Chevrolet 2012, Camaro Convertible 2012 User Manual

Review this Quick Reference Guide for an overview of some important features in your Chevrolet Camaro. More detailed information can be found in your Owner Manual. Some optional equipment described in this guide may not be included in your vehicle. For easy reference, keep this guide with your Owner Manual in your glove box.
denotes optional equipment www.chevrolet.com
2
Turn Signal Lever/Driver
Information Center Controls
Information Center
Windshield
Wipers Lever
Hood
Release
Lever
Tilt/Telescopic
Steering Wheel
Lever
Audio Steering
Wheel Controls
Cruise Control Buttons
Exterior/Interior
Lamps Control
INSTRUMENT PANEL
Safety Belt Reminder
Check Engine Low Tire Pressure Brake System
Warning Antilock Brake
System Warning
Charging System Oil Pressure Airbag Readiness Security Fog Lamps Cruise Control Set Traction Control Off
StabiliTrak/Traction Control Off
StabiliTrak/Traction Control Warning
Lights On
Head-Up
Display
Controls
3
* The accessory power outlet does not operate once the key is removed from the ignition and the driver’s door is opened.
Note: Refer to your Owner Manual to learn about the information being relayed by the lights, gauges and indicators of the instrument cluster, as well as what to do to ensure safety and prevent damage.
See Instruments and Controls in your Owner Manual.
Climate Controls/
Heated Seat Buttons
Audio
System
Auxiliary
Gauges
StabiliTrak
Button
Accessory Power
Outlet*
Hazard Warning Flashers Button/
Power Door Locks Button
4
REMOTE KEYLESS ENTRY TRANSMITTER
Unlock
Press to unlock the driver’s door only or all doors. The unlock setting can be changed in the Vehicle Settings menu by pressing the CONFIG button on the audio system.
Lock
Press to lock all doors. The driver’s door will not lock if open.
Trunk
Press and hold to unlatch the trunk.
Vehicle Locator/Panic Alarm
Press and release to locate your vehicle. The turn signal lamps will flash and the horn will sound.
Press and hold to activate the alarm. The turn signal lamps will flash and the horn will sound until the button is pressed again or the ignition is turned on.
Remote Vehicle Start
Use to start the engine from outside the vehicle.
REMOTE VEHICLE START
During a remote start, the vehicle’s climate control system will operate at the same setting as when the vehicle was last turned off and, based on outside temperature, the heated seats will turn on. The heated seats will turn off when the ignition is turned on.
Starting the Vehicle
1. Aim the Remote Keyless Entry transmitter at the vehicle. (Transmitter range depends on operating conditions.)
2. Press and release the Lock button on the transmitter.
3. Immediately press and hold the Remote Start button for at least two seconds. When the vehicle starts, the parking lamps will light and remain on while the engine is running. The engine will continue running for 10 minutes.
4. Repeat these steps for a 10-minute time extension. Remote start can be extended only once.
After a remote start, the ignition must be turned to the On position before driving.
Canceling a Remote Start
• Press and hold the Remote Start button until the parking lamps turn off.
Note: Several conditions will cause the Remote Vehicle Start feature not to operate, such as if the key is in the ignition or the hood or doors are not closed.
See Keys, Doors and Windows in your Owner Manual.
5
SEAT ADJUSTMENTS
HEAD-UP DISPLAY
A. Seat Adjustment
Move the horizontal control to move the seat forward or rearward and to raise, lower or tilt the seat.
B. Power Seatback Recline
Adjustment
Move the vertical control to recline or raise the seatback.
A. Seat Adjustment
Move the lever up or down repeatedly to raise or lower the seat.
B. Power Seatback Recline
Adjustment
Move the vertical control to recline or raise the seatback.
Seat Position
Lift the front handle to slide the seat forward or rearward.
See Seats and Restraints in your Owner Manual.
6-Way Power Seat Adjustment
(Driver and Front Passenger)
OFF
Turn the knob fully counterclockwise to turn off the display.
Brightness
Turn the knob to brighten or dim the display.
PAGE
Press the PAGE button on the knob to select one of three display formats.
Up/Down
Press the HUD up or down arrow button to adjust the up/down position of the display on the windshield.
See Instruments and Controls in your Owner Manual.
The Head-Up Display (HUD) projects a range of vehicle information on the windshield, reducing the need to look away from the road.
HUD Controls
4-Way Seat Adjustment
(Driver only)
AB
B
A
