CHINA ELECTRONICS SPB60 User Manual

WELCOME

Fast Start Instruction

Welcome to use SPB60 super Bluetooth speaker, to use the device correctly, please read this instruction very
carefully before use.

Product Specification

Bluetooth version: Bluetooth V2.1+EDR
Working distance: support wireless music within 10m, working distance may be different

with different environment and Bluet oo th dev ice .
Built-in battery: 1200mAh
RMS: 1.6W*2
Rated Voltage: DC5V
Audio input: 3.5mm
Speaker weight: 480g
Speaker size: 186*58*58mm

Package list:

Speaker: 1 User manual: 1 USB cable: 1 Warranty card: 1 Aux-in cable: 1

Product Indicators:

1、Microphone 7、Hands free
2、Bluetooth/AUX mode indicator 8、Power
3、Volume down 9、Charging indicator
4、Volume up 10、AUX input jack
5、Pause 11、Micro USB charging socket
6、Bluetooth pair

Fast Learning

Picture 1: Turn the power button to 'ON', when the blue indicator flashes slowly, the device is pairing with the
latest paired device.
Picture 2: Searching Bluetooth device when speak er is on, device is pairi ng when the blue indicato r flash quickly;
device is connected when the blue indicator is bright constantly.
Picture 3: Play audio with phones.

Buttons:

1. long press, device sounds when volume is up; short press, next track.

2.

short press, device sounds when volume is down; short press, prev track.
