CHIMEI INNOLUX N156BGE-EA1 Specification

PRODUCT SPECIFICATION

Customer:

Doc. Number:

□ Tentative Specification
▓ Preliminary Specification
□ Approval Specification

MODEL NO.: N156BGE

SUFFIX: EA1

APPROVED BY SIGNATURE

Name / Title

Note

Please return 1 copy for your confirmation with your
signature and comments.

Approved By Checked By Prepared By

楊竣傑

2012-12-17

16:51:26 CST

曹文彬

2012-12-05

13:41:06 CST

蔡百琪

2012-11-27

19:39:21 CST

Version 1.0 01 October 2012 1 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

CONTENTS

1. GENERAL DESCRIPTION.........................................................................................................4

1.1 OVERVIEW ................................................................................................................................4

1.2 GENERAL SPECIFICATI0NS ...................................................................................................4

2. MECHANICAL SPECIFICATIONS .............................................................................................4

2.1 CONNECTOR TYPE..................................................................................................................5

3. ABSOLUTE MAXIMUM RATINGS .............................................................................................5

3.1 ABSOLUTE RATINGS OF ENVIRONMENT ..........................................................................5

3.2 ELECTRICAL ABSOLUTE RATINGS......................................................................................6

3.2.1 TFT LCD MODULE............................................................................................................6

4. ELECTRICAL SPECIFICATIONS...............................................................................................7

4.1 FUNCTION BLOCK DIAGRAM...............................................................................................7

4.2. INTERFACE CONNECTIONS .................................................................................................7

4.3 ELECTRICAL CHARACTERISTICS........................................................................................9

4.3.1 LCD ELETRONICS SPECIFICATION...............................................................................9

4.3.2 LED CONVERTER SPECIFICATION..............................................................................11

4.3.3 BACKLIGHT UNIT...........................................................................................................13

4.4 DISPLAY PORT SIGNAL TIMING SPECIFICATION...........................................................14

4.4.1 DISPLAY PORT INTERFACE ..............................................................................................14

4.4.3 COLOR DATA INPUT ASSIGNMENT ............................................................................15

4.5 DISPLAY TIMING SPECIFICATIONS ...................................................................................16

4.6 POWER ON/OFF SEQUENCE ................................................................................................17

5. OPTICAL CHARACTERISTICS ...............................................................................................19

5.1 TEST CONDITIONS.................................................................................................................19

5.2 OPTICAL SPECIFICATIONS ..................................................................................................19

6. RELIABILITY TEST ITEM ........................................................................................................22

7. PACKING..................................................................................................................................23

7.1 MODULE LABEL ....................................................................................................................23

7.2 CARTON...................................................................................................................................24

8. PRECAUTIONS........................................................................................................................26

8.1 HANDLING PRECAUTIONS..................................................................................................26

8.2 STORAGE PRECAUTIONS ....................................................................................................26

8.3 OPERATION PRECAUTIONS.................................................................................................26

Appendix. EDID DATA STRUCTURE...........................................................................................27

Appendix. OUTLINE DRAWING..................................................................................................30

Version 1.0 01 October 2012 2 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

REVISION HISTORY

Version

1.0 Oct. 01, 2012 All Spec Ver.1.0 was first issued.

Date Page Description

Version 1.0 01 October 2012 3 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

1. GENERAL DESCRIPTION

1.1 OVERVIEW

PRODUCT SPECIFICATION

N156BGE-EA1 is a 15.6” (1

5.547

” diagonal) TFT Liquid Crystal Display module with LED Backlight
unit and 30 pins eDP interface. This module supports 1366 x 768 HD mode and can display
262,144 colors. The optimum viewing angle is at 6 o’clock direction.

1.2 GENERAL SPECIFICATI0NS

Item Specification Unit Note
Screen Size 15.547” diagonal
Driver Element a-si TFT active matrix - ­Pixel Number 1366 x R.G.B. x 768 pixel ­Pixel Pitch 0.252 (H) x 0.252 (V) mm ­Pixel Arrangement RGB vertical stripe - ­Display Colors 262,144 color ­Transmissive Mode Normally white - ­Surface Treatment Hard coating (3H), Anti-Glare - ­Luminance, White 200 Cd/m2
Power Consumption Total (2.86W) (Max.)@cell (1.0 W) (Max.), BL (1.86W) (Max.) (1)

Note (1) The specified power consumption (with converter efficiency) is under the conditions at VCCS =

3.3 V, fv = 60 Hz, LED_VCCS = Typ, fPWM = 200 Hz, Duty=100% and Ta = 25 ± 2 ºC, whereas mosaic
pattern is displayed.

2. MECHANICAL SPECIFICATIONS

Item Min. Typ. Max. Unit Note

Horizontal (H) 359 359.5 360 mm
Vertical (V) 206 206.5 207 mm

Module Size

Bezel Area

Active Area

Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.

Thickness (T) - 3.05 3.20 mm
Thickness (T)

(PCBA with Mylar)

Horizontal 347.06 347.36 347.66 mm
Vertical 196.29 196.59 196.89 mm
Horizontal 343.932 344.232 344.532 mm
Vertical 193.236 193.536 193.836 mm

Weight - 345 360 g

- - 3.25 mm

(1)

Version 1.0 01 October 2012 4 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

Pin1 Pin30

2.1 CONNECTOR TYPE

Please refer Appendix Outline Drawing for detail design.

