USER MANUAL
FROST FREE
BOTTOM MOUNTED REFRIGERATOR
Keep this manual in a safe location and use it for reference.
Read this manual carefully before commencing operation of this appliance,
and comply with the Terms and Conditions.
www.chiq.com.au
ENGLISH
CBM430B
1
PART NAMES AND LOCATIONS
No
Description
1
Light
2
Lighting switch
3
Cooling room shelves
4
Vegetable and fruit crisper
cover
5
Vegetable and fruit crisper
6
Freezing drawers
7
Door balcony
IN ACCESSORY BAG: USER MANUAL, WARRANTY CARD & DOOR STOPPER (small
plastic parts for door reverse purpose ONLY)
As the manufacturer holds the authority to redesign or modify its products without notice:
Any modifications or upgrades of our products will result in this refrigerator varying slightly from this
manual but the functionality will remain the same to that as set out within this manual.
2
IMPORTANT SAFETY INSTRUCTIONS
WARNING
Follow these basic precautions to reduce the risk of fire,
electrical shock hazards or injury when operating the
refrigerator:
It is critical use this appliance safely. Read all instructions before operating the refrigerator
and do not attempt to repair or modify this unit in any way as it can cause harm or void the
warranty.
Please ensure all persons using this appliance are also informed and comply with the
details set out within this manual and the product Terms and Conditions.
When unpacking the appliance for the first time, keep all cardboard and plastic packaging
out of reach from children and report any notable defects with the appliance to Changhong
or retailer as soon as it is noted. Failure to do so can result in a non-warranty claim. Keep all
packaging materials in a safe location until the unit has been properly installed.
If the supplied power cord of this unit is damaged, it must be replaced by the manufacturer
or its service agent or similarly qualified persons in order to avoid any risk of injury. It is
recommended the power cord is situated in a safe location when operating or transporting
the appliance to prevent any damage that may cause electrical shock or fire hazards. DO
NOT unplug the appliance without switching the unit off from the outlet first or by yanking
the cord.
This appliance is intended to be used in a domestic household or similar applications such as:
- Staff areas in shops and offices, hotels, motels and other residential type environments;
- Catering and similar non-retail applications.
DANGER or WARNING: Risk of Child Entrapment.
If discarding this unit, follow these simple precautions:
- Remove the door/s from the unit.
- Leave the shelves in place so that children may not easily climb inside.
- Never allow children to operate, play with, or crawl inside the refrigerator.
- Children should be supervised near the unit at all times.
- This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by persons responsible for
their safety.
- Children should be supervised not to play with the appliance.
- Only dispose of this appliance at an authorized waste disposal centre.
DANGER or WARNING: Ventilation Hazards
- Never clean the refrigerator or refrigerator parts with flammable fluids, or store gasoline or
any other flammable vapors and liquids in the vicinity of this or any other refrigerator as the
gas and/or vapour can cause a fire hazard, explosion or inhalation.
Electrical Connection
Make certain, when installing or moving the unit that the power outlet has been connected
to, has been fitted by a qualified electrician and the ground wire has been connected
properly to meet the Australian Electrical Standards.
3
R600a WARNINGS
NOTE: This model uses R600a flammable refrigerant in its sealed system.
The following must be observed for your safety:
R600a Refrigerant Warning
• This appliance contains 0.053kg R600a refrigerant which is environmentally
friendly, but flammable. It does not damage the ozone layer, nor does it
increase the greenhouse effect.
• During transportation and installation, ensure that the tubing of the refrigerant
circuit is not damaged.
• Leaking refrigerant can ignite and may damage the eyes.
• In the event any damage does occur, avoid exposure to open fires and any
device which creates a spark. Disconnect the appliance from the mains
power.
• Thoroughly ventilate the room in which the appliance is located for several
minutes.
• Notify Customer Service for necessary action and advice.
• The room for installing the appliance must be at least 1 cubic metre per 8
grams of refrigerant. The refrigerant quantity contained in this appliance is
listed above in grams; it is also noted on the Rating Plate of the appliance.
* Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
It is hazardous for anyone other than an Authorised Service Person to carry out
servicing or repairs to this appliance. In Queensland the authorized person must hold a
Gas Work Authorisation for hydrocarbon refrigerants, before carrying out servicing or
repairs which involve the removal of covers.
1. Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of
obstruction.
2. Do not use mechanical devices or other means to accelerate the defrosting process, other
than those recommended by the manufacturer.
3. Do not damage the refrigerant circuit.
4. Do not use electrical appliances inside the food storage compartments of the appliance,
unless they are of the type recommended by the manufacturer.
5. Do not store explosive substances such as aerosol cans with a flammable propellant in the
appliance.
Disposal
The environment and personal safety must be considered when disposing of this appliance.
Please ensure the appliance is taken to a recycle center for safe recycling. DO NOT dispose
of the appliance in land fill as the insulation and refrigerant gas contained in these appliances
are flammable.
4
INSTALLATION INSTRUCTIONS
Before Using the Refrigerator
Remove the exterior and interior packing.
Before connecting the refrigerator to a power source, let the unit stand upright for
approximately 4 hours to mitigate the possibility of a malfunction in the cooling system from
improper handling during transportation.
Clean the interior surface with lukewarm water using a soft cloth. (Refer to the cleaning
instruction on page 5)
Installing the Refrigerator
This appliance is designed to be free standing only, and should not be recessed or built-in.
Place the refrigerator on a leveled/even floor surface that is strong enough to support the
weight of the refrigerator when it is fully loaded to prevent vibrations and allow water to
properly drain. The front feet can be adjusted to level the appliance properly.
The leveling feet should only be used in forward and backward motions and never side to
side.
Allow at least 5cm of space between the back and sides of the refrigerator to allow
proper air ventilation. Adjust the two front feet to keep the refrigerator leveled or elevated.
Situate the refrigerator away from direct sunlight and sources of direct heat (stove, heater,
radiator, etc.). Direct sunlight may also affect the acrylic coating and heat sources may
cause an increase electrical consumption. Ambient temperature below 50°F or above 85°F
will hinder the performance of this appliance.
This unit is not designed for outside installation.
Avoid situating the refrigerator in moist OR pest infestation areas.
Plug the refrigerator into dedicated, properly installed-grounded wall outlet. Do not under
any circumstances cut or remove the third (ground) prong from the power cord. Any
questions concerning power and/or grounding should be directed toward a certified
electrician or an authorized service center.
After plugging the appliance into a wall outlet, turn the unit on and allow the unit to cool
down for 2~3 hours before placing food in the refrigerator or freezer compartment.
Do not place items on the top of this appliance.
ENERGY SAVING TIPS
Allow hot foods to cool to room temperature before placing in the refrigerator. Overloading
the refrigerator forces the compressor to work harder. Foods that freeze too slowly may
lose quality, or spoil.
Do not adjust the temperatures colder than necessary. Refer to page 4 for temperature
instructions.
Be sure to wrap foods properly, and wipe containers dry before placing them in the
refrigerator. This cuts down on frost build-up inside the refrigerator.
Organize and label food to reduce door openings and extended searches. Remove as
