automated mounts
cm6dV CABINET ACCESSORY
1
2
FEATURES
EAsy instAllAtion
1
Ships with motor box pre-mounted onto track
for quick and easy installation.
AutoMAtED light Control
Lighting can be dimmed by remote control.
intEgrAtED sAFEty Control
2
Motor stops and reverses doors if travel is
obstructed.
loCk-out oPtion
Key switch can block access to part of the
wall unit.
MultiPlE Control oPtions
Control options include: dry contact
connections, 8 position RJ45 modular phone
jack, and IR remote (included).
Front view
WHAT YOU NEED TO KNOW
VoltaGe optIons
115V and 600W max for lighting
oRdeRInG optIons
Available in Standard and Custom lengths:
• CM6DV79 = Dual Vertical Panel Lift (79” track length)
• CM6DV83 = Dual Vertical Panel Lift (83” track length)
• CM6DV-xx = Custom Dual Vertical Panel Lift (custom track length)
RECOMMENDED ACCESSORIES
HOME THEATER APPLICATION
SPECIFICATIONS
Track Length 83” (210.8 cm)
Max Door Weight 50 lbs (22.7 kg)
Max Door Width 60” (152.4 cm)
Max Door Height 21” (533 mm)
Exposed Area 40.5” (102.9 cm)
(height)
Specifications given for CM6DV83.
TECHNICAL DRAWINGS
84
CLICK
www.chiefmfg.com
CALL
800.582.6480
Top view
FAX
877.894.6918