Connector Part No.: IPEX-20455-030E-12
User’s connector Part No: IPEX-20453-030T-01

3. ABSOLUTE MAXIMUM RATINGS

3.1 ABSOLUTE RATINGS OF ENVIRONMENT

Item Symbol

Min. Max.
Storage Temperature TST -20 +60 ºC (1)
Operating Ambient Temperature TOP 0 +50 ºC (1), (2)

Note (1) (a) 90 %RH Max. (Ta <= 40 ºC).
(b) Wet-bulb temperature should be 39 ºC Max. (Ta > 40 ºC).
(c) No condensation.

Value

Unit Note

Version 1.0 01 October 2012 5 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

Note (2) The temperature of panel surface should be 0 ºC min. and 60 ºC max.

Relative Humidity (%RH)

100

90
80

60

Operating Range

40

20
10

Storage Range

80 60 -20 40 0 20 -40

Temperature (ºC)

3.2 ELECTRICAL ABSOLUTE RATINGS

3.2.1 TFT LCD MODULE

Item Symbol

Power Supply Voltage VCCS -0.3 +4.0 V
Logic Input Voltage VIN -0.3 VCCS+0.3
Converter Input Voltage
Converter Control Signal Voltage
Converter Control Signal Voltage

Note (1) Stresses beyond those listed in above “ELECTRICAL ABSOLUTE RATINGS” may cause

permanent damage to the device. Normal operation should be restricted to the conditions

LED_VCCS
LED_PWM,

LED_EN

Value

Min. Max.

-0.3 (26) V (1)

-0.3 (5) V (1)

-0.3 (5) V (1)

Unit Note

(1)

V

described in “ELECTRICAL CHARACTERISTICS”.

Version 1.0 01 October 2012 6 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

4. ELECTRICAL SPECIFICATIONS

SCAN DRIVER

CIR

CUIT

EDID

DC/DC CONVERTER &

LED

4.1 FUNCTION BLOCK DIAGRAM

Display port
Signals

INPUT CONNECTOR

PRODUCT SPECIFICATION

TIMING

CONTROLLER

TFT LCD PANEL

VCCS
GND

Converter
Input Signals

4.2. INTERFACE CONNECTIONS

PIN ASSIGNMENT

Pin Symbol Description Remark

1 NC No Connection (Reserved)
2 H_GND High Speed Ground
3 NC No Connection (Reserved)
4 NC No Connection (Reserved)
5 H_GND High Speed Ground
6 ML0- Complement Signal-Lane 0
7 ML0+ True Signal-Main Lane 0
8 H_GND High Speed Ground

9 AUX+ True Signal-Auxiliary Channel
10 AUX- Complement Signal-Auxiliary Channel
11 H_GND High Speed Ground
12 VCCS Power Supply +3.3 V (typical)
13 VCCS Power Supply +3.3 V (typical)
14 NC No Connection (Reserved for CMI test)
15 GND Ground
16 GND Ground
17 HPD Hot Plug Detect
18 BL_GND BL Ground
19 BL_GND BL Ground
20 BL_GND BL Ground
21 BL_GND BL Ground
22 LED_EN BL_Enable Signal of LED Converter

EEPROM

REFERENCE VOLTAGE

GENERATOR

CONVERTER

DATA DRIVER IC

BACKLIGHT UNIT

Version 1.0 01 October 2012 7 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

Pitch

23 LED_PWM
24 NC No Connection

25 NC No Connection
26 LED_VCCS BL Power
27 LED_VCCS BL Power
28 LED_VCCS BL Power
29 LED_VCCS BL Power
30 NC No Connection (Reserved)

Note (1) The first pixel is odd as shown in the following figure.

PWM Dimming Control Signal of LED
Converter

1,1

(odd)

2,1

1,2

(even)

2,2

1,3

(odd)

1,4

(even)

3,1

1,Xmax

Ymax,1

Pitch

Ymax,
Xmax

Version 1.0 01 October 2012 8 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

C2

4.3 ELECTRICAL CHARACTERISTICS

4.3.1 LCD ELETRONICS SPECIFICATION

Parameter Symbol

Min. Typ. Max.

Power Supply Voltage VCCS 3.0 3.3 3.6 V (1)-

Value

Unit Note

HPD

High Level (2.25) - (2.75) V

Low Level (0) - (0.4) V
Ripple Voltage VRP - (50) - mV (1)­Inrush Current I

- - (1.5) A (1),(2)

RUSH

Mosaic (250) (300) mA (3)a

Power Supply Current

Black

lcc

(300) (340) mA (3)
Note (1) The ambient temperature is Ta = 25 ± 2 ºC.
Note (2) I

: the maximum current when VCCS is rising

RUSH

IIS: the maximum current of the first 100ms after power-on

Measurement Conditions: Shown as the following figure. Test pattern: black.

