chiliGREEN W251CZQ User Manual [en, de, es, fr, it]
Contents
About this Concise User Guide .........................................................1
System Startup ..................................................................................4
System Map: Front View with LCD Panel Open (Model A) ...........5
System Map: Front View with LCD Panel Open (Models B & C) ..6
LED Indicators ..................................................................................7
Hot-Key Buttons - Some Model A Designs Only ............................8
Keyboard ...........................................................................................8
Control Center .................................................................................10
System Map: Front, Left, Right, Rear & Bottom Views
(Model A) ............................................................................... .........14
System Map: Front, Left, Right, Rear & Bottom Views
(Model B) ........................................................... .............................15
System Map: Front, Left, Right, Rear & Bottom Views
(Model C) ........................................................... .............................16
3G Module ......................................................................................17
Driver Installation ...........................................................................18
Troubleshooting ..............................................................................19
Specifications ................. .................................... ............................. 20
Inhalt
Über das Ausführliche Benutzerhandbuch .....................................23
Schnellstart ................. ................. ................ ................ ............... .....26
Systemübersicht: Ansicht von vorne mit geöffnetem
LCD-Bildschirm (Modell A) ..........................................................27
Systemübersicht: Ansicht von vorne mit geöffnetem
LCD-Bildschirm (Modelle B & C) .................................................28
LED-Anzeigen ................. ........................................................ .......29
Hot-Key-Tasten - nur einige Designs des Modells A .....................30
Tastatur ...........................................................................................30
Funktionstasten ...............................................................................31
Control Center (Steuerzentrum) ............................... .......................32
Systemübersicht: Ansicht von vorne, links, rechts, hinten und unten
(Modell A) . ......................................................................................36
Systemübersicht: Ansicht von vorne, links, rechts, hinten und unten
(Modell B) .......... ............................... ..............................................37
Systemübersicht: Ansicht von vorne, links, rechts, hinten und unten
(Modell C) .......... ............................... ..............................................38
3G-Modul .......................... ............................................... ...............39
Installation der Treiber ....................................................................40
Fehlerbehebung ...............................................................................41
Technische Daten ............................................................................42
Sommaire
A propos de ce Guide Utilisateur Concis ........................................45
Guide de démarrage rapide .............................................................48
Carte du système: Vue de face avec l’écran LCD ouvert
(Modèle A) ............................... .......................................................49
Carte du système: Vue de face avec l’écran LCD ouvert
(Modèles B & C) .............................................................................50
Indicateurs LED ..................... .........................................................51
Boutons Hot-Key - certains designs du modèle A seulement .........52
Clavier ...................................................... .......................................52
Touches fonction .... ............................................................ .............53
Control Center (Centre de contrôle) .......................... ......................54
Carte du système: Vues de face, gauche, droite, arrière & dessous
(Modèle A) ............................... .......................................................58
Carte du système: Vues de face, gauche, droite, arrière & dessous
(Modèle B) ............................................................ ..........................59
Carte du système: Vues de face, gauche, droite, arrière & dessous
(Modèle C) ............................................................ ..........................60
Module 3G .......................................................................................61
Installation du pilote ........................................................................62
Dépannage ......................... ...................................... ........................63
Spécifications ..................................................................................64
Contenidos
Acerca de esta Guía del Usuario Concisa .......................................67
Guía rápida para empezar ...............................................................70
Mapa del sistema: Vista frontal con panel LCD abierto
(Modelo A) ............................................................................... .......71
Mapa del sistema: Vista frontal con panel LCD abierto
(Modelos B & C) ............................................................................72
Indicadores LED .............................................................................73
Botones Hot-Key - sólo algunos diseños del Modelo A .................74
Teclado ....................... ............... .................. ................ ............... .....74
Control Center (Centro de control) .... ............................... ..............76
Mapa del sistema: Vistas frontal, izquierda, derecha, posterior e
inferior (Modelo A) .........................................................................80
Mapa del sistema: Vistas frontal, izquierda, derecha, posterior e
inferior (Modelo B) .........................................................................81
Mapa del sistema: Vistas frontal, izquierda, derecha, posterior e
inferior (Modelo C) .........................................................................82
Módulo 3G ......................................................................................83
Instalación de controladores ...........................................................84
Solución de problemas ....................................................................85
Especificaciones .................. ............... ................ ............... ..............86
Sommario
Informazioni su questa guida rapida ...............................................89
Guida di avvio rapido ......................................................................92
Descrizione del sistema: Vista anteriore con pannell o LCD aper to
(Modello A) ....................................................................................93
Descrizione del sistema: Vista anteriore con pannell o LCD aper to
(Modelli B & C) ............................................................ ..................94
Indicatori LED ................................................................................95
Pulsanti Hot-Key (solo alcuni design di modello A) ......................96
Tastiera ................ ............. .............. ............... .............. ............. .......96
Tasti funzione ..................................................................................97
Control Center (Centro di controllo) ...............................................98
Descrizione del sistema: Vista anteriore, sinistra, destra, posteriore
e inferiore (Modello A) ............................................................... ..102
Descrizione del sistema: Vista anteriore, sinistra, destra, posteriore
e inferiore (Modello B) .............. ...................................................103
Descrizione del sistema: Vista anteriore, sinistra, destra, posteriore
e inferiore (Modello C) .............. ...................................................104
Modulo 3G ....................................................................................105
Installazione driver ...... ............................... ...................................106
Risoluzione dei problemi ........... ...................................................107
Specifiche tecniche ........................................................................108
About this Concise User Guide
FCC Statement
This device complies with Part
15 of the FCC Rules. Operation
is subject to the following two
conditions:
1.This device may not cause
harmful interference.
