CHIMEI INNOLUX V315HH6-LS1 Specification

Global LCD Panel Exchange Center

MODEL NO.: V315HH6

www.panelook.com

PRODUCT SPECIFICATION

ϭʳ Tentative Specification
ϮϮϮϮʳ Preliminary Specification
ϭʳ Approval Specification

SUFFIX: LS1

Customer:

APPROVED BY SIGNATURE

Name / Title

Note

Please return 1 copy for your confirmation with your
signature and comments.

Approved By Checked By Prepared By

Chao-Chun Chung

Version 1.3 1 Date

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

Vincent Chou Samuel Huang

ΚΚΚΚ

11 Feb., 2011

www.panelook.com

Global LCD Panel Exchange Center

www.panelook.com

PRODUCT SPECIFICATION

CONTENTS

1. GENERAL DESCRIPTION...................................................................................................................................................5

1.1 OVERVIEW....................................................................................................................................................5

1.2 FEATURES ....................................................................................................................................................5

1.3 APPLICATION................................................................................................................................................5

1.4 GENERAL SPECIFICATIONS ........................................................................................................................5

1.5 MECHANICAL SPECIFICATIONS ..................................................................................................................6

2.1 ABSOLUTE RATINGS OF ENVIRONMENT....................................................................................................6

2.2 PACKAGE STORAGE ....................................................................................................................................7

2.3 ELECTRICAL ABSOLUTE RATINGS..............................................................................................................7

2.3.1 TFT LCD MODULE...............................................................................................................................7

2.3.2 BACKLIGHT CONVERTER UNIT .........................................................................................................7

3. ELECTRICAL CHARACTERISTICS ................................................................................................................................... 8

3.1 TFT LCD MODULE........................................................................................................................................8

3.2 BACKLIGHT CONNECTOR PIN CONFIGURATION..................................................................................... 11

4. BLOCK DIAGRAM OF INTERFACE................................................................................................................................ 15

4.1 TFT LCD MODULE.......................................................................................................................................15

5. INPUT TERMINAL PIN ASSIGNMENT ..........................................................................................................................16

5.1 TFT LCD Module Input .................................................................................................................................16

5.2 BACKLIGHT UNIT........................................................................................................................................ 21

5.3 CONVERTER UNIT......................................................................................................................................21

5.4 BLOCK DIAGRAM OF INTERFACE .............................................................................................................23

5.5 LVDS INTERFACE .......................................................................................................................................25

5.6 COLOR DATA INPUT ASSIGNMENT............................................................................................................26

6. INTERFACE TIMING......................................................................................................................................................... 27

6.1 INPUT SIGNAL TIMING SPECIFICATIONS..................................................................................................27

6.2 POWER ON/OFF SEQUENCE.....................................................................................................................31

7. OPTICAL CHARACTERISTICS ........................................................................................................................................ 33

7.1 TEST CONDITIONS .....................................................................................................................................33

7.2 OPTICAL SPECIFICATIONS ........................................................................................................................34

Version 1.3 2 Date

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

ΚΚΚΚ

11 Feb., 2011

www.panelook.com

Global LCD Panel Exchange Center

www.panelook.com

PRODUCT SPECIFICATION

PRECAUTIONS...................................................................................................................................................................... 39

8.1 ASSEMBLY AND HANDLING PRECAUTIONS .............................................................................................39

8.2 SAFETY PRECAUTIONS............................................................................................................................. 39

9. DEFINITION OF LABELS..................................................................................................................................................40

9.1 CMI MODULE LABEL...................................................................................................................................40

10. PACKAGING ....................................................................................................................................................................41

10.1 PACKAGING SPECIFICATIONS.................................................................................................................41

10.2 PACKAGING METHOD .............................................................................................................................. 41

11. MECHANICAL CHARACTERISTIC ..............................................................................................................................43

Version 1.3 3 Date

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

ΚΚΚΚ

11 Feb., 2011

www.panelook.com

Global LCD Panel Exchange Center

Version Date Page(New) Section Description
Ver. 1.0

1.1

1.2

1.3

17 Nov., 2010
18 Nov., 2010

10 Dec., 2010

11 Feb., 2011

All
11
11

12
6

11

27
28
30
31
34

37
8
11
27
28
37
38

www.panelook.com

PRODUCT SPECIFICATION

REVISION HISTORY

All

3.2.1

3.2.2

1.5

3.2.1

3.2.2

6.1.1

6.1.2

6.1

6.2.2

7.2

7

3.1

3.2.2

6.1.1

6.1.2

7.2

7.2

The preliminary specification was first issued.
Note(1): IL: 120 mA  130 mA
Revise converter 2D mode power consumption:
Typ: 45  (50) Max: 51.8  (57.5)
Revise converter 2D mode input current: 2.08  (2.04)
Revise input inrush current, 3D mode: 9.5  (6.67),
IL: 3*typ  2*typ
Note(3): Specify for 2D mode duration
Revise note(6) test condition drawing
Depth(3) Min 34.925,Typ. 35.926, Max. 36.927;
Add depth(4) item
Weight: TBD  4540 g
One string voltage: Max.: 45.5  47.45
Power consumption: Pbl(3D): Typ.: (21.6)(24.0),
Max: (24.8)(27.6)
Converter input current: Ibl(3D):Typ.: (0.9)(1.0),
Max: (1.03)(1.15)
Add column “Frame rate”
Add column “Frame rate”
Note(6) add 3D horizontal timing requirement
New added
Center Luminance: Min: -  (350)
Add 3D Luminance: Typ : (45)
Modify Color chromaticity R,G,B coordinates
Add column “Transmission direction of up polarizer”
Add note(7) and note(8)
Rush current: (3)  (4)
Update note(3) description
Vertical active display term: 3D, Total : 1524  1400
Vertical active display term: 3D, Total : 1524  1400
Update note(7) TN mode shutter glass reference drawing
Update note(8) 3D mode measurement illustration

Version 1.3 4 Date

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

ΚΚΚΚ

11 Feb., 2011

www.panelook.com

Global LCD Panel Exchange Center

1. GENERAL DESCRIPTION

1.1 OVERVIEW

V315HH6-LS1 is a 31.5” TFT Liquid Crystal Display module with LED Backlight unit and 4ch-LVDS interface. This

module supports 1920 x 1080 Full HDTV format and can display 16.7M colors (8-bit). The converter module for

backlight is built-in.

1.2 FEATURES

Ё High brightness (400 nits)

Ё High contrast ratio (1000 :1)

Ё Fast response time (3ms)

Ё High color saturation (NTSC 72%)

Ё Full HDTV (1920 x 1080 pixels) resolution, true HDTV format

Ё DE (Data Enable) only mode