(High to Low)

(Control Signal)

SW

+12V

+3.3V

R1
47K

R2

1K

47K

VR1

C1

1uF

Q1 2SK1475

0.01uF

Q2

2SK1470

FUSE

C3

1uF

VCCS

(LCD Module Input)

VCCS rising time is 0.5ms

Version 1.0 01 October 2012 9 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

Note (3) The specified power supply current is under the conditions at VCCS = 3.3 V, Ta = 25 ± 2 ºC, DC

Current and fv = 60 Hz, whereas a power dissipation check pattern below is displayed.
a. Mosaic Pattern

Active Area

Version 1.0 01 October 2012 10 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

PWM Control Permissive Ripple

4.3.2 LED CONVERTER SPECIFICATION

Parameter Symbol

Value

Unit Note

Min. Typ. Max.
Converter Input power supply voltage
Converter Inrush Current

LED_Vccs

ILED

RUSH

(5.0) (12.0) (21.0) V

- - (1.5) A (1)

Backlight On (2.2) - (5) V

EN Control Level

Backlight Off

PWM High Level

PWM Control Level

PWM Low Level

(0) - (0.6) V

(2.2) - (5) V

(0) - (0.6) V

PWM Control Duty Ratio (5) - (100) %

Voltage
PWM Control Frequency f

LED Power Current LED_VCCS =Typ.

Note (1) ILED

: the maximum current when LED_VCCS is rising,

RUSH

(190) - (2K) Hz (2)

PWM

ILED (116) (145) (163) mA (3)

- - (100) mV

V

PWM_pp

ILEDIS: the maximum current of the first 100ms after power-on,
Measurement Conditions: Shown as the following figure. LED_VCCS = Typ, Ta = 25 ± 2 ºC, f

= 200 Hz, Duty=100%.

PWM

(High to Low)

(Control Signal)

SW=24V

LED_VCCS(Typ)

LED_VCCS(Typ)

C1

1uF

VR1

R1
47K

47K

Q1 IRL3303

R2

1K

0.01uF

Q2

IRL3303

C2

VLED rising time is 0.5ms

FUSE

C3

1uF

(LED Converter Input)

Version 1.0 01 October 2012 11 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

0.5ms

≤∗+

∗+≤

≥

PRODUCT SPECIFICATION

90%

ILED

10%

Rush

100ms

ILED

IS

LED_VCC

LED_PWM

LED_EN

ILED

Note (2) If PWM control frequency is applied in the range less than 1KHz, the “waterfall” phenomenon on

the screen may be found. To avoid the issue, it’s a suggestion that PWM control frequency should
follow the criterion as below.

0V

0V

0V

PWM control frequency f

fN )33.0(

N

: Integer

f

: Frame rate

Note (3) The specified LED power supply current is under the conditions at “LED_VCCS = Typ.”, Ta = 25

± 2 ºC, f

= 200 Hz, Duty=100%.

PWM

should be in the range

PWM

f

PWM

)3(

N

fN

)66.0(

Version 1.0 01 October 2012 12 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

4.3.3

BACKLIGHT UNIT

PRODUCT SPECIFICATION

Parameter Symbol

LED Light Bar Power
Supply Voltage
LED Light Bar Power
Supply Current
Power Consumption PL 1.4784 1.584 W (3)
LED Life Time LBL 12000 - - Hrs (4)

Note (1) LED current is measured by utilizing a high frequency current meter as shown below :

Light Bar Feedback
Channels

VL 27.5 30.8 33 V

IL 48 mA

Min. Typ. Max.

V

L, IL

Ta = 25 ± 2 ºC

Value

LED
Light Bar

11S3P

Unit Note

(1)(2)(Duty100%)

Note (2) For better LED light bar driving quality, it is recommended to utilize the adaptive boost converter

with current balancing function to drive LED light-bar.
Note (3) PL = IL ×VL (Without LED converter transfer efficiency)
Note (4) The lifetime of LED is defined as the time when it continues to operate under the conditions at Ta =

25 ±2 oC and IL = 20 mA(Per EA) until the brightness becomes 50% of its original value.≦

Version 1.0 01 October 2012 13 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

0V

VCM

|VID|

4.4 DISPLAY PORT SIGNAL TIMING SPECIFICATION

4.4.1 DISPLAY PORT INTERFACE

Parameter Symbol Min. Typ. Max. Unit Notes
Differential Signal Common Mode
Voltage(MainLink and AUX)
AUX AC Coupling Capacitor C

Note (1) Display port interface related AC coupled signals are following VESA DisplayPort Standard

Version1. Revision 1a and VESA Embedded DisplayPortTM Standard Version 1.1.
(2) The AUX AC Coupling Capacitor placed on Source Devices.
(3) DisplayPortCompliance Test Specification (CTS) 1.1

Single Ended

VCM (0) (2) V (1)(3)

(75) (200) nF (2)

AUX

VD-

Version 1.0 01 October 2012 14 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

4.4.3 COLOR DATA INPUT ASSIGNMENT

The brightness of each primary color (red, green and blue) is based on the 6-bit gray scale data input

for the color. The higher the binary input the brighter the color. The table below provides the assignment
of color versus data input.