2. This device must accept any
interference received, including interference that may
cause undesired operation.
This quick guide is a brief introduction to getting your system started. This is a supplement, and not a substitu te for the
expanded English language User’s Manual in Adobe Acrobat format on the Device Drivers & Utilities + User’s Manual
disc supplied with your computer. This disc also contains the drivers and utilities necessary for the prop er operation of
the computer (Note: The company reserves the right to revise this publication or to change its contents without notice).
Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure
(or re-install) portions of the system, refer to the expanded User’s Manual. The Device Drivers & Utilities + User’s
Manual disc does not contain an operating system.
Regulatory and Safety Information
Please pay careful attention to the full regulatory notices and safety information contained in the expanded User’s Manual on the Device Drivers & Utilities + User’s Manual disc.
© September 2012
Trademarks
Intel and Celeron are trademarks/registered trademarks of Intel Corporation.
English
1
Instructions for Care and Operation
The computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
• Don’t drop it, or expose it to shock. If the computer falls, the
case and the components could be damaged.
• Keep it dry, and don’t overheat it. Keep the computer and power
supply away from any kind of heating element. This is an electrical appliance. If water or any other liquid gets into it, the computer
could be badly damaged.
English
• Avoid interference. Keep the computer away from high capacity
transformers, electric motors, and other strong magnetic fields.
These can hinder proper performance and damage your data.
• Follow the proper working procedures for the computer. Shut
the computer down properly and don’t forget to save your work.
Remember to periodically save your data as data may be lost.
Servicing
Do not attempt to service the computer yourself. Doing so may
violate your warranty and expose you and the computer to
electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply. Then refer
servicing to qualified service personnel under any of the fo llowing conditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to any liquids.
• If the computer does not work normally when you follow the operating instructions.
• If the computer has been dropped or damaged (do not touch the
poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your computer.
Safety Information
• Only use an AC/DC adapter approved for use with this computer.
• Use only the power cord and batteries indicated in this manual. Do
not dispose of batteries in a fire. They may explode. Check with
local codes for possible special disposal instructions.
• Do not continue to use a battery that has been dropped, or that
appears damaged (e.g. bent or twisted) in any way. Even if the
computer continues to work with a damaged battery in place, it
may cause circuit damage, which may possibly result in fire.
• Make sure that your computer is completely powered off before
putting it into a travel bag (or any such container).
• Before cleaning the computer, make sure it is disconnected from
any external power supplies, peripherals and cables (including
telephone lines). It is advisable to also remove your battery in
order to prevent accidentally turning the machine on.
• Use a soft clean cloth to clean the computer, but do not apply
cleaner directly to the computer. Do not use volatile (petroleum
distillates) or abrasive cleaners on any part of the computer.
• Do not try to repair a battery pack. Refer any battery pack repair or
replacement to your service representative or qualified service personnel.
• Note that in computer’s featuring a raised LCD electro-pl ated
logo, the logo is covered by a protective adhesive. Due to general
wear and tear, this adhesive may deter iorate over time and the
exposed logo may develop sharp edges. Be careful when handling
the computer in this case, and avoid touching the raised LCD electro-plated logo. Av oid placing any other items in the carrying bag
which may rub against the top of the computer during transport. If
any such wear and tear develops contact your service center.
2
Polymer Battery Precautions
Battery Disposal & Caution
The product that you have purchased contains a rechargeable
battery. The battery is recyclable. At the end of its useful life,
under various state and local laws, it may be illegal to dispose
of this battery into the municipal waste stream. Check with
your local solid waste officials for details in your area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the
manufacturer. Discard used battery according to the manufacturer’s instructions.
Note the following information which is specific to polymer
batteries only, and where applicable, this overrides the general
battery precaution information.
• Polymer batteries may experience a slight expansion or swelling,
however this is part of the battery’s safety mechanism and is not a
cause for concern.
• Use proper handling procedures when using polymer batteries. Do
not use polymer batteries in high ambient temperature environments, and do not store unused batteries for extended periods.
English
3
System Startup
Shut Down
Note that you should always shut your computer down by
choosing Shut Down
from the Start Menu.
This will help prevent
hard disk or system
problems.
130 ﾟ
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Insert the battery and make sure it is locked in position.
4. Securely attach any peripherals you want to use with the
computer (e.g. keyboard and mouse) to their ports.
5. Attach the AC/DC adapter to the DC-In jack on the left of the
computer, then plug the AC power cord into an outlet, and
English
connect the AC power cord to the AC/DC adapter.
6. Use one hand to raise the
(do not exceed 130 degrees); use the other hand (as illustrated
in Figure 1) to support the base of the computer (Note: Never
lift the computer by the lid/LCD).
7. Press the power button to turn the computer “on”.
lid/LCD to a comfortable viewing angle
System Software
Your computer may already come with system software
pre-installed. Where this is not the case, or where you are
re-configuring your computer for a different system, you
will find this manual refers to Microsoft Windows 7.
Model Differences
This notebook series includes different models that vary
slightly in design style, color and general appearance.
