USER MANUAL
UPRIGHT FREEZER
Customer Service 1300 796 688
www.chiq.com.au
MODEL
CSF166NW
CSF165NSS
PART NAMES AND LOCATIONS
No
Description
1
Control panel
2
Flip cover
3
Freezer drawers
4
Adjustable Feet
IN ACCESSORY BAG: USER MANUAL, WARRANTY CARD
As the manufacturer holds the authority to redesign or modify its products without notice:
Any modifications or upgrades of our products will result in this Freezer varying slightly
from this manual but the functionality will remain the same to that as set out within this
manual.
1
IMPORTANT SAFETY INSTRUCTIONS
Follow these basic precautions to reduce the risk of fire,
WARNING
electrical shock hazards or injury when operating the
Freezer:
• This product has been designed for using in a normal domestic environment. It is
not intended for commercial use which will avoid warranty, such as supermarket,
food shop, pharmacy, commercial kitchen & etc.
• Persons with lack of experience and knowledge, reduced physical or mental capabilities,
need to be given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
• It is critical use this appliance safely. Read all instructions before operating the Freezer
and do not attempt to repair or modify this unit in any way as it can cause harm or
void the warranty.
• Please ensure all persons using this appliance are also informed and comply with the
details set out within this manual and the product Terms and Conditions.
• When unpacking the appliance for the first time, keep all cardboard and plastic
packaging out of reach from children.
• Report any notable defects with the appliance to Chiq or retailer as soon as it is noted.
Failure to do so can result in a non-warranty claim. Keep all packaging materials in a
safe location until the unit has been installed properly.
• If the supplied power cord of this unit is damaged, it must be replaced by qualify
service agent or similarly qualified persons in order to avoid any risk of injury. It is
recommended the power cord is situated in a safe location when operating or
transporting the appliance to prevent any damage that may cause electrical shock or
fire hazards.
• DANGER or WARNING:
Service of this unit
The installation or any service of the appliance is recommended by a qualified technician
or service company.
Ventilation Hazards
Never clean the Freezer or Freezer parts with flammable fluids, or store gasoline or any
other flammable vapors and liquids in the vicinity of this or any other Freezer as the
gas and/or vapour can cause a fire hazard, explosion or inhalation.
Electrical Connection
Make certain, when installing or moving the unit that the power outlet has been
connected to, has been fitted by a qualified electrician and the ground wire has been
connected properly to meet the Australian Electrical Standards.
2
R600a WARNINGS
NOTE: This model uses R600a flammable refrigerant in its sealed system.
The following must be observed for your safety:
R600a Refrigerant Warning
• This appliance contains 0.043kg R600a refrigerant which is
environmentally friendly, but flammable. It does not damage the ozone
layer, nor does it increase the greenhouse effect.
• During transportation and installation, ensure that the tubing of the
refrigerant circuit is not damaged.
• Leaking refrigerant can ignite and may damage the eyes.
• In the event any damage does occur, avoid exposure to open fires and
any device which creates a spark. Disconnect the appliance from the
mains power.
• Thoroughly ventilate the room in which the appliance is located for
several minutes.
• Notify Customer Service for necessary action and advice.
• The room for installing the appliance must be at least 1 cubic metre per
8 grams of refrigerant. The refrigerant quantity contained in this
appliance is listed above in grams; it is also noted on the Rating Plate of
the appliance.
* Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
It is hazardous for anyone other than an Authorised Service Person to carry out
servicing or repairs to this appliance. In Queensland the authorized person must
hold a Gas Work Authorisation for hydrocarbon refrigerants, before carrying out
servicing or repairs which involve the removal of covers.
1. Keep ventilation openings, in the appliance enclosure or in the built-in structure,
clear of obstruction.
2. Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
3. Do not damage the refrigerant circuit.
4. Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
5. Do not store explosive substances such as aerosol cans with a flammable propellant
in the appliance.
Disposal
The environment and personal safety must be considered when disposing of this
appliance. Please ensure the appliance is taken to a recycle center for safe recycling. DO
NOT dispose of the appliance in land fill as the insulation and refrigerant gas contained
in these appliances are flammable.
3
Door reversal instruction
There is no spare parts required for door reversal job.
The following tool is required, flat screwdriver, phillips screwdriver, adjustable spanner,
socket wrench and 8mm socket.
1. Make sure the power cable is unplugged.
2. Remove the hinge cover with a flat screwdriver, remove the three screws that hold the
upper hinge on the door, then remove the upper hinge.