Data Signal

Color

R5 R4 R3 R2 R1 R0 G5 G4 G3 G2 G1 G0 B5 B4 B3 B2 B1 B0
Black
Red
Green

Basic
Colors

Gray
Scale
Of
Red

Gray
Scale
Of
Green

Gray
Scale
Of
Blue

Note (1) 0: Low Level Voltage, 1: High Level Voltage

Blue
Cyan
Magenta
Yellow
White
Red(0)/Dark
Red(1)
Red(2)

:

:
Red(61)
Red(62)
Red(63)
Green(0)/Dark
Green(1)
Green(2)

:

:
Green(61)
Green(62)
Green(63)
Blue(0)/Dark
Blue(1)
Blue(2)

:

:
Blue(61)
Blue(62)
Blue(63)

0
1
0
0
0
1
1
1
0
0
0

:

:
1
1
1
0
0
0

:

:
0
0
0
0
0
0

:

:
0
0
0

Red Green Blue

0

0

0

0

0

0

0

0

0

0

0

0

1

1

1

1

1

0

0

0

0

0

0

0

0

0

0

0

0

1

1

1

1

1

1

0

0

0

0

0

0

0

0

0

0

0

0

1

0

0

0

0

0

1

1

1

1

1

1

1

1

1

1

1

1

0

0

0

0

0

0

1

1

1

1

1

1

1

1

1

1

1

1

0

1

1

1

1

1

1

1

1

1

1

1

1

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

1

0

0

0

0

0

0

0

0

0

0

1

0

0

0

0

0

0

0

0

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

1

1

1

0

1

0

0

0

0

0

0

0

1

1

1

1

0

0

0

0

0

0

0

0

1

1

1

1

1

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

1

0

0

0

0

0

0

0

0

0

0

1

0

0

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

0

0

0

0

0

1

1

1

1

0

1

0

0

0

0

0

0

1

1

1

1

1

0

0

0

0

0

0

0

1

1

1

1

1

1

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

0

0

0

0

0

0

0

0

0

0

0

1

0

0

0

0

0

0

0

0

0

0

0

1

0

0

0

0

0

0

0

0

0

0

0

1

0

0

0

0

0

0

0

0

0

0

0

0

1

1

1

1

1

1

1

1

1

1

1

1

0

0

0

0

1

1

1

1

0

0

0

0

0

0

0

0

0

0

0

0

:

:

:

:

:

:

:

:

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

:

:

:

:

:

:

:

:

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

1

:

:

:

:

:

:

:

:

1

1

1

0

1

1

1

1

1

1

1

1

0
0
0
1
1
1
0
1
0
0
0

:

:
0
0
0
0
0
0

:

:
0
0
0
0
1
0

:

:
1
0
1

Version 1.0 01 October 2012 15 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

4.5 DISPLAY TIMING SPECIFICATIONS

The input signal timing specifications are shown as the following table and timing diagram.

Signal Item Symbol Min. Typ. Max. Unit Note
DCLK Frequency 1/Tc (67.9) (75.45) (79.22) MHz -

Vertical Total Time TV (790) (806) (830) TH -

Vertical Active Display Period TVD (768) (768) (768) TH -

DE

Vertical Active Blanking Period TVB TV-TVD (38) TV-TVD TH -

Horizontal Total Time TH (1482) (1560) (1716)

Horizontal Active Display Period THD (1366) (1366) (1366)

Horizontal Active Blanking Period THB TH-THB (194) TH-THB Tc -

INPUT SIGNAL TIMING DIAGRAM

Tc ­Tc -

DE

DCLK

DE

DATA

TC

THD

Version 1.0 01 October 2012 16 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

10%

t6

-

-

-

4.6 POWER ON/OFF SEQUENCE

The power sequence specifications are shown as the following table and diagram.

-Power Supply
for LCD, VCCS

-eDP Display

-HPD from Sink

-AUX Channel

-Main Link Data

0V

0V

Power On

90%

10%

t1

Power Off

t11

90%

t2

Black Video

t3

AUX Channel Operational

t4

Link

Training

t7

Idle

Video from Source

Valid Video Data

t10

Black Video

Idle or off

Restart

10%

t12

Power Supply for

LED Converter,
LED_VCCS

LED Converter

Dimming Signal,
LED_PWM

LED Converter

Enable Signal,
LED_EN

0V

0V

0V

10%

t5

90%

t8

t

A

t

C

t

E

t9

90%

10%

t

B

t

D

t

F

Version 1.0 01 October 2012 17 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

Timing Specifications:

Parameter

t1 Power rail rise time, 10% to 90%
t2

t3
t4

t5 Link training duration Source
t6 Link idle Source

t7
t8

t9
t10
t11

t12 VCCS Power off time Source

tA

tB

tC

tD

tE

tF

Note (1) Please don’t plug or unplug the interface cable when system is turned on.

Delay from LCD,VCCS to black
video generation
Delay from LCD,VCCS to HPD
high
Delay from HPD high to link
training initialization

Delay from valid video data from
Source to video on display
Delay from valid video data from
Source to backlight on
Delay from backlight off to end of
valid video data
Delay from end of valid video data
from Source to power off
VCCS power rail fall time, 90% to
10%

LED power rail rise time, 10% to
90%
LED power rail fall time, 90% to
10%
Delay from LED power rising to
LED dimming signal
Delay from LED dimming signal to
LED power falling
Delay from LED dimming signal to
LED enable signal
Delay from LED enable signal to
LED dimming signal

Description

Reqd.