Note that though your computer may look slightly different from that pictured throughout this documentation, all
ports, jacks, indicators, specifications and general functions are the same for all the design styles.
Figure 1 - Opening the Lid/LCD/Computer with AC/DC
Adapter Plugged-In
4
System Map: Front View with LCD Panel Open (Model A)
4
Note that the Touchpad and
Buttons valid operational
area is that indicated within
the red dotted lines above.
6
3
5
7
1
8
2
8
Figure 2
Front View with LCD Panel
Open (Model A)
1. PC Camera (Optional)
2. LCD
3. Power Button
4. Hot-Key Buttons (Some
Model A Designs Only)
5. LED Status Indicators
6. Keyboard
7. Built-In Microphone
8. Touchpad & Buttons
14” (35.56cm)
Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices aboard aircraft is
usually prohibited. Make
sure the wireless modules are OFF if you are
using the computer
aboard aircraft.
Use the key combinations
to toggle power to the 3G/
WLAN/Bluetooth modules, and check the LED
indicator/visual indicator
to see if the modules are
powered on or not (see
Table 4 on page 9).
English
5
System Map: Front View with LCD Panel Open (Models B & C)
5
3
4
6
1
7
15.6” (39.62cm)
2
4
6
3
5
7
1
2
17.3” (43.94cm)
Model B
Model C
Figure 3
Front View with LCD Panel Open (Models B & C)
1. PC Camera (Optional)
2. LCD
3. Power Button
4. LED Status Indicators
5. Keyboard
6. *Built-In Microphone
*Note that the microphone
location is dependent
upon your model design.
7. Touchpad & Buttons
6
Note that the
Touchpad and
Buttons valid
operational
area is that indicated within
the red dotted
lines above.
7
English
6
LED Indicators
Model A - Design lI
Model A - Designs l & III
Models B & C
The LED indicators on the computer display helpful information about the current status of the computer.
Icon Color Description
Icon Color Description
Green The Wireless LAN Module is Powered On
Orange The Bluetooth Module is Powered On
Green Hard Disk Activity
Green Number Lock (Numeric Keypad) Activated
Green Caps Lock Activated
Green Scroll Lock Activated
Table 1 - LED Status Indicators
Orange The AC/DC Adapter is Plugged In
Green The Computer is On
Blinking
Green
Orange The Battery is Charging
Green The Battery is Fully Charged
Blinking
Orange
Table 2 - LED Power Indicators
The Computer is in Sleep Mode
The Battery Has Reached Critically
Low Power Status
English
7
Hot-Key Buttons - Some Model
Function Keys
NumLk &
ScrLk
Models B & C
Model A
Numeric
Keypad
Fn Key
Function Keys
NumLk &
ScrLk
Numeric
Keypad
Fn Key
Keyboard
A Designs Only
The Hot-Key buttons give instant access to the default Internet browser and e-mail program, and allow you to toggle the Silent Mode/the WLAN module on/off with one
quick button press.
English
Hot-Key Button Function
*Activate the Default E-Mail Browser
Activate the Default Internet Program
**Toggle Silent Mode
*Note that In Windows 7 without Outlook/Outlook Express
installed this button has no function. If Outlook/Outlook Express
are installed then the button will activa te the application.
**When enabled, Silent Mode will reduce fan noise and save
power consumption. Note this may reduce computer performance.
or
WLAN Module Power Toggle
or
The keyboard (Model A) has a numeric keypad for easy
numeric data input. Pressing Fn + NumLk turns on/off
the numeric keypad. It also features function keys to allow you to change operational features instantly.
The keyboard (Models B & C) includes a numeric keypad (on the right side of the keyboard) for easy numeric
data input. Pressing Fn + NumLk turns on/off the numeric keypad. It also features function keys to allow you
to change operational features instantly.
Table 3 - Hot-Key Buttons - Some Model A Designs Only
8
Figure 4 - Keyboard
Function Keys
The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the
basic function key combinations, visual indicators are available when the hot key driver is installed.
Keys Function/Visual Indicators Keys Function/Visual Indicators
Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F8/F9
Fn +
(Models A &
B Only)
Fn + F1 Touchpad Toggle Fn + F11
Fn + F2
Fn + F3 Mute Toggle Fn + NumLk Number Lock Toggle
Fn + F4 Sleep Toggle Fn + ScrLk Scroll Lock Toggle
Fn + F5/F6
Fn + F7 Display Toggle Fn + Esc Control Center Toggle (see page 10)
3G Module Power Tog-
gle
(Press a key to or use Touchpad to turn on)
Volume Decrease/
Increase
Turn LCD Backlight Off
Fn + F10
Fn + F12
Caps Lock Caps Lock Toggle
Brightness Decrease/
Increase
PC Camera Power
Toggle
WLAN Module Power
Toggle
Bluetooth Module
Power Toggle
Table 4 - Function Keys & Visual Indicators
English
9
Control Center
Wireless & Bluetooth
Modules are Off
Press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to toggle the
Control Center on/off. The Control Center gives quick access to frequently used controls, and enables you to quickly
turn modules on/off.
English
Figure 5 - Control Center
Click on any button to turn any of the modules (e.g. TouchPad, Camera) on/off. Click on Power Conservation to switch
between Performance, Balanced or Energy Star modes. Click on the buttons (or just click and hold the mouse button)
to adjust the slider for Brightness/Volume. Click on Display Switch/Time Zone/ Desktop Background to bring up
the appropriate Windows control panel. Click on the Sleep button to put the computer into Hibernate or Sleep modes.
