ELOX SERIES

BT-04B-U3//ITX TOWER

Product

M/B support

Color

BT-04B-U3 - Elegant technology that convinces any time! As a desktop or

tower, the ITX case fits all individual requirements. Even what the equipment
concerns, you don’t need to do be afraid of any down strokes. With the
possibility of installing two graphic cards, the gnome is the perfect solution of
being a gaming machine for instance.

Features

Technical Data

M/B Support:

Dimension (DxWxH):

Weight:

Drive Bays external:

Drive Bays internal:

Power supply:

Front I/O:

computer case

mini ITX

black

Mini ITX

240mm x 135mm x 323mm

3,50 Kg with PSU

1x 5,25“ Slim Line

2x 2,5“ or 1x 2,5“ + 1x 3,5“

250Watt SFX Power supply (CSM-250P)

2x USB 3.0, mic-in, Audio-out (AZALIA / HD-Audio)

Expansion Slots:

Material:

Cooling (optional):

CPU cooler height (max.):

Special features

Ergonomically positioned front interfaces

250Watt SFX Powersupply (CSM-250P) included

Suitable for one slim line 5,25” ODD

Two expansion slot for PCI/PCIe cards

Space saving

2

SECC, 0,6mm

1x 80mm on the front / 2x60mm on the rear

~60mm with 3,5“ HDD/SSD / ~70mm with 2,5“ HDD/SSD

The listed specifications may be altered at any point in time without any pre-notice. Chieftec® is a registered trade mark. All other brands and/or logos are property of the respective owners.
