USER MANUAL
BAR FRIDGE
Customer Service 1300 796 688
www.chiq.com.au
MODEL
CSR125DW
CSR124DBS
PART NAMES AND LOCATIONS
No Description
1 Chill compartment Door
2 Thermostat
3 Glass Shelf
4 Crisper Cover
5 Crisper
6 Adjustment foot
7 Door Pocket Rack
8 Door Bottom Rack
IN ACCESSORY BAG: USER MANUAL, WARRANTY CARD
As the manufacturer holds the authority to redesign or modify its products without notice:
Any modifications or upgrades of our products will result in this refrigerator varying
slightly from this manual but the functionality will remain the same to that as set out
within this manual.
1
IMPORTANT SAFETY INSTRUCTIONS
Follow these basic precautions to reduce the risk of fire,
WARNING
electrical shock hazards or injury when operating the
refrigerator:
• This product has been designed for using in a normal domestic environment. It is
not intended for commercial use which will avoid warranty, such as supermarket,
food shop, pharmacy, commercial kitchen & etc.
• Persons with lack of experience and knowledge, reduced physical or mental capabilities,
need to be given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
• It is critical use this appliance safely. Read all instructions before operating the
refrigerator and do not attempt to repair or modify this unit in any way as it can cause
harm or void the warranty.
• Please ensure all persons using this appliance are also informed and comply with the
details set out within this manual and the product Terms and Conditions.
• When unpacking the appliance for the first time, keep all cardboard and plastic
packaging out of reach from children.
• Report any notable defects with the appliance to Chiq or retailer as soon as it is noted.
Failure to do so can result in a non-warranty claim. Keep all packaging materials in a
safe location until the unit has been installed properly.
• If the supplied power cord of this unit is damaged, it must be replaced by qualify
service agent or similarly qualified persons in order to avoid any risk of injury. It is
recommended the power cord is situated in a safe location when operating or
transporting the appliance to prevent any damage that may cause electrical shock or
fire hazards.
• DANGER or WARNING:
Service of this unit
The installation or any service of the appliance is recommended by a qualified technician
or service company.
Ventilation Hazards
Never clean the refrigerator or refrigerator parts with flammable fluids, or store gasoline
or any other flammable vapors and liquids in the vicinity of this or any other
refrigerator as the gas and/or vapour can cause a fire hazard, explosion or inhalation.
Electrical Connection
Make certain, when installing or moving the unit that the power outlet has been
connected to, has been fitted by a qualified electrician and the ground wire has been
connected properly to meet the Australian Electrical Standards.
2
R600a WARNINGS
NOTE: This model uses R600a flammable refrigerant in its sealed system.
The following must be observed for your safety:
R600a Refrigerant Warning
• This appliance contains 0.023kg R600a refrigerant which is
environmentally friendly, but flammable. It does not damage the ozone
layer, nor does it increase the greenhouse effect.
• During transportation and installation, ensure that the tubing of the
refrigerant circuit is not damaged.
• Leaking refrigerant can ignite and may damage the eyes.
• In the event any damage does occur, avoid exposure to open fires and
any device which creates a spark. Disconnect the appliance from the
mains power.
• Thoroughly ventilate the room in which the appliance is located for
several minutes.
• Notify Customer Service for necessary action and advice.
• The room for installing the appliance must be at least 1 cubic metre per
8 grams of refrigerant. The refrigerant quantity contained in this
appliance is listed above in grams; it is also noted on the Rating Plate of
the appliance.
* Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
It is hazardous for anyone other than an Authorised Service Person to carry out
servicing or repairs to this appliance. In Queensland the authorized person must
hold a Gas Work Authorisation for hydrocarbon refrigerants, before carrying out
servicing or repairs which involve the removal of covers.
1. Keep ventilation openings, in the appliance enclosure or in the built-in structure,
clear of obstruction.
2. Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
3. Do not damage the refrigerant circuit.
4. Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
5. Do not store explosive substances such as aerosol cans with a flammable propellant
in the appliance.
Disposal
The environment and personal safety must be considered when disposing of this
appliance. Please ensure the appliance is taken to a recycle center for safe recycling. DO
NOT dispose of the appliance in land fill as the insulation and refrigerant gas contained
in these appliances are flammable.