By

Source (0.5) (10) ms -

Sink (0) (200)
Sink (0) (200)

Source - - ms

Sink (0) (50) ms
Source
Source - - ms
Source (0) (500)
Source (0.5) (10) ms

Source (0.5) (10) ms
Source (0) (10) ms
Source (1) - ms
Source (1) - ms
Source (1) - ms ­Source (1) - ms -

Value

Min Max

- - ms

- - ms

- - ms

(500) - ms

Unit Notes

ms ­ms -

ms

-

-

-

-

-

-

-

-

-

-

-

-

-

Note (2) Please avoid floating state of the interface signal during signal invalid period.
Note (3) It is recommended that the backlight power must be turned on after the power supply for LCD and the

interface signal is valid.

Version 1.0 01 October 2012 18 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

5. OPTICAL CHARACTERISTICS

5.1 TEST CONDITIONS

Item Symbol Value Unit
Ambient Temperature Ta
Ambient Humidity Ha
Supply Voltage VCC 3.3 V
Input Signal According to typical value in "3. ELECTRICAL CHARACTERISTICS"
LED Light Bar Input Current IL 48 mA

The measurement methods of optical characteristics are shown in Section 5.2. The following items
should be measured under the test conditions described in Section 5.1 and stable environment shown in
Note (5).

5.2 OPTICAL SPECIFICATIONS

Item Symbol

Contrast Ratio CR 350 500 - -

Response Time

Average Luminance of White

Red

Color
Chromaticity

Green

Blue

White

Horizontal

Viewing Angle

Vertical

White Variation of 5 Points

TR - 3 8 ms
TF - 8 13 ms

L

AVE

Rx
Ry
Gx
Gy

Bx

By
Wx 0.313
Wy

θ

+

x

θ

-

x

θ

+

Y

θ

-

Y

δW5p θx=0°, θY =0°

Condition Min. Typ. Max. Unit Note

θ

=0°, θY =0°

x

Viewing Normal Angle

CR≥10

25±2

50±10

%RH

170 200 - cd/m

0.577

0.364

0.348

Typ –

0.03

0.563

0.151

Typ +

0.03

0.116

0.329
40 45
40 45 ­15 20 -

Deg.

40 45 ­80 - - %

o

C

(2),

(5),(7)
(3),(7)

(4),

2

(6),(7)

-

-

-

­(1),(7)

-

-

-

-

(1),(5),

(7)

(5),(6),

(7)

Version 1.0 01 October 2012 19 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

Note (1) Definition of Viewing Angle (θx, θy):

Gray Level 63

Gray Level 0

Gray Level 63

T

ime

66.67 ms

66.67 ms

PRODUCT SPECIFICATION

Normal

θx = θy = 0º

θ

X-

= 90º

x-

6 o’clock

θ

y-

= 90º

y-

Note (2) Definition of Contrast Ratio (CR):

The contrast ratio can be calculated by the following expression.

Contrast Ratio (CR) = L63 / L0
L63: Luminance of gray level 63
L 0: Luminance of gray level 0
CR = CR (1)
CR (X) is corresponding to the Contrast Ratio of the point X at Figure in Note (6).

θy- θ

θx−

y+

θx+

12 o’clock direction

y+

y+

= 90º

θ

x+

θ

X+

= 90º

Note (3) Definition of Response Time (TR, TF):

100%

90%

Optical

Response

10%

0%

TR

Note (4) Definition of Average Luminance of White (L

Measure the luminance of White at 5 points

L

= [L (1)+ L (2)+ L (3)+ L (4)+ L (5)] / 5

AVE

L (x) is corresponding to the luminance of the point X at Figure in Note (6)

AVE

TF

):

Version 1.0 01 October 2012 20 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

Note (5) Measurement Setup:

Light Shield Room

( Ambient

L

uminance < 2

l u x)

X=1 to 13

X

The LCD module should be stabilized at given temperature for 20 minutes to avoid abrupt
temperature change during measuring. In order to stabilize the luminance, the measurement
should be executed after lighting Backlight for 20 minutes in a windless room.

LCD M odule

PRODUCT SPECIFICATION

LCD P anel

USB2000

or equivalent

CS - 2000T

or equivalent

Center of the S creen

500 mm

Note (6) Definition of White Variation (δW):
Measure the luminance of White at 5 points / 13 points

δW5p = {

Minimum [L (1)~ L (5)] / Maximum [L (1)~ L (5)]}*100%

10mm

6

H/4

2 3

7

8

: Test Point

Version 1.0 01 October 2012 21 / 35

H

H/4 H/4 H/4

Note (7) The listed optical specifications refer to the initial value of manufacture, but the condition of

the specifications after long-term operation will not be warranted.

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

9

4 5

11 12 13

10mm 10mm

10mm

W/4 W/4 W/4 W/4

1

W

10

Active area

PRODUCT SPECIFICATION

6. RELIABILITY TEST ITEM

Test Item Test Condition Note
High Temperature Storage Test 60ºC, 240 hours
Low Temperature Storage Test -20ºC, 240 hours
Thermal Shock Storage Test

-20ºC, 0.5hour←→60℃, 0.5hour; 100cycles, 1hour/cycle
High Temperature Operation Test 50ºC, 240 hours
Low Temperature Operation Test 0ºC, 240 hours

High Temperature & High Humidity
Operation Test

ESD Test (Operation)

Shock (Non-Operating)

Vibration (Non-Operating)

Note (1) criteria : Normal display image with no obvious non-uniformity and no line defect.
Note (2) Evaluation should be tested after storage at room temperature for more than two hour
Note (3) At testing Vibration and Shock, the fixture in holding the module has to be hard and rigid enough

so that the module would not be twisted or bent by the fixture.