3. Lift up the door and remove it from the cabinet, keep it on a stable position.
4. Remove the screws that secure the lower hinge, then remove the hinge.
5. Remove the washer and nut that secure the pin shaft to the right hole on the lower
hinge, then remove the shaft
6. Insert the pin shaft into the left hole on the lower hinge, then secure the shaft with
the washer and nut.
7.Install the lower hinge on the left side of the cabinet.
8. Remove the screw that secures the door stop from the bottom right of the freezer
compartment door, then remove the door stop and install to the bottom left side.
9. Install the freezer compartment door.
10. Move the door bushing from the top right side of the freezer door to the top left side
of the door. And move the left hole cover to the right side.
4
11. Remove the screw that secures the hinge screw hole cover from the top left side of
the cabinet and put it on the right side.
12. Secure the upper hinge with the three screws. Before you tighten the upper hinge
screws, make sure the door is level with the cabinet and rubber gasket has a good seal.
13. Install the hinge cover over the hinge on the top left side of the cabinet.
14. Remove the left screw caps and screws in handle, remove the right hole plugs.
15. Install the right hole plugs on the left side, and install the handle on the right, put
screw caps back on.
5
INSTALLATION INSTRUCTIONS
Before Using the Freezer
• Remove the exterior and interior packing.
• Before connecting the Freezer to a power source, let the unit stand upright for
approximately 4 hours to mitigate the possibility of a malfunction in the cooling
system from improper handling during transportation.
• Clean the interior surface with warm water using a soft cloth.
Installing the Freezer
• This appliance is designed to be free standing only, and should not be recessed or
built-in.
• Allow at least 5cm of space between the back and sides of the Freezer to allow
proper air ventilation. Insufficient space will result in cooling and working life issue
and voiding warranty.
• Place the Freezer on a leveled/even floor surface that is strong enough to support
the weight of the Freezer when it is fully loaded to prevent vibrations.
• Place the Freezer on a concrete, tile floor or waterproof floor is recommended.
The fridge will produce defrost water or condensation moisture, it might cause
water damage in some extreme circumstances.
• The front feet can be adjusted to level the appliance properly. Adjust the two
front feet to keep the Freezer leveled or elevated.
• Situate the Freezer away from direct sunlight and sources of direct heat (stove, heater,
radiator, etc.). Direct sunlight may also affect the acrylic coating and heat sources
may cause an increase power consumption.
• This unit is not designed for outside installation.
• Avoid situating the Freezer in moist OR pest infestation areas.
• Plug the Freezer into dedicated, properly installed-grounded wall outlet. Do not under
any circumstances cut or remove the third (ground) prong from the power cord. Any
questions concerning power and/or grounding should be directed toward a certified
electrician or an authorized service center.
• After plugging the appliance into a wall outlet, turn the unit on and allow the unit to
cool down for 4-6 hours before placing food in the Freezer.
• Do not place heavy items on the top of this appliance.
ENERGY SAVING TIPS
• Allow hot foods to cool to room temperature before placing in the Freezer. Overloading
the Freezer forces the compressor to work harder. Foods that freeze too slowly may
lose quality, or spoil.
• Be sure to wrap foods properly, and wipe containers dry before placing them in the
Freezer. This cuts down on frost build-up inside the Freezer.
• Organize and label food to reduce door openings and extended searches. Remove as
many items as needed at one time, and close the door as soon as possible.
6
OPERATING INSTRUCTIONS
TEMPERATURE CONTROL PANEL
The freezer has temperature control panel on the top.
Temperature control key:
Press the set key to adjust temperature setting. Keep pressing until it reaches desired
temperature and the number will flashing on display panel. Wait for few seconds, it
will be light up stable and setting is changed properly.
-18 is recommend for normal use environment.
Temperature adjustment range:-16~-24。
The digital display is cycled as follows: -16→-…→-24→ -16.
The number only shows the setting temperature which might vary to the exact
temperature inside the unit.
Fast freezing mode :
When fast freezing mode is active, the will show on the display area.
Fast freezing mode is recommended for the first time use or food need to be frozen
quickly.
After the freezer runs in fast freezing mode for 3 hours, it will quit the fast freeze
mode automatically.
Notes
Large quantities of food stored in the appliance or directly in front of the air vent
will affect the cooling efficiency and the airflow.