10
Power Modes
You can set a Power Mode by clicking the appropriate icon at the top of the Control Center. Each power mode will
affect the power status of modules (e.g. WLAN, 3G or Camera), screen brightness, Touchpad power and Silent Mode.
You can click a Control Center icon to set an overall power mode and then click individual icons in the Control Cen-
ter to power on/off any modules etc.
Table 5 illustrates the basic settings for each power mode. If you choose User Defined the settings will correspond to
your selected system settings.
English
Modes
Icon
Power Plan Power Saver Balanced Power Saver Power Saver
Power Conservation Mode Energy Star BIOS Default Energy Star Energy Star Performance
Brightness 14 42 100 42 100
WLAN OFF OFF ON ON ON
3G OFF OFF OFF OFF OFF
PC Camera OFF OFF OFF ON ON
Touchpad ON ON ON ON ON
Power
Saving
Flight Entertainment Quiet Performance User Defined
High Perfor-
mance
Table 5 - Power Modes
User Defined
11
Power Status
The Power Status icon will show whether you are currently powered by the battery, or by the AC/DC adapter plugged
in to a working power outlet. The power status bar will show the current battery charge state.
Brightness
The Brightness icon will show the current screen brightness level. You can use the slider to adjust the screen brightness
or the Fn + F8/F9 key combinations, or use the Fn + F2 key combination to turn off the LED backlight (press any key
to turn it on again). Note that screen brightness is also effected by the Power Mode selected.
English
Volume
The Volume icon will show the current volume level. You can use the slider to adjust the volume or the Fn + F5/F6
key combinations, or use the Fn + F3 key combination to mute the volume.
Power Conservation
This system supports Energy Star power management features that place computers (CPU, hard drive, etc.) into a lowpower sleep mode after a designated period of inactivity. Click either the Performance, Balanced or Energy Star but-
ton.
Sleep
Click the Sleep button to bring up the Hibernate or Sleep buttons, and click either button to have the computer
enter the appropriate power-saving mode.
12
Display Switch
Click the Display Switch button to access the menu (or use the + P key combination) and select the appropriate
display mode.
Time Zone
Clicking the Time Zone button will access the Date and Time Windows control panel.
Desktop Background
Clicking the Desktop Background button will allow you to change the desktop background picture.
Touchpad/PC Camera/Wireless LAN Module /Bluetooth/3G Module
Click any of these buttons to toggle the Touchpad or module’s power status. A crossed out icon will appear over the top
left of the icon when it is off
Power Mode selected.
. Note that the power status of a module, and Touchpad power, is also effected by the
Caps Lock/Scroll Lock/ Number Lock
Click the button to toggle the appropriate lock mode.
English
13
System Map: Front, Left, Right, Rear & Bottom Views (Model A)
2
1
7
8
4
6
3
Left
Right
5
Front
Rear
10
6
12
15
11
18
Bottom
13
14
6
9
7
17
7
17
16
7
7
14
Figure 6 - Front, Left, Right, Rear & Bottom Views (Model A)
1. LED Power Indicators
2. DC-In Jack
3. External Monitor Port
4. RJ-45 LAN Jack
5. HDMI-Out Port
6. 3 * USB 2.0 Ports
7. Vent
8. Multi-in-1 Card Reader
9. Microphone-In Jack
10. Headphone-Out Jack
11. Optical Device Drive Bay
12. Emergency Eject Hole
13. Security Lock Slot
14. Battery
15. Component Bay Cover
16. Hard Disk Bay Cover
17. Speakers
18. USIM Card Cover
(Optional)
Overheating
To prevent your computer from overheating make
sure nothing blocks any vent while the computer is in
use.
CPU
The CPU is not a user serviceable part. Accessing the
CPU in any way may violate your warranty.
Bottom Covers
If your model includes the 3G option then a small cover to enable you to access the module’s USIM
card will be included (see page 16).
18
English
14
System Map: Front, Left, Right, Rear & Bottom Views (Model B)
2
1
7
8
4
6
3
Left
Right
5
Front
Rear
10
6
13
11
14
12
6
9
15
14
7
Bottom
16
17
7
17
18
Figure 7 - Front, Left, Right, Rear & Bottom Views (Model B)
1. LED Power Indicators
2. DC-In Jack
3. External Monitor Port
4. RJ-45 LAN Jack
5. HDMI-Out Port
6. 3 * USB 2.0 Ports
7. Vent
8. Multi-in-1 Card Reader
9. Microphone-In Jack
10. Headphone-Out Jack
11. Optical Device Drive Bay
12. Emergency Eject Hole
13. Security Lock Slot
14. Battery
15. Component Bay Cover
16. Hard Disk Bay Cover
17. Speakers
18. USIM Card Cover
(Optional)
Disc Emergency Eject
If you need to manually eject a disc (e.g. due to an unexpected power interruption) you may push the end of
a straightened paper clip into the emergency eject
hole. Do not use a sharpened pencil or similar object
that may break and become lodged in the hole.
Bottom Covers
If your model includes the 3G option then a small cover to enable you to access the module’s USIM
card will be included (see page 16).