50°C, 80% RH, 240 hours

150pF, 330Ω, 1sec/cycle
Condition 1 : Contact Discharge, ±8KV
Condition 2 : Air Discharge, ±15KV

220G, 2ms, half sine wave,1 time for each direction of
±X,±Y,±Z

1.5G / 10-500 Hz, Sine wave, 30 min/cycle, 1cycle for each

X, Y, Z

(1) (2)

(1)

(1)(3)

(1)(3)

Version 1.0 01 October 2012 22 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

7. PACKING

7.1 MODULE LABEL

The barcode nameplate is pasted on each module as illustration, and its definitions are as following explanation.

N156BGE-EA1

(a) Model Name: N156BGE - EA1
(b) Revision: Rev. XX, for example: C1, C2 …etc.
(c) Serial ID: X X X X X X X Y M D L N N N N

(d) Production Location: MADE IN XXXX. XXXX stands for production location.
(e) UL logo: “AAAA” especially stands for panel manufactured by CMO China satisfying UL requirement.

“LEOO” and “COCKN” is the CMO’s UL factory code for Ningbo factory..

Serial No.
Product Line

Year, Month, Date

CMO Internal Use

Revision

CMO Internal Use

Version 1.0 01 October 2012 23 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

7.2 CARTON

PRODUCT SPECIFICATION

Figure. 7-2 Packing method

Version 1.0 01 October 2012 24 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

7.3 PALLET

PRODUCT SPECIFICATION

Figure. 7-3 Packing method

Version 1.0 01 October 2012 25 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

8. PRECAUTIONS

8.1 HANDLING PRECAUTIONS

(1) The module should be assembled into the system firmly by using every mounting hole. Be careful

not to twist or bend the module.

(2) While assembling or installing modules, it can only be in the clean area. The dust and oil may cause

electrical short or damage the polarizer.

(3) Use fingerstalls or soft gloves in order to keep display clean during the incoming inspection and

assembly process.

(4) Do not press or scratch the surface harder than a HB pencil lead on the panel because the polarizer

is very soft and easily scratched.

(5) If the surface of the polarizer is dirty, please clean it by some absorbent cotton or soft cloth. Do not

use Ketone type materials (ex. Acetone), Ethyl alcohol, Toluene, Ethyl acid or Methyl chloride. It
might permanently damage the polarizer due to chemical reaction.

(6) Wipe off water droplets or oil immediately. Staining and discoloration may occur if they left on panel

for a long time.

(7) If the liquid crystal material leaks from the panel, it should be kept away from the eyes or mouth. In

case of contacting with hands, legs or clothes, it must be washed away thoroughly with soap.
(8) Protect the module from static electricity, it may cause damage to the C-MOS Gate Array IC.
(9) Do not disassemble the module.
(10) Do not pull or fold the LED wire.
(11) Pins of I/F connector should not be touched directly with bare hands.

8.2 STORAGE PRECAUTIONS

(1) High temperature or humidity may reduce the performance of module. Please store LCD module

within the specified storage conditions.
(2) It is dangerous that moisture come into or contacted the LCD module, because the moisture may

damage LCD module when it is operating.
(3) It may reduce the display quality if the ambient temperature is lower than 10 ºC. For example, the

response time will become slowly, and the starting voltage of LED will be higher than the room

temperature.

8.3 OPERATION PRECAUTIONS

(1) Do not pull the I/F connector in or out while the module is operating.
(2) Always follow the correct power on/off sequence when LCD module is connecting and operating.

This can prevent the CMOS LSI chips from damage during latch-up.
(3) The startup voltage of Backlight is approximately 1000 Volts. It may cause electrical shock while

assembling with converter. Do not disassemble the module or insert anything into the Backlight unit.

Version 1.0 01 October 2012 26 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

Appendix. EDID DATA STRUCTURE

The EDID (Extended Display Identification Data) data formats are to support displays as defined in the
VESA Plug & Display and FPDI standards.

Reference

Byte #

(decimal)

10 0A
11 0B
12 0C
13 0D
14 0E
15 0F
16 10
17 11
18 12
19 13
20 14
21 15
22 16
23 17
24 18
25 19
26 1A
27 1B
28 1C
29 1D
30 1E
31 1F
32 20
33 21
34 22
35 23
36 24
37 25
38 26

Byte #

(hex)

0 0
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9

Field Name and Comments

Header
Header
Header
Header
Header
Header
Header
Header
EISA ID manufacturer name (“CMN”)
EISA ID manufacturer name (Compressed ASCII)
ID product code (N156BGE-EA1) BD
ID product code (hex LSB first; N156BGE-EA1) 15
ID S/N (fixed “0”)
ID S/N (fixed “0”)
ID S/N (fixed “0”)
ID S/N (fixed “0”)
Week of manufacture (fixed week code)
Year of manufacture (fixed year code)
EDID structure version # (“1”)
EDID revision # (“4”)
Video I/P definition (“digital”)
Max H image size (“34.42cm”)
Max V image size (“19.35cm”)
Display Gamma (Gamma = ”2.2”)
Feature support (“Active off, RGB Color”)
Rx1, Rx0, Ry1, Ry0, Gx1, Gx0, Gy1, Gy0 D1
Bx1, Bx0, By1, By0, Wx1, Wx0, Wy1, Wy0 F5
Rx=0.577 93
Ry=0.364 5D
Gx=0.348 59
Gy=0.563 90
Bx=0.151 26
By=0.116 1D
Wx=0.313 50
Wy=0.329 54
Established timings 1
Established timings 2
Manufacturer’s reserved timings

