Page 1
INSTALLATION INSTRUCTIONS
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Outdoor Casters Accessory
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
PAC775
Page 2
PAC775 Installation Instructions
Tighten Fastener
Apretar elemento de fijación
Befestigungsteil festziehen
Apertar fixador
Serrare il fissaggio
Bevestiging vastdraaien
Serrez les fixations
Loosen Fastener
Aflojar elemento de fijación
Befestigungsteil lösen
Desapertar fixador
Allentare il fissaggio
Bevestiging losdraaien
Desserrez les fixations
TOOLS AND PARTS REQUIRED FOR INSTALLATION
B (2)
A (2)
[4" caster] [4" caster w/brake]
DISCLAIMER
Milestone AV Technologies and its affiliated corporations and
subsidiaries (collectively "Milestone"), intend to make this
manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Milestone
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Milestone assumes
no responsibility for accuracy, completeness or sufficiency of
the information contained in this document.
Chief® is a registered trademark of Milestone AV T echnologies.
All rights reserved.
IMPORTANT WARNINGS AND
CAUTIONS!
WARNING:
serious injury or death if you do not follow the instructions.
A WARNING alerts you to the possibility of
CAUTION:
damage or destruction of equipment if you do not follow the
corresponding instructions.
WARNING:
follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all components are
properly assembled and installed using the instructions
provided.
WARNING:
for this component can result in serious personal injury or
damage to equipment! It is the installer’s responsibility to
make sure the structure to which this component is attached
can support five times the combined weight of all equipment.
Reinforce the structure as required before installing the
component.
WARNING:
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components does not exceed the maximum allowable
weight of the mount to which this accessory is being installed.
A CAUTION alerts you to the possibility of
Failure to read, thoroughly understand, and
Failure to provide adequate structural strength
Exceeding weight capacity can result in
LEGEND
2
Page 3
Installation Instructions PAC775
1
x 4
(A) x 2
2
(A)
Cart
Leg
(B) x 2
3
Cart
Leg
4
(B)
ASSEMBLY
1. Using a wrench, loosen the bolts and remove the four
casters currently installed on the cart. (See Figure 1)
Figure 1
2. Place casters (A) on front of cart and tighten bolts. (See
Figure 2)
3. Place locking casters (B) on rear of cart and tighten bolts.
(See Figure 3)
Figure 3
4. Lock rear casters (B) by stepping on top edge at
BRAKE ON imprint. (See Figure 3)
5. Unlock rear casters (B) by stepping on the OFF button on
top edge of caster.
Figure 2
3
Page 4
PAC775 Installation Instructions
Chief Manufacturing, a products division
of Milestone AV Technologies
8809-002001 REV 01
©2009 Milestone AV Technologies, a
Duchossois Group Company
www.chiefmfg.com
05/09
