location of the refrigerating
appliance, ambient temperature and the frequency of door opening, the setting of any temperature control device might
have to be varied to allow for these factors, if appropriate.

Locks

If your Refrigerator is fitted with a lock, keep the key out of reach and not in the vicinity of the appliance to prevent children
being entrapped. When disposing of an old Refrigerator, break off any old locks or latches as a safeguard.

Freon-free

The freon-free refrigerant (R600a) and the foaming insulation material (cyclopentane) that is environmentally friendly are
used for the refrigerator, causing no damage to the ozone layer and having very small impact on the global warming.
R600a is flammable, and sealed in a refrigeration system, without leakage during normal use. But, in case of refrigerant
leakage due to the refrigerant circuit being damaged, be sure to keep the appliance away from open flames and open the
windows for ventilation as quickly as possible.

Product Features

This is a side-by-side inverter fridge-freezer adopting the electronic control mode. Its upper part is the fridge compartment
for fresh food storage, such as fruits, vegetables, eggs, milk, cooked foods, etc.; and its lower part is the freezer
compartment where fish, meat, etc. can be frozen for the long-term storage.

★Computer control
Adopting the electronic temperature control, the fridge-freezer is designed with a LED display screen, by which the
temperature of each compartment and the working parameters can be managed and set.
★Inverter technology
Integrated with precise frequency conversion, noise reduction, energy saving, precise temperature control and other
technologies, the fridge-freezer boasts of superior performances. Furthermore, working efficiency of the inverter
compressor can be automatically adjusted according to the ambient temperature and the set temperature, so as to keep
the fridge-freezer operating in its optimal state.
★LECO
The fridge-freezer is internally configured with the LECO device for the net flavor and fresh-keeping purpose, with the
preservation time of fruits and vegetables effectively extended.
★Green technology
The freon-free refrigerant and foaming insulation material are used for the fridge-freezer, causing no damage to the ozone
layer and having a very small impact on the global warming, so it is the environmentally friendly product.
★Stylish appearance
Adopting the optimized man-machine engineering design, the side-by-side refrigerator has an elegant and novel
appearance, and is easy to be opened.
★More user-friendly designs
Such functions as wide working voltage range, automatic temperature control, power-off memory, power-on delay,
automatic alarm, fast freezing, and fridge power-off, etc. are available.

Explosive views

Note: Due to technological innovation, the product descriptions in this manual may not be completely consistent
with your refrigerator. Details are in accordance with the real product.