18
English
15
System Map: Front, Left, Right, Rear & Bottom Views (Model C)
Figure 8 - Front, Left, Right, Rear & Bottom Views (Model C)
1. LED Power Indicators
2. DC-In Jack
3. External Monitor Port
4. RJ-45 LAN Jack
5. HDMI-Out Port
6. 3 * USB 2.0 Ports
7. Vent
8. Multi-in-1 Card Reader
9. Microphone-In Jack
10. Headphone-Out Jack
11. Optical Device Drive Bay
12. Emergency Eject Hole
13. Security Lock Slot
14. Battery
15. Component Bay Cover
16. Hard Disk Bay Cover
17. Speakers
Disc Emergency Eject
If you need to manually eject a disc (e.g. due
to an unexpected power interruption) you
may push the end of a straightened paper
clip into the emergency eject hole. Do not
use a sharpened pencil or similar object that
may break and become lodged in the hole.
17
7
Bottom
7
1
7
6
4
6
3
Left
Right
5
Front
Rear
10
12
13
11
8
14
15
7
7
9
14
17
7
16
7
6
2
English
16
3G Module
123
1
3
2
(Models A & B Only)
If you have included an optional 3G module in your purchase option, follow the instructions below to install the
USIM card (which will be provided by your service provider), and then run the appropriate application supplied
with your module.
USIM Card Insertion
1. Turn off the computer, and turn it over and remove the battery
(slide the latches in the direction indicated below and slide
the battery out).
2. Locate the SIM card cover and loosen screw and remove
the SIM card cover .
3. Insert the USIM card as you would into your mobile phone.
4. Slide the SIMLOCK towards the hinge (in the direction to the
arrow illustrated in Figure 10) in order to release the lock and
lift it up.
5. Insert the USIM card and close the SIMLOCK.
English
Figure 10 - Unlock the SIMLOCK
6. Lock the SIMLOCK by pushing it in the direction of the arrow in
Figure 11 until it clicks into the lock position.
Figure 11 - Lock the SIMLOCK
7. Replace the cover, screw and battery.
Figure 9 - Battery & SIM Card Cover Removal
17
Driver Installation General
Guidelines
As a general guide follow the
default on-screen instructions for each driver (e.g.
Next > Next > Finish) unless
you are an advanced user. In
many cases a restart is required to install the driver.
Make sure any modules (e.g.
PC Camera, WLAN or 3G)
are ON before installing the
appropriate driver.
Windows Update
After installing all the drivers
make sure you enable Win-
dows Update in order to get
all the latest security updates
etc. (all updates will include
the latest hotfixes from Mi-
crosoft).
Driver Installation & Power
When installing drivers make sure
your computer is powered by the
AC/DC adapter connected to a
working power source. Some drivers draw a significant amount of
power during the installation procedure, and if the remaining battery
capacity is not adequate this may
cause the system to shut down and
cause system problems (note that
there is no safety issue involved
here, and the battery will be rechargeable within 1 minute).
English
18
Driver Installation
The Device Drivers & Utilities + User’s Manual disc contains the drivers and utilities
necessary for the proper operation of the computer. This setup will probably have already been done for you. If this is not the case, insert the disc and click Install Drivers
(button), or Option Drivers (button) to access the Optional driver menu. Install the
drivers in the order indicated in Figure 12. Click to select the drivers you wish to
install (you should note down the drivers as you install them). Note: If you need to
reinstall any driver, you should uninstall the driver first
If the Found New Hardware wizard appears during the installation procedure, click
Cancel to close the window, and follow the installation procedure as directed.
Figure 12 - Install Drivers
.
Troubleshooting
Problem Possible Cause - Solution
The Wireless LAN/
Bluetooth/3G modules
cannot be detected.
The Bluetooth module is off
after resuming from Sleep.
A file cannot be copied to/
from a connected Bluetooth
device.
The captured video files from
the PC Camera are taking up
too much disk space.
The modules are off. Check the LED indicator and/or function key indicator to see if the WLAN/
Bluetooth/3G module is on or off (see Table 1 on page 7 and Table 4 on page 9). If the LED
indicator is off, then press the Fn + F11 (WLAN), Fn + F12 (Bluetooth) or Fn + (3G) in order to
enable the modules (see Table 4 on page 9).
The Bluetooth module’s default state will be off after resuming from the Sleep power-saving state.
Use the key combination (Fn + F12) to power on the Bluetooth module after the computer resumes
from Sleep.
Transferring data between the computer and a Bluetooth enabled device is supported in one
direction only (simultaneous data transfer is not supported). If you are copying a file from your
computer to a Bluetooth enabled device, you will not be able to copy a file from the Bluetooth
enabled device to your computer until the file transfer process from the computer has been
completed.
Note that capturing high resolution video files requires a substantial amount of disk space for each
file.
Note that the Windows system requires a minimum of 15GB of free space on the C: drive system
partition. It is recommended that you save the capture video fil e to a loca tion ot her than the C:drive,
limit the file size of the captured video or reduce video resolution (Options > Video Capture Pin...
> Output Size).
English
19
Specifications
Latest Specification Information
The specifications listed in this here
are correct at the time of going to
press. Certain items (particularly
processor types/speeds) may be
changed, delayed or updated due to
the manufacturer's release schedule. Check with your service center
for details.