Standard timing ID # 1

Value

(hex)

00 00000000
FF 11111111
FF 11111111
FF 11111111
FF 11111111
FF 11111111
FF 11111111

00 00000000
0D 00001101
AE 10101110

00 00000000

00 00000000

00 00000000

00 00000000

11 00010001

16 00010110

01 00000001

04 00000100

95 10010101

22 00100010

13 00010011

78 01111000

02 00000010

00 00000000

00 00000000

00 00000000

01 00000001

Value

(binary)

10111101

00010101

11010001

11110101
10010011
01011101
01011001

10010000

00100110
00011101

01010000
01010100

Version 1.0 01 October 2012 27 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

39 27
40 28
41 29

42 2A
43 2B

44 2C
45 2D
46 2E
47 2F
48 30
49 31
50 32
51 33
52 34
53 35

54 36
55 37

56 38
57 39
58 3A
59 3B
60 3C
61 3D
62 3E
63 3F
64 40

65 41
66 42

67 43
68 44
69 45
70 46

71 47
72 48

73 49
74 4A

75 4B
76 4C

77 4D
78 4E
79 4F
80 50
81 51
82 52

Standard timing ID # 1
Standard timing ID # 2
Standard timing ID # 2

Standard timing ID # 3
Standard timing ID # 3
Standard timing ID # 4
Standard timing ID # 4
Standard timing ID # 5
Standard timing ID # 5
Standard timing ID # 6
Standard timing ID # 6
Standard timing ID # 7
Standard timing ID # 7
Standard timing ID # 8
Standard timing ID # 8

Detailed timing description # 1 Pixel clock (“75.45MHz”, According to
VESA CVT Rev1.1)

# 1 Pixel clock (hex LSB first)
# 1 H active (“1366”)
# 1 H blank (“194”)
# 1 H active : H blank (“1366 : 194”)
# 1 V active (”768”)
# 1 V blank (”38”)
# 1 V active : V blank (”768 :38”)
# 1 H sync offset (”31”)
# 1 H sync pulse width ("65”)
# 1 V sync offset : V sync pulse width (”4 : 12”)

# 1 H sync offset : H sync pulse width : V sync offset : V sync width
(”31: 65 : 4 : 12”)

# 1 H image size (”344 mm”) 58
# 1 V image size (”194 mm”) C2
# 1 H image size : V image size (”344 : 194”)
# 1 H boarder (”0”)
# 1 V boarder (”0”)

# 1 Non-interlaced, Normal, no stereo, Separate sync, H/V pol
Negatives

Detailed timing description # 2
# 2 Flag
# 2 Reserved

# 2 FE (hex) defines ASCII string (Model Name “N156BGE-EA1”,
ASCII)

# 2 Flag
# 2 1st character of name (“N”) 4E
# 2 2nd character of name (“1”) 31
# 2 3rd character of name (“5”) 35
# 2 4th character of name (“6”) 36
# 2 5th character of name (“B”) 42
# 2 6th character of name (“G”) 47

01 00000001
01 00000001
01 00000001

01 00000001
01 00000001

01 00000001
01 00000001
01 00000001
01 00000001
01 00000001
01 00000001
01 00000001
01 00000001
01 00000001
01 00000001

79 01111001

1D 00011101

56 01010110

C2 11000010

50 01010000
00 00000000
26 00100110
30 00110000

1F 00011111

41 01000001

4C 01001100

00 00000000

10 00010000
00 00000000
00 00000000

18 00011000
00 00000000

00 00000000
00 00000000

FE 11111110

00 00000000

01011000
11000010

01001110
00110001
00110101
00110110

01000010

01000111

Version 1.0 01 October 2012 28 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

83 53
84 54
85 55
86 56

87 57
88 58

89 59
90 5A
91 5B
92 5C
93 5D
94 5E
95 5F
96 60
97 61
98 62

99 63
100 64
101 65
102 66
103 67
104 68
105 69
106 6A
107 6B
108 6C
109 6D
110 6E

111 6F
112 70

113 71
114 72
115 73
116 74
117 75
118 76
119 77
120 78
121 79
122 7A
123 7B
124 7C
125 7D
126 7E
127 7F

# 2 7th character of name (“E”) 45
# 2 8th character of name (“-”) 2D
# 2 9th character of name (“E”)
# 2 10th character of name (“A”)