Please allow 6 hours for temperature to stabilize between temperature setting
changes.
Do not keep opening and closing the door which will increase the temperature in
the unit.
Please note different sections of Freezer compartment may be warmer or
cooler than others – typically the back wall and bottom lowest drawer will
be the coolest area.
7
Door open alarm
If any door is opened for more than 3 minutes, buzzer alarm will be continuously
beeping. It can be stopped by pressing key button, but it will be restored after 3 minutes
if the door keeps opening.
The alarm will stop when the doors are closed properly.
Fault alarm
When the alarm indicator keeps flashing (with the corresponding indicator light of “-16, 20, -24, or fast freezing” flickering simultaneously), it indicates fault with the refrigerator.
Please contact customer service centre.
GENERAL CARE AND MAINTENANCE
Cleaning the Freezer
• Upon installation of your new appliance, it is recommended that it be cleaned
thoroughly and properly maintained thereafter.
• Turn off the Freezer and then unplug the unit from the wall outlet.
• Remove all food content before washing the inside with a damp cloth soaked in
lukewarm water and dishwasher liquid. Don’t use any chemical detergent which
might damage coating of the freezer.
• Be sure to keep the door gasket (seal) clean to keep the unit running efficiently as
improper cleaning can cause the seal to dislodge and tear.
• Dry the interior and exterior with a soft cloth.
Vacation Time
• Turn off the Freezer first and then unplug the unit from the power point.
• Remove all food.
• Clean the Freezer.
• Leave the lid open slightly to avoid possible formation of condensation, mold, or odors.
• Use extreme caution in the case of children. The unit should not be accessible to
child’s play.
• Short vacations: Leave the Freezer operating during vacations of less than three
weeks.
• Long vacations: If the appliance will not be used for several months, remove all food
and unplug the power cord. Clean and dry the interior thoroughly. To prevent odour
and mold growth, leave the door open slightly: blocking it open if necessary.
8
Repositioning and Relocating the Freezer
• Unplug the power cord from the wall outlet.
• Remove all the food and drinks.
• Securely tape down all loose items inside your Freezer.
• Tape the doors to be closed securely.
• It is recommended that the Freezer stays in the upright position during
transportation. But if it is laid down for transport purpose, please lift it up
immediately after the job is done. Please wait for at least 24 hours before putting the
power.
TROUBLESHOOTING GUIDE
Problem
The freezer has no power
Compressor runs all the
time
Temperature inside the
Freezer is too cold.
Solution
Power cord isn’t plugged in properly.
The circuit breaker tripped or a blown fuse.
Try a different power point.
The room temperature is hotter than normal.
A large amount of food has been added to the Freezer.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The Freezer does not have the correct clearances.
The Freezer has recently been disconnected for a period
of time. 6+ hours are required for the Freezer to cool
down completely pending on operating conditions.
Temperature control is set too cold. Turn the control to a
warmer setting and allow several hours for the
temperature to stabilize.
Temperature of external
Freezer side walls are
warm.
The exterior Freezer walls can be as much as 15-20
degrees warmer than room temperature.
This is normal while the compressor works to transfer
heat from inside the Freezer cabinet to the condenser
behind the Freezer side walls.
9
Popping or cracking sound
when compressor comes on.
Metal parts undergo expansion and contraction, as in
hot water pipes. This is normal. Sound will level off or
disappear as Freezer continues to run.
Bubbling or gurgling sound,
like water boiling.
Vibrations.
Moisture forms on outside
of Freezer.
The doors will not close
properly.
Refrigerant (used to cool Freezer) is circulating
throughout the system. This is normal operation.
Check the Freezer is on a level/even surface.
Freezer rocks on the floor when it is moved slightly. Be
sure floor can adequately support Freezer.
Level the Freezer by putting wood or metal shims under
part of the Freezer.
The Freezer is touching the wall. Re-level the Freezer and
move it from the wall. See “Installation Instructions”.
Door is slightly open, causing cold air from inside the
Freezer to meet warm moist air from the outside.
The Freezer is not on a level surface.
The gasket/s may be dirty or not properly maintained.
Clean the seals and make sure they are dry before
closing the door/s.
The storage basket and/or shelves are out of position.
For any enquiries, please call the CHiQ Cusotmer care on: 1300 796 688
Customer Service
1300 796 688
www.chiq.com.au
c
Changhong Electric (Australia) P/L all rights reserved.
Loading...