Processor
BIOS
English
Intel® Celeron® 847 Processor
1.10GHz, 32nm, 2MB L3 Cache, DDR3-
1333MHz, TDP: 17W
Intel® Celeron® 877 Processor
1.40GHz, 32nm, 2MB L3 Cache, DDR3-
1333MHz, TDP: 17W
Display
Model A - Designs I & III:
14” (35.65cm) HD (Thickness: 5.2mm)
Model A - Design II:
14” (35.65cm) HD (Thickness: 3.6mm)
Model B:
15.6” (39.62cm) HD
Model C:
17.3" (43.94cm) HD+ / FHD
Core Logic
Intel® NM70 Chipset
Memory
Two 204 Pin SO-DIMM Socket Supporting
DDR3 1333/1600MHz Memory (The real
memory operating frequency depends on the
FSB of the processor)
Memory Expandable up to 8GB
One 48Mb SPI Flash ROM
AMI BIOS
Video Adapter
Intel® HD Graphics
Dynamic Frequency (Intel Dynamic Video
Memory Technology for up to 1.7GB)
Microsoft DirectX®10.1 Compatible
Audio
High Definition Audio Compliant Interface
2 * Built-In Speakers
Built-In Microphone
Storage
(Factory Option) One Changeable
12.7mm(h) Super Multi Optical Device Drive
(Factory Option) Dummy ODD (Some
Model A designs and some Model B
designs Only)
One Changeable 2.5" 9.5mm (h) SATA
HDD
20
Interface
Communication
Mini Card Slots
Three USB 2.0 Ports
One Headphone-Out Jack
One Microphone-In Jack
One External Monitor Port
One HDMI-Out Port
One RJ-45 LAN Jack
One DC-in Jack
Security
Kensington Lock Slot
BIOS Password
Keyboard
Model A:
“WinKey” keyboard (with embedded
numeric keypad)
Models B & C:
Full-size “WinKey” keyboard (with numeric
keypad)
Pointing Device
Built-in Touchpad
10Mb/100Mb Ethernet LAN
(Factory Option - Models A & B) 300K
Pixel
/2M HD PC Camera Module
(Factory Option - Model C) 2M HD PC
Camera Module
(Factory Option) 3G Mini-Card Module
(Models A & B Only)
WLAN/ Bluetooth Half Mini-Card
Modules:
(Factory Option) Intel® Centrino® Wireless-N 105 Wireless LAN (802.11b/g/n)
(Factory Option) Intel® Centrino® Wireless-N 135 Wireless LAN (802.11b/g/n) +
Bluetooth 3.0
(Factory Option) Third-Party Wireless LAN
(802.11b/g/n)
(Factory Option) Third-Party Wireless LAN
(802.11b/g/n) + Bluetooth 4.0
Card Reader
Embedded Multi-In-1 Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD
MS (Memory Stick) / MS Pro / MS Duo
Models A & B:
Slot 1 for WLAN Module or WLAN and
Bluetooth Combo Module
(Factory Option) Slot 2 for 3G Module
Model C:
Slot 1 for WLAN Module or WLAN and
Bluetooth Combo Module
Power
Model A:
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19V, 3.42A/18.5V, 3.5A (65W)
Removable 6 Cell Smart Lithium-Ion Battery Pack, 48.84WH
(Factory Option) Removable 3 Cell Smart
Lithium-Ion Battery Pack, 24.42WH
(
Factory Option) Removable 6 Cell Smart
Lithium-Ion Battery Pack, 62.16WH
Models B & C:
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19V, 3.42A/18.5V, 3.5A (65W)
Removable 6 Cell Smart Lithium-Ion Battery Pack, 48.84WH
(
Factory Option) Removable 6 Cell Smart
Lithium-Ion Battery Pack, 62.16WH
English
21
Environmental Spec
Dimensions & Weight
Temperature
Operating: 5
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
°C - 35°C
English
Model A Design I:
340mm (w) * 238mm (d) * 25.05 - 33.5mm
(h)
2.2kg with 48.84WH Battery & ODD
Model A Design II:
340mm (w) * 238mm (d) * 13.9 - 31.8mm
(h)
340mm (w) * 238mm (d) * 12 - 30.2mm (h)
2.2kg with 48.84WH Battery & ODD
Model A Design III:
341mm (w) * 238.5mm (d) * 16 - 34mm (h)
(h)
2.2kg with 48.84WH Battery & ODD
Model B Design I:
374mm (w) * 250mm (d) * 20 - 37.2mm (h)
2.6kg with 48.84WH Battery & ODD
Model B Design II:
374mm (w) * 238mm (d) * 14.3 - 34.1mm
(h)
2.3kg with 48.84WH Battery & ODD
Model C:
413mm (w) * 270mm (d) * 14 - 40.5mm (h)
2.9kg (with 48.84WH Battery and ODD)
22
Über das Ausführliche Benutzerhandbuch
Diese Kurzanleitung soll einen Überblick über die Schritte geben, die dazu notwendig s ind, das System zu starten. Dieses ist
nur eine Ergänzung und kein Ersatz für das erweiterte englischsprachige Benutzerhandbuch, das auf der mitgelieferten Disc
Device Drivers & Utilities + User's Manual im Adobe-Acrobat-Format vorliegt. Diese Disc enthält auch die Treiber und
Utility-Programme, die für einen einwandfreien Betrieb des Computers notwendig sind (Hinweis: Das Unternehmen behält
sich das Recht vor, diese Publikation ohne Vorankündigung zu überarbeiten und den Inhalt zu verändern).