# 2 11th character of name (“1”)
# 2 New line character indicates end of ASCII string
# 2 Padding with “Blank” character
Detailed timing description # 3
# 3 Flag
# 3 Reserved
# 3 FE (hex) defines ASCII string (Vendor “CMN”, ASCII)
# 3 Flag
# 3 1st character of string (“C”)
# 3 2nd character of string (“M”)
# 3 3rd character of string (“N”)
# 3 New line character indicates end of ASCII string
# 3 Padding with “Blank” character
# 3 Padding with “Blank” character
# 3 Padding with “Blank” character
# 3 Padding with “Blank” character
# 3 Padding with “Blank” character
# 3 Padding with “Blank” character
# 3 Padding with “Blank” character
# 3 Padding with “Blank” character
# 3 Padding with “Blank” character
Detailed timing description # 4
# 4 Flag
# 4 Reserved

# 4 FE (hex) defines ASCII string (Model Name“N156BGE-EA1”,
ASCII)

# 4 Flag
# 4 1st character of name (“N”) 4E
# 4 2nd character of name (“1”) 31
# 4 3rd character of name (“5”) 35
# 4 4th character of name (“6”) 36
# 4 5th character of name (“B”) 42
# 4 6th character of name (“G”) 47
# 4 7th character of name (“E”) 45
# 4 8th character of name (“-”) 2D
# 4 9th character of name (“E”)
# 4 10th character of name (“A”)
# 4 11th character of name (“1”)
# 4 New line character indicates end of ASCII string
# 4 Padding with “Blank” character
Extension flag
Checksum

45 01000101
41 01000001

31 00110001

0A 00001010

20 00100000
00 00000000
00 00000000
00 00000000

FE 11111110

00 00000000

43 01000011
4D 01001101
4E 01001110
0A 00001010

20 00100000

20 00100000

20 00100000

20 00100000

20 00100000

20 00100000

20 00100000

20 00100000

20 00100000

00 00000000

00 00000000

00 00000000
FE 11111110

00 00000000

45 01000101

41 01000001

31 00110001
0A 00001010

20 00100000

00 00000000
A3 10100011

01000101

00101101

01001110
00110001
00110101
00110110

01000010

01000111

01000101

00101101

Version 1.0 01 October 2012 29 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

Appendix. OUTLINE DRAWING

PRODUCT SPECIFICATION

Version 1.0 01 October 2012 30 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

Version 1.0 01 October 2012 31 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

Appendix.

1. Design gap A between panel & any components on system cover

Definition

2 Design gap B1 & B2 between panel & protrusions

SYSTEM COVER DESIGN NOTICE

a). Sufficient gap between panel & system is a must for preventing from backpack or pogo
test fail.

b). Zero gap from panel's maximum thickness boundary to any components, foreign objects,
wire, cable or extrusion on system cover inner surface is forbidden.

B1

Protrusion

2.0mm min. gap is recommended between panel & protrusions for preventing from shock

Definition

3 Design gap C between system front bezel & panel surface.

related failures.

Protrusion

B2

Version 1.0 01 October 2012 32 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

a). Sufficient gap between system front bezel & panel surface is a must for preventing from
pooling or glass broken.

Definition

4 Design gap D1 & D2 between system front bezel & PCB Assembly.

b). Zero gap or interference is forbidden.

a). Sufficient gap between system front bezel & PCB assembly is a must for preventing from
abnormal display after backpack test, hinge test, twist test or pogo test.

Definition

5 Interference examination of antenna cable and WebCam wire

Definition

6 System inner surface examination

b). Zero gap or interference is forbidden.

WebCam Wire

a). Antenna cable or WebCam wire overlap with panel outline is forbidden for preventing
from abnormal display & white spot after backpack test, hinge test, twist test or pogo test.

b). Antenna cable or WebCam wire bypass panel outline is recommended.

WebCam Wire

Version 1.0 01 October 2012 33 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

Definition a). Burr at logo edge, step, protrusion or PCB board will easily cause white spot or glass

broken.
b). Keeping flat surface underneath backlight is recommended.

7 Tape/sponge design on system inner surface

Definition a) To prevent abnormal display & white spot after scuffing test, hinge test, pogo test,

backpack test, it is not recommended to add tape/sponge in separate location. Since each
tape/sponge may act as pressure concentration location.

b) We suggest to design a tape/sponge that well covered under panel rear cover.

8 Assembly SOP examination

Definition To prevent panel crack during system front bezel assembly process with hook design, it is

prohibited to press panel or any location that related directly to the panel.

9 Material used for system rear bezel

Version 1.0 01 October 2012 34 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.

PRODUCT SPECIFICATION

Definition To prevent panel crack during system front bezel assembly process without hook design, it

is only allowed to give slight pressure with large contact area. This can help to distribute the
stress to prevent point concentration, also it is suggest to put the system on a flat surface
stage during the assembly.

10 Material used for system rear bezel

Definition a) To prevent abnormal display & white spot after scuffing test, hinge test, pogo test,

backpack test, as the poor rigidity result from deformation of system rear cover during the
test.

b) We suggest to use aluminum-magnesium alloy as the rear frame material with thickness
min 1.5mm, instead of using PC/ABS.

11 System base unit design near keyboard and mouse pad

Definition To prevent abnormal display & white spot after scuffing test, hinge test, pogo test, backpack

test, no sharp edge design is allowed in any area that may damage the panel during the
test. We suggest to remove all sharp edges, or to reduce the thickness difference of
keyboard/mouse pad from the nearby surface.

Version 1.0 01 October 2012 35 / 35

The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited.
