CHINA ELECTRONICS BT2610 User Manual

BT2610U

Product Specification:

Main parameter:

•output power：5W×2

•frequency response：75hz-18khz

•RMS：（ THD = 10%）

•drive：1.5’× 2

•power supply：DC 5V

•distortion：≦1%

•S / N：≥ 65dB

•battery capacity：2000mAh/3.6V-4.2V

•battery working time：2.5-3hours (play as the max Volume)

•battery charging time：2.5-3 hours

•size：L336 *w61.5 * h61.5mm

•N.W.：790g

Packing Contents:

1、the quake blue-tooth speaker
2、user’s manual
3、USB charging cable
4、3.5mm stereo cable

Charging the Speaker:

Before using the speaker for the first time, charging it for at least 2 hours.
1、Plug the USB cable into the port on the speaker, plug the other end into the USB port on the adapter(5V).
2、Red LED will turn on to indicate that the unit is charging.
3、Red LED will turn off when fully charged.

Start-up& Shutdown Functions:

1、Long press POWER to start the blue-tooth speaker.
2、Trumpet emit and alternating flashing blue LED.(蓝色 LED 快速闪烁）
3、Long press POWER to shutdown the blue-tooth speaker.
4、Blue LED off if shutdown the speaker.

Pairing the Device:

1、Place the speaker near the Blue-tooth-enabled device.

2、Long press POWER to start the blue-tooth speaker, alternating flashing blue LED（蓝色 LED 快速闪烁）, the speaker is now
in pairing mode.

3、Follow the instructions of your device to search for the speaker.
4、The speaker is called “BT2016U”, enter the PIN”0000” if need.
5、The blue LED will turn on and trumpet emit when pairing is complete.
6、The speaker is in the state of pairing the last device default in the first 3 seconds after starting. If failing to pair, the
speaker will be in state of pairing automatically.

LED Indicator

1、Charging: Red LED on
2、Fully charged: Red LED off
3、Pairing Mode: alternating flashing blue
4、4、Connected: Blue LED will flash slowly(flash 1 time/1-2 seconds)
5、Line IN Mode: Blue LED will flash slowly

Safety and General Information:

1、Do not expose the device to water or attempt to disassemble the device. If the device is exposed to water or disassembled,
the user may be risking an electronic short.
2、Do not use this products in an aircraft or in hospital.
3、Do not expose the device to direct sunlight, heat and flame.
4、Device may be warm while charging. It is normal.
5、Changes or modifications to this equipment not expressly approved by the party responsible for compliance could avoid the
user’s authority to operate the equipment.

Key’s Sketch Map:

② ③

① ⑤ ④