Einige oder alle Funktionen des Computers sind bereits eingerichtet worden. Falls das nicht der Fall ist oder wenn Sie einzelne Teile des Systems neu konfigurieren (oder neu installieren) möchten, finden Sie eine Anleitung im erweiterten Benut-
zerhandbuch. Die Disc Device Drivers & Utilities + User's Manual enthält nicht das Betriebssystem.
Einhaltung gesetzlicher Vorschriften und Sicherheitshinweise
Beachten Sie sorgfältig die Hinweise zu gesetzlichen Vorschriften und zu Sicherheitshinweisen im erweiterten Benutzerhandbuch auf der Disc Device Drivers & Utilities + User's Manual.
© September 2012
Warenzeichen
Intel und Celeron sind warenzeichen/eingetragenes warenzei chen de r Intel Corporation.
Deutsch
23
Hinweise zu Pflege und Betrieb
Das Notebook ist zwar sehr stabil, kann aber dennoch beschädigt werden. Damit es nicht dazu kommt, sollten Sie die
folgenden Hinweise beachten:
• Das Gerät darf nicht herunterfallen und in anderer Form Stößen
ausgesetzt werden. Wenn der Computer fällt, können das Gehäuse und
andere Komponenten beschädigt werden.
• Das Gerät darf nicht nass werden und sich nicht überhitzen. Computer und Netzteil dürfen nicht in der Nähe von Wärmequellen stehen oder
gelagert werden. Dies ist ein elektrisches Gerät. Wenn Wasser oder
andere Flüssigkeiten eindringen, kann der Computer stark beschädigt
werden.
• Vermeiden Sie Interferenzen mit anderen Geräten. Halten Sie den
Computer fern von magnetischen Feldern, die von Stromquellen, Monitoren, Magneten etc. erzeugt werden. Die können die Leistung beein-
Deutsch
trächtigen und Ihre Daten beschädigen.
• Achten Sie auf die richtige Bedienung des Computers. Schalten Sie
ihn erst aus, wenn alle Programme geschlossen wurden (speichern Sie
Ihre Daten!). Speichern Sie regelmäßig Ihre Daten, da diese verloren
gehen können, wenn der Akku verbraucht ist.
Reparatur
Nehmen Sie vor dem Reinigen des Wenn Sie versuchen, den
Computer selbst zu reparieren, können Ihre Garantieansprüche
verloren gehen. Außerdem besteht Stromschlaggefahr für Ihre
Gesundheit und das Gerät durch frei liegende Teile. Lassen Sie
Reparaturarbeiten nur von qualifizierten Reparaturfachleuten
durchführen, insbesondere wenn folgende Umstände vorliegen:
• Wenn das Netzkabel oder der AC/DC-Adapter beschädigt od er zers ch li s sen sind.
• Wenn der Computer Regen ausgesetzt war oder mit Flüssigkeiten in
Berührung gekommen ist.
• Wenn der Computer unter Beachtung der Bedienungsanweisungen nicht
korrekt arbeitet.
24
• Wenn der Computer heruntergefallen ist oder beschädigt wurde (berühren Sie nicht die giftige Flüssigkeit des LCD-Bildschirms).
• Wenn ein ungewöhnlicher Geruch, Hitze oder Rauch aus dem Computer
entweicht.
Sicherheitsinformationen
• Verwenden Sie nur einen AC/DC-Adapter, der für die Verwendung mit
diesem Computer zugelassen ist.
• Verwenden Sie nur das Netzkabel und die Akkus, die in diesem Benutzerhandbuch spezifiziert sind
Sie können explodieren. Richten Sie sich nach den regional gültigen Entsorgungsvorschriften.
• Verwenden Sie den Akku nicht mehr , wenn er heruntergefallen ist oder in
anderer Weise beschädigt (z.B. verzogen) ist. Auch wenn der Computer
mit dem beschädigten Akku zu funktionieren schein, können dadurch
Stromkreise beschädigt werden, die schließlich einen Brand verursachen
können.
• Achten Sie darauf, dass Ihr Computer ausgeschaltet ist, wenn Sie es fur
den Transport z.B. wahrend einer Reise in eine Tasche einpakken.
• Nehmen Sie vor dem Reinigen des Computers den Akku heraus, und
trennen Sie es von allen externen Stromquellen, Peripheriegeräten und
Kabeln (einschließlich Telefonkabel) ab.
• Reinigen Sie den Computer mit einem weichen, sauberen Tuch. Tragen
Sie das Reinigungsmittel nicht direkt auf den Computer auf. Verwenden
Sie keine flüchtigen Reinigungsmittel (Petroleumdestillate) oder Scheuermittel zum Reinigen des Computers.
• Versuchen Sie nicht, Akkus zu reparieren. Lassen Sie die Akkupacks
durch den Servicevertreter oder qualifiziertes Fachpersonal reparieren
oder austauschen.
• Beachten Sie, dass das Logo bei den Computern, die über ein galvanisch
beschichtetes LCD-Logo verfügen, von einer Schutzfolie bedeckt ist.
Durch die natürliche Abnutzung kann diese Schutzfolie beschädigt werden oder abgehen und die scharfen Kanten des frei liegenden Logos
freigeben. Seien Sie in solch einem Fall vorsichtig bei der Handhabung
des Computers, und vermeiden Sie es, das herausstehende beschichtete
LCD-Logo zu berühren. Legen Sie keine Gegenstände in die Tragetasche, da diese während des Transports gegen den Computer drücken
können. Wenden Sie sich in einem solchen Fall von Abnutzung an Ihr
Service Center.
. Entsorgen Sie die Akkus nicht in Feuer.
Polymer Akku Sicherheitshinweise
Entsorgen der Akkus/ Batterien & Achtung
Das von Ihnen gekaufte Produkt enthält einen aufladbaren Akku. Dier
Akku ist wiederverwertbar. Nach verschieden en nationalen und regionalen Getzgebungen kann es verboten in, einen nicht mehr
gebrauchsfähigen Akku in den normalen Hausmüll zu werfen. Informieren Sie sich bei Ihrem regionalen Entsorgungs unternehmen über
Recycling-Möglichkeiten oder korrekte Entsorgung.
Wenn ein falscher Akku eingesetzt wird, besteht Explosionsgefahr.
Tauschen Sie den Akku nur durch den gleichen oder einen baugleichen
Typ aus, der vom Hersteller e mpfohlen wird. Entsorgen Sie den ver brauchten Akku entsprechend der Anweisungen des Herstellers.
Beachten Sie die folgenden Hinweise, die sich speziell auf
Polymer Akkus beziehen. Diese Hinweise haben zudem Vorrang gegenüber den Allgemeinen Akku Sicherheitshinweisen.
• Polymer Akkus können sich etwas ausdehnen oder anschwellen. Dies ist
Teil des Sicherheitsmechanismus des Akkus und kein Anlass zur Sorge.
• Seien Sie vernünftig im Umgang mit Polymer Akkus. Verwenden Sie
keine Polymer Akkus in Umgebungen mit hohen Temperaturen und
lagern Sie keine ungenutzten Akkus über längere Zeiträume.
Deutsch
25
Schnellstart
Herunterfahren
Bitte beachten Sie, daß
der Computer immer mit
dem Befehl Herunter-
fahren im Menü
Start
heruntergefahren werden muß.
Dadurch werden Festplatten- bzw. Systemprobleme vermieden.
130 ﾟ
1. Entfernen Sie das gesamte Verpackungsmaterial.
2. Legen Sie den Computer auf eine stabile Unterlage.
3. Setzen Sie den Akku ein, und stellen Sie sicher, dass sie fest sitzt.
4. Schließen Sie alle Peripheriegeräte, die Sie mit dem Computer
verwenden wollen (z. B. Tastatur und Maus), an die
entsprechenden Schnittstellen an.
5. Schließen Sie den AC/DC-Adapter an die DC-Eingangsbuchse an
der linken Seite des Computers an. Verbinden Sie dann das
Netzkabel mit einer Netzsteckdose und dem AC/DC-Adapter.
6. Klappen Sie den Deckel/LCD vorsichtig mit einer Hand auf, und
öffnen Sie ihn auf einen angenehmen Sichtwinkel (jedoch nicht
weiter als 130°). Mit der anderen Hand halten Sie das Unterteil
des Computers fest (siehe Abb. 1) (Hinweis: Heben Sie den
Deutsch
Computer niemals am Deckel/LCD hoch).
7. Drücken Sie auf den Netzschalter, um den Computer einzuschalten.
Systemsoftware
Möglicherweise wurde das Notebook bereits mit vorinstallierter Software ausgeliefert. Ist das nicht der Fall, oder
wenn Sie das Notebook für ein anderes System neu konfigurieren möchten, finden Sie dazu eine Anleitung in diesem
Handbuch zu Microsoft Windows 7.
Modellunterschiede
Diese Notebookserie umfasste verschiedene Modelle, die
sich leicht in Design, Farbe und allgemeinen äußeren
Merkmalen voneinander unterscheiden. Ihr Modell kann
zwar äußerlich von dem in dieser Dokument abgebildeten
Modell etwas abweichen, jedoch sind alle Ports, Anschlüsse,
Anzeigen, Spezifikationen und allgemeinen Funktionen bei
allen Modellen gleich.
Abb. 1 - Öffnen des Deckels/LCD/Computers mit ange-
schlossenem AC/DC-Adapter
26
Systemübersicht: Ansicht von vorne mit geöffnetem LCD-Bildschirm
8
Die Benutzung drahtlos
angeschlossener
Geräte in Flugzeugen
In der Regel ist die Benutzung jeglicher tragbarer
elektronischer Funkgeräte in Flugzeugen verboten. Achten Sie
darauf, daß die
Wireless-Module AUSGESCHALTET sind,
wenn Sie den Computer
im Flugzeug benutzen.
Drücken Sie die entsprechenden
Tastenkombinationen, um
jeweils das 3G-, das
WLAN- oder das Bluetooth-Modul zu aktivieren. Prüfen Sie anhand
der LED-Anzeigen/visuellen Anzeigen, ob die
Module eingeschaltet sind
(siehe Tabelle 4 auf
Seite 31).
Abb. 2
Ansicht von vorne mit ge-
öffnetem LCD-Bildschirm
(Modell A)
1. PC-Kamera (optional)
2. LCD-Bildschirm
3. Netzschalter
4. Hot-Key-Tasten (nur
einige Designs des
Modells A)
5. LED-Statusanzeigen
6. Tastatur
7. Mikrofon
8. Touchpad mit Tasten
Beachten Sie, dass der Funktionsbereich des Touchpads
und der Tasten innerhalb der
rot gepunkteten Linien liegt.
4
6
3
5
7
1
8
2
14” (35,56cm)
(Modell A)
Deutsch
27
